Woodworking Equipment For Sale

Mereen Johnson 424-DC Gang Rip Saw

Manufacturer specs (to be confirmed): - Mereen Johnson "312-DC-1" Gang rip saw - 12" Arbor cap., 14" max. dia. tooling, 3-1/2" max. thickness, 30" min. length for glue joint accuracy & 22" min. for busting only; 6" throat. - 50 HP - 3,600 RPM TEFC Direct drive motor - Arbor with disc brake & load meter - Arbor lockout on the access door - Feed & chain: 3 HP Variable feed speed from 30 - 150 FPM with adjustable jam protection, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain - "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with BRAND NEW replaceable steel-backed rubber insert strips, automatic chain oiler with low-level shutoff. - (4) 3" Dia. air loaded overhead pressure rolls; full width segmented maple, spring loaded overhead pressure shoe, pressure rolls & pressure shoe unit adjust with scale & pointer thickness reference; anti-kickback fingers. Includes (1) saw sleeve and spacers. - 460 v/3 ph

Mereen Johnson 524-DC/SR4 Rip Saw (4) Shifting Saw Blades Infeed & Outfeed Decks Per MFG - Saw was ingrates into: Rip Navigator Scout Deck, Power Table, Servo Laser Stand, Sorting Printer

Mereen Johnson 424 DC Gang Rip Outfeed Rollers

225 KVA 480 volt to 208Y/120

MIDWEST AUTOMATION GS 214 Top and Bottom Glue Spreader53" Cap., top & bottom opposed glue applicator rolls, max. 3" opening, 40" pass-line height, 7-3/4" dia. grooved rubber spreading rolls. -- Rolls fitted with Teflon end seals and water tight bearings, upper elevator opening by single hand wheel on left with dial indicator; dual hand wheel opening glue film thickness adjustment. -- Galvanized collection tank; 54 FPM feed speed, top & bottom direct drive, 1.5 HP direct drive motors. -- Complete with: (2) Protection safety guards at roller in- & outfeed with safety interlocks, complies with UL & CE safety standards.

Specification from owner 5 Foot Wide - Midwest Automation top and bottom high pressure laminating line capable of laminating up to 5’ x 12’ panels consisting of the following equipment: Powered infeed roller conveyor PC-160 panel cleaner with top and bottom nylon brushes and dust collection shrouds. GS-417 top and bottom glue spreader with 65” panel width capacity, glue rolls are in excellent condition, separate top and bottom direct drive motors, powered opening, glue pump system. PP-500 panel positioning station for panels up to 62”W x 148”L x 1.63”T. RP-3170 heated roller press with 67”W high temperature silicone covered top and bottom rolls. SL-510 scissor lift table, 5’ x 10’ roller platform and 6000 lb. capacity. Includes 2 new recoated glue rollers and manuals. All equipment is 575V, 3PH. May consider selling pieces separately.

Automatically feeds, shapes & ejects Rosette blocks in sizes from 2-1/2" - 5" max. square blocks; 1.5 HP motor belt drives 2-7/8" spindle cutterhead @ 7,500 RPM. -- Operation: Adjustable hopper feed to side of spindle automatically indexes Rosette blocks under cutterhead up against a corner-V holding fixture with overhead spring fingers, cutterhead advances and machines Rosette, then automatically ejects block to front (hydraulic position of block and air eject cylinder). -- Features: Cutterhead equipped for standard 16°/60° corrugated back 1/4" thick knives to be ground at 0° hook angle. -- Produces up to (500) Rosettes/Hr; Rosette profiles can be ground on any profile grinder for infinitely variable design possibilities; table top unit may include base.

Automatically feeds, shapes & ejects Rosette blocks in sizes from 5-1/2" - 8" max. square blocks; 3 HP motor belt drives 4-3/4" spindle cutterhead @ 7,500 RPM. -- Operation: Adjustable hopper feed to side of spindle automatically indexes Rosette blocks under cutterhead up against a corner-V holding fixture with overhead spring fingers, cutterhead advances and machines Rosette, then automatically ejects block to front (hydraulic position of block and air eject cylinder). -- Features: Cutterhead equipped for standard 16°/60° corrugated back 1/4" thick knives to be ground at 0° hook angle. -- Produces up to (500) Rosettes/Hr; Rosette profiles can be ground on any profile grinder for infinitely variable design possibilities; table top unit may include base.

Designed for curved casings, crowns, circles, ellipses and straight mouldings. -- Working dimensions: 6" wide x 7" thickness capacity. -- Spindle diameter 1-1/4" with cutterhead speed of 6,000 RPM. 6-1/2" max. cutting circle in horizontal position, 6" max. cutting circle tilted. -- Feed motor 7.5 HP variable speed 0 - 30 FPM. -- Tilting of spindle head 0° - 52°. -- Includes: Hand wheel for spindle height & tilt adjustment, mechanically adjustable fence for accurate and easy positioning. Axial adjustment. Floating work table 30" x 23". -- Linear tracking system guides the work piece smoothly and directly under the cutterhead, while keeping the workpiece flat. -- Includes (1) 4" dia. corrugated cutterhead. Operating video and manual, spare parts list and (1) year warranty. -- Additional options: Proscale digital readout for height and tilt setting .... add $900.00 for each.

