HOLZ-HER CUT 6120 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: 3,900 mm (153.5") Max. rip cut cap., 3,900 mm (153.5") pull back pusher stroke; 82 mm (3.2") saw blade projection.15 HP (11 kW) Main saw motor, 1.5 HP (1.1 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 320 FPM (1 - 100 MPM ), return speed of 416 FPM (130 MPM).Motorized bi-directional grooving capabilities with electronic adjustment for 0 mm - 35 mm.Automatic cutting length limiter adjusts the cutting height & cutting length at the end of the workpiece. -- Pusher Fence:(7) Material gripper clamps, (1) Double Finger mounted at the cross-cut fence location for narrow strip cutting & (6) standard clamps. 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Variable pressure settings for delicate materials. Pressure beam has an integrated "Last Cut" operation to achieve a "0" mm panel dimension.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EASY-PLAN" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Moving Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."Opti-Cut" & "EASY-PLAN" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non-Marking rear roller support rails: Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm). Side aligner is "Fully Automatic" adjustment when panel is less than 1,300 mm (51")"Quick Change" Blade system with automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(3) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 23.6" (1,800 x 600 mm); -- Actual Model is HOLZ-HER CUT 6120 Dynamic

HOLZ-HER 1435-SE EDGEBANDERCartridge glue system, 5 mm edge thickness cap. (up to 8 mm w/optional tooling), automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff.Workstations: -- Double motor end trim (2) 0.3 HP - 9,000 RPM motor ea.), chamfers 0° - 10° -- Universal top & bottom fine trim (for bevels from 0° - 15°) allows simultaneous bevel & profile trimming, (2) 0.8 HP - 18,000 RPM motor each; all trim motors are 0.6 kW HF - 300 Cy. -- Top & bottom PVC scraper unit for 0.8 - 5 mm radius, with air jets for blowoff. -- Top & bottom "jump" buffing (0.3 HP - 1,620 RPM ea.). -- Single feed speed 35 FPM. --Complete with: --Built-in operator control panel, outboard panel support, frequency converter, used tooling, and sound enclosure.

HOLZ-HER - 1432, ...CP/B Edgebander (Compact) -- Cartridge glue system (single cartridge system); edge thickness cap.: 0.3 to 3 mm (1/8"); max. banding height: 2"; min. panel width: 60 mm; min. length: 180 mm.Equipped with: -- Semiautomatic feed magazine; coil stock feeds automatically with guillotine cutoff; all strip stock is fed manually with pusher bar to advance the edging.Workstations: -- Single motor end trim for leading & trailing edge (trim motor recently replaced). -- Top & bottom flush/bevel trim: 1 HP - 28,000 RPM Motor ea. (recently replaced with BOSCH Trimmer motors). -- Top & Bottom buffing unit: 0.3 HP - 1,620 RPM ea. motor; equipped with: Cotton flap wheels. -- Single feed speed: 16-1/2 FPM.Complete with: -- Sound/safety enclosure; outboard panel support. - Machine is on casters.

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging. Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM. -- Complete with: Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.

HOLZ-HER - 1619, ...Boring Machine (Construction & Line Boring) -- Specifications:(19) Spindles on 32 mm centers; bores vertically from top and horizontally from the rear; repositions via manual air shock assisted tilting.2 HP Motor with: 2,800 RPM Gear driven boring head. -- Features:4-Position turret style depth stop for boring depth and a 4-3/4" max. stroke of boring head.24-3/4" Working width; 27-1/8" max. panel width; 19-1/2"; x 38"; x 32-1/2"; H table size. -- Equipped & Complete with:RH & LH Indexing fence with flip stops; (2) indexing pins (for continuous line boring); (3) 4" dia. pneumatic holddown clamps; foot pedal actuator; magnetic push button starter. -- Actual Model is: HOLZ-HER 1619Dimensions of this specific machine with pallet: 52" x 40" x 65" H.Dimensions of this specific machine when vertical: 52" x 37" x 60" H.Dimensions of this specific machine when horizontal: 52" x 51" x 46" H.

