DIEHL - SL-52, Straight Line Rip SawSpecifications: -- 15 HP Motor, 3,600 RPM belt driven, fixed 2" arbor. -- 14" to 18" Blade diameter. -- 4-1/4" Max. thickness with 18" blade diameter. -- 2 HP - 1,800 RPM feed drive, variable feed speed from 65 to 190 FPM. -- 25" Throat depth to right of blade, 24" of table to left of blade. --Table size: 61" x 80".Equipped with & Features: -- Cast iron pressure bar arms with ball bearing rollers. -- Adjustable rip fence. -- Self-adjusting antikickback fingers with control cam. -- Automatic lubrication of feed chain & race. -- Full overload and under voltage protection. -- Manual arbor brake for safety with interlock.Shipping Dimensions 7-1/2' L x 7' W x 5-1/2' H; weight of 5,000 Lbs.

DIEHL SL-55 Straight Line RipsawSpecifications: -- 15 HP - 3,450 RPM Direct drive arbor motor, 2" dia. arbor, 16" blade cap. -- 4" Max. depth of cut, 12" min. part length -- 20-1/2" width of the table to the right of blade & 30" to the left, 66" table length.Equipped with & Features: -- 3 HP 4-Step feed drive 30 - 50 - 75 & 120 FPM; -- Twin chain drive. -- Automatic drip chain lubrication. -- Top pressure system with (6) full-width rollers & (2) split rollers over the blade.

DIXIE AIR SPB Pulse Jet Dust Collector. -- 16,100 CFM @ 9.5:1 air-to-cloth ratio, round baghouse with (108) cloth filter bags of 12' length resulting in a total approx. 1,695 sq ft of filter media area. -- Ground mounted main Blower with 50 HP motor connected in a negative pressure configuration. -- Automatic reverse pulse cleaning system with differential pressure gauge, positive displacement air pump for pulse clean. -- Galvanized steel bag frames with positive bag bolt down to eliminate leakage and ride-up of bags once installed. -- Walk-In Clean Air Service Plenum. Tangential dirty air inlet. -- Electrical control panel. -- Single cone hopper outlet with 10" Rotary Airlock discharge. -- Horizontal shared transfer auger (about 54' long). -- Steel support structure with access ladder and service platform.Professional disassembly, loading on truck and/or transportation available upon request.NOTE: Unit being sold under this record is pictured on the right side on the first two photos. For the larger diameter unit on the left side (PNEUMAFIL) see record "DO-011265".

DONALDSON / TORIT - 2DF-16, ...Cartridge Dust CollectorSpecifications: -- Holds (16) cartridge filters. -- Includes "New" AirMax Premium Media Cartridge Filters: Fire retardant. -- Total filter media area: 3,616 ft². -- Air-to-Media ratio @ 8,000 CFM: 2.2:1. -- Automatic Pulse Clean System with: Differential pressure gauge and sequencing control in enclosure. -- (2) Hopper outlets with sealing drum cover kits. -- Steel support structure. -- Includes: 20 HP Top mount, direct-drive Blower. -- Rated for 8,000 CFM. -- Electrical motor starter & controls. -- Includes: Installation/Operation/Maintenance Manuals.Sold with 6-Month Mechanical Warranty

DONALDSON / TORIT - DFT2-16, ...Cartridge Dust CollectorSpecifications: -- Holds (16) cartridge filters. -- Includes: "New" AirMax premium media cartridge filters: Fire retardant. -- Total filter media area: 4,064 ft². -- Air-to-Media eatio @ 8,000 CFM: 2:1. -- Automatic Pulse Clean System with differential pressure gauge and sequencing control. -- (2) Hopper outlets with: Sealing drum cover kits. -- Steel support structure. -- Includes: 20 HP Top mount, direct drive blower. -- Motor starter & controls Sold with 6-Month Mechanical Warranty

