Edgebanders For Sale

BIESSE AKRON 1440 SINGLE SIDE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + with "AIR FORCE" PUR & EVA TECHNOLOGY: -- Specifications: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm; Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm.Multi-Feed speed 8-12-15 &18 MPM.Glue & Pressure Section: -- Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting glue. Special glue container for PU glue; Additional glue container for EVA gluing unit with melting device.Additionally equipped with the AirForce "VC-710", High pressure, hot air system to reactivate special pre-coated edge material (commonly referred to as laser edge.Automatic edge feed; Cutter knife; Pressure zone with 1-Drive & 2 pressure rollers.Working Units: -- Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; -- Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. Machine Features: -- Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating. The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Auto adjustment of in feed fence. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator & Machine Control: -- Biesse, Windows-based "

BIESSE ROVER B EDGE 1667 CNC MACHINING CENTER (W/EDGEBANDING) -- Specifications:This "Bridge Gantry" machine is "IDEAL" for window, stair, door & component parts manufacturing. -- Working Field considering "all" units when Routing, "X" Axis is 265" (6,735 mm), "Y" axis is 75.9" (1,930 mm), "Z" axis stroke 13.6" (345 mm), max. material thickness when machining 9.6" (245 mm)When "Edge Banding" "X" Axis is 227" (5,780 mm), "Y" axis is 75.9" (1,930 mm), the max. banding material thickness is 2.55" (65 mm); the minimum internal radius is 30 mm & minimum external radius is 8 mm (depending on flexibility of the banding material). -- Positioning Speed: "X" & "Y" axis is 279 FPM (85 MPM), "Z" axis is 98 FPM (30 MPM); AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Worktable: (10) "EPS" (Electronic Positioning System) Vacuum bar support rails with pneumatic lifting blades, (4) "ATS" (auto Table Setting) vacuum pods per rail; set up assistance according to the program to process.(10) Pneumatic pop-up back stops, (10) pneumatic pop-up front stops, (4) pop-up side stops, (4) pop-up/removable central stops create (2) independent work zones.Edge Banding unit:The edgebanding unit GU60C with glue pot automatically applied EVA glue to square or irregularly shaped parts as the CNC head rotates along the "X" "Y" & "Z" axis and simultaneously rotates the tooling up to 360° on a high precision "C" axis.Floating "hot melt" glue pot & application roller with separate thermostats apply glue on the panel edge.Pneumatically controlled pressure roller with manually adjustable guides for coil & strip feeding; numerically controlled with encoder that measures strip feeding process.(1) 4-Coil tape magazine with warning sensor when the end of the spool is near; edge banding unit precisely applies 0.4 - 3 mm ABS & PVC with 60 mm (2.3") max. edge height.Pneumatically activated saw blade performs the end trimming at a 35° angle for precise fitting of overlapping joints on adjoining edges. -- Boring Unit: BH17 Boring Head with 4 HP (3 kW) motor, variable speed from 1,500 - 6,000 RPM; (10) Independent "Quick Change" vertical spindles with (5) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal boring spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) "X" axis grooving for up to 120 mm dia blade. -- Machining: (2) 18 HP (13.2 kW) Air cooled electro-spindle router with HSK F63 adaptor; 1,000 - 24,000 RPM. (1) NC controlled "C" axis for 360° horizontal processing.(21) Total ATC slots, with(1) 6-position ATC Tool Plate mounted on the "Y" carriage at the back of the machine & (1) 16-position ATC Changer on the "X" carriage. -- Operator Interface: PC Front End with Biesse "BH 660" +"bTouch" +"bSolid" + "bEdge" + Windows "WRT" (Windows Real Time) operating system.21" LCD monitor, CPU Intel(R) Core I5 or superior, 8 GB RAM memory, 128 SSD GB hard disk or superior. graphic card, LCD dis

