HOLYTEK HK 610 Double-Sided Strato Planer -- 24" x 8" Cap. Double Surface Planer, spiral carbide cutterheads belt driven by 20 HP top and 15 HP bottom motors at 5,000 RPM. -- Spriral cutter head 125 mm diam. with 96 inserts 30 mm X 12 mm X 1.5 mm -- Variable feed motor delivers a range of 6 M./min to 25 M./min. (9.5 FPM to 82 FPM), -- Feed motor 3 HP, corrugated sectional infeed rollers and (4) table rollers provide superior feeding regardless of the type of wood being processed; -- Hard-chromed table surface precision ground to provide smooth performance and maximum wear resistance at high speeds.Technical Specifications:• Maximum width 635 mm (25")• Minimum length: 300 mm (11.9")• Maximum thickness 200 mm (7.87")• Minimum thickness 10 mm (.39")• Table size: 686 mm x 2616 mm (27" x 103")Features: &#9679 Dovetailed slideways on the table elevation ensure stability and rigidity; Mechanical readout provides accurate details of table positioning adjustment; &#9679 Thickness limit guard is provided at the infeed end as a safety feature. &#9679 Machine weight 6,600 Lbs

HOLYTEK MHB 242 Top/Bottom Wide Belt SanderHeavy-duty and powerful double surface sander providing significant time saving and improved productivity.Smooth and quiet oscillation. Belts oscillation controlled electronically by an infrared system which resists dust.Pneumatic sanding belts tensioning ensuring fast and easy belt replacement.Independent motor for each sanding belt.Pneumatic disc brake system automatically activated if power supply is interrupted, thus preserving the sanding belts from being damaged. Top and bottom 24" wide belt sanderFeatures: -- Spiral grooved 8" (D) rollers (R) and 3-1/2" (D) rollers (K) keep the sanding belts cool. -- Sanding belts: 75" Long. -- Elevation of table with digital readout and activated by independent motor. -- Control panel with: Ammeters indicating main motors current. Specifications: -- Upper Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Upper Combination head motor: 10 HP; 600 V; 60 Hz - 3-Ph. -- Lower Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Lower Combination head motor: 10 HP, 600 V, 60 Hz - 3-Ph. -- Feeding motors: 2 HP (x2). -- Table elevation motor: 0.5 HP. -- Electrical intensity: 53 A. -- Drums: 8" (D) - 75 DUROS. -- Max. working width: 24". -- Min. working length: 13-3/4". -- Working thickness: 3/16" ~ 5" -- Sanding belts dimensions: 25" x 75". -- Variable feeding speed: 8 - 16 MPM. -- Dust hoods Top: 4 x 4"(D); Bottom: 3 x 4"(D). -- OAL 127" x 70" x 75" high. -- Weight: 9,460 Lbs.

HOLYTEK - KL-36PC, ...2-Head Sander 2-Head Planer Sander 36" with planer head & combination head.Description: -- Planing Head (P): 6'' Dia. made of steel with spiral design for heavy stock removal. 228 TCT Tips: 15 x 15 x 2.5 mm; each disposed on (6) rows. Each knife has: (4) Usable cutting edges; easy access to planing head for tips rotation or replacement. -- Precise dial indicator showing the exact positioning of the sanding pad; quiet & smooth oscillation! Pneumatic oscillation system controlled electronically by an infrared system, which is not affected by dust. -- Combination Head: (1) Drum & (1) sanding pad (C) for superior quality of finishing. Sanding belt with: 120 or 150 Grit; allows finishing sanding in a single pass. -- Elevation Table: (4) Screws. -- Infeed roller table extension: 15-3/4". -- Outfeed roller table: 15-3/4" with (2) Rollers. -- Centralized Control Panel with: Electronic digital readout (Metric or Imperial) for elevation; precise positioning at the elevation requested. -- Ammeter indicating: Electrical intensity on the spiral cutterhead and the combination head motors. -- Electrical box with: CSA Approved electrical components ensuring maximum dependability and an outstanding long-lasting performance.Specifications -- Spiral cutterhead motor: 20 HP - 600 V; 60 Hz - 3 Ph. -- Combination head motor: 15 HP - 600 V; 60 Hz - 3 Ph. -- Table elevation motor: 1/4 HP - 600 V; 60 Hz - 3 Ph. -- Feed motor: 2 HP - 600 V; 60 Hz - 3 Ph. -- Spiral cutterhead dia.: 6''. -- TCT Tips dim.: 15 x 15 x 2 mm (228); (6) rows. -- Max. working width: 36". -- Min. working length: 12". -- Max. working thickness: 5". -- Sanding belt dim.: 37" x 75". -- Dust hoods dia.: 4'' x 2 & 5" x 2. -- Machine dim.: 71" L x 76" W x 77'' H. -- Net weight: 1,450 kG or 3,190 Lbs.