DONALDSON / TORIT DWST6-5 Cartridge Dust CollectorDownflo® WorkStations (DWST) fit anywhere on the plant floor and apply NO restrictions to worker movements or visibility. The full line of WorkStations are designed specifically for those in-plant areas where dirty and/or noisy operations are out in the open—grinding, sanding, chipping, batch mixing or welding. The DWST delivers exceptional performance in metalworking, woodworking, and process applications where high filtration efficiency and ledge less construction is often a requirement. Specifications: -- (5) Module System, each with 10 HP motor, 7,000 CFM. -- (4) Ultra-Web cartridges. -- Pulse-cleaning manifolds and ventures, (2) dust drawers. -- (1) Acoustical panel per module. Louvers mounted on lower section of unit.Includes: -- (1) IEC control panel includes 460-volt motor starters, circuit protection for each motor, transformer, programmable logic controller. -- Magnehelic gauge mounted in a panel door, start/stop buttons, and a through-the-door disconnect switch. -- Pulse cleaning can be continuous or after-shift. -- All components are IEC rated. The enclosure is rated Type 12. -- 1"; Compressed Air Regulator with Filter Separator and Gauge, Black Iron Fittings, and Black Iron Piping Required for Cleaning System. -- Provides a 1"; Common Connection Point for Design Shutters to Tie into with Existing Compressed Air System.

DOUCET - 16-Section: Clamp Carrier; 16-1/2' Wide(16) Sections with: 16-1/2' wide usable clamping width.Complete with: -- (12) Clamps per section (total of 192 clamps). -- 48" Opening clamps: 3-1/2" High x 4-1/2" jaw width. -- (1) Pneumatic panel flattener. -- Heavy-Duty, 5 HP hydraulic pump for rotation drive. -- (1) Hydraulic torque wrench clamp tightener.Actual model: SRH-16-16.5-19+2-48RNOTE: Tear-down not included.

DOUCET EM-2 End Matcher, Double End:Specifications: -- 12" Min. to 96" max. length x 1-3/4" to 5" width x 3/4" thick cap.; bar spacing is available at 12" center to center. -- Feed chains are is powered by a 3 HP fixed speed drive at 28 lugs per minute (simple to add a variable speed drive). Equipped with independent tongue & groove machining centers laid out on opposite sides of the transport table. -- Capacity is approx. 8,000 - 10,000 board feet per shift based on feed stock 2-1/4" wide x 36" long. Tongue & Groove Machining Centers with: -- 12" Dia. squaring saw; tongue station features a bottom & a 10" dia. top groover; Groove Station with 10" dia. groover; (5) squaring saws & groovers are powered by 3 HP arbor motors. -- When the machining centers, material is pushed up against the holddown press foot for justification with respect to the top of the board; material is placed between the traverse bars at the infeed end of the machine. -- While random length pieces are brought forward, material is positioned by perpendicular roller conveyors ahead of both machining centers; 3rd roller conveyor takes care of lateral outfeed. -- Roller conveyors are 24" wide and are embedded into the transport table; system equipped with motorized pinch roller to re-align pieces longer than 60" prior to the 2nd machining center. -- End-Matcher Model "EM" is designed for end-matching of strip flooring in a mid-sized volume production environment; End-Matcher "EM" is 21' long; overall width including the machining centers is 8 feet.

DOUCET 12-SECTION Clamp Carrier (Hydraulic)Specifications: -- (12) Sections, 8-1/2' width, -- (9) Clamps per section (108) clamps total, -- 36" Clamp opening (rapid change) with 2-1/2" high jaws.Complete with: -- 5 HP hydraulic power pack and motor for rotation -- Hydraulic clamp tightening; -- Pneumatic overhead panel flattener.Note: Tear down not included

DOUCET MFE 300 Lateral chain feeder for moulders and optimizers -- 3'0" x 16'-0" working deck for material length 2'0" - 16'0"; width 2" to 9.5" and thickness 1/2" to 4". -- Feed system: Hydraulic variable speed 50-300 FPM with a 20 HP power unit. In-feed (4) roller accelerator; (2) top steel rollers and (2) bottom drive roller. Additional idler rollers along feed fence to support lumber during feeding. -- Chains: Transport length of lateral chain feeder 3'0". (8) strands of C2060 chains on pneumatic up/down device to release lateral pressure on board when feeding. -- Pedestal: Feeder controls mounted to pedestal with extended cable. Interface relay to stop feeder when moulder is stopped. -- Adjustments: Tool less adjustment handles for quick setups. Easy access to for thickness adjustments at front side of feeder. -- AVAILABLE OPTIONSOne (1) set of four (4) feeding wheels made of steel with hardenedsurface teeth $ 1 000.One (1) set of four (4) feeding flat wheels made of steel, 2" wide insteadof 1" for wide material feeding $ 500.One (1) set of four (4) feeding flat wheels made of steel 1" wide $ N/C.Guiding Tunnel between feeder and moulder,Standard Guiding Tunnel (4' long) $ 1 650.Standard Short Guiding Tunnel (32" long) $ 2 100.Complete Guiding Tunnel (4' long) $ 2 700.Complete Guiding Tunnel with adjustable fence (4' long) $ 3 800.Motorized Guiding Tunnel (4' long) on request.Additional chain transfer length capacity (up to a maximum of 6additional feet) For MFE-300-16 sold per foot $ 1 685. Note: More than 6 add. feet: price upon requestSteel plates between chainsFor MFE-300-16 $ 1 050.Platen chains recommended for softwood speciesFor MFE-300-16 $ 2 850.One (1) additional chain for shorter material down to $ 1 750.18" min. lengthPressurized lateral guide with roller bearing end $ 1 400.Powered lateral guide with roller and side guides on request.Custom working height on request.

