Edgebanders For Sale

HOLZ-HER 1329 SPRINT PERFORMANCE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + EVA/PUR GLUING TECHNOLOGY: -- Specifications:Features the HOLZ-HER Patented Dual "GLU-JET" EVA & PÜR Zero Joint Technology System.Edge thickness min./max. 0.4 - 12 mm (0.016 - 0.472"); coiled material 0.4 - 3 mm (0.016 - 0.157").Panel thickness 8 - 60 mm (0.236 - 2.362"); workpiece width min. of 60 mm (2.36"); workpiece length min. 160 mm (6.29"). Programmable Logic Control (PLC) for Pre milling, edge feed, glue application, end trimming, flush trimming, radius trimming, scraping, corner rounding, and buffing. -- Pre milling Station (1802):(2) 2.0 kW (2.68 HP) - 12,000 RPM motors; equipped with: "ProLock" quick change flange including height adjustment for optimum utilization of cutters. -- Edge Magazine (1901):Small 3° feed angle thanks to nozzle design with easy feeding of coils, strips & up to 3 mm and solid wood edging up to 15 mm (0.059").Exclusive "Tractor-Belt Feed System", edge guide equipped with automatic guillotine lock-out for safety. -- Pressure Section (1913 Mot):Servo-controlled pressure section with (1) large driven roller and (2) cantered idle rollers. Straight and tapered pressure rollers for perfect glued joints. -- Gluing System (GJ301 Auto):"GLU JET" Hybrid Technology "thin film technology processes EVA or PÜR Glue in cartridge or granulate form.Motorized, programmable glue nozzle (upper glue line) height positioning. Automatic reload of the glue cartridges or granulated. Workstations: -- End Trimming Unit (1918-P):Front & Rear - (2) 0.35 kW (0.5 HP) - 9,000 RPM motor each; unipoint swivel axis for no re-indexing when changing from flush to bevel end trim (0° - 10° bevel)."PCS" programmable pneumatic changeover from flush to bevel. -- Multi-Function Trimming Unit (1827MOT4): (2) 0.65 kW (0.87 HP) - 12,000 RPM each motor, Servo motors: (1) for horizontal copy wheel & (1) for tool spindle position; programmable top & bottom unit. Unipoint design with no second adjustment with pneumatic, programmable tilt action for changing the degree of bevel.Digital counters for vertical copy wheel position and pneumatic air cylinder for in/out pre-positioning of trimming motor. -- Corner Rounding Unit (1833 MOT4):(2) motors with 0.22 kW (0.30 HP) - 9,000 RPM, for linear edge trimming or vertical corner rounding with (4) Servo programmable positioning motors; Up to 3 mm edge thickness and workpiece thickness min./max.8 - 60 mm (0.31 - 2.36"); max. feed speed 18 MPM (59 FMP) up to 25 mm panel thickness; 26 - 38 mm panel thickness,16 MPM (52 FPM); 39 - 60 mm panel thickness, 2 MPM (6 FPM). -- Profile Scraping Unit (1929-MOT2): Top/Bottom Servo motor controlled, programmable knife position for PVC edges, reversible insert carbide knives.Equipped with air jet blowers and chip collector box. -- Glue Scraping Unit (1964):Flat, Top/Bottom, ball bearing guided and pneumatic controlled. -- Buffing Station (1940):Top & Bottom buffing motors with - 150 mm

HOLZ-HER AURIGA 1308 XL EDGEBANDER (W/PREMILL & CORNER ROUNDING): + "GLU JET" EVA/PUR GLUING TECHNOLOGY: -- Specifications:Servo controls on the following: Pressure beam height; Top & Bottom trimmer; 3 mm radius scraper; auto-tilt on end trim; programmable corner rounder; pneumatic finish scraper. (1) Centrally located hand wheel for manual raising & lowering of the top pressure beam. Rigid workpiece support extending 380 mm; manual central lubrication of the transport chain.Feed speed: 10 MPM (33 FPM). -- Working Capacity: Edge thickness: Min./max. 0.4 - 3 mm (0.02 - 0.12"); coiled material; optional with flush cutters max. 6 mm (0.24").Panel thickness: 6 - 60 mm (0.236 - 2.362"); workpiece width min. of 65 mm (2.559"); workpiece length min.160 mm (6.299"). -- Premilling Station "1801":(2) x 1.2 kW (1.6 HP) - 12,000 RPM Motors; diamond cutter heads with ProLock quick clamping system. Quick-Lock adjustable infeed fence with digital indicator. -- Edge Magazine "1903":For coil & strip processing; utilizes motion detector to ensure accurate, trouble free positioning of edge material.Exclusive "Tractor-Belt feed System": Edge guide equipped with: Automatic guillotine lockout for safety.3° Approach angle allows easy feeding of solid wood edges. -- Pressure Section "1912-3P":With (1) large driven (synchronized with feed speed) roller and (2) cantered idle rollers, adjustable by hand wheel and scale. -- Glue Jet systemUpper glue line height positioning is set automatically with hold down beam setting.Heat up time to ready stage takes only (2 - 30) minutes!NOTE: Granulate requires an "optional" hopper. - Select our "Select Literature" link on the detail page and scroll to "Page-8" for more details.Workstations: -- End Trimming Unit "1918P": Front & rear 2 x 0.45 KW (0.6 HP) - 9,000 RPM motor each,Uni-point swivel-axis for no re-indexing when changing from flush to bevel end trim (0° - 10° bevel)."PCS" programmable pneumatic change-over from flush to bevel. -- Flush/Bevel/Radius Combination Trimming Unit "1827P": Flush 6 mm, radius 3 mm trimming, servo controlled, 2 servo motors (1) for horizontal copy wheel & (1) for tool spindle position).Programmable top & bottom unit 2 x 0.65 KW (0.88 HP) - 12,000 RPM each motor.Uni-Point design with no second adjustment, pneumatic, programmable tilt action for changing the degree of bevel,Digital counters for vertical copy wheel position and pneumatic air cylinder for in/out pre-positioning of trimming motor. -- Corner Rounding Unit "1832": (1) Motor 0.22 KW (0.30 HP) - 9000 RPM for up to 3 mm edge thickness.Work-piece thickness min./max. 12 - 60 mm (0.473 - 2.362"), Max. feed speed 10 MPM (33 FMP). -- Profile Scraping Unit "1929":Top/Bottom, servo motor controlled/programmable knife position, vertical copy wheel adjustment with quick setting spindle - for PVC edges,Reversible insert carbide knives, equipped with air-jet blowers and chip collector box. -- Glue Scraping Unit "1964":Flat surface, top/bottom,

