Equipment For Sale

NORTHTECH NT 400EL Double Head 16" PlanerHeavy Duty Chain Drive Series Double SurfacerSpecifications: --15 HP Top, 15 HP Bottom Head Motor -- Dual (6) Row Helical Cutterhead with four sided 15 x 15 x 2.5 mm Inserts -- 5,175 RPM solid steel cutterheads with Class 7 NSK bearings -- Cutterhead dimensions: 5"; dia. x 16"; long -- Operating decibel rating of 79 dbProduct Dimensions: -- Working thickness 10 - 155 mm (3/8"; - 6-1/2";) 8 mm min. on request -- 13"; Min. working length -- 16"; Maximum widthFeed System: -- 3 HP Feed motor -- Carpet feeding spike system with (644) spikes -- Feed speed 25 - 85 FPMFeatures: -- 1 HP Elevation motor -- Mechanical variable speed -- Digital control panel with 3 amp meters -- Chrome bed plate 0.01mm (0.004";) thick -- Passline at 32"; -- Amperage requirement: 230V / 115 AMPS, -- (2) 6"; Dust ports requiring 981 CFM @ each point of extraction -- Automatic lubricating system with low level shut off -- UL/CE Certified electrical components -- Includes operator’s manual and parts book -- Net weight: 5,990 Lbs -- Machine / Packed weight: 5,990 Lbs / 6,195 Lbs -- Machine/Packed dimensions (L x W x H): 98"; x 50"; x 70"; / 101"; x 46"; x 80"; -- One year parts warrantyNOTE: All machines are tested stateside prior to shipment providing trouble-free start-up.

NORTHTECH NT-6108ES-6 Edge SanderSpecifications: Sanding Belt is powered by a 3 HP 230/460V motor. -- The platen measures 6-3/4″ X 39″ and has NEW graphite. Rubber covered direct drive pulley. -- Equipped with: (1) 7-3/4" x 37" Adjustable side table and (1) 11-1/2" x 19" Adjustable end table; both side & end tables have vertical table travel w/hand wheel adjustment. Complete with: -- Magnetic controls with overload protection & dust hood with 4" dia. outlet.

NORTHTECH NT-610EL Top & Bottom Planer:24" Wide x 7.5" thick capacity; 1/4" minimum thickness; 12" minimum stock length.Specifications: -- Cutterheads: 25 HP top head; 20 HP bottom head; 5,800 RPM on cutterheads; (6) row spiral insert cutterheads, Carbide knives 15 mm x 15 mm x 2.5 mm 4-sided -- Feed works: 3 HP variable speed feed with speeds from 20 to 75 FPM; 1 HP motorized raise and lower of bed; DP-525 digital thickness controller; Overhead carpet style feed system Equipped with & Features -- Sectional chip breaker; Hard chrome plated bed; Automatic lubrication for feed system; Amp load meter -- Dust Requirements: 3,800 CFM; (1)10" and (1) 7" dust outlet Seller states this machine has less than 600 Hours of use.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5z NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER 2-Head wide belt sanding machine with 37" capacity. - Heads: 1st head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. 2nd head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. Two (2) infeed and outfeed spring loaded hold-down rollers; 2 HP variable speed feed drive. Sanding belt size: 37" X 85" and with electronic belt tracking. Motorized opening between the conveyor and sanding bed. Ammeters for measuring motor loads.

NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER2-Head wide belt sanding machine with 37" capacity. - First head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. -- Second head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. -- Two (2) infeed and outfeed spring loaded holddown rollers; 2 HP variable speed feed drive. -- Sanding belt size: 37" X 85" and with electronic belt tracking. -- Motorized opening between conveyor and sanding bed. -- Ammeters for measuring motor loads. -- Includes spare abrasive belts.

