Woodworking Equipment For Sale

Northfield #4 Table Saw - In great working condition - Size: 4 - Serial: 62354 B - Northfield Special Heavy-Duty Motor: - Type: Arbor - HP: 7.5 - RPM: 3450 - Phase: 3 - Cycles: 60 - Code: L - Frame: J58 - Enclosure: TEFC - Winding: R & M - Serial: MS92250LV - Temp Rise: 55°C - Volts: 220 / 440 - Full Load Amps: 21 / 10.5 - Size information: - 1390 lbs. - 44" L x 36" W x 44" H - Weight & measurements are not inclusive of pallet (not shipping info) Call 800-459-2148 for more info.

NORTHTECH - 24-HCVS-XL, ...Helical Head Planer24" Width capacity; handles up to 7" thickness. -- 10 HP V-belted cutterhead motor; equipped with: 3" Spiral Cutterhead with (6) rows of (24) 15 x15 x 2.5 mm insert knives (144 total knives). -- 1 HP Feed motor; variable feed speed: 0 - 60 FPM. -- Sectional infeed roller; sectional chip breaker.1/8" Min. stock thickness; 4" min. stock length butted; 13" min. stock length not butted; 1/4" max. depth of cut; 21" x 27" powered table with digital position controller.Complete with: Magnetic motor controls and shavings hood.

NORTHTECH NT 1000-50HCVS Single-Sided 40" PlanerSpecifications: -- 40" Planer, 40 HP main motor, Helical Head, Adjustable bed rollers 15 mm x 15 mm x 2.5 mm Carbide Insert cutters. -- The spiral cutterhead provides a high chip removal rate, superior surface finish and low noise. -- Powerful 40 HP cutterhead motor makes this planer ideal for heavy-duty planing and meets high production requirements. -- Variable feed speed is mechanical variable from 0 - 90 FPM. -- Power elevation of the feed bed with "727 M Digital Table Adjustment" for fast accurate, and convenient thickness setting. -- Extra heavy rib reinforced cast iron table, surface precision ground. Equipped with: -- (4) Powered steel bed rollers. -- (4) Upper rollers. -- (2) Powered corrugated infeed rollers. -- (2) Powered urethane outfeed rollers. -- Upper and lower limit switches for opening control. -- (4) Dual 50 mm jack screws for raise/lower bed movement; 12" max opening. -- 2 HP Elevation motor with manual adjust. -- Rear E-Stop for added safety. -- Dual 6" dust ports requiring 1,000 CFM @ points of extraction.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5z NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER 2-Head wide belt sanding machine with 37" capacity. - Heads: 1st head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. 2nd head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. Two (2) infeed and outfeed spring loaded hold-down rollers; 2 HP variable speed feed drive. Sanding belt size: 37" X 85" and with electronic belt tracking. Motorized opening between the conveyor and sanding bed. Ammeters for measuring motor loads.

Northtech NTM-660M-20HCVS Planer 24" capacity

Northtech NT SLR-16SC Precision 16″ Straight Line Rip Saw FEED SYSTEM --Saw motor: 15HP, 3PH 230/460V -- Feed: 1.5HP variable from 40′ – 120′ FPMPRODUCT DIMENSIONS -- Min. thickness: 3/16″ -- Max depth of cut: 4-1/16″ with 16"; Blade -- Max depth of cut: 3-1/16"; with 14"; BladeSpecifications: -- Direct Drive = Direct Drive -- Feed Hp. = 1.5 Hp. -- Feed System = 4"; Split Chain with True Trac -- Feed Speed = 40-120 FPM -- Assisted Start = Wye Delt"; -- Throat Capacity = 18-1/4"; -- Min. Length = 12"; 2nd Roller to Kickback -- Min. Thickness = 3/16″ -- Max. Thickness = 4-1/16"; W/ 16"; BladeGlue Line Rip = Guaranteed 12′ 4/4 stock @ 50 FPMEquipped with & Features -- Blade Size = 14"; Tungsten Carbide Tipped -- Dust Collection = 1417 Total CFM -- Dust Port Out = 4"; Top 6"; Bottom -- Arbor Diameter = 2″ Arbor -- Idle Rollers = (8) Idle Rollers -- Hold Down Style = 8 Spring Loaded Hold Downs -- Kickback Finger = (59) Lower (32) Top -- Automatic Mechanical Oiler -- Low Oil Warning = Low Oil Shut-off -- Laser = 100mw Laser Light & Mount Bracket

