CAM-WOOD M5412-SCX Tenoner & End Matching MachineTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position.One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the full cutting power. -- Twin table moves in and out separated for tongue and groove, end-match application. -- Twin heavy-duty pneumatic pistons hold down the work pieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy duty industrial motor is suitable for heavy-duty cutting under full load. -- Linear guide rails and bearings let the operator move the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD RD-5412-SC Tenoner with Dowel DrillTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position. -- Drill heads for dowel hole at each end. -- One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the fully cutting power. -- Twin table moves in and out separated for tongue and groove, end match application. -- Twin heavy-duty pneumatic pistons hold down the workpieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy-duty industrial motor is suitable for heavy duty cutting under full load. -- Linear guide rails and bearings let the operator moving the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD TRS 0012, Straight Line Rip-SawSpecifications: -- Max. cutting depth 3-3/4". -- Arbor Diameter 1". -- Saw Blade Size 8½" - 12". -- Throat to Blade Depth 15". -- Table Dimensions 33" x 59". -- 10 HP Main Motor. -- Spindle Speed 4,500 RPM. -- Feed Motor 1 HP. -- Feed Chain Width 6". -- Feeding Speed 30 - 85 RPM. -- Automatic Lubrication. -- Chip & Dust Collection Hood Diameter 4".Features: -- Cast iron and hard chrome plated table for durability & extended wear. -- Precision machined saw trunnion & fence assure optimal accuracy. -- Measuring ruler gauge for easy & accurate fence adjustments. -- Double anti-kickback fingers mounted at the infeed provide safety protection for the operator. -- Heavy-duty industrial motor for powerful cutting capacity. -- Rugged fabricated durable steel construction for years of use.Feed System: -- Variable speed settings enable the machine to meet different application needs. -- V-way track and chain block surfaces are heat-treated for longer, lasting usage. -- Automatic lubrication to V-Way track allows the chain to operate smoothly. -- (4) Pressure Rollers for accurate cutting of both large and small workpieces.Special Features: -- Saw arbor is manufactured from NI-Cr-MO alloy steel to provide the best durable and anti-fatigue, heat treated, and balanced for a more accurate cut. -- (4) Bearing spindle mount for prolonged life usage.

CAM-WOOD TRS-3020 Single Blade Bottom Cut Straight Line Rip SawEquipped with & Features: -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Double anti-kickback fingers mounted at the infeed end provides maximum safety protection. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage. -- The variable feed speed enables the machine to meet different requirements of work. -- V-way track and chain block surface are heat-treated for long wear resistance. Automatic lubrication to the V-Way track facilitates the chain running smoothly. -- Precision-built saw head ensures accuracy for straight line rip saw operations. -- Four bearing spindle mount ensures rigidity & long life. -- Anti-kickback finger, two long rollers, in front of the saw blade, 4 x 2 = 8 short rollers at the side of the saw blade, two long rollers at outfeed. -- The auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines.Specifications -- Maximum Cutting Depth 5-5/8" -- Arbor Diameter 2" -- Max. Amount of Blades Per Spindle -- 1 Saw Blade Size 20" -- Table Dimensions 45" x 78" -- Spindle Speed 3600 RPM -- Feeding Speed 30 ~ 85 -- Throat to Blade Depth 26" -- Main Motor 20 HP -- Feed Motor 3 HP -- Feed Chain Width 8-3/4" -- Automatic Lubrication YES -- Minimum Workpiece Length 8" Exhaust -- Hood Diameter 1 4" x 1 + 5"; x 1 -- N.W. 4100 LBS

