Woodworking Equipment For Sale

This machine was purchased new. The seller has changed contracts and no longer needs the system for their application. 2019 Morbidelli P200 5 X 12 Contour Edgebander Eye M Controller with 21.5? Touch Screen Hand Held Pendant w/ 7? Touch Screen Air Conditioned Cabinet 20.5 HP Liquid Cooled Router Tool Touch Probe 12 Position Ride Along Tool Changer 14 Position Side Tool Changer 17 Vertical Spindles 8 Horizontal Spindles / 3+3 in X and 2+2 in Y Hinge Unit Edgebanding Unit Standard two Coils Magazines on Safety Enclosure Additional Support for 6 Coils EVA or PUR Glue Aggregates for 3mm PVC Flexmatic Table with 8 Rails 8 Lifting Rails Variety of Vacuum Pods HE Pods Conveyor for Dust Busch Mink Vacuum Pump Pro Speed w/ Safety Enclosure

MORBIDELLI AUTHOR M400 FR FLAT TABLE MACHINE(W/LOADING/RAKE/OFFLOADING): -- Specifications:5' x 12' Stationary extruded aluminum "MATRIX" table for "Nested Base" manufacturing with "Rake" and "Automatic Off-Loading Conveyor".Loading/working/processing direction is from LH (facing to RH (facing). -- Work Area:"X" Axis 143.7" (3,650 mm), "Y" axis 62.9" (1,600 mm), "Z" axis stroke 11" (280 mm), max material thickness is 6.69" (170 mm). -- Positioning Speeds:"X" & "Y" Axis 279 FPM (85 MPM), "Z" axis 98 FPM (30 MPM).Closed loop AC servo drive system with Precision Rack/Pinion in "X" axis & recirculating ground ball screw in the "Y" & "Z" axis.All axes ride on precision prism linear guideways. -- Work Table:5' x 12' Aluminum grid "MATRIX" vacuum table machined with a square grid pattern for fixturing parts, grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards.(9) Independent, NC controlled working zone areas; external pop-up reference pins located on the sides & back of the table for positioning parts. -- Boring Unit "F37L2":3 HP (2.2 kW) - variable speed up to 7,000 RPM motor; F37L2 Boring Block with (24) Vertical spindles with (10) independent vertical spindles in "X" axis & (14) spindles in "Y" axis.The 10-spindle "X" axis boring unit is NC controlled with a 11.5" (293 mm) "Y" adjustable spread from its home position & independently controlled according to the drilling pattern being performed, this feature is IDEAL for high-speed line hole drilling.(12) Horizontal spindles with (4+4) in "X" axis on the programmable Independently NC controlled 10-spindle vertical boring unit, & (2+2) on the 14-spindle boring unit in "Y" axis. (1) NC controlled 0° - 90° "X" / "Y" Grooving Saw for max. 120 mm dia. blade. -- Machining:(1) 16.5 HP (12 kW) "Power 2000" Electro spindle w/lifetime lubrication and HSK F63 adaptor, NC controlled spindle speeds from 900 - 18,000 RPM.(1) 16-position "Rapid-16 traveling ATC tool plate for "on the fly" ATC NC Touch-off Probe for automatic Tool Length setting. -- Operator & Machine Control,PC Front End with XILOG PLUS + Windows "7" operating system. 17" high resolution LCD flat screen; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor.Programs can be transferred via USB or downloading by wire is possible; all computer components are mounted on a mobile stand. -- "XILOG Plus" offers incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with: Onboard mini-CAD with built-in programming for writing circles, ellipses, & angles with only a few keystrokes.Onboard cycle optimization; onboard calculator; mirror-imaging and repeat imaging; all electronics mounted in an air conditioned, dust-free environment control cabinet. -- Complete with:(3) 300 m³/Hr "BECKER" Vacuum pumps;

