Edgebanders For Sale

BRANDT AMBITION 1440 AT (KDF-440 AT) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AirTec" PUR/EVA Gluing Technology -- Specifications: Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") panel thickness, 160 mm (6.30") min. panel length, 70 mm (2.76") min. panel width.Equipped with: -- Heated Adjustable Infeed Fence: Radiant Heated with Manual adjustment. -- Joint Trimming/Pre-milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, left-hand & right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- "AirTec" PUR Glue Application for Pre-Glued PUR banding. -- Hot Melt Glue Application Unit: 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone: (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touch Screen Monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors with 0° - 15° automatic chamfer, pneumatic adjustment & activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt with Horizontal & Vertical Tracing wheels, Brushless multi-axis Servo motors for positioning of work unit & horizontal copy wheels for quick changeover with (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit: (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for Top & Bottom, Leading & Trailing edges & Corner Rounding of panels, Servo motors for positioning of work unit & horizontal copy wheels. Either radius or chamfer cutters can be mounted, 3 mm (0.12") max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"); Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box, pneumatic adjustment using "POWERTOUCH" control, pneumatic disengagement. -- Top & Bottom Flat Glue Scrapping Unit: To remove excess before Buffing. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle hold-down rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model is BRANDT AMBITION 1440 AT (KDF 440 AT).

BRANDT KDN 210B Edgebander:0.4 - 3 mm (1/8") Edge thickness cap., 8 - 50 mm (0.3" - 2") panel thickness, 60 mm (2.3") min. panel width and 140 mm (5-1/2") min. length.Equipped with: -- Hot Melt granulate glue system with "Quick Melt" start-up (10 - 12 Min heat-up) with reversible rotation glue applicator roller and automatic reduction glue temperature adjustment (when idle drops to 150°, 2-1/2 Min to re-activate). -- Automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock are fed automatically through strip feed magazine. -- 3-Roller pressure section (1st driven, next (2) idle) w/electronically controlled and feed speed synchronized drive roll.Workstations: -- Vertical travel double-motor front & rear end trim with tilting of 0°- 15° cap. (0.24 HP - 12,000 RPM motors). -- Top & bottom flush/bevel trimmers (0.36 HP - 12,000 RPM motors), bevel 0° to 15°. -- Top & bottom buffing unit (0.15 HP - 2,750 RPM motors). -- Feed speed of 30 FPM. Features: -- Operator control panel at eye-level. -- Automatic height adjustment with top pressure beam for all work stations. -- Digital height indicator on hold-down beam. -- Electronic motor brakes on trimmers.Complete with: 200 Hz Electronic frequency inverter, used tooling, sound enclosure w/window, and operators manual.

BRANDT KDF-220 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): Specifications:0.4 - 3 mm (1/8") Edge thickness cap., 8 - 50 mm (0.3" - 2") panel thickness, 60 mm (2.3") min. panel width and 140 mm (5.5") min. length. Equipped with: Hot Melt granulate glue system with "Quick Melt" start-up (10 - 12 Min heat-up) with reversible rotation glue applicator roller and automatic reduction glue temperature adjustment (when idle drops to 150°, 2.5 Min to re-activate. -- Automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock are fed automatically through strip feed magazine. -- 3-Roller pressure section (1st driven, next (2) idle) w/electronically controlled and feed speed synchronized drive rollWorkstations: Pre-milling station with (2) 2.2 KW motors -- Vertical travel double-motor front & rear end trim with tilting of 0° - 15° cap. (0.24 HP - 12,000 RPM motors). -- Corner rounding unit Optimum corner rounding without adjustment or set-up, resulting from the coupled diamond tool and tracer roller. Workpiece thickness up to 40 mm -- Top & bottom flush/bevel trimmers (0.36 HP - 12,000 RPM motors), bevel 0° to 15°. -- Top & bottom buffing unit (0.15 HP - 2,750 RPM motors). -- Feed speed of 33 FPM (10 MPM).