CAM-WOOD TRS-3018 Single Blade Bottom Cut Straight Line Rip SawEquipped with & Features: -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Double anti-kickback fingers mounted at the infeed end provides maximum safety protection. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage. -- The variable feed speed enables the machine to meet different requirements of work. -- V-way track and chain block surface are heat-treated for long wear resistance. Automatic lubrication to the V-Way track facilitates the chain running smoothly. -- Precision-built saw head ensures accuracy for straight line rip saw operations. -- Four bearing spindle mount ensures rigidity & long life. -- Anti-kickback finger, two long rollers, in front of the saw blade, 4 x 2 = 8 short rollers at the side of the saw blade, two long rollers at outfeed. -- The auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines.Specifications: -- Maximum Cutting Depth: 4-3/4", Arbor Diameter 2". -- Saw Blade Size: 14" - 18" in diameter. -- Table Dimensions: 58" x 78". -- Spindle Speed: 3,600 RPM. -- Feeding Speed: 30 - 85 FPM. -- Throat to Blade 26". -- Main Motor: 20 HP, Feed 3 HP motor. -- Feed Chain Width: 8-3/4". -- Minimum Workpiece Length: 8" . -- Exhaust Hood Diameter 4". -- NW: 3,800 Lbs. Note: LA-6000 Laser Beam Light Available @ $980.00

CAM-WOOD TRS-1112 12" Single Blade Top Cut Straight Line Rip Saw;Precision machining and attention to operator safety and production needs, makes this saw one of the most cost effective Rip Saws available in the world today.Features: -- Hard chrome-plated table for maximum wear resistance. -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Double anti-kickback fingers mounted at the infeed end provides maximum safety protection. -- Heavy-duty industrial motor for powerful cutting performance. -- Ruggedly constructed sheet metal frame for durability usage. Feed & Saw Head: -- The variable feed speed enables the machine to meet different requirements of work. -- V-way track and chain block surface are heat-treated for long wear resistance; automatic lubrication to the V-Way track facilitates chain running smoothly. -- Precision-built saw head ensures accuracy for straight-line rip saw operations. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground, and balanced providing precise cutting performance. -- Four-bearing spindle mount ensures rigidity & long life. Four pressure rollers for precise cutting of large and small workpieces. -- Heavy-duty cast iron table.Specifications: -- Max. cutting depth: 3-3/8". -- Arbor dia.: 1". -- Saw blade size: 12" diameter. -- Table dimensions: 28" X 61". -- Spindle speed: 3,300 RPM. -- Feed speed: 30 - 72 FPM; -- Throat to blade depth: 15". -- Main motor: 11.75 KW (15.75 HP) -- Feed motor: 1 HP. -- Feed chain width: 6". -- Automatic lubrication. -- Min. work piece length: 12". -- Exhaust Hood Dia. 4". -- Net weight: 1,960 Lbs.Options: -- AF-RT EXTENSION ROLLERS SIDE TABLE ...$390.00 • LA-6000 LASER BEAM LIGHT ...$980.00

CAM-WOOD TRS-2216 -- 16" Single Blade Bottom Cut Straight Line Rip Saw;Precision fence ensures absolute accuracy between blade & fence, with a precision gauge.Equipped with and Features: -- Double anti-kickback fingers mounted at the infeed end provides maximum safety protection. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage. -- The variable feed speed enables the machine to suit different wood species and work applications. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Precision built saw head ensures accuracy for straight line rip saw operations. -- Four bearing spindle mount ensures rigidity & long life. -- Anti-kick finger, two long rollers, in front of saw blade, 4 x 2 = 8 short rollers at side of saw blade, two long roller at out feed. -- The auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil. Specifications: -- Max. cutting depth: 3-1/8". -- Arbor dia.: 2". -- Saw blade size: 16". -- Spindle speed: 3,300 RPM. -- Feed speed 21 - 85 FPM. -- Throat to blade depth 16". -- Main motor: 10 HP. -- Feed motor 2 HP. -- Min. work piece length: 8". -- Dust Collection Hood dia. 4".Options- LA-6000 LASER BEAM LIGHT ...$980.00

