Woodworking Equipment For Sale

UHLING HP-3000 Case Clamp ... offers versatility, quick (30) second set-up or changeover. -- Clamping Capacity, 55"- L x 96"- H x 24"- D, that's large enough for multiple boxes. -- Pressure Elements, (4) horizontal @ with (3) individual air pods, counter-weight balanced, position them effortlessly and let go, the counter-weight will keep them in place, no need to secure them! -- Air Pod Stroke, 3-1/2" with individual controls for each air pod set. -- Vertical Beam, moves easily on roller bearings with pneumatic carriage locks. -- Operator Control Panel, mounted on vertical beam, so it is always where it is needed, single lever lock-or-unlock control & front/rear pressure selection. -- Counter Support, by solid laminated panel opposite to pressure bars. OPTIONAL: Top Clamping, removable top pressure element for applications such as a vertical center partition or similar needs, removes easily if not needed. Add $ 1,000.00 to standard machine price.CUSTOM:HP-3000 F, ... comes with a "Solid Floor" for easy clamping of upper cabinets, add $ 1,000.00 to standard machine price.HP-3000 M, ... clamping capacity, 60"- L x 96"- H x 36"- D, that's large enough for deep commercial Case Goods. Please call for pricing.

UHLING - HP-3000: Case Clamp (Single-Bay) -- Specifications:Clamping Capacity: 55" L x 96" H x 24" D; Large enough for multiple boxes. - Offers versatility, quick 30-second setup or changeover. Pressure Elements: -- (4) Dual air pod pressure bars that are pneumatically activated and counterweight balanced; position them effortlessly and let go. The counterweight keeps them in place; no need to secure them! -- Air Pod Stroke: 3-1/2" Stroke of air pod with 0 - 120 PSI pressure adjustment. -- Vertical Beam: Moves easily on roller bearings with pneumatic carriage locks; (4) small air cylinders from (1) control point. -- Operator Control Panel: Mounted on vertical beam, so it is always where it is needed; single-lever lock-or-unlock control & front/rear pressure selection.

UHLING HP 4000 Case ClampThe most versatile, quick and easy-to-use Case Clamp on the market!Specifications: -- 100" x 50" x 24" Clamping cap. that's UHLING's most versatile Clamp ever. -- (3) Counterweight balanced, fully adjustable horizontal dual air pod pressure bars and (2) vertical, easy adjustable dual air pod pressure bars. -- 3-1/2" Stroke with individual controls for each air pod pair. -- Roller bearing mounted carriage with pneumatic locks (considered to be the fastest 2-axis Clamp on the market). -- Single lever lock-or-unlock control and front/rear pressure selection. -- Solid panel counter support that is opposite the pressure bars. -- Easy access operator's control panel that's mounted on the vertical beam. -- Approximately (30) Sec or less changeover time. -- Options: Additional dual pod pressure bar assembly for vertical or horizontal.

UHLING HP-4000 ... is a versatile, quick and easy-to-use Case Clamp.Specifications: -- 100" x 50" x 24" Clamping cap. that's UHLING's most versatile Clamp ever. -- (3) Counterweight balanced, fully adjustable horizontal dual air pod pressure bars and (2) vertical, easy adjustable dual air pod pressure bars. -- 3-1/2" Stroke with individual controls for each air pod pair. -- Roller bearing mounted carriage with pneumatic locks (considered to be the fastest 2-axis Clamp on the market). -- Single lever lock-or-unlock control and front/rear pressure selection. -- Solid panel counter support that is opposite the pressure bars. -- Easy access operator's control panel that's mounted on the vertical beam. -- Approximately (30) Sec or less changeover time. -- Options: Additional dual pod pressure bar assembly for vertical or horizontal.

UHLING HP-3000 55" L x 96" H x 24" D Single-Bay Pneumatic Case Clamp Specifications: Clamping Cap. 55" L x 96" H x 24" D, Accommodates multiple boxes. Air pod stroke 3-1/2", Pressure adjustment 0 - 120 PSI. Setup time (25) Sec., Changeover time (30) Sec. Equipped with: Vertical beam, with (3) Counterweight-balanced & (1) Stationary 24” W x 5-3/4” H dual air pod pressure bars, Roller bearing mounted carriage with Pneumatic locks, Adjustable in 5” increments. Solid back support. Adjustable squaring arms. Carriage mounted control panel, with Single lever lock & Individual air pod selection. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

ULTRA GL-630H Feed Through Moulder: 6-Head (B-T-R/L-T-B), "Flooring" working capacity of 12" x 6".Specifications: -- Head sequence: Bottom 25 HP, top 30 HP, right 20 HP/left 20 HP (opposing), top 25 HP, and bottom 25 HP motor. -- Spindle dia. of 1-13/16" with cutterhead speed of 6,000 RPM; all spindles with high prevision bearings. -- Auto. positioning of the left & top spindles radially; all additional spindles with digital readouts, including chipbreaker & pressure elements. -- Pneumatics on all chipbreakers, pressure elements, and holddown rollers. -- Horizontal spindles with HydroLock outboard bearings on #1, #2, #5 & #6. -- Straight jointer on spindles #5 & #6; Profile Jointers on spindles #3, #4, #5 & #6. Equipped with: -- Inverter controlled feed drive, variable speed of 26 - 260 FPM. -- Infeed table 1.2 M (4') with all table plates & fences hard chromed to RC 70. -- Machine table includes: (5) Table rollers for smooth through feed; short stick attachment for through feed on pieces down to 230 mm. -- Electrical cabinet & pedestal for machine controls separate from machine, Heavy Duty sound enclosure. -- Includes Startup training and Warranty!

