Woodworking Equipment For Sale

DOUCET SDM-M-30-72 Frame and Cabinet Door ClampDesigned for quick and accurate clamping & squaring of miter and regular cabinet doors.Specifications: -- 5-1/2" x 12-1/2" Min. door size, 30" x 72" max. door size. -- (1) Fixed vertical clamp, (2) mobile vertical clamps on roller bearings for effortless positioning. -- (1) Mobile horizontal clamp with a unique "gas spring" assisted lever for effortless centering; pressure is distributed with 4' dia. air cylinders. -- "Progressive Flow" clamping system @ 80 PSI; 675 Lbs of clamping pressure per clamp; operator working height adjustment.

"NEW" Doucet RC - STOCK Gluer - Table top unit for glue applications on a smaller scale. Motorized stainless steel roller equipped with a 2 Litre capacity reservoir easily removable for clean up. -- Spread roller: Stainless steel with roller dimension 8" X 3 1/2"; speed of roller 50 FPM. -- Table top dimension: 20-1/2" x 13".

Dubois Lineal Sprayer with Guns

Dubois Gas Fired Oven

DUBOIS Vertical Edge Fill System with Micro UV This machine is designed to fill voids and defects in edges for a smooth, quality finish. These coaters are ideal for filling porous open grain panels like oak, veneers, particleboard, and MDF. Compatible with solvent based, water based, and UV fill coating.1.1 One (1) Continuous chain transport system- Top and Bottom chain transport conveyor with speed matching attachment conveyor chain- Aluminum backed chain pads with EPDM covering1.2 Two (2) double sided vertical edge denibber/buffer- Operator side Adjustable up to 12"; wide, back side fixed edge- Post mounted vertical denibber head- 12"; dia. x silicon impregnated scuffing wheel, buffer wheel to be determined- Dust hood with 4"; connection- Vertical head oscillation for even brush wear- Inverter controlled drive provides speed control for brush and oscillation1.3 Two (2) double sided vertical edge fill stations- Operator side Adjustable up to 12"; wide, back side fixed edge- Electric motor driven Applicator and Doctor roll drives- Quick change applicator sleeve design, 1-1/2"; face- Stainless steel distribution pipe with spring tension- 9"; dia. chrome plated reverse roll- Stainless steel catch pan and drain lines- 3/8"; pail mounted pump and agitator- Spring loaded doctor bar, urethane dr. blade- Air cylinder dr. roll engagement with stroke adjuster- Inverter controlled drives provides speed control for applicator and doctorrolls1.4 Edge Cure UV Oven Banks- Each bank to consist of Two (2) double sided Fusion F600 Microwave UVovens- Space for two (2) future double sided Microwave UV Units- Individually adjustable three (3) position lamp power selector switch(300, 400 & 600 w/in.)- Irradiator cooling exhaust fan for each set of four (4)2. Control Panel System- NEMA 12 Hinged Door Enclosure, with disconnect, required fuses, door mounted buttons and cooling fans- Allen Bradley HMI, PLC items included- Top mounted panel cooling fan- Required Inverters· Edge Fill Finishing Machineo Top and Bottom Conveyor driveso Denibber/Buffer Brusheso Denibber/Buffer oscillatorso Applicator Rollso Doctor Rollso Reverse Rollso UV oven Exhaust fansDesign Parameters- Machine is located in Explosion Proof Area- Voltage= 480 V., 3 Ph., 60 Hz.- Design Speed = 70 - 200 FPM- Line height = 36";- Max./Min. Part Width: 12"; / 2";- Max./Min Part Length: 245"; / 24";- Max./Min Part Thickness: 1-1/4"; / 3/8";- Paint Color· Main Frame and Conveyor: Blue / TS White· Guards: safety yellowNotes:- ¼"; product has the potential of being processed in this machine but has less probably of being successful the wider the product.

The Dubois SP-12 Linear Spray Machine is an automated linear finishing machine that can be used for a variety of applications including priming, staining, sealing, lacquering, etc. of linear stock. This spayer comes with (3) three arms, (3) three guns and (1) one paint pump. The guns are Binks spray guns Model 363, and Binks pump.Compatible with both waterborne and solvent based coatings --Three adjustable gun arms --9’-0"; long variable speed live roll conveyor w/ electric powered drive --Pneumatic gun trigger mechanism to automatically trigger guns on/off --Infeed guide fences --Top roller hold-down on infeed table --Ability to enable/disable individual guns --Easily cleaned spray trough --Adjustable atomizing air pressure --Adjustable fluid pressureIncluded optional features: &#9679 Stain wipe station mounted to outfeed with stain wipe brush &#9679 Exhaust system with spray enclosure, exhaust fan, & exhaust filter system &#9679 Denibbing station mounted to infeed