CAM-WOOD TRS-2218 18" Single Blade Bottom Cut Straight Line Rip SawPrecision fence ensures absolute accuracy between blade & fence, with a precision gauge.Equipped with and Features: -- Double anti-kickback fingers mounted at the infeed end provides maximum safety protection. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage. -- The variable feed speed enables the machine to suit different wood species and work applications. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Precision built saw head ensures accuracy for straight line rip saw operations. -- Four bearing spindle mount ensures rigidity & long life. -- Anti-kick finger, two long rollers, in front of saw blade, 4 x 2 = 8 short rollers at side of saw blade, two long roller at out feed. -- The auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil. Specifications: -- Max. cutting depth: 4-3/4". -- Arbor dia.: 2". -- Saw blade size: 14" - 18" dia., -- Spindle speed: 3,300 RPM. -- Feed speed 30 - 85 FPM. -- Throat to blade depth 26". -- Main motor: 15 HP. -- Feed motor 3 HP. -- Min. work piece length: 8". -- Dust Collection Hood dia. 4".Options- LA-6000 LASER BEAM LIGHT ...$980.00Machine size 91" L X 47" W X 59" H; Net weight: 3960 Lbs

CAM-WOOD BX-1212HR-1 Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; Specifications: -- Max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; -- VFD controlled variable speed from 0 - 60 FPM. Equipped with: -- 20 HP Saw Motor, 24" x 2" dynamically balanced cast iron band wheels, 184" x 1" to 1-1/2" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 10-5/8" x 165-1/2" infeed conveyor from 0° - 30° with side support for bevel cutting; 3 HP drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor.Complete with: -- Programmable Digital Controller for convenient and accurate thickness setting; -- 1/4 HP Blade elevation motor moves blade and saw head; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR Single-Head Band Resaw w/Return ConveyorCan be used to cut boards, cants, or reclaim slabs; max. working height up to 16" under pressure roller x 16-1/2" Widths; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 60 ft./min.Equipped with: -- 30 HP Saw Motor, 32" x 2" dynamically balanced cast iron band wheels, 230-1/4" x 2" - 4" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- 3 HP Frequency Drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor; a side support is applied for safe and stable cutting operations.Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-2410HR Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; max. working height up to 10" H under pressure roller x 24" W; 5/32" - 10" between blade and conveyor; VFD controlled variable speed from 0 - 82 FPM.Equipped with: -- 30 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 195-1/2" x 2-1/8" x 3/64" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 23" x 215" infeed conveyor from 0° - 30° with side support for bevel cutting; hydraulic infeed and outfeed conveyor drive motor; variable feed speed 0 - 82 FPM; return gravity roller conveyor. -- Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR-TN Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 16" H under pressure roller x 16" W; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 30 HP Saw Motor (each head), 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; 1/2 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1212-HR-TNX Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 20 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; -- Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; -- 1/2 HP Blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by a gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.

CAM-WOOD BX-1212BEEX Single Bottom Head Band Resaw.Can be used to cut boards, cants, or reclaim slabs; Specifications: -- Can process up to 12" H x 12" W; 5/16" - 5-1/4" from blade to conveyor. -- 2 HP Electric motor controlled variable speed from 12 - 80 FPM. -- This Model BX-1212BEE is equipped with: -- 20 HP Saw Motor, 28" x 1" band wheels, 168" x 1" band saw blade (not included). Features: -- Hand-wheel blade tensioning; manual elevation adjustment; 2 HP hydraulic system pump motor. Complete with: -- Spring-loaded steel and rubber upper-pressure rolls; 11" X 215" conveyor belt.

