Meadows Mills For Sale

60' of Meadows Roll Case, 24" rolls 8" in diameter, starter box and transfer (5' long 8' wide w/ stop/load/kicker) $10,000 obo 570-412-9065

The Model 120H log turner utilizes two (2) 2 inch by 12 inch hydraulic cylinders with 1 1/2 inch bores to lift its head. The log turner chain comes standard with 13 teeth that are 1 inch wide. The head is chain driven by a Char-lyn 104-1253 hydraulic motor (included). The drive includes a 13 teeth and 25 teeth sprocket and number 80 chain with chain guard included. Controls, not included, with hoses sell for $2,490.00. 20 GPM Hydraulic power sources, not included, sell for $7,320.00. All prices are FOB North Wilkesboro, NC 28659. For questions please send an email to [email protected] or call 1-800-626-2282, ask to speak with Brian Hege. To place an order please call 1-800-626-2282, ask to speak with Brian Hege.

Meadows #2 - 3HB Modular Mill w/Husk Frame, Offing Belt, Overhead Mud Saw, 4 x 5 Control Cab, Computer Setworks & Hyd Drive System, Log Turner, 56" Saw Blade, 100HP Motor, Debarker for Saw Cut. Out and Ready to Ship

Meadows 16' 3 Strand Log Deck w/Drive

For sale, one (1) reconditioned Meadows grits separator, bottom discharge. This unit is belt driven by a 3 HP 3 phase electric motor. Magnetic motor starter available for additional cost. You can pick up the grits separator in North Wilkesboro, NC or we can arrange for its shipment. If you’re interested please call 1-800-626-2282.

Meadows LH 3 Knee Circle Saw Mill 3 Head Block, Carriage. Track. Cab & Controls 52" Blade With Electric Motors. Believe it is a #2

Meadows Chain Turner

Saw Mill Saw Cabin Track (3) peace’s Drop belt Saw Log Turner and transition Log deck 200 HP motor for saw mill

Meadows 4 headblock carriage, Model; #3 DELUXE, good working condition

Meadows 5 HP Small Blower with Electric Motor

Meadows sawmill New parts from MFG: Saw Arbor, Live belt conveyor, misc parts Computer setworks 225 HP Detroit Diesel

MEADOWS #1 Automatic Sawmill;Complete with the following components and features: -- 15' Long 4 HB Carriage. -- Operator’s Cab, . -- Drive & Turner. -- Computer Setworks. -- YAMANI 4" Band Headrig. -- MEADOWS Titan 4" combo Edger also new in 2001; -- 30' x 24" Live Rolls. -- Electrical Switchgear. -- 33" Dia max. log. -- Capacity: 6,000 to 8,000 BF per day.NOTES: &#9679 Can be seen in operation.

MEADOWS MILLS 120H Chain Log TurnerSpecifications: -- Hydraulic Cylinders: Two 2" x 12" with 1-1/2" diameter rod -- Turning Chain: #120 chain with 1" dog width and 13 bits -- Drive: H80TB13 sprocket with bushing, 80Q25 sprocket with bushing, #80 drive chain, and chain guard -- Drive Shaft: 2-3/16" diameter 1018 cold roll -- Idler Shaft: 2-3/16" diameter 1018 cold roll. Construction: -- Frame: Base constructed from 10" x 25.4 Lbs beam, feet constructed from 4" x 6" tubing, head frame: Constructed from 8" x 3" x 4" tubing -- Drive Motor: Charlyn 104-1253 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 12 GPM & 950 PSI -- Controls: not included in the base price

MEADOWS MILLS 100H CHAIN LOG TURNER -- Hydraulic Cylinders: One 2" x 12" with 1 1/2" rod -- Turning Chain: #100 chain with 3/4" dog width and 13 bits -- Drive: H60TB13 sprocket with bushing, H60SDS25 sprocket with bushing, #60 drive chain, and chain guard -- Drive Shaft: 1 11/16" diameter 1018 cold roll -- Idler Shaft: 1 11/16" diameter 1018 cold roll -- Frame: Base constructed from 3" x 4" tubing, uprights constructed from 8" channel and 4" channel, head frame constructed from 3" x 4" x 3/8" angle and various flat bar -- Drive Motor: Charlyn 103-1032 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 10 gpm & 950 psi -- Controls: not included in base price

MEADOWS MILLS 2-STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 4 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 2 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Handset board edger, all mechanical functions, and fixed feed speed -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 14 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- Unison shifting saw collars, each with a 16"; diameter split carbide saw -- 30 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed table with dead rolls -- Tailing device up to 16' long added to outfeed -- Laser lights aligned with each saw