DOUCET - 16-SECTION: Clamp Carrier (Hydraulic)Specifications -- (16) Sections; 8-1/2' width. -- (6) Clamps per section; (86) clamps total. -- 32" Clamp opening (rapid change) with: 2-1/2" High jaws.Complete with: -- 5 HP Hydraulic power pack and motor for rotation. -- Hydraulic clamp tightening. -- Pneumatic overhead panel flattener.NOTE: Tear down included!

DUBOIS Vertical Edge Fill System with Micro UV This machine is designed to fill voids and defects in edges for a smooth, quality finish. These coaters are ideal for filling porous open grain panels like oak, veneers, particleboard, and MDF. Compatible with solvent based, water based, and UV fill coating.1.1 One (1) Continuous chain transport system- Top and Bottom chain transport conveyor with speed matching attachment conveyor chain- Aluminum backed chain pads with EPDM covering1.2 Two (2) double sided vertical edge denibber/buffer- Operator side Adjustable up to 12"; wide, back side fixed edge- Post mounted vertical denibber head- 12"; dia. x silicon impregnated scuffing wheel, buffer wheel to be determined- Dust hood with 4"; connection- Vertical head oscillation for even brush wear- Inverter controlled drive provides speed control for brush and oscillation1.3 Two (2) double sided vertical edge fill stations- Operator side Adjustable up to 12"; wide, back side fixed edge- Electric motor driven Applicator and Doctor roll drives- Quick change applicator sleeve design, 1-1/2"; face- Stainless steel distribution pipe with spring tension- 9"; dia. chrome plated reverse roll- Stainless steel catch pan and drain lines- 3/8"; pail mounted pump and agitator- Spring loaded doctor bar, urethane dr. blade- Air cylinder dr. roll engagement with stroke adjuster- Inverter controlled drives provides speed control for applicator and doctorrolls1.4 Edge Cure UV Oven Banks- Each bank to consist of Two (2) double sided Fusion F600 Microwave UVovens- Space for two (2) future double sided Microwave UV Units- Individually adjustable three (3) position lamp power selector switch(300, 400 & 600 w/in.)- Irradiator cooling exhaust fan for each set of four (4)2. Control Panel System- NEMA 12 Hinged Door Enclosure, with disconnect, required fuses, door mounted buttons and cooling fans- Allen Bradley HMI, PLC items included- Top mounted panel cooling fan- Required Inverters· Edge Fill Finishing Machineo Top and Bottom Conveyor driveso Denibber/Buffer Brusheso Denibber/Buffer oscillatorso Applicator Rollso Doctor Rollso Reverse Rollso UV oven Exhaust fansDesign Parameters- Machine is located in Explosion Proof Area- Voltage= 480 V., 3 Ph., 60 Hz.- Design Speed = 70 - 200 FPM- Line height = 36";- Max./Min. Part Width: 12"; / 2";- Max./Min Part Length: 245"; / 24";- Max./Min Part Thickness: 1-1/4"; / 3/8";- Paint Color· Main Frame and Conveyor: Blue / TS White· Guards: safety yellowNotes:- ¼"; product has the potential of being processed in this machine but has less probably of being successful the wider the product.

