woodworking Equipment For Sale

SCM S 630 PLANER WITH TERSA HEADSpecifications: -- 24" Width cap.; 12 HP main motor, 2 HP feed motor; 4-3/4" dia. with reversible knife TERSA Planer Head rotates @ 4,500 RPM; -- 1/8" - 11-3/4" Thickness opening via motorized bed with LED readout for fine adjustment. -- Max. depth of cut 5/16"; 10" min. length of work piece; variable infeed speed from 20 - 56 FPM.Equipped with: -- 20-3/4" x 39" Cast iron table, sectional chip breaker, sectional grooved infeed & solid outfeed rollers, adjustable bed rollers. -- neoprene out feed rollersComplete with: -- Magnetic starter and dust hood w/6" dia. dust outlet.Owner states: Condition- like new 24" thickness planer- third owner in a one man shop. Machine has seen very few hours of operation.

SCMI OLIMPIC K 800 T-FR2 EDGEBANDER EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): Specifications: -- Edge Capacity, 0.4 to 8 mm (0.016 to 5/16") for strip feeding. -- Panel Capacity, min. width 65 mm and 140 mm min. length, (2-3/8" and 5-1/2"). Panel thickness min./max. 8 - 60 mm (3/8" - 2-3/8"). Equipped With: -- Adjustable In-feed Fence: Manually pre-set with digital indicator and pneumatic panel spacing device. -- Pre-Milling Station, RT-E: Spindles 2 x 3.0 HP, 12,000 RPM, (1) with PLC controlled jump action and manual digital indicators positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. -- Pressure Section: Servo motor positioning, (4) pressure rollers, first larger, Teflon coated and powered. Workstations: -- End Trimming Station K-SEL: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0ø - 15ø, rapid set up between straight and angled cutting with the automatic swivel cylinder. -- Flush Trimming Unit: Top/Bottom, 2 x 1.0 HP, 12,000 RPM with 2 pre-set pneumatic positions, flush and overhang, remote pneumatic in/out positioning. -- Bevel/Radius Trimming Unit: Programmable, servo motor positioning, 2 x 1.0 HP - 12.000 RPM motors for change-over on the fly. -- Corner Rounding / Trimming Unit: For additional top & bottom trimming of linear an/or vertical leading & trailing corner when edgebanding all (4) sides, 2 x 0.8 HP - 12,000 RPM motor. -- Profile Scraping Unit "RAS/1000": Top/Bottom with (2) indexed manual pre-sets. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue Scraping Unit, "RC-V": Top/bottom flat glue scraper with pneumatic positioning through controller and air-blow off nozzle to keep the knifes clean. -- Buffing Unit "SPN": Top/bottom, oscillating 2 x 0.25 HP - 3,000 RPM motors, tilting up to 12°. -- Hot Air Unit: Single blower with adjustable heat range and directional heat shield for top/bottom coverage. Restores color luster on thick pvc edging materials that my be lost during the edge scraping process.Operator Interface: -- Startouch Controller, 12" color touch screen, swivels 270° at in-feed of machine. Capable to store (100) programs, (6) at the touch of a single key. Graphical display of all working units. Tracks production data, diagnostic information and monitors maintenance schedules. Complete With & Features: -- Feed-speed, 36/52 FPM, 1 x 2.5 HP feed drive motor, 200 Hz frequency inverter for all trimming units. -- Electronic, programmable hold-down pressure beam positioning, lighted safety/sound enclosure cover and outboard panel support. -- Actual Model: OLIMPIC K 800 T-FR2

SCMI MINI-MAX ME 25 EDGEBANDEDR, SINGLE SIDED SINGLE PHASE0.4 mm to 3 mm (1/8") Max. edge thickness cap. and 1.96" max. panel thickness; semi-automatic strip & coil feed magazine (feeds coil material automatically and strips one at the time); Teflon coated glue pot w/fast (8-10) Minute heat-up time, 1.2 mm cap. guillotine.Workstations: -- "ME 25" 2-Head -- Single motor end trim (0.8 HP - 12,000 RPM motor) -- Top & bottom flush trims (0.8 HP - 12,000 RPM ea. motor), straight or bevel cutters. -- Top & bottom scraping station. -- Top & bottom buffing, 3,000 RPM motors.22 FPM Fixed feed speed with 0.8 HP drive.Complete with: Sound enclosure, out rigger panel support, frequency converter, and used tooling on the stations.Features: Control Panel on machine infeed side Machine frame made of high rigidity ribbed steel to guarantee excellent support Top thick steel pressure beam with rubber coated wheels Manual adjustment of top beam with Auto positioning of operating units Numeric indicator of selected panel thickness Glue smoke-specific exhaust outlet; centralized extraction of the dust Panel support roller which can be extended the entire length of the machine