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & rear trimming motors; uni-point swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled; (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt and programmable height positioning.Includes" Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Cap. - Edge thickness for strips: Min./max.: 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width; Min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup; MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit & parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502". (2) LH & RH Rotating NC controlled spindles with: Automatic center positioning. -- Anti-Adhesive: "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece surfaces. -- Infrared Heating Lamp. Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine. Automatic for processing coiled & strip edgebanding material. -- Pressure Section Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & Rear trimming motors; unipoint swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled: (2) Servo motors (one for horizontal tool position; one for tool up/down position); uses combination bevel/radius/flush insert knives; prepositioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt & programmable height positioning.Includes: Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE ROXYL 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: Features: -- Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high-temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers.This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without the necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC-controlled spindles with automatic center positioning. -- Edge Magazine: Automatic for processing coiled and strip edge banding material + a (2) position vertical Coil Magazine Cart. -- Pressure Section: Servo-controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IT90-S": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-100": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (4) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece's surfaces. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner

BIESSE AKRON 440 AX EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications Material infeed for strips & coiled edge material like: PVC, ABS, veneer, and solid wood. -- Edge & Workpiece Capacity: 0.4 - 3 mm (0.016 - 0.12") Edge; 10 - 60 mm (0.39 - 2.36") panel thickness; 140 mm (5-1/2") min. panel length, and 85 mm (3.3") min. width. -- Working Units:Premilling Station: (2) 3 kW (4 HP) - 150 Hz, 9,000 RPM Motors; equipped with: Panel blow off device; SIKO digital counters for adjustments. -- EVA Gluing Unit: Edge Feeding & Pressing Unit; automatic loading of tape in rolls and strips; quick-change glue pot system. -- Pressure Section: (1) Large 150 mm dia. driven; (5) idle pressure rollers. -- Feed Speeds: Operating feed speeds: 12 & 18 MPM (39 & 60 FPM). -- Workstations: Double motor End Trim; tiltable from 0° - 15°; each motor: 0.8 kW (1 HP) - 12,000 RPM; sliding in a slicing motion on a 45° precision guide bar with oversized bearing blocks. -- Top & Bottom Trimming: (2) Motors, 0.65 kW (0.87 HP) each; "Pro-Nesting" copiers; cutters: R=2 mm. -- Fine Trim/Corner Rounding Unit: (2) Motors; each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with: PVC, ABS, etc. material; wood edge banding up to 3 mm max. edge thickness. -- Top & Bottom Flat Glue Scrapper: To remove potential glue squeeze out. -- Buffing Station: Top & Bottom; (2) motors; each 0.37 kW (0.5 HP) - 2,800 RPM. -- Operator Interface:Operator Control Panel; "HDI" high definition touchscreen control; Windows XP-based. -- User-friendly graphic user interface with: Diagnostic and assisted maintenance. -- USB and Ethernet port; 1.44 MB floppy drive, automatic or manual startup. -- Complete with:High frequency motors (200 Hz): Padded sound enclosure. -- Top pressure beam with staggered double row holddown wheels mounted on ball bearings. -- Actual Model: BIESSE AKRON 440 AX

BIESSE AKRON 1330 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Computer controlled interface for workstations with servos and pneumatic positioning devices. Programmable selections for 1-touch changeover between edgebanding types and thicknesses.Top Pressure Beam with automatic adjustment from the machine control. -- Working Capacity: Edgebanding thickness, 0.4 - 5 mm capacity. Min. panel width 85 mm (3.3"); min. panel length 140 mm (5.5"); panel thickness 10 - 50 mm (0.39" - 1.96").3 HP (2.2 kW) Variable Feed Speed from 10 - 20 MPM (32 - 65 FPM).Front-End Equipped With: -- Pre-milling Unit with "Auto-set" automatic intervention, Strip & Coil Edge magazine, automatic shear type guillotine. -- Hot-Melt Glue System: Teflon coated glue pot, digital thermostats with automatic kick-down when machine is in idle mode.Pressure Section with (1) large dia. "non-stick" coated drive roller & (5) Teflon plated idle rollers with servo positioning NC controlled material thickness adjustment.Workstations: -- End Trimming Unit:NC controlled end trimming unit, 0.33 HP (0.24 kW) - 12,000 RPM motors.Motors travel on (2) straight slides and pneumatic tilt 0° - 15° on horizontal. plane -- Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit: NC Controlled 2-motor Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit, 0.3 HP (0.24 kW) - 12,000 RPM.Servo driven positioning of motors for different edge trimming profiles & positions. -- Corner Rounding Unit:2-motor 0.3 HP (0.24 kW) - 12,000 RPM motors for trimming leading & trailing upper & lower edge/corners with "Fast Position",Unit can be used as a second top & bottom fine trimmer as well. -- Profile Scraping Unit:Top & bottom 2 mm or 3 mm thick PVC banding, digitals for horiz. adjustments. -- Flat Scraping Unit:Top & bottom glue scraping unit. -- Buffing Unit: Top & bottom Buffing Unit, 0.5 HP (0.37 kW) - 2,800 RPM motors), units tilt 0° - 30°Operator & Machine Control: -- Biesse SMART TOUCH 7" + Windows operating system, user friendly touchscreen control panel for workstations, rotating operator control panel w/keypad and LCD readout.Graphic 7" display touch screen. High-resolution screen for defined and intuitive images and text. Integrated 4GB hard disk for filing media files and the programs back up.USB port for managing in a simple and efficient way multimedia files, programs and updates. Ethernet port for connecting the machine to the net.Complete With: -- Insulated sound enclosure over all trim stations with split dust hood, viewing windows. -- Actual Model is BIESSE AKRON 1330 A

