Woodworking Equipment For Sale

HOLZMA PROFIMAT HPL 500 38/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Cutting length & pull-back; 6.7" (170 mm) max. main blade projection; 40 HP (29.8 kW) Main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Infinitely variable speed from 0 - 492 FPM (0 - 150 MPM), constant return of 492 FPM (150 MPM).Carriage is electronically & automatically controlled (cutting height & length) through the CADmatic according to the material/program being processed."Power-Loc" quick change system for fast and easy saw blade change.NC Controlled scoring saw adjustment from the control panel during operation -- Pusher Fence:Rack & pinion digital drives with AC Servos on both sides, forward speed 295 FPM (90 MPM), return speed 295 FPM (90 MPM).(7) Material clamps which open up to 6.7" (170 mm): (3) Standard clamps with two fingers & (4) clamps with one finger.(4) Trimming rakes for thin strips/scrap removal are attached at the clamps. -- Operator Interface:HOLZMA "Power Touch Control" IPC multi-tasking controller with Windows "7 PRO" + "CADmatic 4.0 PRACTIVE" operating system;Intel i5 Dual-core Processor, Intel HD graphics card, 4GB RAM, SATA 2-250GB hard drive, (6) USB ports, (1) serial port, ATI/DVI video port, Standard industrial keyboard connection,21.5" LCD "Touch-Screen" monitor with real-time moving 2D & 3D graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.(2) Ethernet 10/100 interface connections; downloading from office PC is possible. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (3) Air flotation tables 85" x 31.5" (2,160 x 800 mm) with (1) central blower unit. -- Rear Lift Table:7-Ton (14,000 LBS), 4-Column electro-hydraulic powered rear lift table running lengthwise with fork cut-outs, 150" x 63" (3,800 x 1,600 mm) capacity. Powered rollers are 4.2" (107 mm) dia x 7.79" (198 mm) spacing, 39 FPM (12 MPM) infeed/outfeed speed; Feeding material from (3) sides is possible with additional roller conveyors.22" (560 mm) Max. bunk height from floor level; 30.7" (780 mm) max. bunk height with a pit or risers; -- Complete With: Holzma's Unique "EcoPlus" System offers energy savings up to 20%; Includes Standby button & IE3 energy efficiency Motors rating.Angular cross-cut fence; Automatic side pressure device integrated into the saw carriage for cross-cutting, the machine cuts left to right to the cross-cut fence.Front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed.Min. side aligning dimension 0" (0 mm), max. side aligning dimension 149" (3,800 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Options Include: (1) Non-Powered in/out-feed staging conveyor with fork cut-outs as pictured. Micro In-feed for thin an

Holzma HPL11 Rear Load Panel Saw Still under power. Ready to be removed the end of January 2024

HOLZMA HPP-11-32 OPTIMAT FRONT LOAD PANEL SAW:Specifications & features: 3,200 mm (126") Cutting length & pull-back behind the cutting line; 125 mm (4.9") saw blade projection; 30 HP (22.3 kW) main & 3 HP (2.2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 410 FPM (0 - 125 MPM), constant return of 410 FPM (125 MPM). -- Equipped with: Main blade 18" (450 mm) dia. and scoring blade 8" (200 mm dia.). -- Electronically controlled overhead pusher fence, rack & pinion drive on both sides by AC Servo motor; forward speed from 0 - 262 FPM (0 - 80 MPM), return speed of 262 FPM (80 MPM); equipped with (8) gripper clamps (open up to 4.7"). -- HOLZMA CADmatic Operating system; 15" color monitor (displays cutting dimensions); data input by keyboard or 1.44 MB floppy disk drive & downloading from office PC is possible. -- Control panel mounted on double swiveling arm for ergonomic positioning by the operator. -- Includes: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (3) air floatation tables, 85" x 26" (2,159 x 660 mm) each. -- Complete with: Angular square fence, automatic side aligner for crosscutting, (2) aligning devices on program fence; "Quick Saw Changing System" for main & scoring blade.

