Woodworking Equipment For Sale

FRAVOL VSR TOP & BOTTOM TRIMMERSpecifications: -- Edgebanding thickness 0.4 mm to 3 mm, 16 mm (0.62") to 60 mm (2.36") panel thickness capacity. The rough trimming function uses vertical copy pads and one disc copier between the two cutters in a horizontal position, allowing 0.4 mm to 3mm radius edge rough trimming without replacing the cutters. Panel working height (thickness) is from 16 mm to 60 mm.Equipped with & Features: -- Two 12,000 RPM motors complete with braze welded hard metal cutters Ø 50x16- Z6. Your choice of profiles R1; R2; R3; 5°; 30°. -- The machine comes with a new, patented worktable that provides smooth panel sliding and extremely flexible edging without using jigs. -- Sliding on nylon blocks allows perfect cleaning of the panel melamine surfaces.

FRAVOL SMART S600-23 EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING): -- Specifications: Edge & Workpiece Capacity: 0.4 - 8 mm (0.016 - 0.315") edge; 10 - 60 mm (0.394 - 2.362") panel thickness; -- 140 mm (5.512") min. panel length and 100 mm (3.937") min. panel width. -- Feed-speed, 14 or 18 MPM (46 or 59 FPM.)Front-End Equipped With: -- Pre-Milling Station (RT/S), (2) motors @ 1.1 KW (1.5 HP), 12.000 RPM, LH & RH rotation w/pneumatic programmable jump control for chip-free and clean panel edges. Standard equipped with Dia. 60 mm x 64 mm H, with diamond inserts. -- IR Panel Heat Lamp: Improves gluing bond especially during cooler ambient temperatures and humid conditions. -- Automatic Edge magazine: For strips up to 8 mm & coil stock up to 3 mm thick PVC. -- Duo Gluing System: For regular granulate Hot Melt (EVA) and easy conversion to PUR glue. "Teflon lined" glue tank with bi-directional glue roller. Automatic temperature reduction during stand-by time. Glue tank has quick release system for maintenance or quick change to a different color or glue type. -- Side Pressure Section: (3) Pressure rollers, (1) motorized, (2) idle, pneumatic pressure control and programmable NC-positioning servo motor.Work-stations: -- End Trimming (INT 2/S): (2) motor @ 0.50 KW (0.70 HP) 12,000 RPM, automatic pneumatic chamfer 0° - 15° or total exclusion from control panel. Glides 45° on prismatic linear hardened steel guides. -- Trimming Unit (RF-S/S): Top/Bottom flush/bevel/radius milling unit, (2) motors, 0.73 KW (1.00 HP) 12,000 RPM. Pneumatic remote tilt in (2) positions, postion-1 for radius and thin edges up to 0.8 mm trimming, position-2 for flush trimming up to 8 mm edges.Equipped with banding thickness gauge block feature for quick and easy set-up/changeover. Includes 1-axis NC servo control motors for programmable change-over from thin to 8 mm solid wood edges or incremental re-positioning of the cutter head. -- Corner Rounding Unit (SYNCRO 1): Compact and easy to set up for leading & trailing edges, (1) motor 0.22 KW (0.295 HP) 12.000 RPM, electronically synchronized. Working capacity, min. 10 mm, max. 60 mm panel thickness. -- Profile Scraping Unit (RB/S): Top & bottom radius scraping for PVC - ABS edges. Heavy construction to eliminate vibrations and guarantee superior edge quality. Air blow-off jets and chip collection box. -- Clean Spray System: Top/Bottom spray nozzles applies edge cleaning solvent prior to buffing. -- Glue Scraping Unit (RC/S): Top & bottom pneumatically operated glue scraping on flat panel surface to remove potential glue squeeze-out that otherwise would coat the cloth buffing discs. -- Buffing Station (GSI/S): Top/bottom (2) motors, 0.09 KW (0.125 HP) 2,800 RPM, manual, horizontal, vertical and tilting adjustment -- Hot Air Unit PHON (GP/S): Top/bottom hot air blowers to restore PVC color after scraping. Electrical power 2,000 Watt, 0° to 600° C temperature adjustment.Complete With:• PLC Program Control, with 10.7" co

