Woodworking Equipment For Sale

EMC EXPLORER 1100 2RK ... Wide Belt Sander with (2) Sanding Heads; Roller and Combination head roller/pad.Versatile, medium duty machine, ideal for cabinet shops etc.TECHNICAL DATA: -- Useful working width 1,100 mm (43"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 1,900 mm (75") x (width) 1,120 mm (44"). -- Feed belt speeds adjustable by electronic inverter from 3 to 17 m/Min (10 - 55 FPM). Head configuration:1st Head: Steel Contact Roller -- Roller diameter 142 mm (6") -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. -- Motor power 11 kW (15 HP). -- Automatic Star-delta starter. -- Speed rotation: 18 m/Sec (59 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 142 mm (6"). -- Rubber covered roller with hardness 45 Shore. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. Flexible sanding pad. Quick Change System for removable pad with felt, rubber and graphite. Rotating cutting speed 17 m/Sec (55.8 FPS). --Driven by same main motor.Abrasive belts oscillation by means of electronic photocell sensor.Feed System: -- Working thickness min./max. mm 3 - 190 (1/8" - 7-1/2"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt, machined. Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 17 m/Min (10 - 55 FPM). Centralized Control Cabinet: -- Control panel with self-diagnostics alarm control unit. -- Analog load meters on main control cabinet. -- Table lifting-lowering thickness system, electrically controlled. -- AUTOMATIC Delta - Star starter on main motor and IP 54 protection against dust & moisture. Centralized Independent Pneumatic Control Cabinet: -- Pneumatic air filter with automatic water-drain system. -- Pneumatic adjustment for "Grit set system". --Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). IP 54 protection against dust & moisture. Safety Features: -- Anti-kickback infeed protection. -- Oversized parts infeed protection by swinging bar. -- Emergency push buttons front & rear. --Automatic brakes on main motor. -- Automatic emergency stop and alarm displayOption: TAMPICO Cleaning Brush, 150 mm (6") diameter. Please add ...$3,400USA UL or Canada CSA Safety Features

EMC MERCURY 1350 2RK ... Wide Belt Sander with (2) Sanding Heads; Roller and Combination head roller/pneumatic pad.Versatile, medium duty machine, ideal for cabinet shops etc.TECHNICAL DATA: -- Useful working width 1,350 mm (53"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 2,200 mm (86-5/8") x (width) 1,320 mm (52"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). Head configuration:1st Head: Steel Contact Roller -- Roller diameter 180 mm (7"), spirally grooved. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- Motor power 11 kW (15 HP) driving both heads, with soft starter. -- On/Off Selector control with pneumatic piston to select roller. -- Automatic Star-delta starter. -- Speed rotation: 18 m/Sec (59 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 140 mm (5-1/2"). -- Rubber covered roller with hardness 45 Shore. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. -- New pneumatic aluminium sanding pad, lamina 40 mm. With On/Off selector. -- Quick Change System for removable pad with felt, rubber and graphite. -- Rotating cutting speed 18 m/Sec (59 FPS). -- Driven by same main motor, with soft starter.Abrasive belts oscillation by means of electronic photocell sensor.Feed System: -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt, machined. Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). -- Table rollers. Extension supports with idle rollers in infeed & outfeed.Centralized Control Cabinet: -- Control panel with self-diagnostics alarm control unit. -- Analog load meter on main control cabinet. -- Table lifting-lowering thickness system, electrically controlled. -- AUTOMATIC Delta - Star starter on main motor and IP 54 protection against dust & moisture. Centralized Independent Pneumatic Control Cabinet: -- Pneumatic air filter with automatic water-drain system. -- Pneumatic adjustment for "Grit set system". -- Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). IP 54 protection against dust & moisture. Safety Features: -- Anti-kickback infeed protection. -- Oversized parts infeed protection by swinging bar. -- Emergency push buttons front & rear. --Automatic brake on main motor. -- Automatic emergency stop and alarm displayUSA UL or Canada CSA Safety Features

