Woodworking Equipment For Sale

MULTICAM APEX 3R with 5' X 10' Table and ATC:60" x 120" Fixed table, moving gantry machine in a front-to-back configuration with a multi-zone vacuum table supported by a 20 HP vacuum blower system. -- Equipped with:(1) 10 HP "HSD" spindle with 8-position static tool changer, variable speed by inverter up to 24,000 RPM. -- Full table coverage:X- & Y-axis, rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system, 8" Z-axis travel via lead screw drive. 1,000 IPM Max. cutting feed, 1,700 IPM max. rapid traverse rate on X- & Y-axis. -- Control:The MULTICAM CNC controller Is a stand-alone RISC/DSP system. The controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication. -- Includes:(20 HP) Vacuum blower for hold-down, assorted collets and tool-holder will be included.

MULTICAM APEX 3R with 4' X 8' Table and ATC:48" x 96" Fixed table, moving gantry machine in a front-to-back configuration with a 4-zone vacuum table supported by a 20 HP Republic vacuum blower system. -- Equipped with:(1) 13.4 HP "HSD" spindle with HSK F63 adaptor. (1) 6-position static tool changer, variable speed by inverter up to 24,000 RPM. -- 4 Zone Pneumatic Table:X- & Y-axis, rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system, 6" Z-axis clearance via lead screw drive. 1,000 IPM Max. cutting feed, 1,700 IPM max. rapid traverse rate on X- & Y-axis. -- Control:The MULTICAM Pendant Programmable Controller, PC, is a stand-alone RISC/DSP system. The controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication. -- Includes:Surface Probe and Auto Calibration Sensor; Laser Pointer System; Dual Knife System (Electric Oscillating and Quick Change); K31 Multi-Tool Cutting Head; K41Knife Cutting Head; (1) 20 HP Republic vacuum blower for hold-down, (6) collets and tool-holder will be included.

MULTICAM 5000 SERIES 5-204-R 60" x 120" (5'x10') with ATC:• Working Table (approx.): 61" x 122" (5' x 10')• Table Surface: Phenolic w/ Grid Pattern• Pneumatic pop-up pins• 4 zone vacuum table• Repeatability: 1/1000th Inch• CNC Controls: MultiCam EZ Control w/ Pendant• Tool changer Positions: 12• HSD ES789L, 15KW/20HP Spindle• Spindle Speed: 24,000 RPM (Standard)• Additional 8 position bar type tool changer• Z-Axis Clearance: 8"• Helical Rack & Pinion on X, Y Axis• Ball Screw on Z-Axis• Cut Speed: 1,800 IPM• Rapid Traverse: 3,000 IPM• Dekker 25 HP Vacuum pump• 480v, 3Phase Transformer• Machine Size (approx.): 156" x 118" x 96"• Control Cabinet (approx.): 67" x 16" x 55"• Machine Weight (approx.) 11,000 lbs.

MULTICAM 5000 Series 205-R - 5'x20' CNC Router with ATC: -- Specifications:• Table Size: 5' x 20'• Table Surface: Phenolic w/ Grid Pattern• Pneumatic pop up pins• 4 zone vacuum table• CNC Controls: MultiCam EZ Control w/ Pendant• Electro Spindle 10 HP • Spindle Speed: 24,000 RPM (Standard)• Cut Speed: 1,800 IPM• Rapid Traverse: 3,000 IPM• Repeatability: 1/1000th Inch• (1) 8-Position ATC Tool Plate mounted to the gantry • Helical Rack & Pinion on X, Y Axis• Ball Screw on Z-Axis• Z-Axis Clearance: 8"• Manuals & Documentation.• Machine Size (approx.) 256" x 118" x 96"• Working Tables (approx.): (2) x 61" x 122" (5' x 10')• Total Working Tables (approx.): 61" x 244" (5' x 20')• Control Cabinet (approx.): 67" x 16" x 55"• Machine Weight (approx.) 20,000 lbs.Note: Vacuum Pump(s) are Not Included.

(2) Saws sold as a pair Used for ripping 48" plywood and wafer board Saws can be adjusted anywhere on the shaft. Single Phase motors and variable speed drive motor, 2hp on main shaft.

Multiscore CD 4 Panel Grover Capacity: 30" X 50" Weight: 3500# Dimensions: Length: 70" Width: 78" Height: 51" Table Height: 36" Arbor Drive Motor: 15 HP 3450 RPM Feed Drive Motor: ¾HP geared, with brake Feed Speed: 50 f.p.m. Electric Service Tooling: 480V, 3 phase Dust collection: One 10" diameter outlet

MURPHY-RODGERS HEC-216-S/10 33,000 CFM Continuous Duty Automatic Self-Cleaning Pulse Jet Baghouse Dust Collector Equipped with: (216) 5" Dia. x 10' L Cloth filter bags for a total of 2,827 sq/ff. of filter area. (2) 42-1/2" W x 68" H & (2) 40-1/2" x 68" H Top access doors. (3) Front & (2) side 27" W x 54" H Filter access doors. (2) Square cone bottom hoppers, Each with, 25" x 25" Discharge openings. System utilizes (2) 4-1/2’ x 6’ x 4’ H Waste containers (NOT included). CHICAGO 100 HP - 1,780 RPM Roof-mounted blower, with 41” Dia. inlet. Motorized dampers for winter & summer modes. Winter mode: Directs air back into building, reducing heat loss. Summer mode: Directs air outside, cooling building. Electrical controls (as pictured). Complete with: Spare Filter Bags. NOTE: Installed Used in 2016 with "New" 100 HP motor, new bearings in blower & "New" spring mounts. NOTE: Variable Frequency Drive needs to be replaced. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5y 15 HP Fan motor, free-standing interior/exterior unit rated @ 3,900 CFM. Equipped with: (48) Filter bags having a total of 352 sq. ft. of cloth filter area in a fabricated steel enclosure; 12" dia. inlet. Magnetic starter; rotary air lock, estimated weight: 3,500 Lbs. Unit stands 13.5' tall when fully assembled, but with the legs and muffler removed, it can easily be transported on an open 5'x10' trailer. Machine State: Still in place, but disconnected NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