Horizontal Tilting Multi-Moulder with Verical Router System designed for curved casings, crowns, circles, ellipses and straight mouldings. -- Equipped with: (1) 1-1/4" Diameter Spindle, 6" max. width x 7" max. thickness cap., 7.5 HP spindle motor, 6,000 RPM spindle with reverse rotation, 6-1/2" max. cutting circle horizontal, 6" max. cutting circle tilted, 0° - 52° horizontal tilting arbor, hand wheel spindle height & spindle tilt adjustment. -- Variable feed speed from 0 - 30 FPM, DC feed feed motor; hand wheel adjustable thickness opening, 34" x 30" table, independently adjustable feed rollers, and mechanically adjusted fence. -- 3.25 HP, 5-speed Porter Cable router with 1/2" shank included. This allows easy insert & Channels on both straight and curved mouldings. -- Designed to use standard 4" dia. 2-knife cutterhead for 16°/60° 1/4" corrugated back knives, (1) supplied; includes operating manual & video, parts list and covered by (1) year warranty. -- Optional: ProScale digital readouts for height and tilt settings, please add $900 for each, or for the Optional 8’’ spindle and aluminum Cutter-head, please add $3,550

Milwaukee 8" Panel Saw

MINNESOTA 24-8 Multi-Spindle Carving Machine.Specifications: -- Spindles/Capacity: (24) Spindles, 8" between centers & 72" length capacity. -- Motors: (12) 0.75 HP motors with (1) motor driving (2) spindles via flat belt. -- Features: Manual table elevation, motorized stock rotation, non-indexable head. -- Comes with: (2) Sets of carving tools (one medium and one fine). -- Includes: Tables for flat carving - to be confirmed (?).

16” capacity 5 hp motor 220 volt 3-phase

MOAK - NO. 7, ...Spindle ShaperSpecifications: -- 1.5 HP motor, belt driven to spindle; 9,000 RPM spindle speed; 1" diameter spindle. -- Length of spindle above table is 5"; 3-1/4" vertical adjustment of spindle; 22" x 42" table; manual starter; 750 Lbs machine weight.

Montgomery Blo-Hog, drop feed Steel Flywheel for surge loads Top infeed opening: 18 ¼ X 13 1/4” Bottom discharge Will be repainted Model: ER 18S315FHDL Serial # 1032 75 hp motor. 230/460V, frame: 405T, Support stand Extra parts Contact us for a delivered price

MORBIDELLI AUTHOR M400 FR FLAT TABLE MACHINE(W/LOADING/RAKE/OFFLOADING): -- Specifications:5' x 12' Stationary extruded aluminum "MATRIX" table for "Nested Base" manufacturing with "Rake" and "Automatic Off-Loading Conveyor".Loading/working/processing direction is from LH (facing to RH (facing). -- Work Area:"X" Axis 143.7" (3,650 mm), "Y" axis 62.9" (1,600 mm), "Z" axis stroke 11" (280 mm), max material thickness is 6.69" (170 mm). -- Positioning Speeds:"X" & "Y" Axis 279 FPM (85 MPM), "Z" axis 98 FPM (30 MPM).Closed loop AC servo drive system with Precision Rack/Pinion in "X" axis & recirculating ground ball screw in the "Y" & "Z" axis.All axes ride on precision prism linear guideways. -- Work Table:5' x 12' Aluminum grid "MATRIX" vacuum table machined with a square grid pattern for fixturing parts, grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards.(9) Independent, NC controlled working zone areas; external pop-up reference pins located on the sides & back of the table for positioning parts. -- Boring Unit "F37L2":3 HP (2.2 kW) - variable speed up to 7,000 RPM motor; F37L2 Boring Block with (24) Vertical spindles with (10) independent vertical spindles in "X" axis & (14) spindles in "Y" axis.The 10-spindle "X" axis boring unit is NC controlled with a 11.5" (293 mm) "Y" adjustable spread from its home position & independently controlled according to the drilling pattern being performed, this feature is IDEAL for high-speed line hole drilling.(12) Horizontal spindles with (4+4) in "X" axis on the programmable Independently NC controlled 10-spindle vertical boring unit, & (2+2) on the 14-spindle boring unit in "Y" axis. (1) NC controlled 0° - 90° "X" / "Y" Grooving Saw for max. 120 mm dia. blade. -- Machining:(1) 16.5 HP (12 kW) "Power 2000" Electro spindle w/lifetime lubrication and HSK F63 adaptor, NC controlled spindle speeds from 900 - 18,000 RPM.(1) 16-position "Rapid-16 traveling ATC tool plate for "on the fly" ATC NC Touch-off Probe for automatic Tool Length setting. -- Operator & Machine Control,PC Front End with XILOG PLUS + Windows "7" operating system. 17" high resolution LCD flat screen; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor.Programs can be transferred via USB or downloading by wire is possible; all computer components are mounted on a mobile stand. -- "XILOG Plus" offers incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with: Onboard mini-CAD with built-in programming for writing circles, ellipses, & angles with only a few keystrokes.Onboard cycle optimization; onboard calculator; mirror-imaging and repeat imaging; all electronics mounted in an air conditioned, dust-free environment control cabinet. -- Complete with:(3) 300 m³/Hr "BECKER" Vacuum pumps;