HOLZMA PROFIMAT HPL 500 38/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Cutting length & pull-back; 6.7" (170 mm) max. main blade projection; 40 HP (29.8 kW) Main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Infinitely variable speed from 0 - 492 FPM (0 - 150 MPM), constant return of 492 FPM (150 MPM).Carriage is electronically & automatically controlled (cutting height & length) through the CADmatic according to the material/program being processed."Power-Loc" quick change system for fast and easy saw blade change.NC Controlled scoring saw adjustment from the control panel during operation -- Pusher Fence:Rack & pinion digital drives with AC Servos on both sides, forward speed 295 FPM (90 MPM), return speed 295 FPM (90 MPM).(7) Material clamps which open up to 6.7" (170 mm): (3) Standard clamps with two fingers & (4) clamps with one finger.(4) Trimming rakes for thin strips/scrap removal are attached at the clamps. -- Operator Interface:HOLZMA "Power Touch Control" IPC multi-tasking controller with Windows "7 PRO" + "CADmatic 4.0 PRACTIVE" operating system;Intel i5 Dual-core Processor, Intel HD graphics card, 4GB RAM, SATA 2-250GB hard drive, (6) USB ports, (1) serial port, ATI/DVI video port, Standard industrial keyboard connection,21.5" LCD "Touch-Screen" monitor with real-time moving 2D & 3D graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.(2) Ethernet 10/100 interface connections; downloading from office PC is possible. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (3) Air flotation tables 85" x 31.5" (2,160 x 800 mm) with (1) central blower unit. -- Rear Lift Table:7-Ton (14,000 LBS), 4-Column electro-hydraulic powered rear lift table running lengthwise with fork cut-outs, 150" x 63" (3,800 x 1,600 mm) capacity. Powered rollers are 4.2" (107 mm) dia x 7.79" (198 mm) spacing, 39 FPM (12 MPM) infeed/outfeed speed; Feeding material from (3) sides is possible with additional roller conveyors.22" (560 mm) Max. bunk height from floor level; 30.7" (780 mm) max. bunk height with a pit or risers; -- Complete With: Holzma's Unique "EcoPlus" System offers energy savings up to 20%; Includes Standby button & IE3 energy efficiency Motors rating.Angular cross-cut fence; Automatic side pressure device integrated into the saw carriage for cross-cutting, the machine cuts left to right to the cross-cut fence.Front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed.Min. side aligning dimension 0" (0 mm), max. side aligning dimension 149" (3,800 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Options Include: (1) Non-Powered in/out-feed staging conveyor with fork cut-outs as pictured. Micro In-feed for thin an

HOLZMA HPL 380 43/16 REAR LOAD, AUTOMATIC PANEL SAW + VrSS PPOST FORMING: -- Specifications169.2" (4,300 mm) Cutting length; 3.7" (95 mm) max. main blade projection; 28 HP (20.8 kW) main & 3 HP (2.2 kW) VrSS Post Form (Jump) scoring motor. -- Saw Carriage: Variable speed from 16 - 426 FPM (5 - 130 MPM); constant return of 426 FPM (130 MPM); electronically & automatically controlled through the CADmatic according to the material/program being processed. -- Pusher FenceRack & pinion drive on both sides: Forward speed 82 - 262 FPM (25 - 80 MPM); forward speed is currently set at 0 - 82 FPM (0 - 25 MPM) per CE standards; return speed 262 FPM (80 MPM).(6) Material clamps that open up to 3.9" (100 mm); 1st (2) clamps with: (2) Fingers and the others with (1) finger. -- Operator & Machine ControlHOLZMA "Power Control 22" IPC multitasking controller with: "Windows XP" + "CADmatic 4.0" Operating System.17" TFT Flat Screen display/monitor with: real-time moving graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.Standard industrial keyboard: CD ROM & 1.44 MB floppy drives; possible direct downloading from office PC through RS 232 or USB connection. -- Rear of MachineProfile rails & "Combi Rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent offset panels within the same book. -- Front of Machine(4) Air flotation tables: 85" x 25-1/2" (2,160 x 650 mm); (1) central blower unit. -- Rear Lift TableAutomatic 4-column electrohydraulic rear load lift table; 169.2" x 62.9" (4,300 x 1,600 mm) capacity; 4.2" dia. powered rollers; 39 FPM (12 MPM) infeed/outfeed speed.22.8" (580 mm) Max. bunk height without pit or risers; 30.7" (780 mm) max. bunk height with a pit or risers; 8,800 Lbs (4,000 kG) lift capacity. -- Complete with:Angular crosscut fence; side pressure device for crosscutting with front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed; min. side aligning dimension 0" (0 mm), max. side aligning dimension 169.2" (4,300 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Actual model is: HOLZMA Optimat HPL 380-43/16

