Moulders For Sale

CAM-WOOD SM-3006 Push Feed Moulder4" x 6" 3-Side Planer, Moulder; Our most cost effective small to medium shop size Push-Feed Moulder.Equipped with & Features: -- If you try to run your short runs of special moulding at lower prices, this machine could be your answer. -- Solidly built with cast and steel plate construction, this is one moulder that will give you a foot up on the competition at an affordable price. -- Precision cast and steel plate construction to ensure a smooth finished product. Two vertical and one 1-1/4" horizontal spindle driven by individual industrial motor allowing smooth cutting on three surfaces simultaneously. -- Alloy steel spindle for durability usage. -- Two power infeed rollers feed the material to push previous pieces through moulding process then comes out from the end. -- (2) Belts driving at each spindle for maximum cutting power. -- Top and side pressure hold down to ensure smooth finish. -- Industrial full power motor for maximum cutting capacity. -- Precision sealed long-life bearings. -- Heavy cast iron frames and table for durability usage.Specifications: -- Table Size 47" L x 10" W. -- Moulding Capacity (Max.) 6" W x 5" H, Capacity (Min.) ¼" W x ½" H. -- Top Spindle Size 35 mm x 6" long. -- Side Spindle Size 1¼" x 3½" long. -- Spindle Travel 3", Spindle Speed 7000 RPM. -- Max. Cutter dia. 5". -- Spindle Motor (Top) 5 HP, (side) spindle motors 3 HP each. -- Feed Motor ½ HP and Feed Speed 10 ~ 56 FPM. -- Dust Hood 4" x 4". -- (2) Top Pressure Rollers and (3) Side Pressure Rollers.Overall Dimensions & Weight: -- 51" L x 43" W x 41" H. -- N.W. 1210 Lbs, G.W. 1550 Lbs.

CAM-WOOD SM-156A Feed Through Moulder;6-Head (B-R-L-T-T-B), working cap. 6" x 4".Specifications: -- Head sequence: Bottom 5 HP, right 4 HP, left 4 HP, top 10 top, top 5 HP and bottom 5 HP motor. -- Spindle diameter 40 mm with cutterhead speed of 6,000 RPM; spindles equipped with mechanical readouts for axial and radial adjustments. -- 4 HP Feed Motor variable speed 16- 65 FPM; carden drive system. -- 1.2 M (4'0") Infeed table with lateral side pressure roller mounted at table infeed. Manual table lubrication pump. -- Dust collection Min. 3,500 CFM -- Air requirement 90 psi. -- 150 AMPs. at 220 V. -- Machine dimensions , length & width 137"; long, x 54"; Width x 68"; High

CAM-WOOD SM-156A Feed Through Moulder;6-Head (B-R-L-T-T-B), working cap. 6" x 4".Specifications: -- Head sequence: Bottom 7.5 HP, right 5.5 HP, left 5.5 HP, top 10 top, top 7.5 HP and bottom 7.5 HP motor. -- Spindle diameter 40 mm with cutterhead speed of 6,000 RPM; spindles equipped with mechanical readouts for axial and radial adjustments. -- 4 HP Feed Motor variable speed 16- 65 FPM; carden drive system. -- 1.2 M (4'0") Infeed table with lateral side pressure roller mounted at table infeed. Manual table lubrication pump. -- Includes: Short stock attachment, set up tools and manuals. -- Dust collection Min. 3,500 CFM -- Air requirement 90 psi. -- 150 AMPs. at 220 V. -- Machine dimensions , length & width 137"; long, x 54"; Width x 68"; High Note: Brand New with Warranty!

CAM-WOOD Model SM-236U Moulder Feed Through 6-Head (B-R-L-T-T-U), working cap. 9" x 4-3/4"Specifications: -- Head sequence: Bottom 10 HP, Right 10 HP, Left 10 HP, Top 15 HP, Top 15 HP and Universal 7.5 HP motor. -- Max. (Min.) Working Thickness 4-3/4" -- Min. Working Length 9½" -- Feed Motor 7½ HP and Elevation motor 1½ HP -- Spindle Dia.: 40 MM with cutterhead speed of 6,000. Mechanical digital readouts for all spindle adjustments, as well as chip breakers and pressure elements. Tool cutting circles: vertical spindles 5" to 6.25" and top spindles 5" to 7". -- Variable Feed: From16 ~ 110 FPM with LED speed readout. Over-sized top and bottom rollers run synchronized, ensuring smooth feeding. The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding. -- Universal spindle with 270° rotation from the left side. -- Includes: Infeed table 2M (6'6") with manual table lubrication ports. Side pressure roller at infeed; Hard chrome-plated table for maximum wear resistance. Full sound and safety enclosure and manuals.