Holz-Her 1436SEL Primus Edgebander 230 Voltage 60 Cycle 3 Phase Large coil table and capability for coil and strip feeding

HOLZ-HER 1315 EDGEBANDER WITH CORNER ROUNDINGMax. 5/16" (8 mm) solid wood banding & 3 mm PVC cap., 1-3/4" max. panel thickness and 5-1/2" min. panel length.Equipped with: -- Cartridge glue system w/cartridge hopper & "quick melt" feature, automatic magazine for coil, strip & solid edgebanding; HD guillotine for 3 mm PVC, glue applicator nozzle. -- Pressure section with (1) large dia. drive roller & (2) idle rollers, each w/individual pneumatic plunge & pressure control, powered 1st roller with electronic speed control synchronized with chain feed speed.Workstations: -- Double motor end trim "1918" (0.5 HP - 18,000 RPM motor ea. 300 Cy HF motors), adjustable 0° - 10° for chamfer cuts electro-pneumatically. -- Top & bottom flush fine & radius trim unit "1942M" (0.8 HP - 300 Cy HF motors 18,000 RPM Motor ea.), bevels 0° - 15°, SIKO digital readouts. -- "Single Station" corner rounding unit for leading & trailing edge. -- "1929" Top & bottom profile scraper for thick PVC. -- Top & bottom buffing unit "1940" (0.25 HP - 2,600 RPM ea.), tilts 0° - 5°. -- Two feed speed 8/16 MPM (26 & 52 FPM), panel overhang beyond chain 35 mm (1.38").Equipped with: Opdraded Touch Screen Monitor Microprocessor for line control & glue temperature, 10 KVA frequency changer, outboard panel support, and sound enclosure w/interior lights over enclosed workstations of the machine, & used tooling on the stations.

HOLZ-HER 1417 SPRINT Edgebander w/Premilling.Max. 1/2" (12 mm) solid wood banding & 3 mm PVC cap., 2-3/8" max. panel thickness and 5-1/2" min. panel length. -- Pneumatically controlled Pre-milling station with (2) 3 HP - 18,000 RPM motor vertical milling heads, both with pneumatic jump controls, SIKO digital readouts for setup & adjustment.Equipped with: -- Cartridge glue system (quick heat up time) with stackable hopper & floating glue nozzle for automatic height adjustment. -- Automatic magazine for coil, strip & solid edgebanding with heavy duty guillotine for 3 mm PVC. -- Pressure section is servo-motor controlled with: (1) Large drive roller and (2) idle rollers, each w/individual pneumatic plunge & pressure control, 1st roller with direct chain drive synchronized with conveyor belt feed speed.Workstations: -- Double motor end trim (0.5 HP - 300 Cy HF motors), adjustable 0° - 15° for chamfer cuts electro-pneumatically from control panel. -- Top & bottom flush trim unit (0.8 HP - 300 Cy HF motors 18,000 RPM). -- Servo driven top & bottom super finish & radius trim unit (0.8 HP - 300 Cy HF motors 18,000 RPM), bevels 0° - 15° for bevel cuts. -- Top & bottom profile scrapers for up to 3 mm thick PVC banding, radius range from 2 - 5 mm, vertical & horizontal tracing shoes for precise accuracy. -- Top & bottom jump buffing unit (0.25 HP - 2,600 RPM motor ea.), tilts 0° - 5°. -- Variable feed speed 8 - 20 MPM (26 - 65 FPM), panel overhang beyond chain 35 mm (1.38").Complete with: -- Microprocessor line control, 10 KVA Frequency Inverter; SIKO digital readouts on all high frequency trimming units for increased accuracy. -- Includes: Outboard panel support, and sound enclosure w/interior lights over entire machine.