HOLZMA HPP-11-32 OPTIMAT FRONT LOAD PANEL SAW:Specifications & features: 3,200 mm (126") Cutting length & pull-back behind the cutting line; 125 mm (4.9") saw blade projection; 30 HP (22.3 kW) main & 3 HP (2.2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 410 FPM (0 - 125 MPM), constant return of 410 FPM (125 MPM). -- Equipped with: Main blade 18" (450 mm) dia. and scoring blade 8" (200 mm dia.). -- Electronically controlled overhead pusher fence, rack & pinion drive on both sides by AC Servo motor; forward speed from 0 - 262 FPM (0 - 80 MPM), return speed of 262 FPM (80 MPM); equipped with (8) gripper clamps (open up to 4.7"). -- HOLZMA CADmatic Operating system; 15" color monitor (displays cutting dimensions); data input by keyboard or 1.44 MB floppy disk drive & downloading from office PC is possible. -- Control panel mounted on double swiveling arm for ergonomic positioning by the operator. -- Includes: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (3) air floatation tables, 85" x 26" (2,159 x 660 mm) each. -- Complete with: Angular square fence, automatic side aligner for crosscutting, (2) aligning devices on program fence; "Quick Saw Changing System" for main & scoring blade.

HOLZMA - Optimat HPP 350 31/31: Front Load Automatic Panel SawSpecifications -- 122" (3,100 mm) Cut length; 122" (3,100 mm) pull back; (80 mm) main saw blade projection; 12 HP (9 kW) main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment from the "CADMATIC 4.0" control. Saw Carriage --Travel speed from: 16 - 426 FPM (5 - 130 MPM); constant return: 426 FPM (130 MPM). Pusher Fence -- Overhead program fence with: (6) Gripper clamps; clamps open up to 90 mm (3-1/2"); rack & pinion drive on both sides; forward speed from 82 - 262 FPM (24 - 80 MPM); return speed: 262 FPM (80 MPM). Operator & Machine Control -- HOLZMA Power Control with: "CADMATIC 4.0" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory; TFT 17" flat screen monitor; REAL TIME moving graphics; panel grooving & numeric display. -- Industrial keyboard: 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC.Complete with: -- Automatic "CENTRIC" side aligner with: front & rear forks holding ripped strips squarely against the right angle fence. -- (3) Front air floatation tables: 86" x 25" (2,160 mm x 650 mm). -- Actual model: HOLZMA - OPT. HPP 350 31/31

HOLZMA - HPP 380 32/32: Front Load Automatic Panel SawSpecifications -- 126" (3,200 mm) Rip cutting capacity & pull back; 3.74" (95 mm) saw blade projection.18 HP (13.5 kW) Main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment via "CADMATIC" control. -- Saw CarriageVariable saw carriage travel speed from: 16 - 426 FPM (5 - 130 MPM); constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence; equipped with: (6) Clamps that open up to 100 mm (3.9").Rack & Pinion driven on both sides; forward speed: 262 FPM (80 MPM); return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with "CADMATIC" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.TFT 17" Flat Screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to an office PC. -- Complete with:Automatic "CENTRIC" side aligner with front & rear forks; holding ripped strips squarely against the right-angle fence.(3) Front air flotation tables; 67" x 25" (1.700 mm x 650 mm). Rear support rails with non-marking roller modules. -- Options include:Label Printer as pictured & label printing software -- Actual model is HOLZMA HPP 380 32/32.

HOLZMA - HPP 350 38/38: Front Load Automatic Panel Saw -- Specifications149.6" (3,800 mm) Cut length; 145.7" (3,700 mm) pull back; 3" (80 mm) saw blade projection. 18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 492 FPM (5 - 150 MPM); constant return 492 FPM (150 MPM). -- Pusher FenceOverhead program fence with: (7) Gripper clamps; clamps open up to 90 mm (3-1/2"); rack & pinion drive on both sides.Forward speed: 82 to 295 FPM (24 - 90 MPM); return speed: 295 FPM (90 MPM). -- Operator InterfaceHOLZMA "Power Control 22" with: "CADMATIC 4.0 PROFESSIONAL" + "Windows XP" operating system. Virtually unlimited cutting dimensions memory.TFT 19" flat Touchscreen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right angle fence.(3) Front air floatation tables: 85" x 31.-1/2 (2,160 mm x 800 mm). -- Options Include:Label Printer as pictured. -- Actual model - HOLZMA HPP 350 38/38.

