VITAP ALFA - 27: Construction/Line Borer27-Spindle boring head on 32 mm centers; drills vertically from bottom-up and head rotates to horizontal position for edge boring; head rotation is pneumatic with switch control. -- 2-3/4" Max. drilling depth; 2-1/2 HP - 2,800 RPM motor; pneumatic drill head advance with speed control; head height adjustment with mechanical digital readout; 34" x 20" table size; max. workpiece width 31-1/2". -- Equipped with: Left- & right-side fences for construction boring; (2) pneumatic holddown clamps; 118" line boring fence w/flip stops; pneumatic foot pedal control; magnetic starter; overload protection.

VITAP BLITZ CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) CNC Controlled head assembly with rapid (side-to-side) traverse, assembly with boring, gluing & insertion unit, This Flexible machine is IDEAL for JIT or high production runs. -- Working Area:Useable working area "X" axis 36.2" (920 mm), "Y" axis 3.14" (80 mm), "Z" axis up to 1.57" (40 mm) material thickness with digital readouts -- BG & D Unit(1) 1 HP - 6,000 RPM horizontal drill motor; 0.47" (12 mm) Maximum drill bit dia. (1) Glue injector & (1) dowel Inserter with 1.57" (40 mm) Max. dowel lengthMachine is capable of processing dowel diameters from 6 mm dia x 25 mm long - 10 mm dia x 40 mm long dowels (currently setup for 8 mm dia dowels); -- Operator & Machine Control:CNC "Color Touch-Screen" Controller for function & simple part programming and program storage. -- Complete with: (1) 12" Dia. vibratory feed hopper, totally sealed electronically metered glue system with "Automatic" injector flushing; (1) 4.75 G (18 L) Glue tank & (1) 2.37 G (9 L) water tank;(4) Inclined vertical pneumatic hold-down clamps; Function selector control for boring only or doweling; Anti-slip table surface, Rack & pinion drive and centralized dust collection manifold.

VITAP RC 92 Semi-Automatic Top & Bottom Edge Trimmer, New, Never Used!Specifications: -- For straight & curved edge banded panels. -- Max. edge thickness 3 mm (0.12"). -- Panel thickness 10 - 60 mm (0.39" - 2.36"). -- Table size 27" x 31".Equipped with: -- (2) 0.55 kW (0.7 HP) - 12,000 RPM Spindle motors. -- Large dia. guide bearings to ensure precise trimming of edges.NOTE: Sold "As Is" without Warranty!

For pre-glued PVC, veneer, & melamine laminate coil stock; 0.4 - 1.2 mm edge thickness; up to 35 mm panel thickness cap., automatic coil feed. -- Equipped with: Electronically controlled temperature setting for hot air blower; 3,000 Watts for up to 650° F temperature; (1) Min heat up time. -- Guillotine type front & rear end trim (with fast speed, flying knife); top & bottom flush trims with single motor drive to cutterheads. -- Overhead belt type feeder; 16 FPM feed speed. -- Mounted on machine base with panel support table.

VITAP LINEA 42 Line Boring SystemSpecifications: -- (2) Drill heads of (21) spindles ea., drills from bottom up, ea. support with 2 HP motor and (21) spindle boring block w/panel support mounted on top; -- Drills panels from 100 - 3,000 mm in length, and 100 - 950 mm in width. Complete with: -- Digital readouts for boring blocks, 2,000 mm bar scale fence with (5) adjustable flip stops. -- (2) Moveable overhead pneumatic holddown cylinders, foot pedal for clamping & boring cycle.

Vitap Forma Boring Machine 21 Vertical Spindles 21 Horizontal Spindles Approx $1000 worth of carbide bits DUAL LINE machine and there are (2) vertical lines of 21 spindles each for a total of 42 ...... PLUS an additional single line of 21 horizontal spindles!

Vitek Stroke sander Approx 8 foot capacity

The VOLPATO LS-1N 1A Wide Belt Sander, introduced in 2006, epitomizes precision and efficiency in the woodworking industry. Crafted with advanced technology, this machine excels in delivering impeccable sanding results on wood surfaces, showcasing its commitment to high-quality finishing. Designed with a robust and reliable structure, the LS-1N 1A ensures stability during sanding operations, contributing to the production of top-notch wood products. The wide belt configuration allows for efficient material removal, achieving smooth and consistent finishes across various wood types.