SCMI K 203 SINGE SIDED EDGEBANDER5/16" (7.9 mm) Max. edge cap. for strip feeding, 1/8" (3 mm) for coil feeding; 60 mm min. panel width and 160 mm min. panel length; panel thickness 10 - 50 mm.Equipped with: -- Teflon coated glue pot (heat-up time 10 Min), automatic strip and coil feed magazine, 3 mm cap. guillotine, 3-roll pressure unit w/pneumatic control.Workstations: -- Double motor front & rear end trim mounted on THK guideways (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15° from the control panel with (2) preset positions. -- Top & bottom flush & bevel trims with quick release mount and plug-in motors for quick tooling changes (0.7 HP - 12.000 RPM motor ea.), bevels 0° - 15³ with precision digital indicators for quick setup. -- Top & bottom Scraping station -- Top & bottom buffing unit (0.25 HP - 2,800 RPM motors). -- 36 FPM Fixed feed speed, 0.75 HP feed drive.Complete with: -- Microprocessor for line control (can store up to 50 preset programs), control panel at eye level for easy programming, full cover sound enclosure. Features: -- Mechanical digital readouts for setup adjustments, frequency inverter and outboard panel support.

SCM SANDYA 10/S M2 2-Head Wide Belt SanderHead Configuration1st Head: 7" Diameter Spirally-grooved steel contact roll, 20 HP Motor.2nd Head: Combination head, 7" Diameter Spirally-grooved rubber-coated contact roll, Finishing platen with Electronic sectional pad with EPICS System, 3-1/2" Steel contact roll, 13 kW (17-1/2 HP) Motor.Specifications: -- 4.5 - 9 m/min (15 - 30 FPM) Variable feed speeds, -- Part thickness 4 mm (0.2") to 170 mm (6.7"). -- 43" W x 103" L Abrasive belt, Electronic sanding belt tracking & Pneumatic belt tensioning. -- 34" H Natural rubber feed belt,Equipped with & Features -- Automatic thickness adjustment, Automatic feed belt tracking & Tensioning, -- Motorized rise & fall of working table, -- Part thickness & Conveyor belt speed LED readout, -- Infeed safety bar for operator protection and oversized parts. -- 3" Diameter Entry & exit rolls, 13" L 2-Roll Infeed & Outfeed extensions with 2" Diameter Rollers & Manifold. -- Unopened box of (10) KP520 100 Grit Belts (Purchased for $500).Dimensions: 88" L x 86" W x 90" H.Weight: 4,440 Lbs.

SCM S1000-T/ERL EDGEBANDER WITH PRE-MILL & CORNER ROUNDINGSpecifications: 15/32" (12 mm) Max. edge cap., 2" max. (w/corner rounding only 1-3/4") banding height, 2-3/8" min. panel width and 6-5/16" min. length.Equipped with: -- Automatic strip & coil feed magazine w/Heavy Duty 3 mm PVC cap. guillotine. -- Teflon coated glue pot with glue roller application system complete w/automatic recycling device for unused glue, digital thermostat adjustment for temperature control. -- 3-Roll pressure unit w/pneumatic controls for all pressure rollers.Workstations: -- "RM-K" 2-Head Pre-milling station model (2.5 HP - 19,000 RPM motors ea.). -- Double motor front & rear end trim (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15°, end trimmers mounted on 45° THK guide. -- Top & bottom flush trims (0.8 HP - 12,000 RPM motor ea.), bevels 0° - 15°. -- Top & bottom fine/radius trimmer (0.8 HP - 12,000 RPM motors) w/pneumatic positioning from control panel. -- 2-Motor Corner Rounding units for leading & trailing corner when edgebanding all (4) sides (two 0.5 HP - 200 Cy motors ea.). -- Top & bottom PVC Scraper for up to 5 mm radius. -- Top & bottom buffing unit (0.33 HP - 2,800 RPM motors). Hot Air Heating Unit, for restoring color on scraped PVC edges. -- Feed & Speed: Single 42 FPM fixed feed speed, 1 HP drive.Complete with: -- Microprocessor for line control & glue temperature (can store up to 50 preset programs). -- Swivel control panel. -- Pneumatic positioning of super finish. -- Full cover sound enclosure. -- 200 Cy - 5 kW Frequency inverter w/automatic motor brakes for all HF motors.

