Woodworking Equipment For Sale

SCMI OLIMPIC S1000 T-ERL EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) -- Specifications:Edge Capacity, 0.4 to 15 mm (0.016 to 5/8") for strip feeding. -- Panel Capacity, min. width 50 mm and 140 mm min. length, (2.0" and 5-1/2"). Panel thickness min./max. 8 - 60 mm (3/8" - 2-3/8"). Equipped With:&#9679 Adjustable In-feed Fence: Manually pre-set with digital indicator and pneumatic panel spacing device. -- Pre-Milling Station, RT-E: Spindles 2 x 5.25 HP, 12,000 RPM, (1) with PLC controlled jump action and manual digital indicators positioning and Diamond Cutter-heads. -- Anti-Adhesive Spraying System: Top/Bottom, positioned prior to the Pre-Milling Unit, it prevents glue buildup on the work-piece surfaces. It consists of (2) independent spray nozzles, and a tank for anti-adhesive liquids. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station, Vc/1000: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. -- Pressure Section: Servo motor positioning, (4) pressure rollers, first larger, Teflon coated and powered. Workstations:&#9679 End Trimming Station K-SEL: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0ø - 15ø, rapid set up between straight and angled cutting with the automatic swivel cylinder. -- Flush Trimming Unit, Rsp: Top/Bottom, 2 x 1.5 HP, 12,000 RPM with 2 pre-set pneumatic positions, flush and overhang, remote pneumatic in/out positioning. -- Bevel/Radius Trimming Unit, Ri/S: Programmable, servo motor positioning, 2 x 1.0 HP - 12.000 RPM motors for change-over on the fly. -- Corner Rounding / Trimming Unit, Round-K: For additional top & bottom trimming of linear an/or vertical leading & trailing corner when edgebanding all (4) sides, 2 x 0.8 HP - 12,000 RPM motor. Comes with (2) pre-set pneumatic positions to allow to go from thick to thin pvc automatically. -- Profile Scraping Unit "RAS/1000": Top/Bottom with (2) indexed manual pre-sets. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue Scraping Unit, "Rca/2c": Top/bottom flat glue scraper with pneumatic positioning through controller and air-blow off nozzle to keep the knifes clean. -- Buffing Unit "SPN": Top/bottom, oscillating 2 x 0.25 HP - 3,000 RPM motors, tilting up to 12°. -- Hot Air Unit: Single blower with adjustable heat range and directional heat shield for top/bottom coverage. Restores color luster on thick pvc edging materials that my be lost during the edge scraping process.Controls: -- Startouch Controller, 12" color touch screen, swivels 270° at in-feed of machine. Capable to store (100) programs, (6) at the touch of a single key. Graphical display of all working units. Tracks production data, diagnostic information and monitors maintenance schedules. Complete With & Features: -- Feed-speed, 40/60 FPM, 1 x 2.5 HP feed drive motor, 200 Hz frequency inverter for all

