As Taken From Service: Includes return conveyor

HOMAG AMBITION 2274 (KAL 370/6/A3) EDGEBANDER (W/PRE-MILL): -- Specifications: Working Capacity: Coiled stock min/max Edge thickness 0.3 - 3 mm (0.011. - 0.118"), Strip material min/max Edge Thickness 0.4 - 1 mm (0.016 - 0.039"),Panel stock min/max thickness 8 - 60 mm (0.472" - 1.574"). Panel Over-Hang 30 mm (1.18").Minimum workpiece width: 2.36" (60 mm) with workpiece thickness ≤ 22 mm) & 4.13" (105 mm) with workpiece thickness > 22 mm). -- Cleaning Agent Spraying Units:Top/Bottom spraying device prior to workpiece pre-milling. Designed for applying a separating agent, for easier cleaning of any residual glue on the panel. -- In-Feed Fence: Pre-heated manually adjustable in-feed fence with digital indicators. -- Pre-Milling Station:(2) 2.2 HP (3.0 kW) - 150 Hz, 9,000 RPM vertical jointing spindle motors; equipped with panel blow-off device and SIKO digital counters for adjustments. -- Panel Pre-Heat Unit: Quartz lamp for heating substrate edge before glue application. -- Edge Magazine:A multi-purpose 2-coil magazine expands capability by running coiled material & strips. Maximum roll diameter: 400 mm & 830 mm.Magazine height adjustment allows for greater usage of varying panel heights by raising and lowering the magazine table, allowing the operator to center the panelon the edgebanding. -- Gluing System Homag Quickmelt: QA 3 - Quick Melt Overhead Unit & heated roller applicator digitally displayed thermostat for both upper and lower unit.34 mm Dia. Glue Roller allows for excellent control of temperature for optimum bonding results with individual adjustment for leading and trailing glue gatesLower melting unit equipped with automatic glue level control. Melting capacity: 12 kG/Hr (26 Lbs/Hr). Ultra-fast five-minute (5) heat-up time. -- Pressure Section: Programmable (Servo), automatic pressure zone adjustment, (1) large 150 mm dia. driven & (4) 70 mm dia. idle rollers, pneumatic pressure control depending on edgebanding material used.Workstations: -- End Trimming Unit:(2) 1 HP (0.8 kW) - 200 Hz, 12,000 RPM Motor ea. to cut excess edge on the front & back of the panel; pneumatic adjusting from chamfer to straight snip. Programmable (Servo). -- Rough/Pre-Trimming Unit:(2) 0.55 kW 0.74 HP (0.55 kW) - 12,000 RPM Motors, tilting range +/- 1° & counter-rotating to machine feed to prevent blowout & .Height adjustment synchronized with the top pressure-beam .With digital counters. -- Scraping Unit:Top & bottom for thick PVC/ABS, electro-pneumatic positioning & pneumatically activated. Pneumatically-controlled blow off nozzles. Height adjustment synchronized with top pressure beam. -- Flat Glue Scraper Unit:Top & bottom to remove potential glue squeeze-out, electro-pneumatic positioning in and out of the processing area & electro-pneumatically activated height adjustment synchronized with top pressure beam. -- Buffing Unit:Top & bottom edge buffing/polishing. Operator & Machine Control: -- Power Touch Control Multi-Touch Screen C

HOMAG ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:All manuals, documentation provided with machine. -- Actual Model is HOMAG ABD 050.