MORBIDELLI N 100 15 FLAT TABLE MACHINE (W/ATC/BORING/RAKE): -- Specifications: 5' x 12' x 37" H High-efficiency laminate aluminum with Magnetic vacuum locking system.Grid pattern allows use of vacuum pods or closed cell rope gasket material & use of spoil boards for nested base machining, Part location pop-up pins mounted on table perimeter, Chips conveying device. -- Working Area: X-Axis 3,686 mm (145.12"), Y-Axis 1,555 mm (61.22"), Z- Axis 150 mm (5.91"). -- Travels:X-Axis 4,230 mm (166.54), Y-Axis 1,985 mm (78.15"), Z-Axis 250 mm (9.84"). -- Positioning Speeds: X- & Y- Axes 35 MPM (114 FPM), Moving Gantry, High precision rack & pinion system for X & Y Axes, Ground ball screws for Z-Axis, All axes ride on extra-large precision profile linear guide ways. -- Boring Unit: 2.2 kW (3 HP) Motor, (12) Independent vertical roto-axial spindles with (8) in X-Axis & (4) in Y-Axis, Maximum spindle speed 8,000 RPM. -- Machining: (1) 15 kW (21 HP) Air-cooled electro spindle with HSK F63 Adaptor, Variable spindle speeds to 24,000 RPM, (1) 14-Position TR side tool changer. -- Operator Interface:Mobile console with Integrated PC “EYE-M"; Industrial PC with 21-1/2" Full HD Multi-touch color touchscreen, WINDOWS Operating system, "MAESTRO SUITE" with Auto-diagnostic to Zooming, Controlled acceleration & deceleration, Encoder feedback, Dynamic tool correction via PLC due to active tool wear using space-and-time criteria, "TECPAD" Remote pendant with 7" Color touchscreen. -- Complete with: PRO-SPACE safety system which allows worktable access to all sides of the machine, (1) 300 m³/Hr. Vacuum pump, Automatic lube system, -- NOTE: Machine was de-installed by a technician and is currently in storage.

MORBIDELLI AUTHOR 636 FLAT TABLE MACHINE (W/ATC/RAKE): -- Specifications:5' x 12' Stationary extruded aluminum "MATRIX" table for "Nested Base" manufacturing. -- Work Area:"X" Axis 144" (3,660 mm); "Y" axis 57.8" (1,470 mm) for routing & 48" (1,230 mm) for boring; "Z" axis stroke 11" (280 mm); max. material thickness is 7" (180 mm). -- Positioning Speeds:"X" & "Y" Axes 262 FPM (80 MPM); "Z" axis 74 FPM (22.5 MPM).Closed loop AC Servo drive system with: Recirculating ground ball screw in the "X", "Y" & "Z" axis; all axes ride on precision prism linear guideways. -- Worktable:Aluminum grid "MATRIX" vacuum table machined with: Square grid pattern for fixturing parts;, grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards.(2) Independent working areas; external pop-up reference ins located on the sides & back of the table for positioning parts. -- Boring Unit:3 HP (2.2 kW) - dual speed 4,500 & 6,000 RPM motor; (12) vertical spindles with: (7) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis. -- Machining:(1) 15 HP (11 kW) "Power 2000" Electro-spindle w/lifetime lubrication and HSK F63 adaptor; spindle speeds from 900 - 18,000 RPM.(1) 12-position "Rapid-12" traveling ATC tool plate for "on the fly" ATC. -- Operator & Machine Control:PC Front End with: NUM 1040 + Xilog III + Windows Operating System.Includes: 12" High resolution CRT, ergonomic keypad, 1.44 MB & CD ROM disk drives, (2) serial ports RS-232 & RS-242. All housed in air-conditioned cabinet with a KELVIN air conditioner. -- Complete with:(2) 250 cbm BECKER "VTLF 250" Vacuum pump with: Emergency stop rope, handheld pendant control. -- Options Include:Nesting Rake: Off feed table to increase machine/operator output; (1) 208/230/460 Volt transformer. -- Actual model - MORBIDELLI AUTHOR 636 S.

Morbidelli N 100 12 C CNC Machining Center:Specifications: -- 4' x 8' Traveling "Bridge Gantry", stationary aluminum grid "MATRIX" table with square grid pattern for fixturing parts; (8) vacuum zones controlled by electronic switches. Grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards for "nested base machining". Part location pop-up pins mounted on the table perimeter. Working Field: -- "X" Axis is 98" (2,500 mm); "Y" axis is 48" (1,250 mm); "Z" axis stroke is 9.4" (240 mm); max. material thickness 5.9" (150 mm) Positioning Speed: -- "X" & "Y" Axis 229 FPM (70 MPM), "Z" axis at 82 FPM (26 MPM); closed-loop AC Servo drive system. High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra-large precision profile linear guide ways. Boring unit: -- 3 HP (2.2 kW) - 8,000 Max RPM motor; (18) independent vertical spindles on 32 mm centers, (2) in Y axis and (4) in X axis Machining: -- (1) 21 HP (15 kW) Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM; (1) 11-Position ATC tool rack mounted at the rear of the machine base.Operator & Machine Control: -- PC Front-End with: "MAESTRO SUITE" + Windows "XP PRO" operating system; 17" high-resolution LCD flat-screen; ergonomic keypad; CD ROM & 1.44 MB disk drives. USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible; all computer components are mounted on a mobile stand. -- "MAESTRO SUITE" offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, and dynamic tool correction via PLC due to active tool wear using space-and-time criteria. Remote "TECPAD" Pendant with 7" Color display for the effective management of the machine functions Complete with: -- (1) 300 m³/Hr Vacuum Pump; Hand-Held Pendant; Automatic lube systemNOTE: The above specs are taken from literature and thought to be accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