Northtech Machine NT-GRS-300RF Gang Rip Saw REDUCED Roller feed Max depth of cut is 4". Max width is 12". New Saw Blades And Spacers

Northtech MRS-12N Gang Rip 50 HP Motor Needs a new safety with on the door

Northteck MRS-14-DXL 460v Manufacturer notes: This is a very popular machine and cost effective. New open ended design allows for you to cut wide material up to 27-1/8? wide. Plus spare arbors, lasers, and the optional quick locking, easy to adjust infeed will not break the bank. The Northtech heavy-duty 50 HP multi-rip (“gang-rip”) saw with 15? maximum blade diameter quickly and accurately cuts material up to 4-15/16? thick and 27-1/8” wide. Cutting both sides of your blanks at once provides incredible parallelism, reducing required moulder allowance, and increasing your yield. Laser guides (one included) and an optional 103” fence make proper alignment of even the longest material simple and precise. Variable feed speeds of 25 – 120 FPM and powered height adjustment further improve operator efficiency.

NORTHTECH - NT-KL-920-PRR- B & NT-KL-920 PRR-U, ...Top & Bottom 3-Head Planer Sander3-Head bottom with: Planer, drum and platen; 3-head top with: Planer, drum, and platen 920 mm (36") wide.Capacity: 36" x 5" thickness.SpecificationsBottom Machine Model: "NT-KL-920 PPR". -- Infeed driven Conveyor: 37" x 72" Long. -- 1st Head: Spiral cutterhead; (8) rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 175 mm (7") Dia. and 50 HP motor. Segmented chip breaker before the cutterhead. -- 2nd Head: Contact roller; (280 mm) 11" in dia.; 70 durometers, powered by a 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head: 3-1/4" Pneumatic Polishing Platen; engineered as a combination station, air-cushioned & adjustable in pressure to various grits and materials application. Powered by a 30 HP motor. -- Lifting & lowering conveyor bed; 1-1/2 HP motor (includes auto. thickness setup device). -- Variable speed: 7.5 HP; inverter duty motor integrated with an AC inverter (VFD); control providing variable feed rate from 15 - 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control for: Conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads.Top Machine Model: NT-KL-920 PRR-U -- 1st Head - Spiral Cutterhead: (8) Rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 7" (175 mm) Dia.; 50 HP motor.Segmented Chip Breaker: Before the cutterhead. -- 2nd Head - Contact Roller: 11" (280 mm) Dia.; 70 durometers; powered by 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head - 3-1/4" Pneumatic Polishing Platen: Engineered as combination station; air-cushioned & adjustable in pressure to various grits and materials application; powered by 30 HP motor. -- Lifting & lowering Conveyor Bed: Motor 1.5 HP (includes auto. thickness setup device). -- Variable speed 7.5 HP inverter duty motor; integrated with AC inverter (VFD) control; variable feed rate: 15 to 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control: For conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads. -- Powered dropdown Conveyor between Bottom & Top machine.Features (includes both machines) -- Massive monoblock base: 3/4" Thick plate steel weldments. -- Large dia. roller hold-downs; ball bearing supported; 65 duro UV rubber are standard features. -- Automatic soft start of main motors (Y-Delta). -- Disc braking/emergency shut down protection for: Sanding belt breaking, non-tensioned sanding belt; and mistracking of sand belt. -- All motors & electrics are CE-approved. -- Electronic oscillating belt tracking system. -- Au

