Gang Rip Saws For Sale

Mereen-Johnson 424 DCS Short Stock Gang Rip sawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 14" min. length for glue joint accuracy and 22" min. for busting only, -- 6" throat. Equipped with and Features -- 75 HP - 3,600 RPM TEFC Direct drive motor, -- 2-3/16" dia. arbor with disc brake, -- load meter and slip-off outboard bearing. -- Feed & chain: 3 HP Variable feed speed 30 to 170 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain -- "Quad Life" hardened dip cams -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips --, Automatic chain oiler. -- (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, -- Pressure rolls and bed plate unit with scale & pointer thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- Sound enclosure, -- (2) Upper dust hoods (1) 10" & (1) 5" dia. and (1) lower 4" dia. hood, -- Requires 3,820 CFM;NOTE: Laser Rack with 10 Lasers

MEREEN-JOHNSON - 431DC, ...Gang Rip Saw: Specifications: -- 31" Arbor width cap., 14" max. dia. tooling, 3-1/2" max thickness. -- Motorized thickness adjustment. -- 29" Min. length for glue joint accuracy and 22" min. for busting only; 6" throat. -- 75 HP - 3,600 RPM TEFC direct drive motor. -- Arbor with disc brake & load meter. -- Arbor lockout on the access door.Equipped with & Features: -- Feed, Chain & Holddown. -- 5 HP Variable feed speed 30 - 150 FPM with adjustable jam protection. -- MEREEN-JOHNSON "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain. --"Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips. -- Automatic chain oiler with low-level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls. -- Full width spring loaded overhead bed plate. -- Pressure rolls & bed plate unit with powered adjustment; scale & pointer for thickness reference; -- Antikickback Finger System with: (1) Lower & (2) Upper on Infeed; (1) upper assembly on outfeed.

MEREEN-JOHNSON Model 524-DDCSR 2+4 Double Arbor Gang Rip SawSPECIFICATIONS: -- First Arbor Arranged with Two (2) Independently Adjustable Select Saw Assemblies for Mounting Hogging Blades -- Second Arbor with Four (4) Independently Adjustable Select Saw Assemblies -- Arbor Space 24" -- Thickness Capacity to 1-3/4" with 12" Tooling and 2-3/4" Using 14" Tooling -- Minimum Length 30"Equipped with & Features -- Two (2) M-J Direct Drive Motors 75 HP Each -- Feed Motor 7.5 HP TEFC, 30' to 235' rate with Frequency Inverter Speed Control -- Saw Set Up for Second Party Optimizing System.

Mereen-Johnson 312-DC/SR2 Gang Rip Saw with Rip Navigator Scout InfeedSpecifications -- Arbor Space: 12" -- Thickness Capacity: Up to 3" (w/ 14" Blades) -- Minimum Length: 22" (30" for Glue-Joint) -- Two Shifting Blades -- 1"Minimum Net Rip Between Shifting Blades -- Machine-Mounted Laser Stand -- Arbor Motor: 50 HP, Direct-Drive -- Feed Motor: 3 HP -- Variable Speed Feed: 30 - 150 FPM -- "Posi-Feed" Friction Feed Chain w/ Aluminum Slats and Replaceable Rubber Inserts (Rubber Inserts are Brand New) -- Hardened Steel Feed Chains & Track w/ Oil Mist Lubrication -- Air-Loaded Press Rolls -- Single Lower, Double Upper Infeed Anti-Kickback Fingers w/ Single Upper OutfeedEquipped with & Features -- Rip Navigator Scout Arranged to Receive 17'-6" Maximum Length Boards from Scissors Lift Manually placed on Board Dealer ArmsIndividual Boards are Automatically Dealt onto Lateral Chains and Conveyed to a Board Stop -- Board Stop Queues Boards for Advancement to Disappearing Fence -- Automatic Adjusting Fence Positions Boards for Placement into Gang Rip Saw Fence Positioning Through Rip Navigator -- Fence Mounted Pinch Roll Feeds -- Board to Gang Rip Saw Mounted Power Table -- Voltage: 480 with Transformer (Original Voltage as built is 575) -- New Bearing in Saw Arbor -- New Rails for Scout Infeed Chains -- 5743 HOURS -- NEW IN 2013