FRIULMAC - MULIREX: End Matcher with: Stackable SpindlesEnd Matcher with: Stackable Spindle for fast Changeover!Equipped with: -- (2) Profiling Motors: 10 HP (7.5 kW). -- (2) Tool changer motors: 1/2 HP (0.25 kW). -- (2) Infeed/Outfeed conveyor belt motors: 1-1/2 HP (1.10 kW). -- Central conveyor belt: 3/4 HP (0.55 kW). -- Min. part length: 4-7/8" (120 mm). -- Min. part width: 1-3/16" (30 mm). -- Max. part width: 9-7/8" (250 mm). -- Min. part thickness: 1/2" (10 mm). -- Max. part thickness: 1-3/16" (30 mm). -- Min. cutter diameter: 6-5/8" (170 mm). -- Max. cutter diameter: 7-7/8" (200 mm). -- Diameter spindles: 50 mm. -- Spindle length: 11-1/4" (285 mm) under the nut for stackable tooling. -- Cutter speed: 9,000 RPM. -- Dust ports: (4) 4-3/4" for each spindle (2 on the top & 2 on the rear side).

FRIULMAC Quadramat Single End TenonerSingle end tenoner with (4) heads with Jump cope, cope, disc sanding and disc sandingSpecifications: -- Workpiece Length: 125 - 1500mm -- Workpiece Width: 125-1500mm -- Workpiece Thickness: 13 - 40mm -- Configuration: Jump-Cope, Cope, Wheel-Sanding, Wheel-Sanding -- First Station: 7.4 HP Jump-Cope/Profiling Unit with 40mm Diameter Shaft, 6000 RPM Rotation -- Second Station: 7.4 HP Cope/Profiling with 40mm Diameter Shaft, 6000 RPM Rotation -- Thirds Station: 4.7 HP Sanding Wheel -- Fourth Station: 4.7 HP Sanding Wheel -- Variable Speed Control of Sanding Stations from 750 - 1400 RPM -- Feed Speed: 13 - 98 FPM

FRUILMAC RANDOMAT E - End Matcher; -- For End Matching flooring or cabinet & entry door rails or tongue and groove. The feed-thru system allows continuous feeding of random length parts with any kind of profile.÷Capacity & Description: -- Width cap. 1-3/16" x 9-7/8'; length cap. 6-5/16" x 137" length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap. -- Approx. (10) cycles/Min depending on part length & width; -- Feed system with (2) 120" long x 10" wide powered infeed & outfeed belt conveyors, parts are automatically fed & positioned with sensors. -- Positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7.5 HP - 7,500 RPM high-speed shaper motors which pneumatically traverse in tandem for each cutting cycle. -- Cutting station with overhead hold-down wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps. -- Controller & Operator Interface: Key Pad SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line, and shaper head advance with LED readout on the controls. -- Includes Infeed and Outfeed Conveyors

FRUILMAC - RANDOMAT E: End MatcherFor end matching: Flooring, cabinet & entry door rails, or tongue & groove. The feed through system allows: Continuous feeding of random length parts with any kind of profile. -- Capacity & Description -- Width cap.: 1-3/16" x 9-7/8'; Length cap.: 6-5/16" x 137" (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap. -- Approx. (10) cycles/Min - depending on part length & width. -- Feed System with: (2) 120" Long x 10" wide powered infeed & outfeed belt conveyors; parts are automatically fed & positioned with sensors. -- Positive stop to the 1st vertical shaper head (2nd shaper head next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head; automatically reversed & positioned to a positive stop for the 2nd cut on the other end of the part. - At the same time, the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7-1/2 HP - 7,500 RPM high-speed shaper motors, which pneumatically traverse in tandem for each cutting cycle. -- Cutting station with: Overhead holddown wheels; 4-point pneumatic clamping with: (2) Overhead & (2) horizontal clamps. -- Controller & Operator Interface Keypad: SIEMENS Controller; PLC controlled conveyor & shaper cut cycle for automatic operation; variable feed speed conveyor line; shaper head advance with LED readout on the controls. -- Includes: Infeed & Outfeed Conveyors.