SCM SANDYA 15S (3) Head Wide Belt Sander42" Width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: Steel contact roll, 7" dia., 35 HP motor;2nd Head: Rubber-covered contact roll, 24 HP motor3rd head: Combination head, rubber-covered contact roll (45 Shore) and 3" wide finishing platen, 17.4 HP motor.Specifications: -- 43" x 103" Abrasive belts -- Electronic tracking & pneumatic belt tensioning, abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 4 HP motor -- Automatic part thickness adjustment -- Motorized thickness opening via (4) precision conveyor bed jacksEquipped With & Features: -- LED readout, 0" - 6-1/4" opening. -- Infeed & outfeed spring loaded rubber covered hold-down rollers -- Motor load meters -- Infeed and outfeed roller conveyor extensions.

SCM SANDYA - 40 M3 135, ...3-Head Wide Belt Sander 52" Width cap. Drum, Drum, Combination HeadHead Configuration:1st Head: Steel Contact 22 kW Pneumatic blowdown and alignment.2nd Head : Rubber Contact 18.5 kW Pneumatic blowdown and alignment.3rd Head: Combination Platen 15 kW Pneumatic blowdown and alignment.Note:The SCM sander does not have a brush. After the 3rd head, it has this pneumatic blow-off bar with multiple blow-offs running the length of the sanders width. Sander can be seen under power if needed.Specifications: -- 53" x 103" Abrasive belts with electronic tracking. -- All heads with abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 5 HP motor. -- Automatic part thickness adjustment. -- Motorized thickness opening via (4) precision conveyor bed jacks with LED readout. --0" - 7-7/8" opening. -- Equipped with & Features -- Outfeed rubber covered holddown rolls or shoes on all heads. -- Motor load meters. --Infeed and outfeed conveyor extensions. -- WYE-DELTA soft start.Note: The SANDYA model "40" is more or less the same as the SANDYA "30" but more Heavy Duty.

SCM TECH Z 30 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working Field "X" axis 120" (3,050 mm); "Y" axis 52.7" (1,340 mm) for routing & 44" (1,118 mm) for boring; "Z" axis stroke 7.8" (200 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:"X" & "Y" Axes are 197 FPM (60 MPM); "Z" axis is 72 FPM (22 MPM).Axes positioning by: AC Brushless motors and YASKAWA drives; high precision ball screw drive system in "X", "Y". "Z" Axes;All axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" Tubeless mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels.(6) Pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED Display positioning assistance for the support rails & vacuum pods; (2) independent working fields. -- Boring Head:3 HP (2.2 kW) motor - 4,000 RPM; (15) independent vertical spindles: (8) Spindles in "X" & (7) spindles in "Y".(6) Horizontal spindles (2 + 2) in "X" & (1 + 1) in "Y-axis".(1) X-axis grooving saw with 100 mm dia. blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Electro-spindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM.Static inverter for stepless speed & rapid shutdown rotation.(1) 6-Position ATC tool plate mounted on the on the machine for "on the fly" ATC; max. tool weight is 8 kG (17.6 Lbs). -- Operator & Machine Control:PC Front-End with: SCM "UNIVERSAL K2" + "Xilog Plus" + Windows "XP" Pro Operating System; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet. -- Complete with:(1) 100 m³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system. -- Actual Model is SCM TECH Z30 R6