EMC VENUS 1300 1K ... Finishing Sander with (1) Sanding Head: Combination Head.Useful working width 1,300 mm (51"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8").Working Unit: Combination Roller & Pad. -- Roller diameter 142 mm (5-5/8"). Rubber covered hardness 85 Shore. Roller pressure adjustment control & "Grit-set system". Main Motor On Off Selector control with pneumatic piston to select roller, 22 kW (30 HP) Automatic star-delta starter Rotating cutting speed: 18 m/Sec (59 FPS). -- PNEUMATIC Controlled Flexible Sanding Pad Including On-Off Selector: Quick Change System: Removable pad with felt, rubber and graphite. Rotating cutting speed 18 m/Sec (55.8 FPS). Abrasive belts oscillation by means of electronic photocell sensor.Feed system:CONSTANT PASS LINE - fixed infeed height 900 mm (35") from floorIdle table rollers support in infeed and outfeedRubber covered presser rollers, groovedVariable feed belt speed, adjustable from 3 to 19 m/Min (9.8 - 62 FPM). Inverter ControlledLarge diameter screws on machined guides with columns and pistonsAutomatic feed belt centering deviceElectronic digital display for working thicknessGeneral Machine Features: -- Analog ammeters on main control cabinet. -- Electronic motorized grit set system, control from touch screen.Electronical Panel: -- Check Control Self Diagnostics with Alarm Control. -- Analog Ammeter on the main control cabinet. -- Infeed table thickness system electrically controlled. -- Independent Overload protection.Safety: -- Infeed front emergency swinging bar for oversized panels. -- Infeed protection pressing blade to avoid pieces to go back to operator. -- Rear and front emergency push buttons. -- Automatic brake on abrasive belts motors. -- Automatic emergency stop and alarm display in case of: &#9679 Low Air Pressure. &#9679 Doors opened ("easy maintenance and inspection"). &#9679 Electric motors overloading. &#9679 Emergency detector for over thickness material cut. &#9679 No tension on abrasive belt. &#9679 Abrasive belt lateral mistracking. &#9679 Abrasive belt broken.Idle table rollers support in infeed and outfeedCentralized Control Cabinet: &#9679 IP 54 protection against dust & moisture. &#9679 Analog ammeter on main control cabinet. &#9679 Table lifting-lowering thickness system electrically controlled. &#9679 AUTOMATIC Delta - Star starter on abrasive belts motors. Centralized independent pneumatic control cabinet: &#9679 IP 54 protection against dust & moisture. &#9679 Pneumatic air filter with automatic water-drain system. &#9679 Pneumatic adjustment for "Grit set system". &#9679 Pneumatic plant working without lubrication. &#9679 Compressed air pressure 6 bar (85 PSI). Options Available: Tampico Brush natural fiber brush for cleaning of the pieces, diameter 150 mm (6"). Motor Power 1.1 kW (1.5 HP). $3,950

EMC PIONEER 2RK Wide Belt Sander, (2) Head: 37" Width capacity. Drum, Combination Head.Head Configuration: 1st Head: -- Rubber covered contact roll 180 mm diameter.2nd Head: -- Combination Head, rubber covered roller with padSpecifications: -- Useful working width: 950 mm (37"). -- Working thickness min/max: 3 - 170 mm. -- Abrasive belts length: 1,900 mm. -- Abrasive belt width: 975 mm. -- (2) Feed speeds: 5 - 10 m/min. -- Electronic digital display for working thickness. -- Abrasive belt oscillation by electronic photocell. -- Main drive motor 15 HP -- Feed drive 2 to 19 Meter/min.