DURAMAC - DUR52-2, ...2-Head Wide Belt Sander2-Head Wide Belt Sander with: Drum, combi-head, and brush cleaner. -- Max. working width: 52". -- Max. working thickness: 6". -- 23" Infeed load space. -- 50" Wide rubber conveyor belt size. -- 1st Head: Grooved rubber contact sanding drum; 40 HP, 230 Volt - 3-phase drive motor. -- 2nd Head: Combination contact drum & polishing platen; 30 HP, 230 Volt - 3-phase drive motor. -- Spring-loaded pinch rollers. -- Electronic belt tracking, pneumatic belt tensioning. -- (1) Rear top outfeed panel brush cleaning head, 0.5 HP, 230 Volt - 3-phase drive motor. -- Power raise & lower of worktable. -- Inverter driven feed works drive motor for variable speeds, 0 to 60 FPM. -- Front operator control station; motor ammeters. -- TOSHIBA Feedworks inverter. -- "DP-626S" electronic digital readout for setting table heightAlso Available: -- Transformer for 600 Volt operation, 112.5 KVA.

•Durand plywood stacker •Will stack panels up to 5ft wide x 10ft long panels •Serial # 1286 •Was in use on skinner/trimmer line when the plywood mill went out of business •Currently stored inside, and ready to load on a truck •No charge for loading

Line Shaft Ready Triple Combination Table Saw/Band Saw/Router all in one.

Maximum Assembled Product Size: 37.5” x 98” Minimum Assembled Product Size: 11.375” (vertical) x 9.75” (horizontal) with spacer blocks 7.5” (vertical) x 5.5” (horizontal) Maximum Framing Width: 4” Minimum Framing Width: 1.5” Tubular Steel Frame THK Linear Bearings and Rails (1) Allen Bradley Compact Logix PAC (4) Allen Bradley Kinetix Servos and Drives a. (1) Vertical Beam b. (1) Horizontal Beam (2) On the Upper Right Hand Clamp to ensure that uniform pressure can be applied regardless of the cut accuracy of the frame parts (1) Hoffman Upright Enclosure Allen Bradley Control Components (Push Buttons, Relays, Power Supplies, Buzzer, etc.) (1) Hoffman Air Conditioner for Electrical Enclosure EMS Press Control/Server Communication Software Package (4) Tregarne Woodwelder with Production Gun

Eagle Machinery Infeed Deck: Chain driven, approx 12" wide x 195" long Eagle tilt hoist table

EKSTROM CARLSON - Model EE, ...Straight Line Rip SawSpecifications: -- 30 HP Saw arbor motor. -- Max. thickness 3-1/4"; with 16"; dia. saw blade (no blade). -- 5 HP Feed Motor with feed rates infinitely variable to 280 FPM. -- (3) Lower infeed rollers are chain driven and are adjustable from 0° - 5°. -- Elongated pressure bar housing assures the proper guidance across the entire table length.Equipped with & Features: -- Spring-loaded rollers with 1 in. yield. -- Dual position and lubrication system; (2) outfeed rollers. -- Please note: Chain appears to be in very good condition.

EKSTROM / CARLSON - 18, ...Pump Sander Pump Sander with: (2) 1" Dia. horizontal spindle; 2 HP - 1,200 RPM enclosed motor; mounted on heavy cast iron pedestal. -- Complete with: Push button magnetic controls & starter; 4" dust collection port.

Single Line Rip Saw 110V 3 Phase

EKSTROM CARLSON - Model EE, ...Straight Line Rip SawSpecifications: -- 30 HP Saw arbor motor. -- Max. thickness 4-1/2"; with 16"; dia. saw blade (no blade). -- 5 HP Feed Motor with feed rates infinitely variable to 250 FPM. -- (3) Lower infeed rollers are chain driven and are adjustable from 0° - 5°. -- Elongated pressure bar housing assures the proper guidance across the entire table length.Equipped with & Features: -- Spring-loaded rollers with 1 in. yield. -- Dual position and lubrication system; (2) outfeed rollers. -- Please note: Chain appears to be in very good condition. -- 3 extra blades

Good condition, 3 phase/480 volt

ELIO VALERI ELVAP 120 Copy Lathe. -- General data: 48" max. length cap., 7" max. dia. without steady rest, 3.93" max. dia. with steady rest, and up to 2.5" x 2.5" dia. with steady rest for square pieces; 0 - 39 FPM forward and 0 - 52 FPM return speed, 5.5 HP motor, 1,300 - 3,500 - 5,000 RPM; -- Features: Air/oil feed and copier, chain head stock drive, gate loading, pattern; pneumatic tail stock, automatic pneumatic control program.

