Routers For Sale

AXYZ Panel Builder 5018 CNC Router

Bacci Artist Jet 6-Axes Machining Centre CNC - Installed New in 2019Description: Bacci, 6 Axis, ARTIST JET CNC Machining Centre with twin shuttle tables specially configured for clamping and cutting solid wood furniture parts.Specifications: X = 3,500 mm (pass through distance between the columns is 3,050mm) Y = 2,200 mm Z = 830 mm B = unlimited C = 400° (+/-200°) Rotating revolver head with two (2) 10Hp, double ended electro-spindles, ER32 tool connections, ceramic bearings, 24,000 maximum RPM provides fast 4-tool action Two (2) Electronic Inverters to independently control the spindle's rotation speed up to 24,000RPM Two (2) “TGV"; type working tables (Paolino Bacci patent), each table with three (3) 750mm long steel rails, adjustable center to center (C/C) distance up to 1,170mm The support surface for each table is 1,170mm x 750mm Semi-Automatic X-Axis positioning of the “TGV"; rails is included Eight (8) Pneumatic Clamping Cylinders, sliding on the sides of the “TGV"; rails The Artist/Jet is prepared for vacuum Clamping One (1) 100m3/h vacuum pumps is included Six (6) removable, frontal Free-Jig clamps Factory electrical parts upgraded for 2021 CSA electrical compliance.

Baileigh WR-84V, 220V 1 Ph, 7.5HP CNC ROUTING TABLE with Cyclone DC2100C Dust Collector 3hp Shipping Weight 3000lbs Actual Working Area 97" x 48" Spindle 7.4hp Z Axis Stroke 5.375" Maximum Moving Speed (Inches Per Minute) 590 Maximum Engraving Speed (Inches Per Minute) 590 Reposition Accuracy 0.0019 Tool Diameters ER32 Power 220V Single Phase Length 118" Width 78" Height 65" Weight (lbs) 2500 Table Style T-Slot with Vacuum Option 4x8' Table w/ Perfect for solid wood processing, making closet doors, furniture, signs, and much more. 0 to 18,000 rpm variable spindle speed range. 7.4 hp spindle has the power to cut hardwoods quickly and precisely. Spindle is air-cooled to prevent overheating, prolong the machine’s lifespan, keep it producing high-quality cuts. 15,000 mm per minute maximum engraving or travel speed. Solid steel gantry can tackle hardwoods at high speeds without flinching. Stepper motors with square rails ensure smooth movement along the X, Y, and Z axes. Use the handheld digital controller to move the spindle, adjust the speed, and go through your design. Comes standard with software that allows you to set up almost any kind of design. (Details below.) Upload your cut pattern to the table with a USB drive. Rack and pinion mechanism holds up over long periods of heavy use and allows for more fluid and precise movement than a ball and screw mechanism. 4 collets accept any standard tooling profiles with ?”, ¼”, 3/8", and ½” bit sizes. Includes 10 different tooling profiles. Steel T-clamps hold the material down on the table to reduce vibrations and prevent errors. Table is pre-plummed 4 vacuum zones, each with a separate valve and handle, ready to accept optional 7hp vacuum pump. Extremely rigid steel structure reduces vibrations and helps the table stay accurate for years. Dust shroud covers the spindle and vacuums out sawdust and wood chips while you’re cutting.

Has Cyclone DC2100C Dust Collector 3hp 220V Single Phase Table Style T-Slot with Vacuum Option 4x8' Table w/ Perfect for solid wood processing, making closet doors, furniture, signs, and much more. 7.4 hp spindle has the power to cut hardwoods quickly and precisely. Handheld digital controller to move the spindle, adjust the speed, and go through your design. Comes standard with software that allows you to set up almost any kind of design. Rack and pinion mechanism holds up over long periods of heavy use and allows for more fluid and precise movement

Biesse Rover C 9.65 CNC Router Vacuum Pumps Still under power for inspection

Biesse Rover B Edge semi automatic pod setting 4 coil magazine vertical and horizontal drill bank main spindle with U axis Milling X1: 5055 mm Y1: 1600 mm Edgebanding X2: 4100 mm Y2: 1600 mm Milling Module H74 - Z1: 245 mm Module H29 - Z2: 290 mm