EMC MERCURY 1350 3WRK Abrasive Planer / Wide Belt Sander with (3) Heads; Planer Head, Contact Roller, and Combination Head.Useful working width 1,350 mm (53"). Working thickness min./max. 3 - 170 mm (1/8" - 6-11/16"). The machines uses abrasive belts 2,620 x 1,370 mm (103" x 54") for longer life of the sanding belts.Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 140 mm (5-1/2"). -- Shaft for helicoidal position knives with (380) Interchangeable knives with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 20 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer. group in working position. -- Working pressure adjustment. -- Motor power: 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 32 m/Sec (115 FPS). -- Soft starter for slow starting2nd Head: Steel Roller "R", Belts dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 180 mm (7"), spirally grooved. -- Electronic motorized roller pressure adjustment "Grit-set system". -- On-Off selector switch control for roller. -- Constant control to any position with accuracy 0.02 mm. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with Automatic star-delta starter. -- Abrasive Belt cutting speed: 18 m/Sec (59 FPS). -- Timing oscillating cleaning abrasive belt blower located at the bottom 3rd Head: COMBINATION Unit "K", Belt dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 140 mm (5-1/2"). -- Roller rubber hardness 45 Shore, Constant control to any position with accuracy 0.02 mm. -- On-Off selector switch control for 3rd roller including pneumatic piston -- Pneumatic Aluminum PAD , lamina 40 mm, On-Off. -- Quick changing system, extractable blade with felt, rubber and graphite. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with automatic star-delta starter. Abrasive Belt cutting speed:18 m/Sec (59 FPS).Feed system: -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 18 m/Min (9.8 - 58 FPM) Inverter Controlled. -- Automatic feed belt centering device. General Machine Features: -- Large diameter screws on machined guides with columns and pistons. -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each (head) working group. Electronic programmable color TOUCH SCREEN display, 7" wide -- PLC with micro-processor of latest generation, modular and expandable. -- Connection USB, RS232, Ethernet 10/100/1000. -- Memory capacity: 100 working programs or more. -- Graphic synoptic to facilitate programming.Software facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickn

EMC GIANT 1350 2WR Abrasive Planer with (2) Heads, Planer Head and RollerTop of the line Heavy Duty Abrasive Planer from EMC. The series of GIANT machines are available in many configurations. Abrasive Planer has a helicoidal head with insert tooling.Useful working width 1,350 mm (53"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8").Head configuration: 1st Head: Planer Head "W" -- Cutter head knifes diameter 180 mm. -- Shaft for helicoidal position knifes with (512) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer group in working position. Working pressure adjustment. Motor power 30 kW (40 HP), Star-delta starterSpeed rotation: 35 m/Sec (115 FPS).2nd Head: Roller "R" Belts dimensions: 3,250 x 1,370 mm (128" x 54"). -- Roller diameter: 320 mm (12-5/8"). -- Roller rubber hardness 45 Shore. Constant control to any position with accuracy 0.02 mm. -- On-Off pneumatic piston, controlled from the electrical panel. -- Rotation: Against feed (clockwise). -- Motor power: 22 kW (30 HP) Automatic star-delta starter. Rotating cutting speed: 21 m/Sec (99 FPS). Blower for the roller unit.Feed system: -- Constant pass line, 900 mm (35.4") from floor (In line machine). -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 20 m/Min (9.8 - 65.6 FPM). Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each working group.Electronic programmable color TOUCH SCREEN display, 7" widePLC with micro-processor of latest generation, modular and expandableConnection USB, RS232, Ethernet 10/100/1000Memory capacity: 100 working programs or moreGraphic synoptic to facilitate programmingSoftware facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickness. -- Command, programming and display for feeding. -- Command, programming and display for all inverters. -- Command, programming and display for selected groups. -- Command, programming and display for blowers, including compressed air saving function. -- Display report and reset of alarms (self diagnostic) with memory records.Options Included: -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Rotating blowers for part and feed belt cleaning. -- LED light inside the machine. -- Telemetry for remote computer assistance