Morbidelli Planet P800 CNC Router

MORBIDELLI UNIFLEX HP 1.1 CNC MACHINING CENTER (2-HEAD): -- Specifications:Flexible "TOP & BOTTOM" Machining Center that uses an innovative panel handling system. -- Positioning SpeedsThe "UNIFLEX" can reach positioning speeds of: 130 MPM in "X" Axis; 80 MPM in "Y" axis; 50 MPM in "Z" axis with total safety, providing an unmatched working capacity. -- Working DimensionsMax. worktable part size for: "X" axis is 118" (3,000 mm); "Y" axis is 51" (1,300 mm) "Z" axis max. part thickness 3.1" (80 mm).Min. worktable part size for: "X" Axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness 0.157" (4 mm). -- Worktable:Automatic LH infeed air table with gripper clamps; automatic RH outfeed transfer conveyor with belts; both infeed & outfeed are considered Robot ready. -- Boring Units:(1) Top mounted boring block: 4.2 HP (3 kW); variable speed from 1,500 - 6,000 RPM; (48) vertical spindles: 24-Spindles in "X axis & 24-spindles in "Y" axis; (6) horizontal spindles with: (2+2) in "X" axis & (1+1) in "Y" axis; (1) 4.2 HP (3 kW) - 9,000 RPM, NC controlled 0°-90° "X/Y" Grooving Saw, max. 120 mm dia. blade.(1) Bottom mounted boring block: 4.2 HP (3 kW); variable speed from 1,500 - 6,000 RPM; (48) vertical spindles: 24-Spindles in "X axis & 24-spindles in "Y" axis; (6) horizontal spindles with: (2 + 2) in "X" axis & (1 + 1) in "Y" axis; (1) 4.2 HP (3 kW) - 9,000 RPM, NC controlled 0°-90° "X/Y" Grooving Saw, max. 120 mm dia. blade. -- Machining:(1) Top mounted 10 HP (7.5 kW) electro-spindle with: HSK D-50 Adaptor; "ERC 32" tool holders & RC-32 collets, 1,500 - 24,000 RPM.(1) Bottom mounted 10 HP (7.5 kW) electro-spindle HSK D-50 adaptors, "ERC 32" tool holders & RC-32 collets; 1,500 - 24,000 RPM. -- Operator Interface:PC Front-End with: "XYLOG PLUS" + Windows environment Operating system; 20 GB hard drive; 17" TFT monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports, USB ports; (1) 1.44 MB floppy drive; (1) CD ROM drive; all mounted in separate control console. -- Operating System:"XYLOG PLUS" Offers Real time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: Pneumatic part clamping devices; sound enclosure; safety mats. -- Operating features: Machine can work the panel from above & below at the same time and can produce (2) identical or mirrored panels per cycle with no difficulty.The "UNIFLEX" can machine porous materials since the pieces are held with grippers, directly managed by the numerical control; it can even process small pieces and carry out "through" machining.(4) Operating modes at each cycle, it can change automatically from: Top machining to bottom machining, to top & bottom machining together, either on (1 or 2) stacked panels. -- Actual model is MORBIDELLI UNIFLEX HP.

MORBIDELLI AUTHOR 503 FT CUSTOM CNC MACHINING CENTER (W/ATC): -- Specifications:4' x 8' Custom Stationary Extruded Aluminum Table for "Nested Base" manufacturing;Working cap. "X" axis is 125.2" (3,180 mm), "Y" axis is 41.3" (1,050 mm) for routing "Z" axis stroke is 5.7" (144 mm); max. material thickness is 3.1" (80 mm) -- Positioning speed:"X " & "Y" axis is 213 FPM. (65 MPM), "Z" axis is 82 FPM (25 MPM). -- Work Table: 4' x 8' Custom Stationary Extruded Aluminum Table for "Nested Base" manufacturing;(2) pneumatic side stops, (2) working areas -- Machining Units:(1) 10 HP (7.5 kW) Vertically mounted electro-spindle router with ISO-30 adapter, LH & RH rotation, inverter driven from 12,000 - 18,000 RPM,(1) 5-position ATC tool rack mounted on the LH side for automatic tool change, -- Operator & Machine Control:Separate control cabinet with Morbidelli "TRIA 7500" CNC Multi-processor, VGA monitor, ergonomic keypad, 3-1/2" disk drive, and (2) serial ports RS-232 & RS-242.Offers incredible list of functions from (a) auto-diagnostic to (z) zooming; -- Complete with: Voltage stabilizer 208. 230, 460 V, 60 Hz, 3 Phase Auto Transformer (1) 100 m³/Hr vacuum pump. -- Actual model is MORBIDELLI AUTHOR 503 FT CUSTOM

