TRS-460M4 Multiple Blade Rip Saw w/Optimizing, (4) SHIFTING BLADES &#9679 WITH 18" OF USEABLE ARBOR SPACE!Specifications: -- Moveable sawblades when using the Optimization program.1-1/2"; minimum distance between movable saw blades -- Sawblade configuration with (4) movable saws and (1) fixed sawblade -- Sawblades are optional -- Infeed & outfeed roller tables are optional -- With 50 HP saw arbor drive motor and 3 HP feed motor -- Pressure rollers elevation motor: 1/2 HP -- (4) 1 HP servo motors for shifting sawblades -- Fence adjustment is manual. -- (4) 0.13 HP servo motors for shifting Laser Lights -- With (5) Laser Lights -- UL electrical components. -- 10 to 130 FPM variable feed speed -- 18"; Max. distance between fixed saw and the last (outside) movable saw -- 31"; Max. material feeding width -- 27"; Min. cutting length -- (2) 6"; Dust hoods -- Cutting depths: 10" blade, 1.65"; thick ; 12"; blade, 2.65"; thick; 14", 3.66"; thick; 16" blade, 4.64"; thick -- Sawblade size vs. RPM. Make Blade size clear when order) -- Spindle speed @: 3,800 RPM (10" & 12"sawblade) / 3,000 RPM (14" & 16"sawblade)Computerized Rip Optimizing Program, Included: -- The operator only sets a line for total width, then the computer performs optimized ripping according to sizes set on the job sheet and the priority mode set from these options: -- 1. Priority according to the widest -- 2. Priority according to the same size -- 3. Fixed-width ripping -- 4. Yield priority -- 5. Value priorityOPTIONAL MODEL TRS-460M4-INCOV 3500mm AUTOMATIC INFEED CONVEYOR SYSTEM WITH SCANNER AND OPTIMIZING SYSTEM, add $198,000 -- Automated infeed system, speed rate controlled by electrical clutch connected with the Ripsaw's feed chain -- 13' max. infeed length with (16) width detectors (scans every 8") -- Special pressure roller set, motion with liner rail and air cylinder -- Width scanning by sensors, with optimizing program for auto calculating -- Moving fence by servo motor, according to the wood width

CAM-WOOD MODEL TRS-3000TB.12" SLAT RIPPER - (1) top & (1) bottom rip spindle.CAM-WOOD MODEL TRS-2050TB.8" SLAT RIPPER - (1) top & (1) bottom rip spindle - DEDUCT $8,000 for the 8" Cap. modelFEATURES: -- The machine can plane or shape the wood at two surfaces and then rip it. Ideal for shutters, louver slats, yardstick blanks, etc.. -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show the true value of these machines in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with a measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw heads built to precise tolerances assure accuracy for all ripping and profiling operations providing a stellar cut quality. -- Top & bottom powered pneumatically tensioned pressure rollers for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground, and balanced providing precise cutting performance.SPECIFICATIONS: -- 12"; Max. Cutting Width (TRS2050 WITH 8" MAX. WIDTH) -- 4-3/4"; Max. Cutting Depth -- Min. Cutting Depth Limited by Thin Material Breakup -- 10"; Min. Workpiece Length -- 14"; Dia. Max. Sawblade Size on Top Spindle -- 10" to 16"; Dia. Sawblade Size on Bottom Spindle (TRS2050 WITH 16" DIAMETER) -- 4,000 RPM Top & Bottom Spindle Speed -- 12"; Spindle Length (TRS2050 WITH 8" SPINDLE LENGTH) -- 40mm Arbor Diameters with 2-Keyways (TRS 2050TB WITH 70MM ARBORS) -- 15 HP Top Rip Saw Motor (TRS 2050 WITH 10 HP MOTOR) -- 30 HP Bottom Rip Saw Motor -- (6) Upper and (2) lower Feed Rolls -- 12 to 60 FPM Feeding Speed (Variable) -- 1 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Lower Saw Arbor Elevating Motor -- 7-1/2 HP Feed Motor (TRS2050 WITH 3 HP MOTOR) -- Dimensions (L x W x H) 96" x 64" x 55"

CAM-WOOD MODEL TRS-1200TB SLAT RIPPER - (1) Top & (1) Bottom Rip Spindle.The machine can plane or shape the wood on two surfaces and then rip it. Ideal for shutters, louver slats, yardstick blanks, etc.Features: -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with a measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight-line ripping operations and provides a stellar quality of cut. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground, and balanced providing precise cutting performance.SPECIFICATIONS: -- 8"; Max. Cutting Width -- 5"; Max. Cutting Depth -- 10"; Min. Workpiece Length -- 4"; to 6"; Dia. Top Spindle Sawblade Size -- 8"; to 12"; Dia. Bottom Spindle Sawblade Size -- 6,000 RPM Top & Bottom Moulder Spindle Speed -- 8"; Spindle Length -- 40 mm Rip Saw Arbor Diameter (with key) -- 10 HP Top Rip Saw Motor -- 15 HP Bottom Rip Saw Motor -- 12 to 60 FPM Feeding Speed (Variable) -- 1/2 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Rip Saw Arbor Elevating Motor -- 3 HP Feed Motor

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: Short Stock version12" Width cap.; 3/8" min. to 3-3/4"; max. cutting depth; 7" min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 10"; - 12"; dia.; arbor is powered by a 40 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 28"; Wide x 67"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high-quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision-built saw head ensures accuracy for straight-line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) holddown plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards.