NORTHTECH NT-6108ES-6 Edge SanderSpecifications: Sanding Belt is powered by a 3 HP 230/460V motor. -- The platen measures 6-3/4″ X 39″ and has NEW graphite. Rubber covered direct drive pulley. -- Equipped with: (1) 7-3/4" x 37" Adjustable side table and (1) 11-1/2" x 19" Adjustable end table; both side & end tables have vertical table travel w/hand wheel adjustment. Complete with: -- Magnetic controls with overload protection & dust hood with 4" dia. outlet.

NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER2-Head wide belt sanding machine with 37" capacity. - First head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. -- Second head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. -- Two (2) infeed and outfeed spring loaded holddown rollers; 2 HP variable speed feed drive. -- Sanding belt size: 37" X 85" and with electronic belt tracking. -- Motorized opening between conveyor and sanding bed. -- Ammeters for measuring motor loads. -- Includes spare abrasive belts.

NORTHTECH - NT-KL-920-PRR- B & NT-KL-920 PRR-U, ...Top & Bottom 3-Head Planer Sander3-Head bottom with: Planer, drum and platen; 3-head top with: Planer, drum, and platen 920 mm (36") wide.Capacity: 36" x 5" thickness.SpecificationsBottom Machine Model: "NT-KL-920 PPR". -- Infeed driven Conveyor: 37" x 72" Long. -- 1st Head: Spiral cutterhead; (8) rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 175 mm (7") Dia. and 50 HP motor. Segmented chip breaker before the cutterhead. -- 2nd Head: Contact roller; (280 mm) 11" in dia.; 70 durometers, powered by a 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head: 3-1/4" Pneumatic Polishing Platen; engineered as a combination station, air-cushioned & adjustable in pressure to various grits and materials application. Powered by a 30 HP motor. -- Lifting & lowering conveyor bed; 1-1/2 HP motor (includes auto. thickness setup device). -- Variable speed: 7.5 HP; inverter duty motor integrated with an AC inverter (VFD); control providing variable feed rate from 15 - 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control for: Conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads.Top Machine Model: NT-KL-920 PRR-U -- 1st Head - Spiral Cutterhead: (8) Rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 7" (175 mm) Dia.; 50 HP motor.Segmented Chip Breaker: Before the cutterhead. -- 2nd Head - Contact Roller: 11" (280 mm) Dia.; 70 durometers; powered by 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head - 3-1/4" Pneumatic Polishing Platen: Engineered as combination station; air-cushioned & adjustable in pressure to various grits and materials application; powered by 30 HP motor. -- Lifting & lowering Conveyor Bed: Motor 1.5 HP (includes auto. thickness setup device). -- Variable speed 7.5 HP inverter duty motor; integrated with AC inverter (VFD) control; variable feed rate: 15 to 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control: For conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads. -- Powered dropdown Conveyor between Bottom & Top machine.Features (includes both machines) -- Massive monoblock base: 3/4" Thick plate steel weldments. -- Large dia. roller hold-downs; ball bearing supported; 65 duro UV rubber are standard features. -- Automatic soft start of main motors (Y-Delta). -- Disc braking/emergency shut down protection for: Sanding belt breaking, non-tensioned sanding belt; and mistracking of sand belt. -- All motors & electrics are CE-approved. -- Electronic oscillating belt tracking system. -- Au

NORTHTECH NT-610EL Top & Bottom Planer:24" Wide x 7.5" thick capacity; 1/4" minimum thickness; 12" minimum stock length.Specifications: -- Cutterheads: 25 HP top head; 20 HP bottom head; 5,800 RPM on cutterheads; (6) row spiral insert cutterheads, Carbide knives 15 mm x 15 mm x 2.5 mm 4-sided -- Feed works: 3 HP variable speed feed with speeds from 20 to 75 FPM; 1 HP motorized raise and lower of bed; DP-525 digital thickness controller; Overhead carpet style feed system Equipped with & Features -- Sectional chip breaker; Hard chrome plated bed; Automatic lubrication for feed system; Amp load meter -- Dust Requirements: 3,800 CFM; (1)10" and (1) 7" dust outlet Seller states this machine has less than 600 Hours of use.