EMC GIANT 1350 3WRF Abrasive Planer with (3) Heads, Planer Head, Roller and Superfinishing PadTop of the line Heavy Duty Abrasive Planer from EMC. The series of GIANT machines are available in many configurations. Abrasive Planer has a helicoidal head with insert tooling.Useful working width 1,350 mm (53"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8"). Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 180 mm (7-1/16"). -- Shaft for helicoidal position knives with (512) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer group in working position. Working pressure adjustment. -- Motor power 30 kW (40 HP), Star-delta starter.Speed rotation: 35 m/Sec (115 FPS).2nd Head: Roller "R" Belts dimensions: 3,250 x 1,370 mm (128" x 54"). -- Roller diameter: 250 mm (9-13/16"). -- Roller rubber hardness 60-65 Shore. Constant control to any position with accuracy 0.02 mm. -- On-Off pneumatic piston, controlled from the electrical panel. -- "Grit-set system". -- Rotation: Against feed (clockwise). -- Motor power: 22 kW (30 HP) Automatic star-delta starter. Rotating cutting speed: 21 m/Sec (99 FPS). Blower for the roller unit.3rd Head: SUPERFINISHING PAD "F" Electronic PAD segmented in (75) sections. -- Belts dimensions: 3,250 x 1.370 mm (127-15/16" x 54"). -- Width of a single element (section): 18 mm (11/16"). -- APC - Automatic Programmable Control and setting of the air pressure. -- Electronic motorized roller pressure adjustment "grit-set system". -- Rotation: Against feed (clockwise). -- Timed oscillating abrasive belt "air jets" cleaning. -- Motor power: 18,5 kW (25 HP) with electronic inverter variable abrasive belt speed 3 to 18 m/Sec (9.8 - 59 FPS).Feed system: -- Constant pass line, 900 mm (35.4") from floor (In line machine). -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 20 m/Min (9.8 - 65.6 FPM). Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each working group.Electronic programmable color TOUCH SCREEN display, 7" widePLC with micro-processor of latest generation, modular and expandableConnection USB, RS232, Ethernet 10/100/1000Memory capacity: 100 working programs or moreGraphic synoptic to facilitate programmingSoftware facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, program

EMC FLEXY 1350 3WRK Abrasive Planer / Wide Belt Sander with (3) Heads; Knife Head, Roller, Combination Head Roller/Pad.Useful working width 1,350 mm (53"). Working thickness min./max. 3 - 190 mm (1/8" - 7-1/2").Head configuration: 1st Head: Knife Planer Head "W" -- Cutter head knives diameter 140 mm (5-1/2"). -- Shaft for helicoidal position knives with (380) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 70 independent elements. -- On-Off pneumatic cylinder for planer. group in working position. -- Working pressure adjustment. -- Motor power 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 35 m/Sec (115 FPS).2nd Head: Steel Roller "R", Belts dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 250 mm (10"), spirally grooved. -- Electronic motorized roller pressure adjustment "Grit-set system". -- Constant control to any position with accuracy 0.02 mm. -- Rotation: Against feed (clockwise). -- Motor power 15 kW (20 HP). -- Automatic star-delta starter. -- Abrasive Belt cutting speed: 18 m/Sec (59 FPS). -- Air Jet Blower for abrasive belt cleaning.3rd Head: Combination Head "K", Belt dimensions: 2,620 x 1,370 mm (103" x 54"). -- 3° roller diameter mm 150, Roller rubber covered, hardness 45 shores, Roller pressure adjustment control and "grit-set system" -- ON-OFF selector switch control for 3° roller, including pneumatic piston -- PNEUMATIC aluminum pad, lamina 40 mm, ON-OFF -- Quick changing system; extractable blade with felt, rubber and graphite -- Abrasive belt motor power 15kW (20hp) • Soft starter for slow starting 15kW• Rotating cutting speed 18 m/sec. -- Air Jet Blower for abrasive belt cleaning.Feed system:Constant pass line, 900 mm (35.4") from floor -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 18 m/Min (9.8 - 59 FPM) Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each (head) working group. Electronic programmable color Touch Screen display, 10" wide -- PLC with micro-processor of latest generation, modular and expandable. -- Connection USB, RS232, Ethernet 10/100/1000. -- Memory capacity: 100 working programs or more. -- Graphic synoptic to facilitate programming.Software facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickness. -- Command, programming and display for feeding. -- Command, programming and display for all inverters. -- Command, programming and display for selected groups