BIESSE - AKRON 855, ...Edgebander with Premill & Corner Rounding (Loaded!)Specifications: -- Edge & Workpiece Capacity: 0.4 - 15 mm (0.016" - 0.59") Edge thickness; 14 - 65 mm (0.55" - 2.56") edge height; 10 - 60 mm (0.39" - 2.36") panel thickness; 140 mm (5-1/2") min. panel length; 85 mm (3.3") min. panel width. Infeed Section: -- Premilling Unit - "FI-701"Rectifies face to be edged before applying glue; horizontal & vertical movement of (2) motors on linear guides; independent automatic temporized intervention of (2) 1.8 kW (2-1/2 HP) - 12,000 RPM motors; independent copying pads on each unit, Autoset device to ensure optimum positioning of cutters according to thickness of panel being machined. -- Edge Feeding, Gluing & Pressing Unit - "VC-710"With automatic edge magazine for strip & coil stock; 3 mm (0.04") PVC guillotine; "TEKNO-GLUE" System includes: Pre-Melt "QM-701"; for quick heating & tank changing with floating & bidirectional glue roller applicator & NC axis idle presser roller movement device. -- Pressure Section: (1) Large driven & (5) Idle rollers, Independent pneumatic pressure control, Programmable servo motor for quick edge thickness changeover, Feed speeds 10, 14 & 20 MPM (33, 46 & 65 FPM).WORKSTATIONS: -- End (Edge) Trimming Unit - "IN-701-V"(2) 0.35 kW (0.5 HP) - 12,000 RPM Motors; automatic 4-position programmable chamfer from Control Panel (0°, 3.6°, 11°, 15°); sliding in slicing motion on 45° precision guide bar with oversized bearing blocks. -- Superimposed Flush (Double Edge) Trimming Unit - "RS-701"Top & bottom; (2) 0.8 kW (1 HP) - 12,000 RPM motors with superimposed motor position; 1° tilt capability; includes: Pneumatic exclusion device & Pneumatic top/bottom motor positioner. -- Tilting Top & Bottom Trimming Unit - "RI-701"(2) 0.65 kW (0.87 HP) - 12,000 RPM Motors; for radius top & bottom fine trimming; unit can be tilted 0° - 45°; includes: NC axis multiple machining device. -- Corner Rounding Unit - "CR-200V"For corner rounding; top & bottom trimming on panel edge with synthetic material & wood edgebanding up to 5 mm (0.20") max. edge thickness. -- Edge Scraping Unit - "RB-701"For finishing rounded off edges in PVC or ABS up to 5 mm (0.20") thickness includes: Pneumatic Unit Lifter. -- Flat (Glue) Scraper - "RCC-700"Top & Bottom, Removes potential excess glue before buffing unit. -- Buffing Unit, "SPL-700":Top & Bottom. -- Hot Air Blower Unit - "PH-700" - (2) STEINEL "2346" 2,000 W; reactivates color of thick plastic.Complete with: -- PC-Based Control Panel with: 15" Color LCD monitor, HF (High Frequency motors on all cutting & trimming workstations. Top pressure beam programmable via positioning motor; top pressure provided by belt holddown. 36" Dia. Coil table: Padded sound enclosure. -- Manuals (as pictured).Dimensions: 280" x 42" x 72" H. - Weight: 3,500 kG (7,750 Lbs.).