CAM-WOOD SM-623L Moulder, Feed Through 6-Head (B-R-L-T-T-B), working cap. 9-3/4" x 5-1/4". Head sequence: -- Bottom 10 HP, right 10 HP, left 10 HP, top 20 HP, top 15 HP, and bottom 20 HP motor. -- Spindle dia. 40 mm with a cutter-head speed of 7,200 RPM. All spindles with mechanical digital readouts. -- Feed: Variable speed of 26 - 119 FPM, with 7-1/2 HP feed drive motor. Powered feed rollers top and bottom. -- Infeed Straightening table 2M (6'6"), with side pressure roller and table lubrication pump. -- Dust outlet Diameters are 5" X 6" outlets. Includes: -- Hard chrome-plated fences and table, -- Operator/spare parts manuals, -- Centralized control panel, -- Sound and safety enclosure, -- Short stock feeding mechanism (9 1/2" min length), -- Power elevation (1-1/2 HP beam.)Options:Training and installation, tooling & rigging are optional. -- SM-KFST Knife Setting Stand ...$1,970.00The machine base is one piece coated from high-quality cast iron (FC-25) for maximum stability of the structure. Base is machined by CNC machine equipment to ensure the utmost working accuracy. Net weight 11,220 Lbs Shipping weight 12,300 Lbs.

CAM-WOOD SM-155AX Feed Through Moulder 5-Head Moulder with a 6" width and a 4.75" max. thickness capacity.Overall Description: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 16 - 66 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments except 1st bottom spindle with mechanical digital readouts. -- Left and Top spindles with mechanical Digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 5' Infeed table length, Chromed table plates, fences, and pressure shoes. Manual Waxilit pump, Central lubrication of the machine from the front side.Specifications: -- Max. (Min.) Working Width 6" (3/4") -- Max. (Min.) Working Thickness 4-3/4" (5/16") -- Min. Working Length 9½". -- 1st Spindle Horsepower 7½ HP. -- 2nd, 3rd Spindle Horsepower 5½ HP, 5½ HP; -- 4th, 5th Spindle Horsepower 10 HP, 7½ HP. -- Cutterhead Dia.: 1st Bottom Head 5" dia.; 2nd, 3rd Vertical Head 5" - 6-1/4" dia.: 4th, 5th Head 5" - 7" diameter. -- Feed Motor 4 HP. -- Elevation 1 HP motor. -- Spindle Diameter 40 mm. -- Cutter Head Speeds 6,500 RPM. -- Variable Feed Speeds 16 ~ 66 FPM. -- Pneumatic Air 90 PSI (5 CFM by bolume) -- Dust Outlet Diameter 5" x 5" -- Net Weight 5,900 Lbs; Gross Weight 6,700 LbsIncludes: -- Operator/spare parts manuals and setup tools.

CAM-WOOD - SM-236AX, ...Moulder Feed Through 6-Head (B-R-L-T-T-B), working cap. 9" x 5-1/4". Specifications: -- Head sequence: Bottom 10 HP, Right 10 HP, Left 10 HP, Top 15 HP, Top 10 HP and Bottom 10 HP motor -- Max. (Min.) Working Thickness 5-1/4" (5/16") -- Min. Working Length 9-1/2 in. -- Feed Motor 4 HP, variable feed speed from 16 - 82 FPM -- Elevation motor 1 HP -- Spindle Dia.: 40 mm with cutterhead speed of 6,500 RPM. -- Mechanical digital readouts for all spindle adjustments, as well as chip breakers and pressure elements. -- Tool cutting circles: First bottom head 5", 2nd & 3rd head 5" to 6-1/4", 4th to 6th head 5" to 7".Feed System: -- Variable Feed Speed from 16 - 82 FPM with LED speed readout. -- Oversized top & bottom rollers run synchronized, ensuring smooth feeding. -- The (3) independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding.Complete with: -- Infeed table: 2M (6'-6") with manual table lubrication ports. -- Side pressure roller at infeed. -- Hard chrome-plated table for maximum wear resistance. -- Full sound and safety enclosure and manuals.

CAM-WOOD SM-124TAX Feed Through Moulder4-Head Moulder with a 11-3/4" width x 9" maximum thickness when used as a 2-sided planer, and 10-1/4" width x 4" maximum thickness when used in 4-sided operation ( please see literature ).Equipped with: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 11 - 52 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments with mechanical digital readouts. -- Left and top spindles with mechanical digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 40" Infeed table length, Chromed table plates, fences, and pressure shoes. Manual waxilit pump, Central lubrication of the machine from the front side.SPECIFICATIONS SM-124TA Max. (Min.) Working Width 10-1/4"Max. (Min.) Working Thickness 4"1st Spindle Horsepower 4.1 HP - 7,000 RPM2nd, 3rd Spindle Horsepower 4.1 HP - 7,000 RPM4th, Spindle Horsepower 4.1 HP - 7,000 RPMFeed Motor 1/2 HPSpindle Diameter 40 MMCutter Speeds 6,500 (RPM)Variable Feed Speeds (FPM) 17 ~ 66Cutter head Diameter 1-1/4" or 30 mmPneumatic Air 90 PSI (CFM) 5Dust Outlet Diameter 5" x 4"N.W. 1,157 LbsG.W. 1,366 LbsIncludes: -- Operator/spare parts manuals and set-up tools.