Mereen-Johnson 424 Gang Rip sawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 14" min. length for glue joint accuracy and 22" min. for busting only, -- 6" throat. Equipped with and Features: -- 75 HP - 3,600 RPM TEFC Direct drive motor, -- 2-3/16" dia. arbor with disc brake, -- Load meter and slip-off outboard bearing. -- Feed & chain: 3 HP Variable feed speed 30 to 170 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain -- "Quad Life" hardened dip cams -- Extruded structural aluminum feed bed slats with replaceable steel-backed rubber insert strips --, Automatic chain oiler. -- (4) 3" Dia. air-loaded overhead pressure rolls; full-width spring-loaded overhead bed plate, -- Pressure rolls and bed plate unit with scale & pointer thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- Sound enclosure, -- (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood, -- Requires 3,820 CFM;Also included: -- (7) Lasers with mounting rack -- (2) additional arbor and lots of spacers

MEREEN-JOHNSON - 431DC: Gang Rip SawSpecifications -- 31" Arbor width cap.; 14" max. dia. tooling; 3-1/2" max thickness. -- Motorized thickness adjustment. -- 29" Min. length for glue joint accuracy; 22" min. for busting only; 6" throat. -- 75 HP - 3,600 RPM TEFC Direct drive motor. -- Arbor with: Disc brake & load meter. -- Arbor lockout on the access door.Equipped with & Features: -- Feed, Chain & Holddown. -- 5 HP Variable feed speed: 30 - 150 FPM With adjustable jam protection. -- MEREEN-JOHNSON "Posi-Feed" dip bed: Carried on 5" pitch hardened double-V chain. --"Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with: Replaceable steel backed rubber insert strips. -- Automatic chain oiler with low-level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls. -- Full width spring loaded overhead bed plate. -- Pressure rolls & bed plate unit with: Powered adjustment; scale & pointer for thickness reference. -- Anti-kickback Finger System with: (1) Lower & (2) upper on infeed; (1) upper assembly on outfeed.

MEREEN-JOHNSON "312-DC-OPH1" DIP CHAIN GANG RIP SAWSpecifications -- 12" Arbor cap., -- 14" max. dia. tooling, 3-1/2" max. thickness, -- 30" min. length for glue joint accuracy & 22" min. for busting only; -- 6" throat. Equipped with: & Features -- 50 HP - 3,600 RPM TEFC Direct drive motor, -- Arbor with disc brake & load meter, arbor lockout on access door.Feed & chain: -- 3 HP Variable feed speed from 30 - 150 FPM with adjustable jam protection, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, -- Automatic chain oiler with low level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls; -- Full width segmented maple, spring loaded overhead pressure shoe -- Pressure rolls & pressure shoe unit adjust with scale & pointer thickness reference -- Anti-kickback fingers. -- Lasers at infeed for pocket location.

MEREEN JOHNSON 424 DC Multiple Blade Rip Saw:Specifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max., -- 22" min. length, -- 6" throat -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake. -- Feed & chain: 3 HP Variable feed speed from 50 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, -- "Quad Life" hardened dip camsEquipped with & Features -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips -- Automatic chain oiler with low level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls; -- Full width spring loaded overhead bed plate -- Height adjustment with scale & pointer reference --Anti-kickback finger system with (1) lower & (2) upper on infeed -- (2) Upper dust hoods, (1) 10" & (1) 5" dia. & (1) lower 4" dia. hood, requires 3,820 CFM

MEREEN JOHNSON 424 DC Multiple Blade Rip Saw:Specifications: -- 24" Arbor cap., 14" max. dia. tooling, 3-1/2" max., 22" min. length, 6" throat. -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake. --Feed & chain:3 HP Variable feed speed from 50 to 150 FPM, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, -- "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low-level shutoff. --Equipped with & Features: -- (4) 3" Dia. air-loaded overhead pressure rolls -- Full width spring-loaded overhead bed plate -- Height adjustment with scale & pointer reference -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- (2) Upper dust hoods, (1) 10" & (1) 5" dia. & (1) lower 4" dia. hood -- Requires 3,820 CFM

MEREEN-JOHNSON Model "424-DC/SR ( 1 ) Moving Blade Gang Rip SawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max., -- 22" min. length, 6" throat. -- "Select-A-Rip" multiple Rip Saw with rapid adjustment of (1) moveable saw blade (shifts at approx. 3" per second); can be used independently or in conjunction with a gang sleeve arrangement; provides straight line gang ripping while maintaining optimum yield and delivering glue-joint accuracy.Equipped with & Features -- Select-A-Rip includes a control console and overhead laser lights for accurate blade positioning. -- 75 HP - 3,600 RPM TEFC Direct drive motor. -- Feed & chain: 3 HP Variable feed speed from 50 - 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams, -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, -- Automatic chain oiler with low level shutoff. --: (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, -- Eight ( 8 ) adjustment with scale & pointer reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- (2) Upper dust hoods, (1) 10" & (1) 5" dia., requires 3,820 CFM. -Note From The Seller Machine was used in a low production environment and has low hours.

