Woodworking Equipment For Sale

FELDER FORMAT4 PROFIT H08 FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications5' x 10' "MATRIX" Phenolic Flat Table design for: "Nested Base" Manufacturing. -- Working Capacity"X" Axis is 121.6" (3,090 mm); "Y" axis is 60.2" (1,530 mm);"Z" axis stroke is 11.8" (300 mm); max. material thickness is 4.3" (110 mm). -- Positioning Speed"X" & "Y" Axis at 197 FPM (60 MPM); "Z" axis is 49 FPM (15 MPM). -- WorktableThe working area is subdivided into (8) vacuum fields (H08 16.31) to ensure the best holding force for the most varied board sizes.The vacuum fields are controlled manually by means of: Hand levers on the front side of the machine. Prepared for (optional) elevated pods: Allows profile & horizontal machining. -- Boring Unit(1) DH 8-Spindle Vertical Drill block on 32 mm centers. -- Machining(1) 13.4 HP (10 kW) Vertically mounted electrospindle Router with: HSK F63 Adaptor; inverter driven 1,000 - 24,000 RPM; max. torque from 12,000 RPM.(1) 15-Position ATC Tool Rack: Mounted at the end of the machine. -- Operator & Machine ControlPC Based user-friendly; icon driven control housed on the: Main machine base + "WOODFLASH" Operating System. -- Complete with:(2) 250 cbm/Hr Vacuum pumps; handheld terminal with: Potentiometer & emergency stop; automatic measuring system of the tool length.Sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Options Include: Automatic unloading unit with: Electromotive offloading pusher. This addition allows finished workpieces to be automatically pushed off the table after processing: Reducing manual handling & speeding up production cycles. -- Actual model: FELDER FORMAT4 - PROFIT H08 16.31

FELDER - G-330: Edgebander0.4 - 3 mm Edge thickness cap.; 40 mm panel thickness; 3" min. width; 4-3/4" min. panel length.Equipped with: -- Quickmelt TEFLON coated glue pot for granular hot-melt adhesive. -- Heavy-Duty Guillotine: Up to 3 mm thick PVC. -- Integrated Operator PLC controls and an LCD display. -- "Anti-slip" rubberized surface chain pads.Workstations -- Single motor; Double Blade End Trim with: HF Motor; 12,000 RPM. -- Top & Bottom Flush/Bevel Trim: Bevels 0° - 15°; 1/2 HP motor - 12,000 RPM each. -- Open space at outfeed. -- Single feed speed: 26 FPM.Complete with: -- Sound & Safety enclosure over trim stations; outrigger panel support; used tooling.NOTE: Seller states that the equipment has less than (500) hours of use!

FELDER FORMAT4 - Profit H08: Flat Table Machine Specifications -- 4’ x 8‘ Flat Table Working Capacity: X: 2,500 mm (98.4";); Y: 1,250 mm (49.2";); Z: 85 mm (3.3";).Gantry Outrigger: (2) synchronized Servo drivers in the X-direction; max. speed rate: 25 MPM (985 IPM). -- (1) Servo Driver: Y-Direction; max. 25 MPM (985 IPM); (1) Servo driver: Z-Direction max.; 15 MPM (590 IPM); power transmission in X. -- Y Via rack & pinion ball bearing spindle on: Z Axis; axis runs on ground linear guides. -- Automatic Centralized Lubrication of all axes -- Nesting Table: (2) Stops in X-direction: (1) Stop in Y-direction, left rear side; (6) manual switches situated in front of the machine; heavy valve system. -- Phenolic Vacuum Table with: (6) Vacuum fields and manual field choice. -- Stop cylinder at: Rear left; (2) in X, (1) in Y direction; electric box front left with light barrier. -- 1 ST 305-01004. -- Configuration package "Professional" H08 13.25 10 kW (S6) main spindle: HSK F63 Left/right rotation; 1,000 - 24,000 RPM controlled by inverter. -- Drilling Head "DH8": (8) Vertical drills; 1,000 - 6,000 RPM; controlled by inverter; 8-position tool changer. Extraction Hood: (22) Separate connections -- Software: Compact; standard PC with Windows 7 Controller; control for the use of ISO-Code; WOODFLASH programs on the machine.Includes: 210 cbm/Hr BECKER Vacuum Pump.

