iDry/Vacutherm Air Vac 2.5 Vacuum Kiln Brand new Weil McLain Boiler Ready to ship!

Vak-matic Vacuum Table as pictured

Vance PT600R8 Drum Chipper See this machine at IWF Atlanta 2024! This Wood Drum chipper PT600 is used in production of wood chips from logs and veneer waste. It has a toothed roller system that allows efficient material infeed, a rubberized conveyor belt and a Hydropneumatic unit to lift the rotor cover for maintenance. It comes with 01 chipper Knife set and 01 nose bar set. It does not come with the output conveyor. - Width of inlet: 600 mm; - Height: 300 mm; - Rotor diameter: 800 mm; - Toothed roller: 01 upper and 01 lower; - Grooved rollers: 01; - Rollers gear motor: GD (helical gears); - Metal detector: Flat model; - Rollers motor size: 5 hp (2x); - Number of rotor knives: 02; - Wood chip size: 25 - 40 mm; - Main motor 125 hp 4P: Included; - Drive panel: Included; - Lead Time: 240 Days; - Estimated production: 55 m3 / h (it may vary according to the type of material and time used with blade sharpening); - Infeed conveyor length: 3 500 mm (included); - Width: 1 850 mm; - Height: 1 .150 mm; - Overall length: 6 700 mm; - Approximate weight: 4,900 kg.

Weeke BHP 007/430 CNC Router 13 HP HSK 63F Spindle with air blast nozzles 8 Position Rack Style ATC 7 Spindle Boring Block 4x8 Table Part location pins (2) Becker 7 HP vacuum pumps Woodwop Light Barrier safety system

Weeke BHP 007/430 CNC Router 13 HP HSK 63F Spindle with air blast nozzles 8 Position Rack Style ATC 7 Spindle Boring Block 4x8 Table Part location pins (2) Becker 7 HP vacuum pumps Woodwop Light Barrier safety system

The Vantec Wood Wast Drum Chipper is used to produce chips from logs and veneer waste. It has a roller infeed system, rubber conveyor belt and hydro-pneumatic unit to lift the rotor for maintenance. Manufacturer specs: - Width of inlet: 600 mm; - Height: 200 mm; - Rotor diameter: 600 mm; - Toothed roller: 01 upper and 02 - lower; - Grooved rollers: 01; - Rollers gear motor: GD (helical - gears); - Upper Rollers motor size: 5 hp; - Upper Rollers motor size: 5 hp; - Feed speed: 40m/min; - Number of rotor knives: 02; - Wood chip size: 30 - 40 mm; - Chipper screen: size: 65 x 65mm - Main motor 100 hp 4P: Included; Drive panel: Included; - Estimated production: 38 m3 / h (it may vary according to the type of material and time used with blade sharpening); - Infeed conveyor length: 3 500 mm (included); - Width: 1 650 mm; - Height: 1 .000 mm; - Overall length: 5800 mm; Approximate weight: 2,900 kg.

This Wood Drum chipper PT600 is used in production of wood chips from logs and veneer waste. It has a toothed roller system that allows efficient material infeed, a rubberized conveyor belt and a Hydropneumatic unit to lift the rotor cover for maintenance. It comes with 01 chipper Knife set and 01 nose bar set. It does not come with the output conveyor. - Width of inlet: 600 mm; - Height: 300 mm; - Rotor diameter: 800 mm; - Toothed roller: 01 upper and 01 lower; - Grooved rollers: 01; - Rollers gear motor: GD (helical gears); - Metal detector: Flat model; - Rollers motor size: 5 hp (2x); - Number of rotor knives: 02; - Wood chip size: 25 - 40 mm; - Main motor 125 hp 4P: Included; - Drive panel: Included; - Lead Time: 240 Days; - Estimated production: 55 m3 / h (it may vary according to the type of material and time used with blade sharpening); - Infeed conveyor length: 3 500 mm (included); - Width: 1 850 mm; - Height: 1 .150 mm; - Overall length: 6 700 mm; - Approximate weight: 4,900 kg.

This Wood Drum chipper PT750 is used in production of wood chips from logs and veneer waste. It has a toothed roller system that allows efficient material infeed, rubberized conveyor belt and Hydropneumatic unit to lift the rotor cover for maintenance. It comes with 01 chipper Knife set and 01 nose bar set. It does not come with the output conveyor. Width of inlet: 750 mm; • Height: 300 mm; • Rotor diameter: 800 mm; • Toothed roller: 03 upper and 03 lower; • Grooved rollers: 01; • Rollers gear motor: GD (helical gears); • Upper Rollers motor size: 7,5 hp (2x); • Feed speed: 35 m/min; • Number of rotor knives: 02; • Wood chip size: 25 - 40 mm; • Chipper screen: size: 70x 70mm; • Main motor 200 hp 4P: Included; • Drive panel: Included; • Estimated production: 65 m3 / h (it may vary according to the type of material and time used with blade sharpening); • Lead Time: 240 Days • Infeed conveyor length: 3 500 mm (included); • Width: 2 500 mm; • Height: 1.250 mm; • Overall length: 7 300 mm; • Approximate weight: 8 750 kg.