NORTHTECH NT 400EL Double Head 16" PlanerHeavy Duty Chain Drive Series Double SurfacerSpecifications: --15 HP Top, 15 HP Bottom Head Motor -- Dual (6) Row Helical Cutterhead with four sided 15 x 15 x 2.5 mm Inserts -- 5,175 RPM solid steel cutterheads with Class 7 NSK bearings -- Cutterhead dimensions: 5"; dia. x 16"; long -- Operating decibel rating of 79 dbProduct Dimensions: -- Working thickness 10 - 155 mm (3/8"; - 6-1/2";) 8 mm min. on request -- 13"; Min. working length -- 16"; Maximum widthFeed System: -- 3 HP Feed motor -- Carpet feeding spike system with (644) spikes -- Feed speed 25 - 85 FPMFeatures: -- 1 HP Elevation motor -- Mechanical variable speed -- Digital control panel with 3 amp meters -- Chrome bed plate 0.01mm (0.004";) thick -- Passline at 32"; -- Amperage requirement: 230V / 115 AMPS, -- (2) 6"; Dust ports requiring 981 CFM @ each point of extraction -- Automatic lubricating system with low level shut off -- UL/CE Certified electrical components -- Includes operator’s manual and parts book -- Net weight: 5,990 Lbs -- Machine / Packed weight: 5,990 Lbs / 6,195 Lbs -- Machine/Packed dimensions (L x W x H): 98"; x 50"; x 70"; / 101"; x 46"; x 80"; -- One year parts warrantyNOTE: All machines are tested stateside prior to shipment providing trouble-free start-up.

Northtech NT 16R-10 Tilting Arbor Table Saw Infeed Roller 10 HP Motor

Northtech MRS-12N Gang Rip 50 HP Motor Needs a new safety with on the door

NORTHTECH - NT-SL2000XL, ...Straight Line Rip SawSpecifications: -- 20 HP Direct Drive Straight Line Rip Saw. -- 2" Arbor. -- Distance from column to blade: 18 in. -- Saw blade size: 10" - 14". -- 3-1/8" Cutting capacity. -- Glue Line Saw. -- Feed Motor: 1.5 HP. -- Feed Speed: 20 - 105 FPM.

Rigid one piece welded steel frame, with 10 HP direct drive spindle motor at 7,800 RPM, 1-1/4" x 4-1/2" stackable multi-cutter spindle to mill stile, rail & raised panel profiles. -- Stackable cutter spindle with push button indexing to significantly reduce set-up time as each station is preset; the change from one cutter to another is achieved via a select switch for each operation. -- Complete with: X - Y Sliding table w/pneumatic holddown. -- 2-way linear movement for straight or arch top doors up to 50" long. -- 5" Dust collection hood, and cutter shield. -- Includes: (1) Cathedral arch templates, (1) complete set of tools.

6” x 24” capacity 2 sided knives on helical cutter head 534 hours in meter

NorthTech 18" Pop-Up Saw. 10hp Motor. #00872

Northteck MRS-14-DXL 460v Manufacturer notes: This is a very popular machine and cost effective. New open ended design allows for you to cut wide material up to 27-1/8? wide. Plus spare arbors, lasers, and the optional quick locking, easy to adjust infeed will not break the bank. The Northtech heavy-duty 50 HP multi-rip (“gang-rip”) saw with 15? maximum blade diameter quickly and accurately cuts material up to 4-15/16? thick and 27-1/8” wide. Cutting both sides of your blanks at once provides incredible parallelism, reducing required moulder allowance, and increasing your yield. Laser guides (one included) and an optional 103” fence make proper alignment of even the longest material simple and precise. Variable feed speeds of 25 – 120 FPM and powered height adjustment further improve operator efficiency.

Northtech Machine NT-GRS-300RF Gang Rip Saw REDUCED Roller feed Max depth of cut is 4". Max width is 12". New Saw Blades And Spacers

Northtech Chop Saw