FRIULMAC - Dual-Feed, ...Double End Cut-Off SawFor squaring workpieces and for transportation to a Planer or Moulder with a straightening table.Specifications: -- 79" Max. (2,000 mm) opening from Saw to Saw. Motorized opening with LED readout on the control panel; left-hand fixed with left-hand fence line. -- Hopper Magazine - material capacity: Min. length: 7.87" (200 mm), max.: 79" (2,000 mm); width: 1-1/8" (30 mm) to 6-3/4" (170 mm); and thickness: 0.59" (15 mm) min. up to 2-3/8" (60 mm) max.; hopper stack height: 23-1/2" (600 mm).Each side is equipped with: -- (2) Trim saw motors, 5.36 HP each; saw blade dia. 9.84" (250 mm). -- Hydraulic feed drive unit: 4 HP (3 kW) motor. -- Trimming & throughput capacity: Up to (55) pieces/Min.NOTE: Voltage transformer for 600 Volts available with the machine

FRIULMAC - Dual Feed: Double End Cutoff SawFor squaring the workpieces and for transportation to a Planer or Moulder with a straightening table. -- 59" Max. (1,500 mm) opening from Saw to Saw; motorized opening with LED readout on the control panel; left hand fixed with left hand fence line. -- Hopper Magazine, material capacity: Min. length 7.87" (200 mm); max. 59" (1,500 mm); width 1-1/8" (30 mm) to 4-3/8" (110 mm); thickness 0.59" (15 mm) min.; up to 2-3/8" (60 mm) max.; hopper stack height: 23-1/2" (600 mm).Each side equipped with: -- (2) Trim saw motors: 5.36 HP Each; saw blade dia. 9.84" (250 mm). -- Hydraulic feed drive unit with: 3 HP (2.2 kW) Motor. -- Trimming & throughput capacity: Up to (40) pieces per minute..

Friulmac Dualfeed Double End Chop Saw & Moulder Feeder Friulmac Dualfeed Automatically Trims Workpieces and Feeds into a Moulder Cutting Length: 200mm - 1500mm (8" - 59") Cutting Width: 30mm - 110mm (1.2" - 4.3") Cutting Thickness: 15mm - 60mm (0.6" - 2.4") Trim Saw Motors 5.5HP (4KW) Feed Motor 3.5HP (2.64KW) Anti-Kickback Spring-loaded Top Pressure System w/ Manual Adjustment and Readout Manual Board Length Adjustment w/ Readout Manual Blade Height Adjustment w Readout Hopper Fed Voltage: 460V 3PH

- End Matcher for the Continuous Feeding of Random Length Work Pieces - Minimum Working Length: 160mm (6.3") - Working Width: 30-250mm (1.18"-9.84") - Working Thickness: 10-30mm (0.39"-1.18") - Two 7-1/2 HP, 3ph Profiling Motors - Spindle Speeds: 6,800 RPM - Spindle Diameters: 40mm - Cutterhead Feed Motor: 1 HP - Two 1-1/2 HP Motors for Infeed/Outfeed Conveyors - Infeed/Outfeed Conveyor Sizes: 123" x 11" - Sound/Safety Enclosure - New in 2004 - Current Voltage: 460V

2002 Randomat E Endmatcher Manufacturer’s Specifications Working cap.: width 1-3/16" to 9-7/8"; thickness 3/8" to 1-3/16" and length 7" to ???? Feed: (2) 5.5 HP motors for infeed and out feed 10" x 120" belt conveyors. Positioning motor (2) 1.5 HP to shaper heads for tongue and groove. Sensor activated stops for true cut positioning. Approx. 10-12 cycles per minute. Profiling: (2) shaper heads 7.5 HP with 7,500 RPM with spindle dia. 40mm. Tool cutting circle to 8-5/8