VALPATO LBK-150-ST 1 Feed Through Profile SanderTECHNICAL FEATURES: An added small needle type drum sander can be fitted with drum sanding aggregates of 25, ­30, ­35,­40, ­45 ­50 mm diameters which can be used for tighter curves and smaller radius sanding requirements. Storage compartments (2 in total) are located on each machine extremities, these are easily accessible and can be used for sanding belts and various tooling storage. Sanding belt motor power: 3 Kw Abrasive head motor power: 1.5 Kw Oscillation motor power: 0.38 Kw Feed motor power: 0.75 Kw Motor power for electrical adjustment of sanding group: 0.19 Kw Machine voltage: 480/3/60 Full Load Amps @ 480V: 15A Compressed air: Not required Dust collection requirement one (1) only 6" (150mm) port: 950 CFM Sanding belt speed: 14 Mt/sec Variable speed of the belt: from 5 to 25 m/min Sanding belt dimensions: 150 x 2640 mm Height of working table: 930 mm Dimensions of front working table: 1980 x 250 mm Machine dimensions: 2500 x 900 x 1600 mm Net weight: 1000 KMAIN FEATURES: User friendly PLC touch screen control panel is accessible from 360° by the operator, the control panel is centrally located on the infeed end of the machine. Factory installed variable feed drive (VFD), enables machine to run from 5 M/Min to 25M/min (+/­ 80 ft/Min). The entire sanding plenum rise and fall is motorized, it can be adjusted vertically in height to utilise the full height/width of the sanding belt. An oiling unit ensure long life of sanding plenum rise and fall master cylinder.

VOORWOOD "A 515 GH" Arch Door Sander with Floating Head ARCH SANDER with: (4) 1.5 HP Motors for precision sanding; quality sanding using Disc sanding at continuous feed. Equipped with: -- (4) Floating Sanding Stations equipped with: 1.5 HP Precision balanced drive motors and quick change spindles. -- Infeed & outfeed (1st and last) spindles equipped with: Double collets and angular, horizontal & vertical adjustments with accurate and repeatable digital readouts. -- PLC Control with: Monitor at eye level height.Feedthrough Arch Machine capable of sanding arch profiles on cabinet door components, plus can do straight cuts.. .

VOORWOOD M 15A CNC Round End Tenoner & Mortiser for 45° Door --The "M15A" Miter Machine is designed to rapidly make mortise and tenon cuts at 0°, 45° Only, . Parts can be up to 1.5"; thick and up to 4"; wide, and of ANY length. --A primary application for this machine is for miter cabinet door frames. Parts can be quickly transferred from left to right. They are mortised on the left side of the machine and tenoned on the right. The machine can also mill the slots. --Specifications & Equipped with: -- The mortise station has (3) servo-controlled axes (X, Y, and Z) that are coordinated by the machine controller to achieve complex CNC motion. It is equipped with a collet-style router spindle for cutting. The tenon station uses the same X- and Y-servo-controlled axes as the mortise station and is configured for pneumatically actuated in-and-out movement along the Z-axis. The tenon station is equipped with a direct drive shaper spindle for cutting. -- -- Pneumatic clamping assemblies with non-marring urethane pads are mounted to the hold-down assembly to secure the parts during cutting and these can be adjusted to various locations over the cutting surface. -- -- M15 Miter Machine operator interface consists of a colored touch screen. For simplicity, the entire calibration, setup, and monitoring of the machine are accomplished using only four touchscreen displays. The program designs the depth and location of both the mortise and the tenon. When the design is complete, it is saved in a recipe format. Once this recipe is opened, the operation is as simple and boils down to feeding the substrate into the machine. -- -- The full-color touchscreen panel is located on the front of the machine to provide easy access for setting up or operating the machine. Clamping and shaping operations are controlled by operating lighted pushbutton switches.

WADKIN CP 32 Sliding Table SawSpecifications: -- 10' Cutting length sliding table saw with scoring unit. -- Equipped with: -- 9 HP 2-speeed (2,880 & 4,080 RPM) Main motor and 3/4 HP, 9,900 RPM scoring motor; 14" (standard) - 16" max. dia. saw blade. -- 4" Dia. scoring blade; 0° to 45° tilting arbor; sliding table size 15-3/4" x 125". -- Fixed table 29" x 42"; 36" max rip cap. from saw blade to rip fence.