- Close link chain vs. open (no dust or pinch point) - Oiler has twice the number of lube points (critical) - The VS adjustment location on the 14N. - Can cut up to 4 15/16? with 14? blade vs. the MRS-12 12? blade 3-15/16”. - Can run 12? as well on the MRS-14N - Bottom kickback fingers for added safety - Saws, with proper tooling and material, can glue line Specifications: - Main Motor Hp. = 50 Hp. - Voltage/ Freq. = 460 Volt 60Hz - Phase = 3 Phase - Amp Requirement = 35 Amps - Feed Hp. = 2 Speed 1.5 / 3 Hp. - Feed System = Feed Chain - Feed Speed = 25 – 120 FPM - Variable Speed = Variable Speed Pulley - Elevation Hp. = 1/4 Hp. - Elevation Style = Manual Wheel Adjustment - Elevation Sys. = Jack Screw / Linear Guides - Total Hp. = 53.25 Hp. - Electronics = CE Approved Components - Dual Voltage = Elevation Arbor Motors - Control Voltage = 110 Volt - Assisted Start = Wye-Delta - Pass-Line = 33-1/2” - Min. Length = 17-3/4” - Min. Width = 1/2” - Max. Width = 27-1/8” - Min. Thickness = 5/16” - Max. Thickness = 4-15/16” - Arbor Rpm = 3570 Rpm - Blade Size = 12” Tungsten Carbide Tipped - No. of Teeth = 36 Tooth - Blade Kerf = 3.5 mm - Cleaning System = Brush on Chain - Vertical Travel = 3/8” – 5” - Dust Collection = (2) 6” @ 1962 CFM - Arbor Diameter = 70 mm - Hold Down Style = Pressure Plate - Kickback Finger = (2) Top (1) Bottom Sets - Emergency Stop = Push Button - Rear E Stop = Push Button - Safety Feature = Safety Interlock Switch - Guarding = Full Cabinet Enclosure - Oiler = Automatic Mechanical Oiler - Low Oil Warning = Low Oil Shut-off - Fence Type = Adjustable - Fence Dims. = 103” Length - Frame Const. = 5/16” Steel Construction - Worktable Dims. = 27-1/8” x 64” - Infeed Table = 13-3/4” x 103” - Decible Rating = 74 dB - Net Weight = 4402 Lbs. - Gross Weight = 4694 Lbs. - Machine Dims. = 67” x 58” x 71” - Packaging Dims = 72” x 65” x 77”

NORTHTECH - NT-SL2000XL, ...Straight Line Rip SawSpecifications: -- 20 HP Direct Drive Straight Line Rip Saw. -- 2" Arbor. -- Distance from column to blade: 18 in. -- Saw blade size: 10" - 14". -- 3-1/8" Cutting capacity. -- Glue Line Saw. -- Feed Motor: 1.5 HP. -- Feed Speed: 20 - 105 FPM.

Northtech NT SLR-16SC Precision 16″ Straight Line Rip Saw FEED SYSTEM --Saw motor: 15HP, 3PH 230/460V -- Feed: 1.5HP variable from 40′ – 120′ FPMPRODUCT DIMENSIONS -- Min. thickness: 3/16″ -- Max depth of cut: 4-1/16″ with 16"; Blade -- Max depth of cut: 3-1/16"; with 14"; BladeSpecifications: -- Direct Drive = Direct Drive -- Feed Hp. = 1.5 Hp. -- Feed System = 4"; Split Chain with True Trac -- Feed Speed = 40-120 FPM -- Assisted Start = Wye Delt"; -- Throat Capacity = 18-1/4"; -- Min. Length = 12"; 2nd Roller to Kickback -- Min. Thickness = 3/16″ -- Max. Thickness = 4-1/16"; W/ 16"; BladeGlue Line Rip = Guaranteed 12′ 4/4 stock @ 50 FPMEquipped with & Features -- Blade Size = 14"; Tungsten Carbide Tipped -- Dust Collection = 1417 Total CFM -- Dust Port Out = 4"; Top 6"; Bottom -- Arbor Diameter = 2″ Arbor -- Idle Rollers = (8) Idle Rollers -- Hold Down Style = 8 Spring Loaded Hold Downs -- Kickback Finger = (59) Lower (32) Top -- Automatic Mechanical Oiler -- Low Oil Warning = Low Oil Shut-off -- Laser = 100mw Laser Light & Mount Bracket

6” width capacity 8” thickness capacity 30 hp main motor, 1.4 hp feed motor 3 hp blower motor…460 volt 3 phase 559 rpm blade speed digital oiling

Has (2) Blades Will cut up to a 12 x 12" Powered by (2) 20 HP 460 Volt 3 Phase motors Runs (2) 1 1/4" band blades Excellent Condition, (new condition with less than 4 hours use).

