Boilers For Sale

SolaGen 650,000 BTU / Hour Pellet Boiler - Complete System with Scafco 12 ft Diameter 1540 Cu. Ft. Storage Silo. Decommissioned from Pool Heating when natural gas main was installed and available in town. Equipment includes all factory components, control panel and 3 phase panel, pumps, plate heat exchanger, expansion tank, valves. FlexFlo pellet feed system. Ash auger moves ash to outside bin. Full Set of factory manuals included. Several tons of pellets in sealed totes available. Silo can be included or excluded, depending on transport options. $69,000

BARKER 600 HP BOILER, BIOMASS-FIRED: -- BARKER Boiler and Fuel System built & tested in 2011 as a pilot unit. Successful testing has been completed. This surplus equipment includes the following main features: -- Combustion Temp Capability- 2,000 deg. F.; Steam Flow 24,000 lbs/hr saturated; Steam Pressure 1,500 PSI @ 600 deg. F. -- Fuel Feed rate - 3,000 Lbs/hr at 1/4" biomass (5% moisture) -- Heat Input - 7,500 btu/Lbs HHV @ 22 mmbtu/hr. -- All equipment has less than 2,500 actual operating hours since installation.EQUIPMENT MAJOR COMPONENTS: Combustor, Cyclonic combustion technology, Refractory lined Heat Recovery. Steam Generator. Rotary Drum Dryer for Fuel drying - capable of 30% moisture reduction (at the above combustion parameters) and 1.5 tons per hour (installed as used equipment).BALANCE OF PLANT FUEL FEED SYSTEM: Live-bottom bin, Bunker, Feed conveyors, Wood hog, Vibrating screen, Drag and screw conveyors. Boiler water system - feed pump, water and steam piping Emissions Control: All required bag houses (SJVUAPCD) California permitted. -- Now REDUCED PRICE from $1.5 million !!

BOILERSMITH 400 HP BOILER, WOOD-FIRED -- Wood-Fired BOILERSMITH Boiler fitted with CHALLENGER Combustion Unit. -- Complete with the following major components and features: -- 250 PSIG design pressure. -- BOILERSMITH Boiler Model HRT2H8-2600SF-XW-250 with 2600 Sq. Ft. boiler surface area. -- Fuel can vary in moisture up to 50%. (Boiler HP is reduced as moisture increases.) -- Fuel feed Auger with Variable Frequency Drive. -- Fire-Tube Boiler with integrated Air Blast Tube Cleaning. -- De-Ash Augers. -- All Electrical Controls and starters. -- All mechanical/electrical engineer's drawings.NOTES: Removed and ready to load onto two trucks, 38,000 and 42,000 pounds. 15,000 to 16,000 pounds per hour steam if burning wood pellets. No building included but same building can be purchased from STAR.

BRYAN CL 240-W-GI BOILER, HOT WATER TUBEThis Boiler was taken out of an Office Furniture Factory where it was used to heat drying tunnels to a temp of 120 F.Disconnected and in storage for 1-1/2 years.Details & Specifications:Model: CL240-W-GIInput MBH: 2,160/1,080Output MBH: 1,728BRYAN #: 971292Relief Valve Setting: 50 PSIGHeating Surface: 287 sq/ftMAWP Water: 60 PSIGNational Bond #: 41033Canadian Reg #: E6190.25Gas Data:Natural GasMax Input CFH: 2,160Min. Input CFH: 1,080Min. supply Pressure: 7 In. WCMax supply pressure: 14 In. WCManifold pressure in WC: 3.5Orifice size: DMS 29

12,000 MBTU Natural Gas or Propane Fired New never used (2) Available

CB Package Boiler Natural Gas, CBI 700-300-15, Max Pressure 15st PSI, Input 12.600.000 BTU/HR Serial# OL 094585, 460 3Phase

