ROBUST SD 60E Low Noise Vertical GrinderFeatures: -- One-piece machined cutterhead without welding for increased accuracy in knife fastening. -- The inserts can be used on their four (4) sides, which reduces operating and tooling costs. -- Overload protection. -- Several dimensions of HARDOX Screen available according to your requisitions.Technical Specifications: -- Motor (18.5KW) - 25CV/600V/60C/3Ph -- Top opening 946 mm x 567 mm (37" X 22.3") -- Cutterhead diameter 222 mm -- Cutterhead speed 80 à 120 RPM -- Quantity of TCT tips 14 ( + 2 latéral) -- Productiion capacity 3 à 4 m3/hour The capacity varies according to the dimensions of the grill, the type of wood and its humidity rate . -- Rear screen dimensions of holes 10 à 30 mm -- Dust hood 160 mm -- Machine dimensions 1881(L) x 1115(W) x 1670(H) (70" X 44" X 65.7")

ROBUST SD 70 Low Noise Vertical Wood Waste GrinderBasic machine features: -- BOVER_BASIC intelligent control system -- Power set (electric motor, reduction gear, and belt transmission) -- Vertical hopper -- Hydraulic pressure unit -- Robust and adjustable -- Hardened knives with four cutting edges with an extended service life -- Hardened cleaning knives -- Hardened cutting racks -- HARDOX sieve -- The motor start-up is controlled by the star/triangle systemTechnical Specifications: -- Main motor 30 kW (40 HP) -- Top Opening: 1445 mm × 1345mm ( 56.8" X 53") -- Rotor working length: 650 mm -- Rotor diameter: 270 mm -- Number of knives: 28 -- Screen hole diameter 10 - 50 mm -- Production capacity: 3 - 5 Cubic meter -- Weight : 1,750 Kg (3,850 Lbs) -- OAL 1973 mm X 1548 mm (77.6" X 61")

137.5" WIDE 4 YARD CAPACITY FOR CATERPILLAR 980M FOR CATERPILLAR 980M PIN ON LUGGING ROCKLAND ROCK BUCKET SOLD AS IS

BOLT ON CUTTING EDGE PIN ON LUGGING ROCKLAND 4.0 CYD GENERAL PURPOSE BUCKET SOLD AS IS

ROCKLAND 48IN TILT BUCKET FOR CAT BHL TILT 45 DEGREES EACH WAY

ROCKWELL/DELTA 16" Radial Arm SawSpecifications: -- Blade dia. 16";. -- Base size 37" x 37 x 31"; H. -- Rip cap.: 42"; Out & 26"; In.Equipped with: -- 5 HP - 3,450 RPM Motor.

20” Rockwell Delta Shop Bandsaw. Single phase power. Good saw!

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5w 2 HP Motor, belt driven to saw arbor, 10" blade cap., 5/8" dia. tilting arbor, tilts 0° - 45°; 36" x 27" table. 18" left of the blade. Complete with: 2-3/4" x 33" Rip Fence with approx. 25" travel. NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

NEW Rolly Rollers, In-Stock, $5500/set

Rebuilt Rolly II Heads available

Rolly II Processor rotate motors in good condition

RONNING ENGINEERING Single Pass 10.5' X 40' Dryer/Cooling Drum;Complete with the following components: -- Like new condition, used approximately 1000 hours. -- Trunnion bases with Wheels & Drum Guide Idler. -- Gearbox/base (no motor). -- Insulation -- Endplates. -- This is a hi-performance design with full panel flighting originally set up as a cooling drum. The heat exchange surface is greatly increased with the addition of the panel flighting for which other standard single pass coolers/dryers would need to be much larger to compete with. -- Originally, this was set up has a cooling drum, but by simply reversing the air flow would make it an equally hi performance single pass dryer.