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: (...Typically in stock for immediate delivery!)12" Width cap.; 3/8" min. to 4-3/4"; max. cutting depth; 14"; min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 12"; - 14"; dia.; arbor is powered by a 50 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 30"; Wide x 62"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision-built saw head ensures accuracy for straight line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) hold-down plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground, and balanced, providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards. Options when ordering with machine: -- (1) Set spare feed chain link, please add ...$ 96. -- (1) Set of arbor drive belts consisting of (6) matched belts, add ...$680. -- Additional saw sleeve with spacer set consisting of: (2) 50 mm, (3) 25 mm, (4) 10 mm, (18) 1 MM, (10) 0.5 mm, (8) 0.25 mm, Please add... $745

CAM-WOOD TRS-405-SS Short Stock Rip Saw ...with the following specifications and features:Specifications: -- Max cutting width: 12.6"; -- Min length part: 3.15"; -- Short stock ratio of thickness to length: 2:5 -- Distance from center of chain to throat, 30"; -- Saw arbor powered by 50 HP Std. - 30 HP, 60 HP and 75 HP optional -- Spindle speed, 3,200 RPM -- Sawblade diameter to thickness: 10"; dia = 2"; thick, 12"; dia = 3"; thick, 14"; dia = 4"; thick, 16"; dia = 5"; thick -- Sleeve diameter (sawblade bore), 70 mm -- Sawblade keyway, 2 each 20 mm wide -- Spacer size, 70 mm ID x 95 mm OD -- 2 HP feed motor, 3 HP optional -- Variable feed speeds from 20 to 80 FPM -- Head elevation powered by ¼ HP motor -- With (2) 6"; dia. dust outlets -- NET weight, 5,500 Lbs. Features and Benefits: -- Exclusive feed track - Design for short stock feed – see literature! -- Exclusive length capacity on a standard Gang Ripsaw, as short as 3";! -- Turn waste blocks into useable parts -- Pressure rolls supported from both sides hold stock securely for even, smooth ripping -- Pressure plate (hold-down shoe) supported from both sides; helps prevent split parts from damaging sawblades -- Power raise and lower for overhead pressure roll and hold-down assembly -- Variable feed speeds allow ripping a variety of material, hard or soft, thick or thin -- 2-Top and 1-bottom rows of kickback fingers plus side splitter guards provide operator safetyNOTE: ...Where have you seen a Gang Ripsaw capable of ripping as short as 3"!!! ...Also perfect for slats!

CAM-WOOD TRS-190-2VS 7.5"; x 6"; VERTICAL SPINDLE MOULDER FOR SMOOTH SLAT RIPPINGIncludes one setup including Splitter Set, Holddown Plate, Fence, Sawblades, and Spacers WORKING CAPACITY -- Working width: 3"; to 7-1/2"; -- Working height: 3/4"; to 6"; RIGHT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. LEFT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. SPINDLE COMPONENTS AND ASSEMBLY -- Precision spindles are manufactured from SCM-4 tool steel imported from MITSUBISHI Japan, heat treated to HR 46° (ROCKWELL C Scale) fitted with class 6 -- SKF-matched ball bearings then mated to precision machined spindle housings. -- The spindle body and bearing housing are burnished. -- Spindle hardness and accuracy, high precision SKF bearings, and precise spindle housing and bearing installation by SHEN KO provides a spindle assembly -- Capable of speeds to 9,000 RPM and will meet every user’s requirement. -- Spindles are powered by V-shaped belts (MITSUBISHI) without slippage. FEED SYSTEM -- Powered with a 5 HP motor -- Feed speed is infinitely variable by inverter drive from 20 to 120 FPM -- Infeed rolls consist of (3) top and (2) bottom-powered feed rolls. -- Outfeed with (1) set of top and bottom-powered feed rolls -- Pneumatic pressure to all (4) top feed rolls -- Top rolls with independent pressure adjustment -- All top and bottom feed are driven by a universal joint drive -- Feed rolls are 5-1/2"; diameter TABLE AND FENCE -- 4’ infeed table with (1) driven roller above the tablet -- Table is harden and chromed. -- Fence is harden PRESSURE ELEMENTS -- A pneumatic pressure plate assures stability during slicing -- Precision splitting wedge guide for saw kerf SETUP FEATURES -- Mechanical digital read-outs -- Mobile jog box for ease of setting up -- Central lubrication system for spindles -- Oil pump to remove the resin from table -- Each table has (2) holes for lubrication ELECTRICAL -- Operating voltage 230.460/575/600-volt, 60-cycle, 3-phase -- All “name brand"; electric components. -- Operating panel separate from motor control cabinet for ease of operation MISCELLANEOUS -- Machine cover/hood with a lamp for ease of set up -- Includes a toolbox and operator’s manual