BRANDT 0 KDN 660 2C EDGEBANDER WITH CORNER ROUNDING0.4 - 12 mm Edge cap; 8 - 55 mm Panel thickness; 160 mm (6-3/8") min. panel length and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. -- 16 MPM Feed Speed (11 MPM automatically when corner rounding).Equipped with: Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" & Servo controlled pressure sections for quick edge thickness changeover.Workstations: -- Double motor end trim (0.5 HP - 12,000 RPM motors), automatic chamfer from control panel 0° - 15°. -- Top & bottom flush trim (0.5 kW approx. or 0.67 HP - 12,000 RPM motor). -- Servo Controlled Top & Bottom Fine trim station (0.35 kW approx. or 0.50 HP - 12,000 RPM) bevels 0° - 25°, horizontal & vertical tracing wheels, comes with optional brushless Servo motors for quick thickness changeover. -- 2-Motor Corner Rounding unit (0.35 kW motors or 0.5 HP - 12,000 RPM motors) for leading & trailing edges of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Top & bottom PVC radius scraping with pneumatic control, PVC Scrape collection box. -- Top & Bottom PVC/joint scrape station. -- Top & bottom buffing (0.125 HP - 1,400 RPM motors). -- End trim & flush trim stations have HF motors with electronic brakes.Complete with: -- Operator control panel w/PLC (Programmable Logic Control) keypad & LED readouts, -- Padded sound enclosure, and used tooling.

BRANDT AMBITION KDF 1230 FC (KDF 230C) (W/PRE-MILL & CORNER ROUNDING): -- Specifications:Edge material thickness 0.4 - 6 mm (0.016 - 0.23"); panel thickness 0.8 - 40 mm (0.03 - 1.57"); min. panel length 160 mm (6.29"); min. panel width 70 mm (2.75").Equipped with: -- Pre-Milling Station, (2) motors @ 0.75 kW (1.0 HP) ea., 12.000 RPM, LH & RH rotation w/pneumatic jump control for chip-free and clean panel edges. -- Infrared Radiant Quartz Heating Unit: Between glue roller and pressure section. -- Automatic Edge Magazine: For strip & coil stock, strips 0.4 mm - 3 mm (0.016 - 0.011"), coils up to 3 mm PVC; "HD" guillotine. -- Gluing Station: "A3" Gluing Unit for granulate adhesive application system with Quick Change application unit underneath glue reservoir. -- "Quick Change" Glue Tank: For maintenance & glue color change. -- Pressure Section: 1st. roller driven plus (2) idle rollers, Digital readout for manual adjusting pressure zone to edge thickness. Timed pneumatic pressure controlled; -- Feed Speed: Feed chain track speed 11 MPM. (36 FPM) w/gear motor feed drive.Workstations: -- End Trimming: (2) Motor @ 0.18 kW (0.24 HP) 12,000 RPM, automatic chamfer from control panel 0°- 15°. -- Flush/Bevel-Fine/Radius Trimming Unit: Top/bottom (2) motors, 0.27 kW (0.36 HP) 12,000 RPM, tilt positioning 0° - 25°, with combination flush/radius/chamfer cutter-heads; horizontal and vertical tracing wheels. -- Corner Rounding Unit: (1) Motor 0.35 kW (0.5 HP) 12,000 RPM for leading & trailing edges vertical corner rounding of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Radius Scraping, Multi-Profile: Top/bottom with (2) profiles. 1 mm & 2 mm or 3 mm instead of 2 mm, PVC scrape collection box. -- Flat Glue Joint Scrapers: Top & Bottom Glue Joint scrapers for removal of adhesive residue for perfect finish, sensing from top & bottom; height adjustment with top pressure beam, equipped with (2) reversible cutter knives. -- Buffing Units: (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors Top & Bottom Buffing Units.Operator & Machine Control: -- "ECO Plus Control", easy operation with simple menu format; large LCD display and integrated line control via keypad.Production readiness displayed by traffic light indicator with ability to adjust units quickly thanks to direct access via ctrl keys. Intuitive, user-oriented navigation with a clear overview of the help and assistant functions, including the glue pot temperature or troubleshooting in plain text. -- Actual Model is BRANDT AMBITION KDF 1230 FC (KDF 230C)