EMC EXPLORER 1100 SUPER WK Abrasive Planer / Wide Belt Sander with (2) Sanding Heads; Planer Head, Combination head roller/pad.TECHNICAL DATA: -- Useful working width 1,100 mm (43"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 2,200 mm (86.6") x (width) 1,120 mm (44"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 63 FPM). Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 142 mm (5-9/16"). -- Shaft for helicoidal position knives with (316) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 20 independent segments. -- Anti kickback protection made of 60 independent elements. -- On-Off pneumatic cylinder for planer group in working position. -- Working pressure adjustment. -- Motor power 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 30 m/Sec (97.5 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 142 mm (5-9/16"). Rubber covered hardness 45 Shore. Automatic abrasive belt grit compensation with "Grit-Set System". On Off Selector control for 2° roller incl. pneumatic piston -- Pneumatic elastic pad high resistance with quick changing system; extractable felt, rubber & graphite. . Complete with On-Off Selector and Quick Change System for removable pad with felt, rubber and graphite. Rotating cutting speed 18 m/Sec (59.1 FPS). -- Motor power 15 kW (20 HP). Belt blowers, oscillating, for cleaning of abrasive belt. Abrasive belts oscillation by means of electronic photocell sensor. -- Cleaning Brush: -- Tampico brushing unit for panel cleaning, at outfeed, 150 mm diameterFeed system: -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt machined. -- Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). -- Idle table rollers support in infeed and outfeed.Centralized Control Cabinet: Analog ammeters on main control cabinet. Table lifting-lowering thickness system electrically controlled. AUTOMATIC Delta - Star starter on main motors and IP 54 protection against dust & moisture. Centralized independent pneumatic control cabinet: Pneumatic air filter with automatic water-drain system. Pneumatic adjustment for "Grit set system". Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). Features: -- Control panel with self-diagnostics alarm control unit. -- Telemetry computer remote diagnostics control. Direct connection with EMC via internet for assistance.USA UL or Canada CSA Safety Features

EMG SEMI-AUTOMATIC Twin Stair Trencher; 2" x 12" Max. stringer size, semi-automatic operation.Specifications: -- (2) 3 HP Belted motors to "top & bottom" 18,000 RPM spindles, 1-1/2" depth of plunge cut, T & B heads are arranged to advance in-and-out to facilitate open plain stairs. -- Pneumatic advance and twin table clamps each rated at over 2,000 Lbs.Features: -- Any rise and run, whether straight or tapered, can be achieved in just a few minutes of setup. Includes: -- Overload protection with on-control resets, individually timed motor startup with adjustable 2nd delay.NOTE: Available for fully automatic operation, please ask for a Quote.

Used for the accurate radius measuring of cutterheads; allows for speedy tool changes on moulder. 12" Long x 6-1/2" base, 1-1/2" dia. arbor will handle up to 9-1/4" long tool body. -- Digital caliper rides up and down on precision machined octagonal bar. -- Options: T-bushings for 1-13/16" dia. & 40mm dia., please specify.

EXTREMA PERFORMA XS-2P52 Wide Belt Sander (2) Heads;52" Width cap. Drum, Roller and Platen - 75"; Belt Lengths Head Configuration: -- 1st Head: Contact drum 30 HP motor; -- 2nd Head: Roller and Platen 30 HP motor.Features: -- Over thickness safety device -- Infeed bed rollers -- Digital thickness controller -- Individual amp meters -- Disc brakes on sanding heads -- Telemecanique electrics. -- Camozzi pneumatics -- Variable speed drive system.Specification: -- Feed motor 3 HP -- Elevation motor 0.5 HP -- Max. thickness 6" - Min. thickness 1/8" -- Contact drum 1st head 8" dia. -- Roller drum on 2nd head 5" dia. -- Dust Collection requirements 4800 CFM -- Feed speeds 15 - 50 FPM. -- Weight 6500 Lbs -- AMPS (220 V / 460 V ) 148/74.

