Woodworking Equipment For Sale

Brandt KDF 440 Highflex 1440 Edgebander

Great Condition Recently Fully Serviced Profile Scrapers and Surface Scrapers No Premill/No Buffers

Brandt KDF 650 Edgebander

Brandt Ambition 1110 Edgebander

2007 Brandt KDF 680 Single sided Edgebander with Pre Milling and Corner Rounding

BRANDT AMBITION 1440 (KDF-440 C) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") panel thickness, 160 mm (6.30") min. panel length, 70 mm (2.76") min. panel width.Equipped with: -- Adjustable Infeed Fence: Manual adjustment. -- Joint Trimming/Pre-milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, left-hand & right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone: (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touch Screen Monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors with 0° - 15° automatic chamfer, pneumatic adjustment & activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt with Horizontal & Vertical Tracing wheels, Brushless multi-axis Servo motors for positioning of work unit & horizontal copy wheels for quick changeover with (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit: (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Servo motors for positioning of work unit & horizontal copy wheels. Either radius or chamfer cutters can be mounted, 3 mm (0.12") max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"); Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box, pneumatic adjustment using "POWERTOUCH" control, pneumatic disengagement. -- Top & Bottom Glue Scraping Unit: Flush on panel surface with floating insert knives. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle hold-down rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model is BRANDT AMBITION 1440 (KDF 440 C).

BRANDT AMBITION 1440 FC (KDF-440 FC) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") panel thickness, 160 mm (6.30") min. panel length, 70 mm (2.76") min. panel width.Equipped with: -- Heated Adjustable Infeed Fence: Radiant Heated with Manual adjustment. -- Joint Trimming/Pre-milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, left-hand & right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone: (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touch Screen Monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors with 0° - 15° automatic chamfer, pneumatic adjustment & activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt with Horizontal & Vertical Tracing wheels, Brushless multi-axis Servo motors for positioning of work unit & horizontal copy wheels for quick changeover with (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit: (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for Top & Bottom, Leading & Trailing edges & Corner Rounding of panels, Servo motors for positioning of work unit & horizontal copy wheels. Either radius or chamfer cutters can be mounted, 3 mm (0.12") max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"); Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box, pneumatic adjustment using "POWERTOUCH" control, pneumatic disengagement. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle hold-down rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model is BRANDT AMBITION 1440 FC (KDF 440 FC).

Pre-milling Unit End Trim Profile/Flush trimming Unit Corner Rounding Unit Profile scraping Buffing Max feed speed: 10 m/min Maximum panel thickness: 50 mm

Brandt KDF 440C Edgebander

Brandt 1100 Edgebander Seller closed shop about 1 year ago and put this in storage. Claims they were using the machine up until they shut down.

BRANDT KDF 650 C EDGEBANDER WITH PRE-MILL AND CORNER ROUNDING Specifications: 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator."PC-16" Program Control with: 7-1/2" VGA Screen, 8 MB IDE flash disk, 8 MB RAM, internal modem for remote diagnostic link; signal infeed light to ensure proper spacing between panels.Equipped with: Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. -- Automatic magazine for strip & coil stock, 3 mm PVC guillotine, -- (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover.Workstations: -- End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; -- Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. -- 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blowoff nozzles -- Top & bottom buffing (0.25 HP - 1,400 RPM motors). -- End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive.Complete with:Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling.NOTE: Actual Model "KDF 650 C".SELLER STATES: Edgebander has many new parts including motors and glue pot. CPU has failed. Unit is inoperable in current condition. Being sold as-is, non-working for parts or repair by new owner. Quoted new controller for $ 8,000.00 plus installation.

BRANDT KDF 440 C (AMBITION 1440 FC) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & 3,359 Hrs.Specifications: -- Edge & Workpiece Capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") Panel thickness, 160 mm (6.30") Min. panel length, 70 mm (2.76") Min. panel width.Equipped with: -- Adjustable Infeed Fence: Motorized adjustment with 0.049 kW (0.07 HP) Motor. -- Joint Trimming/Pre-Milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, Left-Hand & Right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, 3 mm (0.12") PVC Max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). -- Workpiece Preheating Unit -- Pressure Zone: (1) Driven & (2) Idle Rollers, Timed pneumatic pressure controlled, Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming. -- BRANDT "POWERTOUCH" Control: With 21" HD LCD Touchscreen monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors, with 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt, with Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. -- Multi-Functional Trimming Unit: (2) 0.4 kW (1/2 HP) 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERTOUCH" control, Pneumatic disengagement. -- Top & Bottom Glue Scraping Unit: Flush on panel surface, with Floating insert knives. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) 2,750 RPM Motors.Complete with: -- Motorized, programmable hold-down pressure beam with 0.12 kW (0.16 HP) Motor, 1.5 kW (2 HP) Feed motor, 32" Diameter Coil table, Padded sound enclosure.NOTE: CPU needs to be replaced.