BRANDT KDN 210B Edgebander:0.4 - 3 mm (1/8") Edge thickness cap., 8 - 50 mm (0.3" - 2") panel thickness, 60 mm (2.3") min. panel width and 140 mm (5-1/2") min. length.Equipped with: -- Hot Melt granulate glue system with "Quick Melt" start-up (10 - 12 Min heat-up) with reversible rotation glue applicator roller and automatic reduction glue temperature adjustment (when idle drops to 150°, 2-1/2 Min to re-activate). -- Automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock are fed automatically through strip feed magazine. -- 3-Roller pressure section (1st driven, next (2) idle) w/electronically controlled and feed speed synchronized drive roll.Workstations: -- Vertical travel double-motor front & rear end trim with tilting of 0°- 15° cap. (0.24 HP - 12,000 RPM motors). -- Top & bottom flush/bevel trimmers (0.36 HP - 12,000 RPM motors), bevel 0° to 15°. -- Top & bottom buffing unit (0.15 HP - 2,750 RPM motors). -- Feed speed of 30 FPM. Features: -- Operator control panel at eye-level. -- Automatic height adjustment with top pressure beam for all work stations. -- Digital height indicator on holddown beam. -- Electronic motor brakes on trimmers.Complete with: 200 Hz Electronic frequency inverter, used tooling, sound enclosure w/window, and operators manual.

BRANDT AMBITION 1440 FC (KDF 440 C) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & 3,359 Hrs.Specifications: -- Edge & Workpiece Capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") Panel thickness, 160 mm (6.30") Min. panel length, 70 mm (2.76") Min. panel width.Equipped with: -- Adjustable Infeed Fence: Motorized adjustment with 0.049 kW (0.07 HP) Motor. -- Joint Trimming/Pre-Milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, Left-Hand & Right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, 3 mm (0.12") PVC Max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). -- Workpiece Preheating Unit -- Pressure Zone: (1) Driven & (2) Idle Rollers, Timed pneumatic pressure controlled, Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming. -- BRANDT "POWERTOUCH" Control: With 21" HD LCD Touchscreen monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors, with 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt, with Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. -- Multi-Functional Trimming Unit: (2) 0.4 kW (1/2 HP) 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERTOUCH" control, Pneumatic disengagement. -- Top & Bottom Glue Scraping Unit: Flush on panel surface, with Floating insert knives. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) 2,750 RPM Motors.Complete with: -- Motorized, programmable hold-down pressure beam with 0.12 kW (0.16 HP) Motor, 1.5 kW (2 HP) Feed motor, 32" Diameter Coil table, Padded sound enclosure.NOTE: CPU needs to be replaced.

BRANDT KDF 650 (1650 HIGHFLEX) EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING), with 3,339 Hrs. (As of 10/31/23):Specifications: -- 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. -- Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. -- "PC-16" Program Control with: 21-1/2"; Display, signal infeed light to ensure proper spacing between panels.Equipped with: -- Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. -- 32"; Dia. Coil table. -- Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover.Workstations: -- End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; -- Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. -- 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blow off nozzles; -- Top & bottom buffing (0.25 HP - 1,400 RPM motors). -- End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive.Complete with: -- Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling.NOTE: Actual Model "KDF 650".NOTE: Specifications must be confirmed.Machine Dimensions: 254"; x 50"; x 68"; H.Machine Dimensions with Outboard Panel Support Extended: 254"; x 66"; x 68"; H.