2007 Biesse Rover B 7.40 R FTK - 61.22" (routing) - 75" (drilling) - Working field of machine in Z-axis - 5.9" X-axis stroke - 157.87" Y- axis stroke - 77.16" Z-axis stroke - 6.23" 61.22" x 145"

BIESSE ROVER B 4.40 FT FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications:4' x 10' Flat Table with "Matrix" grid phenolic surface for "Nested Base Manufacturing". -- Working cap:"X" Axis 126" (3,200 mm), "Y" axis 53.5" (1,360 mm), "Z" axis stroke is 6.3" (160 mm), max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ball screw on "Y" & "Z" axis. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing", (2) independent working areas; (4) external pop-up reference pins with (3) on the back of the table & (1) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit: (1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (12) independent vertical spindles, (6) in "X" axis & (6) in "Y" axis.(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) 120 mm dia "X" axis grooving saw. -- Machining:(1) 10.2 HP (7.5 kW) Electro-spindle with ISO 30 adaptor, variable speed from 1,000 - 20,000 RPM;(1) 10-Position ride along tool changer for "on the fly" ATC. -- Operator Interface: PC Front End with Biesse "XP600 + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with: Universal Auto-Transformer for voltages between 200-600 V, 50/60 HZ; (2) 10 HP, (7.5 kW) BUSCH Vacuum Pumps; safety mats & fencing. -- Actual Model is BIESSE ROVER B 4.40 FT.

BIESSE ROVER K 1531 FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 10' "Bridge Gantry" machine with "Phenolic Matrix Grid" table. -- Working Capacity: "X" Axis 122" (3,100 mm), "Y" axis 61.4" (1,560 mm), "Z" axis stroke is 12.5" (320 mm), max. material thickness 6.69" (170 mm). -- Positioning Speed:"X" & "Y" axis 82 FPM (25 MPM), "Z" axis 82 FPM (25 MPM); "X" & "Y" axes use a precision rack & pinion system, "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital brushless AC Servo motors; All motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with "Phenolic Matrix Grid" worktable that allows for automatic locking using T slots or possible vacuum locking (requires a vacuum pump). The machine has 1 working area with 2 left + 1 front & 1 rear origins, (2) reference pin stops for rear LH area, (3) reference pin stops for front LH area &(2) reference pin for side stops (LH side) -- Boring Unit:"BH 10" boring head, (1) 2.5 HP (1.7 kW) - 2,800 - 6,000 RPM variable speed motor; (5) independent vertical spindles in "X" axis & (5) independent Vertical spindles in "Y" axis. -- Machining:(1) 12 HP (9 kW) Air cooled "HSD" Electro-spindle with HSK F63 adaptor, variable speed from 1,000 - 24,000 RPM.(1) 10-Position ATC tool rack mounted on the end of the machine; NC controlled digital presetting device for the measurement of the tool length. -- Operator Interface:PC Front End with: Biesse "BH 660" + "BiesseWorks" + WINDOWS "WRT" (Windows Real Time) operating system;Intel Core I7 CPU, 8 GB RAM memory, 128 SSD GB hard disk, Dedicated graphic card, DVD burner, USB ports.21.5" LCD Flat screen monitor; full keyboard & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWorks graphic interface with assisted graphic editor used to program machining operations; parametric programming and guided creation of parametric macros Import of CAD and other external software files in DXF and CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(2) "Becker H360/1428" 300 m³/Hr vacuum pumps, Automatic program update according to the tool length touch-off probe. Automatic Lubrication system for linear guides, pads and re-circulating ball screw. Universal Auto-Transformer for voltages between 200-600 V, 50/60 Hz. Hand-held control Pendent.NCE safety system for stand-alone machine with 3 sides access with 4 sides light barriers & Anti-climb over extension on the right side of the base-frame -- Actual Model is BIESSE ROVER K 1531 FT

--This machine is in an Auction on exfactoryauctions.com--NO RESERVE-- (2 Available) BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since! Specifications: Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. Working Capacity: "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31"). Work Table: Left-hand infeed & Right-hand outfeed, Each with 20-1/2” x 66” x 35-1/2” H infeed & outfeed areas with Fixed caster-type conveyor rails. Positioning Speed: "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM). Boring Units: (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91"). Machining: (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets. Operator & Machine Control: Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. Pedestal & Pendant controls. Equipped with: Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat. Complete with: 7’ x 9’ x 35-1/2” H Infeed Table, with Rails & Pusher. 6-1/2’ x 8’ x 35-1/2” H Outfeed Table, with Transfer Belts. Handheld Bar Code Reader. Dust Manifold. Dimensions including Safety Fence: 307" x 184" x 98" H.