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6h WADKIN JET-3 Single End Tenoner/End Jointer Specifications: For Windows, doors, finger jointing, & stair strings. Stock type: PAR & Moulded. Max. tenon length 120 mm (4.72"). Max. stock width 150 mm (5.91"), Max. stock length: Unlimited, Max. stock thickness: 150 mm (5.91") for Rear tables, 280 mm (11.02") for Front table, & 450 mm (17.72") for Multiple tables. Vertical table adjustment 230 mm (9.06"), Horizontal table adjustment 25 mm (0.98"). Cutterhead dia. 250 - 322 mm (9.84" - 12.68"). Cutterhead speed 3,600 RPM. Max. cutting speed 4 MPM (13 FPM), Return speed 8 MPM (26 FPM). Equipped with: (3) 7” x 27-1/2” Multi-level tables, Each with Adjustable height, Fence, & (2) with 3” Dia. Pneumatic hold-downs, Allowing machining of (3) separate pairs of parts in (1) pass or All joints of window frame/sash in (2) passes. (1) Trim/hog saw & (1) 50 mm (1.97") Dia. x 240 mm (9.45") L Stackable spindle with 7.5 kW (10 HP) - 3,420 RPM Motor, with Automatic brake.

WADKIN "GD 220" 5-Head Molder8-5/8" X 4-3/4" cap. - Head sequence: Bottom 7.5 HP, right 7.5 HP, left 7.5 HP, top 10 HP, bottom 7.5 HP motor.Other Specifications: -- All spindles 40 mm dia. at 6,000 RPM, with vertical and horizontal adjustments; electric spindle braking; (2) digital position indicators with tool radius compensation fitted to the horizontal movement of the right side head and vertical movement of the top head. 0.5 HP Motorized feed beam with pneumatic feed hold-down wheels; -- Cardan drive variable feed speed 18 - 72 FPM, 3 HP feed drive, reverse feed, 5-1/2" dia. hardened and chromed steel feed rollers up to top head, polyurethane feed rollers 2" x 2" after top head; all feed and pressure rollers move with the rise and fall of the feed beam. -- Diameter of cutting circle: minimum 100 mm all heads; for planing, maximum 125 mm all heads; and, maximum of 195 mm all heads for moulding. -- Complete with: Manual bed lubrication, 2-meter (78") infeed straightening table, sound enclosure and owner's manual.Like New Condition - this Moulder has never been used, and is still sitting on factory shipping pallet.

WADKIN "GA-220" 5-Head Feed Through MoulderSpecifications: -- 5-Head, with 8-5/8" x 4-5/8" cutting capacity (220 mm x 120 mm) -- 40 mm Spindle diameter with cutterhead speed of 6,000 RPM. -- Head sequence: Bottom 10 HP, Right 7-1/2 HP, Left 7-1/2 HP, Top 15 HP, Bottom 10 HP motor. -- 2 HP variable feed speed 19 to 72 FPM, chain drive. -- Currently wired for 460 Volt, 3-Phase power.

WADKIN GD 220 6-Head Feed Through MoulderSpecifications: -- Working capacity: 230 mm W x 130mm H (9.06" W x 5.12" H) Timber admitted, 220 mm W x 120 mm H (8.66" W x 4.72" H) Finished timber. -- Head Sequence: Bottom 7-1/2 HP, Right 7-1/2 HP, Left 7-1/2 HP, Top 15 HP, Bottom 10 HP, & Universal 7-1/2 HP. -- Spindle dia. 40 mm (1.57"), Spindle speed 6,000 RPM. -- Variable feed speeds 6 - 22 MPM (20 - 72 FPM).Equipped with: -- Right, Left & Top heads with Mechanical digital readouts. -- 1/2 HP Motorized feed beam, 2.2 kW Feed motor, 3 HP Cardan drive, Reverse feed, 5-1/2" Dia. Hardened & Chromed steel feed rollers up to top head, 2" x 2" Polyurethane feed rollers after top head, All feed & pressure rollers move with rise & fall of feed beam. -- 2 M (78.74") L Infeed straightening table. -- Manual bed lubrication. -- Sound enclosure.

7 Spindle Moulder with Manual Bed Lubrication 6000 RPM Spindle Speed 19-91 F/Min Feed Speed Will Take 7" x 5" Lumber Specs: 1ST BOTTOM--7.5 HP 1ST FENCE SIDE--7.5HP 1ST LH SIDE--10HP 2ND FENCE SIDE--7.5 HP 1ST TOP-15HP 2ND BOTTOM-10HP UNIVERSAL-7.5 HP FEED DRIVE--3 HP BEAM LIFT--.5 HP

Manufacturer NV300 - With bilateral linear action providing profiling and straight knife grinding up to a max of 310 mm. Will shape and regrind moulder knives in the block and profile grind solid tipped heads. Suitable for HSS, Stellite and TCT. Max length of cutter profile 310 mm. Max dia of cutting circle 300 mm. Includes arbor, grinding wheel, stylus, 220 volt 3-phase

Wadkin GA 5363 5 Head Moulder

Wadkin K23 5 Head Moulder Largest Motor is 20HP S/N 99/2093 440 Volt 3 Phase Electric Motors