HOLZMA - HPP 350 31/31: Front Load, Automatic Panel Saw -- Specifications122" (3,100 mm) Cut length; 122" (3,100 mm) pull back; 3" (80 mm) saw blade projection.18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 426 FPM (5 - 130 MPM); Constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence with: (6) Gripper clamps; clamps open up to 90 mm (3-1/2").Rack & Pinion drive on both sides; forward speed: 82 to 262 FPM (24 - 80 MPM); Return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with: "CADMATIC 4.0" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.17" TFT Flat screen monitor; REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with: Front & rear forks holding ripped strips squarely against the right angle fence.(1) Front air floatation tables: 86" x 25" (2,160 mm x 650 mm); (2) front air floatation tables: 69" x 25" (1.760 mm x 650 mm); rear support rails with non-marking rollers. -- Options include: ZEBRA "Z4M" Plus thermal label printer; (4) sets main/scoring blades; miscellaneous spare parts. -- Actual model: HOLZMA HPP 350 31/31

HOMAG - OPTIMAT BOF 211/30/R: Flat Tale Machine (w/ATC/Boring/C-Axis) -- Specifications4' x 10' Flat Matrix grid Phenolic working table. -- Working Field"X" Axis 120" (3.050 mm); "Y" axis 51" (1,300 mm); "Z" axis stroke 21" (535 mm); max material thickness 8.2" (210 mm). -- Positioning Speed"X" & "Y" Axis is 260 FPM (80 MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Unit4.2 HP (3 kW) Variable speed from 1,500 - 7,500 RPM; (12) independent vertical spindles: (6) in "X" axis & (6) in "Y" axis. -- Machining(1) 19.4 HP (14.5 kW) Liquid-Cooled electrospindle router with: HSK 63F Adaptor; variable speed from 1,000 - 24,000 RPM. -- (1) NC Controlled C-axis for 360° horizontal processing. -- (1) 12-Positon automatic tool changer mounted at the back of the head for "on the fly" ATC. -- Operator Interface PC Front-End with: "Homatic" PC 85 Power Control + Windows "NT" + WoodWOP Operating System. -- 14" Color graphic monitor; industrial keyboard for data entry; 1.44 MB & CD RW disk drives; EtherNET interface for possible LAN connection to office PC. -- USB & RS-232 Serial interface for simple PC connection. -- NUM (PLC) With 3D Linear interpolation; 4-axis control for "X", "Y" "Z" & "C" axes. -- All mounted in separate free-standing control cabinet. -- Complete with:(1) 40 HP DEKKER "VMX055" Vacuum Pump; safety fencing; safety mats (will stop machine if operator enters work area); handheld pendent control. -- Actual Model: HOMAG - OPTIMAT BOF 211/30/R

HOMAG CENTATEQ N 300 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 12' Flat Table "Bridge Gantry" machine with User-Friendly "MATRIX" grooved phenolic vacuum table. -- Working Area:"X" Axis is 145.7" (3,700 mm), "Y" axis 61" (1,550 mm), "Z" axis stroke Routing is 12.8" (325 mm), "Z" axis stroke Boring is 7.3" (185 mm) max. material thickness of 3.9" (100 mm). -- Positioning speed: "X" Axis is 236 FPM (72 MPM); "Y" axis is 203 FPM (62 MPM); "Z" axis 82 FPM (25 MPM). Machine head travels on THK linear motion guides on all axes. -- Worktable: (1) Pneumatic locator/positioning rail in "X" Axis & (1) pneumatic locator/positioning rail in "Y" Axis. - (10) NC Controlled Vacuum Table work zone. -- Boring Unit:3.6 HP (2.7 kW) motor, (12) Independent vertical spindles with "Quick Change" drill bit holders; programmable variable speed from 1,500 - 7,500 RPM. -- Machining:(1) 16 HP (12 kW) High-speed electro-spindle router with: "HSK F63" Adaptor; constant duty; variable speed from 1,250 - 24,000 RPM, RH or LH rotation.(1) 14-Position Rotary Tool Changer. -- Operator Interface:PC Front-End with: WEEKE "PC 85T" + Windows "10 PRO" + WoodWOP Operating System.17" TFT Color graphic monitor, keyboard for data entry, PC 85T hand control pendant; CD R/W & floppy drives, EtherNET interface for LAN connection to office PC, RS-232 serial interface, USB ports.BECKHOFF Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the Controller is contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (2) 9 HP BUSCH Mink MV 0312 B Vacuum Pumps. Light curtain (machine will stop if the operator enters the work area). Perimeter safety devices. Separate control cabinet. Touch-off tool length measuring device. Handheld pendant control. -- Actual Model is: HOMAG CENTATEQ N 300/512.