HOLYTEK - HK 400, ...Top & Bottom PlanerSpecifications: -- 16" x 8" Cap., top & bottom helical insert knife heads, 4,000 RPM cutterhead rotation. -- 15 HP Top & 10 HP bottom; 10" min. stock length. -- 2 HP Variable feed speed from 23 - 65 FPM; sectional feed rolls & chipbreaker. -- 0.5 HP Motorized opening w/micro-adjustable table. Complete with: -- Heavy swing-out carriage with a built-in micro-dial; supports bottom cutterhead, pulled out for "quick & easy" replacement of knives.

HOLYTEK HP-11P Horizontal Resaw -- Hydraulic Feeding conveyor, hydraulic pump with 3 HP motor -- Main saw motor 20 hp. Specifications: -- Working width capacity 12“ (300 mm) -- Variable Feed Speed 0- 17 m/min (0 to 55 FPM) -- Thickness capacity 4mm to 125 mm (.11/8" to 4.92") -- Conveyor tilting 0 ° to 7° -- Electroni display of cutting height -- Blade Capacity 4270 X 25 X 0.89 mm. -- Wheels Diameter 725 mm -- Return conveyor on machine top

HOLYTEK SS-512 TS Shaper with Tilting Spindle, and Power FeederSpecifications: -- 1-1/4" Interchangeable spindle, 7.5 HP motor with (5) spindle speed settings of 3,000 - 4,000 - 6,000 - 8,000, & 10,000 RPM. -- Approx. 6" max. cap. under nut, 31" x 39" cast iron table. -- Insert ring diameters 2.8", 4/3", 6" and 8". -- Tilting spindle +10° and -45° -- Vertical movement of the spindle 7" -- sliding tableComplete with: -- Reverse rotation switch, adjustable fence assembly, and dust hood. -- 3-Roll Power Feeder

HOLYTEK - HRS-12TK, ...Straight Line Rip SawSpecifications: -- Overhead saw arbor, 15 HP motor belt driven, 4,500 RPM arbor. -- 12" Dia. max. saw blade. -- 3-3/8" Max. depth of cut. -- 18" Max. throat depth. -- 2 HP Stepped feed speeds of 50 - 65 - 83 - 100. -- Automatic lubrication of chain. -- Magnetic controls. -- Saw is glue line rated.Equipped with & Features: -- Overhead holddown rolls. -- Double-row of antikickback fingers. -- (6) Pressure rollers. -- Infeed adjustable fence line. -- Cast Iron table with rip fence.

Holytek 37DA Wide Belt Sander (2) Heads37" Width cap Drum, Combination Head1st Head: 7" Dia. spiral grooved rubber covered contact roller, 20 HP motor;2nd Head: Combination sanding head with 5" dia. spiral grooved rubber covered contact roll & 2" wide polishing platen, 15 HP motor.Specifications -- Abrasive belt size of 37" x 60" -- Pneumatic belt tensioning and electronic abrasive belt tracking -- 12" min. working length. -- 2 HP Conveyor belt motor, -- Variable feed speed from 13 - 52 FPM,Equipped with & Features -- Infeed & outfeed rubber covered holddown rolls; -- 0" - 4" motorized thickness adjustment by 0.5 HP motor. -- Safety stop bar, emergency rail stop across the front of conveyor -- Motor load meters.

