Edgebanders For Sale

ALTENDORF F4 (aka Herbrock F4) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + EVA/PUR GLUING TECHNOLOGY: -- Specifications:Working Capacity:Min. workpiece width: 80 mm; min. workpiece length: 180 mm; min. workpiece height: 8 mm; max. workpiece height: 50 mm; edge thickness in coils (min./max.) 0.4 - 3 mm: 23 FPM (7 MPM) Fixed Feed Speed with indicator light for panel spacing. Features & Equipped with: 15" LED Smart Touch Control with: Touchscreen display with integrated operational/maintenance software. -- Pullout workpiece support to assist in the processing of larger work pieces. -- Top pressure beam with (2) offset lines of rollers for equal pressure distribution on the workpiece. -- Chain feeder with a fixed speed of 7 MPM (23 FPM) and rubber grip pads for maximum grip on the workpiece. Working Units: Pre-milling unit with: (2) 1.1 kW independent motors running at 12,000 RPM and diamond-tipped cutters; Manual positioning of the depth of cut between 0 – 2 mm; (2) diamond-tipped cutters included. -- Edge feed for coiled material: 0.4 – 3 mm thick coil stock. -- Guillotine trimming unit for: Precutting of PVC/ABS edge band material 0.4 – 3.0 mm thick. "Quick-Change" Teflon coated gluepot with: (3.5) Minute heat up time; 1.5 kG capacity. - Glue is applied using a fine adjustable glue roller and quick-change System, as well as monitoring of the heating element; pneumatically feed controlled glue unit capable of processing PUR & EVA hot-melt glue. Pressure unit with: (1) Large motor-driven roller and (1) conical roller operating pneumatically. -- End trimming unit with: (1) Motor, 0.35 kW, 12,000 RPM. -- Multi-functional trimming unit for: Radius & flush trimming and bevel trimming of thin edges with (2) independent motors, each with 0.75 kW and 12,000 RPM; manual positioning of the edge thickness adjustment with pneumatic disengage function via the Control Panel. -- Corner Round Units with: 0° - 10° Manual adjustment. Corner rounding unit for soft- and post-forming pieces for processing edges of between 0.4 and 3.0 mm in thickness and 10 – 60 mm in height. -- Finishing Units: 2-Axis, motor-driven, position-controlled radius trimming unit incl. pneumatic reverse function. -- Complete with: Nesting tracers for milling station and radius profile scraper -- Actual Model is: ALTENDORF F4 (aka Herbrock F4).

BIESSE AKRON 1440A EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + EVA & PUR Gluing Systems: --Specifications:Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm.Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm. -- Min. panel protrusion from the track: 25 mm.Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm. -- Multi-Feed speed 8-12-15 &18 MPM. (26, 39, 49 & 59 FPM) -- Glue & Pressure Section:Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting gluing unit with melting device.Special glue container for PU glue. Additional glue container for EVA glue. -- Working Units:Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. -- Machine Features:Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating.The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. -- Operator Interface:Biesse, Windows-based "SMART TOUCH" control & operating system. -- Complete With:Kit pro-nesting for fine trimming unit, equipped with (2) bearing copiers in addition to the top vertical copier to permit processing of panels with holes and/or grooves. -- Sliding unit for corner rounding unit, for the application of sliding liquid before the corner rounding unit. -- Cleaning unit LPT02 to apply a cleaning liquid of the glued edge, giving a perfect polishing of the edge. -- Actual Model is BIESSE AKRON 1440 A

