SUPERFICI/VALTORTA F1SPECIFICATIONS: --Belt width - 1370 mm / 54 inches, Roller width 1500 mm / 59 inches --Working height 900 mm / 35 inches --Panel thickness 3 - 120 mm / .11" - 4.75" -- Min. panel length - 300 mm / 11.8" -- Application roller diameter - 245 mm / 9.6" -- Standard hardness of the application roller - 50Sh -- Doctor roller diameter - 175 mm / 6.8" -- Feed speed - 7 - 20 m/min / 23 - 65.5 fpm -- Compression air consumption 25 NI/min -- Approximate installed power 2kW

SPERFICI - "Climber Easy 150-C-2/2100", ...Automatic Moulding StackerThis equipment collects strips/profiles coming from a Painting Line and stacks them up automatically on suitable Racks for drying.General Description: -- Machine structure built with electro-welded and painted steel with some aluminum profiles parts. -- On the base of the machine are the columns of the balance devices, as well as the roller way where profiles are fed into the Stacker. -- Side of the roller way built with aluminum profiles having PVC-covered cantilever rollers with different pitch. -- Rollers are driven by an electric motor controlled by an Inverter. -- Lifting balance devices are driven by chains with top system for profiles, movement is mechanically synchronized. -- The machine has (3) Cantilever arms, supported by cross parts & plates sliding on nylon wheels, driven by (3) vertical aluminum profiles. -- The cantilever arms, which place the profiles on the rack arms, have (3) driven V-belts which are covered with soft polyurethane and have different speeds controlled by an Inverter.Technical Data:- Overall dimension: 3,850 mm.- Rollers conveyor speed: 20 - 70 MPM (avg. working speed 150 FPM).- Working height: 900 +/-20 mm.- Working width: 150 mm (6").- Arms pitch: 2,100 mm (6'-8").- Max. profile length: 3,200 mm (10-1/2').- Min. profile length: 1,300 mm (50").- Max. height for profile deposit: 2,000 mm.- Min. height for profile deposit: 490 mm.- Max. cycle: (20) Pcs./Min.- Installed power: 3.8 kW.- Compressed air consumption: Negligible.

SUPERFICI Compact Spray Automatic Spraying Machine; System is ideal for medium to high volume production. Product: Kitchen cabinet components, panels, furniture components, doors, etc.Coatings: TBDGENERAL EQUIPMENT FEATURES:Pass-line Height: 900 mm (35-7/16")Operating side: RH, as viewed from inlet of line.Work piece Dimensions (Approx.):Min. - max length: 300 mm - 4,800 mm (12" - 16')Min - max width: 25 mm - 1,300 mm (1" - 51")Min - max thickness: 3 mm - 80 mm ( 1/8" - 3-1/8" )Max. weight: 2.2 Lbs per sq ft maximumSpeeds:Mechanical Speed: 2 - 6 m/MinAvg. production speed: TBD based on coatings and Drying system used. -- Photocell Reading System to detect the incoming workpieces profile and the electronic control to adjust the spray profile of the parts. The guns will trigger only when the parts are present. -- Closed belt conveyor system mounted on an open structure for easy removal. The belt conveyor is made of a special material to work with all types of stains and paints. -- Reclamation system for spray lacquer, varnish, multicure (UV) and water base solvents. Patented lacquer recovery system for recovery and cleaning of the conveyor belt; the system is mounted on trolley that is extractable from the machine for easy maintenance. -- A double arm reciprocator driven by inverter controlled motor and sliding on high precision guide rails. -- The two arms are equipped with guns holder supporting up to max four (4) guns each arm with two active lacquer circuits. -- Pressurized spray cabin with access windows from both sides; filtering roof intake celling in the spray cabin with blowing fans on the top of the roof. -- Exhaust system with double stage paint filters over exhaust ventilator.Technical Specifications: -- Mechanical speed: 2 - 6 MPM (6-1/2 - 19-1/2 FPM) Avg. - Typical Production speed: 2 - 3 MPM (6-1/2 - 10 FPM). -- Working width of 1,300 mm (51"), max. part thickness 80 mm (3-1/16"), Pass through working height above floor 900 mm (35-1/2"); -- Exhaust air volume of 7,000 cbm/Hr. -- Compressed air consumption (with guns) 1,500 N1/Min. Approximatley.Utility Connections:Voltage: 480 V / 3Ph / 60 Hz + groundCompressed air: 6 bars (90 PSI)USED LAMINAR DRYER, is available with this sprayer at an additional cost (not included in this price)CEE standard execution. Conveyor executed according to the European norms, to be positioned in a safe environment (not classified as an area with risk of explosion).