Cleaver Brooks Boiler 500 HP 4-Pass dryback Natural Gas 60 PSI Design pressure

(3) Available Natural gas fueled 10,461,000 BTU/hour 460 volt 3 phase

Coen 230 Combustion Wood/LP Gas Fired Burner

Continental Automatic Gas Fired Boiler S/N L 196710

English 600 HP Boiler - (2) Units available New in 2000 One is set up for wood and only run for 3-years The second is wood/oil backup and only test fired 300' Covered Waste Conveyors available to transport waste to boilers Large capacity bucket load/silo available to store wood waste Complete loading/unloading augers available All pumps, condensate tanks, piping, electrical, catwalk, exhaust, infeed bins, suit bins, augers included. Two large stacks also available

Plant Boiler System for up to 60,000 pounds of steam production per hour (1790 HP) with the following features and main components: -- (2) ENGLISH BOILER AND TUBE, INC. Boilers each rated for 20,700 pounds of steam per hour each. However, manufacturer specified they can be operated at 30,000 pounds per hour with dry wood or bark fuel (12 percent moisture). -- 250 PSI operating pressure ratings on each Boiler. -- VFD Drives on all main Motors. (The plant uses a maximum 75 HP for each boiler.) -- Electrical Controls. -- (1) Boiler has an Oil Burner for operating optionally on oil if sawdust or wood chips is not available. -- Chemical Water Conditioning System and Pumping System. -- De-aerator and Condensate Tank. -- Multi-clones for particle emissions reduction and abatement. -- (2) Fuel Storage Silos (25’x40’ & 20’x38’) with LAIDIG Model 243 Track-Driven Unloaders. -- Fuel Transfer Conveyors. -- The Silos also are included at the price shown and are available individually. See our listings DB-010162 and DB-010163 for details and individual pricing. -- Boilers can be purchased individually or as a pair. -- Professional removal and installation services are available.

HURST SERIES 45 BOILER, NATURAL GAS: -- SpecificationsBuilt New in 2016; Complete, never installed & ready to deliver! 207.5 HP; 60 PSI Hot Water; Natural Gas Fired Firebox -- Efficient 3-pass design NATURAL GAS FIREBOX. -- ASME Code constructed & stamped for 15 PSI Stream; 30 - 100 PSI Water. -- Registered with the National Board of Boiler Inspectors. -- Easily maintained, designed for efficiency; large Furnace volume for ultimate combustion efficiency -- Unified refractory base floor; steel skids; lifting eyes. -- Low heat release; Factory insulated. – 2"; Mineral wool, Factory jacketed & painted. -- Easy access to fireside surfaces; ample waterside clean-out openings -- Fully automatic operation; U.L. listed; forced draft Burners. -- Wet back construction. -- U.L. Listed controls & trim. -- Factory test fired, flame observation ports front & rear.Boiler Design. 3-Pass “FireBox"; design with: Stress relieving “Wetback"; fire tube construction.Hot Water pressures models are from: 8.5 - 415 HP; 100 PSI max.; 500 - 813 HP; 60 PSI max. built to Section-IV ASME Code.Hot water temperature not to exceed 250° degrees F at or near the outlet of Boiler.Hot Water Model Trim. Safety relief valve; operating temperature control; high limit temperature control with manual reset; combination pressure & temperature gauge; low water cutoff control with manual reset.Hot Water Supply. 180 D/F Return: 160 D/F. -- Fireside Heating Surface: 830 Sq/ft. Furnace volume: 132 Cu/ft. Hot water outlet: 8"; hot water drain: 6"; drain connection: 2".Burner: Matched UL listed “forced draft"; power burners with factory pre-piped, wired and tested fuel configurations for natural gas, propane (LP) gas, No. 2 (diesel) oil, or combination of both gas/oil.All units are factory packaged with operating controls, relief valves, burner, and fuel train. Installation is made simple in that only service connections are needed to place in operation.High density 2"; mineral wool insulation assures lower radiant heat loss. In addition to meeting the requirements of U.L., Burner Systems are optionally available to meet the requirements of FM, IRI, Military, and others. -- Actual model is: HURST S45 – G – 207.5 – 60W

