Woodworking Equipment For Sale

Machine Equipped as follows: NC 410 PC Based Controller Keyboard with Floppy Drive Automatic Strip Feed Magazine Belt Driven Top Pressure Beam Multi-Coiled Infeed Magazine RT63 Pre-Milling Unit SP20 Glue System w/ Pre-Melt Unit Hot Air Gluing system Automatic Infeed Pressure System T45 Front & Rear End Trimming Units w/Tilt RS10 Top & Bottom Rough Trimming Units RF30 Top & Bottom Fine Trimming Units AR10 4 Motor Corner Rounding Trimming Units RB30 Top & Bottom Profile Scraping Units RC10 Top & Bottom Glue Scraping Units SZ30 Top & Bottom Oscillating Buffing Units PH10 Top & Bottom Edge Heaters Specifications: Min. Panel Thickness:....................10mm? Max. Panel Thickness:....................60mm? Height of Edge-Band Material:…..15-65mm? Min. Banding Thickness:.................0.3mm ? Max. Banding Thickness:........ ...... 20mm? Min. Panel Length:...........................150mm? Min. Panel Width:............................ 100mm? Feed Speeds:.................................10-24m./min? Electrics: ......................................... 460-480V 3 Phase

Biesse Akron 440 Edgebander Premill Top & Bottom Trim Corner Round Edge Scrape Glue Scrape Buffing Unit 12-18 m/min Feed Speed All work units are servo controlled

BIESSE - ROVER K 1532: CNC Machining Center (ATC & Boring) -- Specifications:"BRIDGE GANTRY" Machine with: Working field in "X" axis 126" (3,200 mm); "Y" axis 61" (1,560 mm); max. material thickness 6" (165 mm). -- Positioning Speed:"X" Axis 279 FPM (85 MPM); "Y" Axis 196 FPM (60 MPM);"Z" axis 65 FPM (20 MPM). -- Worktable(6) "ATS" Panels supports with: (4) Lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with: (6) Pneumatic back & center stops; (4) pneumatic side stops; (2) LH & (2) R. with (12) removable nylon clamping units for narrow pieces. -- Boring Unit:4 HP (3 kW) Motor with: Variable speed from: 2,800 - 6,000 RPM."BL 30" Boring head with: (20) "Quick Change" independent vertical spindles; (9) spindles in "X" axis; (11) spindles in "Y" axis.(8) Horizontal boring spindles with: (2 + 2) in "X"'; (2 + 2) in "Y" axis.(2) Grooving Saws: (1) In "X" axis; (1) in "Y" axis for max. 120 mm dia. blade. -- Machining(1) 17.7 HP (13.2 kW) Electrospindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM.Motorized dust deflector shield with: 6-Position adjustable dust suction hood; blowing unit.NOTE: NC Controlled C-Axis for 360° horizontal processing is not installed but CAN BE ADDED. - Per spec sheet on Dropbox folder: "“Prearrangement for the assembly of a 360° operating unit (C axis). It includes all the harness for the electric cabinet. The slot is to be specified. It allows reducing machine downtime for the installation of this unit on an already delivered machine";. (1) 16-Position ATC tool plate mounted on board the "X" axis at the "X" axis carriage (rear of the machine base). -- Operator Interface:PC Front-End with: BIESSE "BH 660" + BIESSE "bSolid" + Windows "7 WRT" Operating System.21-1/2" Flat screen monitor; full standard keyboard & mouse; 8 GB RAM memory;128 SSD GB hard disk or superior; USB Ports for data entry. Dedicated graphics card; Ethernet connection to an office PC with specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioned & dust free environment control cabinet. -- BIESSE "bSolid" is a 2D/3D CAD/CAM software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the Operator to visualize the piece prior to processing; it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; handheld "Remote Control" pendant for immediate Operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Centralized Automatic Lubrication System; Scrap Belt conveyor; Tool Per-setting device; Safety fences; s

