Northfield For Sale

JLT CLAMPS 79F-M2-6-PC Panel and Door ClampAn Industry standard for Cabinet doors and so much more. -- (5) Levels of 6' wide x 40" deep cap. -- Heavy tubular frame with (8) clamps. -- Manually adjusted bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional clamps are available.

JLT CLAMPS 79F-8-1R Single Row Panel ClampEdge Glue and Face Glue a variety of solid wood components. Produce 10+ edge glued panels per day with a Standard Setup. -- Taylor’s Patented and Successful Clamp Arm Design Features: -- 8' Single Row Panel Clamp level. -- Free Standing Unit with 500 lbs. Weight Capacity. -- 100% Complete Tubular Steel Construction. -- Complete 3 Year WarrantyIncludes: -- (8) 3 1/2″ High jaw 40″ Clamps. -- Optional 52″ Clamps Available on Request(Photo Is a Generic of Single Row Panel Clamps)

JLT CLAMPS 79F-M2-8-PC Panel and Door Clamp. An Industry standard for Cabinet doors and so much more. -- (5) Levels of 8' wide x 40" deep cap. -- Heavy tubular frame with (18) clamps. -- Manually adjustable bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional opening clamps available.

JLT - 79K-10: Entry Panel & Door ClampVersatility: Leave the center squaring bar to do multiple doors at once or remove the bar to take advantage of the full capacity of the machine. -- Capacity for solid wood doors: 48" x 120". -- Quick release latches on the jaws; moveable squaring bar. -- Squaring mechanism can be recalibrated, if necessary. -- (2) Horizontal pneumatic clamps. -- (4) Vertical pneumatic clamps. -- 1-Lever operation. -- 1,000 Lbs Clamping force per cylinder. -- 3" Stroke from each cylinder.

JLT CLAMPS 79K-10 Panel and Door Clamp; Versatility-Leave the center squaring bar to do multiple doors at once or remove the bar to take advantage of the full capacity of the machine. -- Capacity for solid wood doors 48" x 120". -- Quick release latches on the jaws and moveable squaring bar. -- The squaring mechanism can be re-calibrated if necessary. -- (2) Horizontal pneumatic clamps. -- (4) Vertical pneumatic clamps. -- One lever operation. -- 1000 Lbs of clamping force per cylinder. -- 3" Stroke from each cylinder.Custom sizes available in 1' increments ...ask the Product Manager.

JLT CLAMPS - 79K-7-M, ...Clamp (Door, Double Miter) Large cap. Miter Door Clamp with: 38" x 84" Max. cap., (2) vertical and (2) horizontal pneumatic clamps. -- Each clamp includes: JLT Dial control system for fine adjustments. This innovative dial control system allows for adjustments in both directions while the door is under clamping pressure. -- Also, successfully clamp and square stile & rile cabinet doors.

JLT CLAMPS 79K-8-DDC CLAMP, PANEL AND DOOR.Pneumatically operated Cabinet Door Clamp to square & clamp a door in (1) Sec. -- 38" Front-to-back x 98" left-to-right clamping capacity. -- Single row 2-station Door Clamp with (2) horizontal pneumatic clamps and (6) vertical pneumatic clamps. -- Special mount on a 30° angle for ease of loading & less operator fatigue. -- (8) Large diaphragm cylinders for quick clamping pressure with single-lever operation. -- 40 PSI Air pressure to produce 500 Lbs of force on each clamp. -- Shelf to hold the pieces of the frame before pressing for all squaring components. -- 60 Sq/ft footprint.

JLT CLAMPS 79X-8-A Panel/Door Clamp 8-Section rotating machine for precise, accurate pneumatic squaring of Stile & Rail cabinet doors. -- 100% Heavy-Duty steel construction. -- Each squaring section: 26" x 62" max. cap.; 4" x 12" min. cap. -- Single Lever operation; (2) vertical & (1) horizontal pneumatic roller clamps. -- Clamps & squares a door in (2) Secs; 500 Lbs clamping force per cylinder. -- Machine rotates counterclockwise for safety; features automatic indexing stop system. -- 110 V Electric gear motor with: Variable speed AC drive control; push button activates rotation.

JLT Panel Pro Clamp Model 78D-5-S 5-Levels with (6) clamps each with panel flatner 110 v Single phase Will do 80”x 40”

JLT CLAMPS 138B Glue ApplicatorPlate type glue applicator with 8" wide x 48" long applicating capacity. -- Spreader frame is constructed of heavy perforated aluminum components. -- All glue application components such as the grid, glue pan and cover are constructed of steel. -- Foot treadle operated and the grid rises out of the reservoir of glue. -- The thickness of the glue is easily regulated by the operator. -- No daily clean-up is required, simply spray the surface of the glue with water and cover the unit for overnight storage. -- Several depressions of the foot treadle mixes the glue and can thin the glue when water is added.