HOMAG - AMBITION 2480: Edgebander (w/Premill & Corner Rounding) -- SpecificationsWorking Capacity. Coiled stock: Min./max. edge thickness 0.3 - 3 mm (0.011. - 0.118").Strip material min./max. Edge Thickness: 0.3 - 20 mm (0.011 - 0.78").Solid Wood Material min./max. Edge Thickness: 0.6 - 20 mm (0.024 - 0.78").Panel stock min/max thickness: 8 - 60 mm (0.472" - 1.574"); panel overhang: 30 mm (1.18").Min. workpiece width 2.36" (60 mm) with workpiece thickness ≤ 22 mm; 4.13" (105 mm) with workpiece thickness > 22 mm). -- Cleaning Agent Spraying Units Top/Bottom spraying device prior to workpiece premilling. Designed for applying a separating agent for: Easier cleaning of any residual glue on the panel. -- Infeed FencePreheated, manually adjustable infeed fence with: Digital indicators. -- Premilling Station(2) 2.2 HP (3.0 kW) - 150 Hz - 9,000 RPM: Vertical jointing spindle motors; equipped with: Panel blow off device & SIKO digital counters for adjustments. -- Preheat UnitQuartz lamp for: Heating substrate edge before glue application. -- Edge MagazineMultipurpose 2-coil magazine expands capability by: Running coiled material & strips. Max. roll diameter: 400 mm & 830 mm.Magazine height adjustment. Allows greater usage of varying panel heights by raising & lowering the magazine table; allows the Operator to center the panelon the edgebanding. -- Gluing System: HOMAG Quickmelt Premelting Unit. QA 3: Quick Melt Overhead Unit & Heated roller applicator; digitally displayed thermostat for both upper & lower unit. 34 mm Dia. Glue Roller. Allows excellent control of temperature for: Optimum bonding results with individual adjustment for leading & trailing glue gates.Lower melting unit equipped with: Automatic glue level control. Melting capacity: 12 kG/Hr (26 Lbs/Hr). Ultra-fast 5-minute heat up time. -- Pressure SectionProgrammable (Servo). Automatic pressure zone adjustment: (1) Large 150 mm dia. driven; (4) 70 mm dia. idle rollers; pneumatic pressure control depending on edgebanding material used.Workstations -- End Trimming Unit: PK 25(2) 1 HP (0.8 kW) - 200 Hz - 12,000 RPM Motor ea.: Cuts excess edge on the front & back of the panel; pneumatic adjusting from chamfer to straight snip. - Programmable (Servo). -- Rough/Pre-Trimming Unit - BF 10(2) 0.55 kW (0.74 HP) - 12,000 RPM Motors; tilting range: +/- 1° & Counterrotating to machine feed to prevent blowout.Height adjustment synchronized with: The top pressure-beam. -- 4-Motor Corner Rounding Unit: FF 32(4) 0.54 HP (0.4 kW) - 12,000 RPM; Motors to fine trim the edge overhangs at the workpiece front & rear vertical edge.Max. feed speed: 20 MPM (66 FPM) when using "Corner Rounding Unit". -- Open Space -- Profile/Bevel Scraping Unit PN 10Top & Bottom for thick PVC/ABS; electro-pneumatic positioning & pneumatically activated. Pneumatically controlled blow off nozzles. Height adjustment synchronized with: Top pressure beam. -- Flat Glue Scraper Uni

HOMAG BAZ 211 VENTURE 21M Machining Center with ATC & "C" Axis -- Maximum Working field: X-Axis 3,225 mm (126.9"), Y-axis 1,500 mm (59"), Z-axis stroke 300 mm (11.8"), max work piece thickness 60 mm (2.4"). -- X-axis travel speed 80 MPM (262 FPM), -- Y-axis travel speed 60 MPM (197 FPM), -- Z-axis 40 MPM (131 FPM), AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Working area: Working tables consist of (6) adjustable support rails, (2) vacuum cups per rail; laser unit to aid in the quick positioning of the vacuum cups. -- Machining unit: (1) 14.75 HP (11 kW) liquid cooled electro-spindle router (1,500 - 18,000 RPM), "HSK F63" quick change tooling; 12-position ATC automatic tool changer, "C" axis for 360ø horizontal processing. -- Drilling Unit: Vertical drilling head with (17) individual vertical spindles, 11-spindles in "X", 7-spindles in "Y", spindles on 32 mm centers. (1) saw blade aggregate, 125 mm dia; (1) 4-spindle lock case horizontal trimming unit aggregate. -- "POWER CONTROL PC 85" Numerical control with: "WOODWOP + BAZ" interface software, "WINDOWS NT"; icon driven with a graphical interface to allow the operator to quickly and efficiently create programs. -- Includes: 144 MB Disk drive, CD ROM drive, 12" color LCD monitor. -- Features: RS-422 Serial & USB connection to PC (up to 300 meters), (2) line adaptors RS-232 & 485.2 with 9-25 pin and card for RS-232 line (cable not included). -- Features: Multitask operating system, input/output modules, axes override, 4-axis interpolation, "WOOD SCOUT" diagnostic graphics aid for programming, machine data & tool management. -- Editor Module for PC with same look and functionality of software on the machine, allows transmission of programs and work lists; Required office PC configuration (not included): Pentium processor, 8 MB RAM, 8 MB hard disk; VGA video card. Complete with: -- ELMO 100 cm/h vacuum pump; perimeter protection cage; user & maintance manuals on CD with wiring diagrams and operation of Numerical Control. -- "C" Axis -- Actual Model is BAZ 211 VENTURE 21M.Riggers are required for tear down and loading