BIESSE AKRON 246 EDGEBANDER WITH CORNER ROUNDING (New controller installed summer of 2024)0.4 - 8 mm (5/16") Cap. Edgebanding thickness, min. panel width 85 mm & min. length 140 mm, panel thickness 10 - 50 mm; Automatic strip & coil feed magazine with robust shear type 3 mm PVC guillotine.Equipped with: -- Adjustable top pressure beam positioning. -- Hot-Melt glue system (12 min. heat up time) with Teflon coated gluepot, digital thermostats with automatic kick-down when machine is in idle mode. -- 1" Dia. glue applicator roller; pressure section with (1) large dia. "non-stick" coated drive roller & (2) chrome plated idle rollers with pneumatic positioning.Workstations: -- Front & rear end trims (0.33 HP - 12,000 RPM motors), motors travel on (2) straight slides and pneumatic tilt 0° - 25° on horz. plane. -- Top & Bottom flush trims with "Quick Change" motors (1.0 HP - 12,000 RPM motors), digital readouts for easy setup. -- Corner rounding unit for trimming leading & trailing upper & lower edge/corners with "Fast Position", and can be used as a second Top & Bottom fine trimmer as well. -- Top & bottom scrapers for 3 mm thick PVC banding, digitals for horiz. adjustments. -- Top & bottom (2,000 Watt) hot air blowers with temperature adjustment. -- Top & bottom buffing (0.5 HP - 2,800 RPM motors), units tilt 0° - 30°. -- Feed Speed 39 FPM, 3 HP feed drive. Complete with: -- Microprocessor for workstations & feed speed, insulated sound enclosure over all trim stations with triple split dust hood, industrial lights and viewing windows. -- Extendible side panel support rail, 12 KVA - 240 Hz digital frequency inverters. -- Includes: Used tooling on all workstations.NOTE: New controller installed summer of 2024

BIESSE AKRON 1440 SINGLE SIDE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + with "AIR FORCE" PUR & EVA (Hot Melt) Gluing Systems: -- Specifications: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm; Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm.Multi-Feed speed 8-12-15 &18 MPM.Glue & Pressure Section: -- Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting glue. Special glue container for PU glue; Additional glue container for EVA gluing unit with melting device.Additionally equipped with the AirForce "VC-710", High pressure, hot air system to reactivate special pre-coated edge material (commonly referred to as laser edge.Automatic edge feed; Cutter knife; Pressure zone with 1-Drive & 2 pressure rollers.Working Units: -- Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; -- Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. Machine Features: -- Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating. The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Auto adjustment of in feed fence. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator & Machine Control: -- Biesse,

Biesse Akron 245 Machine was in good working condition when removed from service. Computer works, but the screen does not.

BIESSE ROXYL 5.5 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). --Machine Interface:"Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy, icon of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine In-Feed Configuration:Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System:EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special pre coated edge material (commonly referred to as laser edge).Workstations:End Trimming Unit "IN-801": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat, top/bottom, digital positioning indicators, pneumatic controlled for in/out position. -- Buffing Station "SP-501": Top & Bottom buffing motors with 150 mm ( 6") cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with driven flat belt and program

Machine Equipped as follows: NC 410 PC Based Controller Keyboard with Floppy Drive Automatic Strip Feed Magazine Belt Driven Top Pressure Beam Multi-Coiled Infeed Magazine RT63 Pre-Milling Unit SP20 Glue System w/ Pre-Melt Unit Hot Air Gluing system Automatic Infeed Pressure System T45 Front & Rear End Trimming Units w/Tilt RS10 Top & Bottom Rough Trimming Units RF30 Top & Bottom Fine Trimming Units AR10 4 Motor Corner Rounding Trimming Units RB30 Top & Bottom Profile Scraping Units RC10 Top & Bottom Glue Scraping Units SZ30 Top & Bottom Oscillating Buffing Units PH10 Top & Bottom Edge Heaters Specifications: Min. Panel Thickness:....................10mm? Max. Panel Thickness:....................60mm? Height of Edge-Band Material:…..15-65mm? Min. Banding Thickness:.................0.3mm ? Max. Banding Thickness:........ ...... 20mm? Min. Panel Length:...........................150mm? Min. Panel Width:............................ 100mm? Feed Speeds:.................................10-24m./min? Electrics: ......................................... 460-480V 3 Phase

Biesse Akron 440 Edgebander Premill Top & Bottom Trim Corner Round Edge Scrape Glue Scrape Buffing Unit 12-18 m/min Feed Speed All work units are servo controlled

Manufacturer Specs premill hot glue end trim top/bottom trim corner rounding scraping buffing Computer interface

Biesse Akron 245 Edgebander System is still under power until approx mid-October 2024. Touch PLC will need to be replaced. Everything else is working good on the machine. Owner has had it serviced by Biesse.