HOMAG KAL 310/7/A3/S2 EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING)Working Capacity: -- Edgebanding thickness in rolls (min/max) 0.3 - 3 mm. -- Panels thickness (min/max) mm 12 - 60 (1/2" through 2-3/8"). -- Feed speed (adjustable) 18 - 25 MPM (59 to 82 FPM). Front-End Equipped: -- In-feed fence, manual digital positioning. -- Pre-Milling Unit (vertical joint trimmers) (2) x 3 Kw each. -- Lamps to pre-heat the work pieces edge. -- Edge Magazine, vertical coil cart with 2 positions. -- Gluing Unit QA 34, EVA (Hot Melt) -- Side Pressure Zone, (3) rollers, adjustable by N.C. servo motor. Working Units: -- End Trimming Unit HL 81 Motors, 2 x Kw 0.22 (0.50 HP) -- Pre-Rough Trimming Unit: Top/Bottom, 2 x 0.55 Kw. (0.75 HP) 12,000 RPM motors, none tilt with digital indicator positioning. -- Multi Function Unit FK 11: Profile Contour Trimming, 2 x 0.4 Kw, 12000 RPM motors, for linear top/bottom edge trimming and vertical front/back corner rounding. -- Profile Edge Scraping Unit:Pneumatic in/out and manual digital indicator positioning. -- Glue Scraper:Top/Bottom, flat panel surface glue scraper. -- Buffing Unit: Top/Bottom oscillating buffing motors 2 x 0.25 Kw (0.35 HP).Operator & Machine Control: -- HOMATIC NC 21 controller, flat color LCD screen with keyboard and mouse input. Complete With: -- Top pressure system with rubber belt. -- Panel Support Outrigger. -- Sound and safety hoods over all working stations. Actual Model is HOMAG KAL 310/7/A3/S2

HOMAG EDGETEQ S 300 4.5 SERVO QUICK MELT EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + EVA/PUR Gluing Technology: SpecificationsRH Feed (BRANDT) Configuration: 0.4 - 3 mm (0.016 - 0.125") Coil cap.; 0.4 - 8 mm (0.016 - 0.315") edge strip cap.; 8 - 60 mm (0.32" - 2.4") panel thickness; 160 mm (6.3") min. panel length; 70 mm (2.76") min. panel width.Equipped with: Premilling Station: (2) Motors @ 2.25 kW (3.0 HP); 12.000 RPM; (1) clockwise & (1) counterclockwise rotation for chip-free and clean panel edges.Equipped with diamond cutter-heads. -- Infeed fence with: Servo motor positioning. -- Infrared "radiant quartz" Heating Unit: Between glue roller & pressure section. -- Automatic Edge Magazine for: Strip & coil stock; strips 0.4 mm - 8 mm (0.016 - 0.315"); coils up to 3 mm PVC; "HD" guillotine. -- QA-65N Gluing Unit for: PUR & EVA Glue with "Quick-Change" pot for maintenance, glue purging/color change. -- Pressure Section: 1st Roller driven plus (2) idle rollers; timed pneumatic pressure controlled; motorized positioning of the Pressure Zone. -- Feed Speed: Variable 8 - 14 MPM (26 - 46 FPM); 14 MPM (46 FPM) when contour trimming. -- HOMAG "Power Touch" Control: Full HD wide-screen multi-touch display; keyboard; mouse; Industrial PC.PLC Control according to IEC 61131 standards; USB connection at the operating panel; Ethernet connection 10/100 MBIT RJ45.WorkstationsStraight/Chamfer End Trimming: (2) Motors; each 0.35 kW (1/2 HP) - 12,000 RPM; automatic indexing for straight to bevel trimming from control panel. -- Multistage Fine Trimming "MS 40" Unit: Top/Bottom: (2) Motors; 0.55 kW (3/4 HP) - 12,000 RPM; equipped with: (2) Multi-Profile Radius cutter-heads; each with (4) Carbide insert knives. (4) Profile Options - Profile1, Profile2, Bevel, Flush trimming via the Program Control. Includes: Auto-tilt feature; Servo controlled to edge thickness; nesting top copy system. -- Multi-Function Contour Trimming/Corner Rounding Unit MF-50: (2) Motors with 0.4 kW (1/2 HP) - 12,000 RPM; dual purpose for CR; continuous Top & Bottom edge trimming with soft touch for high gloss panels. Servo motor control of the cutter: 2-Position automatic indexing for 1-mil, 2-mil & 3-mil thickness for: Leading & trailing edges' vertical corner rounding of panels.Equipped with: Radius cutters; HSK 25 System; 3 mm max. edge thickness. -- Scraping, multi-stage Profile Scraping Unit MZ 40 Top/bottom with Multi-Profile for: (2) Radii; 1 mm, 2 mm, or 3 mm in place of 2 mm; Servo control positioning of vertical & horizontal copy wheels.PVC Scrape Collection Box -- Finish Scraping Unit: Flush top/bottom on panel surface with floating insert knives. -- Buffing Unit: Top/bottom (2) motors; 0.10 kW (0.125 HP) - 2,800 RPM. -- Front/Rear Spray StationsComplete with:Motorized, programmable Top hold-down pressure beam; padded sound enclosure; isolation transformer for: Multiple input voltages; used tooling; Original Factory machine documentation. -- Actual Model: HOMAG EDGETEQ