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications:4' x 10' "Matrix" grid phenolic surface table for "Nested Base Manufacturing". -- Working cap.:X-Axis is 122" (3,100 mm), Y-axis 49.2" (1,250 mm), Z-axis stroke is 9.8" (250 mm).Max. material thickness of 6.1" (155 mm). -- Positioning Speed:X- & Y-Axis is 328 FPM (100 MPM), Z-axis 98 FPM (30 MPM).X-Axis uses a helical rack & pinion system, "Y- & Z-axis use precision ball screws.All axes movement is on precision linear guides/ways & controlled by digital, brushless AC Servo motors.All motion components are maintained by a lubrication system. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.External pop-up reference pins: Reference pins are adjustable & can be placed on the front of the table, on the back of the table, on the RH side & on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts.Each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) Independent vertical spindles, (7) in X-axis & (7) in Y-axis.(6) Horizontal spindles with: (2 + 2) in X-axis & (1 + 1) in Y-axis; (1) X-axis grooving saw for max. 120 mm dia. blade.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 10.2 HP (7.6 kW) Electrospindle Router, variable speed from 1,000 - 20,000 RPM. -- Operator & Machine Control:PC Front End with: NC 1000 + WINDOWS "NT" operating system; 15" color CRT display.40 GB Hard drive; floppy & CD drives; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:Manuals, documents, and safety perimeter devices.NOTE: No Vacuum Pump included with this machine.

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" grid phenolic surface table for "Nested Base Manufacturing". -- Working Cap."X" Axis is 122" (3,100 mm), "Y" axis 49.2" (1,250 mm), "Z" axis stroke is 9.8" (250 mm).Max. material thickness of 6.1" (155 mm). -- Positioning Speed:"X" & "Y" Axis is 328 FPM (100 MPM), "Z" axis 98 FPM (30 MPM)."X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides / ways & controlled by digital, brushless AC Servo motors.All motion components are maintained by a lubrication system. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(4) External pop-up reference pins: Reference pins are adjustable & can be placed on the front of the table, on the back of the table, on the RH side & on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts,Each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) Independent vertical spindles, (7) in "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2+2) in "X" axis & (1+1) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia blade.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 10.2 HP (7.6 kW) Electro-spindle Router, variable speed from 1,000 - 20,000 RPM; -- Operator & Machine Control:PC Front End with: NC 1000" + WINDOWS "NT" operating system; 15" color CRT display.40 GB Hard drive; floppy & CD drives; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:Universal Auto-Transformer for voltages between 200 - 600 V, 50/60 Hz.; Manuals, documents & safety perimeter devices. -- Actual Model is BIESSE ROVER 24 FTS.NOTE: The Vacuum Pump is NOT Included with this machine

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 4' x 10' Flat table design for "Nested Base" processing: Working cap.: X-Axis is 122" (3,100 mm), Y-axis is 49" (1,250 mm), Z-axis is 6.1" (155 mm). -- Worktable:Phenolic "MATRIX" grid vacuum table for FT "Nesting" or single part processing using (optional) pods or jigs; (2) side & (4) rear pop-up pins for easy material location. -- Positioning Speed:X- & Y-axis 262 FPM (80 MPM), Z-axis 98 FPM (30 MPM); "X-axis uses a helical rack & pinion system, Y- & Z-axis use precision ball screws; all axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Boring Unit:(1) 4 HP (3.3 kW) - 4,000 RPM motor: (14) independent vertical spindles, (7) in X-axis & (7) in Y-axis; (6) horizontal drills with (2 + 2) in X-axis & (1 + 1) in Y-axis. -- Machining:(1) 16 HP (12 kW) Liquid-cooled vertically mounted HSD electro-spindle router with HSK F63 adaptor, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM; (1) 6-position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Operator & Machine Control:PC Front End with: BIESSE "XP600 + WINDOWS" XP-operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities; programs can be transferred via diskette or downloaded by wire; built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with: 11 KVA Stabilized autotransformer for voltages between 220 - 600 V; automatic "forced" lubrication system for guides & ball screw; emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on; sound absorbing protective head enclosure with debris curtain around bottom edge. -- NO Vacuum Pump is included but let us know if needed we can source a good used unit.