MORBIDELLI N 100 15 FLAT TABLE MACHINE (W/ATC/BORING/RAKE): -- Specifications: 5' x 12' x 37" H High-efficiency laminate aluminum with Magnetic vacuum locking system.Grid pattern allows use of vacuum pods or closed cell rope gasket material & use of spoil boards for nested base machining, Part location pop-up pins mounted on table perimeter, Chips conveying device. -- Working Area: X-Axis 3,686 mm (145.12"), Y-Axis 1,555 mm (61.22"), Z- Axis 150 mm (5.91"). -- Travels:X-Axis 4,230 mm (166.54), Y-Axis 1,985 mm (78.15"), Z-Axis 250 mm (9.84"). -- Positioning Speeds: X- & Y- Axes 35 MPM (114 FPM), Moving Gantry, High precision rack & pinion system for X & Y Axes, Ground ball screws for Z-Axis, All axes ride on extra-large precision profile linear guide ways. -- Boring Unit: 2.2 kW (3 HP) Motor, (12) Independent vertical roto-axial spindles with (8) in X-Axis & (4) in Y-Axis, Maximum spindle speed 8,000 RPM. -- Machining: (1) 15 kW (21 HP) Air-cooled electro spindle with HSK F63 Adaptor, Variable spindle speeds to 24,000 RPM, (1) 14-Position TR side tool changer. -- Operator Interface:Mobile console with Integrated PC “EYE-M"; Industrial PC with 21-1/2" Full HD Multi-touch color touchscreen, WINDOWS Operating system, "MAESTRO SUITE" with Auto-diagnostic to Zooming, Controlled acceleration & deceleration, Encoder feedback, Dynamic tool correction via PLC due to active tool wear using space-and-time criteria, "TECPAD" Remote pendant with 7" Color touchscreen. -- Complete with: PRO-SPACE safety system which allows worktable access to all sides of the machine, (1) 300 m³/Hr. Vacuum pump, Automatic lube system, -- NOTE: Machine was de-installed by a technician and is currently in storage.

MORBIDELLI AUTHOR 636 FLAT TABLE MACHINE (W/ATC/RAKE): -- Specifications:5' x 12' Stationary extruded aluminum "MATRIX" table for "Nested Base" manufacturing. -- Work Area:"X" Axis 144" (3,660 mm); "Y" axis 57.8" (1,470 mm) for routing & 48" (1,230 mm) for boring; "Z" axis stroke 11" (280 mm); max. material thickness is 7" (180 mm). -- Positioning Speeds:"X" & "Y" Axes 262 FPM (80 MPM); "Z" axis 74 FPM (22.5 MPM).Closed loop AC Servo drive system with: Recirculating ground ball screw in the "X", "Y" & "Z" axis; all axes ride on precision prism linear guideways. -- Worktable:Aluminum grid "MATRIX" vacuum table machined with: Square grid pattern for fixturing parts;, grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards.(2) Independent working areas; external pop-up reference ins located on the sides & back of the table for positioning parts. -- Boring Unit:3 HP (2.2 kW) - dual speed 4,500 & 6,000 RPM motor; (12) vertical spindles with: (7) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis. -- Machining:(1) 15 HP (11 kW) "Power 2000" Electro-spindle w/lifetime lubrication and HSK F63 adaptor; spindle speeds from 900 - 18,000 RPM.(1) 12-position "Rapid-12" traveling ATC tool plate for "on the fly" ATC. -- Operator & Machine Control:PC Front End with: NUM 1040 + Xilog III + Windows Operating System.Includes: 12" High resolution CRT, ergonomic keypad, 1.44 MB & CD ROM disk drives, (2) serial ports RS-232 & RS-242. All housed in air-conditioned cabinet with a KELVIN air conditioner. -- Complete with:(2) 250 cbm BECKER "VTLF 250" Vacuum pump with: Emergency stop rope, handheld pendant control. -- Options Include:Nesting Rake: Off feed table to increase machine/operator output; (1) 208/230/460 Volt transformer. -- Actual model - MORBIDELLI AUTHOR 636 S.

X5 Author cnc router 11KW/15HP 5 axis electrospindle router motor Spindle takes HSK63 tool holders 120” x 51.2” working area Max speed in X/Y/Z – 131/131-/74 FPM Remote pendant 18 spindle boring unit with 12 vertical (7+5) and six horizontal (2+2, 1+1) 12 position rear tool changer Centralized dust collection See less