Sanding wheel shaper for the production of profiles on the sanding wheels. -- Template carrier holds metal or plexiglass template (same as can be used on the moulder knives). -- Spindle length 5" with 1" diameter arbor for wheel support. Handles 8" diameter wheels (3) included with the machine. -- X and Y axis on dovetail slide with lineal bearing support for smooth movement during the wheel grinding. Pneumatic clamping on grinding wheels. Depth of grinding 1.5" for raised panel. -- Tilt capabilities from 0 to + 30°. -- Grinds all types of varda wheels on 1 HP motor with speed of 1,750 RPM. --You can customize this machine to you needs.

Fukami RT-300 Straight Line Rip SawSpecifications : -- 12" Blade cap., -- 10 HP main motor, 5,700 RPM arbor speed, -- 2-3/8" depth of cut, 8-1/4" min. stock length, 15" throat depth; -- 7-1/2" wide rubber pad feed chain, -- Variable feed speed 50 - 100 FPM, -- 31" X 55" table size.Equipped with and Features --: Anti-Kick back fingers, -- Push button and chain lubricator.NOTE from the seller : Fukami Straight Line Ripsaw. In good condition. Good non marring track is like new. Used in small shop. Nice compact machine with dust collection hood. 12"; carbide blade. 10 hp 3 phase belt drive. Easily changed to single phase. Owner can load

2019 Gabbiani P 55 Front Loading Panel Saw Like New !

Gabbiani Gallixy 125 Rear Loading Panel Saw

Gabbiani Galaxy 125 Panel Saw Manufacturer Specifications to be confirmed: Cutting length; 3800mm Pusher stroke; 3800mm Speed is variable, via VFD Number of grippers; 9 Main motor power; 18.5kw (25.5hp) Saw blade diameter max; 420mm Saw blade projection 125 mm

GANNOMAT VANTAGE 152 LINE BORER (CNC Line Boring)Specifications: -- (1) Boring aggregate with: 152 Spindles; pitch 32. --The unit (aggregate) consists of 2 independent sets: (4) 19-Spindle drill heads; each drill head is powered by: 1.5 kW motor. -- Up & down travel for each aggregate is by pneumatic/hydraulic feed. -- Boring depth: 0 - 35 mm Wit9990oh 70 mm tooling installed. -- 2-Depth Selection for: Blind boring & through boring is programmable through the PLC. -- 76 Drill bits: 5 x 70 mm V-Point, right hand per -- 76 Drill bits: 5 x 70 mm V-point, left hand. -- (8) Holddown clamps for: Workpieces up to 40 mm thick. -- "Y" Axis travel for the drilling unit; NC controlled from 20 - 580 mm from the fixed backstop ruler. -- Travel speed: 250 mm Per second. -- Back fence with: (2) End stops; adjustable from: 0 - 150 mm. -- Electronic control with: LCD Display; (99) programs with: max. of (4) rows of holes per program. --Fully automatic electronic control with: Foot pedal initiation of the clamping/reclamping; drilling cycle; safety control. -- Dims: 142" L x 58" W x 60" T; machine weight: 3,100 Lbs. -- Actual Model -GANNOMAT VANTAGE 152