HOLZ-HER - 1411-3, EDGEBANDER Cartridge Glue System, 5 mm edge thickness cap. (up to 13 mm w/optional tooling), 1-3/4" max. panel thickness, and 7" min. panel length.Equipped with: -- Automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff. -- Pressure section with (1) large dia. drive roller & (1) idle. Workstations: -- Double-motor end trim model "1918" (tilting 0° - 10°), 0.5 HP - 18,000 RPM motor each. -- Top & bottom radius trim model "1942", 0.8 HP - 18,000 RPM motor each (trim motors are 0.6 kW HF). -- Top & bottom glue scraper unit "1964", with air jets for blow-off. -- Top & bottom buffing unit "1940" (tilting cap. 0 - 5°), 0.2 HP - 1,400 RPM Motors each. -- Variable feed speed from 36 - 52 FPM. - Fixed outboard panel support. Complete with: -- PLC (Programmable Logic Control) for easy setup and program storage. -- Frequency converter, sound enclosure, and used tooling..

HOLZ-HER STREAMER 1054 EDGEBANDER W/PRE-MILLING: -- Specifications:Capacity: Min/Max. 0.4-6 mm Edge Cap;8 -60 mm panel thickness; Min. panel length 160 mm. Feed-speed, 10 m/Min (33FPM) single speed.Equipped With: -- Pre-Milling, (2) vertical spindles, counter-rotating with jump action and manually adjustable in-feed fence. -- HOLZ-HER "GLU JET" Cartridge System and flat glue nozzle applicator. Glue heat up time 2 to 3 minutes max! -- Pressure Section: With (1) large dia. drive roller & (2) pneumatic pressure controlled idle rollers, horizontal adjustment w/digital indicator. -- Automatic Edge Magazine: For coil and strip feed.Workstations: -- End Trimming Unit: Double motor end trims travel on 45° slides; tilt from 0° to 15°. -- Multi-Function Trimming Unit: Top & Bottom trim station for flush/bevel/radius with digital readouts. -- Profile Scraping Unit: Top and bottom radius scraping unit with mechanical digital readouts positioning. -- Buffing Unit: (2) motor top and bottom buffing.Controls: -- Compact Controls, with swivel control panel at eye height, dual digital thermostats, manual push button on/off switches for glue heat-up, edge magazine and all work-stations. -- Complete With: -- Safety/Sound Hood over all wok-stations, fixed panel support out-rigger, manually adjustable hold-down beam. Original factory documentation. Used tooling on the machine. -- Note: This machine will be available the 2nd week in September.

HOLZ-HER 1411 K-3 SPRINT EDGEBANDER -- Specifications: Cartridge Glue System for EVA & PUR pucks, 5 mm edge thickness cap. (up to 13 mm w/optional tooling), 1.77" max. panel thickness, and 7" min. panel length.Equipped with:Automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff. -- Pressure section with (1) large dia. drive roller & (1) idle. Workstations:Double-motor end trim model "1918" (tilting 0° - 10°), 0.5 HP - 18,000 RPM motor each. -- Top & bottom radius trim model "1942", 0.8 HP - 18,000 RPM motor each (trim motors are 0.6 kW HF). -- Top & bottom glue scraper unit "1929". -- Top & bottom buffing unit "1940" (tilting cap. 0 - 5°), 0.2 HP - 1,400 RPM Motors each. -- Variable feed speed from 36 - 52 FPM. - Fixed outboard panel support. Complete with:PLC (Programmable Logic Control) for easy setup and program storage. -- Frequency converter, sound enclosure, and used tooling.

HOMAG KAL 310/4/A3/S2 EDGEBANDER (W/PRE-MILLING): -- Specifications:Working Capacity: 0.3 - 3 mm Edge thickness cap., min. panel width 22 mm; max. panel thickness 60 mm; Dual speed -- Equipped with: Pre-Milling Unit 3481: (2) motors, 3 kW, 9000 RPM each, pneumatic controlled/jump milling spindles and adjustable, manual with digital indicator in-feed fence. -- Hot Melt Glue System "QA 34" Quick-Melt Unit: with heated glue roller; -- Edge Magazine Unit 2456: Automatic (2) coil/strip magazine, coils 0.3 - 3.0 mm. -- Pressure Section: Pressure roll section with (3) rollers, (1) large dia. driven & (2) idle rollers; with pneumatic pressure control for straight edges -- HOMATIC "NC 21" Power Control System: Controller operates in Windows-XP environment; Keypad w/LCD display, fault diagnostic, etc.; diagnostic analysis from HOMAG service support via Modem. -- Workstations:End Trimming Unit: (2) motors, 0.18 kW - 12,000 RPM each, to cut excess edge on the front & back of the panel. -- Flush/Pre-Trimming Unit 3201: Top & bottom trim station, 0.55 kW - 12,000 RPM +/- 1° angle adjustment, manual positioning with digital counters. -- Fine/Bevel Trim Unit 3216: (2) motors 0.4kW - 12,000 RPM each, manual positioning with digital counters -- Profile Edge Scraping Unit: with electro-pneumatic adjustment -- Buffing Unit 4402: Top and bottom with oscillation. (2) motors, 0.25kW, 2850 RPM -- Complete with & Features:Electronic DC brakes on all trim motors; sound cabin for all workstations. -- Adjustable outboard panel support with swing out arms for up to 800 mm. -- 80 mm Feed track pads; manually adjusted V-groove belt on top pressure beam and Sound/Safety enclosure over workstations. -- Actual Model is HOMAG KAL 310/4/A3/S2Note: This machine has a new display and a new back up one as well!