CAM-WOOD TRS-340 M2 Gang Rip Saw With (2) Moveable Blades:Capacity: -- Depth of cut with 14"; dia. blades: 4"; at movable blades, 4.3"; at fixed blades -- Depth of cut with 12"; dia. blades: 2.95"; at movable blades, 3.34"; at fixed blades -- Depth of cut with short stock holddown and 14"; dia. blades: 3.14"; -- Depth of cut with short stock holddown and 12"; dia. blades: 2.36"; -- Max. rip width cap. 13.4"; -- Max material width, 25.6"; -- Min. rip length, 22"; -- Min rip length with short stock holddown, 15.8";Other Specifications: -- Max. sawblade dia., 14"; -- Min. sawblade dia., 12"; -- Sawblade bore, 90 mm (3.54";) -- Saw arbor dia., 70 mm (2.75";) -- Arbor motor, 50 HP -- Arbor speed, 3,800 RPM with 50 or 60 HP motors -- Feed speed from 20 to 135 FPM -- Feed motor by 3 HP VFD -- Overhead pressure roll raise & lower motor, 1/2 HP -- Dust collection; (2) 8"; diameter -- Overall dims., 62"; wide x 88"; long x 72"; high x 5,000 Lbs Features: -- Machine combines edging, selective, and gang rip functions -- Control Panel can be located for easy access -- Edges of random width boards can be trimmed in a single pass -- The positions of the movable saw blades are accurately controlled from the control panel for fast and convenient sets. -- Saw blade movement is driven through precision ball screws along a linear slideway for accurate, effortless traverse -- Exclusive laser projection system ensures accuracy -- Digital display for saw blade traverse; readouts in inch and metric displays are switchable -- Pressure rolls are supported on both sides and hold stock firmly and evenly -- Overhead pressure roll mechanism includes powered raise and lower -- Variable feed speed permits effortless ripping of a variety of stock; hard or soft, thick, or thin -- Double top and single bottom anti-kickback fingers, plus a side guard, provide excellent safety for the operator. -- Stepping motors drive precision ball screws for fast and accurate width settings. -- Same as above. f equipped with optional shifting fence and includes a digital display to accurately indicate fence travel -- Suspension of pressure plate from two sides helps prevent split or broken parts from damaging the saw arbor or saw blades -- Saw blade's movements are concentric for perfect rip accuracy and parallelism of ripped boards. Comes standard with: -- (3) 15 Mw Laser -- (2) Fixed saw seats -- (3) 12" Carbide Tipped SawbladesOptional: --TRS-FTAO-3: Automated In-Feed Table, 3 Meter Powered Conveyor System with Movable Fence, Shifting Laser Lights for 2-Moveable Blades for Rip Width Settings, and Digital Display, -- TRS-FTMU-3: 3 Meter Powered In-feed Table, Manual,

CAM-WOOD TRS-350X Heavy-Duty Dip Chain Gang Ripsaw75 HP! ... plenty of power for those with a lot of ripping work!Specifications: -- Maximum cutting width, 13-3/4"; -- Maximum depth of cut, 5-1/4"; -- Distance from column to first blade, 15"; -- Minimum working length, 25"; -- Maximum blade diameter, 16"; -- Minimum blade diameter, 10"; -- Sawblade bore, 2.756"; -- Saw arbor diameter, 2.165"; -- Saw arbor speed, 3,000 RPM -- Saw arbor motor, 75 HPFeatures: -- Variable feed speeds, 25 to 100 FPM -- Feed motor, 2 HP -- Roller holddown elevation motor, 1/2 HP -- Table working area 72"; x 31";Shipping dimensions, 84"; x 71"; x 68"; x 6,000 Lbs
