Band Resaws For Sale

CAM-WOOD BX-1212BEEX Single Bottom Head Band Resaw.Can be used to cut boards, cants, or reclaim slabs; Specifications: -- Can process up to 12" H x 12" W; 5/16" - 5-1/4" from blade to conveyor. -- 2 HP Electric motor controlled variable speed from 12 - 80 FPM. -- This Model BX-1212BEE is equipped with: -- 20 HP Saw Motor, 28" x 1" band wheels, 168" x 1" band saw blade (not included). Features: -- Hand-wheel blade tensioning; manual elevation adjustment; 2 HP hydraulic system pump motor. Complete with: -- Spring-loaded steel and rubber upper-pressure rolls; 11" X 215" conveyor belt.

CAM-WOOD BX-1212HR-1 Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; Specifications: -- Max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; -- VFD controlled variable speed from 0 - 60 FPM. Equipped with: -- 20 HP Saw Motor, 24" x 2" dynamically balanced cast iron band wheels, 184" x 1" to 1-1/2" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 10-5/8" x 165-1/2" infeed conveyor from 0° - 30° with side support for bevel cutting; 3 HP drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor.Complete with: -- Programmable Digital Controller for convenient and accurate thickness setting; -- 1/4 HP Blade elevation motor moves blade and saw head; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR Single-Head Band Resaw w/Return ConveyorCan be used to cut boards, cants, or reclaim slabs; max. working height up to 16" under pressure roller x 16-1/2" Widths; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 60 ft./min.Equipped with: -- 30 HP Saw Motor, 32" x 2" dynamically balanced cast iron band wheels, 230-1/4" x 2" - 4" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- 3 HP Frequency Drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor; a side support is applied for safe and stable cutting operations.Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-2410HR Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; max. working height up to 10" H under pressure roller x 24" W; 5/32" - 10" between blade and conveyor; VFD controlled variable speed from 0 - 82 FPM.Equipped with: -- 30 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 195-1/2" x 2-1/8" x 3/64" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 23" x 215" infeed conveyor from 0° - 30° with side support for bevel cutting; hydraulic infeed and outfeed conveyor drive motor; variable feed speed 0 - 82 FPM; return gravity roller conveyor. -- Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR-TN Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 16" H under pressure roller x 16" W; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 30 HP Saw Motor (each head), 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; 1/2 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1212-HR-TNX Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 20 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; -- Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; -- 1/2 HP Blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by a gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

Cantek Horizontal Resaw Great Condition Very Low Hours Voltage 230/480/3

CANTEK HB-800 32" Vertical Band Resaw32" Wheel diameter, 20 HP motor Vertical Band Saw;Specifications: -- 3.543" (90 mm) wheel width, 30-5/8" throat capacity, 15-3/8" under guide capacity. -- 4" Blade width X 216- 217-1/8" blade length. -- 20 HP main motor, generates a blade speed of 5,024 SFPM.Features: -- Heavy fabricated steel machine frame. -- Specially designed Bakelite guide blocks provide rigid side blade support for straight cutting. -- Large cast iron work table is precision ground & can tilt to a maximum of 45°. -- Convenient blade tension adjustment by means of a handwheel and gauge. -- Cast iron upper and lower saw wheels are precision machined and dynamically balanced. -- Rack & pinion blade guide adjustment. -- Wheel is crowned for proper blade tracking & added stability of the blade.Complete with: -- Foot brake for braking wheels & blade. -- Blade lubrication system and reservoir for lubricant keeps blades cool.Including Electrics to UL/CSA - all starters -- Auto Start-Delta control for main motor with Emergency Stop Switch -- Telemecanique brand magnetic switchHF-150A Feeder: -- 1 HP motor with variable feed speed from 16 - 66 FPM; 6" feed opening. -- Pneumatic tensioned feed roller. -- Feed pressure is adjustable. -- Feed roller opening & closing is controlled by a foot switch for operator convenience. -- Knurled steel roller.

3 phase/230 volt

4- Head customer built resaw 6" Wide belt Hydraulic hold down rollers 15 HP Motors on each head Pneumatic tension

DANCKAERT - 44 , ...ResawAir Strain 44"; x 5"; Bandsaw.Features & Specifications: -- McDONOUGH Center Split Feed Works. -- Wheel is supported on both sides - not cantilevered. -- Pressured guides. -- McDONOUGH Infeed Rolls. -- Max. Cut: 14";. -- New Dynamic brake. -- 60 & 100 HP. -- Control Cabinet (has battery backup and resistors to prevent spikes). -- Infeed & outfeed systems are the same. -- 24 ft. Long Camel Back chain (has air bags that are controlled by photo cell to raise & lower and index 1-board at a time). -- Max. length of lumber: 24 ft.From Seller: "The machine has a new VFDD 100 HP and a new WEG Severe Service 60 HP motor. All new hydraulic motors, caramel back chain, and roll cases."NOTE: Needs hydraulic unit.