This Drum chipper is used in production of wood chips from logs and wood residues (slabs, board off cuts, veneer waste). It has a toothed driven roller system that allows an efficient infeed of the material, rotor with interchangeable thread locks and with a disposable steel plate in the front of the rotor, hydraulic nose-bar/anvil extractor, infeed conveyor with rubberized belt and hydro-pneumatic unit to lift the chipper/rotor lid. (maintenance). It comes with 01 set of blades and 01 nose-bar/anvil. Does not come with outlet conveyor. - Inlet width: 1000 mm; - Nominal chip size: 23 - 30 mm; - Inlet Height: 450 mm; - Main Motor indicated: 300 hp 4P (2x); - Rotor diameter: Ø 1000 mm; - Soft starter drive panel; - Shaft diameter: Ø 220mm; - Metal detector; - Toothed roller: 03 upper and 03 lower; - Estimated production: 130 m3/ h; (may vary according to the type of wood and the sharpening period of the knives); - Roller diameter: Ø 353mm; - Diameter of roller shafts: Ø 100mm; - Chipper Screen: 65 x 65mm; - Grooved roller: 01; - Infeed conveyor length: 5000mm (included); • Driven roller gearmotor: (helical gears); - Width: 3 500 mm; - Driven rollers motor: 15 hp (2x); - Height: 2 100 mm; - Main motor belt: Torque-Team; - Total length: 10 500 mm; - Inlet conveyor speed: 40 mL / min; - Approximate weight: 22 700 kg; - Number of rotor blades: 03;

Equipment designed for debarking/rounding of logs for veneer production. This debarker is capable of processing logs from 120mm to 735mm diameter. It is fitted with metal tempered grooved rollers to press/rotate the log against the lathe knife. The log carriage moves on skates and linear guides through hydraulic cylinders. It has a rack and pinion system that ensures the alignment of the carriage. It also comes with the drive panel, but it does not come with lathe knife. Maximum Diameter capacity (logs with • bark): 735 mm; Maximum diameter for de- • barked/rounded logs: 600mm; Minimum diameter for de- barked/rounded logs: 120mm; Max. log length: 2.800mm; Min. log length: 1.800mm; Rail Skids: 65 model; Rollers gear motor: GD (helical gears); Approximate weight: 9.000 kg; Power consumption: 35HP, Power of the rollers: 50cv 4p (5cv + 20cv); Cylinder diameter: 50mm; Lead Lime: 270 days Hydraulic unit: 210 l; Motor unit: 10 hp 4p; Hydraulic pump: 60 l / min; Width: 7.000 mm; Length: 2.840 mm; Height: 3.100 mm;

The Vantec 2800mm Spindleless Veneer Lathe is designed to process veneer for plywood production from both hard and soft logs. Its metal tempered grooved rollers and lathe knife inclination system work perfectly to make sure there will always be a precise contact area between the lathe knife and the log during the peeling process by eliminating vibration that could cause damage to the Veneer sheets. Vantec Spindleless lathe proves its efficiency by delivering consistent thickness variation and a impressive top linear speed of 180 m/ min throughout the peeling process for face or core veneers with smooth surfaces. - Log diameter up to 600 mm; - Max log length: 2750 mm; - Min log Length: 2300mm; (with stacker) - Min log length:1800mm (no stacker); - Veneer thickness: 1.0 to 4.0 mm; (Pine and eucalyptus); - Log core after peeling: 40 to 45mm; - Maximum linear speed 180 m/min; - Drive panel included; - Each motor is individually connected by a Variable Speed Drive for torque control in two points of traction on the rollers to pre- vent excessive load on tip ends; - Log Central aligner with maximum of 2200 mm of movement; - Pneumatic scriber Knives (02 fitted on the sides to cut in width and 01 in the Center to cut the length); - Width: 7640 mm; - Length: 3400 mm; - Height: 2550 mm; - Approximate weight: 14000 kg.

The Vantec Automatic Rotary clipper is designed to clip 2800 mm veneer sheets into specific sheet sizes as per the auto stacker preselection. It comes with electronic drive panel, automatic gauge system, positioning of clipper knife by Servomotor and encoder. It is de- signed to work with one tensioned clipper knife with gear motor. It also comes with a 2 HP motor on the output. The clipper knife is not included. - Veneer Thickness : 1 to 4 mm; - Max. Log: 2.750mm; - Minimum veneer width cut: 800 mm; - Max. Veneer length cut: 2700 mm; - Min. Veneer length cut: 700 mm; - Min. Venner rounding length: 150 mm; - Rotor gear motor: helical gears; - Clpper rollers power drive: 4 hp 6P; - Outlet conveyor Motor: 2hp 4P (input) 1 hp 8P (output); - Clipper Servomotor: 40 Nm (2x); - Width: 4800 mm; - Length: 6000 mm; - Height: 1700 mm; - Approximate weight: 7.000 kg