SCM OLIMPIC K 600 T-ERL EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications0.4 to 3 mm Roll feeding and up to 8 mm for strip feeding.Panel Capacity Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2"). Min./max. panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 508 mm (20").Feed speed: 36 & 52 FPM (2-1/2 HP feed motor).Equipped with:Adjustable infeed fence: Manually preset with: Digital indicator, pneumatic in/out positioning.Coil feeder: For banding up to 3 mm thick with a 3 mm guillotine.Gluing Station:For EVA (Hot Melt) with: Quick change/disconnect Teflon glue pot for fast glue tanks change if needed; heat-up time approx. 8-10 Min.Pressure Section:Manual digital positioning: Teflon coated pneumatic driven roller; (2) spring-loaded idle rollers; includes: "Strip Feed Magazine".Workstations End Trimming Station: "K-SEL 2" Front & rear: 1/2 HP - 12,000 RPM Motor mounted on THK guides; swivels 0° - 15°, rapid set up between straight and angled cutting with the automatic swivel cylinder. Top & Bottom Trimming Unit: (2) 1.0 HP - 12.000 RPM Motors: Capable of tilting 0° to 25° with copy wheels; pneumatic positioning for (3) settings:Flush/bevel/radius trimming via precision digital indicators to go from 3 mm PVC to thin tape through the controller for quick set up.Corner Rounding:(2) 0.80 HP Independent motors that slide on THK guides. The features of the "Round-K" (SCM patent) allow for the double function of both the simultaneous trimming and rounding operations.Top & Bottom Profile Scraping Unit: "RAS/K" Profile scrape station for 3 mm PVC: Pneumatic positioning with digital indicators; large dia. copy wheels for max. accuracy; pneumatic in/out positioning. Buffing Unit:Top/Bottom (2) 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator Interface "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs.Machine automation: PLC Function and encoder positioned in the panel feed track pinion.Diagnostics for a quick solution to errors: Process statistics data (i.e., Number of pieces/edges and track feeding).Features & Complete with: &#9679 (1) 2.0 HP Feed drive motor. &#9679 200 Hz Frequency Inverter for all trimming units. &#9679 Manual adjustable hold-down pressure beam. &#9679 Full sound enclosure cover & outboard panel support. &#9679 Adjustable side support. &#9679 Replaceable track pads. &#9679 Digital inverter for electronic motor braking. &#9679 Acoustical safety enclosure. &#9679 Dust Collection: Working units are individually ported on the top of the safety enclosure for maximum efficiency. &#9679 Suitable Transformer for 230 V to 600 V - 3 Ph. -- Actual model: SCM OLIMPIC K 600 T-ERLNOTE: Pictured Return Conveyor is "NOT INCLUDED"

SCM OLIMPIC K230-EVO SINGLE SIDED EDGEBANDERSpecifications: --0.4mm to 3mm Edge thickness, Panel thickness 8mm to 50mm (3/8" to 1-15/15"), minimum part width 110mm (4.33"), minimum part length 160mm (6.30"). -- Equipped with: -- 1.5 Kg Teflon-coated glue pot, glue roller application system complete w/automatic recycling device for unused glue, digital thermostat adjustment for temperature control. pneumatic guillotine, 3-Roll pressure unit w/pneumatic controls for all pressure rollers. -- Automatic strip & coil feed magazine --Workstations: --÷Double motor front & rear (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15°, end trimmers mounted on 45° THK guide. --Top & bottom flush & bevel trims with quick release mount and plug-in motors for quick tooling changes (0.7 HP - 12.000 RPM motor ea.), bevels 0° - 15° with precision digital indicators for quick setup. --Top & bottom scraping unit w/pneumatic positioning from the control panel. -- Top & bottom buffing unit (0.25 HP - 2,800 RPM motors). 29.5FPM Fixed feed speed, 0.75 HP feed drive.

SCMI Compact 22/S 4-Head Moulder4-Head (B-R-L-T), working cap. 8-5/8" x 4-11/16". -- Head sequence: Bottom 5.5 HP motor, right/left 7.5 HP motor and top 5.5 HP motor. -- Spindle dia. 35 mm with cutterhead speed of 6,000 RPM. Variable feed speed 14 to 72 FPM with a 2 HP motor. -- Complete with: 2M (6'6") Infeed straightening table, sound insulation hood, dust hoods, and Owner's Manual.