1998 SCM TECH 30 Super Router

2008 SCM Morbidelli Universal 3612

SCMI SIGMA 107 IMPACT FRONT LOAD, AUTOMATIC PANEL SAWSpecifications: -- 149.6" (3,800 mm) Max. rip cut cap., 4.2" (107 mm) saw blade projection using a 380 mm dia. blade -- 12 HP (9 kW) main saw motor, 4,400 RPM main blade speed, 2 HP (1.5 kW) scoring motor, 7,650 RPM score blade speed.Saw Carriage: -- Variable saw carriage speed from 20 - 98 FPM (6 - 30 MPM), return speed of 98 FPM (30 MPM); Automatic saw carriage lubrication, balanced on hardened cylindrical guides, external score saw adjustment, THK guides for vertical saw movement.Pusher Fence: -- Programmable rear fence with rack & pinion movement, 124 FPM (38 MPM) forward speed, 124 FPM (38 MPM) return speed; (8) Material gripper clamps, grippers fit into a slotted pressure beam for positive material control during the final cutOperator & Machine Control: -- PC Front-end with SCM "WinCUT" real-time operation software with onboard optimizer; 64 MB RAM, 15" color super VGA monitor, on-screen diagnostics & production reports -- (2) Serial ports & (1) parallel port, spacing available for networking cards.Complete with: -- Rear support rails with rollers; (1) front Bakelite-coated air table 79" x 20" (2,007 x 508 mm) & (2) Bakelite-coated air tables 59" x 20" (1,499 x 508 mm) -- Automatic crosscut side aligner out to 72.7" (1,848 mm), plastic safety sectors & emergency bar surround cutting area, service kit & manuals, triple dust collector outlet. Note, Air compressor is not included, machine has been dismantled for transport.NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify.

SCM SI 300 S NOVA 5' Short-Stroke Sliding Table SawSpecifications: -- 62.9" Rip cap., telescoping crosscut fence with panel support and back squaring fence; (2) flip-stops. Equipped with: -- 9 HP Main blade motor; 1 HP scoring blade motor; tilting arbor 0° - 45°, 2-position table lock mechanism. Features: -- 50" Rip cut cap. with movable fence, 315 mm (12") main saw blade dia. (used blade included); 1" main blade arbor, 120 mm (4.7") scoring blade dia.; 3/4" scoring blade arbor. -- Max. cutting height is 100 mm (3.9") at 90° and 70 mm (2.75") at 45°; 4,800 RPM main blade speed and 9,600 RPM scoring blade;"EZ Dial" adjustable split scoring blade assembly - simply turn the dial to adjust the width of the score. This system eliminates the need for shims and is fully adjustable in 0.1 mm increments. Complete with: -- Overhead guard w/dust extraction outlet & emergency stop button. -- Instruction Manual & Spare Parts Catalog.Palletized Dimensions: 89" x 89" x 67" H.

SCM - Concept 2000, ...Double End Tenoner.Double End Tenoner with: Jump scoring, Hogging, Shaping with stacked tooling. -- 122" Opening cap., motorized opening with keypad entry & LED readout, 12" infeed chain area in front of holddowns. -- 0" - 4" Motorized thickness opening with mechanical digital readout. -- 6" Min. width, 2-post machine. Each side equipped with: -- 1st Station: Jump scoring. -- 2nd Station: Hogging unit. -- 3rd Station: Coping head with stacked tooling capacity (manually operated). -- 4.5 HP Drive for 10 - 60 FPM variable feed speed. -- Chain dogs on 15-3/4" centers, rubber top nonmarring chain pads. -- Heavy-Duty chain links with: Needle bearings, automatic oil mist chain oiler, automatic brake on feed motor with emergency stop.Complete with: -- Upper driven holddowns with: Continuous feed belts; feed beams can be disengaged for conventional part feeding in front of dogs. -- Mobile remote control for setup; dual lead screw for traversing beam; exhaust hoods on all heads.Note: Tear down and loading not included.