HOMAG AMBITION 2262 (KAL 210) PRODUCTION EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): + LIGMATECH Return ConveyorSpecifications: -- Working Capacity: Coiled stock min/max Edge thickness 0.4 - 3 mm (0.016. - 0.118"), Panel stock min/max thickness 12 - 40 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18"). -- In-feed Fence:Adjustable in-feed fence with manual digital indicator positioning. -- Pre-Milling Station:Two 3.0 kW (4.0 HP), 150 Hz, 9,000 RPM Motors; equipped with trimming column, (2) horizontal and cross slides with spindle adjustment, electro-pneumatic horizontal jump movement of the first motor; includes electronic frequency inverter for control of motor speed and braking, two (2) dust extraction hoods, air jet panel blow-off device & SIKO digital counters for adjustments. -- Panel Pre-HeaterPre-heating the panel brings the panel to an appropriate temperature for better adhesion; this is especially beneficial in cooler temperatures.Quartz lamp for heating substrate edge before glue application improved edge quality and optimum bonding. -- Multi-Purpose Magazine:A multi-purpose 6-coil magazine expands capability by running coiled material.Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panelon the edgeband. -- Gluing System: (EVA - Hot Melt)QA 34 - Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allow for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gatesLower melting unit equipped with automatic glue level control. Melting capacity: 12 KG/h (26 LBS/h) -- Pressure Section:Manual Adjustment with digital counter, (1) large 160 mm dia. driven & (6) 70 mm dia idle rollers, pneumatic pressure control depending on edge banding material used.WORKSTATIONS: -- End Trimming Unit HL 81:0.8 kW (1.0 HP) x 2 - 200 Hz, 12,000 RPM Motors. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer 30 deg. to straight cut. -- Rough/Pre-Trimming Unit:Top & bottom, 0.55 kW (0.74 HP) x 2 - 12,000 RPM Motors; Height adjustment with the top pressure-beam and tilting range +/- 1°.Manually adjusted with digital counters. -- Profile/Bevel/Corner Rounding Unit FK 11:Multi function 0.4 kW (0.54 HP) x 2)- 12,000 RPM Motor to fine trim the edge overhangs at the work-piece upper & lower edge, as well as trimming around the front & rear vertical edge; Servo controlled, Max. feed speed 20 MPM (65.6 FPM). -- Profile/Bevel Scraping Unit:Top & bottom for thick PVC/ABS, pneumatically activated. -- Flat Glue Scraper Unit:Top & bottom, pneumatically activated to remove potential glue squeeze-out. -- Buffing Unit:Top & bottom edge buffing/polishing. -- Spraying Units:Top/Bottom spraying device is designed for applying a separating agent, for easier cleaning of any residual

HOMAG AMBITION 2240 PRODUCTION EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Working Capacity: Coiled stock min/max Edge thickness 0.4 - 3 mm (0.016. - 0.118"), Strip material min/max Edge Thickness 0.4 - 6 mm (0.16 - 0.234"),Panel stock min/max thickness 12 - 40 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18") -- In-feed Fence:Adjustable in-feed fence with manual digital indicator positioning. -- Pre-Milling Station:Two 3.0 kW (4.0 HP), 150 Hz, 9,000 RPM Motors; equipped with trimming column, (2) horizontal and cross slides with spindle adjustment, electro-pneumatic horizontal jump movement of the first motor.includes electronic frequency inverter for control of motor speed and braking, two (2) dust extraction hoods, air jet panel blow-off device & SIKO digital counters for adjustments. -- Panel Pre-HeaterPre-heating the panel brings the panel to an appropriate temperature for better adhesion; this is especially beneficial in cooler temperatures.Quartz lamp for heating substrate edge before glue application improved edge quality and optimum bonding. -- Multi-Purpose Magazine:A multi-purpose 2-coil magazine expands capability by running coiled material & strips. Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panelon the edgebanding. -- Gluing System: (EVA - Hot Melt)QA 3 - Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gatesLower melting unit equipped with automatic glue level control. Melting capacity: 12 kG/Hr (26 Lbs/Hr) -- Pressure Section:Automatic pressure zone adjustment (Servo), (1) large 160 mm dia. driven & (6) 70 mm dia. idle rollers, pneumatic pressure control depending on edgebanding material used.Work Stations End Trimming Unit HL 81:0.8 kW (1.0 HP) x 2 - 200 Hz, 12,000 RPM Motors. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer 30° to straight cut. -- Top & Bottom Flush Trimming Unit:Top & bottom, 0.4 kW (0.74 HP) x 2 - 12,000 RPM Motors; Height adjustment with the top pressure-beam and tilting range +/- 1°. -- Profile/Bevel/Corner Rounding Unit FF 12:Multi-function 0.4 kW (0.54 HP) x 2 - 12,000 RPM Motor to fine trim the edge overhangs at the work-piece upper & lower edge, as well as trimming around the front & rear vertical edge. Max. feed speed 20 MPM (65.6 FPM) -- Profile/Bevel Scraping Unit PN 10:Top & bottom for thick PVC/ABS, pneumatically activated/adjustment. -- Flat Glue Scraper Unit:Top & bottom, pneumatically activated to remove potential glue squeeze-out. -- Buffing Unit FA 11:Top & bottom edge buffing/polishing, pneumatically activated.Operator Interface: HOMATIC PC 22 Power Control w/Touch Screen:Controller functions in Windows