HOLYTEK HK 610 Double Sided Planer with THOMAS MANUFACTURING Return ConveyorHOLYTEK HK 610 Double Sided Planer specifications - -- 24" x 8" Cap. Double Surface Planer, spiral carbide cutterheads belt driven by 20 HP top and 15 HP bottom motors at 4,000 RPM. -- Spriral cutter head 125 mm diam. with 96 inserts 30mm X 12 mm X 1.5 mm -- Variable feed motor delivers a range of 7 M./min to 20 M./min. (19.5 FPM to 82 FPM) -- Feed motor 3 HP, corrugated sectional infeed rollers and (4) table rollers provide superior feeding regardless of the type of wood being processed; hard-chromed table surface precision ground to provide smooth performance and maximum wear resistance at high speeds. -- Machines are currently wired for 220 Voltage.Technical Specifications:• Maximum width 610 mm (24")• Minimum length: 300 mm (11.9")• Maximum thickness 170 mm (6.69")• Minimum thickness 8 mm (.31")• Table size: 686 mm X 2616 mm (27" X 103")• Dovetailed slideways on the table elevation ensures stability and rigidity; a mechanical readout provides accurate details of table positioning adjustment; thickness limit guard is provided at the infeed end as a safety feature. • Machine Dimensions - 109" Long x 46" Wide x 68" High, Machine weight 7,280 lbsTHOMAS MANUFACTURING Return Conveyor specifications -37" Wide x 144" Long Receiving Table that transfers to a 20" Wide x 240" Long Return Conveyor1 HP - 3 Phase Variable-Speed DrivePhotoelectric SensorRemote ControlSolid State TimerSwing-Out Section that is 20" Wide x 90" Long

HOLZ-HER 1327 SPRINT CLASSIC SPECIAL EDGEBANDER + EVA/PUR GLUING TECHNOLOGY: -- Note: This is a "SPECIAL MACHINE for THIN TAPE Only". -- Specifications: Features the HOLZ-HER patented dual "GLU-JET" EVA & PUR Zero Joint Technology System.Edgebanding capacity: Edge thickness min./max. 0.4 - 8 mm (0.02 - 0.31"); coiled material 0.4 - 3 mm (0.016 - 0.157").Workpiece thickness: 6 - 60 mm (0.23" - 2.36"); Workpiece width min. of 65 mm (2.56").Workpiece length: Min. 160 mm (6.29"); variable feed speed 10 - 18 MPM (33 - 59 FPM). Machine Infeed: -- "Open Space" for Pre-milling Station "1802": (2) 2.0 kW (2.68 HP) - 12,000 RPM motors.NOTE: This machine is not equipped with the Premilling Station, but it can be added. -- Edge Magazine "1903":For coil & strip processing; utilizes motion detector to ensure accurate, trouble free positioning of edge material.Exclusive "Tractor Belt Feed System": Edge guide equipped with automatic guillotine lockout for safety.3° Approach angle allows easy feeding of solid wood edges. -- Pressure Section "1913 Mot":1-Axis Servo controlled adjustment of the edge thickness.Pneumatic Plunge controlled pressure section with: (1) Large driven roller and (2) cantered idle rollers. -- Gluing System "GJ301Auto":Glue Jet Hybrid Technology: Processes "EVA" or "PUR" glue in cartridge or granulate form.Motorized programmable glue nozzle (upper glue line); height positioning. approx. 3-minute heat up time. Workstations: -- End Trimming Unit "1918P": Front & Rear; 2 x 0.45 kW (0.6 HP) - 9,000 RPM each motor.For Straight or Chamfer trimming with: "UNI-POINT Axis for "PCS" pneumatic changeover/swiveling up to 10° bevel. -- Combination Trimming Unit "1827": Top & Bottom; 2 x 0.65 kW (0.87 HP) - 12,000 RPM each motor; for T & B Flush/Bevel/Radius trimming. - "ProLock" Clamping System for rapid tool change.Manual edge radius adjustment up to 3 mm & chamfer adjustment up to 15° with a max. edge thickness of 6 mm. -- "Open Space" for 2nd T & B Trimming Unit.NOTE-1: This machine is not equipped with the 2nd T & B Trimming Unit, but it can be added. -- "Open Space"for Profile Scraping Unit "1929P". NOTE-2: This machine is not equipped with the Profile Scraping Unit "1929P", but it can be added. -- "Open Space" for Finish Scraping "1964". NOTE-3: This machine is not equipped with the Finish Scraping "1964", but it can be added. -- "Open Space"for Buffing Unit "1940". NOTE: This machine is not equipped with the Buffing Unit "1940", but it can be added. Operator Interface: -- HOLZ-HER "PPC 231" Power-PC + "Windows-like" Operating System. - 15" SVGA Flat "Touchscreen" control.USB Connection & Ethernet network connection ready; programs can be easily created and recalled at will. Graphic interface makes programming easy; icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters that can be programmed.Edgebander can be operated manually when required, without necessity to write a program.