MOTIMAC FR650 5-Head Abrasive Brush Sander with (3) top & (2) side heads: -- Specifications:Two sides heads & Three tops heads • Side heads able to sand in multiple angles • Independent height adjustment on all hubs • Independent operation of each hub • Siemens electronic controls • Capable of sanding flat or profiled surfaces • 25"; Working Width • Side heads adjust to sand from 2";wide to 25";wide pieces. -- Working Capacity:Maximum Sanding Width 25“; Minimum Working Length 21.5"; for Edge Sanding Rollers & 15"; for Horizontal Rollers. -- Working Height 0.12"; - 4";; Variable Feed Speed 10 - 55 FPM (3-17 MPM). -- (2) 100-450 RPM Side Heads @ 0.75 HP ea. & (3) 60-450 RPM Top Heads @ 4 HP. Total Power 15.5 HP (11.5 kW).

ME R80 14" Radial Arm Saw

Infeed Deck & Conveyors. Infeed Deck: 12' motorized chain driven - 4 metal chains. Stationary table with 4 sets of 5.5" rollers for Moulder

Heavy Duty 5-Axis Machine ideal for high speed and precision routing/sizing/milling/triming & surfacing of wood & composite parts, as well as machining light alloys. -- Steel bar table with threaded holes in 23.6" x 11.8" (600 mm x 300 mm) centers for attaching fixtures and vacuum jigs; system comes with one removable center safety wall for penular load and unload work. -- Axis strokes & quick positioning speeds: X-Axis is 120" (3,050 mm) at 275 FPM (84 MPM); Y-axis is 62.2" (1,580 mm) at 275 FPM (84 MPM); Z-axis is 35.4" (900 mm) at 131 FPM (40 MPM). -- A-Axis is +/- 120° at 30 RPM.; C-axis is +/-360° at 30 RPM. -- Equipped with: (1) 7.5 kW (10 HP), ISO 30 Type air cooled ATC spindle, variable speed from 1,000 - 24,000 RPM with 8-position tool rack. -- "OSAI 10/510" Series CNC Control operating with WINDOWS/XP "Pro Multilingual", 15" LCD color display, large hard disk for program storage, network ready via Ethernet. -- Features: 5-Axis simultaneous motion, M & G code programming operation. -- Complete with: Safety enclosure and automatic doors. -- Options: A- & C-Axis alignment system for re-setting both polar axes, please add ...$ 3,600; Radio touch probe system add ...$ 9,580; OSAI Teach Pendant System add ...$ 3,775.

MULTIAX T 1105 3626 Heavy Duty 5-Axis MachineIdeal for high speed and precision routing/sizing/milling/trimming of wood & component parts, as well as machining light alloys.Specifications: -- The work table is 3,040 mm (119") x 1540 (60.6"), divided in two independent suction areas. During the work cycle the operator unloads and loads parts on one side of the machine table, while parts are being machined on the other side of the machine table. A safety wall is provided for separating the two work zones. The machine bridge will not enter the loading station until the operator is clear of the area. -- Axis strokes & quick positioning speeds: X-axis is 120" (3,050 mm) at 275 FPM (84 MPM), Y-axis is 62.2" (1,580 mm) at 275 FMP (84 MPM); Z-axis is 40" (900 mm) at 131 FPM (40 MPM). -- A-axis is +/- 120° at 30 RPM.; C-axis is +/-365° at 30 RPM.Equipped with: -- (1) 10 kW (13 HP) , HSK-63F type liquid cooled ATC spindle, variable speed from 1,000 - 22,000 RPM with 8-position tool rack. -- NEW OSAI Series open CNC control CNC Control operating with 20 Gb memory P, (5) simultaneously interpolated axes.CNC display unit with Windows XP Pro, 15" TFT color display, large hard disk for program storage, network-ready via Ethernet, features 5-axis simultaneous motion, M & G code programming operation. -- Complete with: 6.5 HP "TYP 251 Garder Denver" 255 CMH vacuum system and safety doors. Twin 10 place vacuum manifolds connected to automatic vacuum valves controlled by the CNC, enables clamping the workpieces on one table, while the other table is inactive, for unloading and loading operations.The vacuum system includes a filter to prevent impurities inside the pump.Professional set-up and delivery are an option .

