Woodworking Equipment For Sale

BALESTRINI IDEA 1 5-Axis CNC Router:Specifications:The Balestrini Idea is a compact, high-performance 5-axis CNC machining center engineered by the SCM Group. It is specifically designed for solid wood element manufacturers who produce highly complex, curved components typical of interior and exterior furniture, chairs, tables, and design accessories.The key features, advantages, and technical configurations of the Balestrini Idea include:• Ultra-Compact Footprint: Marketed as one of the smallest machines in its category, it requires an operating area of just 13.5 square meters. Its reduced dimensions mean it can often be shipped without full disassembly, yet it does not sacrifice the ability to process large workpieces. • Fixed Gantry Structure: Built on a heavy, single-piece machine bed with a rigid fixed gantry architecture, ensuring high precision and structural stability during aggressive multi-axis movements. • High Processing Speed & Versatile Machining Heads:• Revolver Machining Unit: It can be configured with a 5-axis revolver head unit keeping all necessary tools ready-to-use, drastically eliminating tool-change downtime and accelerating cycle speeds.• Single-Spindle (LI11) Unit: Alternatively, it can be equipped with a single heavy-duty electrospindle designed for complex geometries and high-volume material removal.• Modular Worktables: Features highly flexible bar-style or aluminum multifunction worktables. The tables can be integrated with customized clamping systems, suction cups, or specialized pneumatic jigs to securely lock irregular, curved, or uniquely shaped wood elements.• Pendulum Cycle Operation: Available with one or two independent mobile worktables, allowing operators to run "pendulum machining"—loading or unloading parts on one table while the spindle continuously works on the other. • Advanced Control and Software: Equipped with SCM's eye-M 21.5-inch touchscreen console running Maestro active CNC human-machine interface software. It is further supported by Smart Pro CAD/CAM software, which simplifies 5-axis programming by automating path optimization and offering complete virtual simulations. • Operator Safety: Designed with a protective enclosure featuring vertical sliding doors that grant immediate, safe access for part setups while keeping dust and debris fully contained. Common Applications• The Balestrini Idea series is widely used in high-end woodworking sectors, notably for: Chair legs, armrests, and backrestsCurved table frames and solid wood furniture components. Complex, multi-angled joinery and architectural elements.

BALESTRINI - 2 TAO: Round End TenonerTwin positioning tables with: Traversing single cutterhead design; fully automatic work cycleTables alternate into cutting cycle for continuous operation. -- Each table: Laterally positioned automatically; rotational movement of cutterhead is easily adjusted by changing mechanical copy attachment.Specifications -- Belt driven cutterhead; 4 HP - 9,000 RPM spindle motor; 1 HP positioning motor; straight, simple or compound angles are easily adjusted with tables. -- (2) 14" x 9" Tables tilt 0° - 20°, each table with: Pivoting fences; vertical height adjustment; overhead pneumatic holddowns. -- Capacity: Max. width of tenon: 0" - 3-15/16"; Max. thickness of tenon: 1/8" - 1-3/16"; Max. depth of tenon: 1/4" - 3-1/8".

BALESTRINI PICO Round End Tenoner;Produces straight, simple or compound angle round end tenons, for blind tenons.Left & right twin tables allow for (1) part to be tenoned while other table is unloaded and loaded, approx. (600 to 700) per hour.Features: -- 14" x 9" (355 x 230 mm) Tables tilt 0° - 20°, table fence swivels up to 45°, 4-3/4" (120 mm) vertical table adjustment, (2) vertical pneumatic holddowns. -- 4 HP Cutter block motor, 1 HP cutter block rotation motor, 9,000 RPM spindle speed, movement of table with 0.75 HP motor. Capacity: -- 3-15/16" (100 mm) Max. tenon length, 1-3/16" (30 mm) max. thickness, and 1-31/32" (50 mm) max. depth; can also produce round end dowles. -- Hourly production rate of (600 - 700) tenons.This machine must be sold as a set with the Mortiser; please see "MO-010505"