GANNOMAT - INDEX 280 PRO: CNC Bore, Glue & Dowel Inserter -- SpecificationsCNC Controlled horizontal Point-to-Point Drilling, Gluing & Dowel Inserting Work Center for: Absolute, incremental, variable (parametric) programming of boring patterns. "Z" Axis NC-controlled with: Ball screw drive and dynamic positioning. -- Working Field(4) Independent zones for individual processing: (1- 4) pieces; pneumatically activated Stop system (side fences) consisting of: Right hand, left hand, and center stop. Max. single part length: 2,300 mm (90-1/2") with: 2nd Glue & Dowel inserting unit the max. length is 2,150 mm (84.6"). Min./Max. material thickness: 1/2" - 3.125". NOTE. Machines with Top drilling unit: Max. thickness (Z) will be reduced by 0.78" (20 mm) to 2.345" max. material thickness. "X" Axis Positioning speed: 246 FPM (75 MPM); driven by rack & pinion for fast acceleration/deceleration of working unit. "Y" Axis: Set by mechanical digital counters. Z" Axis with: NC Controlled height adjustment for boring/inserting units. -- Hold-down ClampsTotal of (8): Pneumatic, "quick-change" hold-down Clamps. -- Dowel Driving & Horizontal Boring(2) Gluing & (2) dowel inserting units: (1) For 6 mm; (1) for 8 mm; with (2) separate hopper feeds. Dowel Driving Unit: Located alongside the Boring Station; both units are mounted on: (1) Support; desired dowel diameter is programmable by controller. -- Horizontal Drilling Unit1.5 kW Motor with Mult spindle drill head: (3) Individually single selectable drilling spindles on 32 mm centers in "X" axis.Can be setup for 6 or 8 mm; dowel length from: 25 - 50 mm. (3) Selectable spindle speeds: 3,300 / 4,950 / 6,600 RPM for Horizontal drilling. -- Vertical Top Drilling Unit1.5 kW Motor with multi-spindle drill head with: (3) Individually single selectable drilling spindles on 32 mm centers in "X" axis.Can be setup for 6 or 8 mm; dowel length from 25 - 50 mm. (3) Selectable spindle speeds: 3,300 / 4,950 / 6,600 RPM for vertical drilling. NOTE: For machines with top drilling unit, the maximum workpiece thickness (Z): Will be reduced by 0.78" (20 mm). -- Doweling Station includes:(2) Vibrating hoppers, each hopper with: (1) Single drop device and (1) outlet tube; (1) insertion & dowel driving unit with: Air impulse for each Hopper.Mechanical dowel diameter & dowel length control: Prevents the insertion of any oversized dowels. -- Glue StationRetractable close-range glue nozzle: glue nozzle mounted between drilling and inserting station.Glue amount controlled via: Software; can be adjusted per milliseconds. -- Operator InterfaceGANNOMAT + BECKHOFF TWINCAT TFT Operating System.15" Touchscreen color monitor; network card (for online operation); serial, parallel, USB ports. -- Complete with:(2) Standard stainless steel 1-1/2 gal. pressurized tanks (one for glue, one for water to clean/purge the glue tubes).(1) 5 KVA 208 / 230 / 460 / 480 Volt transformer. -- Actual model: GANNOMAT INDEX 280 PRO.

GANNOMAT - 260: Case Clamp (Semi-Automatic): -- Specifications 100" x 50" x 26" Clamping Cap.; (3) vertical combination air cylinders & shoes mounted on horizontal beam for top pressure; 0.33 HP motor for up/down travel. -- (2) Combination air cylinders & shoes mounted on adjustable vertical, side pressure beam.Vertical beam locks in place with: (4) Air cylinders and rides on bearings for quick and easy positioning. -- Push button operated with: Independent pressure control for top or side; air pressure up to 125 PSI (Clamp shoe assemblies are interchangeable from vertical to horizontal). -- Complete with: -- Pressure gauges and timer control with (0 - 30) Min setting.

GANNOMAT COMBI 110 CONSTRUCTION LINE BORER(23) Spindle head, 2 HP - 2,800 motor, 31-1/2" max. working width, 3" drilling stroke, drills vertically from bottom and horizontally from rear, tilts pneumatically from lower to rear position with positive stop at 45° for angle drilling. -- Holddown clamp assembly tilts 90° for clamping short panels vertically for edge boring, no need to swivel boring head, hydraulic brake for through boring. -- Complete with: (4) Pneumatic holddowns, mirror imaging fences, 4,000 mm line boring fence w/stops and 1,500 mm butt joint fence with (2) flip stops.