BIESSE KLEVER 1224 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 8' "Bridge Gantry" Machine with "Aluminum" worktable allows: Automatic locking using T-slots or possible vacuum locking (requires a vacuum pump). -- Working Capacity:"X" Axis 98.8" (2,511 mm); "Y" axis 49.2" (1,250 mm); "Z" axis stroke is 10.2" (260 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" Axis 74 FPM (23 MPM); "Z" axis 41 FPM (13 MPM); "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with "Aluminum" worktable that allows for automatic locking using T-slots or possible vacuum locking (requires a vacuum pump). (3 + 3) Manual flip reference stops in "Y" axis & (2) reference stops in "X" axis. -- Machining:(1) 12 HP (8.9 kW) Air-cooled "HSD" Electro-spindle with: ISO 30 Adaptor, variable speed from 1,000 - 24,000 RPM.(1) 6-Position tool rack; NC controlled digital presetting device for the measurement of the tool length. -- Operator & Machine Control:PC Front End with: BIESSE "BH 660" + "BiesseWorks" + WINDOWS "WRT" Operating System; 19" TFT flat-screen monitor; server, full keyboard & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWorks graphic interface with: Assisted graphic editor used to program machining operations, parametric programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF and CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 10 HP (7.5 kW), 250 m³/Hr "BUSCH" vacuum pump; Tool Measuring Touch-Off Probe; safety fencing; automatic program update according to the tool length; automatic lubrication system for linear guides, pads and recirculating ball screw.; Universal Autotransformer for voltages between 200 - 600 V, 50/60 Hz. -- Options Include: NC Controlled automatic division of vacuum area according to the program. -- Actual Model is: BIESSE KLEVER 1224 G FT

BIESSE ROVER 24 FST FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" Grid phenolic surface table for "Nested Base Manufacturing". -- Working Cap.:"X" Axis is 122" (3,100 mm), "Y" axis 49.2" (1,250 mm), and "Z" axis stroke is 9.8" (250 mm); max. material thickness of 6.1" (155 mm). -- Positioning Speed:"X" & "Y" Axis is 328 FPM (100 MPM), Z-axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(14) External pop-up reference pins with: (6) Pins on the front of the table, (4) on the back of the table, (2) on the RH side, (2) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) independent vertical spindles: (7) In "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 2019 - 10.2 HP (7.6 kW) Air-cooled electro-spindle with HSK F63 adaptor; variable speed from 1,000 - 24,000 RPM. -- Operator & Machine Control:PC Front-End with: NC 1000" + WINDOWS "NT" Operating System; 17" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(1) 2014 - BECKER 250 CBM/Hr Vacuum Pump; Universal Autotransformer for voltages between 200 - 600 V, 50/60 Hz.; manuals, documents, safety mats & fencing. -- Actual Model is: BIESSE ROVER 24 FTS.