For dumping (1) load at a time. Hoist is fabricated from steel tubing with a box cradle that pivots at the top. The cradle holds the box as it is pivoted up to 135° to the final dumping position. The cradle is pivoted with a hydraulic cylinder driven by a 3 HP hydraulic pump. The cylinder is manually energized via operator foot-switches. -- System includes all mechanical equipment, electric powered hydraulic pump, and (2) foot switches. All wiring and controls by others. ~ Accepts a standard 96" long X 60" wide X 60" high box.

For dumping (1) load of fingerjoint blocks at a time. Hoist is fabricated from steel tubing with a box cradle that pivots at the top. -- 3-Sided cradle will hold the box or pallet when it is pivoted up to 135° to the final dumping position; cradle opening is 88" long X 48" wide X 50" high. -- A pair of replaceable forks hold pallets in place in the cradle. The cradle is pivoted by a hydraulic cylinder driven by a 3 HP hydraulic pump. The hydraulic cylinder is manually energized by the fingerjointer operator with foot switches. -- Scope of supply includes all mechanical equipment, electric powered hydraulic pump, and two foot switches. All wiring by others.

For dumping (1) load of fingerjoint blocks at a time. Hoist is fabricated from steel tubing with a box cradle that pivots at the top. -- 3-Sided cradle will hold the box, pallet, OR unit when it is pivoted up to 135° to the final dumping position; cradle opening is 88" long X 48" wide X 50" high . -- A pair of replaceable forks hold pallets in place in the cradle. The cradle is pivoted by a hydraulic cylinder driven by a 3 HP hydraulic pump. The hydraulic cylinder is manually energized by the fingerjointer operator with foot switches. -- Scope of supply includes all mechanical equipment, electric powered hydraulic pump, and two foot switches. All wiring by others.

ROSE GBUB-80 Glue-Bound Unit Breaker. Machine breaks the glue bond in a staggered stack of finger jointed material - see picture of material with the checkerboard end pattern. --Features -- Equalized Hydraulic squeeze, provides uniform load compression. --Hydraulic length change. Air operated Locking Pins on the Backstop Platen. --Backstop platen position indicator. --Simple manual controls for load length adjustment and crushing stroke on the control panel. --Heavy Duty Structural Steel Construction, Ease of Maintenance and Simple Operation (no cables).Does not use cables!Specifications: --Maximum opening is 16’-10"; for a single 4' x 4' x 16' unit. --Backstop Platen locks at 12" increments (2' minimum load length) --Pressure Platen, hydraulic actuated with 18" stroke. --Platen size 5' x 5' --5 HP Hydraulic Unit with a Pressure Compensated Pump (approx. 1 minute squeeze time) --Overall size approximately 5' x 25' x 7' high --480 VAC, 60 hertz, 3 phase, 30 ampsOptions: --10 HP hydraulic unit with approx. 30 second squeeze time, add $4,200 --Double unit capacity; crushes (2) 4' x 4' loads with 5' x 10' platen, add $19,700 --Automated Control Package with 2 Remote Controls for initiation of Pressing Stroke; Automatic open and hydraulic shut down; PLC Controls, automated load length adjustment with lighted indicators, add $ 7,400