BRANDT KDF 650 (1650 HIGHFLEX) Edgebander, with 3,339 Hrs. (As of 10/31/23), Pre-Mill & Corner RoundingSpecifications: -- 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. -- Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. -- "PC-16" Program Control with: 21-1/2"; Display, signal infeed light to ensure proper spacing between panels.Equipped with: -- Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. -- 32"; Dia. Coil table. -- Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover.Workstations: -- End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; -- Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. -- 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blow off nozzles; -- Top & bottom buffing (0.25 HP - 1,400 RPM motors). -- End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive.Complete with: -- Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling.NOTE: Actual Model "KDF 650".NOTE: Specifications must be confirmed.Machine Dimensions: 254"; x 50"; x 68"; H.Machine Dimensions with Outboard Panel Support Extended: 254"; x 66"; x 68"; H.

--MAKE AN OFFER!--VERY GOOD CONDITION-- BRANDT KDF 650 (1650 HIGHFLEX) Edgebander, with 3,339 Hrs. (As of 10/31/23), Pre-Mill & Corner Rounding Specifications: 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. "PC-16" Program Control with: 21-1/2” Display, signal infeed light to ensure proper spacing between panels. Equipped with: Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. 32” Dia. Coil table. Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover. Workstations: End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blowoff nozzles; Top & bottom buffing (0.25 HP - 1,400 RPM motors). End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive. Complete with: Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling. NOTE: Actual Model "KDF 650". NOTE: Specifications must be confirmed. Machine Dimensions: 254” x 50” x 68” H. Machine Dimensions with Outboard Panel Support Extended: 254” x 66” x 68” H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

--make offer--requires repair-- BRANDT KDF 440 C/AMBITION 1440 FC EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & 3,359 Hrs. Specifications: Edge & Workpiece Capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") Panel thickness, 160 mm (6.30") Min. panel length, 70 mm (2.76") Min. panel width. Equipped with: Adjustable Infeed Fence: Motorized adjustment with 0.049 kW (0.07 HP) Motor. Joint Trimming/Pre-Milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, Left-Hand & Right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, 3 mm (0.12") PVC Max. coil thickness. Hot Melt Glue Application Unit: 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). Workpiece Preheating Unit Pressure Zone: (1) Driven & (2) Idle Rollers, Timed pneumatic pressure controlled, Servo motor positioning for programmable edge thickness changeover. Feed Speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming. BRANDT "POWERTOUCH" Control: With 21" HD LCD Touchscreen monitor. Workstations: Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors, with 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERTOUCH" control. Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt, with Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. Multi-Functional Trimming Unit: (2) 0.4 kW (1/2 HP) 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERTOUCH" control, Pneumatic disengagement. Top & Bottom Glue Scraping Unit: Flush on panel surface, with Floating insert knives. Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) 2,750 RPM Motors. Complete with: Motorized, programmable hold-down pressure beam with 0.12 kW (0.16 HP) Motor, 1.5 kW (2 HP) Feed motor, 32" Diameter Coil table, Padded sound enclosure. NOTE: CPU needs to be replaced. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

--make offer--excellent condition-- BRANDT OPTIMAT KTD 820 Contour Edgebander Specifications: Designed for straight, curved (contour), or beveled edgebanding. Edgebanding thickness 0.4 - 3 mm (0.02” - 0.12”). Coil cutoff 0.4 - 3 mm (0.02” - 0.12”) (Max. edge height 45 mm/1.77”). Panel thickness 16 - 40 mm (0.63” - 1.57”). Min. radius 25 mm (0.98”). Min. panel length 180 mm (7.09”), Min. panel width 100 mm (3.94”). Feed speeds 0.7 - 4.2 MPM (2.30 - 13.80 FPM). Equipped with: 33” Dia. Vertical coil table. Small glue pot for quick heat-up. Magazine for coil or solid strips. Guillotine. Handheld gluing unit, with Tool balancer & Rotating jib with 8’ Travel. (2) 23-1/2” x 27-1/2” x 35 H Work tables. Large panels can be glued by guiding handheld gluing unit around panel mounted to vacuum suction table. Small panels can be glued by guiding panel along gluing unit mounted to table. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Brandt KDN 210 Edgebander

BRANDT KDN 210B EDGEBANDER0.4 - 3 mm (1/8") Edge thickness cap., 8 - 50 mm (0.3" - 2") panel thickness, 60 mm (2.3") min. panel width and 140 mm (5-1/2") min. length.Equipped with: -- Hot Melt granulate glue system with "Quick Melt" start-up (10 - 12 Min heat-up) with reversible rotation glue applicator roller and automatic reduction glue temperature adjustment (when idle drops to 150°, 2-1/2 Min to re-activate). -- Automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock are fed automatically through strip feed magazine. -- 3-Roller pressure section (1st driven, next (2) idle) w/electronically controlled and feed speed synchronized drive roll.Workstations: -- Vertical travel double-motor front & rear end trim with tilting of 0°- 15° cap. (0.24 HP - 12,000 RPM motors). -- Top & bottom flush/bevel trimmers (0.36 HP - 12,000 RPM motors), bevel 0° to 15°. -- Top & bottom buffing unit (0.15 HP - 2,750 RPM motors). -- Feed speed of 30 FPM. Features: -- Operator control panel at eye-level. -- Automatic height adjustment with top pressure beam for all work stations. -- Digital height indicator on hold-down beam. -- Electronic motor brakes on trimmers.Complete with: 200 Hz Electronic frequency inverter, used tooling, sound enclosure w/window, and operators manual.

Brewer BR-425 Step Planer

Brewer Step Planer 24in, BR425, S/N 12286, 50HP Electric Motor Up to 6" thick