HOLZMA HPP 250 Front Load Automatic Panel Saw: Specifications: -- 149.6" (3,800 mm) Cutting length & pull-back; 2.8" (72 mm) saw blade projection -- 10 HP (7.5 kW) - 4,700 RPM Main saw motor, 350 mm main saw dia; -- 1.5 HP (1.1 kW) - 5,100 RPM scoring motors, 200 mm scoring saw dia.; NC controlled scoring saw adjustment from "CADMATIC" controlSaw carriage: Variable travel speed from 16 - 262 FPM (5 - 80 MPM), constant return of 262 FPM (80 MPM).Pusher Fence: -- Electronically controlled overhead program fence, rack & pinion driven on both sides; forward speed capacity from 0 - 197 FPM (0 - 60 MPM).Operator & Machine Control: -- PC Front-End with: HOLZMA "CADMATIC 3" Power

HOLZMA HPP 350 38/38 FRONT LOAD AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) cut length, 145.7" (3,700 mm) pull back, 3" (80 mm) saw blade projection. 18 HP (13.5 kW) main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw carriage:Travel speed from 16 - 492 FPM (5 - 150 MPM), constant return of 492 FPM (150 MPM). -- Pusher Fence: Overhead program fence with (7) gripper clamps, clamps open up to 90 mm (3.5"); rack & pinion drive on both sides,Forward speed from 82 to 295 FPM (24 - 90 MPM), return speed of 295 FPM (90 MPM). -- Operator Interface:HOLZMA Power Control 22 with "CADMATIC 4.0 PROFESSIONAL" + "Windows XP" operating system. Virtually unlimited cutting dimensions memory;TFT 19" flat Touch Screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44MB Floppy & CD ROM drives, capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right angle fence.(3) Front air floatation tables 85" x 31.5" (2,160 mm x 800 mm). -- Options Include:Label Printer as pictured. -- Actual model is HOLZMA HPP 350 38/38.

HOLZMA HPP 350 31/31 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications:122" (3,100 mm) cut length, 122" (3,100 mm) pull back, 3" (80 mm) saw blade projection.18 HP (13.5 kW) Main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw Carriage:travel speed from 16 - 426 FPM (5 - 130 MPM), constant return of 426 FPM (130 MPM). -- Pusher Fence:Electronically controlled overhead program fence with (6) gripper clamps, clamps open up to 90 mm (3.5").Rack & pinion drive on both sides, forward speed from 82 to 262 FPM (24 - 80 MPM), return speed of 262 FPM (80 MPM). -- Operator Interface:HOLZMA Power Control with "CADMATIC 4.0" + "Windows XP" operating system; virtually unlimited cutting dimensions memory.17" TFT Flat screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44MB Floppy & DVD R/W drives, capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aliginer with front & rear forks holding ripped strips squarely against the right angle fence.(1) Front air floatation tables 86" x 25" (2,160 mm x 650 mm), (2) front air floatation tables 69" x 25" (1.760 mm x 650 mm); Rear support rails with non-marking rollers. -- Options Include: Zebra Z4M Plus thermal label printer, (4) sets main/scoring blades, miscellaneous spare parts -- Actual model is HOLZMA HPP 350 31/31.

- SAW BLADE PROJECTION 3.2" - CUTTING LENGTH 126" - PROGRAM FENCE SPEED 295 ft/min - SAW CARRIAGE SPEED 492 ft/min - MAIN SAW MOTOR 18.5 HP - SCORING SAW MOTOR 3 HP - AVERAGE TOTAL AIR REQUIREMENT 4.3 cfm - COMPRESSED AIR REQUIREMENT 87 psi - EXTRACTION SYSTEM 1port 960 cfm - TOTAL CONNECTED LOAD 27 HP - WORKING HEIGHT 36" - AIR TABLES (3) 3/4 x 85"

HOLZMA HPP 380 32/32 FRONT LOAD AUTOMATIC PANEL SAW Specifications: -- 126" (3,200 mm) Rip cutting capacity & pull back; 3.74" (95 mm) saw blade projection.18 HP (13.5 kW) Main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment via "CADMATIC" control. -- Saw Carriage:Variable saw carriage travel speed from 16 - 426 FPM (5 - 130 MPM), constant return of 426 FPM (130 MPM). -- Pusher Fence:Electronically controlled overhead program fence, equipped with (6) clamps that open up to 100 mm (3.9").Rack & pinion driven on both sides, forward speed of 262 FPM (80 MPM), return speed of 262 FPM (80 MPM). -- Operator Interface:HOLZMA Power Control with "CADMATIC" + "Windows XP" operating system; virtually unlimited cutting dimensions memory.TFT 17" Flat Screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44MB Floppy & DVD R/W drives, capable of online operation via RS 232 or USB port for possible link to an office PC. -- Complete with:Automatic "CENTRIC" side aligner with front & rear forks, holding ripped strips squarely against the right angle fence.(3) Front air flotation tables, 67" x 25" (1.700 mm x 650 mm). Rear support rails with non-marking roller modules. -- Options Include:Label Printer as pictured & label printing software -- Actual model is HOLZMA HPP 380 32/32.