BRANDT AMBITION 1200 (EDGEBANDER WPRE-MILL & CORNER ROUNDING): -- Specifications: Edge & Workpiece Capacity, 0.4 - 3 mm Edge cap., min. panel thickness 8 mm (0.3"), max. panel thickness 40 mm (1.57"), min. panel width 70 mm (2.75"). Min panel length: 140 mm (5.5")Line control (NO limit switches) for workstation function. Automatic height adjustment with top pressure beam for all workstations. Auto in-feed stop to insure proper spacing between panels. Equipped with:Pre-Milling Station:(2) motors @ 0.75 kW (1.0 HP) ea., 12.000 RPM, LH & RH rotation w/pneumatic jump control for chip-free and clean panel edges. Equipped with diamond cutter heads. -- Gluing Section:Automatic magazine for strip & coil (large coil table 800 mm diameter to accommodate large coils of 3 mm PVC) stock, 3 mm PVC guillotine, Pressure Section with (1) large drive plus (2) idle rollers "pneumatically controlled." Hot Melt granulate quick heat-up glue system. Workstations: End Trimming: 2 x 0.18 kW (1/4 HP), 12,000 RPM motors, THK guided, chamfers 0° - 15°. -- Flush/Bevel/Radius Trimming:2 x 0.55 kW (0.75 HP),12,000 RPM motors with insert knives for 3 mm PVC radius. cutter-heads, bevels 0° - 15°. -- Corner Rounding Station:1-Motor (4-corners) contour trim for profile corner rounding, 1 x 0.35 kW (0.5 HP), 12,000 RPM motor, with insert knivesFor 3 mm PVC radius w/digital read-out set-up and pneumatic change-over from thin to thick PVC edge tape. -- "Quick-Change" Profile Scraping Unit:Top & bottom for 2 - 3 mm radius, pneumatically controlled blow-off nozzles. -- Flat Scraping Unit:Top & bottom flat scraping units with copy wheels to remove residual glue squeeze-out.Operator & Machine Control: "ECO Plus Control", easy operation with simple menu format; large LCD display and integrated line control via keypad.Production readiness displayed by traffic light indicator with ability to adjust units quickly thanks to direct access via ctrl keys. Intuitive, user-oriented navigation with a clear overview of the help and assistant functions, including the glue pot temperature or troubleshooting in plain text. -- Complete With: &#9679 Trim stations have HF motors w/electronic brakes &#9679 Fixed feed chain track speed of 8 MPM (26 FPM) &#9679 2 HP feed drive &#9679 208/230/440/480v, 3ph Transformer &#9679Sound/Safety Enclosure &#9679 Adjustable Out-Rigger Support &#9679 Used tooling. -- Actual Model is BRANDT AMBITION 1200.