CAM-WOOD SM-632LX 6-Head Feed Through Moulder[6-Head (B-R-L-T-T-B), working cap. 12-1/2" x 6"]Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with a cutterhead speed of 7,600 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chip breakers; all chip breakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 38 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 98' per minute are a standard feature. -- The full safety enclosure covers as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-532L 5-Head Through Feed Moulder5-Head (B-R-L-T-B), working cap. 12-1/2" x 6".Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP and bottom 20 HP motor. -- All Horizontal spindle have outboard bearings -- Spindle dia. 50mm with cutterhead speed of 7,600 RPM. -- All spindles equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 28 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 28' ~ 98' per minute are a standard feature. -- The full safety enclosure cover as chip guard and helps to reduce noises. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table, permits the table to be position extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-632 HS 6-Heads High-Speed Through Feed Moulder(6) Heads (B-R-L-T-T-B), working cap. 12-1/2" x 6-1/4"".Specifications: -- Max/Min working width 12 " - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic Jointer for all (6) heads add: ...$46,900 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications) -- For 6 heads machine add $82,800 -- For 7 heads machine add $ 90,600

CAM-WOOD SM-167AX Lateral Chain FeederLateral Chain Feeder for up to 11.8"' X 16' long materialFeatures: -- The feed table is designed to be able to connect with any 4-sided Moulder, Multiple Blade Rip Saw, Straight Line Rip Saw and Planer -- Feed rollers are pneumatically actuated for quick clamping of wood. The feed speed of the front set of rollers is adjustable to match the moulder -- Hydraulic drive motors for each feed roller allow variable feed drive -- Centralized control panel, with push-button for start and stop, chain feed regulation and display, feed roller raising/lowering control -- Infeed fence, the infeed fence allows the material to be lined up properly with the feed roller -- Wood thickness limit. There are two adjustable thickness limits preventing over-thickness material to enter the moulderSpecifications: -- Working width 25 to 300 mm (1" to 11.8") -- Working thickness: 8 to 160 mm (0.315" to 6.3") -- Working lenght: 2,000 mm to 7,000 mm (78.7" to 275.6") -- Infeed table 5,425 mm L X 2,090 mm W X 1,920 mm H ( 213.5' L X 82.2" W X 75.5" H) -- Minimum working length: 1,000 mm (39") -- Feed speed: 10 - 120 MPM (32.5 FPM - 390 FPM) -- Feed motor drive for hydraulic motor: 5 HP -- Table feed motor: 2 HP with inverter control -- Feed roller diameter: 140 mm (5-1/2")

CAM-WOOD SM-623-HS 6-Head High-Speed Trough Feed Moulder(6)-Heads (B-R-L-T-T-B), working cap. 9" x 6-1/4".Specifications: -- Max/Min working width 9-3/4" -- Max/Min thickness 6-1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 10 HP, right 10 HP, left 10 HP, top 15 HP, top 15 HP and bottom 15 HP motor. -- Spindle dia. 40 mm (or by request) with cutterhead speed of 6,200 RPM. -- Feed works: Inverter driven, 10 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2 M (6'6"), chromed tables, and fences. Side pressure roller mounted at the infeed. Features and complete with: -- SM-237-DG where the last bottom spindle can be used for cutter head or saws with inverter RPM control -- HMI Touch Screen Control for all the head positions -- Automatic setting from 2nd to 6th heads, (2) axis positions and thickness control by servo control movement -- 200 sets of memory (Extendable) -- Feed speeds ranging from 20' ~ 260' per minute are standard specifications. -- Hard chrome-plated table for maximum wear resistance. -- Full enclosure safety hood reduces noise and completely prevents chips from splashing. -- Anti-impact plate for over-width and over-thickness protection. -- Oversize top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard features maximum durability and is impact resistance. -- The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers canbe set with individual pressure allowing for consistent feeding results and outstanding effect. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Exclusively designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate with table feeding roller design, provides smooth and precise cutting of dry and wetwood, reducing the possibility of material jams. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic jointer head for all (6) heads add ...$ 58,500 -- Siko encoder with digital display for all axis add ...$ 4,200 per head -- Automatic lateral chain feeder P.O.R.

CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys

CAM-WOOD SM-545 HS 5-Heads High-Speed Trough Feed /Planer/Moulder(5) Heads (B-R-L-T-T), working cap. 450 mm X 160 mm (17-7" x 6-1/4").Specifications: -- Max/Min working width 17.7" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, and top or bottom 20 HP . -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications)

A. Costa Spamatic 220 Molder

Each system is custom built to fit your specifications. Standard Electric Lateral Chain Feeders include Basic Feeder with transport length of 30" Workpiece width 3/4" - 9-1/4" Min. Workpiece length 12" Drive system with 4 HP total drive system Feed speed range 50 - 250 ft/min (up to 400ft/min available) Thickness 1/4" - 4" Steel flat top chain 60 Cycle per minute Adjustable Fence 35MM Feed Wheel Shafts Options 6'-16' Lateral Chain Feeder Feed Wheel Knurled, Urethane or Light Knurl Hub Options 3/4" or 2" Powder Coating Bridge Side Fence Feed Speeds up to 400 FPM Short Stock Fence 12" Wide Capacty

DIEHL - TFM-68, ...4"; x 8"; 5-Head High Speed Jointed Moulder5-Head (B-R-L-R-T-B) with 8-5/8" x 4-1/2" capacity. Head sequence: Bottom 15 HP, Right 10 HP, Left 10 HP, Right 10 HP, Top 15 HP, and Bottom 20 HP motor.1st Bottom and 1st right side run at 3,600 RPM; all the other spindles run at 6,000 RPM utilizing the included Frequency Changer.Side heads tilt 35° inward and 5° outward. Specifications: -- Spindle diameter: Vertical 1-13/16"; Horizontal 2-1/8" dia. for top spindle only. -- Built-in straight & profile jointers on spindles 2 - 3 - 4 & 5. -- Variable feed speed from 20 - 150 FPM via 15 HP feed drive. -- Cardan Shaft driven. -- WAXLIT Pump and groove bed with groove cutters for 1st bottom. -- Air chipbreakers and feed roll tensioning. -- Starting panel and transformer included.Weight: Approx. 14,000 Lbs

DIEHL DL-405 MOULDERSpecifications: -- 5-Head, 8-5/8" x 4-1/2" cap. -- Head sequence: Bottom 15 HP, right 10 HP, left 10 HP, top 15 HP, bottom 10 HP motor; all spindles 1-13/16" dia., belt driven at 6,000 RPM; detachable jointers on side, top, and bottom spindles, spindles reversing on side heads; -- Mechanical digital readout for left horizontal spindle & top vertical spindle. -- 5 HP Feed motor, Cardan drive, variable feed speed 22 to 135 FPM, motorized feed beam, dual action holddown, powered lower infeed and outfeed rolls, pneumatically pressured feed rolls and top chip breakers with separate regulator and gauge for rolls after the top spindle.Equipped with: -- Automatic bed lubrication, hardened bed plates, attached operator's console, sound enclosure, 77" x 9" straightening table.- Also includes dust collection manifold.

DOUCET MFE 300 Lateral chain feeder for moulders and optimizers -- 3'0" x 16'-0" working deck for material length 2'0" - 16'0"; width 2" to 9.5" and thickness 1/2" to 4". -- Feed system: Hydraulic variable speed 50-300 FPM with a 20 HP power unit. In-feed (4) roller accelerator; (2) top steel rollers and (2) bottom drive roller. Additional idler rollers along feed fence to support lumber during feeding. -- Chains: Transport length of lateral chain feeder 3'0". (8) strands of C2060 chains on pneumatic up/down device to release lateral pressure on board when feeding. -- Pedestal: Feeder controls mounted to pedestal with extended cable. Interface relay to stop feeder when moulder is stopped. -- Adjustments: Tool less adjustment handles for quick setups. Easy access to for thickness adjustments at front side of feeder. -- AVAILABLE OPTIONSOne (1) set of four (4) feeding wheels made of steel with hardenedsurface teeth $ 1 000.One (1) set of four (4) feeding flat wheels made of steel, 2" wide insteadof 1" for wide material feeding $ 500.One (1) set of four (4) feeding flat wheels made of steel 1" wide $ N/C.Guiding Tunnel between feeder and moulder,Standard Guiding Tunnel (4' long) $ 1 650.Standard Short Guiding Tunnel (32" long) $ 2 100.Complete Guiding Tunnel (4' long) $ 2 700.Complete Guiding Tunnel with adjustable fence (4' long) $ 3 800.Motorized Guiding Tunnel (4' long) on request.Additional chain transfer length capacity (up to a maximum of 6additional feet) For MFE-300-16 sold per foot $ 1 685. Note: More than 6 add. feet: price upon requestSteel plates between chainsFor MFE-300-16 $ 1 050.Platen chains recommended for softwood speciesFor MFE-300-16 $ 2 850.One (1) additional chain for shorter material down to $ 1 750.18" min. lengthPressurized lateral guide with roller bearing end $ 1 400.Powered lateral guide with roller and side guides on request.Custom working height on request.