BRANDT - KDN 210: Edgebander0.4 - 3 mm (1/8") Edge thickness cap.; 8 - 50 mm (0.3" - 2") panel thickness; 60 mm (2.3") min. panel width; 140 mm (5-1/2") min. length.Equipped with: -- Hot Melt granulate glue system with: "Quick Melt" start up (10 - 12 Min heat up) with: Reversible rotation glue applicator roller & automatic reduction glue temperature adjustment (when idle drops to 150°, 2-1/2 Min to reactivate). -- Includes: Automatic feed magazine; coil stock feeds automatically with guillotine cutoff; all strip stock fed automatically through strip feed magazine. -- 3-Roller pressure section: 1st Driven; next (2) idle) with: Electronically controlled & feed speed synchronized drive roll.Workstations -- Vertical travel double motor front & rear end trim with: Tilting of 0°- 15° cap. (0.24 HP - 12,000 RPM motors). -- Top & bottom flush/bevel trimmers (0.36 HP - 12,000 RPM motors); bevel 0° to 15°. -- Feed speed: 30 FPM. Features -- Operator control panel at: Eye-level. -- Automatic height adjustment with: Top pressure beam for all workstations. -- Digital height indicator on holddown beam. -- Electronic motor brakes on trimmers.

BRANDT AMBITION 1650 FC HIGH FLEX EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING): -- Specifications: Edge thickness 0.4 - 12 mm (0.02" - 0.5"), incl. 3 mm (0.12") PVC banding. -- Workpiece thickness 8 - 60 mm (0.314" - 2.375"). -- Min. workpiece width 70 mm (2.76"), Min. workpiece length 160 mm (6.37"). -- Working height 950 mm (37.8"). -- Equipped with:3 HP (2.2 kW) Feed motor for variable feed speeds from 26 - 59 FPM (8 - 18 MPM) applying solid or using corner rounding units. -- Infeed panel support with roller guide extends out to 800 mm (31.4"). Motorized top pressure beam adjustment with 0.16 HP (0.12 kW) Motor. -- 80 mm (3.15") W Heavy Duty feed chain, with rubber pads, automatic chain track lubrication. -- Top pressure section with double-wide compound V-belt to prevent panel movement. -- All cutting & trimming workstations are HF (High Frequency Motors); line control (no limit switches) for workstation functions. -- Top & bottom spraying device located in front of pre-milling station for easy residual glue cleaning. -- Manual adjustment in case of modified panel overhang. -- Automatic edge infeed. -- Reinforced guillotine for coiled edgebanding material; 0.3 - 3 mm (0.01 - 0.12") thickness & 8 - 45 mm (0.314" - 1.78") Height.Pre-milling Station: -- (2) 3 HP (2.2 kW) - 12,000 RPM Vertical milling/jointing heads, Electro-pneumatic jump control on 1st motor, electronic frequency inverter for control of motor speed & braking, SIKO digital units for vertical & horizontal adjustments.Glue Preheat Unit: -- 2.5 kW, 3 kG (6.61 Lbs) cap.; glue viscosities 25,000 - 80,000 mPa, temperature range 120° - 245° C (248° - 473° F); max. melting capacity 6 KG/Hr.EVA Hot Melt Glue Application System: -- Quick-change glue tank for easy maintenance & glue color change, melting capacity approx. 6 - 10 KG/Hr; glue reactivating infrared heating unit positioned between glue roller & pressure zone to improve edge quality.Pressure Zone: -- Program controlled positioning of the pressure zone; (1) large driven & (3) secondary pneumatically controlled idle rollers.Workstations: -- Front & Rear End Trimming Unit with: Gap optimization, (2) 0.5 HP (0.35 kW) - 12,000 RPM motors, electro-pneumatic reset for straight or chamfer trimming. -- Top & Bottom Multistage Trimming Unit: (2) 0.73 HP (0.55 kW) - 12,000 RPM Motors with vertical & horizontal tracing; 2-position programmed controlled indexing. Position #1 with a slight projection of 0.2 mm & Position #2 with flush trimming without projecting edge; Servo motor, controlled positioning of the work units and side copy for multiple edge thickness. -- Multifunction Profile Trimming Unit (Corner Rounding) with: Magnetic drive technology, (2) 0.54 HP (0.4 kW) - 12,000 RPM motors, 18 MPM (59 FPM) max. feed speed; 3 mm (0.12") max. edge thickness, 12 - 60 mm (0.50 - 2.375") workpiece thickness, quick-change motor system for different radius profiles, pneumatic (2) position indexing for different edge thicknesses