BIESSE ROXYL 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: Features: -- Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers.This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without the necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material + a (2) position vertical Coil Magazine Cart. -- Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IT90-S": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-100": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (4) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece's surfaces. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner a

BIESSE - AKRON 855, ...Edgebander with Premill & Corner Rounding (Loaded!)Specifications: -- Edge & Workpiece Capacity: 0.4 - 15 mm (0.016" - 0.59") Edge thickness; 14 - 65 mm (0.55" - 2.56") edge height; 10 - 60 mm (0.39" - 2.36") panel thickness; 140 mm (5-1/2") min. panel length; 85 mm (3.3") min. panel width. Infeed Section: -- Premilling Unit - "FI-701"Rectifies face to be edged before applying glue; horizontal & vertical movement of (2) motors on linear guides; independent automatic temporized intervention of (2) 1.8 kW (2-1/2 HP) - 12,000 RPM motors; independent copying pads on each unit, Autoset device to ensure optimum positioning of cutters according to thickness of panel being machined. -- Edge Feeding, Gluing & Pressing Unit - "VC-710"With automatic edge magazine for strip & coil stock; 3 mm (0.04") PVC guillotine; "TEKNO-GLUE" System includes: Pre-Melt "QM-701"; for quick heating & tank changing with floating & bidirectional glue roller applicator & NC axis idle presser roller movement device. -- Pressure Section: (1) Large driven & (5) Idle rollers, Independent pneumatic pressure control, Programmable servo motor for quick edge thickness changeover, Feed speeds 10, 14 & 20 MPM (33, 46 & 65 FPM).WORKSTATIONS: -- End (Edge) Trimming Unit - "IN-701-V"(2) 0.35 kW (0.5 HP) - 12,000 RPM Motors; automatic 4-position programmable chamfer from Control Panel (0°, 3.6°, 11°, 15°); sliding in slicing motion on 45° precision guide bar with oversized bearing blocks. -- Superimposed Flush (Double Edge) Trimming Unit - "RS-701"Top & bottom; (2) 0.8 kW (1 HP) - 12,000 RPM motors with superimposed motor position; 1° tilt capability; includes: Pneumatic exclusion device & Pneumatic top/bottom motor positioner. -- Tilting Top & Bottom Trimming Unit - "RI-701"(2) 0.65 kW (0.87 HP) - 12,000 RPM Motors; for radius top & bottom fine trimming; unit can be tilted 0° - 45°; includes: NC axis multiple machining device. -- Corner Rounding Unit - "CR-200V"For corner rounding; top & bottom trimming on panel edge with synthetic material & wood edgebanding up to 5 mm (0.20") max. edge thickness. -- Edge Scraping Unit - "RB-701"For finishing rounded off edges in PVC or ABS up to 5 mm (0.20") thickness includes: Pneumatic Unit Lifter. -- Flat (Glue) Scraper - "RCC-700"Top & Bottom, Removes potential excess glue before buffing unit. -- Buffing Unit, "SPL-700":Top & Bottom. -- Hot Air Blower Unit - "PH-700" - (2) STEINEL "2346" 2,000 W; reactivates color of thick plastic.Complete with: -- PC-Based Control Panel with: 15" Color LCD monitor, HF (High Frequency motors on all cutting & trimming workstations. Top pressure beam programmable via positioning motor; top pressure provided by belt holddown. 36" Dia. Coil table: Padded sound enclosure. -- Manuals (as pictured).Dimensions: 280" x 42" x 72" H. - Weight: 3,500 kG (7,750 Lbs.).

BIESSE SPARK 3.3 Edgebander (Compact)0.4 mm to 3 mm material thickness. Min. panel thickness 10 mm, max. panel thickness 40 mm. Min. panel width 90 mm, min. panel length 140 mm.Equipped with: -- 2 Liter Glue Teflon coated tank with quick heating system. -- Top pressure beam with manual adjustment through numerical read-out equipped with rubberized holddown wheels. -- Pneumatic Guillotine knife for automatic edge cutting with a max thickness of 3 mm with automatic “kickback"; of the edge. -- Adjustable edge pressure unit with (2) rollers: 1st roller motorized with separate adjustable pressure system; 2nd idle roller with separate adjustable pressure system. Work stations: -- Double Motor End Trimming Unit - 2 tilting motors HF 0.5 HP each. -- Top and bottom Trim with (2) HF motors, 0.75 HP (0.55 kW) each and micrometric adjustment with numerical read-out. Cutters with 3 mm radius with (4) knives. -- Top and bottom Buffing station. -- Material feed speed 12 MPM (39 FPM).

