Woodworking Equipment For Sale

RENZO BORGONOVO - SP 6P, ...6-Gun Spray Machine with 3/4" - 12" width cap.3-1/4" Max, part thickness and 32" min. part length. Standard specifications: -- (6) Gun mounts made from aluminum rods and HDPE mounting brackets, for connections for (6) HVLP automatic spray guns, and (1) dual diaphragm fluid pump. (Guns and Pumps are not included). -- Complete with: Teflon coated recovery cabinet for each spray station and easy rollout feature, front access door with large viewing window & gas shock support arms. -- (2) Paint circuits with (3) spray guns each (guns not included).Features: -- Machine is operated with a central control panel and gun timing is controlled by a PLC that times the spray guns in relation to the length of the work piece and feed speed. -- PLC Records the number of workpieces and total linear feet processed in session. -- The machine is set up with infeed & outfeed conveyors that operate at any speed between 60 and 300 FPM and is made up of Antistatic and Antisolvent belts and intermediate steel rollers between Spray Stations. -- 11.8" Dia., 1.5 HP exhaust fan rated at 4,000 cbm/Hr. -- This Sprayer integrates easily into any line whether as a primary unit or as an intermediate step. -- Overall length is just under 10'.Sprayer will include:qty (1) WAGNER HVLP Zip52 pump $1920.00qty (6) WAGNER HVLP aSP 30 spray guns with 1.2 nozzle $5,616.00Working dimensions: -- Length: Min. 800 mm / max. infinite. -- Width: Min. 15 / 300 mm. -- Height: Min. 15 mm / max. 100 mm. -- Height of worktable: 900 mm. -- Compressed air consumption - NI/min 1,500 – 2,000. Overall size: 3,000 x 2,900 x 2,220 mm and 800 kG (I,750 Lbs).

RENZO BORGONOVO - SP 6P, ...6-Gun Spray Machine with 3/4" - 12" width cap.3-1/4" Max, part thickness and 32" min. part length. Standard specifications: -- (6) Gun mounts made from aluminum rods and HDPE mounting brackets, for connections for (6) HVLP automatic spray guns, and (1) dual diaphragm fluid pump. (Guns and Pumps are not included). -- Complete with: Teflon coated recovery cabinet for each spray station and easy rollout feature, front access door with large viewing window & gas shock support arms. -- (2) Paint circuits with (3) spray guns each (guns not included).Features: -- Machine is operated with a central control panel and gun timing is controlled by a PLC that times the spray guns in relation to the length of the work piece and feed speed. -- PLC Records the number of workpieces and total linear feet processed in session. -- The machine is set up with infeed & outfeed conveyors that operate at any speed between 2- - 100 mpm (65 - 325 FPM) and is made up of Antistatic and Antisolvent belts and intermediate steel rollers between Spray Stations. -- 300mm (11.8" Dia.), 1.5 HP exhaust fan rated at 4,000 cbm/Hr. -- This Sprayer integrates easily into any line whether as a primary unit or as an intermediate step. -- Overall length is just under 10'.The Machine is priced with no guns or supply installed, these will need to be added by the buyer or a separate quote can be requested for guns and supply pumps.Working dimensions: -- Length: Min. 800 mm / max. infinite. -- Width: Min. 15 / 300 mm. -- Height: Min. 15 mm / max. 100 mm. -- Height of worktable: 900 mm. -- Compressed air consumption - NI/min 1,500 – 2,000. Optional: InHand Networks Industrial Router Overall machine dimensions and weight Teleservice module for remote troubleshootingPrice includes the following options: Stainless Steel carriage Teleservice module for remote service.PRICE IS FOB EAST COAST PORT, INLAND FREIGHT WILL BE QUOTED.Overall size: 3,000 x 2,900 x 2,220 mm and 800 kG (I,750 Lbs).

Renzo Borgonova Rope Moulder and Splitter

RENZO BORGONOVO MVS-2500 Automatic Sanding and Buffing MachineFOR LINEAR FRAMES AND PROFILES - Sanding and buffing of frames, rods, ledges and fitting parts of veneer, solid, raw or varnished wood, etc. (processing of 3 sides for each pass). -- Advancing speed electronically variable by inverter: 10 TO 50 M/MIN. -- Total power: kW 10,5 (14 HP) -- Compressed air: Atm 6 -- Total exhaust capacity; m3/h. 2800 (25 m/sec.) -- Working height: mm. 10 min. mm. 100 max. -- Working width: mm. 20 min. mm. 200 max. -- Working length: mm. 1200 min.DISC SANDING UNITS TYPE “SCOTCH BRITE"; (N° 4) -- Power motor: 3 HP (2.2 kW) -- Rotation speed: 1400 RPM -- Disc sanding unit holder shaft diameter: mm. 30 -- Spindle-disc sanding unit connection flange diameter: mm. 76 -- Disc sanding unit diameter: mm. 200 max. -- Disc sanding unit height: mm. 100 max. -- Dust suction hood diameter: mm. 100 -- Extraction rate: m3/h. 700 (25 m/sec.)