HOMAG AMBITION 2274 (KAL 370/6/A3) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Working Capacity: Coiled stock min/max Edge thickness 0.3 - 3 mm (0.011. - 0.118"), Strip material min/max Edge Thickness 0.4 - 1 mm (0.016 - 0.039"),Panel stock min/max thickness 8 - 60 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18").Minimum workpiece width: 2.36" (60 mm) with workpiece thickness ≤ 22 mm) & 4.13" (105 mm) with workpiece thickness > 22 mm). -- Cleaning Agent Spraying Units:Top/Bottom spraying device prior to workpiece pre-milling. Designed for applying a separating agent, for easier cleaning of any residual glue on the panel. -- In-Feed Fence: Pre-heated manually adjustable in-feed fence with digital indicators. -- Pre-Milling Station:(2) 2.2 HP (3.0 kW) - 150 Hz, 9,000 RPM vertical jointing spindle motors; equipped with panel blow-off device and SIKO digital counters for adjustments. -- Panel Pre-Heat Unit: Quartz lamp for heating substrate edge before glue application. -- Edge Magazine:A multi-purpose 2-coil magazine expands capability by running coiled material & strips. Maximum roll diameter: 400 mm & 830 mm.Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panelon the edgebanding. -- Gluing System Homag Quickmelt: QA 3 - Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gatesLower melting unit equipped with automatic glue level control. Melting capacity: 12 kG/Hr (26 Lbs/Hr). Ultra-fast five-minute (5) heat-up time. -- Pressure Section: Programmable (Servo), automatic pressure zone adjustment, (1) large 150 mm dia. driven & (4) 70 mm dia. idle rollers, pneumatic pressure control depending on edgebanding material used.Workstations: -- End Trimming Unit:(2) 1 HP (0.8 kW) - 200 Hz, 12,000 RPM Motor ea. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer to straight snip. Programmable (Servo). -- Rough/Pre-Trimming Unit:(2) 0.55 kW 0.74 HP (0.55 kW) - 12,000 RPM Motors, tilting range +/- 1° & counter-rotating to machine feed to prevent blowout & .Height adjustment synchronized with the top pressure-beam .With digital counters. -- Profile/Bevel/Corner Rounding Unit:(2) 0.54 HP ( 0.4 kW) - 12,000 RPM, Multi-function Motors to fine trim the edge overhangs at the work-piece upper & lower edge, as well as trimming around the front & rear vertical edge.By way of the machine control, this unit adjusts between a radius and a chamfer without a tooling change.Max. feed speed 20 MPM (65.6 FPM) when using "Corner Rounding Unit". -- Profile/Bevel Scraping Unit:Top & bottom for thick PVC/ABS, electro-pneumatic positioning & pneumatically activated. Pneumatically-controlled

HOMAG AMBITION 2274 (KAL 370/6/A3) EDGEBANDER (W/PRE-MILL/HIGH PRODUCTION) (aka "TAPE ROCKET"): -- Specifications: Working Capacity: Coiled stock min/max Edge thickness 0.3 - 3 mm (0.012. - 0.125"), Strip material min/max Edge Thickness 0.4 - 1 mm (0.016 - 0.039"),Panel stock min/max thickness 8 - 60 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18"). Minimum Work piece length 610 mm(24").Minimum workpiece width: 2.36" (60 mm) with workpiece thickness ≤ 22 mm) & 4.13" (105 mm) with workpiece thickness > 22 mm). -- Cleaning Agent Spraying Units:Top/Bottom spraying device prior to workpiece pre-milling. Designed for applying a separating agent, for easier cleaning of any residual glue on the panel. -- In-Feed Fence: Pre-heated manually adjustable in-feed fence with digital indicators. -- Pre-Milling Station:(2) 2.2 HP (3.0 kW) - 150 Hz, 9,000 RPM vertical jointing spindle motors; equipped with panel blow-off device and SIKO digital counters for adjustments. -- Panel Pre-Heat Unit: Quartz lamp for heating substrate edge before glue application. -- Edge Magazine:A multi-purpose 2-coil magazine expands capability by running coiled material & strips. Maximum roll diameter: 400 mm & 830 mm.Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panelon the edgebanding. -- Gluing System Homag Quickmelt GA 65 / QA 65: QA 65 - EVA Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gatesLower melting unit equipped with automatic glue level control. Melting capacity: 12 kG/Hr (26 Lbs/Hr). Ultra-fast five-minute heat-up time. -- Pressure Section: Programmable (Servo), automatic pressure zone adjustment, (1) large 150 mm dia. driven & (4) 70 mm dia. idle rollers, pneumatic pressure control depending on edgebanding material used.Workstations: -- End Trimming Unit PK 25:(2) 1 HP (0.8 kW) - 200 Hz, 12,000 RPM Motor ea. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer to straight snip. Programmable (Servo). -- Fine Trimming Unit PF20:(2) 0.54 HP ( 0.4 kW) - 12,000 RPM, fine trimming unit for edge overhangs at the work-piece upper & lower edge.Operator Interface: -- Power Touch Control Multi-Touch Screen Controller on separate console with 21.5" Full HD flat screen display, keyboard and mouse. Functions in Windows environment, includes fault diagnostic, OS9 real-time operating system."WoodScout", included graphic diagnostic tool designed to increase throughput and decrease down time. Graphical PLC diagnosis display of the error location in the machineCustomer-specific data base system that allows the operator to enter the reason for the error as well as the corrective measures to assist with future tro

