Woodworking Equipment For Sale

The Original Radial Arm Saw 230/460 Volt 3Phase

ORMA Glue Spreader

ORMA NPC 38-16 Hot PressSteel (fabricated) platen dimensions: 150" x 62.99" (3,800 x 1,600 mm); 17.71" (450 mm) max. daylight opening, -- (6) Hydraulic 3.34" dia. (85 mm) chromed upstroke pistons on guide bushings which are constantly lubricated; 17.70" Cylinder stroke and press opening with double rack & pinion guide system, parallelism sensor to ensure parallel closing of the platens. -- 120 Ton thrust; specific pressure will be based on 80% of platen area. -- Design allows loading from (3) sides; constructed with a heavy I-beam welded steel frame. -- Control panel: Touch-screen control with individual programmable electronic control (PLC), central unit CPU, EEPROM memory card with expansion possibility of inputs and outputs; CROUSET hardware & ORMAMACCHINE software; Digital controls for adjustment of pressure, temperature, timing, boiler on/off, weekly timer for start of shift preheating and partial heating possibility (50%) of the boiler to save electric power.Includes: -- Hydraulic unit with double pump and motor in oil bath for less noise and better lubrication; high-capacity low-pressure pump for quick closing and low-capacity high-pressure pump for slow movement -- Oil control unit with mechanical control and safety valves as follows: Circuit breaker safety valve when closing; Max. Pressure pump safety valve when pushing; Check safety valve for pressure; Pre-relief safety valve for slow pressure relief; Electromagnet control for fast oil release. -- Additional: Safety rope around the machine, Press structure with welded beams, insulation between press platen and press structure to prevent overheating, CE & CSA electrical standards, -- Electric boiler (27 kW) for thermal oil heating.

ORTON - TYPE F, ...Ship Shaper/RouterORTON Type "F" Ship Shaper/Router with: 40" x 60" Table Size. -- 5 HP - 230 Volt, 3-Phase. -- Oil Mist Lubrication. -- Machine "Completely Restored". -- Can be used as a Shaper or Router. -- Comes with: Mandrel with Top Bearing Attachment so the machine can be used as a Tilting Spindle Shaper. -- Also used as a Tilting Spindle Router with: Collet Chuck attachment with: 1" HSS spiral cutter and template guide. -- Heavy-Duty spindle with: BROWN & SHARPE "#11 Tapered Socket" in Spindle. -- Spindle tilts: 30° forward and 45° backward. -- Includes: BROOKS Frequency changer to increase 60-Cycles to 250-Cycles to increase speed of routers to 4,700 RPM. -- Great for cutting changing bevels. -- Approx. weight 3,000 Lbs. -- Lamp & cord NOT included. 5 HP - 230 Volts, 3-phase; in "Excellent Condition." Routers come with: 4 Ft x 14 ft table for clamping down work with patterns.

Complete OSAMA Feed Through White Glue Laminating Line, with MIDWEST AUTOMATION Laminate Indexing/Lay-up Table & HMT Laminator Specifications: Line was designed to use the HMT Laminator as a pinch roller with heaters for large quantity runs. The HMT Laminator was used as a stand-alone machine for small quantity runs. Max. panel size 60" x 120" (Based on current outfeed scissor lift platform size. With a 60" x 144" or larger scissor lift, 144" L panels could be run.) Consisting of the following machines as late as 2016: AREDON 48" x 96" Electric/Hydraulic Scissor Lift Platform. 2007 OSAMA SP/RSI-1600 1600 mm (63") Top & Bottom Brush Panel Cleaner, S/N 8103, Min. panel length 430 mm (16.93"), Panel thickness 0 - 100 mm (3.94"), Feed speed 22 MPM (72 FPM), with 290 mm (11.42") Dia. Top & bottom brush rolls with 0.6 mm (0.02") Dia. Black nylon bristles, Spare pair of brushes, 460 V, 60 Cy, 3 Ph., Dimensions 108" X 36" X 70" H, Weight 1,100 Lbs. 2006 OSAMA S2R-1600 1600 mm (63") Top & Bottom Glue Spreader, S/N 20944, Panel thickness 0 - 100 mm (3.94"), Pass line height 800 mm (31.50"), Feed speed 18 MPM (59 FPM), with 185 mm (7.28") Dia. x 64" L Grooved anti-acid rubber-covered top & bottom applicator rolls, each with Manual brush washer, Side glue wipers, Removeable bottom pan, Front & rear safety fences, 230 V, 60 Cy, 3 Ph., Dimensions 90" x 30" x 60" H, Weight 1,500 Lbs. MIDWEST AUTOMATION LT 500 60” x 144” Laminate Indexing/Lay-up Table. 2016 HMT ADVANTAGE PLUS 61" Laminator, S/N 5A391, with 10.5 kW Heatbank, 208 V, 60 Cy, 1 Ph., Dimensions 120" x 83" x 55" H, Weight 1,400 Lbs., NOTE: This machine is also being offered for sale separately (EXF #LA-011186). SOUTHWORTH 5,000 Lb. Capacity 60” x 120” Electric/Hydraulic Scissor Lift Platform, with Gravity roller conveyor top. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