HOLZ-HER 1488 TRIATHLON EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING) + LIGMATECH -ZR01 Return Conveyor -- Specifications:Working Capacity: Max. 1" (25 mm) solid wood banding. thin PVC, Veneer, HPL & 3 mm PVC cap.; 60 mm (2.37") max. panel thickness, and 140 mm (5-1/2") min. panel length.Front-End equipped with: -- Pre-milling Unit: (2) 2.2 kW (3.0 HP) - 12,000 RPM; (1) jump spindle with digital indicators for positioning. -- Gluing System: "ULTRA-GRANUPRESS" System with: Flat glue nozzle only 3° angle of approach ideal for solid wood edgebanding & "quick melt" feature. -- Automatic Edge Magazine for: Coil, strip & solid wood edgebanding with TRACTOR-BELT feed system; Heavy-Duty guillotine for 4 mm PVC. -- Pressure Section with: (3) Large dia. rollers, each w/individual pneumatic plunge and pressure control; programmable with Servo motor positioning; powered 1st roller with electronic speed control synchronized with chain feed speed.Edgebanding Workstations: -- End Trimming Unit: (2) 0.75 HP - 6,800 RPM ea. "HF" Motors with: "Uni-Point Swivel", quick change from flush 0° - 15° bevel programmable from operator panel; Servo controls. -- Flush Trimming Unit: (2) 2.6 HP - 12,000 RPM - 200 Cy HF motors; Servo controls. -- Fine/Bevel/Radius Trimming Unit: (2) 1-1/2 HP- 12,000 RPM - 200 Cy HF motors; bevels 0° - 45°, Servo controls + SIKO digital readouts. -- Corner Rounding Unit: (2) "HF" Top motors & (2) HF Bottom motors for trimming leading-and-trailing upper-and-lower edge/corners; trailing edge (4 x 3/4 HP - 12,000 RPM - 300 Cy HF motors; 2 mm or 3 mm radius cap. -- Profile Scraper Unit: "Super Duty" for positively smooth finishing thick PVC for radius range from 2 - 5 mm; vertical & horizontal tracing wheels, positioning enabled through (1) Servo motor function from Control Panel; SIKO readouts for easy setup. -- Buffing Unit: (2) Lateral buffing wheel positioning motors with Oscillating & Programmable Jump Action for cleaning & polishing of edges (two 0.25 HP - 3,600 RPM motors); tilts 0° - 5°, Servo controls.Equipped with and Includes: -- PPC 231 Controller with 15" LCD color screen: 90% of all set-ups can be adjusted from the Control Panel; programmable for a large variety of edges like solid lumber, veneer strips or coils, HPL, thin & thick PVC; line control so there are no mechanical limit switches along the chain track. -- Variable feed speed from 8 - 20 MPM (26 - 65 FPM); panel overhang beyond chain 35 mm (1.38"); features automatic track pad lubrication. -- Factory Documentation: Operating and Spare Parts Manuals. -- Actual Model is: HOLZ-HER 1488 TRIATHLON + LIGMATECH ZR01

HOLZ-HER 1417 SPRINT Edgebander w/Premilling.Max. 1/2" (12 mm) solid wood banding & 3 mm PVC cap., 2-3/8" max. panel thickness and 5-1/2" min. panel length. -- Pneumatically controlled Pre-milling station with (2) 3 HP - 18,000 RPM motor vertical milling heads, both with pneumatic jump controls, SIKO digital readouts for setup & adjustment.Equipped with: -- Cartridge glue system (quick heat up time) with stackable hopper & floating glue nozzle for automatic height adjustment. -- Automatic magazine for coil, strip & solid edgebanding with heavy duty guillotine for 3 mm PVC. -- Pressure section is servo-motor controlled with: (1) Large drive roller and (2) idle rollers, each w/individual pneumatic plunge & pressure control, 1st roller with direct chain drive synchronized with conveyor belt feed speed.Workstations: -- Double motor end trim (0.5 HP - 300 Cy HF motors), adjustable 0° - 15° for chamfer cuts electro-pneumatically from control panel. -- Top & bottom flush trim unit (0.8 HP - 300 Cy HF motors 18,000 RPM). -- Servo driven top & bottom super finish & radius trim unit (0.8 HP - 300 Cy HF motors 18,000 RPM), bevels 0° - 15° for bevel cuts. -- Top & bottom profile scrapers for up to 3 mm thick PVC banding, radius range from 2 - 5 mm, vertical & horizontal tracing shoes for precise accuracy. -- Top & bottom jump buffing unit (0.25 HP - 2,600 RPM motor ea.), tilts 0° - 5°. -- Variable feed speed 8 - 20 MPM (26 - 65 FPM), panel overhang beyond chain 35 mm (1.38").Complete with: -- Microprocessor line control, 10 KVA Frequency Inverter; SIKO digital readouts on all high frequency trimming units for increased accuracy. -- Includes: Outboard panel support, and sound enclosure w/interior lights over entire machine.