- Min. panel height 0.47 inch - Max. panel height 1.57 inch - Min. edge thickness 0.01 inch - Max. edge thickness 0.24 inch - Max. forward feed speed 82.02 ft/min - Top pressure with rubber belt - No. Panel Sizing / Milling units 2 Pre-milling unit - Lamps to preheat the side of the panel - Edge coil magazine - Gluing system - glue pot for EVA hot melt glue - premelter for EVA hot melt glue - QA65 - Roller set to press the edge - no. pressure roller 7 - with positioning by NC No. Edge Processing Units 6 First Processing Unit - End trimming Constructor model HL81 - no. motors 2 - with positioning by NC Second Processing Unit - top and bottom rough trimming - no. motors 2 - with positioning by NC Third Processing Unit - Multi Function trimming and corner rounding - Constructor model - FK11 - no. motors 2 - with positioning by NC Fourth Processing unit - edge scraping - with positioning by NC Fifth Processing Unit - glue scraping - with positioning by NC Sixth Processing Unit - buffing - no. motors 2 Spray unit Control system Power Touch

HOMAG OPTIMAT KL-75 / A20 EDGEBANDER 0.4 - 20 mm (3/4") Thickness edgebanding cap., 70 mm min. panel thickness.Equipped with: Automatic edge feed magazine for coil, HPL & strip stock; "Hot Melt" glue system with QA34 Quickmelt unit, with reversible glue roll applicator; pneumatically controlled pressure roll section with 7 pressure rollers. -- Workstations: Double motor front & rear end trim, straight & chamfer trimming (0.5 HP - 10,400 RPM ea. motor). -- Top & Bottom rough trims (2 HP - 11,500 RPM ea. motor). -- Top & Bottom fine trims, tiltable 0° - 30° (0.5 HP - 10,980 RPM ea. motor); open space for workstation. -- Adjustable top and bottom glue scraper. -- Electronic Height adjustment for Top pressure beam with double V-belts, 80 mm wide Heavy Duty feed chain w/rubber pads. -- Feed speed variable up to 35 MPM. -- Complete with: SIKO Digital adjustments on T & B Flush and Fine Trim. -- Homatic NC21 Controller, Fixed position Outrigger panel support, insulated sound cabins w/interior and overhead lighting for all trim workstations. -- Includes Owners Manual and the Electrical Schematics.NOTE: Suggested replacement parts needed, as noted by our technician - all the track pads, the hold-down belt, the pressure roller, and likely a glue pot rebuild. Estimated cost for these parts, not including labor is $5600. The replacement of these parts is NOT included in the machine price.