BIESSE SPARK 3.3 Edgebander (Compact)0.4 mm to 3 mm Material thickness. Min. panel thickness 10 mm, max. panel thickness 40 mm. Min. panel width 90 mm, min. panel length 140 mm.Equipped with: -- 2 Liter Glue Teflon coated tank with quick heating system. -- Top pressure beam with manual adjustment through numerical read-out equipped with rubberized holddown wheels. -- Pneumatic Guillotine knife for automatic edge cutting with a max thickness of 3 mm with automatic “kickback"; of the edge. -- Adjustable edge pressure unit with (2) rollers: 1st roller motorized with separate adjustable pressure system; 2nd idle roller with separate adjustable pressure system. Workstations: -- Double Motor End Trimming Unit - 2 tilting motors HF 0.5 HP each. -- Top and bottom Trim with (2) HF motors, 0.75 HP (0.55 kW) each and micrometric adjustment with numerical read-out. Cutters with 3 mm radius with (4) knives. -- Top and bottom Buffing station. -- Material feed speed 12 MPM (39 FPM).

BIESSE - AKRON 420, ...Edgebander -- Machine Capacity -- Thickness of banding rolls: 0.4 - 3 mm (0.12"); thickness of strips: HPL, veneer, solid wood strips, 0.4 - 6 mm (0.24"); panel thickness: 60 mm (2.4") max. & 10 mm min.; min. panel length: 140 mm (5-1/2"); min. panel width: 85 mm (3.3"). -- Equipped with: -- Feed/Glue Unit: Automatic strip & coil feed magazine with: Robust shear-type; 3 mm PVC guillotine. -- Hot Melt Glue System: 10 Min heat-up time; Teflon coated gluepot; digital thermostats with automatic kickdown when machine is in idle mode. - 1" Dia. glue applicator roller; pressure section with: (1) large dia. "non-stick" coated drive roller & (2) chrome plated idle rollers with pneumatic positioning. -- Workstations --÷ Inclined travel Front & Rear End Trims: 1/4 HP - 12,000 RPM motors; motors travel on (2) straight slides; pneumatic tilt: :0° - 15° on horizontal plane. -- Top & Bottom Fine Trims: 1/2 HP - 12,000 RPM motors; numeric readouts for easy set up. -- Top & Bottom Buffing Station: 1/2 HP - 2,800 RPM motors; units tilt :0° - 30°. -- Feed Speed: 12 MPM (39 FPM); 3 HP feed drive. -- Complete with: Insulated sound enclosure over all trim stations; extendible side panel support rail.

BIESSE AKRON 440 AX EDGEBANDER (W/PRE-MILL & CORNER ROUNDING: -- Specifications: Material infeed for strips & coiled edge material like PVC, ABS, veneer, and solid wood. -- Edge & Workpiece Capacity: 0.4 - 3 mm (0.016 - 0.12") Edge; 10 - 60 mm (0.39 - 2.36") panel thickness; 140 mm (5-1/2") min. panel length, and 85 mm (3.3") min. width. -- Working Units:Pre-milling Station: (2) 3 kW (4 HP) - 150 Hz, 9,000 RPM Motors; equipped with panel blow off device and SIKO digital counters for adjustments. -- EVA Gluing Unit: Edge Feeding & Pressing Unit; automatic loading of tape in rolls and strips; quick-change glue pot system. -- Pressure Section: (1) Large 150 mm dia. driven & (5) idle pressure rollers. -- Feed Speeds: Operating feed speeds 12 & 18 MPM (39 & 60 FPM). -- Workstations: Double Motor End Trim; tiltable from 0° - 15°; each motor 0.8 kW (1 HP) - 12,000 RPM; sliding in a slicing motion on a 45° precision guide bar with oversized bearing blocks. -- Top & Bottom Trimming: (2) Motors 0.65 kW (0.87 HP) each; "Pro-Nesting" copiers; cutters R=2 mm. -- Fine Trim/Corner Rounding Unit: (2) Motors; each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with PVC, ABS, etc. material, and wood edge banding up to 3 mm max. edge thickness. -- Top & Bottom Flat Glue Scrapper: To remove potential glue squeeze out. -- Buffing Station: Top & Bottom, (2) motors, each 0.37 kW (0.5 HP) - 2,800 RPM. -- Operator Interface:Operator Control Panel, "HDI" High-Definition touchscreen control, Windows XP based. -- User-friendly graphic user interface with diagnostic and assisted maintenance. -- USB and Ethernet port; 1.44 MB floppy drive, automatic or manual startup. -- Complete with:High frequency motors (200 HZ): Padded sound enclosure. -- Top pressure beam with staggered double-row hold-down wheels mounted on ball bearings. -- Actual Model is: BIESSE AKRON 440 AX