0.4 - 3 mm (1/8") Edge thickness cap., automatic coil & strip feed magazine, guillotine for 3 mm PVC banding, fast startup (12 Min heat up) glue system; reversible rotation glue applicator roller. -- Workstations: Vertical travel double motor front & rear end trim, 0.25 HP - 12,000 RPM motors. -- Top & bottom flush/bevel trimmers, bevel 0° to 15°, 0.35 HP - 12,000 RPM motors; top & bottom PVC scraping unit for up to 3 mm radius; top & bottom buffing unit, 0.15 HP - 2,750 RPM ea. motor. -- Feed speed 30 FPM; digital height indicator on holddown beam. -- Equipped with: Operator control panel at eye-level, electronic line control (no limit switches), electronic motor brakes on trimmers, 200 Hz electronic frequency inverter; used tooling & sound enclosure w/window.

BRANDT KDF 660 Edgebander w/Premilling & Corner RoundingSpecifications -- 0.4 - 15 mm (5/8") Edge cap.; panel thickness 5/16" - 2-3/8"; min. panel length 160 mm (6-3/8") and 65 mm (2-3/8") min. width; -- Line Control (NO limit switches) for workstation function. -- Pressure beam height adjustment for all workstations via digital height indicator. -- PC-20 Program Control with: 12" Industrial PC screen; 256 MB RAM; 1 gB Flash card with USB Port & remote diagnostic link. -- Signal infeed light to insure proper spacing between panels.Equipped with: -- 2-Motor Premill unit; (2) 3 HP motors (12,000 RPM) with straight and chamfer capability; program controlled indexing from straight to bevel. -- Quick heat up glue system (approx. 10 minutes); hopper feeder & glue tank for maintenance & quick glue color change.Glue temperature indicator for both the glue pot and glue roller with LED thermostat and automatic temperature reduction if the machine is idle for (15) minutes or more. -- The glue applicator roller is reversible and retractable from the fence line. -- Automatic magazine for strip & coil (large coil table; 800 mm dia. to accommodate large coils of 3 mm PVC stock); 3 mm PVC guillotine; (1) drive plus (3) secondary rollers "pneumatically controlled" pressure sections. Workstations: -- Double-end trim with: (2) 0.5 HP - 12,000 RPM motors; chamfers 0°- 15° via programmable Controller. -- Top & Bbottom flush/radius trim; bevels 0° - 15° (0.75 HP - 12,000 RPM motor); insert knives for 3 mm PVC radius. -- Corner Rounding Unit. -- Top & Bottom scraping for 3 mm PVC radius; pneumatically controlled indexing system. -- Top & Bottom oscillating buffing (0.25 HP - 2,800 motors). -- Variable feed speed 36 - 65 FPM (3 HP feed motor).

Brandt KDF 440 Highflex 1440 Edgebander

BRANDT - Ambition 1440 AT (KDF-440 AT): Edgebander (w/Premill & Corner Rounding) + "AirTec" PUR/EVA Gluing Technology -- Specifications Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness; 8 - 60 mm (0.31" - 2.36") panel thickness; 160 mm (6.30") min. panel length; 70 mm (2.76") min. panel width.Equipped with: -- Heated Adjustable Infeed Fence. Radiant Heated with: Manual adjustment. -- Joint Trimming/Premilling Station. (2) 2.2 kW (3 HP) - 12,000 RPM Motors; left-hand & right-hand rotation with: Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device. 3 mm x 45 mm (0.12" x 1.77") Or 1 mm x 55 mm (0.04" x 2.17") max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- "AirTec" PUR Glue Application. For preglued PUR banding. -- Hot Melt Glue Application Unit. 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone. (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds. 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touchscreen Monitor.Workstations -- Front & Rear End Trimming Unit. (2) 0.18 kW (1/4 HP) - 12,000 RPM Motors with: 0° - 15° Automatic chamfer; pneumatic adjustment; activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit. (2) 0.55 kW (3/4 HP) - 12,000 RPM Motors; 0° - 25° automatic tilt with: Horizontal & vertical tracing wheels; brushless multiaccess Servo motors for positioning of work unit; horizontal copy wheels for Quick changeover with: (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit. (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for top & bottom, leading & trailing edges, and corner rounding of panels.Servo Motors for: Positioning of work unit & horizontal copy wheels.Either radius or chamfer cutters can be mounted: 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit. (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08").Servo Control positioning of: Vertical & horizontal copy wheels.PVC Scrape collection box, pneumatic adjustment using: "POWERTOUCH" Control, pneumatic disengagement. -- Top & Bottom Flat Glue Scrapping Unit. To remove excess before Buffing. -- Top & Bottom Buffing Unit. (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle holddown rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model: BRANDT - AMBITION 1440 AT (KDF 440 AT).