BIESSE - ROVER 20: CNC Machining Center (w/ATC/Boring)Specifications: -- Working capacity: X-Axis: 2,885 mm (113.58"); Y-Axis: 898 mm (35.35") for boring; 950 mm (37.40") for routing; max. panel thickness: 65 mm (2.56"). -- Positioning speed: X-Axis: 75 MPM (246 FPM); Y-Axis: 45 MPM (147 FPM); Z-Axis: 15 MPM (49 FPM).Equipped with: -- Work area with (2) Working zones: (6) Manually positioned & pneumatically locked panel supports; each with: (2) 6"; x 6-1/4"; Vacuum pods; (6) backstops/clamps; left & right side stops; all pneumatic raised & lowered automatically by start/stop of machining cycle. -- High precision prismatic guides & ground helical rack on X-axis; hardened ground ball screws on Y- & Z-axes. -- Boring Unit: 1.7 kW (2.3 HP) - 5,135 RPM Motor; spindle speed: 4,000 RPM; (10) vertical independently operated spindles with: (6) In X-Axis & (4) in Y-axis; (6) horizontal spindles with: (2 + 2) In X-Axis & (1 + 1) in Y-axis; (1) grooving saw in X-axis with 120 mm (4.72") dia. blade & blade speed 5,200 RPM. -- Machining: HSD "ES 919A" 6.6 kW (8.9 HP) Air-cooled electrospindle with: ISO 30 Adapter; RH & LH rotation; spindle speeds: 1,000 - 24,000 RPM; 4-position side-mounted automatic tool changer magazine; 3-position rear-mounted on-the-fly automatic tool changer (ATC). -- Control: PC Front-End with: 15" Color display; pendant control; (2) foot pedal controls.Complete with: -- BECKER "PICCHIO 2200" Vacuum Pump: 3 kW - 4 HP - 130 mbar.Control Dimensions: 60" x 36" x 77" H.Vacuum Pump Dimensions: 28 x 14 x 24 H.

BIESSE - SKIPPER V31: CNC Machining Center (Vertical) -- Specifications:Flexible "Vertical" Machining Center that can reach movement speeds of :164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis - with total safety. -- Max. workable part size: "X" Axis is 98.4" (2,500 mm); "Y" axis 35.4" (900 mm); max. part thickness 2-3/4" (70 mm). -- Min. workable part size: "X" Axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of .39" (10 mm). -- Boring Unit:(1) Boring block with: "QUICK CHANGE" Spindle system; 4.2 HP (3 kW); variable speed from 1,500 - 7,500 RPM; (10) vertical spindles with: (5) Spindles in "X" axis & (5) Spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) Horizontal spindles in "X" axis & (1 + 1) horizontal spindle in "Y" axis.(1) "X" Axis grooving saw: 9,000 RPM; 120 mm saw blade dia. -- Machining unit:(1) 6 HP (4.5 kW) Electrospindle router with ISO 30 adaptor;variable speed from 1,000 - 20,000 RPM.ISO 30 "QUICK CHANGE" push button Tool Change System. -- Operator & Machine ControlBIESSE XP 600 + "BiesseWORKS Advanced" Operating System.19" TFT Monitor; international keyboard; soft touch keypad; industrial mouse.RS-232 Serial ports; USB ports; (1) CD ROM drive; modem. Ethernet connection; real-time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with:Pneumatic part clamping devices; sound enclosure; lateral grid protection & safety mats; forced autolubrication; air-conditioned control cabinet. -- Actual Model is BIESSE - SKIPPER V31

Biesse Rover B Edge semi automatic pod setting 4 coil magazine vertical and horizontal drill bank main spindle with U axis Milling X1: 5055 mm Y1: 1600 mm Edgebanding X2: 4100 mm Y2: 1600 mm Milling Module H74 - Z1: 245 mm Module H29 - Z2: 290 mm

Capacity overall cutting length 3200 mm (128"). Cutting height 100 mm saw blade projection. 18 HP main and 3.6 HP scoring motor. Modular roller rear machine table. Side aligning device for squaring ripped strips out to 74". Variable saw carriage travel speed 0-328 FPM. 328 FPM return. Electronically controlled overhead program fence. Rack & pinion driven. Forward speed 196 FPM. Return speed 196 FPM. 6 clamps (open up to 100 mm), of which (2) are closely spaced in crosscut area for strip handling and the other (4) are at equal distance in rip cut area. AC Servo motor drives on both saw carriage and pusher fence. "Gateway" PC controller w` monitor and >assist line> w`LED readout integrated into high tech look operator control panel (displays cutting dimensions & patterns). Data input by keyboard or direct downloading from office PC. Side Crosscut aligner. "Quick Change" saw blade replacement system. (3) front mounted air floatation tables with patented rounded front for moving panel from rip to crosscut position (24" x 79" each).

Min. Panel Thickness: 0.39? Max Panel Thickness: 2.36? Height of Edge-Band Material: 0.55-2.51? Min. Banding Thickness: 0.01? Max Banding Thickness: 0.39? Min. Panel Length: 5.51? Min. Panel Width: 1.96? 2 Feed Speeds: 39ft/min & 59ft/min Electrical: 230V, 60Hz, 3Phase Equipped With Siemens TD200

Biesse Akron 1440 PUR Return conveyor available - demo unit!