Cam-Wood TRS-MR-1300 X 75mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

Cam-Wood TRS-MR-1300 X 100mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

CAM-WOOD AC-7580 Piston Air CompressorCompact unit with a 7.5 HP induction motor.Features & Specifications: -- 22 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-5080 Piston Air CompressorCompact unit with a 5 HP induction motor.Features & Specifications: -- 18 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-100120 Piston Air CompressorHeavy Duty unit with a 10 HP induction motor.Features & Specifications: -- 34.2 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 120-Gal. horizontal tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD DC-102 Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 230 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.

CAM-WOOD DC-8075 Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 5,800 CFM.Includes: -- Heavy Duty 7.5 HP motor pre-wired at 220 V. -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 db. keeps the work area quiet. -- Optional connection for using barrels.

CAM-WOOD DC-8100X Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 7400 CFM.Includes: -- Heavy Duty 10 HP motor pre-wired at 230 V. -- 10" Inlet -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 Db keeps the work area quiet. -- Optional connection for using collection barrels.Note: 230 or 460 Volt, 60 Cy, 3-Ph please advise.

CAM-WOOD DC-535X DUST COLLECTOR 2900 CFM5 HP Motor and 14" Dia. Radial-fin type steel impeller to get the best efficiency usage.Specifications: -- Two top filters and two collection bags. -- Heavy-duty motor for powerful operation. -- Larger size impeller and extra long top air exhaust bags enabling to collect sawdust and wood chips more easily. -- Standard steel spring clamps to secure the bags with the body without leaking dust. -- Low sound levels keep the working area quiet. -- Replacement bags or 5 micron bags for fine dust are available. Optional connect bags for barrels are available.

CAM-WOOD DC-07 STA Cyclone Dust Collector w/ After-filtersNew designed two-stage cyclones. As the “dirty"; air stream enters the collector, the heavy particles are separated by cyclonic action and fall to the bottom storage bag. The remaining air stream with fine dust goes through the impeller, it can increase dramatically the life of the impeller & motor preventing damage from large material.Features: -- 7.5 HP blower with 4,200 CFM. -- Inlet Diameter 12" x 4" x 5. -- Heavy sheet metal frame and base. -- Extra-large radial-fin type steel impeller for high-efficiency airflow. -- Heavy duty totally enclosed industrial motor for maximum air suction and extended service life. -- Quick-release clamps are used to tighten the bags; this helps to reduce downtime when doing maintenance. -- Low sound levels to keep the working area quiet. -- Includes: (2) Collection drums

CAM-WOOD DC-102-3X Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 460 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.

CAM-WOOD DC-10 STAX Cyclone Dust Collector w/ After-filtersNew designed two-stage cyclones. As the “dirty"; air stream enters the collector, the heavy particles are separated by cyclonic action and fall to the bottom storage bag. Then the remaining air stream with fine dust goes through the impeller, it can increase dramatically the life of the impeller & motor preventing damage from large material.Features: -- 10 HP blower with 5,000 CFM. -- Inlet Diameter 13" x 4" x 5. -- Heavy sheet metal frame and base. -- Extra-large radial-fin type steel impeller for high-efficiency airflow. -- Heavy duty totally enclosed industrial motor for maximum air suction and extended service life. -- Quick-release clamps are used to tighten the bags; this helps to reduce downtime when doing maintenance. -- Low sound levels to keep the working area quiet. -- Includes: (2) Collection drums

CAM-WOOD BX-1212BEEX Single Bottom Head Band Resaw.Can be used to cut boards, cants, or reclaim slabs; Specifications: -- Can process up to 12" H x 12" W; 5/16" - 5-1/4" from blade to conveyor. -- 2 HP Electric motor controlled variable speed from 12 - 80 FPM. -- This Model BX-1212BEE is equipped with: -- 20 HP Saw Motor, 28" x 1" band wheels, 168" x 1" band saw blade (not included). Features: -- Hand-wheel blade tensioning; manual elevation adjustment; 2 HP hydraulic system pump motor. Complete with: -- Spring-loaded steel and rubber upper-pressure rolls; 11" X 215" conveyor belt.

CAM-WOOD BX-1212HR-1 Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; Specifications: -- Max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; -- VFD controlled variable speed from 0 - 60 FPM. Equipped with: -- 20 HP Saw Motor, 24" x 2" dynamically balanced cast iron band wheels, 184" x 1" to 1-1/2" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 10-5/8" x 165-1/2" infeed conveyor from 0° - 30° with side support for bevel cutting; 3 HP drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor.Complete with: -- Programmable Digital Controller for convenient and accurate thickness setting; -- 1/4 HP Blade elevation motor moves blade and saw head; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR Single-Head Band Resaw w/Return ConveyorCan be used to cut boards, cants, or reclaim slabs; max. working height up to 16" under pressure roller x 16-1/2" Widths; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 60 ft./min.Equipped with: -- 30 HP Saw Motor, 32" x 2" dynamically balanced cast iron band wheels, 230-1/4" x 2" - 4" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- 3 HP Frequency Drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor; a side support is applied for safe and stable cutting operations.Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-2410HR Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; max. working height up to 10" H under pressure roller x 24" W; 5/32" - 10" between blade and conveyor; VFD controlled variable speed from 0 - 82 FPM.Equipped with: -- 30 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 195-1/2" x 2-1/8" x 3/64" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 23" x 215" infeed conveyor from 0° - 30° with side support for bevel cutting; hydraulic infeed and outfeed conveyor drive motor; variable feed speed 0 - 82 FPM; return gravity roller conveyor. -- Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