HOMAG KAL 210 AMBITION 2260 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications:Coiled stock min/max. Edge thickness 0.4 - 3 mm (0.016. - 0.118"), Strip material min/max Edge Thickness 0.4 - 6 mm (0.16 - 0.234"). -- Panel stock min/max. thickness12 - 40 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18"). -- In-feed Fence: Adjustable in-feed fence with manual digital indicator positioning. -- Pre-Milling Station: Two 3.0 kW (4.0 HP), 150 Hz, 9,000 RPM Motors; equipped with trimming column, (2) horizontal and cross slides with spindle adjustment, electro-pneumatic horizontal jump movement of the first motor;Includes electronic frequency inverter for control of motor speed and braking, two (2) dust extraction hoods, an air-jet panel blow-off device & SIKO digital counters for adjustments. -- Panel Pre-Heater: the Pre-heater brings the panel to an appropriate temperature for better adhesion; this is especially beneficial in cooler temperatures. -- Multi-Purpose Magazine: 2-Coil magazine expands capability by running coiled material & strips, magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panel on the edgebanding. -- Gluing System: (EVA - Hot Melt) QA 3 -Quick Melt Overhead Unit & heated roller applicator; digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gates, lower melting unit equipped with automatic glue level control. Melting capacity: 12 KG/Hr (26 LBS/Hr). -- Pressure Section: Automatic pressure zone adjustment (Servo), (1) large 160 mm dia. driven & (6) 70 mm dia. idle rollers, pneumatic pressure control depending on edgebanding material used. -- WORKSTATIONSEnd Trimming Unit HL 81: 0.8 KW (1.0 HP) x 2 - 200 Hz, 12,000 RPM Motors. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer 30° to straight cut. -- Top & bottom Flush Trimming Unit: Top & bottom, 0.4 kW (0.74 HP) x 2 - 12,000 RPM Motors; Height adjustment with the top pressure-beam and tilting range +/- 1°. -- Profile/Bevel/Corner Rounding Unit FF 12: Multi-function 0.4 KW (0.54 HP) x 2 - 12,000 RPM Motor to fine trim the edge overhangs at the work-piece upper & lower edge, as well as trimming around the front & rear vertical edge. Max. feed speed 20 MPM (65.6 FPM) -- Profile/Bevel Scraping Unit PN 10: Top & bottom for thick PVC/ABS, pneumatically activated/adjustment. -- Flat Glue Scraper Unit: Top & bottom, pneumatically activated to remove potential glue squeeze-out. -- Buffing Unit FA 11: Top & bottom edge buffing/polishing, pneumatically activated. -- Operator & Machine Control:HOMATIC PC 22 Power Control w/Touch Screen: Controller functions in Windows environment and features: Keypad w/LCD flat-screen display, fault diagnostic, OS9 real-time operating syst

HOMAG AMBITION 2262 (KAL 210) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING); PRODUCTION EDGEBANDER): -- Specifications: Working Capacity: Coiled stock min./max. Edge thickness 0.4 - 3 mm (0.016. - 0.118"); strip material min./max. Edge Thickness 0.4 - 6 mm (0.16 - 0.234").Panel stock min./max. thickness 12 - 40 mm (0.472" - 1.574"). Panel Overhang 30 mm (1.18"). -- Infeed Fence:Adjustable infeed fence with manual digital indicator positioning. -- Pre-milling Station:(2) 3.0 kW (4.0 HP), 150 Hz, 9,000 RPM Motors; equipped with: Trimming column, (2) horizontal & cross-slides with spindle adjustment.Electro-pneumatic horizontal jump movement of the 1st motor; includes electronic frequency inverter for control of motor speed and braking.(2) Dust extraction hoods, air jet panel blow-off device & SIKO digital counters for adjustments. -- Panel Preheater:Preheating the panel brings the panel to an appropriate temperature for better adhesion; this is especially beneficial in cooler temperatures.Quartz lamp for heating substrate edge before glue application improved edge quality and optimum bonding. -- Multipurpose Magazine:2-Coil magazine expands capability by running coiled material, strips, and solid wood bands. Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table allowing the Operator to center the panelon the edgeband. -- Premelting System: Overhead Premelting Unit -- Gluing System: EVA - Hot Melt.QA 34 - Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allow for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gates.Lower melting unit equipped with: Automatic glue level control; melting capacity: 12 kG/h (26 Lbs/Hr). -- Pressure Section:Manual adjustment with digital counter: (1) Large 160 mm dia. driven & (6) 70 mm dia. idle rollers; pneumatic pressure control depending on edgebanding material used.WORKSTATIONS: -- End Trimming Unit:(2) 0.8 kW (1.0 HP) - 200 Hz, 12,000 RPM Motors to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer 30° to straight cut. -- Rough/Pre-trimming Unit:Top & bottom, (2) 0.55 kW (0.74 HP) - 12,000 RPM motors; height adjustment with the top pressure beam and tilting range +/- 1°. Manually adjusted with digital counters. -- Multifunction Profile/Bevel/Corner Rounding Unit:Multifunction (2) 0.4 kW (0.54 HP) - 12,000 RPM Motors to fine trim the edge overhangs at the workpiece upper & lower edge, as well as trimming around the front & rear vertical edge; Servo controlled.Max. feed speed 0f 20 MPM (65.6 FPM) when corner rounding. -- Profile/Bevel Scraping Unit:Top & bottom for thick PVC/ABS, pneumatically activated. -- Flat Glue Scraper Unit:Top & bottom, pneumatically activated to remove potential glue squeeze-out. -- Buffing Unit:Top & bottom edge buffing/polishing.