Homag BOF 311/37/15/R CNC Router Specs (to be confirmed): Homag "Vantage 12L" CNC Router Aluminum router table 60" x 144" working area Gridded Pneumatic reference stops Vacuum gauges Foot pedal control Drill unit Nine (9) vertical spindles One (1) horizontal spindle (two outlet) in X axis One (1) horizontal spindle (two outlet) in Y axis Router 16 HP HSK (quick-change) CW/CCW rotation Variable RPM Ten (10) position rotary tool changer Sound enclosure Front safety mats Safety fencing with interlocked access door Controller Flat screen monitor Standard keyboard and mouse Remote control pendant Also included: Laser projecting unit Ceiling mount

--MAKE AN OFFER---EXCELLENT CONDITION HOMAG - Centateq N-300 NBP084/VANTECH 512, ...5' x 12' CNC Flat Table Machining Center with ATC, Boring, Nesting, Infeed Roller & Outfeed Specifications: 5' x 12' x 37” H Flat table "Bridge Gantry" machine. Working Area: X-Axis 3,683 mm (145"); Y-Axis 1,550 mm (61.02"); Z-Axis 100 mm (3.9"). Travels: X-Axis 193" (4,900 mm); Y-Axis 1,965 mm (77.36"); Z-Axis 245 mm (9.65"). Positioning Speed: X-Axis 72 MPM (236 FPM); Y-Axis 62 MPM (203 FPM); Z-Axis 25 MPM (82 FPM). (2) Synchronized X-Axis drives, AC brushless drives on head, THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. (1) Pneumatic locator/positioning rail in X-Axis & (1) pneumatic locator/positioning rail in Y-Axis; (10) CNC-Controlled vacuum table work zones. Boring Unit: 2 HP (1.5 kW) Motor; (7) independent vertical spindles with: (4) In X-Axis & (3) in Y-Axis; variable spindle speeds 1,500 - 7,500 RPM. Machining: (1) 13 HP (10 kW) High-speed electro-spindle router with: HSK F 63 Adapter, constant duty, variable spindle speeds 1,250 - 24,000 RPM, left-hand or right-hand rotation. (1) 14-Position carousel-type automatic tool changer on left-hand side of machine. Operator & Machine Control: "powerControl" Control, with MICROSOFT "Windows" + "WoodWOP 5.0" Operating System. "powerTouch" 21.5“, 16:9 full-HD multitouch display, Ethernet, RS-232, USB ports, and remote pendant control. BECKHOFF Programmable logic control for (3/4) axes; linear, circular, & helical interpolation, Tapio-ready. Complete with: Infeed electric/hydraulic Scissor Lift platform with roller top; 4’ x 4’ transfer Roller Section with: 2-1/8” Dia. x 3/4” W wheels on 12” & 9-1/2” centers; vacuum arm with (2) 10” dia. vacuum pads; rake off-feed System; 61” W x 13’ L outfeed motorized Belt Conveyor; (2) 2018 BECKER "VTLF2.250/0 - 79" 10 HP 200 mbar Vacuum Pumps; light curtain; 6' H safety Fencing, Touch-off tool length Measuring Device. Control Cabinet Dimensions: 44" x 39" x 96" H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