ROSE MACHINERY BDH/LC/LCFT Automated Infeed SystemAutomated, high speed Infeed System for Gang Rip Saws of all makes and models and other similar machines. -- 5-Arm Breakdown Hoist - Electric hoist accepts loads 4' wide x 4' high x 4' - 24' long; 10 HP gear motor (with brake) powers the hoist and holds the load. -- Hoist actuated through foot switches for up & down; limit switches provide max. up & down positions; (5) lifting arms tilt load at 50° allowing layers to spill onto the takeaway conveyor; 16,000 Lbs. max. lift cap. -- Landing Chain - Features: (6) Strands of roller chain; powered by a 5 HP gear motor at 60 FPM nominal rate. -- Tail end constructed with integral slide, stock transits from Breakdown Hoist; head shaft & gear motor supported by tubular steel frame with bolts to allow for leveling at installation. -- Material stops at the head end so the operator can flip & grade each piece. -- Chain races fabricated from steel, UHMW PE wear strips on the top race and on the return race; conveyor is 42' long. -- Magnetic motor starter with foot switch for operator to start & stop of the chain. -- Lateral Chain Feed Table "LCF2013-20": Feeds material 3" - 10" wide x 4' to 24' long x 1" to 3" thick; variable 50 - 200 FPM Feed rate; adjustable fence throughout 3/4" range for alignment with the Rip Saw (or other machines). -- (6) 30" long, low friction steel flattop infeed chains for long life non-marking transport; 1 HP gear motor. -- (3) Powered smooth steel & non-marking feed rolls, 2 HP gear motor; rolls & chains controlled by variable speed drives. -- (3) Overhead pinch rollers, 5" dia., urethane covered; 1st (2) pinch rollers powered by individual 2-1/2" bore air cylinders to singulate pieces onto a 2' bridge; 3rd roller keeps the board moving on the bridge; pinch rolls triggered by photoelectric cells. -- Note: Fabricated frames and appropriate parts of the items in this quotation will be painted with (1) coat of industrial grade Shady Lane Green enamel; guards and appropriate moving parts painted with Safety Orange. -- All gear motors, mechanical equipment, limit switches, sensors or photoelectric devices, as required for each item of this quotation, are supplied and mounted; all pneumatic cylinders or other pneumatic power devices and their valves supplied and mounted; connecting hoses & fittings installed. -- Filter/Regulator units supplied, mounted, and connected by hose to the valves; Note: Compressed air service to equipment is by others.

Ripsaw Feeder with 32" wide feed rolls on 18" thru 28" roll centers; will feed 3' thru 16' lumber. With 24" of in-out fence travel; feed speeds from 50 to 150 FPM; 3/4 HP feed roll drive and 3/4 HP fence drive via gear motor with brake. -- Fabricated frame of structural steel with boots that allow +/- 1" elevation adjustment. 3-1/2" dia. steel feed rolls driven by a variable frequency drive for speed adjustment; rolls are canted to aid in holding stock against the fence. -- Powered fence with 24" fence travel is easily shifted via joystick control for stock alignment with the sawblades. -- With pneumatic powered gate to keep material from feeding until the operator initiates the feed sequence. -- Urethane covered idler pinch roll is attached to the fence and is powered down at the start of the feed sequence. When a photocell detects the board is clear of the gate, the pinch roll and gate will return to their normal position. Electrical control panel ready for connection to the power supply.

ROSE MACHINERY HBR Horizontal Band RE-RIP SawThe Horizontal Band Re-Rip Saw is an effective and efficient means of ripping short blocks into as many as six (6) set rip widths. Rip widths are easily adjustable, as well as the setting for stock thickness.Advantages of the system: -- Compact, efficient use of floor space. -- Accurate cutting of rips with minimum tear-out. -- Short blocks, 4" minimum length, without taper problems. -- Straight through feed design, good for sorting. -- Minimum dust collection required. -- Single point scrap collection. -- One saw drive motor, requires less power. -- Safety, no kickback problems.Specifications: -- Five (5) rip widths - (6) optional -- 20 HP bandsaw drive -- 30" diameter band wheels, 2" wide face -- (2) 3/4 HP feed works drives -- 1-1/2 HP feed belt drive -- 1" to 6" rip width (independently adjustable in each lane) -- 10" maximum board width at maximum rip -- 4" maximum waste piece width -- 3/4" to 2" stock thickness (all lanes adjust together) -- 4" minimum stock length -- 36" maximum stock length -- 80 FPM feed speed -- 52" to 58" pass line height -- Motor starters and push buttons included, wired for 440 volt, 3 phase, 60 Hz (uses standard mag starters) -- An automatic band lubrication system is includedOptional Equipment: -- For SIX (6) LANES, add ...$5,600 (SORTER increases $3,700) -- Automatic machine grease lubrication system, add ...$ 9,200 -- Ergonomic overhead stock slide, add ...$ 5,600 -- Output conveyor and sorter for 5-LANEsingle side discharge, add ...$47,300 -- Output conveyor and sorter for 6-LANE single side discharge, add ...$51,100 -- Operator's platform, add ...$ 7,900 -- Optional voltage configuration: 220/380/440V, 50HZ, add ...$2,900 -- Start-up and training, add $1,000 per day plus expenses at costHorsepower Requirements: -- (1) @ 20 HP -- (1) @ 1-1/2 HP -- (2) @ 3/4 HPDust Collection: -- (2) outlets, 6" diameter, 5,200 FPM velocity @ 2,300 CFMCompressed Air Required: -- 90 PSI @ 1.4 CFM