Biesse Rover C 9.65 CNC Router Vacuum Pumps Still under power for inspection

BIESSE ROVER B 4.35 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working capacity: "X" Axis is 125.9" (3,200 mm) any unit; "Y" axis is 51.7" (1,315 mm); "Z" axis stroke 6.3" (160 mm) max. material thickness is 5.9" (150 mm). -- Positioning Speed:"X" & "Y" Axis is 262 FPM (80 MPM) & "Z" axis is 66 FPM (20 MPM). -- Worktable:(6) Panel support rails with: (3) Vacuum pods per panel support; (4) pneumatic lifting bars for heavy panels.(2) Independent working areas with: (6) Front & (1 + 1) side pneumatic pop-up locating pins for positioning of parts on the worktable.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.3 HP (1.7 kW) - 4,000 RPM Motor: (12) Independent vertical boring spindles with (6) spindles in "X" axis & (6) spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) in "X" Axis & (1 + 1) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia. blade. -- Machining Unit:(1) 10.2 HP (7.5 kW) Vertically mounted HSD "Electrospindle" Router with ISO 30adapter, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM.(1) 10-Position ride-along ATC for "on the fly" tool change. -- Operator & Machine Control:PC Front-End with: BIESSE "XP 600" + "BiesseWORKS Advanced" + Windows "WRT" (Windows Real Time) operating system; INTEL "Celeron" 2.0 GHz processor; 4 GB Hard drive.15" Color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port, USB ports, CD ROM & 1.44 MB disk drives.Separate Control Panel with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment; 11 KVA Stabilized autotransformer for voltages between 200 - 600 Volts. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; centralized manual lubrication system for guides & ball screw; emergency stop rope; safety light barrier & sound absorbing protective head enclosure with debris curtain around bottom edge; scrap belt conveyor. -- Actual model is: BIESSE - ROVER B 4.35.

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.

Biesse Akron 245 Edgebander System is still under power until approx mid-October 2024. Touch PLC will need to be replaced. Everything else is working good on the machine. Owner has had it serviced by Biesse.

Biesse Levia 310-1350 Sander

BIESSE FSE Semi Automatic Dowel Inserter with Boring; 21-Spindle head (spindles on 32 mm centers) fixed horizontally for end boring, -- Equipped with:(8) Glue injectors & dowel inserters,(4) overhead "HD" pneumatic hold-down clamps. -- After the drilling cycle is complete, the head assembly traverses down to the glue & dowel injector line for the glue & dowel injection; quick cycle time. -- PLC function selector control for boring only, inserting only, or boring & inserting. -- Capacity: Handles 8 mm - 10 mm dia., digital indicator for adjustable dowel length from 25 mm - 50 mm, max. boring depth 70 mm. -- Features: Height adjustment w/digital readout for panel thickness, hydraulic brakes for adjustment of boring speed; 2.3 HP - 4,000 RPM motor.Complete with: -- (2) Side fences, front support table w/stop, glue reservoir tank with pressure control & rinsing tank for glue nozzles. -- 4way dowel feeding vibrator, and foot pedal for starting cycle.Note: Only (4) dowel line on the machine, you just need to add more dowel tube

BIESSE AKRON 1440A SINGLE SIDE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + with "AIR FORCE" PUR & EVA (Hot Melt) Gluing Systems: -- Specifications: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm; Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm.Multi-Feed speed 8-12-15 &18 MPM.Glue & Pressure Section: -- Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting glue. Special glue container for PU glue; Additional glue container for EVA gluing unit with melting device.Additionally equipped with the AirForce "VC-710", High pressure, hot air system to reactivate special pre-coated edge material (commonly referred to as laser edge.Automatic edge feed; Cutter knife; Pressure zone with 1-Drive & 2 pressure rollers.Working Units: -- Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; -- Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. Machine Features: -- Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating. The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Auto adjustment of in feed fence. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator & Machine Control: -- Biesse,

BIESSE ROVER 24 FST FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" Grid phenolic surface table for "Nested Base Manufacturing". -- Working Cap.:"X" Axis is 122" (3,100 mm), "Y" axis 49.2" (1,250 mm), and "Z" axis stroke is 9.8" (250 mm); max. material thickness of 6.1" (155 mm). -- Positioning Speed:"X" & "Y" Axis is 328 FPM (100 MPM), Z-axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(14) External pop-up reference pins with: (6) Pins on the front of the table, (4) on the back of the table, (2) on the RH side, (2) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) independent vertical spindles: (7) In "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 2019 - 10.2 HP (7.6 kW) Air-cooled electro-spindle with HSK F63 adaptor; variable speed from 1,000 - 24,000 RPM. -- Operator & Machine Control:PC Front-End with: NC 1000" + WINDOWS "NT" Operating System; 17" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(1) 2014 - BECKER 250 CBM/Hr Vacuum Pump; Universal Autotransformer for voltages between 200 - 600 V, 50/60 Hz.; manuals, documents, safety mats & fencing. -- Actual Model is: BIESSE ROVER 24 FTS.