MEREEN-JOHNSON 419-DC Gang Rip Saw --Specifications -- 19" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat. --Equipped with & Features -- 75 HP - 3,600 RPM drive motor with direct drive to arbor. -- Feed & chain: 3 HP Variable feed speed 30 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, and chain oiler. -- (4) 3" Dia. spring loaded overhead pressure rolls (with new springs); full width spring loaded overhead bed plate, pressure rolls and bed plate unit with scale & pointer thickness reference; anti-kickback finger system , -- (1) lower & (2) upper on infeed (kickback fingers are newly replaced). -- (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood; requires 3,820 CFM; (2) 19" saw sleeve with mics. spacers. -- New Laser Light Array complete with (5) Lasers and Mounting Hardware, --. Spare parts including extra saw sleeve, short stock holddown plates, a few sawblades, etc. -- Notice the feed chain - it's in exceptional condition! --Note From The Seller Arbor motor burnt out, needs repair

Complete MEREEN-JOHNSON/CHOICE MACHINERY GROUP 431-DC-1/C1210 - C1260 Gang Rip Saw LineOverall Specifications: -- Panel width 24" - 27". -- Panel length 36" - 109". -- Panel thickness 1/2" - 1-1/8".Consisting of the following machines as late as 2022: -- 2022 CHOICE MACHINERY GROUP C1210 7-1/2’ W x 7’ L x 18-1/2"; H 5-Chain Transfer Deck Conveyor, S/N 1048, with Distance between chains (Left-to-right) 22";, 22";, 21"; - 24";, 16"; - 19";, 1/2 HP - 1,720 RPM TEFC Motor, & (2) 6"; W x 55"; H Back stops. -- 2022 CHOICE MACHINERY GROUP C1220 31" Capacity Automatic Unstacker/Panel Feeder, S/N 1049, with Unstacker platform with Raised height 52" & Lowered height 18", (4) 125"; L x 3-3/4"; Dia. Motorized rollers on 9-1/2" Centers, Safety light curtain, & 5 HP Hydraulic unit, and Automatic panel feeder with Chain-driven pusher & 3/4 HP - 1,710 RPM TEFC Motor. -- MEREEN-JOHNSON 431-DC-1 Dip Chain Gang Rip Saw, S/N MJ-6837 (Approximately 2003), with 7,564 Hrs., Arbor cap. 31", Max. blade dia. 14", Max. thickness 3-1/2", Min. length: 29" for Glue joint accuracy & 22" for Busting, Throat 6", Variable feed speeds 30 - 170 FPM, with 75 HP - 3,600 RPM TEFC Direct drive arbor motor with Disc brake, Load meter & Arbor lockout for access door; "POSI-FEED" Dip bed with 5" Pitch Hardened double-V chain, "QUAD LIFE" Hardened dip cams, 2-3/8" x 14"; Extruded structural aluminum feed bed slats with 1-3/4"; Replaceable steel-backed rubber insert strips, Automatic chain lubrication with Low-level shutoff, & 5 HP Feed motor with Adjustable jam protection; (4) 3" Dia. Air-loaded overhead pressure rolls, Full width spring-loaded overhead bed plate, Motorized thickness adjustment, Anti-kickback finger system with (1) Lower & (2) Upper on infeed & (1) Upper on outfeed, Complete with Spare arbor with (11) Blades. -- 2022 CHOICE MACHINERY GROUP C1230 Motorized Belt Conveyor, S/N 1050, with 3/4 HP - 1,710 RPM TEFC Motor. -- 2022 CHOICE MACHINERY GROUP C1240 Dual Reel Automatic Strapper/Stacker, S/N 1051, with SOUTHWORTH 4,000 Lb. Cap. Electric/hydraulic scissor lift platform with 3.3 HP Hydraulic unit, & Safety light curtain. -- 2022 CHOICE MACHINERY GROUP C1250 Tilt Unit, S/N 1052, with 5 HP Hydraulic unit & Motorized rollers with 1/2 HP - 1,720 RPM TEFC Motor. -- 2022 CHOICE MACHINERY GROUP C1260 Motorized Roller Conveyor, S/N 1053, with End stop. -- 2022 CHOICE MACHINERY GROUP C12XX Control Console, with S/N 1054, with SCHNEIDER "MAGELIS" Touchscreen control, Operating manual, & Steel bar grating operator platform.VIDEO NOTE: The original operator was not available to run this line, so it was run in manual mode, which is considerably slower than automatic mode. As a result, the video playback speed has been doubled for the convenience of viewing.