The Dubois SP-12 Linear Spray Machine is an automated linear finishing machine that can be used for a variety of applications including priming, staining, sealing, lacquering, etc. of linear stock. This spayer comes with (3) three arms, (3) three guns and (1) one paint pump. The guns are Binks spray guns Model 363, and Binks pump.Compatible with both waterborne and solvent based coatings --Three adjustable gun arms --9’-0"; long variable speed live roll conveyor w/ electric powered drive --Pneumatic gun trigger mechanism to automatically trigger guns on/off --Infeed guide fences --Top roller hold-down on infeed table --Ability to enable/disable individual guns --Easily cleaned spray trough --Adjustable atomizing air pressure --Adjustable fluid pressureIncluded optional features: &#9679 Stain wipe station mounted to outfeed with stain wipe brush &#9679 Exhaust system with spray enclosure, exhaust fan, & exhaust filter system &#9679 Denibbing station mounted to infeed

DURA-QUIP - VC-3532, ...Vibrating Conveyor: -- Specifications:35" Wide x 32' Long; Pan is 7" deep and has 1/4" round holes punched plate in most of length to allow sawdust to drop outside of Conveyor. -- Bottom frame is filled with concrete 12" deep and rests on coil springs to isolate vibration from the ground. Buyer to replace screens. -- Include: 10 HP TEFC 460 V Drive motor.

DURAMAC - DUR52-2, ...2-Head Wide Belt Sander2-Head Wide Belt Sander with: Drum, combi-head, and brush cleaner. -- Max. working width: 52". -- Max. working thickness: 6". -- 23" Infeed load space. -- 50" Wide rubber conveyor belt size. -- 1st Head: Grooved rubber contact sanding drum; 40 HP, 230 Volt - 3-phase drive motor. -- 2nd Head: Combination contact drum & polishing platen; 30 HP, 230 Volt - 3-phase drive motor. -- Spring-loaded pinch rollers. -- Electronic belt tracking, pneumatic belt tensioning. -- (1) Rear top outfeed panel brush cleaning head, 0.5 HP, 230 Volt - 3-phase drive motor. -- Power raise & lower of worktable. -- Inverter driven feed works drive motor for variable speeds, 0 to 60 FPM. -- Front operator control station; motor ammeters. -- TOSHIBA Feedworks inverter. -- "DP-626S" electronic digital readout for setting table heightAlso Available: -- Transformer for 600 Volt operation, 112.5 KVA.

DUST TECHNOLOGY DT-250 Modular Dust Collector Free-standing self-contained internal air system, 25 HP Motor;Specifications: -- Rated for 9,800 CFM, 5-bag unit, 75 cu. ft. collection capacity. -- (5) Upper cloth filter bags with 165 sq. ft. filter area; 16" inlet dia., dust baffling system to fill bags evenly. Supplied with & Includes: -- 25 HP motor with magnetic starter, -- (5) Upper cloth filter bags and (5) lower plastic collection bags. -- (5) Double "T: Bolt straps. -- (5) Quick release metal straps. Three Year Comprehensive Warranty

DUST TECHNOLOGY DT-200 Modular Dust Collector Free-standing self-contained internal air system.Specifications: -- 20 HP Motor, rated for 7,500 CFM, 4-bag unit, 60 cu. ft. collection capacity. -- (4) Upper cloth filter bags with 132 sq. ft. filter area; 14" inlet dia., dust baffling system to fill bags evenly. Features & Includes; -- 20 HP motor, magnetic starter; -- (4) Upper cloth filter bags and (4) lower plastic collection bags. -- (4) Double "T: Bolt straps. -- (4) Quick release metal straps. -- Magnetic starterThree Year Comprehensive Warranty

DUST TECHNOLOGY DT-50 Modular Dust Collector5 HP BALDOR Motor, compact 2-bag free-standing & self-contained Heavy Duty Dust Collector, rated @ 2,400 CFM, 9" - 11" static pressure at fan. -- Equipped with: 10" Inlet dia., (2) Cotton Filter bags with 66 sq. ft. filter area and (2) Plastic Collection Bags w/ 30 cu. ft. collection capacity. -- (2) Double "T" Bolt Straps and (2) Quick Release Metal Straps. Includes: Magnetic Starter

DUST TECHNOLOGY DT-150 Modular Dust Collector Free-standing self-contained internal air system, 15 HP Motor, rated for 6,000 CFM, 4-bag unit, 60 cu. ft. collection capacity. -- (4) Upper cloth filter bags with 133 sq. ft. filter area; 14" inlet dia., dust baffling system to fill bags evenly. -- Includes: 15 HP motor, magnetic starter, (4) Upper cloth filter bags with 133 sq. ft. filter area and (4) lower plastic disposable collection bags