Features - Easy to use main controls - Quick access for changing 3 or 5 inch wide rolls of film or adjusting film stretch - Vigor PLC for reliable operation

(2) Rigma Roll Coaters available Model RR-W4CCB 1350 Max capacity

RILESA UNI-X 2200 FEED THUR CNC BORING MACHINE W/4-SIDE DRILLING, in one pass. -- Specifications:Working Capacity; 230 mm - 2,200 mm (9' - 86.6") Length, 20 mm - 250 mm ((0.78" - 9.84" width, 10 mm - 60 mm (0.39" - 2.36") thickness.Capacity: up to 900 parts/hour without cross drilling. -- Features:One-man operated. 4-side drilling, in one pass. With Rilesa UNI-X drilling machine you get precision, quality and extreme high capacity. It is well suited to both small and large dimensions. It has short set up time and minimal maintenance. -- Polyurethane an guides ensure gentle handling of components. The restraining clamp automatically adjust to component width ensuring correct location to the zero point. -- The drilling boxes are designed for high speed drilling, 4500 RPM. The tool inserts can be chosen Between direct or snap assembly. Special drill boxes can be manufactured to specific customer requirements. -- Assembly of drill boxes takes place with a snap function and is simply locked with screw. The drill box can be freely turned between 0 and 90°. In the outer positions there are stops. -- The drill groups unique design gives a high degree of adjustment flexibility. The center distance between groups is 95 mm. Pneumatic over hydraulic drill feed. Drill speed, 4000 RPM. -- The components are fed in pneumatically up to the reference stop and locked securely in this position. A unique safe regulated system makes sure the component is in place without pressmark. -- The operator uses signal lamps to make adjustments. The operator manually moves the drill groups into position checking the lights. Yellow to green = Tolerance. -- The machine closed design with built in dust extraction gives the perfect place to work. Notice the sturdy construction of the machine body. -- Loading of components is very easy by pushing the stack in through the brushes. The machine components are transported gently back to the operator. The conveyer can run continuously or in step mode. -- For long components support elements can easily be added. They are located with a simple clamp and ensure straightening of the workpiece. -- The machine can be delivered with sideways displacement of the drilling group. The drilling group displace up to 100 mm, this function combined with programming of the drilling, do difficult drilling in one passage, possible. -- The control system is integrated in the back of the machine, well protected against dust. There is room for future expansions to be added. -- Hopper / Magazine:Pneumatic magazine with ergonomics and user friendly access. Automatic fixation to the zero point by a pneumatic counter clamp with polyurethane and nylon covering for careful handling of the component. -- Return conveyor with an adjustable catcher tray, build-in clamp cylinder mounted at each end, for flexible and safe clamping of the components, adjustable catcher tray. -- Operator Interface:Advanced 15"; color TFT touch screen control system where

Ritter 3 Spindle Boring Machine

RITTER DR-3553 Profile Sander2 HP TEFC Motor with direct drive spindle which tilts 90° forward & 20° backward.Specifications: -- 400 - 1,800 RPM Inverter controlled variable speed with RPM display. -- 4" Vertical & 8" horizontal spindle adjustment. -- 36" x 33" Solid northern hard maple tabletop and 36" table height. -- 1-1/4" Dia. x 4" long spindle to accept standard sanding discs and profile discs made to customer's specifications. -- Enclosed fabricated steel base. -- Dust hood w/piano hinge for easy ascess to sanding disc. -- Stationary fence and large hand wheels for easy spindle adjustment.

Designed for machining of beaded face frames, cabinet doors and related joint construction. The machine miters all required corners and notches without the need to change a set-up. -- Production time is reduced to seconds with the use of the 6,500 RPM cutterhead capable of machining (2) parts at the same time. -- Standard Features: 7.5 HP spindle drive motor, 40 MM diameter 6500 RPM spindle, 7" maximum cutter head diameter, Adjustable pneumatic cutter head feed stroke, 60" stile & rail alignment fence, 16" material width capacity, (8) quick reference material fence alignment stops (6) quick reference fence offset stops, (4) hold down clamp cylinders. -- 48" wide table with 34" fixed work table height, magnetic controls, foot pedal controlled machining cycle. -- Tooling Options Sold Separately ($4,500): 7/8" Cutter head pattern, 5/16" bead carbide tipped, 1" cutter head pattern, 5/16" bead carbide tipped. Custom pattern heads upon request. -- Additional Options: 72" & 84" alignment fences, additional fence offset stops, additional fence stops. -- 4" diameter dust outlet. Weight: 1,430 lbs. -- This machine is also available with a 5 HP 220V single phase motor at the same price.

RITTER R-20 Double Spindle Shaper:High quality American made fixed spindle Shaper with (2) Spindles. -- Fabricated steel base with precision ground built-in cast iron table. -- Table insert rings to easily accommodate a wide range of cutterhead dia. (4-1/2" max. opening without rings). -- (2) Solid 1-1/4" spindle with lock for easy tool change. -- (2) Spindle speed settings for a variety of size cutter sizes and Spindle reversing switch. -- Standard 3/4" x 3/8" groove in table for miter gauge (not included). -- Large hand wheel for manual spindle height adjustment. -- Micro-adjustable fence that easily adjusts for short runs. -- Large cabinet style door for easy access to motor & quill assembly. -- Self-braking motor and Emergency stop. -- Magnetic starter & thermal overload switch. -- Integrated dust shroud & spindle guard assembly with manual holddown. -- Operations manual, parts list & tool kit.