HOMAG CENTATEQ T-700/PROFI (BOF 712/32/18/A) TWIN POD SHUTTLE TABLE MACHINE (W/ATC/BORING): -- Specifications Twin Pod Shuttle Table, Bridge Gantry machine with: NC Controlled, User-Friendly support rails & vacuum pods. -- Working Area:"X" Axis is 126" (3,200 mm, "Y" axis 72" (1,828 mm), "Z" axis stroke Routing is 12.8" (325 mm), "Z" axis stroke Boring is 7.3" (185 mm) max. material thickness of 4" (100 mm). -- Positioning Speed"X" & "Y" Axes 426 FPM (130 MPM); "Z" axis is 66 FPM (20 MPM); machine head travels on THK linear motion guides on all axes. -- Worktable x 2Twin Pod Table "Bridge Gantry" machine with: NC Controlled, User-Friendly support rails & vacuum pods, with electronic surveillance of all vacuum rails/pods/stops.(2) Independent 10.5' x 6' working areas, for Pendulum processing during loading & offloading of the materials being processed. -- Boring Unit x 2(1) 3 HP (2.3 kW) Motor; variable speed from 1,500 - 7,500 RPM; (21) independent "Quick Change" vertical spindles; (13) in "X" axis & (8) in "Y" axis.10-Horizontal Spindles; (3+3 in X axis & ( 2+2) in Y axis. (1) 100 mm X-Axis Saw slot. -- Machining x 2(1) 20 HP (15 kW) Air-Cooled, high-speed constant duty Router with HSK F63 adaptor & tool length "touch off" probe.Programmable speed from 1,250 - 24,000 RPM; constant torque achieved at 9,000 RPM, RH or LH rotation.Router is powered by a 14 kW frequency inverter; integrated air jet blow off located in the extraction hood.(1) 10-Position ATC plate mounted at the back of each head. -- Operator Interface:PC87 Front-End with: "Power Control with PowerTouch2" + Windows© 10 + woodWOP Operating System.21" TFT Color graphic touchscreen for data entry; PC 85T hand control pendant; INTEL Core 2 Duo Processor; 1 SATA 160 GB hard disk CD R/W drives.Ethernet Connection 10/100 MBIT RJ45 (without switch) for LAN connection to office PC; USB ports & central USB connection at the operating panel.BECKHOFF Programmable logic control for (3/4) axes; linear, circular & helical interpolation.The machine control is contained on a separate freestanding console that can be placed at either the LH or RH side of the machine. woodWOP can be programmed offline with the same intuitive icon-driven software that the Operator has on the machine controller. -- Shuttle Tables x 2Manual LH & RH facing/loading & automatic shuttle into & out of the working field. Integrated dust/scrap/chip conveyor to clean/remove material form the work/processing area. -- Complete with (2) 100 m³/Hr Vacuum Pump: All zone perimeter Safety System. -- Actual Model is: HOMAG - CENTATEQ T-700/PROFI (BOF 712/32/18/A).

Homag BST 500

HOMAG - OPTIMAT BOF 211/30/R: Flat Table Machine (W/ATC/Boring/"C"Axis) -- Specifications4' x 10' Flat Matrix grid Phenolic working table. -- Working Field"X" Axis 120" (3.050 mm); "Y" axis 51" (1,300 mm); "Z" axis stroke 21" (535 mm); max material thickness 8.2" (210 mm). -- Positioning Speed"X" & "Y" Axis is 260 FPM (80 MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Unit4.2 HP (3 kW) Variable speed from 1,500 - 7,500 RPM; (12) independent vertical spindles: (6) in "X" axis & (6) in "Y" axis. -- Machining(1) 19.4 HP (14.5 kW) Liquid-Cooled electrospindle router with: HSK 63F Adaptor; variable speed from 1,000 - 24,000 RPM. -- (1) NC Controlled C-axis for 360° horizontal processing. -- (1) 12-Positon automatic tool changer mounted at the back of the head for "on the fly" ATC. -- Operator Interface PC Front-End with: "HOMATIC" PC 85 Power Control + Windows "NT" + WoodWOP Operating System. -- 14" Color graphic monitor; industrial keyboard for data entry; 1.44 MB & CD RW disk drives; EtherNET interface for possible LAN connection to office PC. -- USB & RS-232 Serial interface for simple PC connection. -- NUM (PLC) With 3D Linear interpolation; 4-axis control for "X", "Y", "Z", & "C" axes. -- All mounted in separate free-standing control cabinet. -- Complete with:(1) 40 HP DEKKER "VMX055" Vacuum Pump; safety fencing; safety mats (will stop machine if operator enters work area); handheld pendent control. -- Actual Model: HOMAG OPTIMAT BOF 211/30/R