CAM-WOOD EB-L5PM EDGEBANDER (W/PRE-MILLING): -- Specifications:0.4 mm - 3 mm Max. edge thickness cap., 10 mm - 50 mm (0.75" - 2") panel thickness cap. (when edgebanding 3 mm PVC max. thickness is 40 mm). -- Minimum panel dimensions 63.5 mm wide x 160 mm long (2.5" x 6.3"). -- Automatic feed of coil banding and semi-automatic strip fed magazine (strips 1- 3 mm max.) with 3 mm PVC cap. guillotine.Infeed Section: -- Pre-Mill Unit with: (2) 3 HP (2.25 kW) -12,000 RPM High Frequency motors. -- Feeding of edging by strip or coil is automatic and synchronous with panel feed. -- Gluing Unit: Roller driven by a 1 HP (0.75 KW) motor; Tank heating 2.3 kW. -- Guillotine to cut edgebanding in coils up to 3 mm thick. -- Pneumatically controlled side pressure section with (3) pressure rollers; 1st synchronously driven, (2) idlers; Independent adjustment for straight edge banding.Workstations: -- Double Motor end trimming saw unit with (2) 1 HP (0.75 kW) - 12,000 RPM High-Frequency motors. -- Cutting group moves on ways made of hardened steel, to guarantee high precision and reliability. -- Rough Top & Bottom Trim station with (2) 0.75 HP (0.56 kW) - 12,000 RPM Independent High Frequency motors; unit features adjustable copying on vertical & horizontal floating movements, adjustable cutter-head position by mechanical digital readouts, quick release (electrical & mechanical). -- Fine Top & Bottom Trim station with (2) 0.75 HP (0.56 kW) - 12,000 RPM Motors. -- Top & Bottom Scraper station with quick working or exclusion setting of both top & bottom units, micrometer adjustment; features thick chrome plated copying shoes. -- Top & Bottom Buffing/Polishing unit with (2) 0.25 HP (0.18 kW) - 1,400 RPM motors.Feed System & Features: -- 25 - 60 FPM feed speed powered by 2 HP (1.5 kW) gear motor. -- Feed chain pads with precision ground round guides to ensure precise linear tracking of the workpiece. Replaceable rubberized surface inserts. -- Rubberized hold-down rollers with ball bearings for low friction and long life. -- Complete with: Sound / Safety covers for all work units with all required dust extraction outlets. Heavy, robust construction to eliminate vibration and ensures accuracy and stability.Includes: Outrigger support for wider work pieces. -- Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Total machine power is 11 kW. Transformers are available at an added cost to convert to desired alternate voltage requirement.

CAM-WOOD EB-K7PMX EDGEBANDER (W/PRE-MILLING): -- Specifications:0.4 mm - 3 mm Max. edge thickness cap., 10 mm - 60 mm (0.75" - 2.36") panel thickness cap. -- Minimum panel dimensions 160 mm long x 88.9 mm wide (6.3" x 3.5"). -- Automatic feed of coil banding and semi-automatic strip fed magazine (strips 1- 3 mm max.) with 3 mm PVC cap. guillotine.Infeed Section: -- Pre-Mill Unit with: (2) 3 HP (2.25 kW) -12,000 RPM High Frequency motors. -- Feeding of edging by strip or coil is automatic and synchronous with panel feed. -- Gluing Unit: Roller driven by a 1 HP (0.75 KW) motor; Tank heating 2.3 kW. -- Guillotine to cut edgebanding in coils up to 3 mm thick. -- Pneumatically controlled side pressure section with (3) pressure rollers; 1st synchronously driven, (2) idlers; Independent adjustment for straight edge banding.Workstations: -- Double Motor end trimming saw unit with (2) 1 HP (0.75 kW) - 12,000 RPM High-Frequency motors. -- Cutting group moves on ways made of hardened steel, to guarantee high precision and reliability. -- Rough Top & Bottom Trim station with (2) 0.75 HP (0.56 kW) - 12,000 RPM Independent High Frequency motors; unit features adjustable copying on vertical & horizontal floating movements, adjustable cutter-head position by mechanical digital readouts, quick release (electrical & mechanical). -- Fine Top & Bottom Trim station with (2) 0.75 HP (0.56 kW) - 12,000 RPM. -- Top & Bottom Profile Scraper station with quick working or exclusion setting of both top & bottom units, micrometer adjustment; features thick chrome plated copying shoes. -- Top & Bottom Buffing/Polishing unit with (2) 0.25 HP (0.18 kW) - 1,400 RPM motors.Feed System & Features: -- 25 - 60 FPM feed speed powered by 2 HP (1.5 kW) gear motor. -- Feed chain pads with precision ground round guides to ensure precise linear tracking of the workpiece. Replaceable rubberized surface inserts. -- Rubberized hold-down rollers with ball bearings for low friction and long life. -- Complete with: Sound / Safety covers for all work units with all required dust extraction outlets. Heavy, robust construction to eliminate vibration and ensure accuracy and stability.Includes: Outrigger support for wider work pieces. -- Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Total machine power is 11 kW. Transformers are available at additional cost to convert to desired alternate voltage requirements.