BALESTRINI MINI C 2500 DOUBLE SIDED TEMPLATE PROFILE SHAPERSpecifications: -- (2) Offset shaping heads with 10 HP (7.5 kW), 230/460 volt three phase drives. (1 each side) -- Maximum reciprocating length 98" (2500 mm). -- Maximum height 7" (180 mm). -- Maximum width between spindles 8", and shaping heads are staggered for full end rounding. -- 1¼"; Diameter work arbors with 7″ under the nut capacity, and Spindle speed of 8400 RPM -- Hydraulic stroke of 9-3/4″ wide x 110″ long tee slotted work table, with feed speeds of 3 - 49 feet per minute (1-15 m/Min.) powered by 3 HP, 230/460 volt three phase hydraulic pump -- Overhead beam clamp bar with (4) adjustable clamps. -- Push button operator control station.

BALESTRINI MICRON ... Oscillating Slot Mortiser with Twin TablesAutomatically mortises or bores round holes in chairs, frames or case good parts; features (2) Tables eliminating dead cycle time; produces approx. (400 - 500) mortises/Hr..Specifications: -- Twin tables, tiltable 0° - 20°, vertical adjustment 0 - 100 mm (0 - 4"). -- (2) Vertical pneumatic holddowns, (1) for each side. -- Motors: Cutting spindle motor 3 HP - 9,000 RPM spindle speed, oscillating movement motor 1 HP with (50 - 350) Osc./Min. -- Mortise length is 120 mm (4.72"). -- Mortise depth max. of 80 mm (3.14"). -- Max. cutting bit dia. is 20 mm (0.78"). -- Max. mortise angle is 20°.Note from the seller : We have two of these machines, one is 220V and the other is 440V. Both are in very good condition

BALESTRINI - NOVA 3: Double End/Round End Tenoner Automatic double round End Tenoner -- Max. length capacity: 1,950 mm (76 3/4"); min. length cap.: 240 mm (9-1/2"). -- Tenon width: Up to 80 mm (3-1/8") + thickness; thickness up to: 30 mm (1-1/8"); tenon depth range: 15 - 30 mm (9/16" - 1-1/8"); 9,000 RPM cutterhead speeds through high-speed frequency changer.Machine equipped with: -- 9 kW Total connected power; free-standing control console; automatic cycling. -- Produces up to: 1,200 Double ended tenons per hour. -- Some used tooling included.

Barberan UV Oven

Barr Mullin Wondersaw Optimizer with Computerized Laser Controls Tichniess: Up to 3" Width: 31" Min cut: 4" Feed height: 34-1/2" Floor Space: Apprx 21' x 15' 480 volt

30" Planer÷Model S-290÷3 Phase÷Planer is in excellent condition. The planer was refurbished a few years prior to us purchasing in 2020 and is still fully functional.

BAXTER WHITNEY S-290 36" W x 8" Thick Single-Sided Planer, with Helical Cutterhead & SharpenerSpecifications: -- Planing thickness 1/16" - 8". -- Min. stock length: 3" Butted & 14" Not butted. -- Variable feed speeds 30 - 90 FPM. Equipped with: -- Helical Cutterhead, with 40 HP - 3,510 RPM - 230/460 V Motor. -- Sectional chipbreaker. -- Sectional infeed roller. -- 3 HP - 1,755 RPM - 230/460 V Feed motor. -- (2) Powered table rollers. -- Motorized raise-and-lower of table.Complete with: -- Sharpener.

Becker VTLF 250 SK Vacuum Pump: 9.3 kW (12 HP) Oil-less (Dry) Rotary Vane Vacuum Pump System, 176 CFM, max. 25"Hg; Heavy Duty construction, compact design, small foot print. -- 100% Oil-less vacuum pump is virtually maintenance-free with built-in carbon vanes & built-in suction filters, vacuum regulating valve, secondary suction for additional cooling, blow off valve/silencer; 2-1/2" BSP x 2" NPT nipple coupled to a TEFC; 190-255/330/440V, 1,160 RPM motorNote (2) unit available and the price is for each

BECKER - VTLF 2.250: Vacuum Pump (Oil free Vane)Specifications -- (1) 7.5 kW (10 HP) Oilless (Dry) Rotary Vane Vacuum Pump System. -- Pump has: 169 CFM Total; 338 CFM max.; 25"Hg; Heavy-Duty construction; compact design; small footprint. -- 100% Oilless Vacuum Pump virtually maintenance-free with: Built-in carbon vanes & built-in suction filters; vacuum regulating valve; secondary suction for additional cooling; blow off valve/silencer. -- 2-1/2" BSP x 2" NPT Nipple coupled to a TFC; 1,150 RPM motor.