BIESSE SKILL G FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 12' "Matrix" Grid phenolic surface for "Nested Base Manufacturing". -- Working Capacity:"X" Axis 148.2" (3,765 mm); "Y" axis 61.4" (1,560 mm); "Z" axis stroke is 12.7" (324 mm); max. material thickness 4.7" (119 mm). -- Positioning Speed:"X" & "Y" Axis 197 FPM (60 MPM); "Z" axis 65.6 FPM (20 MPM)."X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing".(5) External pneumatic pop-up stops for piece positioning at (4) corners of workstations; automatic NC controlled 8-zone vacuum table.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2-1/2 HP (1.7 kW) Motor; variable speed up to 6,000 RPM; Boring unit with: (10) Independent vertical spindles; (7) in "X" axis & (3) in "Y" axis. -- Machining:(1) 16 HP (12 kW) Air-Cooled "HSD" Electro-spindle with: HSK F63 Adaptor; RH & LH rotation; variable speed from 1,000 - 24,000 RPM.(1) 12-Position ride along tool changer for "on the fly" ATC. NC Controlled tool presetting for the measurement of the tool length -- Operator & Machine Control:PC Front-End with: BIESSE "BH 660" + "BiesseWORKS + "WINDOWS "WRT" (Windows Real Time) Operating System'19" LCD Flat screen monitor; Server; full keyboard & mouse all mounted on a mobile cart.Intel(R) Core i CPU; 8 GB RAM memory; 500 GB (SSHD) hard disk; dedicated graphic card; DVD reader; USB ports; Ethernet card for network connection capabilities. -- Complete with:(1) 300 m³/Hr Vacuum Pump; air-conditioned control cabinet; automatic program update according to the tool length.Automatic Lubrication system for linear guides, pads, and recirculating ball screw; universal autotransformer for voltages between 200 - 600 V, 50 / 60 Hz; teleservice capabilities; perimeter safety mats; manuals & documents on CD. -- Options Include:Prearrangement for a "C" axis at a later date. -- Actual Model is BIESSE SKILL 1536 G FT.

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". -- Working Capacity: "X" Axis 122 (3,100 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing";Automatic NC controlled zoning of the vacuum table with (9) individual zones.(2) Pneumatic "side" pop-up reference stops, (4) pneumatic "back" pop-up reference stops, & (6) pneumatic "front" pop-up reference stops.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis;(1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 20,000 RPM.(1) 8-position ATC tool changer plate located at the back of the machine base;NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE XP 660 + BiesseWORKS + WINDOWS WRT operating system;17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 900 m³/Hr Vacuum Pump; Safety mats & fencing; Tool touch-off probe for automatic program update according to the tool length;Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: (1) NC Controlled infeed Scissor Lift table with vacuum loading; (1) Rake system; (1) NC controlled & powered belt outfeed table with vacuum sweeping system; (1) Additional NC controlled powered belt outfeed table; Bar code label printer. -- Actual Model is BIESSE ROVER A 2231 G FT

BIESSE ROVER K 1531 FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 10' "Bridge Gantry" machine with "Phenolic Matrix Grid" table. -- Working Capacity: "X" Axis 122" (3,100 mm), "Y" axis 61.4" (1,560 mm), "Z" axis stroke is 12.5" (320 mm), max. material thickness 6.69" (170 mm). -- Positioning Speed:"X" & "Y" axis 82 FPM (25 MPM), "Z" axis 82 FPM (25 MPM); "X" & "Y" axes use a precision rack & pinion system, "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital brushless AC Servo motors; All motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with "Phenolic Matrix Grid" with built in push off device with dust collection flange to sweep the cut parts and vacuum the table simultaneously.Automatic segmented vacuum table with eight (8) auto-controlled zones based on panel size.The machine has (2) reference pin stops for LH area, (1) reference pin stops for front LH area & (2) reference pin stops for RH area), (1) reference pin stops for front RH area -- Boring Unit:"BH 10" boring head, (1) 2.5 HP (1.7 kW) - 2,800 - 6,000 RPM variable speed motor; (5) independent vertical spindles in "X" axis & (5) independent Vertical spindles in "Y" axis. -- Machining:(1) 12 HP (9 kW) Air cooled "HSD" Electro-spindle with HSK F63 adaptor, variable speed from 1,000 - 24,000 RPM.Blowing unit with 4 ring nozzle at router tool to improve cut quality and improve dust collection.(1) 10-Position ATC tool rack mounted on the end of the machine; NC controlled digital presetting device for the measurement of the tool length. -- Operator Interface:PC Front End with: Biesse "BH 660" + "BiesseWorks" + WINDOWS "WRT" (Windows Real Time) operating system;Intel Core I7 CPU, 8 GB RAM memory, 128 SSD GB hard disk, Dedicated graphic card, DVD burner, USB ports.21.5" LCD Flat screen monitor; full keyboard & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWorks graphic interface with assisted graphic editor used to program machining operations; parametric programming and guided creation of parametric macros Import of CAD and other external software files in DXF and CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 300 m³/Hr vacuum pump. Hand held control keyboard. Automatic program update according to the tool length touch-off probe. Automatic Lubrication system for linear guides, pads and re-circulating ball screw. Universal Auto-Transformer for voltages between 200-600 V, 50/60 Hz. Hand-held control Pendent. Pre-arranged for "C" axis- 4th axis. NCE safety system for stand-alone machine with 3 sides access with 4 sides light barriers & Anti-climb over extension on the right side of the base-frame -- Actual Model is BIESSE ROVER K 1531 FT