SCMI OLIMPIC K 560 T-ER2 EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING) Specifications: -- Edge Capacity, 0.4 to 6 mm (0.016 to 0.25") for strip feeding. -- Panel Capacity: Min. Panel width 60 mm (2.375"); Min Panel length 140 mm (5.5");Min./max. Panel thickness 8 - 54 mm (0.375" - 2.125"); Minimum distance between panels 600 mm (24").Equipped With: -- Pre-milling station: (2) 2.0 HP (1.5 kW) motors, to rectify/clean panels already sized. -- Adjustable In-feed Fence: Manually pre-set with digital indicator, pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with Quick change/disconnect Teflon glue pot for fast glue tanks change if needed. Heat-up time approx. 10 Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollersWorkstations: -- End Trimming Station: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: 2 x 0.7 HP - 12.000 RPM motors, capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Corner Rounding Unit "Round 2M": corner rounding unit with (2) 0.80 HP independent motors that slide on THK guides. -- Top & Bottom Profile Scraping Unit: with digital indicators. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: Eliminates any excess glue. -- Buffing Unit: Top/bottom, 2 x 0.25 HP - 2,800 RPM motors, tilting up to 12°.Operator & Machine Control: -- "STARTOUCH" Controller with 12" touchscreen display, capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors. Process statistics data, ie. No. of pieces/edges, and track feeding.Features & Complete With: -- 2-Speed feed-speed of 40 & 60 FPM (12 & 18 MPM); 1 x 2.5 HP feed drive motor; -- 200 Hz frequency inverter for all trimming units; -- Manual adjustable top hold-down pressure beam; -- Full sound enclosure cover and outboard panel support. -- Actual Model is SCM OLIMPIC K 560 T-ER2Following items have been replaced (date) since 2021:1) 2.5KG Glue Pot (19-JUl-21)2) Recondition old glue pot (spare glue pot) (30-Aug-21)3) Replace Guillotine ( 17-Sep-21)4) New diamond corner rounder / trimmer cutters (9-Nov-21)5) Machine Optimization & Tool swaps (22-Nov-21)6) Trimmer & rounder reset (15-Dec-21)7) New Servo motor & Chip (27-May-22)8) Motor programming (27-May-22)9) Servo Motor replacement / machine dial in / testing (22-Jun-22)10) Needle Roller (20-Jun-23)

SCMI OLIMPIC K 560 T-ER2 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edge Capacity: 0.4 to 6 mm (0.016 to 1/4") for strip feeding. -- Panel Capacity: Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. Panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Pre-milling Station: (2) 2.0 HP (1.5 kW) motors; rectifies/cleans panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with: Quick change/disconnect Teflon glue pot for fast glue tanks change if needed; Heat up time approx. (10) Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollers.Workstations: -- End Trimming Station: (2) Front & rear 1/2 HP - 12,000 RPM motors mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: (2) 0.7 HP - 12.000 RPM Motors; capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Corner Rounding Unit "Round 2M": corner rounding unit with (2) 0.80 HP independent motors that slide on THK guides. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: Eliminates any excess glue. -- Buffing Unit: (2)Top/bottom 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator & Machine Control: -- "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors: Process statistics data (i.e., number of pieces/edges) and track feeding.Features & Complete with: -- 2-Speed feed speed of 40 & 60 FPM (12 & 18 MPM); (1) 2-1/2 HP feed drive motor. -- 200 Hz frequency inverter for all trimming units. -- Manual adjustable top hold-down pressure beam. -- Full sound enclosure cover and outboard panel support. -- Actual Model is: SCM OLIMPIC K 560 T-ER2

SCM TECH Z1 CNC MACHINING CENTER (W/ATC/BORING/"C" AXIS): -- Specifications:Working Capacity:"X" axis 120" (3,050 mm), "Y" axis 41.3" (1,050 mm), "Z" axis stroke 5.9" (150 mm), max material thickness 3.9" (100 mm). -- Positioning speed: "X" & "Y" axis is 229 FPM (70 MPM), "Z" axis is 72 FPM (22 MPM).Axes positioning by AC Brushless motors and YASKAWA drives; all axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" tube-less mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels; (6) pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED display positioning assistance for the support rails & vacuum pods; (2) independent working fields; -- Boring Head:3 HP (2.2 kW) motor, 4,000 RPM; (8) Independent vertical spindles, (5) spindles in "X" & (3) spindles in "Y".(6) Horizontal spindles (2+2) in "X" & (1+1 ) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Air-cooled Electro-spindle router with HSK F63 adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM; static inverter for stepless speed & rapid shutdown rotation.(1) NC controlled "C" Axis for 360° Horizontal Processing.(1) 10-Position ATC rack mounted on the RH side of the machine. Max. tool weight is 8 KG (17.6 Lbs). -- Operator & Machine Control:PC front end with SCM "Xilog Plus" + Windows "7" Pro operating system; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet."XILOG PLUS" offers the advantage of having simple and intuitive software • Easy-to-use: easy planning of 3D elements due to the software modules: Cabinet to create complete cabinets and furniture; Nesting for rectangular and free-form elements it also ensures reduced production time and tool paths; WD to create complete fastenings; intuitive programming due the pre-set large graphics macro library; Immediate work table set-up from 3D graphics -- Complete with:(1) 100 M³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system; Scrap conveyor. -- Actual Model is SCM TECH Z1