Mereen Johnson 424 DC/SR4 Gang Rip Saw with Automated Infeed with multiple lasers manufacturer’s specs to be confirmed 24” width capacity 3-1/2” thickness capacity 75 HP main motor 3 hp feed motor feed rete 30-245 fpm

Mereen Johnson 424DC 24" Wide Arbor 75 HP Motor (460v/3Ph) 3 HP Feed Speed Variable Feed Speed Air loaded pressure rollers

Mereen Johnson Model 312 DC SR1R Rip Saw 600 V/3 PH/60 Cy

Mereen Johnson 431-DC Gang Rip Saw

Morgan Splitter Saw

NEWMAN/Cameron - KF-24: Dip Chain Gang Rip Saw with CAMERON "34H-M1" Infeed SystemSpecifications -- Saw Arbor: 24" Arbor cap.; 14" max. dia. tooling; 4" max. motorized thickness adjustment;22" min. length for glue joint accuracy; 6" throat. -- 2-13/16" Dia. arbor; 24-1/2" capacity saw sleeve arranged for 3-1/8" dia. bore saw blades; saw blade options: 10" - 14" Dia.; spacers: 4-5/8" dia. includes: (1) Saw sleeve and spacers. -- 75 HP - 3,600 RPM TEFC Direct drive motor; arbor with: Disc brake & load meter; arbor lockout on the access door. Feed & Chain: -- 5 HP Variable feed speed: 20 to 100 FPM with: Jam arbor protection. Dip bed carried on: 5" Pitch hardened Double-V chain; hardened dip cams; extruded structural aluminum feed bed slats with: Replaceable steel-backed rubber insert strips; automatic chain oiler with low level shutoff. -- (2) 4" Dia. air loaded overhead pressure rolls; spring-loaded overhead bed plate; pressure rolls & bed plate unit with motorized adjustment; slide type infeed guide with: Handle block; either side of the guide can be used for a stock engraver. -- Anti-kickback finger system with: (1) Lower & (2) upper on infeed; (1) upper kickback on outfeed. Equipped with & Features: Upper outfeed main dust hood: 7-7/8" Dia. 2,150 CFM Infeed dust hood 4-7/8 dia. (855 CFM). (1) Spare sleeve; (2) setup fixtures; generous array of spacers (see photos).

Northtech FR-200 Frame SawSpecifications: -- Saw capacity of 6" width x 8" vertical capacity. -- Minimum working 2"; high X 12"; long. -- Main drive motor to saw frame is 30HP 3PH, wired 460 --V servo drive system to feed works is 1/4HP 3PH, --Blower to saw frame rack for added cleaning value is 3HP 3PH, -- Body of frame saw is (2) sections allowing for fast access to the saw frame, -- Saw blade speed is fixed at 550RPM, -- Dust extraction requires min 3000 CFM and is arranged with (4) 5" ports, -- Blade size is standard with 500mm L x 40mm W x 0.9mm body in stellite or TCT tip,Equipped with & Features -- Digital electronic oiling system provides proper lubrication to the saw frame guides -- Vertical rail system which allows optimum cooling and long term durability, -- (4) guide blocks are thermo- censored to allow auto shut-off of machine should possible heat buildup occur.Machine dimensions 122"; L X 40"; WX, 79"; H weight 7100 lbs. Machine was new in 2007.

Northtech MRS-14-DXL 460v Manufacturer notes: This is a very popular machine and cost effective. New open ended design allows for you to cut wide material up to 27-1/8? wide. Plus spare arbors, lasers, and the optional quick locking, easy to adjust infeed will not break the bank. The Northtech heavy-duty 50 HP multi-rip (“gang-rip”) saw with 15? maximum blade diameter quickly and accurately cuts material up to 4-15/16? thick and 27-1/8” wide. Cutting both sides of your blanks at once provides incredible parallelism, reducing required moulder allowance, and increasing your yield. Laser guides (one included) and an optional 103” fence make proper alignment of even the longest material simple and precise. Variable feed speeds of 25 – 120 FPM and powered height adjustment further improve operator efficiency.