CAM-WOOD EB-L5 EDGEBANDER0.4 mm - 3 mm Edgebanding thickness capacity, 10 mm (3/8") - 50 mm (1.96") material thickness capacity, 63.5 mm (2.5") minimum part width, 160 mm (6.3") minimum part length. Equipped with: -- Automatic feed of coil banding and semi-automatic strip fed magazine (strips 1- 3 mm max.) with 3 mm PVC cap. guillotine. -- Teflon coated glue pot w/fast (10 - 12) Min heat-up time; 4-liter capacity. -- Guillotine to cut edgebanding in coils up to 3 mm thick. -- Pneumatically controlled pressure section with (3) pressure rollers; 1st drive, (2) idle.Workstations: -- Double Motor end trimming saw unit with (2) 1 HP (0.75 kW) - 12,000 RPM High-Frequency motors. Cutting group moves on rounded ways made of hardened steel, to guarantee high precision and reliability; cutting movement from the top of the panel. -- Top & Bottom Trim station with: (2) 0.75 HP (0.56 kW) - 12,000 RPM High-Frequency motors; unit features adjustable copying on vertical & horizontal floating movements, adjustable cutterhead position by mechanical digital readouts, quick release (electrical & mechanical). Includes (2) 3 mm radius cutters. -- Top & Bottom Buffing unit with (2) 0.50 HP (0.37 kW) - 1,400 RPM motors. Feed & Holddown: -- Feed rate of 12 MPM (40 FPM); feed chain pads with replaceable rubberized surface inserts. -- Special design "track frame" to eliminate feed chain side-to-side movement after years of use. -- Rubberized holddown rollers with ball bearings for low friction and long life. -- Complete with: Sound enclosure protects the operator from noise and debris.

CANTEK - MX340, ...Edgebander (Single Phase)The CANTEK "MX340" is designed to be a compact and durable Edgebander. -- Equipped with: End trimming, flush trimming, PVC scraping, and buffing. -- Edgebander is operated through: PLC Control System, LED display, and keypad.Specifications -- Panel thickness cap.: 0.315" to 1.77" (8 mm to 45 mm). -- Edgebanding coil feed accepts: 0.4 mm -3 mm Thick; strip material can be hand-fed. -- Conveyor feed speed: 29-1/2 FPM (fixed).Workstations -- Heated infeed fence for optimum glue penetration; large capacity Teflon coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine: 3 mm Max. thick banding; followed by spring loaded double pressure rollers. -- Single front/rear trimming unit: 0.3 HP Motor. -- Double top & bottom trimming units: (2) 1/2 HP motors. -- Top & bottom scraper/radius scraper. -- Top & bottom buffing station: (2) 0.16 HP Motors.