EXTREMA 126TV Single Sided Planer;26" Max. width capacity, 11.75" thickness, Solid cast iron construction. -- Precision ground cast iron table with motorized programmable height adjustment; 1/2 HP elevation motor. -- 20 HP Main drive motor -- Scale & pointer readout for accurate thickness adjustments. -- "VECTOR" cutterhead with (6) rows of 4-sided inserts. -- 1 HP Feed drive, variable feed speed setting from 20 to 75 FPM. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers; (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor with magnetic starter & thermal overload switch and Emergency stop. -- Includes Operations manual, parts list & tool kit.

EXTREMA XP-124TV Single Head PlanerSpecifications: -- Solid cast iron construction. -- 15 HP Main drive motor, 1 HP feed motor 20 to 70 FPM, 1/2 HP elevation motor. -- Precision ground cast iron table w/motorized programmable adjustment. -- Scale & pointer readout for accurate thickness adjustments. -- "VECTOR" insert cutterhead with (4) sided inserts. -- Fixed feed speed setting for consistent stock removal. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers.Features: -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor. -- Magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit. -- Options: Single-phase power, please add ...$ 100, 460 volt add...$ 150.

EXTREMA XP-610 SINGLE SIDED PLANER24" Width capacity, 8-3/4" thickness, solid cast iron construction. -- 10 HP main drive motor -- Precision ground cast iron table w/motorized height adjustment, with digital thickness display; 1/2 HP elevation motor. -- Scale & pointer readout for accurate thickness adjustments. -- "VECTOR" cutterhead with (6) rows of 4-sided inserts. -- Variable feed speed from 20 to 42 FPM; 1 HP feed drive. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor with magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit.

6" Wide x 108" long belt (non-oscillating), 6" x 40" graphite covered platen, 1.5 HP motor w/magnetic switch, 6" dia. drive pulley, 7-3/4" x 37" front table & end table for radius work both w/approx. 6" vertical adjustment. -- Features: Industrial laminated tables, fabricated steel base, swing-away type safety dust hood, rigid tracking.

EXTREMA ET-100 Fixed Spindle Shaper; "Extremely" well-built and with solid features. -- Single phase with 3 HP or 3-phase with 5 HP motor. -- Interchangeable spindles of 1-1/4" and 3/4". -- (2) Spindle speeds of 7,500 & 10,000 RPM. -- Heavy cast iron table with a 6" max. table ring. -- Spindle lock, micro-adjustable back fence and reversing switch. -- Miter gauge, 1/2" router collet adapter and cutterhead guard.

EXTREMA ET-120 Spindle Shaper;"Extremely" Well-built and with solid features. -- 5 HP Single-phase motor. -- Interchangeable spindles of 1-1/4" & 3/4" and (1) router collet adapter. -- Dual drive belts and (2) spindle speeds of 7,500 & 10,000 RPM. -- Heavy cast iron table with a 6" max. table ring. -- Spindle lock, micro-adjustable back fence and reversing switch. -- Complete with: Miter gauge, 1/2" router collet adapter and cutterhead guard.

EXTREMA ET-120.3 Shaper w/Fixed Spindle; "Extremely" Well-built and with solid features. -- 5 HP motor. -- Interchangeable spindles of 1-1/4" & 3/4" and (1) router collet adapter. -- Dual belts and (2) spindle speeds of 7,500 & 10,000 RPM. -- Heavy cast iron table with a 6" max. table ring. -- Spindle lock, micro-adjustable back fence and reversing switch. -- Miter gauge, 1/2" router collet adapter and cutterhead guard.

"Extremely" Well-built and with solid features. -- Solid spindle of 1-1/4" with 5-13/16" under nut. -- Dual belts and (3) spindle speeds of 5,500 - 7,500 & 10,000 RPM. -- Heavy cast iron table with a 12-3/8" max. table ring. -- Spindle lock, micro-adjustable back fence and reversing switch. -- Large 7.5 HP motor. -- Miter gauge, cutterhead guard assembly, operators manual, and tool kit.