600 hp 300 psi Hurst Hybrid boiler system. 1996 year model Equipment Included: 1- 1- Hurst 1996 Hybrid Boiler 2- 1- Hurst woodfire furnace box 3- 1- Hurst 12” metering conveyor system 4- 1- Overfire air combustion fan 5- 1- Underfire air combustion fan 6- 1- Hurst combustion air preheater 7- 2- Hurst multi-cyclone collectors with rotary air lock 8- 1- Flyash Duct 9- 1- Induced draft fan with exhaust stack 10- Access platforms with ladders 11- Boiler and collector system support frame and legs 12- Boiler system control panel (PLC Controller, frequency drives, UDC) 13- Under feed fuel stoker system with cast iron grate system. 14- 20,000 lbs/hr DA Tank with two 15 HP Grunfos Pumps 15- Rear Injection Fan

HURST 600 HP Waste Fired Boiler; -- Specifications:Complete in-place system with the following features: -- Decommissioned July 2019. -- 150 PSI. (300 PSI max wp), -- 20,700 Lbs per hour. -- Fuel House, Boiler Building and all Controls -- System has been "pickled" to maintain tube integrity.

HURST 205 HP / 6.9mm BTU / 15 PSIG WET WOODY BIOMASS FIRED BOILER/STEAM PLANT: -- Specifications: Complete in-place system with the following features: -- 205 HP Biomass Wood Fired Boiler, 7,073 PPH, gross steam output @ 212° F. -- Low Pressure "Fire Tube" design fire box model FB-1332-15-UF, built in accordance with ASME Code. -- Operator Interface:Allen Bradley PLC with Power Supply Rack. Pentium-based computer with network & modem remote communication capabilities with operator interface software. -- RSView Runtime for automatic operating of the steam pressure, temperatures, fuel flow & combustion airflow. -- The control system incorporates a 4-20 milliamp steam pressure transmitter to sense any changes in steam flow, boiler pressure, & regulates the fuel feed & combustion airflow accordingly. -- Complete with:Additional details on file for the scope of this Complete System's original project.NOTE: Building that houses Boiler can be included with Boiler if desired by Buyer.

1989 Hurst Wood Waste Fire Boiler System MDL 710 W/Water Tank Condensate Tank, Infeed Auger, Ash Removal Unit, Controls, 150 PSI, Max WP PSI 975, 5, 175 lbs Steam Per HR & S/N HYB-150-2

Three systems available. Pricing will include removal and loading onto trucks. - Hurst Hybrid 600 HP 150 PSI - Hurst Hybrid 200 HP 150 PSI - Hurst Hybrid 300 HP 150 PSI Each system should include (email for specifics): Hurst Hybrid Vessel Hurst Boild Furnace with cast grates Hurst underfeed stoker system Hurt Metering conveyor system Overfire air combustion fan Underfire air combustion fan Hurst combustion air preheater Access platforms with ladders Boiler system control panel (PLC, frequency drives, UDC, control for automatic operation)

Used 1995 Hurst Hybrid Boiler system 200 HP 150 PSI 1– Hurst Hybrid Boiler 200 HP 150 PSI Boiler 1 - Hurst Boiler 200 HP Woodfired Furnace for Boiler vessel with cast iron grate system. 1 – Deaerator Tank 1 – Blowdown Separator for fuel storage equipment 1 – 8” Underfeed stoker System 1 – 10” Metering Bin Screw Conveyor with Hopper 1- 20HP Over fire air combustion fan 1- 15HP Under fire air combustion fan 1- Hurst multi-cyclone collectors 1- Induced draft fan

Hurst Boiler System 1. 1- Used1995 200HP 150 PSI Hurst Hybrid Vessel 2. 1- Used 1995n refractory lined boiler furnace 3. 1- 8” underfeed stoker system 4. 1- 10” Fuel feed metering conveyor system 5. 1- Overfire air combustion fan with ductwork 6. 1- Underfire air combustion fan with ductwork 7. 1- Multi cyclone flyash collector 8. 1- Induced draft fan with exhaust stack 9. Muti cyclone and ID fan support steel with legs 10. Access platforms to boiler with ladders 11. Hurst open vented feedwater tank with 2 Grundfos feedwater pumps and control panel 12. Blowdown separator 13. Hurst Boiler control panel 14. Boiler piping parts 15. Boiler electrical parts 16.Equipment loaded onto trucks Optional: Fuel handling and storage supply system: Walking floor Vibrating Screen Screw conveyor Controls