HOMAG EDGETEQ S-380/1660 6.6 Edition EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR TEC" EVA/PUR GLUING TECHNOLOGY: Specifications:0.4 - 12 mm (0.016 - 0.47") edgeband thickness; 8 - 60 mm (0.31" - 2.36") panel thickness for EVA/PUR & 40 mm (1.57" )max for Air Tec" processing; 160 mm (6.25") min. panel length and 70 mm (2.75") min. panel width.Equipped with: Pre-Milling Station, (2) motors @ 2.25 kW (3.0 HP), 12.000 RPM, LH & RH rotation w/pneumatic jump control for chip-free and clean panel edges.Equipped with diamond cutter heads. -- In-feed Fence, with servo motor positioning. -- Infrared Radiant Quartz Heating Unit between glue roller and pressure section. -- Automatic Edge Magazine, for strip & coil stock, strips 0.4 mm - 12 mm (0.016 - 0.47"), coils up to 3 mm PVC and "HD" guillotine. -- QA-65N Quick Melt "AirTec" EVA/PUR pre-melter gluing technology with auto purging function, "Quick Change" Glue Tank for maintenance & glue color change. -- Pressure Section, 1st. roller driven plus (3) idle rollers, Lube spray unit on last pressure zone roller for high gloss peel coat processing; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speed, variable 8 - 20 MPM. (26 - 66 FPM), 14 MPM (46 FPM) when using contour trimming. -- HOMAG "Power Touch Control, Memory: 256 MB Ram, 1 GB Flash Card Drive.Operator control panel w/22" color HD wide screen, soft keypad & internal modem for remote diagnostic link.Workstations: End Trimming: - (2) Motor @ 0.35 kW (1/2 HP) 12,000 RPM, automatic chamfer from control panel 0°- 15°. -- MS-40 Multi-Stage Flush/Bevel-Fine/Radius Trimming Unit: - Top/bottom (2) motors, 0.55 kW (3/4 HP) 12,000 RPM, auto tilt positioning 0° - 25°, with combination flush/radius/chamfer cutter-heads.Horizontal and vertical tracing wheels, equipped with brushless multi-axis Servo motors for positioning of work-unit & horizontal copy wheels for quick changeover. Includes (4) positioning options, profile 1, profile 2 = bevel and flush trimming. Auto-tilt and servo control for edge thickness. Nested top copy system. -- MF-50 Multi-Function Contour/Corner Rounding Unit: (2) Motors 0.35 kW (1/2 HP) 12,000 RPM, with "soft touch" Magnetic Linear Drive System for 1-mil, 2-mil & 3-mil thickness.For leading & trailing edges vertical corner rounding of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- MZ-40 Multi-Stage Scraping, Multi-Profile (PVC): Top/bottom with (2) radii profiles. 1 mm and 2 mm or 3 mm instead of 2 mm, servo control positioning of vertical & horizontal copy wheels. Nested top copy system. PVC scrape collection box. -- Scraping Glue Unit: - Flush top/bottom on panel surface with floating insert knives. -- Buffing Unit: - Top/bottom (2) motors, 0.10 kW (0.125 HP) 2,800 RPM. Complete with:Separating spraying/cleaning agents; Motorized, programmable hold-down pressure beam; padded sound enclosure, isolation transformer for