Northtech horizontal band resaw, (2) blades, will cut up to a 12 x 12" cant, powered by (2) 20 HP 460 Volt 3 Phase motors, runs (2) 1 1/4" band blades, Excellent Condition, (new condition with less than 4 hours use). Owner is retiring. Ref# 119, Contact Amy (928) 723-9449

NORTHTECH - SRS-12NS, ...Straight Line RipsawSpecifications: --15 HP Motor, 1" dia. saw arbor, speed of 4,500 RPM, 8". -- Max. blade cap.: 12". -- Max. depth of cut: 3-5/16". -- Part length: 8" Min. -- Distance between saw & column: 18"; 60" W x 33" table. -- Feed & Chain: 2 HP Feed drive motor; variable feed speeds of: 59 - 72 - 91 - 111 & 137 FPM. --7" Wide double chain, with automatic chain lubrication.Equipped with & Feature: -- Top pressure system with (6) spring loaded holddown rollers. -- Double row antikickback fingers. -- Adjustable infeed fence. -- Safety side guard. -- 4" Dia. dust hood outlet. -- Push button controls. -- Magnetic starters. - Overhead post for laser mounting.

NORTHTECH NT-SRS12 Straight Line Rip Saw: 15 HP - 4,500 RPM Direct drive overhead mounted arbor motor, 1" dia. arbor, 8" - 12" max. blade cap., 3-3/8" max. depth of cut, 8" min. part length. Specifications: -- 18" Distance between saw and column. -- 57" L x 39" W table, table height 31-1/2", floor space required 1,200 x 1,600 mm (48" x 63").. -- 2 HP Variable feed drive, (5) feed speed from 59 - 137 FPM. -- Chain drive with automatic chain lubrication; feed chain track travels on hardened V-way guides. -- Top pressure system with spring loaded holddown rollers, dual anti-kickback devices. Equipped with & Features: -- Micro-adjust rip fence -- Laser Guide Line Light -- Digital auto chain oiler -- Full coverage guards -- 4" Dia. dust hood outlet -- Push button controls, and magnetic starters

Rigid one piece welded steel frame, with 10 HP direct drive spindle motor at 7,800 RPM, 1-1/4" x 4-1/2" stackable multi-cutter spindle to mill stile, rail & raised panel profiles. -- Stackable cutter spindle with push button indexing to significantly reduce set-up time as each station is preset; the change from one cutter to another is achieved via a select switch for each operation. -- Complete with: X - Y Sliding table w/pneumatic holddown. -- 2-way linear movement for straight or arch top doors up to 50" long. -- 5" Dust collection hood, and cutter shield. -- Includes: (1) Cathedral arch templates, (1) complete set of tools.

NorthTech 18" Pop-Up Saw. 10hp Motor. #00872

Northtech FR-200 Frame SawSpecifications: -- Saw capacity of 6" width x 8" vertical capacity. -- Minimum working 2"; high X 12"; long. -- Main drive motor to saw frame is 30HP 3PH, wired 460 --V servo drive system to feed works is 1/4HP 3PH, --Blower to saw frame rack for added cleaning value is 3HP 3PH, -- Body of frame saw is (2) sections allowing for fast access to the saw frame, -- Saw blade speed is fixed at 550RPM, -- Dust extraction requires min 3000 CFM and is arranged with (4) 5" ports, -- Blade size is standard with 500mm L x 40mm W x 0.9mm body in stellite or TCT tip,Equipped with & Features -- Digital electronic oiling system provides proper lubrication to the saw frame guides -- Vertical rail system which allows optimum cooling and long term durability, -- (4) guide blocks are thermo- censored to allow auto shut-off of machine should possible heat buildup occur.Machine dimensions 122"; L X 40"; WX, 79"; H weight 7100 lbs. Machine was new in 2007.