HOLZ-HER - 1411-3, EDGEBANDER Cartridge Glue System, 5 mm edge thickness cap. (up to 13 mm w/optional tooling), 1-3/4" max. panel thickness, and 7" min. panel length.Equipped with: -- Automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff. -- Pressure section with (1) large dia. drive roller & (1) idle. Workstations: -- Double-motor end trim model "1918" (tilting 0° - 10°), 0.5 HP - 18,000 RPM motor each. -- Top & bottom radius trim model "1942", 0.8 HP - 18,000 RPM motor each (trim motors are 0.6 kW HF). -- Top & bottom glue scraper unit "1964", with air jets for blow-off. -- Top & bottom buffing unit "1940" (tilting cap. 0 - 5°), 0.2 HP - 1,400 RPM Motors each. -- Variable feed speed from 36 - 52 FPM. - Fixed outboard panel support. Complete with: -- PLC (Programmable Logic Control) for easy setup and program storage. -- Frequency converter, sound enclosure, and used tooling..

HOLZ-HER 1315 EDGEBANDER WITH CORNER ROUNDINGMax. 5/16" (8 mm) solid wood banding & 3 mm PVC cap., 1-3/4" max. panel thickness and 5-1/2" min. panel length.Equipped with: -- Cartridge glue system w/cartridge hopper & "quick melt" feature, automatic magazine for coil, strip & solid edgebanding; HD guillotine for 3 mm PVC, glue applicator nozzle. -- Pressure section with (1) large dia. drive roller & (2) idle rollers, each w/individual pneumatic plunge & pressure control, powered 1st roller with electronic speed control synchronized with chain feed speed.Workstations: -- Double motor end trim "1918" (0.5 HP - 18,000 RPM motor ea. 300 Cy HF motors), adjustable 0° - 10° for chamfer cuts electro-pneumatically. -- Top & bottom flush fine & radius trim unit "1942M" (0.8 HP - 300 Cy HF motors 18,000 RPM Motor ea.), bevels 0° - 15°, SIKO digital readouts. -- "Single Station" corner rounding unit for leading & trailing edge. -- "1929" Top & bottom profile scraper for thick PVC. -- Top & bottom buffing unit "1940" (0.25 HP - 2,600 RPM ea.), tilts 0° - 5°. -- Two feed speed 8/16 MPM (26 & 52 FPM), panel overhang beyond chain 35 mm (1.38").Equipped with: Opdraded Touch Screen Monitor Microprocessor for line control & glue temperature, 10 KVA frequency changer, outboard panel support, and sound enclosure w/interior lights over enclosed workstations of the machine, & used tooling on the stations.

HOLZ-HER CUT 85 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications:4,250 mm (167") Max. rip cut cap., 3,800 mm (149") pull back pusher stroke; 97 mm (3.8") saw blade projection.15 HP (11 kW) Main saw motor, 3 HP (2.2 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 328 FPM (1 - 100 MPM ), return speed of 328 FPM (100 MPM).Automatic cutting length limiter adjusts the cutting length at the end of the workpiece, automatic saw carriage lubrication. -- Pusher Fence:(7) Material gripper clamps; 259 FPM (80 MPM) forward positioning speed, 259 FPM (80 MPM) return speed.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with CUTCONTROL "Direct Cut" + "OPTIPRO" + Windows 2000 operating system,15" TFT Display with unlimited program storage via floppy disk, keypad for data entry, USB & RS-232 serial port, CD ROM & 1.44 MB disk drive for additional storage of programs.CUTCONTROL offers Real-Time Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."Direct Cut" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."OPTIPRO" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting. -- Complete with: Rear roller support rails; automatic crosscut side aligner; automatic saw blade height adjustment.(3) Air support tables, ea. 78" x 24" (1,981 x 509 mm). -- Actual Model is HOLZ-HER CUT 85 4300.