ROSE MACHINERY LCFCMS14 PANEL RIPPER TO MOULDER TRANSFER SYSTEM OUTFEED ROLLCASE: -- Outfeed Rollcase receives material from the LHI Panel Ripper at 47 1/4"; elevation and drops down to place the lumber onto the Transfer Chains at 42"; elevation. 66"; wide rolls are 2-12"; diameter steel rolls, snap in style on 12"; centers. Rolls are powered by a line shaft using round Eagle Belts and a 1-1/2 HP gear-motor. The conveyor will be fabricated from tubular and sheet steel and designed to interface with the Transfer Chains. The conveyor speed is 80-120 FPM to create a gap between courses exiting the Panel Ripper. The drop will be triggered when a photocell detects the leading end of the boards, creating a far side lumber line. A pneumatic cylinder provides lifting power. When the transferred boards clear the rolls, another photocell triggers the rolls to return to the up position. Stock length handled by the Outfeed Rollcase is from 6’ to 16’. Elevation adjustment is +/- 1";.TRANSFER CHAINS: -- Transfer Chains receive material from the Outfeed Rollcase. The Transfer Chains are fabricated from tubular and structural steel. There are (6) strands of 2060H conveyor chain approximately 17’-6"; CC long, leaving 11’ clear space to accumulate (2) layers of ripped strips. (2) sets of pin stops are incorporated to keep the layers separate. The conveyor is powered by a 1-1/2 HP gear motor. Conveyor speed is 90 FPM maximum. Elevation is 42"; +/- 1";. LATERAL CHAIN FEED TABLE (ROSE MODEL LCFCMS14): -- Standard duty low friction flat top steel infeed chains drive the stock to the fence. The fence is adjustable for alignment with downstream equipment such as a Moulder. (3) lower powered feed rolls are smooth steel and non-marking. The feed rolls and chains are controlled by adjustable frequency drives. (3) upper pinch rolls are 5"; diameter urethane. The first (2) rolls singulate pieces while (1) pinch roll keeps the board moving on the bridge. The pinch rolls are triggered by photocells. A PLC in the control cabinet cycles the outputs based on operator input. Operator controls allow for start and stop of the chains and rolls, the feed to be paused, the rolls to be reversed and speed controls. -- Fabricated structural steel frame -- Passline height 42"; +/- 1"; -- Stock width 2"; to 9"; -- Stock Thickness 1/4"; to 4"; -- Stock Length 6’ - 16’ -- Rolls include a variable feed rate from 60 to 300 FPM -- Feed roll drive is by a 3 HP gearmotor -- (6) infeed chains, each 50"; long, are driven by a 1-1/2 HP gearmotor -- Infeed chain's variable feed rate is 20 to 75 FPM -- 2-1/2"; bore air cylinders actuate the pinch rolls -- With 3/4"; fence adjustment. ELECTRICAL CONTROLS: -- Controls are incorporated in the LCF Cabinet for the above Transfer System. It consists of operator controls, (2) VFDs, and additional PLC I/O and programming. STARTUP: -- 2-days startup assistance is included. Travel expenses are billed se