SCM STARTECH CN - CNC MULTI SPINDLE DRILLINGFeatures: -- Easy Motion Work Table -- 7" Touchscreen -- (7) Independent Vertical Boring SpindlesSpecifications: -- Maximum Panel Dimensions X-Y-Z (3050mm x 800mm x 50mm), Minimum Panel Dimensions X-Y-Z (300 mm X 90 mm x 10 mm) -- Drilling/Grooving working area: 0mm x 800 mm/0mm x 800 mm ÷X-Axis Stroke: 750 mm÷X-Y maximum axis speed: 25m/Min. -- Vertical Spindles: 7 (4X-4Y one of them is shared) Horizontal Spindles: (along Y-axis): 2 (1+1) -- Horizontal Spindles: (along X axis): -- 1 Fixed Integrated Blade (cutting into direction): X Blade Diameter: 100 mm Maximum Blade Thickness: 5 mm -- Motor Power: 3 HP (2.2 kW) Spindle Rotation Speed: 3350 RPM÷Blade Rotation Speed: 4300 RPM -- Electrical Supply: 230 Volt (60 Hz) Installed Motor Power: 4.5 KVAHigh-performance numeric controlled (NC) Drilling Machine engineered for full-production woodworking shops and craftsmen. The Startech CN drilling head's seven (7) independent vertical spindles, the spindle and blade in the “X"; axis, and the possibility of drilling in the “Y"; axis make it both flexible and ideal for batch furniture productions. This machine allows the operator unparalleled flexibility for tailored products without the need of operator intervention for the worktable and machine set-up according to the panel dimensions.

SCM OLIMPIC K 560 T-ER2 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edge Capacity: 0.4 to 6 mm (0.016 to 1/4") for strip feeding. -- Panel Capacity: Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. Panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Pre-milling Station: (2) 2.0 HP (1.5 kW) motors; rectifies/cleans panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: "SGP": For EVA (Hot Melt) with: Quick change/disconnect Teflon glue pot for fast glue tanks change if needed; Heat up time approx. (10) Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollers.Workstations: -- End Trimming Station: (2) Front & rear 1/2 HP - 12,000 RPM motors mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: (2) 0.7 HP - 12.000 RPM Motors; capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Corner Rounding Unit "Round 2M": corner rounding unit with (2) 0.80 HP independent motors that slide on THK guides. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: "RC-N": Eliminates any excess glue. -- Buffing Unit: "SP-V": (2) Top/bottom 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator Interface: -- "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors: Process statistics data (i.e., number of pieces/edges) and track feeding.Features & Complete with: -- 2-Speed feed speed of 40 & 60 FPM (12 & 18 MPM); (1) 2-1/2 HP feed drive motor. -- 200 Hz frequency inverter for all trimming units. -- Electronic Positioning of the top hold-down pressure beam. -- Nesting Copying Device. -- Full sound enclosure cover and outboard panel support. -- Actual Model is: SCM OLIMPIC K 560 T-ER2

SCM S1000-T/ERL EDGEBANDER WITH PRE-MILL & CORNER ROUNDINGSpecifications: 15/32" (12 mm) Max. edge cap., 2" max. (w/corner rounding only 1-3/4") banding height, 2-3/8" min. panel width and 6-5/16" min. length.Equipped with: -- Automatic strip & coil feed magazine w/Heavy Duty 3 mm PVC cap. guillotine. -- Teflon coated glue pot with glue roller application system complete w/automatic recycling device for unused glue, digital thermostat adjustment for temperature control. -- 3-Roll pressure unit w/pneumatic controls for all pressure rollers.Workstations: -- "RM-K" 2-Head Pre-milling station model (2.5 HP - 19,000 RPM motors ea.). -- Double motor front & rear end trim (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15°, end trimmers mounted on 45° THK guide. -- Top & bottom flush trims (0.8 HP - 12,000 RPM motor ea.), bevels 0° - 15°. -- Top & bottom fine/radius trimmer (0.8 HP - 12,000 RPM motors) w/pneumatic positioning from control panel. -- 2-Motor Corner Rounding units for leading & trailing corner when edgebanding all (4) sides (two 0.5 HP - 200 Cy motors ea.). -- Top & bottom PVC Scraper for up to 5 mm radius. -- Top & bottom buffing unit (0.33 HP - 2,800 RPM motors). Hot Air Heating Unit, for restoring color on scraped PVC edges. -- Feed & Speed: Single 42 FPM fixed feed speed, 1 HP drive.Complete with: -- Microprocessor for line control & glue temperature (can store up to 50 preset programs). -- Swivel control panel. -- Pneumatic positioning of super finish. -- Full cover sound enclosure. -- 200 Cy - 5 kW Frequency inverter w/automatic motor brakes for all HF motors.