SUPERFICI - Bravorobot: Complete Spray LineLine includes: Sanding; Brush Cleaning; Robot Sprayer; IR Flash Oven, Forced Air Dryer, Cooling Off section, Panel Turner, and Outfeed Conveyor.Robot can be used for: 5-Axis or Flat Line spraying.Specifications Part length:......................Min. 12"; max. 120" for panel & 144" for moulding. Part width.........................Min. 1"; max. 51". Part Thickness.................Min. 1"; max. 4". Working height.................900 mm +/- 20 mm (35 7/16"). Feed speed......................2 - 6 MPM. Sprayer Speed.................40 - 140 MPM. Overall line dimensions....112' Long x 40' wide.Line Composition 1) Infeed Conveyor. 2) Denibbing Sander: PROFICANDER-C "Flextrim" (2) Brush. 3) Belt Conveyor for quality control. 4) Cleaning Brush: FV/SISAL/1. 5) Infeed Conveyor. 6) VALTORTA "Bravorobot" P1 with: (4) Guns for flat spraying & (1) 5-Axis Robot Sprayer; Paper Belt Cleaning System. 7) Outfeed Conveyor. 8) 1st Drying Tunnel Flash Off: IRS Laminar Dryer 5 M. 9) 2nd Section: Hot Air Dryer with: Gas heating unit: 6,000,000 BTU.9.10) 3rd Drying zone with: Hot Air.10.11) 4th Drying zone with: Air Blade with UV Lamp.12) Cooling Conveyor & quality control zone.13) DOUCET Panel Turner.14) Outfeed Belt Conveyor.NOTE: System was Professionally torn down & can be reinstalled by the same Technician.

Belt conveyor TT1 3500, Deionizing system, Superfici Twin Spray reciprocating sprayer with recovery system and dry filter UMI UMA, Laminar Dryer UMI UMA Laminar Dryer UMI UMA Laminar Dryer Transition Hoods Twin UV Dryer Belt Conveyor TT1 Line is U-shaped

Manufacturer’s Specification - Maximum Width: 24” - Brush: 9"-11" Typical Diameter - Speed: Ranged Variable, 400-1200 rpm Brush - Motor: 5 HP, 220 Volt, Single Phase - has (1) broken caster

SUPREME AIR SYSTEMS - Conveyorized Paint Spray Line -- (2) SUPREME AIR SYSTEMS - PRO-FIT: 12' W x 14' D x 12-1/2' H Open Face Freestanding Dry Filter Paint Spray Booths. Each with: (2) Cutout openings for conveyor & parts; (4) ceiling flush-mounted light fixtures; bolt-together galvanized steel panels; DWYER "MARK II 25" inclined-vertical manometer & 34" dia. 5 HP ceiling mounted exhaust fan. -- SUPREME AIR SYSTEMS - PRO-FIT 12' W x 14' D x 12-1/2' H Enclosed Freestanding Drying Booth with: (2) Cutout openings for conveyor & parts; (4) ceiling flush mounted light fixtures; bolt together galvanized steel panels. -- (2) CUSTOM-BUILT Infrared Drying Units. Each with: (2) HEDSON "IRT-402 800584" 12 kW Heater Cassettes; each with: "IR7" Digital Programmable Controller with LCD Display & Touchpad. -- APICAL CONVEYOR SYSTEMS 3" I-Beam Overhead Monoveyer Conveyor System: 14' W x 8' L, with: 1 HP Motor; adjustable conveyor speed; "API50008" automatic lubrication system; control panel with: Display & Structural steel support. -- SUPREME AIR SYSTEMS -SAB925DNi: 25,000/12,500 CFM Dual Stage, Direct Fired Natural Gas Heated Air Make-Up Unit: S/N 190405, Roof-mounted with: 20 HP Blower motor, MAXON 40,000 BTU/Hr Burner. NOTE: Line & assembly drawings available upon request.

TAKEKAWA - RG-30S, ...Straight Line Rip SawSpecifications: -- 15 HP - 5,000 RPM Belt driven arbor, overhead arbor design. -- 1-1/4" Dia. arbor. -- 12" Dia. max. blade cap., 2-3/4" max. depth of cu.t -- 12" Min. part length. -- Throat clearance to the right of blade 26". -- Table size: 74" Long x 38" wide; 2 HP step feed drive, 33 - 66 & 131 FPM.Equipped with and Features: -- Automatic chain lubrication. -- Top pressure system with spring loaded rollers. -- Adjustable rip fence. -- Antikickback fingers. -- Push buttons and magnetic starters.