HOMAG ABD-060/12/NA - CNC Bore, Glue & Dowel Inserter: -- Specifications(1) Horizontal drilling head with: (3) Independent spindles on 32 mm centers; Servo control of: "X", "Y" & "Z" Axes; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working CapacityMaterial size: 20 mm - 1,250 mm (3/4" - 49") long; 50 mm - 800 mm (1.97" - 31-1/2") wide; 10 mm - 60 mm (0.4" - 2.4") thick.Machine is currently set up for: 8 mm Dia.; 30 or 35 mm long dowels (additional dowel sizes are optional). -- Work Area(2) Separate working fields with: (4) Pneumatic top clamps can process up to (4) parts independently on the left hand, right hand or center stops.Work can be loaded in: (1) Field while being machined in the other to allow fast production of varying parts. -- Operator InterfacePC Front-End with HOMAG - Power Control PC 85T; WoodWOP 5.0 Operating System with: Graphic programming & error messaging.17" TFT Flat screen monitor; CD-RW drive; 1.44 MB floppy drive; standard keyboard & mouse; software allows program design with automatic mirror image by use of an active center stop: Located 600 mm (23.6") from zero. -- Complete with: All manuals, documentation & program disk provided with machine. -- Actual Model: HOMAG ABD-060/12/NA

HOMAG VANTAGE 12L (BOF 311) 5'x12' CNC Router w/C-axis -- Specifications:• Table sizes: Vantage 12L,145.6" x 61" (3.700 x 1.550 mm)• Aluminum grid table• Main Router Power: 20 HP (14.9 kW)• Spindle Speed: Variable up to 24,000 RPM• Spindle Taper: HSK-F63 quick-change system.• Axes Capability: 3-axis• C-axis capabilities for aggregate clamping (4-axis functionality).• Aggregate Interface: Compatible with specialized HOMAG units, including the Flex5 5-axis aggregate• 10-position rotary/disc for ATC, mounted to the gantry• Drilling unit with 17 vertical and 4 horizontal drills• Drilling speed max: 7,500 RPM.• Homatic Power Control PC85• integrated with HOMAG's woodWOP software for programming• woodWOP with additional software for Nesting and engravings• Vacuum pump(s) with production capacity 500 m³/Hr• Safety cage/devices to minimize access to machine and vacuum pump.

HOUFEK - Maxx 1100: 2-Head Wide belt Sander43 Width cap.; Drum; Combination head.Head Configuration1st Head: Contact roll.2nd Head: Combination contact roll and finishing platen.Specifications -- 1st Head: 6" Dia. rubber-covered contact roll; 25 HP motor. -- 2nd Head: Combination head with: Rubber-covered contact roll; 6" dia.; air cushioned finishing platen; timers control platen inflation& deflation; 20 HP motor. -- 43" x 75" Abrasive belts. -- TRU-TRAK Solid-state belt tracking. -- Variable feed speed with inverter control; 15 - 45 FPM. -- 1 HP Motor; endless belt conveyor with: Automatic tracking. Equipped with & Features -- Motorized part thickness opening with: LED 0" - 6" Opening. -- Infeed & Outfeed rubber-covered holddown rolls. -- Infeed over thickness bar. -- Emergency stops at infeed & outfeed. -- Air-operated disc brakes on sanding heads. -- Electrical interlocks on: Main access doors; motor load meters.NOTE from Seller: This machine was damaged during transport by the straps going over the machine. Doors work fine; they have dents on the top where the straps dented them. - Price REDUCED to reflect this (cosmetic) damage.