OSAMA - S2R 1300: Top & Bottom Glue Spreader51" Cap., top & bottom opposed rollers; max. 4" opening. -- Specifications -- 7-1/4" Dia. grooved rubber spreading rolls; glue film thickness adjustment via mechanical microcontroller of doctor knives on each adhesive tray; galvanized collecting tank. -- Approx. 60 FPM feed speed; 1/2 HP feed drive; bronze end seals and watertight bearings. -- Complete with: (2) Protection safety shields at roller in- & outfeed; emergency shutoff button; complies with UL & CE safety standards.

OSI SM-450 Side Matcher LineSide Matcher:FEATURES -- Directly opposing heads (Side-Matcher): Enhances width tolerance and eliminates pistol grip -- Guarantee machining accuracy of +/- 0.002"; (0.05 mm) on width and on tongue/groove position -- Through feed system in both machines: work boards as short as 9"; (229 mm) out of the defecting station; can be processed directly into the Side-Matcher -- Process twisted, crooked and bowed boards -- Hydro-lock collars on all axis -- Feed wheels on independent suspension -- Very low friction -- High precision spindle -- Very short setup time Easy and quick width adjustment -- Easy opening for tool replacement -- Hydraulic unjammingSpecifications: -- Pre-Milling top and bottom with (2) 15 HP motor -- Feed speed 200 to 450 FPM -- Board width 1 1/2" to 8" -- Board thickness: 1/2" to 1 1/2" -- Board length: minimum of 9" trough feed -- Tooling: (2) X 8", RPM 6,000 -- Spindle drive: (2) X 30 HP -- Feed wheels: (2) rows of (4) wheels on top driven by (2) 3 HP motors -- Feed rolls: (3) chromed rolls on bottom driven by (3) 2 HP motor -- Axis movement: on linear bearings

OSI End Matcher with 91" x 75' slat bed conveyor set for 3 1/4" s/n 6145

(7) Air Operated OSI Defect Saws, Pneumatic Defect Saws

PACCO - 320: Horizontal Boring Machine -- SpecificationsAir-operated horizontal stroke; 1.0 HP; 3,450 RPM motor; (1) horizontal boring spindle.Pneumatic holddown cylinder with: Solid steel bar for more holddown power and narrow parts.Pneumatic spindle movement; manual table adjustment up-and-down; foot pedal controls.1-Phase power with cord & plug; magnetic starter.

PADE UINZE 6 T CNC Copy Shaper/Sander -- (6) Heads (3 each side), 2,500 mm (98.4") max. working length, 500 mm (11.7") max. working width, 180 mm (7.1") max. working height. -- Each side equipped with: 1st & 2nd heads are for shaping only with 7.5 kW (10 HP) - 8,400 RPM motors; 3rd head is either shaping or sanding with 5 kW (6.7HP) - 3,150 RPM motors - 2,235 mm (88") long x 200 mm (7.87") abrasive belt size. Hydraulic variable table feed speed 0 - 30 MPM (0 - 82 FPM), driven by 4 kW (5.5) HP hydraulic pump motor; Overhead pneumatic clamping of work piece with (6) clamps. -- Actual model is PADE UINZE 6 T CNC.