Runs good and is still in operation Hooked up to 460 Table Extension has been repaired Main table has almost zero wear on it.

16" Blade cap., 3-3/4" max. cutting height, 5 HP - 3,600 RPM direct drive motor, arbor tilts 45ø, 44" x 40" cast iron table size, table with miter gauge slot. -- Complete with: Rack & pinion fence and large hand wheels for easy adjustments.

TANNEWITZ - XJ: Table Saw with Tilting Arbor -- 5 HP - 3,600 RPM Fan cooled motor; 1" right tilting arbor; 42" x 45" table size. -- Base formed from: Hot rolled steel; 5/16" thickness; welded into: (1) Solid unit; 10" dia. handwheels for easy & smooth adjustment of tilting; raising & lowering of arbor. -- Saw is upgraded to include: AMBITECH - Model SS-4A-10: Electronic Motor Brake. -- Complete with: 16" Blade dia.; 4" dado width cap.; 4" cut depth at: 90°; 3" cut depth: 45°; magnetic controlled off-switch; 6" dust extraction with: Auxiliary rear opening for easy access.

Capacities: 11” minimum length 98” maximum length 1” minimum width 32” maximum width 5/8” minimum thickness 3” maximum thickness with a conversed glue spreader(model 30J)

Taylor/JLT 79-X-4M Door Clamp Taylor/JLT 4 Section rotary Door Clamp for mitered or regular doors. 120 Volt 10 Amp - Power Button Rotation with Electric Motor Drive, 110 V single phase for all applications - Air Clamping with individual regulator controls for maximum versatility - Approximately 36” X 96” Capacity with adjustability for smaller sizes

Miter Door Pro 5 Rotary Clamp Model 79x-5-LM 5-section 38” x 96” capacity per section (2) Horizontal and (2) Vertical clamps per section heavy duty diaphragm pneumatic cylinders per clamp counter clockwise rotation 1 HP motor for rotation 115 volt

Taylor Rotary Clamp Unit was rebuilt by Taylor

--In Auction: https://exfactoryauctions.com/Detail/CR-230068/event/A122024$1 --No Reserve!-- TAYLOR 800036 7' W 12-Section Semi-Automatic Pneumatic Clamp Carrier, with Flattener & Tightener Equipped with: (71) 32” Cap. Clamps, with 4-5/8” W x 3-1/2” H Jaws. Air motor drive. Dual foot pedal control. Complete with: Pneumatic Panel Flattener. Pneumatic Clamp Tightener.

TAYLOR - 713A-5LCM: Rotary Door Clamp (5-Section) -- 5-Section rotating clamp for: Accurate squaring of Miter Doors & stile and rail doors. - Clamp & Square a door in: (2) Seconds. -- Each section has: 26" x 97" Max. cap.; 4" x 12" min. cap.; counterclockwise rotation with: Auto indexing stop system. -- Single lever operation with (2) vertical and (1) horizontal clamp, 500 Lbs. clamping force per cylinder. -- Electric gear motor runs on standard 110 V; variable speed push button operated rotation system - counterclockwise for safety.

TAYLOR 40 Section Clamp Carrier.Specifications: -- 40-Section, 8-1/2' width capacity -- Average 4/5 clamps per section (175 clamps total), all with 32" max. clamp opening. -- Equipped with (175) clamps plus a pallet of spares that require repair, 32" clamps with 2-1/2" high jaws .Complete with: -- Heavy Duty Drive for rotation,& clamp tightening. -- Foot pedal control. -- Includes a glue applicator.

TAYLOR - 16 Section: Clamp Carrier -- (16) Sections; 8-1/2' wide. -- (6) Clamps per section; total of (96) clamps; 32" opening clamps; 2-1/2" high x 3-1/2" jaw width. Complete with: -- Pneumatic clamp tightening; air motor drive carrier rotation.NOTE: Tear down & loading not included.

TAYLOR: 20-Section Clamp Carrier • 16-1/2' Width cap.; (12) clamps per section (240 approx. clamps total).• 32" Max. clamp opening; clamps with: 2-1/2" Jaw height.Complete with: -- Pneumatic torque wrench clamp tightening; pneumatic panel flattener; air drive carrier rotation.• Buyer will be responsible for: "Tear down" & "Loading!"