HOMAG AMBITION 2262 (KAL 210) PRODUCTION EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications:Working Capacity: Coiled stock min/max Edge thickness 0.4 - 3 mm (0.016. - 0.118"), Strip material min/max Edge Thickness 0.4 - 6 mm (0.16 - 0.234"). -- Panel stock min/max thickness12 - 40 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18"). -- In-feed Fence: Adjustable in-feed fence with manual digital indicator positioning. -- Pre-Milling Station: Two3.0 kW(4.0 HP), 150 Hz, 9,000 RPM Motors; equipped with trimming column,(2) horizontal and cross slides with spindle adjustment, electro-pneumatic horizontal jump movement of the first motor; includes electronic frequency inverter for control of motor speed and braking, two (2) dust extraction hoods, air jet panel blow-off device &SIKO digital counters for adjustments. -- Panel Pre-Heater: Pre-heating the panel brings the panel to an appropriate temperature for better adhesion; this is especially beneficial in cooler temperatures. --Quartz lamp for heating substrate edge before glue application improved edge quality and optimum bonding. -- Multi-Purpose Magazine: A multi-purpose 2-coil magazine expands capability by running coiled material, strips, and solid wood bands. -- Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panel on the edgebanding. -- Gluing System: (EVA - Hot Melt) QA 34 -Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit. -- 34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gates. -- Lower melting unit equipped with automatic glue level control. Melting capacity: 12 KG/Hr (26 Lbs/Hr) -- Pressure Section: Manual Adjustment with digital counter, (1) large 160 mm dia. driven & (6) 70 mm dia idle rollers, pneumatic pressure control depending on edgebanding material used. -- WORKSTATIONSEnd Trimming Unit HL 81: 0.8 kW(1.0 HP)x 2 - 200 Hz, 12,000 RPM Motors. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer 30 deg. to straight cut. -- Rough/Pre-Trimming Unit: Top & bottom,0.55 kW (0.74 HP)x 2 - 12,000 RPM Motors; Height adjustment with the top pressure-beam and tilting range +/- 1°. -- Manually adjusted with digital counters. -- Profile/Bevel/Corner Rounding Unit FK 11: Multi function0.4 kW(0.54 HP) x 2)- 12,000 RPM Motor to fine trim the edge overhangs at the work-piece upper& lower edge, as well as trimming around the front & rear vertical edge; Servo controlled, Max. feed speed 20 MPM (65.6 FPM). -- Profile/Bevel Scraping Unit: Top & bottom for thick PVC/ABS, pneumatically activated. -- Flat Glue Scraper Unit: Top & bottom, pneumatically activated to remove potential glue squeeze-out. -- Buffing Unit: Top & bottom edge buffing/polishing. -- Spraying Units: Top/Bot

HOMAG BHT 500 CNC FEED-THRU MACHINING CENTER (2-HEAD) + BARGSTEADT STACKER: -- Specifications:Homag "BHT 500" CNC 2-Head Through-Feed PtP Machining Center: -- Working capacity: Single panel processing "X" Axis 98.4" (2,500 mm), "Y" axis 55.4" (1,406 mm); "Z" axis 0.5" - "2.36" (12 - 60 mm) min./max. panel thickness.(2) Panel processing "X" axis 98.4" (2,500 mm), Y" axis 23.6" + 23.6" (600 + 600 mm); 0.5" - "2.36" (12 - 60 mm) min./max. panel thickness. -- Positioning Speed:Vertical boring unit(s) positioning speed "X" Axis 328 FPM (100 MPM), "Y" axis 230 FPM (70 MPM), 'Z" axis 82 FPM (25 MPM);Panel transfer belt variable feed speed from 0 - 295 FPM (0 - 90 MPM). -- Horizontal Feed-Thru Boring Units:(2) 2 HP (1.5 kW) Motors (1-motor each side) with variable rotation speed up to 9,000 RPM. (2) 19-Spindle LH units (38) total LH spindles; (2) 19-spindle RH units (38) total RH spindles, spindle are on 32 mm centers,LH Horizontal drilling support is fixed, RH support motorized & equipped with LED indicator for precision positioning, pneumatic locking & individual adjustment for positioning according to the panel size. -- Horizontal PTP Boring Units:CNC controlled horizontal PtP boring units with (2+2 spindles in the "Y" axis on each boring head, (8) "Y" axis spindles total) -- Vertical PTP Boring Units:(2) 4 HP (3 kW) Motors (1-motor each head) with variable rotation speed up to 9,000 RPM;(2) Independently controlled top mounted CNC PtP boring/grooving heads; each head with (30) independent vertical spindles, spindle are on 32 mm centers -- Grooving Saws:(2) 2 HP (1.5 kW) Motors (1-motor each head) "X" axis grooving saw with variable rotation speed up to 12,000 RPM & 100 mm dia blade. -- Operator Interface:IPC with: HOMAG "Power Control 85T" + WoodWOP + Windows "XP" operating system; icon driven software with a graphical interface allows operator to quickly & efficiently create programs & diagnose malfunctions in simple terminology. 17" TFT Color monitor; multitask operating system, input/output modules, axes override, 4-axis interpolation, diagnostic graphics aide for programming, machine data & tool management. -- Options Include: BARGSTEADT "TBH 250/QL/25/12" Vacuum Stacker device.Work cap. "X" Axis 98.4" (2,500 mm), "Y" axis 55" (1,400 mm), 2.3" (60 mm) Max. panel thickness.High-speed workpiece stack exchange with a cycle time of 35 seconds; thin work piece device for panels from 8 mm thick. -- Actual Model is HOMAG BHT 500