BIESSE KLEVER 1530 G FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 10' "Bridge Gantry" machine with: "Aluminum "T"-Slot" table allows for Clamp Fixtures, or Vacuum Locking (requires a vacuum pump). -- Working Capacity: "X" Axis 120" (3,050 mm); "Y" axis 60" (1,550 mm); "Z" axis stroke is 10.2" (260 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" Axis 74 FPM (23 MPM); "Z" axis 41 FPM (13 MPM); "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws.All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Area:Flat table design with: "Aluminum" worktable that allows for automatic locking using T slots or possible vacuum locking (requires a vacuum pump)NOTE: Optional Vacuum Pump is included. -- (3 + 3) Manual flip reference stops in "Y" axis & (2) reference stops in "X" axis. -- Boring Unit:"BH 5" Boring head; (1) 2.5 HP (1.7 kW) - 4,000 RPM motor; (5) independent vertical spindles in "X" axis. -- Machining:(1) 12 HP (8.9 kW) Air-cooled HSD Electro-spindle with ISO 30 adaptor; variable speed from 1,000 - 24,000 RPM.(1) 7-Position tool rack; NC controlled digital presetting device for the measurement of the tool length. -- Operator Interface:PC Front-End with: BIESSE "BH 660" + "BiesseWorks" + Windows "WRT" Operating System;19" TFT flat screen monitor; Server, full keyboard & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWorks Graphic interface with: Assisted graphic editor used to program machining operations, parametric programming and guided creation of parametric macros.Import of CAD and other external software files in DXF and CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 10 HP (7.5 kW), 250 m³/Hr BECKER Vacuum Pump, automatic program update according to the tool length; Automatic Lubrication system for linear guides, pads and recirculating ball screw.; Handheld Pendant control: Universal Autotransformer for voltages between 200 - 600 V, 50 / 60 Hz. -- Actual Model is BIESSE KLEVER 1530 G FT

BUSELLATO JET 3006 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" grid phenolic surface table for "Nested Based Manufacturing". -- Working cap.:"X" Axis is 121.2" (3,080 mm), "Y" axis is 49.2" (1,250 mm), "Z" axis stroke is 8.1" (205 mm); max. panel thickness is 5.9" (140 mm); -- Positioning Speed:Max. programmable speed: "X" & "Y" axis is 328 FPM (100 MPM), "Z" axis is 111 FPM (34 MPM). -- Work Table:(2) independent working areas with locating stop pins on the front & rear - LH & RH sides for positioning of parts on the worktable; prepared for (optional) elevated pods that allow profile & horizontal machining. -- Boring Unit:(16) Independent vertical boring spindles with (8) spindles in "X" axis & (8) spindles in "Y" axis, (4) horizontal spindles with (1+1) spindle in "X" axis & (1+1) in "Y" axis; 120 mm "X" axis grooving saw; inverter controlled variable spindle speed up to 4,000 RPM. -- Machining:(1) 14 HP (10 kW) Vertical electro-spindle router with HSK-F63 adaptor, inverter driven 1,000 - 24,000 RPM with max. torque from 12,000 - 24,000 RPM;(1) 10-position "Ride Along" automatic rotary tool changer for "on-the-fly" ATC. -- Operator & Machine Control:"PC" Front-End with "GENESIS" + Windows '95, '98 & NT operating system; 32-bit Pentium - 400 MHz processor; 4 GB hard drive,15" Color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port and (1) 1.44 MB floppy disk drive.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible;built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- GENESIS Operating system for real-time multitask processing; programs can be transferred via diskette or downloaded by wire; -- Complete with:(1) 25 HP Dekker V-max vacuum pump, automatic "forced" lubrication system for guides & ball screw; emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on; sound absorbing protective head enclosure with debris curtain around bottom edge. built-in 1,500 W air conditioner for constant temperature & dust-free environment - Complies with CE norm specifications. -- Actual Model is BUSELLATO JET 3006 RT