Farano Line Bar Resaw Machine# SR-15773 Model# BS-72

Forestor 900 Resaw 4" Blades Powered Infeed

G Tek Single Head Grade Band Resaw With Complete Run Around System, Cab and Set works, 5 Way Seperator. Just about the Same as a Brewco B-1600. Additional Pictures available on Request

Go Fast Single Head Resaw

Go Fast 5-Head Resaw Unit was cut into two pieces and can be put back together with a weld in the middle. Approx layout is 31' x 8'

Go Fast Resaw 15 HP Motor Put under power to test, never put into production.

6x8 Resaw - ¼” – 6” Tall Cut Height, 8” Wide, Unlimited Length Capacity - 4” Dust Connection (No dust collector required) - Heavy Duty 2-7/16” Blade Arbors and Bearings - 20” Band Wheels - Air Tensioned Blade Mechanism - Operator Return Table - Self- contained Hydraulic System: Adjustable Infeed Speed (0-150 ft/ min) - Easy Crank for Adjustable Blade Position - 3” Right Side Fences - Feed Belt Height: 34” -Dimensions: 84” L, 90” W, 48” H - Approx. Weight: 1400 lbs 6x8 Slave Resaw - ¼” – 6” Tall Cut Height, 8” Wide, Unlimited Length Capacity - 4” Dust Connection (No dust collector required) - Heavy Duty 2-7/16” Blade Arbors and Bearings - 20” Band Wheels - Air Tensioned Blade Mechanism - Self- contained Hydraulic System Runs off First Saw - Easy Crank for Adjustable Blade Position - 3” Right Side Fences - Feed Belt Height: 34” -Dimensions: 60” L, 90” W, 48” H - Approx. Weight: 1340 lbs - (2) 10 HP Motors (220/1/60 TEFC) 2 HEAD Resaw Control Panel - 220V Line Voltage (Single Phase) - 16" Tall X 16" Wide Enclosure (UL Type 1,3R,4,12) - 120V Control Voltage - Service disconnect in panel door - (2) 10HP 220V Motor starters, breaker w/OL - (2) Start/ Stop buttons for each motor w/ legend plates (Head 1, Head 2) - (1) Emergency Stop Button w/ legend plate- Completely for 220V, Pre-wired Motor Starters with Start/ Stop Buttons and Circuit Overload Protection 5' Roller Case Section with Adjustable Legs - 16ga Rollers - 2 Leg Sets with Braces - Height Adjustable from 26" to 32" - Galvanized Finish (Not Painted)

Single Head Horizontal Band Re-saw System Model : HP-11P-SMART • Single saw head configuration. • Motor powered set works for accurate saw wheel elevation. • Digital position controller permits accurate saw wheel height positioning. • Automatic blade tension is controlled by hydraulic cylinder. • Variable feed speed by hydraulic motor drive. • The big pressure roller is air cylinder loaded to hold wood down firmly. Specifications HP- 11P-SMART 1. Saves Time and labor costs 2. Pneumatic pressure roller infeed 3. Digital position controller permits accurate saw wheel height 4. Easy to operate and set up Feed speed: 4-27m/min (13-90FPM) Max. cutting height: 250mm (10”) Max. cutting width: 300mm (11 3/4”) Min. workpiece length: 400mm; 205mm with extension set Max. workpiece length: 580mm Distance from blade to conveyor: 4-125mm Saw wheel Diameter: 711.5mm (28”) Saw wheel width: 22.7mm (1”) Saw blade size: 4265 x 27mm (168” x 1’) Blade speed: 2816m/min (9240FPM) Saw Motor: 15kW(20HP) Feed unit: 0.75kW(2HP) gearbox motor with frequency converter Cooling system Oil mist Blade tensioning Hydraulic system Motor for blade positioning: 0.18kW(1/4HP) Dust post: Ø4” x 4 Table height: 902.5mm Machine weight: 951kgs Machine dimensions: 2835 x 2052 x 1678mm (LxWxH)

High Point 12" Resaw with Return Conveyor