UNIMAK GS140-S Single Sided Hot Melt Glue Laminator4-Foot Wide Hot Melt Glue Spreader for PUR and other Hot Melt Adhesives. Panel Types: MDF, Particleboard, door spar, XPS and Polystyrene sandwich panels. All kinds of panels where adhesive application is required.Glue Types: Polyurethane Hotmelt (PUR) glue. Unfilled EVA.Pressure Sensitive Foil Types: As roll material - PVC, P.P., finish foils and CPL foils. As sheet Stock - Veneer, PVC, laminate, acrylic sheets and door surfaces. Working Speed : 5 - 25 m/Min (16.4 - 82 FPM).Technical Specifications: -- Max. External Working Temperature: 180 ° C (365° F), Chromed Roller. -- Working Width: 200 - 1,400 mm (7-7/8" - 55"). -- Board Thickness: 4 - 210 mm (1/8" - 2-1/4"). -- Upper Spreader Roller - 240 mm (9-1/2") diameter, Silicone Coated. -- Upper Dosing Roller: 215 mm (8-1/2") dia., Chromed. -- Lower Transport Roller: 240 mm (9-1/2") diam., Silicone coated. -- Total Power: 15 kWMelter and Hose are not Included, they are optional and can be quoted separately or purchased locally.

UNIMAK 160-S 5-Foot Wide Single-Sided Hot Melt Glue Spreader for Hot Melt Glue including PURHot Melt Glue Spreader for PUR and other Hot Melt Adhesives. Panel Types: MDF, particleboard, door spar, XPS, and polystyrene sandwich panels. All kinds of panels that adhesive application is required.Glue Types: Polyurethane hot melt (PUR) glue. Unfilled EVA,Pressure Sensitive Foil Types: As roll: PVC, P.P., finish foils and CPL foils As sheet Stock: Veneer, PVC, laminate, acrylic plates and door surfacesWorking Speed: 5 - 25 meter/Min (16.4 - 82 FPM)Technical Specifications: -- Max. External Working Temperature: 180 ° C (365° F) - chromed roller. -- Working Width: 200 - 1,600 mm (7-7/8" - 63"). -- Board Thickness: 4 - 40 mm (1/8" - 1-5/8"). -- Upper Spreader Roller, Silicone Coated and Ø 240 MM (9-1/2"). -- Upper Dosing Roller: Ø 215 MM – Chromed (8-1/2"). -- Lower Transport Roller: Ø 240 MM – Silicone coated. -- Total Power: 15 kWMelter and Hose are not Included, they are optional and can be quoted separately.

UNIQUE 250 GT2 Automatic Raised Panel Door ShaperMachine to manufacture raised panel cabinet doors with (1) operator in (2) Min.Specifications: -- Two Counter-Rotating Variable Speed Direct Drive 10 HP Shaper Motors. -- 5" of vertical stack height, capable of stacking up to (3) cutters. -- Three (3) Position Turret for quick change over between profiles. -- The change from one cutter to another is achieved via a select switch for each operation. -- Two-position pneumatic stop system positions automatically when cutters are selected -- Easy to read positioning scale allows for accurate centering of Arched panel and rail. -- Free-floating table w/pneumatic holddown has a 2-way linear movement for straight or cathedral top doors up to 55" long.Complete with: -- (1) Set of templates (998800). -- One set of tooling included. Set includes Unique 410 cope / rail cutters and 460 panel cutter with back cutter. -- Please call for other options.

UNIQUE 2700 CNC CNC Door ShaperCNC Controlled Machining Center for Raised Panel Doors.Equipped with: -- (1) CNC controlled 5" stackable vertical spindle (max. 4 tools per stack), 7.5 HP belt driven; max. clamping thickness 2-1/2" and 6" max. cutter head diameter. -- "X" Axis of spindle travels 81" on (2) THK rails with ball screw movement, "Y" axis with 5" travel on THK rails with 5" max. workpiece overhang, "Z" axis with 5" max. travel on THK rails.Features: -- Windows based PC computer with large touch screen menu for quick set-up, new door or custom door stiles can be programed in minutes, automatic operation from one style and size of door to the next, straight raised panels & widths of stile or rail and end tenoning work the same. -- Electronic sensors measure the length of the part to be cut allowing for various width panels or rails to be shaped consecutively, once a door is pre-programmed it can be re-called.Complete with: Electronic brake on spindles, (2) 5" dia. outlets for dust collection and UNIQUE's Windows based "Raised Panel Door" Software. .