CANTEK RAPIDEDGE PRO EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications:0.4 - 3 mm Edge thickness; strip material can be hand fed; panel thickness 0.315" - 1.77" (8 - 45 mm); min. panel length 6.7" (170 mm); min. panel width 3.54" (90 mm). 0.4 kW Heated infeed fence for better glue adhesion; 2 HP (1.5 kW) feed motor with fixed feed speed of 29 FPM (9 MPM).Equipped with: -- Pre-mill Unit:(2) 2 HP (1.5 kW) - 12,000 RPM each counter rotating cutter-heads for removing up to 3 mm of the panel edge. -- Glue System:Quick-Change 1.2 kG Teflon coated glue pot is designed for EVA hot melt glue. The glue pot is a Quick-Change type and can be removed and replaced in less than (1) minute.Spring-loaded Pressure Unit with (2) pressure rollers.The Guillotine shear can rough trim coiled material up to 3 mm in thickness. Pressure rollers section consists of : (1) Large driven roller followed by a smaller one. Workstations: -- End Trim: (1) 0.29 HP (0.22 kW) - 12,000 RPM Single motor end trim system with (2) saw blades; unit is mounted on high precision linear guide rails. -- Rapid Top & Bottom Trim:The RAPID adjustment system uses a pneumatic 3-position adjustment to quickly change from 0.5 mm to 1 mm, to 2 mm edgebanding. This is done directly from the Control Panel.(2) 0.5 HP (0.37 kW) - 12,000 RPM high frequency motors for Top & Bottom trimming of the panel; each motor has an inset knife cutter head that can be adjusted from flush to beveled finish for thin edges and radius trimming (2 mm radius). -- Nesting Function:Nesting kits are installed on the Top & Bottom trimmers and scraping units to ensure they properly trace the panel when predrilled for hinge holes. -- Corner Rounding:(1) 0.5 HP (0.37 kW) - 12,000 RPM, high frequency single motor Corner Rounding Unit. Quick change corner rounding motor for fast changeover from 1 mm to 2 mm radius on the ends.Unit can process between 0.4 - 3 mm and up to a board thickness of 1.77" (45 mm).The multifunctional cutter can round straight or radius edges with a 2 mm radius cutter. -- Profile Scrappers:Multi-radius scrapers allow operator to apply a 1 mm or 2 mm radius on the Top & Bottom of the panel. -- Flat Scrappers:Flat insert knives designed to remove any excess glue which remains on the surface of the panel after applying the edge due to squeeze out. -- Buffing Units:(2) 0.2 HP (0.12 kW) - 3,000 RPM motors, Top & Bottom Buffing units leave a super finish on ABS & PVC edging and removes any discoloration on the edges. -- Release Agent Spray Unit:Applies release agent to the Top & Bottom surface of the panel before applying the glue allows for simple removal of any excess glue.The unit is located before the Pre-milling Station so any overspray which gets on the edge will be milled off to ensure proper bonding. -- Cleaning Agent Spray Unit:The Cleaning Agent System sprays the Top & Bottom edge before the Buffing Unit & designed to polish the edge and loosen any excess glue residue on the surface

CANTEK MX340M Edgebander (Single Phase):The MX340 from CANTEK is designed to be a compact, and durable edgebander. -- Equipped with end trimming, flush trimming, PVC scraping, and buffing. -- The CANTEK MX340 Edgebander is operated through a PLC control system with an LED display and keypad.Specifications: -- The MX340 handles panel thiknesses of 0.315" up to 1.77" (8 mm to 45 mm). -- The coil feed accepts edgebanding from 0.4 mm to 3 mm thick, and strip material can be hand-fed. -- Conveyor feed speed is 29.5 FPM (fixed).Work stations: -- Heated infeed fence for optimum glue penetration. Large capacity Teflon coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine for up to 3 mm thick banding, followed by spring loaded double pressure rollers. -- Single front/rear trimming unit 0.3 HP motor. -- Double top and bottom trimming units (2) 1/2 HP motors. -- Top and bottom scraper/radius scraper. -- Top and bottom buffing station (2) 0.16 HP motors.Also available in 220V/3PH/ 60 Hz

CANTEK - MX340M, ...EdgebanderThe "MX340" from CANTEK is designed to be a compact and durable Edgebander. -- Machine equipped with: End trimming; flush trimming; PVC scraping; buffing. -- The "MX340" Edgebander is operated through a PLC Control System with an LED display and keypad.Specifications: -- Handles panel thickness of 0.315" - 1.77" (8 mm to 45 mm); min. part length: 3-1/2"; min. part width: 3-1/2". -- Coil feed accepts edgebanding from 0.4 mm to 3 mm thick; strip material can be handfed. -- Conveyor feed speed: 23 FPM (fixed).Workstations: -- Heated infeed fence for optimum glue penetration; large capacity Teflon coated glue pot; 2.64 Lbs. -- Pneumatically operated guillotine for up to 3 mm thick banding; followed by spring-loaded double-pressure rollers. -- Single front/rear trimming unit: 0.3 HP motor. -- Double top & bottom trimming units; (2) 1/2 HP motors. -- Top & bottom scraper/radius scraper. -- Top & bottom buffing station; (2) 0.16 HP motors.NOTE: Edgebander was used for approx. (1) year before health issues forced closure of shop; has been stored & covered since.