HOLZ-HER CUT 6220 Dynamic FRONT LOAD, AUTOMATIC PANEL SAW with 20'+ RIP cutting capacity!: -- Specifications: 4,300 mm (169.2") Max. rip cut cap., 6,250 mm (246") pull back pusher stroke; 105 mm (4.1") saw blade projection;28 HP (21 kW) Main saw motor, 3 HP (2.2 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 426 FPM (1 - 130 MPM ), return speed of 492 FPM (150 MPM).Automatic cutting length limiter adjusts the cutting length at the end of the workpiece, automatic saw carriage lubrication. -- Pusher Fence:(10) Material gripper clamps; 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EasyPlan" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials"Opti-Cut" & "EasyPlan" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non Marking rear roller support rails; Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm);Automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(4) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 24" (1,800 x 509 mm); -- Actual Model is HOLZ-HER CUT 6220 Dynamic

HOLZ-HER CUT 6120 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: 3,900 mm (153.5") Max. rip cut cap., 3,900 mm (153.5") pull back pusher stroke; 82 mm (3.2") saw blade projection.15 HP (11 kW) Main saw motor, 1.5 HP (1.1 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 320 FPM (1 - 100 MPM ), return speed of 416 FPM (130 MPM).Motorized bi-directional grooving capabilities with electronic adjustment for 0 mm - 35 mm.Automatic cutting length limiter adjusts the cutting height & cutting length at the end of the workpiece. -- Pusher Fence:(7) Material gripper clamps, (1) Double Finger mounted at the cross-cut fence location for narrow strip cutting & (6) standard clamps. 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Variable pressure settings for delicate materials. Pressure beam has an integrated "Last Cut" operation to achieve a "0" mm panel dimension.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EASY-PLAN" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Moving Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."Opti-Cut" & "EASY-PLAN" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non-Marking rear roller support rails: Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm). Side aligner is "Fully Automatic" adjustment when panel is less than 1,300 mm (51")"Quick Change" Blade system with automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(3) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 23.6" (1,800 x 600 mm); -- Actual Model is HOLZ-HER CUT 6120 Dynamic

HOLZ-HER - 1619, ...Boring Machine (Construction & Line Boring) -- Specifications:(19) Spindles on 32 mm centers; bores vertically from top and horizontally from the rear; repositions via manual air shock assisted tilting.2 HP Motor with: 2,800 RPM Gear driven boring head. -- Features:4-Position turret style depth stop for boring depth and a 4-3/4" max. stroke of boring head.24-3/4" Working width; 27-1/8" max. panel width; 19-1/2"; x 38"; x 32-1/2"; H table size. -- Equipped & Complete with:RH & LH Indexing fence with flip stops; (2) indexing pins (for continuous line boring); (3) 4" dia. pneumatic holddown clamps; foot pedal actuator; magnetic push button starter. -- Actual Model is: HOLZ-HER 1619Dimensions of this specific machine with pallet: 52" x 40" x 65" H.Dimensions of this specific machine when vertical: 52" x 37" x 60" H.Dimensions of this specific machine when horizontal: 52" x 51" x 46" H.

HOLZ-HER - 1435-SE EDGEBANDER"1906" Cartridge Glue System; 5 mm edge thickness cap. (up to 8 mm w/optional tooling); automatic magazine coil & strips; 3 mm PVC cap. pneumatic guillotine for coil cutoff. Workstations: -- Double-motor end trim, (2) 0.3 HP - 9,000 RPM motor ea.; chamfers 0° - 10°. -- Universal top & bottom fine trim (for bevels from 0° - 15°); allows simultaneous bevel & profile trimming; (2) 0.8 HP - 18,000 RPM motor ea.; all trim motors are 0.6 kW HF - 300 Cy. -- Top & Bottom PVC scraper unit for 0.8 - 5 mm radius; air jets for blowoff. -- Top & Bottom "jump" buffing (0.3 HP - 1,620 RPM ea.). -- Single feed speed: 35 FPM.Complete with: Built-in Operator Control Panel; outboard panel support; frequency converter; used tooling; and sound enclosure.

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging. Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM. -- Complete with: Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.