(2) 3 HP Spindle Driver Motors Wired 3-Phase 240 30" X 48" Work Table Surface

This machine has been cleaned, repaired and checked over, ready for a new home! (2) 3HP motors 460V 3Ph 6 pneumatic stops for use in horizontal or vertical drilling 72" precision machined back fence 6 fence stops, 4 table stops (2) 23-spindle drilling heads, one horizontal, one vertical 3-position turret dept stop on vertical head 5 pneumatic holddowns Magnetic motor controls 32mm spindle centers 10mm collet diameter 1725 RPM spindle speed 90 PSI air requirement 3" max. drill stroke

RITTER R-300 V Door and Panel Clamp6' x 12' Assembly Easel - VerticalStandard Features: -- (10) Universal Clamping Cylinders and Cylinder Manifold. -- Foot Treadle operated. -- (4) Material Hold-Down Dogs. -- (3) Adjustable Material Positioning Stops. -- (2) Squaring Bars on Left and Right Sides. -- 2" Cylinder Position Grid Pattern. -- 3" Bore Clamp Cylinder Housing. -- Perforated Steel Table. -- (12) Port Manifold with 1/4" NPT Regulator/Gage. -- Adjustable pressure from 20 to 130 PSIShipping Dimensions: 151" L x 77" W x 30" HShipping Weight: 1,643 LBSNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R-375 V Door and Panel Clamp4' X 8' Cap., 45 Degree Vertical Assembly Easel.Standard Features: -- (6) Universal Clamping Cylinders & Cylinder Manifold. -- (2) Squaring Bars on Left and Right Sides. -- 2" Cylinder Position Grid Pattern. -- 3" Bore Clamp Cylinder Housing. -- Perforated Steel Table. -- (6) Port Manifold with 1/4" NPT Regulator/Gage. -- Adjustable pressure from 20 to 130 PSI. -- Foot Treadle operated.Shipping Dimensions: 53" X 106" X 30" HShipping Weight: 778 LBSNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

High performance Drill Tub for pocket hole boring. Foot pedal control

High quality American made fixed spindle Shaper. -- Fabricated steel base with precision ground built-in cast iron table. -- Table insert rings to easily accommodate a wide range of cutterhead dia. -- Interchangeable spindle with lock for easy tool change. -- (8) Spindle speed settings for a variety of size cutters. -- Spindle reversing switch as standard. -- Standard 3/4" x 3/8" groove in table for miter gauge (not included). -- Large hand wheel for manual spindle height adjustment. -- Electronic digital height display. -- Micro-adjustable fence that easily adjusts for short runs. -- Large cabinet style door for easy access to motor & quill assembly. -- Self-braking motor. -- Magnetic starter & thermal overload switch. -- Integrated dust shroud & spindle guard assembly with manual holddown. -- Emergency stop. -- Operations manual, parts list & tool kit.

RITTER R-1207P2 Door and Panel ClampSpecifications: -- Table working area: 146"; x 61"; approx. -- Steep pegboard style table. -- Motorized travers top beam of pneumatic down-acting clamps. -- (24) Pneumatic down-acting clamp cylinders. -- 6"; x 6"; clamps pads. -- (2) Position adjustable side pressure clamps. -- 5"; diameter nylon pads. -- 6"; x 6"; nylon pads. -- Clamp is setup in two equal zones. -- Pedestal mounted controls (One left and one for the right zone). -- Side pressure cylinders have approx. 5"; of stroke. -- Top down pressure cylinders have approx.. 4"; of stroke

RITTER R-1475 Raised Panel Door Router SetupSpecifications: -- 36" X 72" Work table area, 24" door width & unlimited door length capacity. Capable of producing a complete raised panel detail in one (1) minute. Routers are guided by the fences or templates attached to the fences.Equipped with: -- (4) 3" Bore AC 20 clamp cylinders; (4) 1-1/2" x 1-1/2" adjustable fences; -- (2) 1.5 HP router motors with dust hoods; (1) 7/8 HP router with dust hood; and (1) 1475-H Heavy Duty 3-1/2 HP Hogging Router w/ cutter & dust hood.Complete with: -- 1475-A Tooling set, template guides; regulator and gauge; and (4) 2-1/2" dia. X 8' long flexible dust collection hoses.

RITTER R-200 E/A Face Frame Assembly Easel Dimensions 5' x 12' with 45° Bed angle;Specifications: -- Hold-down beam with (5) adjustable hold down cylinders. -- Squaring bars on left, right and bottom sides. -- 1" Thick laminated surfaced table. -- Heavy duty steel frame. -- (1) Coil-hose for pneumatic screw gun (screw gun not included). -- Air pressure required 100 PSI. -- Footprint: 165"l x 48" D.Shipping dimensions: 68" x 169" x 30" H. Shipping weight 1,250 Lbs.NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.