SCMI MINI-MAX ME 25 EDGEBANDEDR, SINGLE SIDED SINGLE PHASE0.4 mm to 3 mm (1/8") Max. edge thickness cap. and 1.96" max. panel thickness; semi-automatic strip & coil feed magazine (feeds coil material automatically and strips one at the time); Teflon coated glue pot w/fast (8-10) Minute heat-up time, 1.2 mm cap. guillotine.Workstations: -- "ME 25" 2-Head -- Single motor end trim (0.8 HP - 12,000 RPM motor) -- Top & bottom flush trims (0.8 HP - 12,000 RPM ea. motor), straight or bevel cutters. -- Top & bottom scraping station. -- Top & bottom buffing, 3,000 RPM motors.22 FPM Fixed feed speed with 0.8 HP drive.Complete with: Sound enclosure, out rigger panel support, frequency converter, and used tooling on the stations.Features: Control Panel on machine infeed side Machine frame made of high rigidity ribbed steel to guarantee excellent support Top thick steel pressure beam with rubber coated wheels Manual adjustment of top beam with Auto positioning of operating units Numeric indicator of selected panel thickness Glue smoke-specific exhaust outlet; centralized extraction of the dust Panel support roller which can be extended the entire length of the machine

SCM S 630 PLANER WITH TERSA HEADSpecifications: -- 24" Width cap.; 12 HP main motor, 2 HP feed motor; 4-3/4" dia. with reversible knife TERSA Planer Head rotates @ 4,500 RPM; -- 1/8" - 11-3/4" Thickness opening via motorized bed with LED readout for fine adjustment. -- Max. depth of cut 5/16"; 10" min. length of work piece; variable infeed speed from 20 - 56 FPM.Equipped with: -- 20-3/4" x 39" Cast iron table, sectional chip breaker, sectional grooved infeed & solid outfeed rollers, adjustable bed rollers. -- neoprene out feed rollersComplete with: -- Magnetic starter and dust hood w/6" dia. dust outlet.Owner states: Condition- like new 24" thickness planer- third owner in a one man shop. Machine has seen very few hours of operation.

SCMI SI 16 W Sliding Table Panel SawSpecifications: -- 126" Cap. with scoring, 9 HP main and 1 HP scoring motors; tilting arbor 0° - 45°, 5-1/2" depth of cut with 15-3/4" blade dia.; 3,200 - 4,500 & 6,000 RPM arbor speed; 59" max. width to rip fence. -- Complete with: -- Telescoping crosscut fence with (2) large flip stops, mechanical work holddown attachment, 2-position sliding table lock and push button magnetic controls.

SCM TECNOMAX SC/4 WS 8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40") Dia. blade: 100 mm (3.94") at 90°, 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor, Blade dia. 315 mm (12.40"), Arbor tilt 0° - 45°, Blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table, 840 mm (33.07") LR Fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence, with 51" Cutting width cap. & Cam-locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame, with Crosscut fence with 1,800 mm (70.87") Cutting cap., (2) Flip stops & Sliding outrigger support.Actual model is SC/4 WS-N.

SCM SI 300 S NOVA 5' Short-Stroke Sliding Table SawSpecifications: -- 62.9" Rip cap., telescoping crosscut fence with panel support and back squaring fence; (2) flip-stops. Equipped with: -- 9 HP Main blade motor; 1 HP scoring blade motor; tilting arbor 0° - 45°, 2-position table lock mechanism. Features: -- 50" Rip cut cap. with movable fence, 315 mm (12") main saw blade dia. (used blade included); 1" main blade arbor, 120 mm (4.7") scoring blade dia.; 3/4" scoring blade arbor. -- Max. cutting height is 100 mm (3.9") at 90° and 70 mm (2.75") at 45°; 4,800 RPM main blade speed and 9,600 RPM scoring blade;"EZ Dial" adjustable split scoring blade assembly - simply turn the dial to adjust the width of the score. This system eliminates the need for shims and is fully adjustable in 0.1 mm increments. Complete with: -- Overhead guard w/dust extraction outlet & emergency stop button. -- Instruction Manual & Spare Parts Catalog.Palletized Dimensions: 89" x 89" x 67" H.

