woodworking Equipment For Sale

IMA 500L Edgebander Will need a new touch screen control and calibration.

IMA Bima 810 V

IMA BIMA-610, 4' x 16’ CNC MACHINING CENTER , (1998), (460/60/3 electrics), S-4535 General Specifications: - 10 HP, 230/460/60/3 tool-changer type router spindle - (12) station traveling rotary tool changer - (1) 7-spindle & (1) 5-spindle point-to-point vertical drill blocks - X & Z axis ball-screw & Y-axis rack & pinion - Adjustable pod and rail system, (10-rails with pods) - Can include a 4’ x 8’ “universal” flow vacuum table for nested base processing - Integrated scrap conveyor under/through the working area - IMAWOP, (Windows workshop-oriented PC programming system) - Hand held start/stop spindle speed control - 3 HP Becker vacuum pump for the pod & rail side - Includes computer, an aggregate horizontal boring unit, and additional tooling - Note: the retrofitted nested base table is not included - 25' long x 9'8" wide x 8' tall

Specifications comming

Industrial Woodworking JFS25 Finger Joint Line Ultimizer Saw Ap-Quip glue system Ace-Co Hydro heads and setup stand.

INDUSTRIAL IWS 10 Finger Jointer:Shaper unit will handle material 2" to 8" wide, 5/8" to 2" thick and 5" minimum length and 30" maximum length.Equipped with: -- ( 2) Trim saws with 5 HP motors, (2) Scoring saws with 3 HP motors and (2) Shaper spindles with 15 HP motors - 1-13/16" dia.. -- Feed speeds from 0 to 150 FPM. Average speed of (100) lugs per minute; feed chain is equipped with lugs on 9" spacing. -- Glue applicator with improved glue spreading and simplified pump. -- Model 3502 90° brush transfer to the assembly and Flying Cut Off Saw. -- MOD - Assembly Press, 16' long, with (1) retrim saw, air over hydraulic clamp & squeezing including Complete with: -- Wertern/Nielson 800 FJ cutterhead grinder -- Set up stand -- (15) cutterhead -- Some spare parts

Specifications: Table Size 60" x 110 "X,Y,Z Working Area 48" x 96" x 12" X,Y,Z, Traveling Position Accuracy+/-.002 Frame StructureWelded Steel X,Y Drive Primary Gear With Micro Precision R & P Z Drive Precision Ball ScrewRapid Speed0-900 IPM SpindleHigh Frequency Liquid Cooled Motor Working ModeVariable to 24000rpm Working Voltage AC220V CommandG CodeInterface PCXY Working Tolerance< 0.002 Packing Size 118" x 64" x 44" Net Weight1980 lbs

24" x 96" belt with 28" wide opening into oven Dayton gear drive with 1/2 HP DC motor 230 volt UV unit 96" x 42" x 71" overall dimension

Ingersoll Rand Air Compressor 3 phase 10 hp Work ready

INGERSOLL-RAND UP6-15C-125 15 HP Single-Stage Horizontal Tank-Mounted Rotary Screw Air Compressor, with 2,313 Hrs. (as of 2/16/24) Specifications: Cap. 55 CFM, Max. pressure 125 PSI. Pump speed 6,250 RPM. Sound level 69 dBA. Equipped with: High efficiency close coupled air end. Motor shaft-mounted centrifugal blower. Electronic stepper motor inlet air control. 2-Stage Air-cooled aftercooler. Total positive lubrication system, with Spin-on filter. Compartmentalized sound enclosure. Complete with: 80 Gallon Cap. 24” Dia. x 33” L Horizontal Air Receiving Tank. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

INGERSOLL RAND D144IN 85 CFM Non-Cycling Refrigerated Compressed Air Dryer Specifications: Cap. 85 CFM. Max. working pressure 203 PSI. Max. inlet temperature 60° C (140° F). Refrigerant type R-134A. Equipped with: Aluminum braze plate heat exchanger. Variable speed fan. Microprocessor control, with Graphic display, LED Dew point indicator, Energy saving mode, & History of last (10) alarms. Remote alarm signal terminal. High pressure switch. Fully-adjustable programmable electronic drain valve. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Interwood B3223 Boring Machine 23-Spindles Manufacturer Specs (to be confirmed): (2) 1.5kw, 220/380v, 3ph motors (2) banks of (23) drills 32mm drill spacing (8) spring hold downs (2) pneumatic locators 50-1/2 inch x 30 inch table Pneumatic operation / foot pedal