CANTEK MX340 Edgebander (Single Phase)The MX340 from CANTEK is designed to be a compact, and durable edgebander. -- This machine is equipped with end trimming, flush trimming, PVC scraping, and buffing. -- The CANTEK MX340 Edgebander is operated through a PLC control system with an LED display and keypad.Specifications: -- The MX340 handles panel thicknesses of 0.315" up to 1.77" (8 mm to 45 mm). -- The coil feed accepts edgebanding from 0.4 mm to 3 mm thick, and strip material can be hand-fed. -- Conveyor feed speed is 29.5 FPM (fixed).Work stations: -- Heated infeed fence for optimum glue penetration. Large capacity Teflon coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine for up to 3 mm thick banding, followed by spring loaded double pressure rollers. -- Single front/rear trimming unit 0.3 HP motor. -- Double top and bottom trimming units (2) 1/2 HP motors. -- Top and bottom scraper/radius scraper. -- Top and bottom buffing station (2) 0.16 HP motors.

CANTEK MX-370P EDGEBANDER (W/ PRE-MILL & CORNER ROUNDING): --Specifications:0.4 - 3 mm Edge thickness, panel thickness 0.315" - 1.77". Minimum panel length 6.7", minimum panel width 3-¾". Heated infeed fence for better glue adhesion. Fixed feed speed 29 FPM.Equipped with: -- Pre-mill (2) 1.5 kW each (12,000 RPM) counter-rotating cutter-heads for removing up to 3mm of the panel edge. -- Quick change 1.2 kg Teflon-coated glue pot is designed for EVA hot-melt glue. The glue pot is a Quick-Change type and can be removed and replaced in less than 1 minute. -- Guillotine shear: The guillotine shear can rough trim coiled material up to 3 mm in thickness. Pressure rollers section consist of one large driven roller, followed by a smaller one. Workstations: -- End Trim: The end trim system is a single motor with (2) saw blades. The unit is mounted on high-precision linear guide rails. -- Top & bottom trimmers with (2) high-frequency motors for top & bottom trimming of the panel. Each motor has an inset knife cutter-head which can be adjusted from flush to beveled finish for thin edges, and radius trimming (2 mm radius). Single motor Corner Rounding Unit Can process between 0.4 - 3 mm and up to a board thickness of 1.77" (45 mm). The multifunctional cutter can round straight or radius edges with a 2 mm radius cutter. -- Radius scraping unit fine-tunes the edge radius while removing knife marks during the milling process on radius edging. Insert knives have a 2 mm radius. -- Buffing unit leaves a super finish on ABS and PVC edging and removes any discoloration on the edges.

CANTEK MX340 EDGEBANDER (COMPACT): (Single Phase)The CANTEK "MX340" is designed to be a compact and durable Edgebander. -- Equipped with: End trimming, flush trimming, PVC scraping, and buffing. -- Edgebander is operated through: PLC Control System, LED display, and keypad.Specifications -- Panel thickness cap.: 0.315" to 1.77" (8 mm to 45 mm). -- Edgebanding coil feed accepts: 0.4 mm -3 mm Thick; strip material can be hand-fed. -- Conveyor feed speed: 29-1/2 FPM (fixed).Workstations -- Heated infeed fence for optimum glue penetration; large capacity Teflon coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine: 3 mm Max. thick banding; followed by spring loaded double pressure rollers. -- Single front/rear trimming unit: 0.3 HP Motor. -- Double top & bottom trimming units: (2) 1/2 HP motors. -- Top & bottom scraper/radius scraper. -- Top & bottom buffing station: (2) 0.16 HP Motors.