Holzma OPT.HpPS81/38 Panel Saw

Homag D-200 Drill & Dowel Inserter

HOMAG DRILLTEQ V-200 CNC MACHINING CENTER (VERTICAL/W/BORING): -- Specifications: Flexible "Vertical" Machining Center with "BORING": Uses less than 5 sq. meter of valuable floor space in addition to an innovative panel handling system. -- Working Cap.Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 33.4" (850 mm); max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.75" (70 mm); min. part thickness of 0.31" (8 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "V-200" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit(1) 3 HP (2.3 kW); Variable speed from 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis; boring block has "QUICK CHANGE" spindle system. -- Operator Interface:HOMAG "POWERTOUCH" + Windows + WoodWOP Operating System; "IntelCore 2 DUO" Processor.21" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:(1) "X" Grooving Saw; 9,000 RPM, max. saw blade dia. 100 mm.(1) 12 HP (9 kW) Electro Spindle router with manual Quick-Change adaptor; variable speed from 6,000 - 24,000 RPM. -- Actual Model is: HOMAG DRILLTEQ V-200 OPTIMAT BHX 055.

HOMAG EDGETEQ 4.5 SERVO QUICK MELT EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + EVA/PUR Gluing Technology: Specifications:RH Feed (Brandt) Configuration; 0.4 - 3 mm (0.016 - 0.125") Coil Cap.; 0.4 - 8 mm (0.016 - 0.315") edge strip cap.; 8 - 60 mm (0.32" - 2.4") panel thickness; 160 mm (6.3") min. panel length; 70 mm (2.76") min. panel width.Equipped with: Pre-Milling Station, (2) motors @ 2.25 kW (3.0 HP), 12.000 RPM, (1) clockwise & (1) counterclockwise rotation for chip-free and clean panel edges.Equipped with diamond cutter heads. -- In-feed Fence, with servo motor positioning. -- Infrared Radiant Quartz Heating Unit between glue roller and pressure section. -- Automatic Edge Magazine, for strip & coil stock, strips 0.4 mm - 8 mm (0.016 - 0.315"), coils up to 3 mm PVC and "HD" guillotine. -- QA-65N Gluing Unit for PUR & EVA Glue, with "Quick Change" pot for maintenance, glue purging/color change. -- Pressure Section, 1st. roller driven plus (2) idle rollers, timed pneumatic pressure controlled; Motorized positioning of the Pressure Zone. -- Feed Speed, variable 8 - 14 MPM. (26 - 46 FPM), 14 MPM (46 FPM) when contour trimming. -- HOMAG "Power Touch Control, Full HD wide screen multi-touch display, keyboard, mouse, Industrial PC.PLC control according to IEC 61131 standards, USB connection at the operating panel; Ethernet connection 10/100 MBIT RJ45Work Stations: Straight/Chamfer End Trimming: - (2) Motor @ 0.35 kW (1/2 HP) 12,000 RPM, automatic indexing for straight to bevel trimming from control panel. -- Multi-Stage Fine Trimming Unit MS 40: - Top/bottom (2) motors, 0.55 kW (0.75 HP) 12,000 RPM, equipped with (2) Multi-Profile Radius cutter heads, each with (4) Carbide insert knives. (4) Profile options, Profile1, Profile2, Bevel & Flush trimming, via the program control. Includes Auto tilt feature, servo controlled to edge thickness, Nesting top copy system. -- Multi-Function Contour Trimming/Corner Rounding Unit MF-50: (2) Motor 0.4 kW (1/2 HP) 12,000 RPM, dual purpose for CR & continuous Top & Bottom edge trimming with servo motor control of the cutter.2-Position automatic indexing for 1-mil, 2-mil & 3-mil thickness. For leading & trailing edges vertical corner rounding of panels; equipped with radius cutters, HSK 25 system; 3 mm max. edge thickness. -- Scraping, Multi-Stage Profile Scraping Unit MZ 40: Top/bottom with Multi-Profile for (2) Radii. 1 mm & 2 mm or 3 mm in place of 2 mm, servo control positioning of vertical & horizontal copy wheels. PVC scrape collection box. -- Finish Scraping Unit: - Flush top/bottom on panel surface with floating insert knives. -- Buffing Unit: - Top/bottom (2) motors, 0.10 kW (0.125 HP) 2,800 RPM. Complete with:Motorized, programmable Top hold-down pressure beam; padded sound enclosure, isolation transformer for multiple input voltages, used tooling and Original Factory machine documentation. -- Actual Model is HOMAG EDGETEQ 4.5 SERVO QUICK MELT.NOTE: Pictured Return Conveyor is NOT INCLUDED