Houfek Buldog 7-3M-1100-RRC 3 Head wide belt sander43" width cap, Roller / Roller / Combination-headHead Configuration1st Head – Rubber – 90 shore @ 200mm (7.9";) dia.2nd Head – Rubber - 90° shore @ 2000mm (7.9";) dia.3rd Head– Rubber - 45° shore @ 200mm (7.9";) dia. with adjustable platen.Specifications -- Sanding width 1100 mm 43" -- Work piece height 3-160 mm 0.118"~6.3" -- Sand belt size 1120 x 2620 mm 44" x 103" -- Conveyor feed speed 3~15 m/min 9.8~49 FPM -- Table motor 0.18 kW 1/4 HP Equipped with & Features -- Main motor 1st head 18 kW 24HP -- Motor 2nd head 15 kW 20HP -- Motor 3rd head 15 kW 20HP -- Voltage 460/3/60 -- Exhaust outlet (4) 180mm; (1) 100mm (4) 7"; (1) 4" -- CFM requirements 6700 m3/hr 3950 CFM -- Weight 3100 kg (approx) 6820 lbs -- Floor space 3885x1715x2260mm153"x68"x89"

Hundegger K2i machining center: Fully automatic wood input with input roller conveyor and input and sliding cross conveyor Working width / Also Working thickness 20 - 450mm. Max. Element length 13,56m Under-table tilting cross-cut saw Universal milling unit – 4-axis (UF4) Combi support for vertically working tools Drilling device (2.2 kW) – drilling direction vertical Combi support for horizontally working tools Drilling device (2.2 kW) – drilling direction horizontal Marking tool (rear or on the user side) Fully automatic element rotation – hydraulic Transport and positioning system “two-hand system” Electronic connection Roller conveyor for removing wooden elements with punch 5-arm storage table Safety device Higher quality upper surface of the machine Extension of the K2i frame to 13.56 m 5-axis universal milling unit - UF5 (upgrade to 4-axis) Remote maintenance (including portable video camera) Dovetail milling machine (with rotating knives) 60x28x16.5 Under-table rotary saw with saw blade from 750 mm to 800 mm, 360 degree rotation, servohydraulic tilting 0 – 65 degrees Universal 5-axis unit equipped with cylindrical milling cutter, end mill and end mill, milling head diameter 350 mm x 100 mm end mill Combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min 460 mm, machining depth min 300 mm Combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min. 460 mm, machining depth min. 300 mm Positioning and gripping of the material using arms, which, while the material is measured, transported to the desired location, the arms keep the processed element as close as possible to the tool that processes it for stability. The processed material can be automatically rotated Tolerance +/- 2 mm over a length of 13 m

Hunton Limited Punch Grinder

HYDREX HPX410-5 Hot Press 160 Tons using (8) hydraulic cylinders, Five daylight openings. Suitable for laminating veneer panels/doors, decorative paper, fireproof board, etc.Features (Overall): -- Board size up to nominal 4' x 10' (about 51" x 126"). -- Front Controls for easy setup & operating configuration, incl. temperatures and cycle time , emergency pedal, quad temperature protection device. -- (8) Cylinders (upstroke) -- 160 Tons of overall pressure -- Recirculating Thermal Oil heated with package heaters housed in a boiler tank.Detailed Specs: -- Platen size 1300 mm x 3200 mm (51" x 126") approx. Thermal Oil heated Hot Press with drilled steel platens, 1.5" thick; -- (8) Hydraulic "upstroke cylinders", approx. 85 mm dia.; rack & Pinion guide system for parallel closing of the platens. -- 40 PSI specific pressure over the entire platen area; 54 kW heating power. Approx. 7.5 kW (10 HP) hydraulic pump motor. -- 1.5 kW (2 HP) Hot Oil circulation pump; approx. 120° C (248° F) max. operating temperature. -- Max Working height is 4"; Loading from (3) sides; 39-1/2" from floor with lower platen in the down position; Heavy I-beam welded steel frame construction. -- "Safety" emergency Stop Cable around the operating sides of the machine, and E-STOP mounted on the control panel. -- Overall press weight is approx. 27.500 Lbs. -- Optional: Extra Large Oil Heating Tank for Special Higher Temperatures if needed. Several more Sizes, Tonagge, Temperatures available. Please inquire.