NANXING MJK1132F1 Sliding Table Saw w/Motorized Raise/Lower/Tilt & Programmable Rip FenceUp, down, and tilting of the main saw and scoring saw blades are controlled electrically by simply pressing buttons. The rip fence enables movement to the required position by inputting a number on a user-friendly touchscreenSpecifications & Features: -- 3,100 mm (122") Cutting length w/scoring; 126" x 16" Anodized sliding table that locks in any position for easy loading. -- Saw blade moves up or down, tilting and fence movement driven by electric servo motor. -- Scoring unit for clean, accurate chip-free cutting, ready for edge banding. Equipped with: -- 7.5 HP Main saw motor; 45° tilting (30 mm) main saw arbor; 13.77" (350 mm) main blade dia.; 3,800/5,200 RPM; -- 4" Max. material thickness at 90°; 2-3/4" at 45°. -- 1.5 HP Scoring saw motor, 4.72" dia. scoring blade; 9,000 RPM. -- Extendable crosscut fence with (2) flip stops, w/digital readout. -- Miter fence; articulating overarm protection guard; outboard and rear extension tables.

NASH 50-72 Spindle Sander(10) Spindles, 72" chucking cap., 3/8" - 6" dia. range;Specifications: -- 2-1/4" Dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds from 700 - 3,000 RPM, 7.5 HP spindle motor, 2 HP feed & oscillation rack motor, variable oscillating speed (60 - 120) strokes/Min, oscillating stroke adjustable up to 2" in length. -- (5) 72" Sanding racks, self-adjusting & oscillating. -- Equipped with: Overhead mounted dust hood, push-button control panel; production rate of (10 - 30) pieces/Min. -- Includes: brushes and sandpaper

NASH - 50-72: Spindle Sander -- (10) Spindles; 72" chucking. -- Cap., 3/8" - 6" dia. range; 2-1/4" dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds: 700 - 3,000 RPM; 7.5 HP spindle motor. -- 2 HP Feed & oscillation sanding rack motor; 60" max. sanding cap. with: (5) Sanding racks, self-adjusting and oscillating. -- Variable oscillating speed: (60 - 120) Strokes/Min; oscillating stroke adjustable up to 2" in length.Equipped with: -- Overhead mounted dust hood., -- Push-button control panel; production rate of (10 - 30) pieces/Min.

New Venture Manufacturing Gang Rip Saw Hydraulic Tank (5) Moving Blades Laser Tower Touchscreen Controls This machine has been removed from service. The photos showing the system setup were taken before it was removed

Newman Helical Carbide Size #5 NEVER USED, Neman/Whitney Planer, 216 pieces SIZE # 5, (E) S.O. 37375, Part# 302 CK (208 pieces) Part # 303 CK ( 4 pieces ) Part # 304 CK ( 4 pieces) (TOTAL PIECES: 216 PIECES) In original packaging from Newman Machine Company REBULT WITH NEW CARBIDE, VIEW PHOTOS WE WILL BUILD A WOOD BOX FOR SHIPPING. CALL FOR DETAILS AND A FREIGHT RATE! Contact us for details or additional photos BOX SIZE 12” X 12” X 8”

Newman HP-688 Twin Bay Hydraulic Cold Press6-Sections (top platens) each 24" x 30" each, Center posts between third and fourth platens, creating two overall areas of 30" x 74". Specifications: -- Max. fixed opening 48" with 11" cylinder stroke, each platen section has (1) 10" bore with 5" dia. ram cylinder; -- Each platen is 15/16″ thick and it’s back structure is webbed every 5-1/2″ X 7-1/2″. -- Side-mounted self-contained hydraulic system w/tank, 10 HP continuous operating pressure compensating pump. -- Hand-Valves to Cycle Individual Platens with pressure gauges for each platen. -- Idle Pop-Up Bed Rollers in the bottom platen for easy loading and unloading.Over all the press is in excellent condition, is extremely heavily built, and is also a beautiful impressive press in person.

This Newman HP-688 press is powered by a 10 HP hydraulic pump. It consists of two 30? X 74? bays. Each bay has (3) individual 24? X 30? platens. Each platen is 15/16? thick and it’s back structure is webbed every 5-1/2? X 7-1/2?. Each platen is driven by a 5? hydraulic cylinder with it’s own control. The max daylight opening is 48? while the minimum is 37?. On the bottom you will find pop up bed rolls. Over all the press is in excellent condition, is extremely heavily built. This fully functional machine has been fully cleaned, checked, and is ready to work

Newman KF-24 Gang Rip Saw

Newman M712 4-sided planer Infeed deck with unscrambler Infeed conveyor Outfeed conveyor Greenchain

Newman M-512 Planer

Newman Power Feed 24"x12' rollcase with spiral positioner, infeed to planer, electric variable drive

Newman S-382 Double Head Planer (Straight Knives) w/Hydraulics & Controls S/N 15292