HOMAG - EDGETEQ S-200, ...Edgebander (w/Premill & Corner Rounding) + "AIR TEC" EVA/PUR Gluing Technology Specifications: -- 0.3 - 3 mm (0.016 - 0.11") Edge; 8 - 60 mm (0,312 - 2.375") panel thickness; 160 mm (6.375") min. panel length, and 70 mm (2.75") min. panel width.Equipped with: -- Separating/cleaning agent spraying units. -- Premilling Station: (2) Motors @ 2.25 kW (3.0 HP), 12.000 RPM, LH & RH rotation w/pneumatic jump control for chip free and clean panel edges. --100 mm Dia. diamond cutterheads. -- Integrated heated glue roller. -- AirTec reactivation unit for zero-edge finish. -- Automatic Edge Magazine for strip & coil stock, up to 3 mm PVC. -- "Heavy-Duty" guillotine. -- EVA/PUR "Quick-Change" glue pot and roller application unit. -- Pressure Section: 1st. Roller driven plus (2) idle rollers; timed pneumatic pressure controlled. -- Feed Speed: 8 MPM. (26 FPM). Operator Interface: -- HOMAG "easyTouch" Operator Interface with: 7" Graphic color touch display & soft keypad; intuitive, user-oriented navigation.(20) Storable programs guarantee flexibility when processing a wide variety of edge materials and changing customer requirements.Clear overview of the help and assistant functions, including the glue pot temperature or troubleshooting in plain text.Workstations: -- End Trimming: (2) Motors each @ 0.35 kW (1/2 HP) 12,000 RPM; automatic chamfer from control panel 0°- 15°. -- Flush/Bevel-Fine/Radius Trimming Unit: (2) Motors: Top/bottom; 0.55 kW (3/4 HP) 12,000 RPM; 0° - 25°auto-tilt positioning from control panel with combination flush/radius/chamfer cutterheads.Includes: (3) Positioning options: Profile 1, Profile 2, and 3--flush trimming. -- Corner Rounding Unit: (1) Motor 0.35 kW (1/2 HP) 12,000 RPM with automatic adjustment from control panel for 1-mil, 2-mil & 3-mil thickness.For leading & trailing edges vertical corner rounding of panels: Ether radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Scraping, Multi-Profile (PVC): Top/Bottom with (2) profiles. 1 mm & 2 mm or 3 mm in place of 2 mm positioning of vertical & horizontal copy wheels. PVC scrape collection box. -- Buffing Unit: Top/bottom (2) motors; 0.10 kW (0.125 HP) 2,800 RPM. Complete with: -- Motorized holddown pressure beam; padded sound enclosure, isolation transformer for multiple input voltages, used tooling, and Original Factory machine documentation. -- Actual Model is: HOMAG EDGETEQ S-200 AT (aka OPTIMAT KDF 1130 AT).

Homag Espana CH-03/32/32-PLUS Panel Saw Still under power and available for inspection. 230/480 V