BIESSE STREAM A 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) (aka "TAPE ROCKET") + NC Axis PackageFeatures: -- "NC Axis Package": The machine adapts to the process being executed based on the edge's thickness and material.Machine management ...100% touch with no need for external devices. - Intelligent language management.Easy program management and usability with rapid transition from one machining operation to the next. Specifications: -- Edgebanding Capacity: Edge thickness for strips: Min./max. 0.4 - 22 mm (0.02" - 0.87"); coiled material from 0.4 - 3 mm (0.02 - 0.12").Panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width: Min. of 85 mm (3.34"); workpiece length: min. 140 mm (5.51").Feed speeds of: 12 - 18 - 20 - 25 MPM (39 - 59 - 65 - 82 FPM).Machine Infeed Configuration: -- Pre-milling Station:(2) 1.8 kW (2.4 HP) - 12,000 RPM Motors; LH & RH Counter Rotating Spindles; NC (Servo) controlled with automatic intervention that guarantees a perfect base for gluing. -- Anti-Adhesive:Automatic Spray Unit with: Glue release agent preventing glue from adhering to work piece's surfaces. -- Infrared Heating Lamp:Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic 2-coil/position magazine for processing coiled & strip edgebanding material in real-time. -- Pressure Section:Servo Controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System w/Premelter: -- EVA (Hot Melt), quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations: -- End Trimming: Front & Rear Linear end trimmer with: Tilt Function for high speeds with (2) 0.8 kW (1.0 HP) - 12,000 RPM motors. The machine axis movement on linear tracks allows the achievement of very high processing speeds.The copying & tracing system guarantees optimal finish quality; also on high gloss edges with film. -- Flush/Bevel Trimming Unit:Top & Bottom flush or bevel trims with: (2) "Quick Change" 0.65 kW (0.8 HP) - 12,000 RPM motors. -- Fine Trimming Unit: (2) 0.65 kW (0.8 HP) - 12,000 RPM Motors; (2) Servo motors for tool positioning (one for horizontal tool position, one for up/down tool position).Prepositioning of motors by pneumatic air cylinders while using a combination bevel/radius/flush insert knives.Absolute machining flexibility thanks to the full adjustment of the machine according to the required edge thickness. -- Corner Rounding Unit: (2) 0.65 kW (0.8 HP) - 12,000 RPM Motors for front/back corner and upper & lower edge profiling.The controlled axis on the Corner Rounding unit supports the management of infinite machining settings. -- Profile Scraping Unit:Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit: Flat, top/bottom, digital positioning indicators, pneumatically controlled for in/out position. -- Buffing Station: Top & Bottom buffing

Biesse Akron 1440 PUR Return conveyor available - demo unit!

Min. Panel Thickness: 0.39? Max Panel Thickness: 2.36? Height of Edge-Band Material: 0.55-2.51? Min. Banding Thickness: 0.01? Max Banding Thickness: 0.39? Min. Panel Length: 5.51? Min. Panel Width: 1.96? 2 Feed Speeds: 39ft/min & 59ft/min Electrical: 230V, 60Hz, 3Phase Equipped With Siemens TD200

BIESSE ROXYL 5.5 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: -- Features: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material. "AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important now that "AirForce" can use PVC. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy, icon of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece's surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special pre-coated edge-material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IN-801": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-posit