HYDREX HPX510-1 Hot Press, Single daylight opening. Suitable for laminating veneer panels/doors, decorative paper, fireproof board, etc.Features (Overall): -- Board size up to 5' x10', -- Front Controls for easy setup & operating configuration, incl. temperatures and cycle time , emergency pedal, quad temperature protection device. -- (8) Cylinders (upstroke) -- 120 Tons of overall pressure, -- Recirculating Thermal Oil heated with package heaters housed in a boiler tank.Detailed Specs: -- 122" x 61" Thermal Oil heated Hot Press with drilled steel platens, 1.5" thick, 4" Max Working height.. -- (8) Hydraulic "upstroke cylinders", 85 mm dia.; rack & Pinion guide system for parallel closing of the platens. -- 120 Ton total pressure, 40 PSI specific pressure over the entire platen area; 4.5 KW (6 HP) hydraulic pump motor. Platen moving speed 5 FPM -- 1.5 kW (2 HP) Hot Oil circulation pump; approx. 120° C (248° F) max. operating temperature. -- Loading from (3) sides; 39-1/2" from floor with lower platen in the down position: heavy I-beam welded steel frame construction. -- "Safety" emergency Stop Cable around the operating sides of the machine, and E-STOP mounted on the control panel. -- Features: "Last" (2) cylinders can be turned off to press shorter panels. - Overall press weight is approx. 19,500 Lbs).

HYDREX HPX510-5 Hot Press 120 Tons with (5) Daylight openings. Suitable for laminating veneer panels/doors, decorative paper, fireproof board, etc.Features (Overall): -- Board size up to 5' x 10', -- Front Controls for easy setup & operating configuration, incl. temperatures and cycle time, emergency pedal, and quad temperature protection device. -- (8) Cylinders (upstroke) -- 120 Tons of overall pressure, -- Recirculating Thermal Oil heated with package heaters housed in a boiler tank.Detailed Specs: -- 122" x 61" Thermal Oil heated Hot Press with drilled steel platens, 1.5" thick; -- (8) Hydraulic "upstroke cylinders", approx. 85 mm dia.; Rack & Pinion guide system for parallel closing of the platens. -- 120 Ton total pressure; 54 kW of heating power. 40 PSI specific pressure over the entire platen area; 4.5 kW (6 HP) hydraulic pump motor. -- 1.5 kW (2 HP) Hot Oil circulation pump; approx. 120° C (248° F) max. operating temperature. -- Max Working height is 4"; Loading from (3) sides; 39-1/2" from the floor with lower platen in the down position: heavy I-beam welded steel frame construction. -- "Safety" emergency Stop Cable around the operating sides of the machine, and E-STOP mounted on the control panel. -- Features: "Last" (2) cylinders can be turned off to press shorter panels. - Overall press weight is approx. 24,000 Lbs. -- Overall dimensions: 3,800 length (+610mm -boiler + 610mm -pump/tank) x 1,790 wide x 2,450 mm high.

HYDREX HPX512-5 Hot Press 160 Tons with (5) Daylight openings. Suitable for laminating veneer panels/doors, plastics/decorative paper, fireproof board, etc.Features (Overall): -- Board size up to approx 5' x 12'. -- Front Controls for easy setup & operating configuration, incl. temperatures and cycle time, emergency pedal, and quad temperature protection device. -- (8) Cylinders (upstroke) -- 160 Tons of overall. Approx 100 psi unit pressure, -- Recirculating Thermal Oil heated with package heaters housed in a boiler tank.Detailed Specs: -- 146" x 61" Thermal Oil heated Hot Press with drilled steel platens, 1.5" thick; -- (8) Hydraulic "upstroke cylinders", approx. 100 mm dia.; Rack & Pinion guide system for parallel closing of the platens. -- 54 kW of heating power. 100 PSI specific pressure over the entire platen area; 4.5 kW (6 HP) hydraulic pump motor. -- 1.5 kW (2 HP) Hot Oil circulation pump; approx. 120° C (248° F) max. operating temperature. -- Max Working height is 4"; Loading from (3) sides; 39-1/2" from the floor with lower platen in the down position: heavy I-beam welded steel frame construction. -- "Safety" emergency Stop Cable around the operating sides of the machine, and E-STOP mounted on the control panel. -- Overall press weight is approx. 30,000 Lbs. -- Overall dimensions: 3,800 length (plus 610mm - boiler + 610mm -pump/tank) x 1,790 wide x 2,450 mm high. -- NOTE: Stated data/specs as it relates to 160 Ton and specific pressure (dimension and weight) , KW, Cylinder Dai. are based on 5' x10' platen size. Revised numbers for 5'x12' size will follow as available from factory. Also if there is a price change it will be revised according as soon as the info is provided from factaory.