INTERWOOD C-4010 CASE CLAMP: -- Specifications:Single-Bay pneumatic Clamp with: 108" Long x 60" high x 27" deep clamping cap. -- Equipped with:Movable; vertically positioned clamping beam with (2) adjustable horizontal clamps; (3) adjustable vertical clamps.Horizontal & vertical clamps with: (2) Pneumatic cylinders ea. for a total of (10) pressure cylinders with 2-3/4" stroke. -- Complete with:Built-in Horizontal/Vertical controls with pressure gauges.700 Lbs/Cylinder pressure at 100 PSI compressed air.

INTOREX TX-1600 Hydraulic Copy Lathe Hopper Feed. Overall Specs: -- Full automatic, equipped with (2) hydraulic copiers, (2) tool holder units, (2) back knives, Hopper Feed, Automatic Loading System. and electronic PLC control. Carriage runs on ball screw and tempered/ground guides. -- 1,600 mm (63") Max. between centers; hopper loading capacity of 140 x 140 mm (5.5" sq.) in automatic cycle and 210 mm (8.3") diameter in semi-automatice cycle. -- 10 HP Main motor with a variable speed of 730 - 5100 RPM; 3 HP hydraulic power pack. _ Fitted with PLC programmed logic to assist in setup; All working units (advance carriage, tailstock, tool holder units, etc) are hydraulically powered with independently adjustable speeds. -- Copying system with (2) hydraulic copier knives and traveling steady rest; includes a pre-rounding knife in front of steady; hydraulically powered back knives for doweling or plugging with form tools. -- Includes: Tooling, front safety guard; front mounted electrical panel with easy access to all pushbuttons and controls, and LED RPM display.

IRONWOOD FX 750 SINGLE SPINDLE SHAPER WITH FEEDER1-1/4" Spindle Shaper, (6) variable speeds from 3,000 - 8,000 RPM, 7-1/2 HP 3-Phase straight 230 Volt motor.Features fine adjustment aluminum segmented finger fence which can be easily adjusted to fit to cutter size.Features:- 1-&frac14;" interchangeable spindle, but can also be fitted with &frac12;", &frac34;", 1", 30 mm and 35 mm sizes (additional sizes not included)- Vertical Spindle Stroke 7-1/16"; (180 mm) and 7-1/16"; (180 mm) Max. Tool Diameter (Below Table).- Electronic spindle brake- Forward and reverse spindle rotation with a directional indicator light to ensure safe climb-cutting operations- Raised and lowering of the spindle is adjusted by a precision graduated handwheel read via digital indicator- Spindle rotation controls with direction indicator light- Spindle speed indicator light indicates current RPM.INCLUDES: STEFF 4 Roll, variable speed feeder (10 to 60 FPM)!

Ironwood BR23 Boring Machine 230V/3PH

IRONWOOD DSP-2500 25" Double Sided Planer25" X 8" Double sided planer -- Max Working Width 25" -- Max Working Thickness 8" -- Min Working Thickness 6 /16" -- Min Length of Cut 12&frac12;" -- Upper Cutterhead Motor 25 hp -- Lower Cutterhead Motor 20 hp -- Feeding Cutterhead Motor 5 hp -- Table Rise/Fall Motor 1/2 hp -- Variable Feed Speed 26-78 fpm (8-24 m/min) -- Cutterhead Speed 5,000 rpm Cutterhead Diameter 5" -- Cutter Knives per Head 96 -- Max Stock Removal &frac12;" total / &frac14;" per head Table adjustment -- Digital Electrical 460v (3 phase) 88 amps @ 460V -- Dust Port Diameter 2 ports, 6" each ; Dust Extraction Requirements 1,600 cfm @ 4,500 feet/min -- Machine Dimensions (W x L x H) 105" x 45" x 68" -- Gross Weight 7000 lbs