FELDER - FORMAT KAPPA 450: Sliding Table SawSpecifications -- 126" (3,200 mm) Cutting length w/scoring; anodized 14-3/4" x 126" aluminum sliding table with tracking by roller bearings; locks for easy panel loading in any position; 450 mm dia. main saw blade. -- Motorized: Raise, lower, and tilting (0° - 45°) of the blade with digital readout. Equipped with: -- 7-1/2 HP Main motor; 1.0 HP scoring motor unit w/external adjustment; square crosscut fence with: (2) Stops; standard rip fence with: 1,250 mm (49") Rip cap. w/digital readout; extension table with: Miter fence and sliding outrigger support. Includes: -- (2) 4" Dia. dust outlets; swing away overarm saw guard.Also available for an extra fee: 30 KVA; 208 - 380 Volt 3-Phase Transformer.

FELDER FORMAT4 PROFIT H08 16.31 FLAT TABLE MACHINE (W/ATC) -- Specifications5' x 10' "MATRIX" Phenolic Flat Table design for "Nested Base" Manufacturing. -- Working Capacity"X" Axis is 121.6" (3,090 mm); "Y" axis is 60.2" (1,530 mm);"Z" axis stroke is 11.8" (300 mm); max. material thickness is 4.3" (110 mm). -- Positioning Speed"X" & "Y" Axis at 197 FPM (60 MPM); "Z" axis is 49 FPM (15 MPM). -- WorktableThe working area is subdivided into (8) vacuum fields (H08 16.31) to ensure the best holding force for the most varied board sizes. The vacuum fields are controlled manually by means of hand levers on the front side of the machine.Prepared for (optional) elevated pods that allow profile & horizontal machining. -- Machining(1) 13.4 HP (10 kW) Vertically mounted electro-spindle router with: HSK F63 Adaptor; inverter driven 1,000 - 24,000 RPM with max. torque from 12,000 RPM.(1) 11-Position ATC tool rack mounted at the end of the machine. -- Operator & Machine ControlPC Based User-Friendly, icon driven control housed on the main machine base + "WOODFLASH" Operating System. -- Complete with:(1) 250 cbm/Hr Vacuum pumps; handheld terminal with: Potentiometer & emergency stop; automatic measuring system of the tool length.Sound absorbing protective head enclosure with debris curtain around bottom edge. -- Actual model: FELDER FORMAT4 - PROFIT H08 16.31

Photos coming! System includes: 24” in-line sander- Single head with buffing roller and clean up brush $340024” Double roll coaters 3ea-24” 2 bulb UV ovens 4ea24” Reverse rollcoaters 2ea24” 3 head brush denibber with double cleanup brushes 53” 2006 Heeseman sander- head 1 is a drum, head 2 is a cross belt, head 3 is a pad and has a clean up brush

FESTO - DSS3: Push Feed MoulderSpecifications -- 4-Head; -- 3-1/4" x 2" max. cap.; 3/32" x 3/16" min. cap.; min. length 10". -- Equipped with: (2) Side heads; 7 HP - 9,500 RPM motor; top & bottom heads 3 HP - 8,500 RPM motor each; 3/4" dia. spindle. -- 4-Feed rollers steel & urethane. -- Top head tilts both directions.

There are (4) machines at this facility. Two are used in production and the other two are in storage. 87" Capacity

FIN - ST 1600, ...Top/Bottom Cleaning Brush.62" Width and 3-1/8" max. thickness opening, thickness adjustment by handwheel via worm gear with dial indicator.Equipped with: -- Top & Bottom nylon brushes driven by 3 HP drive motor (only 1-brush with machine). -- Separate variable speed feed motor with magnetic controls driving 3" dia. rubberized infeed & outfeed pinch rolls. -- Full fabricated sheet metal enclosure for efficient dust collection, dust enclosure hood with central 6" dia. dust outlet connection.

Fletcher FM 200D Double End Tennoner General Specifications: - Top & bottom trim stations - Jump cope station - Cope station - Triangular sanding station, (tilting) - Trianglular sanding station, (tilting)

Manufacturer’s Specs. Hopper Feed 5 HP 5600 RPM Shaper Rotobelt Sanding Station 103” Triangular Belt Sander Air Blow Off Double Wheel Foiler Single Wheel Foiler

FLETCHER EZ-DOOR Raised Panel Door MachineThis freestanding machine can produce an entire 5-piece door in a matter of minutes. Easy to operate, the E-Z Door has a 4-position configuration to produce raised panels, cope/stile profiles and mullions for glass doors. Cathedral doors are produced by using a quick change template system.Specifications: -- Select cutter and material stop with the press of one button. -- Simple four position one spindle design. -- PLC controlled pneumatics. -- Rigid lubricated spindle assembly. -- Re-circulating ball bearing slides. -- 10 HP 230 or 460V/60HZ spindle motor – (460V/3PH=17FLA) – (230V/3PH=33FLA) -- 6,500 RPM spindle speed. -- 62 inch travel length standard with circulating ball bearing slides, cut rails to 59"; and panels to 55"; -- Includes: (4) Standard cutters (shape to be decided), others optional. -- Includes: one template of customers choice. -- 1-¼"; Arbor. -- CFM requirement is 392.Made in North Carolina, USA!