Brandt KDN 210 Edgebander

BRANDT AMBITION 1650 FC HIGH FLEX EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING): Specifications: -- Edge thickness 0.4 - 12 mm (0.02" - 0.5"), incl. 3 mm (0.12") PVC banding. -- Workpiece thickness 8 - 60 mm (0.314" - 2.375"). -- Min. workpiece width 70 mm (2.76"), Min. workpiece length 160 mm (6.37"). -- Working height 950 mm (37.8"). -- Variable feed speeds from 26 - 59 FPM (8 - 18 MPM) applying solid or using corner rounding units.Equipped with: -- 3 HP (2.2 kW) Feed motor for variable feed speeds from 26 - 59 FPM (8 - 18 MPM) applying solid or using corner rounding units. -- Infeed panel support with roller guide extends out to 800 mm (31.4"). Motorized top pressure beam adjustment with 0.16 HP (0.12 kW) Motor. -- 80 mm (3.15") W Heavy Duty feed chain, with rubber pads, automatic chain track lubrication. -- Top pressure section with double-wide compound V-belt to prevent panel movement. -- All cutting & trimming workstations are HF (High-Frequency Motors); line control (no limit switches) for workstation functions. -- Top & bottom spraying device located in front of pre-milling station for easy residual glue cleaning. -- Manual adjustment in case of modified panel overhang. -- Automatic edge infeed. -- Reinforced guillotine for coiled edgebanding material; 0.3 - 3 mm (0.01 - 0.12") thickness & 8 - 45 mm (0.314" - 1.78") Height.Pre-milling Station: -- (2) 3 HP (2.2 kW) - 12,000 RPM Vertical milling/jointing heads, Electro-pneumatic jump control on 1st motor, electronic frequency inverter for control of motor speed & braking, SIKO digital units for vertical & horizontal adjustments.Glue Preheat Unit: -- 2.5 KW, 3 KG (6.61 Lbs.) cap.; glue viscosities 25,000 - 80,000 mPa, temperature range 120° - 245° C (248° - 473° F); max. melting capacity6 KG/Hr.EVA Hot Melt Glue Application System: -- QA 45 Quick-change glue tank with electronic switchable/emptying mode for easy maintenance & glue color change.Melting capacity approx. 6 - 10 KG/Hr; glue reactivating infrared heating unit positioned between glue roller & pressure zone to improved edge quality.Adjustable glue amount with servomotorPressure Zone: -- Program controlled positioning of the pressure zone; (1) large driven & (3) secondary pneumatically controlled idle rollers.Workstations: -- Front & Rear End Trimming Unit with: Gap optimization, (2) 0.5 HP (0.35 kW) - 12,000 RPM motors, electropneumatic reset for straight or chamfer trimming. -- Top & Bottom Multi-stage Trimming Unit: (2) 0.73 HP (0.55 kW) - 12,000 RPM Motors with vertical & horizontal tracing; 2-position programmed controlled indexing. Position #1 with slight projection of 0.2 mm & Position #2 with flush trimming without projecting edge; Servo motor, controlled positioning of the work units and side copy for multiple edge thickness. -- Multifunction Profile Trimming Unit (Corner Rounding) with: Magnetic drive technology, (4) 0.54 HP (0.4 kW) - 12,000 RPM motors, 18 MPM (59 FPM) max. feed speed; 3 mm (0.12") max

2008 Brandt Edgebander 230Y/133V 3 Phase Currently in Production