The Vantec Veneer Auto Stacker, ELV 1.82B is a Vacuum stacker for 2800 mm Veneer lathe. It is fitted with double stacking system (04 bins), with four veneer transport lines and four 5hp exhausters. with of two stoppers and eight ejecting arms. With drive Panel, VSD for exhaust fans and hydraulics lifting tables. Min veneer sheet length sheet: 2300 mm; • Max veneer sheet length sheet: 2700 mm (or Two sheets of 1350mm); • Min veneer sheet width: 800 mm; • Max veneer sheet width: 1500 mm; • Max height of stacks: 1000 mm; • Exhaust motor: 10 hp 4P (8x); • Inlet conveyor motor: 2hp 8P; • Transport conveyor motor: 6hp 4P; • Hydraulic pump motor: 5hp 4P (3x);

SFVG1200 twin vertical Band Saw 1200mm wheel blade size. Machine used for the log break down process in continuous flow sawmill layouts. Capacity to process logs up to 500mm in diameter and 3.000mm long. This machine is fitted with main motor, motor drive panel, servo motor thickness selection, adjustable saw guides, slabs pneumatic side pressers, special chain and hydropneumatic tensioning system to tension the Band saw. - Wheel blade width: 6”; - Minimum log Length: 1200mm; - Standard maximum log length: 3000mm - Minimum diameter: 120mm; - Maximum log diameter: 500mm; - Saw cut width: 70 to 300mm; - 4 set of pneumatic side pressing rollers for side boards; - Motor size: 2 x 75CV 4P 50hz (INCLUDED) - Drive Panel Included; - Central chain motor size: 7,5 HP 4P; - Linear Cutting speed: 30m/s; - Feed speed capacity: 48m/min; - Saw Blades are not included. - Infeed conveyor length: 4.000 mm included; - Outfeed conveyor length: 6.000 mm included; - Machine width: 5.000 mm; - Machine overall Length: 12.000mm - Servo motor thickness setting system (INCLUDED); - Approximate weight: 15.000 kg;

Multirip circular saw for block cutting, with reinforced structure and high production speed. Trailed top and bottom rollers, upper rollers with adjustment, shafts with cartridge system for quicker and more efficient replacement of the set of saws, U-beam base with levelers and central lubrication. It does not come with the circular saws. - Maximum inlet width: 600 mm; - Minimum inlet height: 70 mm; - Maximum inlet height: 160 mm; - Double arbor: Ø 80 mm; - Number of saws per axle: 10x; - Exterior saws Ø: 350 mm interior saws - Ø: 110 mm; - Upper press rollers: 2x; - Bottom rollers: 6x; - Max. Feed speed: 35 m L / min for logs - 160mm above in diameter; - Max. Feed speed: 40-50 m L / min - only for logs 130-160mm in diameter; - Lower main motor indicated: 200 hp 2p (1x) Included; - Top main motor indicated: 150 hp - Main motor belt: 4 / 3v (8 Pcs); - Motor traction of the rollers: 5 cv 4p; - Gearmotor: GS (crown and pinion); - Length: 3366 mm; - Width: 2782 mm; - Height: 2233 mm; - Approximate weight: 5.470 kg

This is a Horizontal Band Saw Resaw Machine with Two saw heads. This is an ideal Machine for the recovery line, as it processes the slabs coming out of the Vertical Twin band saw machine “the resaw process”. It comes with an input chain conveyor, driven press rollers. Cutting Height and saw blade tensioning setting system. It also comes with main motor, motor drive panel, the Frequency inverter, gear motor drive panel. It does not include the saw blade. - Wheel blade: Ø1000mm; - Wheel blade width: 5"; - Maximum wood width: 400 mm; - Maximum wood height: 380 mm; - Minimum length of wood: 1250 mm; - Single Input table/ conveyor width: 600 mm; - Motor press roller: 1 cv 4P (2x); - With two independent infeed rollers; - Forward speed: 45-50m / min for small logs; - Main motor indicated: 2 x 60 hp - Soft starter Drive panel: included; - Servo motor thickness setting system (INCLUDED); - Main transmission belt: 3 x Channel B; Length: 6.532mm; - Width: 2.220mm; - Weight: 7655kg.

Vecoplan RG52-60 U Stretch Slow Speed Grinder 60 HP Motor No Control Panel

Vecoplan Model 45/12/2VU HZF Grinder 75 HP Motor 18" Wide opening No Vibrating Infeed conveyor

Brand new never used!! 16’8” long 22” wide 19” height (adjustable)

Vecoplan RG 42/60 XL 60 HP Motor 15" Rotor 42" x 52" Hopper Opening 1" Screen This machine went through a rebuild. It was not big enough for the buyers application. Available immediately.