FLETCHER FM-2000 Contour EdgebanderSpecifications: 0.4 mm to 2 mm Banding thickness, up to 2" panel thickness, Unit to run strip veneer, coil, rolls of PVC, melamine, or wood veneer. Large overhead glue pot with a quick heat time of 10 minutes. Equipped with: -- Programmable temperature control with safety interlock so that applicator does not run until proper operating temperature is reached. -- 1-3/4" silicone-coated drive roll. -- Foot pedal-controlled tape advance. -- Foot pedal emergency stop. Optional Equipment: -- Power-Feed $ 2,618.00 -- 3° Manual Tilting Table $ 809.00 -- 45° Tilting Table $ 5,382.00 -- Push Button Powered Operated Tilt Table $ 6,232.00 -- Outboard Stock Support $ 1,565.00 -- 3MM Capable $ 2,950.00 -- 4"; Thickness Capacity $ 10,000.00

FORMOSA - RSN-12, ...Straight Line Rip Saw w/Laser LightSpecifications: -- Saw dia.: 14". --Saw kerf: 3.2 - 5.0 mm. -- Max thickness: 2" -- Max. process width: Left of saw blade 250 mm; Right of saw blade 500 mm. -- Min length: 200 mm -- 3,450 RPM. -- Feed Speed: 39 or 26 MPM. -- Main motor: 7.5 HP. -- Feed motor: 1 HP. -- Machine dim.: L 1,950 mm x W 1,280 mm x H 830 mm. -- Weight: 950 kG.Equipped with Laser Light.

39 inch sander for cabinet doors. Electronic motors adjustment for each head, up and down. Speed and rotation for each head Cross sanding- oscillating Cylinder drum flap- oscillating Disc station- oscillation. Double sided abrasives included Three 8’ dust ports. 480 V 3, phase, 60 hz.

FRAMA - TC-1500: Hydraulic Copy Lathe with (1) V-Gouge Copy Head & (2) Manual Top Turret Heads & Knife SharpenerHydraulic Copy Lathe with: (3) Different speeds during execution of the work.Possibility of manual or automatic configuration on (3) intensities: (1) Regular working speed; (2) Slow working speed for difficult points reproduction; (3) Fast speed to eliminate nonproductive points. Technical Data -- Main drive motor: 6 HP. -- Hydraulic pumping unit: 2 HP Motor. -- Max. turning dia.: 300 mm (12"). -- Distance between center: 1,500 mm (59"). -- Max. cross-slide speed: 9.5 MPM (30 FPM). -- Carriage return speed: 11 MPM (36 FPM). -- Copying device stroke 75 mm (3"). -- Max. hydraulic pressure between cones: 20 kG/CBM. -- Headstock taper: MT 4. -- (8) Turning speeds: 1,000 - 1,250 - 1,750 - 2,000 - 2,250 - 2,500 - 3,500 - 4,500 RPM. Also included: -- FRAMA - ATC 2005: Knife Grinder. 2 HP Motor. -- (1) Steady rest - 70 mm; (1) 18 mm; (1) adjustable for square. -- Tailstock & Tool Holder.