MULTICAM 3000 SERIES 3-103-R 4 X 8 with ATC:50" x 100" Fixed table, moving gantry machine in a front-to-back configuration with a multi-zone vacuum table supported by a 16.9 HP vacuum system . -- Equipped with:(1) 13.4 HP HSD Routing HSK spindle, variable speed by inverter up to 23,000 RPM with 6-position rear mount tool changer.. -- Full table coverage:On X- & Y-axis, rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system, 6" Z-axis travel via lead screw drive; 1,400 IPM max. cutting feed, 2,500 IPM max. rapid traverse rate on X- & Y-axis. -- Control:The MULTICAM CNC controller is a stand-alone RISC/DSP system. The controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication. -- Complete with:16.9 HP vacuum pump, assorted tool holders, PC and manuals.

MULTICAM APEX 1R with 5' X 10' Table and ATC:60" x 120" Fixed table, moving gantry machine in a front-to-back configuration with a multi-zone vacuum table supported by a 20 HP vacuum blower system.Equipped with: (1) 10 HP "HSD" ATC spindle, variable speed by inverter up to 24,000 RPM. 5-position, stationary tool rack X- & Y-axes are rack & pinion, Z-axis is lead screw, all axes are driven by brushless servo motors. Phenolic vacuum table with manual zone selectionControl: The MULTICAM CNC controller Is a stand-alone RISC/DSP system. Includes a keypad interface with hotkeys for repetitious functions and DNC access to the host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication.Includes: (20 HP) Vacuum blower for hold-down.

MULTICAM 3000 SERIES 3-204-R, 5' X 10' TABLE WITH ATC SPINDLE AND BORING BLOCK60" x 120" Fixed table, moving gantry machine in a front-to-back configuration with ATC, boring and multi-zone vacuum table.Equipped with: 10 HP "HSK" automatic tool change spindle, variable speed by inverter up to 24,000 RPM. 8 position tool rack 4 spindle drill block in long axis direction Full table coverage on X- & Y-axis Rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system 8" Z-axis travel via lead screw drive. 1,000 IPM Max. cutting feed, 1,700 IPM max. rapid traverse rate on X- & Y-axis.Control: MULTICAM CNC controller Is a stand-alone RISC/DSP system. Controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes. RS-232 interface for PC communication. Includes: Assorted collets and tool-holders.

There are (2) identical machines available. They are brand new, never removed from the crate or plastic. The first photo is of an identical system. The second is how the machines sit right now, ready to load. Multicam Model 3-204 60" x 120" Work area Standard 6" Clearance (2) 7.5 HP Spindles

(2) Saws sold as a pair Used for ripping 48" plywood and wafer board Saws can be adjusted anywhere on the shaft. Single Phase motors and variable speed drive motor, 2hp on main shaft.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5y 15 HP Fan motor, free-standing interior/exterior unit rated @ 3,900 CFM. Equipped with: (48) Filter bags having a total of 352 sq. ft. of cloth filter area in a fabricated steel enclosure; 12" dia. inlet. Magnetic starter; rotary air lock, estimated weight: 3,500 Lbs. Unit stands 13.5' tall when fully assembled, but with the legs and muffler removed, it can easily be transported on an open 5'x10' trailer. Machine State: Still in place, but disconnected NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

MURPHY-RODGERS HEC-216-S/10 33,000 CFM Continuous Duty Automatic Self-Cleaning Pulse Jet Baghouse Dust Collector Equipped with: (216) 5" Dia. x 10' L Cloth filter bags for a total of 2,827 sq/ff. of filter area. (2) 42-1/2" W x 68" H & (2) 40-1/2" x 68" H Top access doors. (3) Front & (2) side 27" W x 54" H Filter access doors. (2) Square cone bottom hoppers, Each with, 25" x 25" Discharge openings. System utilizes (2) 4-1/2’ x 6’ x 4’ H Waste containers (NOT included). CHICAGO 100 HP - 1,780 RPM Roof-mounted blower, with 41” Dia. inlet. Motorized dampers for winter & summer modes. Winter mode: Directs air back into building, reducing heat loss. Summer mode: Directs air outside, cooling building. Electrical controls (as pictured). Complete with: Spare Filter Bags. NOTE: Installed Used in 2016 with "New" 100 HP motor, new bearings in blower & "New" spring mounts. NOTE: Variable Frequency Drive needs to be replaced. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.