BECKER - KVT 2.100: 3.6 kW (5 HP) Oil-less (Dry) Rotary Vane Vacuum Pump System, rated at 69 CFM and 100 cm/Hr with max. 27"Hg: Heavy Duty construction, compact design, small footprint. -- 100% Oilless Vacuum Pump virtually maintenance-free with: Built-in carbon vanes; built-in suction filters; vacuum regulating valve; secondary suction for additional cooling; blowoff valve/silencer. -- Complete with: Vacuum Pump stand; double inlet vacuum Air Filter System.

BECKER - KVT 3.100: 3.6 kW (5 HP) Vacuum PumpOilless (Dry) Rotary Vane Vacuum Pump System rated at: 69 CFM & 100 cm/Hr with max. 27"Hg; Heavy-Duty construction; compact design; small footprint. -- 100% Oilless Vacuum Pump: Virtually maintenance-free with built-in carbon vanes & built-in suction filters; vacuum regulating valve; secondary suction for additional cooling, blow off valve/silencer. -- Complete with:Inlet vacuum Air Filter System.

BECKER KVT 3.100 3.6 Kw (5 HP) Vacuum pump:Oil-less (Dry) Rotary Vane Vacuum Pump System, rated at 69 CFM and 100 cm/Hr with max. 27"Hg; Heavy Duty construction, compact design, small footprint. -- 100% Oil-less vacuum pump is virtually maintenance-free with built-in carbon vanes & built-in suction filters, vacuum regulating valve, secondary suction for additional cooling, blow off valve/silencer. -- Complete WithInlet vacuum air filter system.

Becker VTLF 2.500 "HEAVY DUTY" Vacuum Pump: 12.6 kW (17 HP) Oil-less (Dry) Rotary Vane Vacuum Pump System, 336 CFM, max. vacuum 22.1"Hg; Heavy Duty construction, compact design, small footprint. -- 100% Oil-less vacuum pump is virtually maintenance-free with built-in carbon vanes & built-in suction filters, vacuum regulating valve, secondary suction for additional cooling, blow off valve/silencer; 4" BSP x 4" NPT nipple coupled to a 17 HP, 1,180 RPM TEFC motor; shipping weight 1,000 lbs.

BENCHMARK 205-HP3 Hot Melt Adhesive ApplicatorHot Melt Adhesive Applicator with: -- Bodine adjustable speed motor. -- Bead dispensing applicator. -- Also includes an extra Bodine adjustable speed motor regulator, for fine tuned glue application.

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". Cell Configuration for sheets moving from the RH side to LH side of the line.The loading section is on the RH side, the offloading on the LH side from the operator standpoint. -- Working Capacity: "X" Axis 123 (3,130 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors. All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing". Automatic NC controlled zoning of the vacuum table with (16) individual zones. (2) Pneumatic "side" pop-up reference stops, (1) pneumatic "back" pop-up reference stop, & (1) pneumatic "front" pop-up reference stop. Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis. (6) Independent Horizontal Spindles with (4+4) in "X" axis & (2+2) in "Y" axis. (1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 24,000 RPM. (1) 8-position ATC tool changer plate located at the back of the machine base. NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE BH 660 + BiesseWORKS + BiesseNest + Windows XP/WRT operating system. 17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities. BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros. Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(2) 300 m³/Hr BUSCH Vacuum Pump; Safety mats/devices & fencing; Tool touch-off probe for automatic program update according to the tool length. Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: • (1) NC Controlled infeed Scissor Lift table with vacuum loading; • (1) Rake system; • (1) NC controlled & power