Elio Valeri CNC Lathe This is originally an Italian lathe made by Elio Valery designed to make queen Ann legs or axe handles. Seller modified it to make table legs (4 at a time). Working length 60" Actually setup with 1 or 2 spindles, but project can be completed to add 2-more spindles.

EMC MERCURY 1350 3WRK Abrasive Planer / Wide Belt Sander with (3) Heads; Planer Head, Contact Roller, and Combination Head.Useful working width 1,350 mm (53"). Working thickness min./max. 3 - 170 mm (1/8" - 6-11/16"). The machines uses abrasive belts 2,620 x 1,370 mm (103" x 54") for longer life of the sanding belts.Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 140 mm (5-1/2"). -- Shaft for helicoidal position knives with (380) Interchangeable knives with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 20 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer. group in working position. -- Working pressure adjustment. -- Motor power: 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 32 m/Sec (115 FPS). -- Soft starter for slow starting2nd Head: Steel Roller "R", Belts dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 180 mm (7"), spirally grooved. -- Electronic motorized roller pressure adjustment "Grit-set system". -- On-Off selector switch control for roller. -- Constant control to any position with accuracy 0.02 mm. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with Automatic star-delta starter. -- Abrasive Belt cutting speed: 18 m/Sec (59 FPS). -- Timing oscillating cleaning abrasive belt blower located at the bottom 3rd Head: COMBINATION Unit "K", Belt dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 140 mm (5-1/2"). -- Roller rubber hardness 45 Shore, Constant control to any position with accuracy 0.02 mm. -- On-Off selector switch control for 3rd roller including pneumatic piston -- Pneumatic Aluminum PAD , lamina 40 mm, On-Off. -- Quick changing system, extractable blade with felt, rubber and graphite. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with automatic star-delta starter. Abrasive Belt cutting speed:18 m/Sec (59 FPS).Feed system: -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 18 m/Min (9.8 - 58 FPM) Inverter Controlled. -- Automatic feed belt centering device. General Machine Features: -- Large diameter screws on machined guides with columns and pistons. -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each (head) working group. Electronic programmable color TOUCH SCREEN display, 7" wide -- PLC with micro-processor of latest generation, modular and expandable. -- Connection USB, RS232, Ethernet 10/100/1000. -- Memory capacity: 100 working programs or more. -- Graphic synoptic to facilitate programming.Software facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickn

EMC GIANT 1350 2WR Abrasive Planer with (2) Heads, Planer Head and RollerTop of the line Heavy Duty Abrasive Planer from EMC. The series of GIANT machines are available in many configurations. Abrasive Planer has a helicoidal head with insert tooling.Useful working width 1,350 mm (53"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8").Head configuration: 1st Head: Planer Head "W" -- Cutter head knifes diameter 180 mm. -- Shaft for helicoidal position knifes with (512) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer group in working position. Working pressure adjustment. Motor power 30 kW (40 HP), Star-delta starterSpeed rotation: 35 m/Sec (115 FPS).2nd Head: Roller "R" Belts dimensions: 3,250 x 1,370 mm (128" x 54"). -- Roller diameter: 320 mm (12-5/8"). -- Roller rubber hardness 45 Shore. Constant control to any position with accuracy 0.02 mm. -- On-Off pneumatic piston, controlled from the electrical panel. -- Rotation: Against feed (clockwise). -- Motor power: 22 kW (30 HP) Automatic star-delta starter. Rotating cutting speed: 21 m/Sec (99 FPS). Blower for the roller unit.Feed system: -- Constant pass line, 900 mm (35.4") from floor (In line machine). -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 20 m/Min (9.8 - 65.6 FPM). Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each working group.Electronic programmable color TOUCH SCREEN display, 7" widePLC with micro-processor of latest generation, modular and expandableConnection USB, RS232, Ethernet 10/100/1000Memory capacity: 100 working programs or moreGraphic synoptic to facilitate programmingSoftware facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickness. -- Command, programming and display for feeding. -- Command, programming and display for all inverters. -- Command, programming and display for selected groups. -- Command, programming and display for blowers, including compressed air saving function. -- Display report and reset of alarms (self diagnostic) with memory records.Options Included: -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Rotating blowers for part and feed belt cleaning. -- LED light inside the machine. -- Telemetry for remote computer assistance