SCMI OLIMPIC K 560TE EDGEBANDER (W/PRE-MILLING): -- Specifications: Edge Capacity: 0.4 to 6 mm (0.016 to 1/4") for strip feeding. -- Panel Capacity: Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. Panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Pre-milling Station: (2) 2.0 HP (1.5 kW) motors; rectifies/cleans panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with: Quick change/disconnect Teflon glue pot for fast glue tanks change if needed; Heat up time approx. (10) Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollers.Workstations: -- End Trimming Station: (2) Front & rear 1/2 HP - 12,000 RPM motors mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: (2) 0.7 HP - 12.000 RPM Motors; capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: Eliminates any excess glue. -- Buffing Unit: (2)Top/bottom 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator & Machine Control: -- "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors: Process statistics data (i.e., number of pieces/edges) and track feeding.Features & Complete with: -- 2-Speed feed speed of 40 & 60 FPM (12 & 18 MPM); (1) 2-1/2 HP feed drive motor. -- 200 Hz frequency inverter for all trimming units. -- Manual adjustable top hold-down pressure beam. -- Full sound enclosure cover and outboard panel support. -- Actual Model is: SCM OLIMPIC K 560TE

SCM PRATIX S-15-B FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:Single 5' x 12' traveling "Bridge Gantry" and stationary aluminum dual vacuum table with a MATRIX square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining".(8) Part location pop-up pins mounted on the table perimeter. -- Working field:"X" Axis is 145.11" (3,686 mm); "Y" axis is 61.2" (1,555 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness 4" (100 mm). -- Positioning Speed:"X" & "Y" Axis 115 FPM (35 MPM); "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra large precision profile linear guideways. -- Boring Unit:3 HP (2.2 kW) - 6,000 RPM motor; (7) vertical spindles on 32 mm centers, (5) in "X" axis & (2) in "Y" axis. -- Machining:(1) 9 HP (6.7 kW) Air-cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 14-Position ATC tool rack mounted to the machine base. -- Operator & Machine Control:PC Front End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers: Incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with:Onboard mini-CAD with built-in programming for writing circles, ellipses & angles with only a few keystrokes; Onboard cycle optimization, onboard calculator, mirror-imaging, and repeat imaging. -- Complete with:(1) 300 m³/Hr Vacuum Pump; external transformer 208/230/480 Volt; safety enclosure around the spindle carriage; tool length probe sensor; manual centralized lubrication.Includes: (1) Universal Remote Pendant, 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program.The pendant is fitted with a USB port to allow quick load & setup of new programs; safety "bump-stop" bumpers; emergency stop rope & manuals. -- Actual Model is SCM - PRATIX S-15-B.

SCM Sandya 5 Wide Belt Thickness Sander (Model 5 RCS 110)43" width cap, Drum, Combination headHead configuration1ST Head : Contact roll, 5-1/2″ dia., 25 HP motor;2nd Head: Combination head, rubber covered contact roll, 5-1/2″ dia., and 2″ wide finishing platen for veneer, 18 HP motor.Specifications -- 43″ x 85″ or 103″ Abrasive belts with electronic tracking & pneumatic belt tensioning, -- Pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 10 – 60 FPM, 3 HP feed motor, Equipped with & Features: -- Automatic part thickness adjustment, -- Motorized thickness opening with LED readout, -- 0″ – 6-1/4″ via (4) precision conveyor bed jacks. -- In feed & out feed spring loaded rubber covered hold down rolls on all heads, -- Motor load meters -- In feed and out feed conveyor extensions. -- Automatic advancement carpet -- Grooved rubber precision rollers Aspiration dust fans -- Emergency device to save hands while pieces in feedingMore info -- Dimensions 77″ x 64″ x 92″ Weight 1210 kG - Specifications, Dimensions & Weight data are to the best of our knowledge.