HOMAG OPTIMAT BAK 41/45/G FLAT TABLE MACHINE (W/EDGEBANDING): -- Specifications:Working capacity "X" Axis 177" (4,500 mm), "Y" axis 48" (1,220 mm), "Z" axis stroke is 7.8" (200 mm), max material thickness 2.3" (60 mm). -- Positioning Speed"X" & "Y" Axis 197 FPM (60 MPM), "Z" axis 98 FPM (30 MPM)AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Work Table:Phenolic Flat-Table design with (14) double side "pick-n-place" vacuum pods;Laser aided positioning of the vacuum pods according to the selected program -- Edge Banding unit:Floating "hot melt" glue pot & application roller with separate thermostats apply glue on the panel edge. Pneumatically controlled pressure roller with manually adjustable guides for coil & strip feeding; numerically controlled with encoder that measures strip feeding process; preheated tape magazine with warning sensor when the end of the spool is near. Pneumatically activated saw blade performs the end trimming for precise fitting of overlapping joints on adjoining edges. Precisely applies 0.4 - 3 mm ABS, 1 - 3 mm PVC & 0.4 - 2 veneer with 45 mm max. edge height (65 mm without edging). Minimum internal radius 300 mm (11.8"), Minimum external radius 8 mm (0.3"), both depending on the banding material & thickness when edge banding.The edgebanding is automatically applied to square or irregularly shaped parts as the CNC manufacturing head rotates along the "X", "Y" & "Z" axis & simultaneously rotates the tooling on a high precision "C" axis. -- Machining:(1) 6 HP (4.5 kW) liquid cooled electro-spindle router with HSK F63 adaptor, variable speed fr 1,500 - 18,000 RPM,NC Controlled "C" axis for 360° horizontal processing & contour edge banding.(1) 4-position "on the fly" plate-type rotary tool changer, max. tool dia 7.08" (180 mm) -- Operator & Machine Control:"HOMAG" NC 83 + "WoodWOP" 4.0 + "WINDOWS NT 4.0 operating system; Icon driven with a graphical interface to allow the operator to quickly and efficiently create programs; Pentium processor, 8 MB RAM, 8 MB hard disk; VGA video card.17" color LCD monitor, 1.44MB & CD ROMx32 drives, connection to an office PC is possible (up to 300 meters). Multitasking operating system, input/output modules, axes override, 4-axis interpolation, diagnostic graphics aid for programming, machine data & tool management. WoodWOP Editor Module for PC with same look and functionality of software on the machine, allows transmission of programs and work lists from an office PC (PC not included): -- Complete with: (1) 100 m³/Hr vacuum pump; (1) 1-coil tape magazine; perimeter protection cage, safety mats, user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Options Include:(1) Combination Snipping and Corner Rounding Unit; (1) Corner Rounding Radius Cutter Head; (1) Combi-Flush Trimming Scraping Unit; (1) Flush Trimming Unit; (1) extra glue pot; An assortment of spare parts as pictu