FRAVOL SMART S600-23 EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING): -- Specifications: Edge & Workpiece Capacity: 0.4 - 8 mm (0.016 - 0.315") edge; 10 - 60 mm (0.394 - 2.362") panel thickness; -- 140 mm (5.512") min. panel length and 100 mm (3.937") min. panel width. -- Feed-speed, 14 or 18 MPM (46 or 59 FPM.)Front-End Equipped With: -- Pre-Milling Station (RT/S), (2) motors @ 1.1 KW (1.5 HP), 12.000 RPM, LH & RH rotation w/pneumatic programmable jump control for chip-free and clean panel edges. Standard equipped with Dia. 60 mm x 64 mm H, with diamond inserts. -- IR Panel Heat Lamp: Improves gluing bond especially during cooler ambient temperatures and humid conditions. -- Automatic Edge magazine: For strips up to 8 mm & coil stock up to 3 mm thick PVC. -- Duo Gluing System: For regular granulate Hot Melt (EVA) and easy conversion to PUR glue. "Teflon lined" glue tank with bi-directional glue roller. Automatic temperature reduction during stand-by time. Glue tank has quick release system for maintenance or quick change to a different color or glue type. -- Side Pressure Section: (3) Pressure rollers, (1) motorized, (2) idle, pneumatic pressure control and programmable NC-positioning servo motor.Work-stations: -- End Trimming (INT 2/S): (2) motor @ 0.50 KW (0.70 HP) 12,000 RPM, automatic pneumatic chamfer 0° - 15° or total exclusion from control panel. Glides 45° on prismatic linear hardened steel guides. -- Trimming Unit (RF-S/S): Top/Bottom flush/bevel/radius milling unit, (2) motors, 0.73 KW (1.00 HP) 12,000 RPM. Pneumatic remote tilt in (2) positions, postion-1 for radius and thin edges up to 0.8 mm trimming, position-2 for flush trimming up to 8 mm edges.Equipped with banding thickness gauge block feature for quick and easy set-up/changeover. Includes 1-axis NC servo control motors for programmable change-over from thin to 8 mm solid wood edges or incremental re-positioning of the cutter head. -- Corner Rounding Unit (SYNCRO 1): Compact and easy to set up for leading & trailing edges, (1) motor 0.22 KW (0.295 HP) 12.000 RPM, electronically synchronized. Working capacity, min. 10 mm, max. 60 mm panel thickness. -- Profile Scraping Unit (RB/S): Top & bottom radius scraping for PVC - ABS edges. Heavy construction to eliminate vibrations and guarantee superior edge quality. Air blow-off jets and chip collection box. -- Clean Spray System: Top/Bottom spray nozzles applies edge cleaning solvent prior to buffing. -- Glue Scraping Unit (RC/S): Top & bottom pneumatically operated glue scraping on flat panel surface to remove potential glue squeeze-out that otherwise would coat the cloth buffing discs. -- Buffing Station (GSI/S): Top/bottom (2) motors, 0.09 KW (0.125 HP) 2,800 RPM, manual, horizontal, vertical and tilting adjustment -- Hot Air Unit PHON (GP/S): Top/bottom hot air blowers to restore PVC color after scraping. Electrical power 2,000 Watt, 0° to 600° C temperature adjustment.Complete With:• PLC Program Control, with 10.7" co

FRAVOL VSR TOP & BOTTOM TRIMMERSpecifications: -- Edgebanding thickness 0.4 mm to 3 mm, 16 mm (0.62") to 60 mm (2.36") panel thickness capacity. The rough trimming function uses vertical copy pads and one disc copier between the two cutters in a horizontal position, allowing 0.4 mm to 3mm radius edge rough trimming without replacing the cutters. Panel working height (thickness) is from 16 mm to 60 mm.Equipped with & Features: -- Two 12,000 RPM motors complete with braze welded hard metal cutters Ø 50x16- Z6. Your choice of profiles R1; R2; R3; 5°; 30°. -- The machine comes with a new, patented worktable that provides smooth panel sliding and extremely flexible edging without using jigs. -- Sliding on nylon blocks allows perfect cleaning of the panel melamine surfaces.

FRUILMAC RANDOMAT-E End Matcher;For end-matching flooring or cabinet & entry door rails; the feed-thru system allows continuous feeding of random-length parts with any kind of profile.Specifications: -- Width cap. of 1-3/16" to 9-7/8"; length cap. of 6-5/16" x 137" length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness capacity. -- Approx. (10) cycles/Min depending on part length & width; -- Feed system with (2) 120" long x 10" wide powered infeed & outfeed belt conveyors, parts are automatically fed & positioned with sensors, and a positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed, and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time, the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7.5 HP - 7,500 RPM high-speed shaper motors, which pneumatically traverse in tandem for each cutting cycle. -- Touch-screen SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation. -- Variable feed speed conveyor line; shaper head advance with led readout on the controls. -- Cutting station with overhead holddown wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps.Includes:(4) set of used tooling

FRUILMAC RANDOMAT E - End Matcher; -- For End Matching flooring or cabinet & entry door rails or tongue and groove. The feed-thru system allows continuous feeding of random length parts with any kind of profile.÷Capacity & Description: -- Width cap. 1-3/16" x 9-7/8'; length cap. 6-5/16" x 137" length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap. -- Approx. (10) cycles/Min depending on part length & width; -- Feed system with (2) 120" long x 10" wide powered infeed & outfeed belt conveyors, parts are automatically fed & positioned with sensors. -- Positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7.5 HP - 7,500 RPM high-speed shaper motors which pneumatically traverse in tandem for each cutting cycle. -- Cutting station with overhead hold-down wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps. -- Controller & Operator Interface: Key Pad SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line, and shaper head advance with LED readout on the controls. -- Includes Infeed and Outfeed Conveyors