Single End Tenoner that will handle straight or curved material. Carves round ended tenons through the use of (2) worktables which independently slide on steel rails. Tables independently adjustable for height and tilt Max width 100mm Max thickness 30mm Max Depth 50mm Table adjustment (vertical) 100mm Tilting 20^ front 15^radial Fence 45^ Spindle motor 2.25KW (3HP) (2) dust hoods Weight 960KG Dims 1320 x 1120 x 1250 mm 230 volt 3phase

PANHANS - 436, ...24'' Single Surface Planer -- Specifications24.8" (630 mm) Width x 1/8" to 10" opening; 10 HP Motor; 4-knife - 4-3/4" dia. cutterhead belt driven @ 5,000 RPM; max. cutting depth: 5/16". -- 1 HP Feed motor with: (2) Feed speeds: 22 - 44 FPM. Segmented rubber-covered infeed and outfeed rollers, sectional chip breaker, motorized raise-and-lower of bed w/LED readout, table size 43" x 21". -- Options Include: (16) Cutter knives: Power lift up & down. -- Complete with: Emergency stop;, magnetic starter w/overload protection; knife setting gauge: & 5-1/2" dia. dust hood; includes: Operations manual; parts list; tool kit.

Model P30N 600 V / 3 Ph / 60 Hz Includes Transformer

Paul AB920 Rip Saw Scanning Fenceless Infeed Infeed & Outfeed (not including decks) The machine has one fixed and 2 moving blades. The minimum distance between the moving blades is 44 mm (1.73"). The maximum distance between the moving saw blades is 210 mm (8-1/4"). The machine is designed for incoming boards with the following min./max. dimensions Length: 4' - 16' Width: 2" - 19" Ripped widths: 1.75" - 8" Thickness: 1" - 2" 480 Volt, 60 hz., 3 phase electrics 75 HP main motor Automatic edging separation after the saw Feed speed up to 300 fpm Fenceless infeed system with automatic skewing capability 16 width sensors on the infeed system

PAULSON - 6NB: 4-HeadThrough Feed MoulderSpecifications -- 4-Heads (T-L-R-B): 6" x 2" Moulder. -- 7-1/2 HP Motor on the 1st top spindle. -- 7-1/2 HP Motor on the left & right. -- 7-1/2 HP Motor on the bottom spindle.Equipped with & Features -- 3 HP Variable speed feed works with: Feed speeds from 10 - 75 FPM. -- (2) Top & (1) Bottom powered feed rolls before the 1st top head. -- All spindles: Belted from the motors; driving at 8,000 RPM, 1-1/4" dia. -- Complete with: 1/3 Misc. cutterheads shown in the photo. Comes with: All dust covers, spindle nut; electric motors; spindles; rubber feed wheels; metal feed wheels; manuals. - In good running condition. No heads.

4 Head drill station 20' with powered roll case Hydraulic set stops

Pendu Drill Machine 14’ long, up to 12” wide and 12” thick 12 drills 40” tall hydraulic pack, pedestal controls, air hold downs, hydraulic up and down Complete electrical boxes, very low usage

PHANTOM CNC SYSTEMS - T-Series ATC 48 - 4'x8' w/ATC & Vacuum Pump -- Specifications:• A full-sheet working area backed by multi-zone vacuum hold-down, a 16.1 HP automatic tool-change spindle and Delta servo motion.• Stock working sizes 4' × 8' (special sizes on request)• Spindle 16.1 HP VFD, air-cooled, automatic tool change• Tool interface ISO 30• Tool rack 8 position, linear ATC tool rack• Tool changeover approximately 8 seconds• Table Multi-zone vacuum with T-slot and gate valves• Motion Delta servo motors and drives• Gear reduction Japanese high-precision• Cutting speed Up to 500 IPM• Free speed Up to 1,000 IPM• Dust collection, Air-operated dust collection hood• Tool calibration, Automatic tool height calibration sensor• Lubrication, Automatic lubrication system• Software, Multi-software CAD/CAM compatibility• The T Series is designed to work with multiple CAD/CAM software systems rather than being tied to a single software environment.• (2) 2.2 kw (3 HP) Vacuum Pumps, 6 HP Total vacuum• Actual Model is PHANTOM CNC SYSTEMS - T-Series ATC 48

PHI IR-3 Preheater;Overall dimensions 5' wide x 4' long, consisting of: (3) IR Medium Wave heating banks, each 1" wide x 54" long, bank has gold foil quartz heating elements.This IR unit is designed to preheat the board to facilitate out gassing and help eliminate solvent pop and air bubbles in the coatings of deep pored materials such as oak. Also used to standardize board temps during colder months as well as decrease dry times of other substrates. These units are primarily (but not exclusively) designed for use before the application of stain and sealer coats. Features: Explosion proof electrics, electrical heat temperature adjustable from 100° - 150° F, variable feed speed from 8 - 30 FPM (2.5 - 9 MPM).