SCM MINIMAX - FORMULA S1, ...Sliding Table SawSpecifications: -- 120" Cap. with: Scoring; 9 HP main motor & belt driven scoring blade; -- Manual tilting of the arbor 0° - 45°; Manual raise-and-lower of the main blade; -- 50" crosscut capacity with a movable fence.Features: -- "Easy-Set" scoring adjustment; heavy cast iron trunnion; 12" main saw blade dia. with 1" Arbor, 110 mm scoring blade dia.; -- Max. cutting height 3-1/2" at 90° & 2-3/4" at 45°; 1-speed arbor; 8,000 RPM on scoring blade. -- Complete with: 4" Main dust extraction outlet, miter fence & crosscut fence assembly with (2) flip stops.

SCM SI 320 Sliding Table SawSpecifications: --10' Crosscut cap. with scoring, 7.5 HP main motor with 1" dia. arbor; 1 HP scoring motor with 3/" dia. arbor; tilting arbor from 0° - 45°; 126" table stroke w/table lock mechanism. -- Equipped with: -- 50" Rip cut cap. with movable fence, 300 mm (11.8") main saw blade dia., 100 mm (3.9") scoring blade dia., max. cutting height is 95 mm (3.7") at 90° and 67 mm (2.6") at 45°; 2-speed arbor, 4,800 & 9,600 RPM main blade and 8,000 RPM on scoring blade. -- Complete with: -- Overhead guard w/3.9" dust extraction outlet, crosscut fence assembly with (2) flip-stops, (1) set of carbide saw blades.

SCM - SI 350 N ...10-1/2' Sliding Table SawSpecifications: -- 3,200 mm (126") Stroke & telescoping crosscut fence with: (2) Flip stops; 630 mm (24.80") x 1,040 mm (40.94") Fixed table.Equipped with: -- 6.6 kW (9 HP) Main blade motor; 0.75 kW (1 HP) scoring blade motor, tilting arbor 0° - 45°. -- 4,000 RPM Main blade, 8,500 RPM scoring blade, external scoring blade adjustments. -- 2-Position table lock mechanism; manual raise, lower & tilt. -- 50" Rip cut capacity, 350 mm (13.78") main blade diameter, 30 mm (1.18") main blade arbor, 120 mm (4.72") scoring blade diameter, 20 mm (3/4") Scoring blade arbor. -- Max. cutting height: 118 mm (4.65") at 90°, 81 mm (3.19") at 45°. -- SCM "SPP 100" LED Touchpad control, emergency stop button, 4-3/4" dust extraction outlet.Dimensions: 160" x 134" x 51" H.Weight: 1,950 Lbs.

SCMI HYDRO 3200 Sliding Table SawSpecifications: -- 126" (3,200 mm) Carriage travel, 16" max. blade cap., 5-1/2" depth of cut with 16" blade. Features: -- 45° Tilting arbor, 9 HP main and 1 HP - 9,800 RPM scoring motor. Complete with: -- Foot pedal actuated hydraulic rise & fall and hydraulic tilt of blade, (3) cutting speeds of 3,600 - 4,800 & 6,000 RPM. -- 59" Rip-cut cap. w/quick set & micro-adjust rip fence. Includes: -- 2-Position table lock, overhead saw guard w/dust outlet and crosscut fence with (1) flip stop & telescopic extension.