IRONWOOD P500 508 mm (20") Surface Planer, with Spiral Insert Cutterhead Specifications: 20" (508 mm) max. Width cap., 11.8" (300 mm) max. thickness cap., 0.393 (10 mm) min. thickness cap., 0.325 (8 mm) max. cut depth, 8.6 (220 mm) min material length (un-butted). 7.5 HP Main motor, 3.8" (98 mm) dia. cutter-head with 4.0' (102 mm) cutting circle @ 4,800 RPM; Spiral cutter-head with 75, 2-sided Carbide cutter inserts. Equipped with: Digital Position Controller for Up/Down of the Table. Variable speed by Frequency Inverter from 19 to 39 FPM / 1 HP feed motor. 0.25 HP Motorized support table, 29.4 (748 mm) long x 22.1" (562 mm) wide bed; the table is supported by (4) oversized columns with height positioning via keypad entry within the digital controller. Automatic power off when the top safety hood is opened. Both the infeed chip-breaker and the outfeed pressure rollers incorporate spring-pressured adjustments to ensure positive contact on the workpiece as it is passed through the planer. Two 3” adjustable bed rollers for planing of rough or finished lumber, as well as glued panels. Complete with & more: Magnetic starter, Adjustable bed rollers, (1) 6" dia. Dust outlets. Requires 800 CFM; Instruction Manual & Parts List; Shipping weight 1,800 Lbs. Features: The IRONWOOD P500 Series of 20” thickness planers provide operators with solid thickness planning machinery that offers a powerful cutting performance. This machine features an enhanced heavy-duty cast iron table that is heat-treated and precision ground to assure the greatest rigidity and stability during intense cutting operations. The Ironwood Planers offers enhanced engineering designs and superior build construction for long-lasting and trouble-free performance. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

IRONWOOD SLR 305 Straight Line Rip Saw Specifications: -- Width capacity of 18" and glue line tolerance up to 8'. -- Variable auto-lubrication system providing consistent lubrication to the chain track and automatically adjusting to the chain feed speed -- Minimum Material Length÷ 203 mm (8";). -- Material Thickness, Minimum- Maximum: 6.35 mm (0.25";) to 85 mm (3.35") -- Distance between Blade and Column 457 mm (18"). -- (8) Hold-down Rollers. -- Work Table Height 800 mm (31.5";). -- Saw Arbor Motor 15 HP. -- Saw Arbor Speed 4,500 RPM. -- Saw Blade Diameter 200-300 mm (8&ldquo; - 12&ldquo;). -- Saw Arbor Diameter 25.4 mm (1";). -- Feed Speed 56 - 131 FPM. -- Feed Motor 2 HP.Equipped with & Features: -- Laser device to ensure straight line ripping entire length of the material. -- Maximum safety protection available with multiple rows of extended anti-kickback fingers and a side protection guard. Equipped with & Features -- (8) Accurately aligned pressure rollers extend from the cast iron machining head to provide absolute butting tolerances, low maintenance, and superior safety -- Solid steel cylindrical positioning rod and quick cam, cast iron fence provide accurate set-up, fast movement, and dust-free operations. -- Table Area (W x L) 950 mm (37";) x 1,450 mm (57";). -- Net Weight 2090 Lbs. -- Dust channel outlet (saw guard) 102 mm.

Ironwood S135 MRK Wide Belt Sander Manufacturer specs: 52” Triple head wide belt sander. Head # 1 is a helical planer cutterhead - 150 mm diameter with 30 x 12 x 1,5 mm carbide inserts - Height adjustable with dial indicator - Forty (40) horse power motor - Poly-v belt drive Head #2 is a rubber contact roller - 250 mm diameter 85 shore profiled rubber contact roller - Height adjustable contact roller with dial indicator for grit compensation - Twenty (20) horse power motor - Poly-v belt drive - Cutting speed of 20 mps (65 fps) - Cutting direction against feed Head #3 is a combination head - 140 mm diameter 65 shore profiled rubber contact roller - Height adjustable contact roller with dial indicator for grit compensation - Height adjustable sanding pad - Twenty (20) horse power motor - Poly-v belt drive - Air jet belt cleaning - Cutting speed of 12 mps (40 fps) - Cutting direction against feed