HOMAG EDGETEQ S-500 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications:0.3 - 3 mm (0.012 - 0.125") edge material thickness; 8 - 60 mm (0.3' - 2.375") panel thickness; 160 mm (6.375") min. panel length and 70 mm (2.75") min. panel width.High flexibility is achieved as all edge materials can be processed: 0.3 mm Melamine, up to 3 mm ABS, PP, PVC and wood as coil material.For perfect high-gloss parts, important components such as the motor-driven top pressure and the automatic adjustment of the glue joint scrapers are used.Special tracing elements are ideal for processing of acute angled or obtuse angled parts or parts with hinge holes and transversal grooves.Variable Production Feed Speeds from 16 - 30 MPM (52 - 98 FPM). -- Equipped with: Separating agent spraying unit. -- Pre-milling Station: (2) Motors @ 2.25 kW (3.0 HP), 12.000 RPM; LH & RH rotation w/pneumatic jump control for chip-free and clean panel edges. Equipped with diamond cutter heads. -- Infeed fence with Servo motor positioning. -- Infrared Radiant Quartz Heating Unit between glue roller and pressure section. -- Automatic Edge Magazine for strip & coil stock, strips 0.4 mm - 12 mm (0.015 - 0.47"), coils up to 3 mm PVC with "HD" guillotine. -- "Quick Change" Glue Tank for maintenance, glue type & color change. -- Pressure Section: 1st. Roller driven plus (2) idle rollers, timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- HOMAG "PowerTouch control, memory: 256 MB RAM, 1 GB Flash Card Drive. -- Workstations: End Trimming: (2) Motors @ 0.35 kW (1/2 HP) - 12,000 RPM; automatic chamfer from control panel 0°- 15°. -- Multistage MS40 Flush/Bevel-Fine/Radius Trimming Unit:Top/bottom: (2) Motors, 0.55 kW (3/4 HP) - 12,000 RPM, auto-tilt positioning 0° - 25°; with combination flush/radius/chamfer cutterheads. -- Multifunctional trimming unit MF60 Servo trim - Horizontal and vertical tracing wheels, equipped with brushless multi-axis Servo motors for positioning of work unit & horizontal copy wheels for quick changeover. Includes (3) positioning options: Profile 1, profile 2, and flush trimming; nested top copy system. -- Corner Rounding Unit: (1) 0.35 kW (1/2 HP) - 12,000 RPM Motor for leading & trailing edges, vertical corner rounding of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Scraping, multi-profile (PVC): Top/bottom with (2) profiles (1 mm and 2 mm or 3 mm instead of 2 mm), Servo control positioning of vertical & horizontal copy wheels. PVC scrape collection box. -- Flat Glue Joint Scraping Unit: Flush top/bottom on panel surface with floating insert knives. -- Buffing Unit: Top & bottom (2) motors, 0.10 kW (0.125 HP) 2,800 RPM. -- Operator Interface: HOMAG powerTouch2 control with clearer structure, 30% faster, more intuitive, more ergonomically comfortable, and remote service Support. 22" Color HD wide touch-screen display, soft keypad & internal modem for rem

As Taken From Service: Includes return conveyor

Homag KAL 310 NOT INCLUDING THE RETURN Year of MFG 2006 Control voltage 24 V total connected load 50A recommended fuse 28kW nominal current pprox.. 39A Dust extraction air velocity (min.) 28 m/sec (91.84 ft/sec) air volume 4090 m3/hr (2407 cfm) static pressure 250 mm/ws (9.84”/ws) CompressedAir connection size ¾” pressure required 7 bar (100 psi) consumption / volume 705 sl/min (24.89 cfm) Foundation requirements according to layout drawing # 5-236-01-0360 Electrical equipment installed according to UL regulations. Voltage supplied must not fluctuate in excess of+/- 5% of its stated value. Voltage must be balanced phase-to-phase and phase-to-ground. Note: The stated values are only applicable to the machine as specified. Adding or deleting optional equipment may change service connection requirements. In case ofvariations in technical specifications and capacities between the base machine and working units, the specifications and capacities given for the working units are to be considered correct. Conditions offloor at installation site must adhere to foundation plan. Adjustable lnfeed Fence Homag Unit #0005 • with digital mechanical counter Pre-Milling Unit Homag Unit #3481 HOMAG KAL 525 • with two (2) motors 3 kW, 150 cycle, 9000 rpm • for max. tool diameter of 125 mm (4-15/16") • equipped with trimming column • two (2) horizontal and cross slides with spindle adjustment • electro-pneumatic horizontal jump movement of first motor • two (2) dust extraction hoods • air jet for panel cleaning • with two (2) DIA jointing heads 125 x 35 x 30 mm(4-15/16" x 1-3/8" x 1-1/8"), DKN, z = 2 x 3 • max. workpiece thickness 30 mm (1-1/8") • electronic frequency inverter for control of motor speed and braking Noise Protection Stepped Homag Unit #0424 • for pre-trimming unit • allows for inlay of long strips • centralized dust extraction port Panel Pre-Heater Homag Unit #2325 • quartz lamp for heating substrate edge before glue application • for improved edge quality and optimum bonding QA 34 Quick Melt Gluing Unit Homag Unit #2123 • specially designed by Ho mag - the original innovator of the quick melt syste • lower reservoir unit is designed with only seven (7) wearing parts, which allows for ease of adjustment and reduces maintenance costs • ideally suited for quick heat-up time and color changes • one bolt secures lower unit to drive mechanism • special coupling eliminates alignment of universal drive joint • digitally displayed thermostat for both upper and lower unit, along with heated glue roller allow for excellent control of temperature for optimum bonding results • individual adjustment for front and rear glue gates • upper reservoir for glue granules • glue roller diameter 34 mm (1-11/32") • lower melting unit equipped with automatic control of glue level Glue Roller Drive Homag Unit #2141 • eliminates glue charring on glue roller • lengthens pot life of glue during idle running time o