UNIQUE 2753 Arch Shaper with Sanding HeadThe Unique Model 2753 Is A Single End Machine Designed For High Quality, High Production, Cabinet And Passage Door Arching Of Top Rails And Panels. Its Two Counter-Rotating Spindle Motors are Easily Programmed For Multiple Cuts With Hogging And Finishing Cutters To Eliminate Tear-Our And Extend Tool Life. A Sanding Station Provides A Multi-Pass Sanding Finish On Arched Door Panel Profiles. Unique “ArchPro"; Software Guarantees High-Speed Measuring And Fully Dynamic Programming Abilities.• Shaper Motor: (2) 10 HP Himmel Direct Drive , 440V - 39.2A, 3PH Motor• 5" Stack Height • Compressed Air Requirements: 90 PSI - 2 CFM• Dust Collection: (2) 5" Diameter 1200 CFM each (1) 4" Diameter 800 CFM each• Work Height: 3’6"• Machine Footprint: 113" Width X 78" DepthIncludes - Safety Mats, Dust Collection Manifold, and Owner's Manual

UNIQUE 280-3-60 Door ClampThis 3' x 6' Door Clamp Table on a 60° angle, is designed for ALL shops to accurately square and clamp cabinet or entry doors, panels, etc. -- The UNIQUE magnet and pin combination mounted air cylinders, allows the operator to move them to any location on the table. -- Includes; (4) cylinders, (1) foot valve and (1) squaring bar. One or more projects may be clamped simultaneously on this diversified table.NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

UNIQUE 280-4-60 Door Clamp. This 4' x 8' Door Clamp Table, set at a 60° angle for more comfort, is designed for ALL shops to accurately square and clamp cabinet or entry doors, panels, etc. -- The UNIQUE magnet and pin combination mounted (6) air cylinders, allows the operator to move them to any location on the table. -- One or more projects may be clamped simultaneously on this diversified table. -- Includes: (6) cylinders, (1) foot valve and (2) squaring bars. -- Option; Overarm with (4) cylinders and (1) Foot valve NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

UNIQUE 285 Door Clamp This 6' x 12' Door Clamp Table, is designed for ALL shops to accurately square and clamp cabinet or entry doors, panels, etc. -- This table set at a 60° angle allows (2) operators to work side by side. -- The UNIQUE magnet and pin combination mounted air cylinders, allows the operator to move them to any location on the table. -- One or more projects may be clamped simultaneously on this diversified table. -- Includes; (10) Cylinders and (2) squaring bars and (2) Foot valves to accomodate (2) operators. -- Options; Overarm with (5) cylinders and (1) Foot valve. -- (4) zone operation with center squaring bar, (2) extra foot valves and (6) extra clamps...ask Product Manager

UNIQUE 310 Automatic Cope Shaper; Copes multiple workpieces up to 6" wide x 24" long in only (1) pass, quickly and accurately. -- Equipped with: (2) 5 HP motors with magnetic starter; (2) 1-1/4" dia. counter-rotating cutterheads eliminate tear-out on detail edge of cope/tenon cuts. -- Pneumatic safety clamps hold work in place until sliding table is returned to its forward position.

UNIQUE 310-40 1-1/4" Double-Sided End Cope Shaper Specifications: Max. length 40", Max. width 6", Max. thickness 1". Table size 13” x 42-1/2” x 37-1/4” H, Table travel 14-1/2”. Spindle dia. 1-1/4". Equipped with: (2) 5 HP - 3,450 RPM TEFC Motors, Counter-rotating spindles. Pneumatic hold-downs, Foot pedal control. 39-1/4” L x 1/2” H Fence. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

UNIQUE 71 Pocket Hole Boring Machine -- The UNIQUE "71" is a Single Spindle Pocket Drill capable of producing screw holes with unlimited spacing. -- The heavy-duty industrial construction has proven to give years of service with minimal maintenance. -- Push button control. -- Brand New with Warranty!NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

UNIQUE 73 Pocket Boring MachineThe UNIQUE "73" Drill Tub is a pocket drill capable of producing screw holes with unlimited spacing. -- Heavy-duty industrial construction has proven to give years of service with minimal maintenance. Push button control. -- Double spindle boring tub, 2 drills with counterbore.

UNIQUE 73 Pocket Boring MachineThe UNIQUE "73" Drill Tub is a pocket drill capable of producing screw holes with unlimited spacing. -- Heavy-duty industrial construction has proven to give years of service with minimal maintenance. Push button control. -- Double spindle boring tub, 2 drills with counterbore.NOT IN STOCK - PRICING SUBJECT TO CONFIRMATION.

UNIQUE 79 Face Frame Assembly Table. The UNIQUE Face Frame Assembly System simplifies the assembling process. -- This is to ensure flush alignment of frames reguardless of thickness of material. -- Major face sanding is eliminated. -- 60° Laminated 5' x 8' assembly table, squaring bar. -- Over arm with (5) hold down clamps.