SCM PRATIX S-15-B FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:Single 5' x 12' traveling "Bridge Gantry" and stationary aluminum dual vacuum table with a MATRIX square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining".(8) Part location pop-up pins mounted on the table perimeter. -- Working field:"X" Axis is 145.11" (3,686 mm); "Y" axis is 61.2" (1,555 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness 4" (100 mm). -- Positioning Speed:"X" & "Y" Axis 115 FPM (35 MPM); "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra large precision profile linear guideways. -- Boring Unit:3 HP (2.2 kW) - 6,000 RPM motor; (7) vertical spindles on 32 mm centers, (5) in "X" axis & (2) in "Y" axis. -- Machining:(1) 9 HP (6.7 kW) Air-cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 14-Position ATC tool rack mounted to the machine base. -- Operator & Machine Control:PC Front End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers: Incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with:Onboard mini-CAD with built-in programming for writing circles, ellipses & angles with only a few keystrokes; Onboard cycle optimization, onboard calculator, mirror-imaging, and repeat imaging. -- Complete with:(1) 300 m³/Hr Vacuum Pump; external transformer 208/230/480 Volt; safety enclosure around the spindle carriage; tool length probe sensor; manual centralized lubrication.Includes: (1) Universal Remote Pendant, 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program.The pendant is fitted with a USB port to allow quick load & setup of new programs; safety "bump-stop" bumpers; emergency stop rope & manuals. -- Actual Model is SCM - PRATIX S-15-B.

SCM Sandya 5 Wide Belt Thickness Sander (Model 5 RCS 110)43" width cap, Drum, Combination headHead configuration1ST Head : Contact roll, 5-1/2″ dia., 25 HP motor;2nd Head: Combination head, rubber covered contact roll, 5-1/2″ dia., and 2″ wide finishing platen for veneer, 18 HP motor.Specifications -- 43″ x 85″ or 103″ Abrasive belts with electronic tracking & pneumatic belt tensioning, -- Pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 10 – 60 FPM, 3 HP feed motor, Equipped with & Features: -- Automatic part thickness adjustment, -- Motorized thickness opening with LED readout, -- 0″ – 6-1/4″ via (4) precision conveyor bed jacks. -- In feed & out feed spring loaded rubber covered hold down rolls on all heads, -- Motor load meters -- In feed and out feed conveyor extensions. -- Automatic advancement carpet -- Grooved rubber precision rollers Aspiration dust fans -- Emergency device to save hands while pieces in feedingMore info -- Dimensions 77″ x 64″ x 92″ Weight 1210 kG - Specifications, Dimensions & Weight data are to the best of our knowledge.

SCM - Concept 2000, ...Double End Tenoner.Double End Tenoner with: Jump scoring, Hogging, Shaping with stacked tooling. -- 122" Opening cap., motorized opening with keypad entry & LED readout, 12" infeed chain area in front of holddowns. -- 0" - 4" Motorized thickness opening with mechanical digital readout. -- 6" Min. width, 2-post machine. Each side equipped with: -- 1st Station: Jump scoring. -- 2nd Station: Hogging unit. -- 3rd Station: Coping head with stacked tooling capacity (manually operated). -- 4.5 HP Drive for 10 - 60 FPM variable feed speed. -- Chain dogs on 15-3/4" centers, rubber top nonmarring chain pads. -- Heavy-Duty chain links with: Needle bearings, automatic oil mist chain oiler, automatic brake on feed motor with emergency stop.Complete with: -- Upper driven holddowns with: Continuous feed belts; feed beams can be disengaged for conventional part feeding in front of dogs. -- Mobile remote control for setup; dual lead screw for traversing beam; exhaust hoods on all heads.Note: Tear down and loading not included.

SCM SANDYA 7 RCS Wide Belt Sander2-Head, 42" cap. - Great solid wood finish Sander. -- 1st Head: Grooved steel contact roll, 6-1/4" dia., 30 HP motor -- 2nd Head: Combination head, rubber covered contact roll, 6-1/4" dia. (65 Shore), and 2" wide finishing platen, 25 HP motor. -- 43" x 75" or 85" Abrasive belts with electronic tracking & pneumatic belt tensioning, pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 14.5 - 30 FPM, 1.5 HP motor, automatic part thickness adjustment, -- Motorized thickness opening with LED readout,0" - 6-1/4" via (4) precision conveyor bed jacks. -- Infeed & outfeed spring loaded rubber covered holddown rolls on all heads, -- Motor load meters, infeed and outfeed conveyor extensions, WYE-DELTA soft start.