Homag BST 500

HOMAG - Centateq N-300 NBP084/VANTECH 512, ...5' x 12' CNC Flat Table Machining Center with ATC, Boring, Nesting, Infeed Roller & Outfeed -- Specifications:5' x 12' x 37"; H Flat table "Bridge Gantry" machine. -- Working Area:X-Axis 3,683 mm (145"); Y-Axis 1,550 mm (61.02"); Z-Axis 100 mm (3.9"). -- Travels: X-Axis 193" (4,900 mm); Y-Axis 1,965 mm (77.36"); Z-Axis 245 mm (9.65"). -- Positioning Speed:X-Axis 72 MPM (236 FPM); Y-Axis 62 MPM (203 FPM); Z-Axis 25 MPM (82 FPM).(2) Synchronized X-Axis drives, AC brushless drives on head, THK linear motion guides on all axes. -- Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(1) Pneumatic locator/positioning rail in X-Axis & (1) pneumatic locator/positioning rail in Y-Axis; (10) CNC-Controlled vacuum table work zones. -- Boring Unit:2 HP (1.5 kW) Motor; (7) independent vertical spindles with: (4) In X-Axis & (3) in Y-Axis; variable spindle speeds 1,500 - 7,500 RPM. -- Machining:(1) 13 HP (10 kW) High-speed electro-spindle router with: HSK F 63 Adapter, constant duty, variable spindle speeds 1,250 - 24,000 RPM, left-hand or right-hand rotation.(1) 14-Position carousel-type automatic tool changer on left-hand side of machine. -- Operator & Machine Control:"powerControl" Control, with MICROSOFT "Windows" + "WoodWOP 5.0" Operating System."powerTouch" 21.5“, 16:9 full-HD multitouch display, Ethernet, RS-232, USB ports, and remote pendant control. BECKHOFF Programmable logic control for (3/4) axes; linear, circular, & helical interpolation, Tapio-ready. -- Complete with:Infeed electric/hydraulic Scissor Lift platform with roller top; 4’ x 4’ transfer Roller Section with: 2-1/8"; Dia. x 3/4"; W wheels on 12"; & 9-1/2"; centers; vacuum arm with (2) 10"; dia. vacuum pads; rake off-feed System; 61"; W x 13’ L outfeed motorized Belt Conveyor; (2) 2018 BECKER "VTLF2.250/0 - 79" 10 HP 200 mbar Vacuum Pumps; light curtain; 6' H safety Fencing, Touch-off tool length Measuring Device.Control Cabinet Dimensions: 44" x 39" x 96" H.

--MAKE AN OFFER---EXCELLENT CONDITION HOMAG - Centateq N-300 NBP084/VANTECH 512, ...5' x 12' CNC Flat Table Machining Center with ATC, Boring, Nesting, Infeed Roller & Outfeed Specifications: 5' x 12' x 37” H Flat table "Bridge Gantry" machine. Working Area: X-Axis 3,683 mm (145"); Y-Axis 1,550 mm (61.02"); Z-Axis 100 mm (3.9"). Travels: X-Axis 193" (4,900 mm); Y-Axis 1,965 mm (77.36"); Z-Axis 245 mm (9.65"). Positioning Speed: X-Axis 72 MPM (236 FPM); Y-Axis 62 MPM (203 FPM); Z-Axis 25 MPM (82 FPM). (2) Synchronized X-Axis drives, AC brushless drives on head, THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. (1) Pneumatic locator/positioning rail in X-Axis & (1) pneumatic locator/positioning rail in Y-Axis; (10) CNC-Controlled vacuum table work zones. Boring Unit: 2 HP (1.5 kW) Motor; (7) independent vertical spindles with: (4) In X-Axis & (3) in Y-Axis; variable spindle speeds 1,500 - 7,500 RPM. Machining: (1) 13 HP (10 kW) High-speed electro-spindle router with: HSK F 63 Adapter, constant duty, variable spindle speeds 1,250 - 24,000 RPM, left-hand or right-hand rotation. (1) 14-Position carousel-type automatic tool changer on left-hand side of machine. Operator & Machine Control: "powerControl" Control, with MICROSOFT "Windows" + "WoodWOP 5.0" Operating System. "powerTouch" 21.5“, 16:9 full-HD multitouch display, Ethernet, RS-232, USB ports, and remote pendant control. BECKHOFF Programmable logic control for (3/4) axes; linear, circular, & helical interpolation, Tapio-ready. Complete with: Infeed electric/hydraulic Scissor Lift platform with roller top; 4’ x 4’ transfer Roller Section with: 2-1/8” Dia. x 3/4” W wheels on 12” & 9-1/2” centers; vacuum arm with (2) 10” dia. vacuum pads; rake off-feed System; 61” W x 13’ L outfeed motorized Belt Conveyor; (2) 2018 BECKER "VTLF2.250/0 - 79" 10 HP 200 mbar Vacuum Pumps; light curtain; 6' H safety Fencing, Touch-off tool length Measuring Device. Control Cabinet Dimensions: 44" x 39" x 96" H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Homag Centateq N300 CNC Router 5x10 Table Offload conveyor Schmaltz overhead gantry system

Homag Centateq N300 CNC Router 5 X 10 Infeed system Outfeed table Boring block (2) Vacuum Pumps Main Hours: 1,101 Secondary Hours: 370

Homag Optimat NBP084/ Vantech 480 4x8 Bed 12 HP Spindle 7-Position Boring (2) Vacuum Pumps Clean Machine