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". -- Working Capacity: "X" Axis 122 (3,100 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing";Automatic NC controlled zoning of the vacuum table with (9) individual zones.(2) Pneumatic "side" pop-up reference stops, (4) pneumatic "back" pop-up reference stops, & (6) pneumatic "front" pop-up reference stops.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis;(1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 20,000 RPM.(1) 8-position ATC tool changer plate located at the back of the machine base;NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE XP 660 + BiesseWORKS + WINDOWS WRT operating system;17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 900 m³/Hr Vacuum Pump; Safety mats & fencing; Tool touch-off probe for automatic program update according to the tool length;Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: (1) NC Controlled infeed Scissor Lift table with vacuum loading; (1) Rake system; (1) NC controlled & powered belt outfeed table with vacuum sweeping system; (1) Additional NC controlled powered belt outfeed table; Bar code label printer. -- Actual Model is BIESSE ROVER A 2231 G FT

BIESSE ROVER B 4.40 FT FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications:4' x 10' Flat Table with "Matrix" grid phenolic surface for "Nested Base Manufacturing". -- Working cap:"X" Axis 126" (3,200 mm), "Y" axis 53.5" (1,360 mm), "Z" axis stroke is 6.3" (160 mm), max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ball screw on "Y" & "Z" axis. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing", (2) independent working areas; (4) external pop-up reference pins with (3) on the back of the table & (1) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit: (1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (12) independent vertical spindles, (6) in "X" axis & (6) in "Y" axis.(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) 120 mm dia "X" axis grooving saw. -- Machining:(1) 10.2 HP (7.5 kW) Electro-spindle with ISO 30 adaptor, variable speed from 1,000 - 20,000 RPM;(1) 10-Position ride along tool changer for "on the fly" ATC. -- Operator Interface: PC Front End with Biesse "XP600 + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with: Universal Auto-Transformer for voltages between 200-600 V, 50/60 HZ; (2) 10 HP, (7.5 kW) BUSCH Vacuum Pumps; safety mats & fencing. -- Actual Model is BIESSE ROVER B 4.40 FT.

BIESSE SKILL G FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 12' "Matrix" Grid phenolic surface for "Nested Base Manufacturing". -- Working Capacity:"X" Axis 148.2" (3,765 mm); "Y" axis 61.4" (1,560 mm); "Z" axis stroke is 12.7" (324 mm); max. material thickness 4.7" (119 mm). -- Positioning Speed:"X" & "Y" Axis 197 FPM (60 MPM); "Z" axis 65.6 FPM (20 MPM)."X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing".(5) External pneumatic pop-up stops for piece positioning at (4) corners of workstations; automatic NC controlled 8-zone vacuum table.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2-1/2 HP (1.7 kW) Motor; variable speed up to 6,000 RPM; Boring unit with: (10) Independent vertical spindles; (7) in "X" axis & (3) in "Y" axis. -- Machining:(1) 16 HP (12 kW) Air-Cooled "HSD" Electro-spindle with: HSK F63 Adaptor; RH & LH rotation; variable speed from 1,000 - 24,000 RPM.(1) 12-Position ride along tool changer for "on the fly" ATC. NC Controlled tool presetting for the measurement of the tool length -- Operator & Machine Control:PC Front-End with: BIESSE "BH 660" + "BiesseWORKS + "WINDOWS "WRT" (Windows Real Time) Operating System'19" LCD Flat screen monitor; Server; full keyboard & mouse all mounted on a mobile cart.Intel(R) Core i CPU; 8 GB RAM memory; 500 GB (SSHD) hard disk; dedicated graphic card; DVD reader; USB ports; Ethernet card for network connection capabilities. -- Complete with:(1) 300 m³/Hr Vacuum Pump; air-conditioned control cabinet; automatic program update according to the tool length.Automatic Lubrication system for linear guides, pads, and recirculating ball screw; universal autotransformer for voltages between 200 - 600 V, 50 / 60 Hz; teleservice capabilities; perimeter safety mats; manuals & documents on CD. -- Options Include:Prearrangement for a "C" axis at a later date. -- Actual Model is BIESSE SKILL 1536 G FT.