CANTEK MX350 EDGEBANDER (W/ PRE-MILLING): -- Specifications:0.4-3 mm Edge thickness, panel thickness 8~45 mm, min. panel width 100 mm (4″), min. panel length 170 mm (6.7″). Equipped with: -- Quick melt Teflon coated glue pot 2.5 Lb capacity. Two spring loaded pressure rollers (One driven, one idling). Automatic coil feed PVC/ABS up to 3mm thick, pneumatically operated guillotine. Laminate strip material can be hand-fed. PLC control system with LED display and keypadWorkstations: -- Pre-Mill station with (2) 1.1 Kw 12,000 RPM trim motors 32 mm (1.25") max. material thickness. -- Single motor front and rear edge trim station. -- Top & bottom trim station with insert knife cutters for radius trimming & bevel trimming. -- Top & bottom scrape station 2 mm radius. -- Top & bottom buffing. -- Feed speed 29 FPM

CASADEI FLEXA 47 RMA8 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING):Specifications: -- 0.4 mm - 3 mm Max. edge thickness cap., (0.5 mm to 3 mm for solid strip edge thickness). 8 mm - 50 mm (0.3" - 1.97") panel thickness cap. (when edgebanding 3 mm PVC max. thickness is 40 mm). -- Minimum panel dimensions 80 mm wide x 140 mm long (3.15" x 5.5"). -- Automatic feed of coil banding and semi-automatic strip fed magazine (strips 1- 3 mm max.) with 3 mm PVC cap. guillotine.Equipped with: -- Teflon coated glue pot w/fast (10 - 12) Min heat-up time; 1 Kg. capacity. -- Guillotine to cut edgebanding in coils up to 3 mm thick. -- Pneumatically controlled pressure section with (3) pressure rollers; 1st drive, (2) idle.Workstations: -- Pre-milling unit with 3 HP - 8,300 RPM High Frequency motors. -- Cutting group moves on rounded ways made of hardened steel, to guarantee high precision and reliability; cutting movement from the top of the panel is synchronized by the PLC control. -- Single motor, double-end trimming saw unit with (1) 0.25 HP - 12,000 RPM High Frequency motor. -- Top & Bottom Trim station with (2) 0.45 HP - 12,000 RPM High-Frequency motors; unit features adjustable copying on vertical & horizontal floating movements, adjustable cutter-head position by mechanical digital readouts, quick release (electrical & mechanical). -- Includes (2) 3 mm radius cutters. -- Corner Rounding Unit: 2-Motor Corner Rounding unit for leading & trailing edges. -- Top & Bottom 3 mm scrape station -- Top & Bottom Buffing unit with (2) 0.20 HP - 1,400 RPM motors. -- Fixed feed speed 23 FPM. -- Actual Model is CASADEI FLEXA 47 RMA8

2016 Casadei Flexa 47 Edgebander 230 V/3 PH

Panel height: 0.3 – 2.36” Coil edge thickness: .12” Strip edge thickness: .015 – .24” Max Overhang Total Top and Bottom: 0.16” Min panel width (min length of 8 ¼”: 3.54” Min panel length (min width of 3-15/16?): 5.5” Feed Speed: 33 f/min Glue Tank GP-200 Power: 2.4 kW Glue Capacity: 3.3 lbs End Trimming Unit IK/200 (each): .3 HP Cutting Speed: 12,000 RPM Blade Tilt: 0-15 deg. Top and Bottom Trimming TT/K Motor (each): .4 HP Cutting Speed: 12,000 RPM Shipping Footprint: 13' x 4' x 5' Weight: 2500 lbs Equipped With: – Pre-Milling Unit – Glue Applicator and Pressure Rollers – Edgebanding Trimming Guillotine – End Trim With 2 Tiltable Motors 0-15 deg. – Top and Bottom Trimming via 2 Motors – Profile/ Radius Scrape – Glue Scraping – Buffing