JLT CLAMPS 160B-M3 Glue ApplicatorThe Door Stile spreader compliments the JLT Door Clamp for providing a quick simple method of applying glue to cabinet door stiles. -- Foot pedal operation. -- Includes: (2) Pre-cut profiles and UHMW material to produce up to 12 more profiles. -- Virtually no clean up (end of the day spray with water form the provided spray bottle and cover). Minimize potential for squeeze out. Final set up dimensions: 16"; L x 16" W x 38"; H

JLT CLAMPS 180A-M2 Pneumatic Panel Flattener. -- Complete with; Air System and Docking attachment with 40" reach and up to 2-1/2" material thickness.Additional Thickness Capacities Available (4" & 6")...add $100

JLT CLAMPS 180A-M2-52 Pneumatic Panel Flattener. -- Complete with; Air System and Docking attachment with 52" reach and up to 2-1/2" material thickness.Additional Thickness Capacities Available (4" & 6")

42” Capacity Pneumatic operation

JLT 190B-M3 Drawer Clamp. Heavy-duty Drawer and Box clamp, maximum capacity 10" H x 24" L x 36" W Specifications & Features: -- Achieve 3,000 Lbs. clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergraded pressure hold kit. -- Pneumatic foot pedal activation. -- 2- Clamp Design provides equal pressure from top to bottom. -- Horizontal aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- The vertical clamping carriage slides smoothly for horizontal width adjustments.Complete with: -- (3) Sets of pressure shoes for added strength also eliminate vertical (drawer depth) adjustments. -- (1) Set of aluminum side plates. -- (1) Lever valve pressure hold kit.

JLT 190B-M3-48 Drawer Clamp. Heavy-duty Drawer and Box clamp, maximum capacity 12" H x 24" L x 48" W -- Achieve 3,000 Lbs. clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergraded pressure hold kit. -- Pneumatic foot pedal activation. -- (2) Clamp Design provides equal pressure from top to bottom. -- Horizontal aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- Vertical clamping carriage slides smoothly for horizontal width adjustments. -- (3) Sets of pressure shoes for added strength also eliminates vertical (drawer depth) adjustments. -- (1) Set of aluminum side plates. -- (1) Lever valve pressure hold kit.

JLT CLAMPS 190C-M2 Drawer Clamp Heavy-duty Upper Box and Case Clamp, maximum capacity 12" H x 48" L x 48" W -- Achieve 3,500 Lbs clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergrated pressure hold kit. -- Pneumatic foot pedal activation. -- (4) Clamp Design provides equal pressure from top to bottom. -- Horizontial aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- Vertical clamping carriage slides smoothly for horizontial width adjustments. -- (5) Sets of pressure shoes for added strength also eliminates vertical (drawer depth) adjustments. -- Includes: (1) Set of aluminum side plates, (1) lever valve pressure hold kit.

Cuts with a 16" carbide tipped saw blade 240V/480V 3 phase 7-10 seconds per cycle

(2)Jones Superior Machine No 54T Band Saws

- Gold-Anodized Heating Platens (Extremely Resistant to Scratches & Abrasions) - Dynamic Piston Bearing - Multiple Heating Options: Electric / Hot Water / Thermal Oil - Electronic Temperature Control Systems Basic 70 - Pressing surface 2500 x 1250 mm - Total pressing force 700 kN - Daylight opening max 350 mm - Number of daylights 1 piece - Number of cylinders 4 piece - Diameter of cylinders 80 mm - Spec. pressure at full capacity 2,2 daN/cm2 - Spec. pressure at 2 m2 capacity 3,5daN/cm2 - Operating pressure 350 bar - Required power 1,1kW - Closing time 13 approx. sec. with electric heating platens: - Connected load approx. 18 kW - Heating time to 90°C 16 min. - Hourly consumption with 4 min 4,0 approx. kW/h - pressing time per m2 pressing - material Basic dimensions: - Overall length 2900 mm - Overall width 1450 mm - Overall height 2030 mm - Weight 2950 kg https://img1.wsimg.com/blobby/go/f551bfb5-f644-4017-9e4a-bd2a85fa653d/downloads/Basic-Press.pdf