BIESSE - ROVER A 1564 G FT: "GANTRY"5' x 21' "Matrix" Grid phenolic surface for: Nested Base Manufacturing.Working Cap."X" Axis: 251.9" (6,400 mm); "Y" axis: 62.4" (1,585 mm); "Z" axis stroke: 12.7" (324 mm);, max. material thickness: 6.7" (170 mm).Positioning Speed"X" & "Y" Axis: 279 FPM (85 MPM); "Z" axis: 98.4 FPM (30 MPM). - All axes movement: On precision linear guides & ways; controlled by: Digital, brushless AC Servo motors.All motion components maintained by: Automatic lubrication system. "X" & "Y" Axes use: Precision rack & pinion system; "Z" axis uses: Precision ball screws.WorktableFlat table design with: Matrix grid phenolic surface for Nested Base Manufacturing; (2) external pneumatic pop-up reference stops in "Y" axis; (4) pneumatic pop-up reference stops in "X" axis; (2) zone tables with: Automatic NC controlled zoning of each vacuum table. Prepared for (optional): "Quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with: "Quick connect" vacuum outlet for custom vacuum pods & fixtures. Boring Unit(1) 2-1/2 HP (1.7 kW) Motor. Variable speed: up to 6,000 RPM; (10) independent vertical spindles with: (5) In "X" axis; (5) in "Y" axis. (4) Horizontal spindles with: (1 + 1) In "X" axis; (1 + 1) in "Y" axis; (1) "X axis grooving saw with: 120 mm Dia. blade.Machining(1) 16.1 HP (12 kW) Air-cooled HSD electro-spindle with: HSK F63 Adaptor; variable speed from: 1,000 - 24,000 RPM; (1) 16-position ride-along tool changer for "on the fly" ATC; NC controlled presetting for: measurement of the tool length. Operator & Machine ControlPC Front-End with: BIESSE "XP 600" + WINDOWS WRT Operating system. 15" TFT Flat screen monitor; server; full keyboard & mouse: All mounted on a mobile cart; Ethernet connection capabilities.Graphic interface makes full use of the operating methods typical of the Windows Operating System: Assisted graphic editor used to program machining operations; programming & guided creation of parametric macros. Import of CAD and other external software files in: DXF & CID3 format; 3D simulation of the tool path; calculation of machining time; ability to create rotate virtual faces.Complete with:25 HP TRAVAINI Vacuum Pump; safety mats & fencing; Tool Touch Off Probe; automatic lubrication system for: Linear guides; pads; recirculating ball screw; Tele-Service capabilities; Universal Autotransformer for: Voltages between 200 - 600 V 50/60 Hz.Actual Model: BIESSE ROVER A 1564 G FT.

BIESSE LATO 38 Edgebander. --6-Station Edgebander with 8mm (5/16") edgebanding thickness. --Capacity: Min. panel width 85 mm or 50 mm w/250 mm panel length, min. panel length 140 mm, max. panel thickness 45 mm. --Equipped with: -- Auto strip and coil feed magazine with 3 mm PVC guillotine. -- Teflon coated hot melt glue pot, dual digital thermostats, 1 in. diameter glue applicator roller. -- Pressure section w/ (1) large dia. non-stick coated drive roller and (2) pneumatic pressure controlled idle rollers, horizontal adjustment w/ digital indicator. --Workstations: -- Front and rear end trims (0.5 HP motors), motors travel on 45° slides and tilt 0 - 12° on a horizontal plane. -- Top and bottom rough trim (0.73 HP motors), motors tilt 0 - 30°. --Top and bottom fine/bevel/profile trims (0.73 HP motors), motors tilt 0 - 30°, cutters for 10° bevel and 3 mm PVC radius round, digital readouts for setup (w/ quick change motors for tool change). -- Top and bottom scrapers for 3 mm thick PVC banding, pneumatic pressure control for scraping knives, digital readout for horizontal adjustments. -- Top and bottom hot air blowers. -- Top and bottom buffing (0.5 HP motors), units tilt 0 - 30°. -- Feed chain "anti-slip" 80 mm wide rubber pads, feed speed 33 FPMand with a 2 HP feed drive.
