Woodworking Equipment For Sale

VIET - S2-321-HP/KRT, ...3-Head Planer Sander3-Head Planer/Sander 43" with: Planer, Drum and Combi-HeadSpecifications: -- Max. operating width: 1,100 mm (43") -- Min/Max thickness: 3 mm - 160 mm (1/8" to 6.3") -- Working Height: 900 mm (36") -- Abrasive Belt dimension: 44" x 103" -- Feed speed: 3 - 16 MPM (9-3/4 - 52 FPM) -- Rubberized drum: 30 HP Motor -- Combination head with drum & platen; driven by the same motor as the sanding drum -- Extended infeed & outfeed roller -- Planer head with helical insert knives: 30 HP Drive motor

VIET - S211 R+ KRT, 2-Head Wide Belt Sander43" Width. cap.: Drum and Combination head.Head Configuration:1st Head: 160 mm 6.3″ Helical grooved rubber drum. 25 HP motor2nd Head: 160 mm (6.3") Helical grooved rubber drum with a platen combination head., 25 HP motorSpecifications: -- Each heads are powered by a 25 HP motor. -- The heads can be programmed to pneumatically raise & lower along with the platen and do (3) sanding combinations (with the twist of a button). -- Digital height readout and a calibration unit to the left side of the conveyor. -- Conveyor speed is controlled via a variable frequency drive 2.5 HP . -- Max width: 43″. -- Max. height: 6-1/4". -- Variable speed conveyor belt drive from: 3 - 16 MPM (11 - 52 FPM).Equipped with & Features: -- Both heads are equipped with: 1,130 x 1900 mm (44-1/2" x 75"). -- Roller & pressure shoe holddowns. -- Pneumatic tension of sanding belts and feed conveyor. -- Load meter on main motor. -- Disc brake on main motor. -- Emergency stops front & back. -- Roller table extensions front & back.NOTE: This is an extremely low-hour 2012 BIESSE Viet S1 dual head 43″ calibrating Wide Belt Sander.

Viet Opera 5-4.3 RRRR, (4) Head Wide Belt SanderCalibrating Sander (89 Hours)53″ wide cap. - Drum, Drum, Drum, DrumHead Configuration1st Head: 9″ Helical grooved steel drum powered by a 22 kW or 29.5 HP motor.2nd Head: VARIABLE SPEED (via VFD) 9″ helical grooved rubber drum powered by a 18.5 kW or 25 HP motor. 3rd Head: VARIABLE SPEED (via VFD) 11″ helical grooved rubber drum powered by a 15 kW or 20 HP motor. 4th Head: VARIABLE SPEED (via VFD) 11″ helical grooved rubber drum powered by a 15 kW or 20 HP motor.5th Station: Dust brush powered by a 1.27 kW or 1.7 HP motorSpecifications -- The durometer does get softer from head 2 to 3 and then from head 3 to 4. -- It has 53″ width capacity and a 200 mm or 7.87″ thickness capacity. -- Right above the machine's infeed, you will find inspection LED lighting, a digital thickness calibration unit, and a wireless Mitutoyo Digimatic Caliper that communicates with the Opera’s operating system. -- The vacuum bed is powered by an 11 kW or 15 HP blower under the sander to save space. -- The feed mat is powered by a 5.5 kW or 7.5 HP motor with variable speed via a VFD with feed speeds from 9.8 to 52.4 FPM.Equipped with & Features -- Inside you will find interior LED lighting while all the controls on this Opera are upfront via a touch screen -- Constant pass lineNOTE : This calibrating sander has a total of 1,982 power on hours and ONLY 89 run (conveyor) hours. This is a very loaded, LOW Viet Viet Opera 5 (4) Head 53″ Calibrating Sander

VIET OPERA 7-5.3 HRKXF 1,350 mm (53.15") 5-Head Knife Planer/Calibrating Sander, with 3,634 Powered-On & 675 Run Hrs.Specifications: -- Thickness cap. 200 mm (7.87";).Equipped with: -- 1st Head: “HPG"; Planer Unit, with 180 mm (7.09";) Dia. Cutterhead with (520) Knives & 30 kW (40 HP) Motor, 26-Section Front pressure shoe, & Single back pressure shoe with chromium anti-wear lip. -- 2nd Head: “2620"; Working Unit, with 320 mm (12.60";) Dia. 90 Shore Rubber-covered contact roll with 22 kW (30 HP) Motor, Cam shaft system belt cleaning blower, & Single front pressure shoe with chromium anti-wear lip. -- 3rd Head: “KOMBI 2620"; Combination Working Unit, with 190 mm (7.48";) Dia. 60 Shore Rubber-covered contact roll, Platen with “IPA"; Electronic segmented pad with (42) Segments, 32 mm (1.26";) Pitch, Low pressure action, & Contact insert with Steel & felt grooves & Removable graphite cloth, 18.5 kW (25 HP) Motor with Electronic inverter, & Cam shaft system belt cleaning blower. -- 4th Head: “X-SPIN PLUS"; Unit, with (15) Discs, with Steel inserts & Slots for 180 grit abrasive inserts, & 11 kW (15 HP) Motor with Electronic inverter. -- 4th Head: “2620"; Superfinishing Unit, with 2,160 x 1,420 mm (85.04"; x 55.91";) Chevron belt with Removable graphite cloth, & Platen with “IPA"; Electronic segmented pad with (42) Segments, 32 mm (1.26";) Pitch, Low pressure action, & Contact insert with Steel & felt grooves & Removable graphite cloth, 15 kW (20 HP) Motor with Electronic inverter, & Cam shaft system belt cleaning blower. -- All heads with Disc brakes. -- Adjustable 55 Shore spiral grooved rubber-coated pressure rollers. -- 200 mm (7.87";) Dia. “SCOTCH-BRITE"; Brush roll, with 1.1 kW (1-1/2 HP) Motor. -- Rotary Panel cleaner, with Air saving system. -- 50 Shore Rubber ground laminar surface vacuum feed belt, with 900 mm (35.43";) Height, 7.5 kW (10 HP) Motor with Electronic inverter, & Pneumatic belt tracking. -- 3-Roll Front & rear table extensions, Each with (1) Driven & (2) Idler Rollers. -- All motors with IP54 & Thermal relay protections. -- Self-lubrication system for pneumatic components. -- Front safety bar. -- Carbon steel electro-welded profile frame. -- IPC 15"; Touchscreen control (“SOPHIA"; IoT Connection-ready), with 100-Working program memory, Motor load meters, & Electronic digital readout with Automatic thickness positioning.Complete with: -- Translucent “LEXAN"; Side doors. -- 150 mm (5.91";) Wireless Panel Thickness Caliper.

VIET Challenge S2-3232620-SW53 Wide Belt Sander, 3-Head with (3) Contact Rollers3-Head, 1,350 mm (53") max. working width. Solid wood and thick veneer sander. Head configuration:1st Head: Rubber covered contact roll 320 mm (12-1/2") diameter. Shore hardness 80, 18.5 KW motor, abrasive belt speed 24 m/Sec. (79 FPS).2nd Head: Rubber covered contact roll 200 mm (7.9") diameter. Shore hardness 50. 15KW motor. Abrasive belt speed 20 m/Sec. (66 FPS).3rd Head: Rubber covered contact roll 200 mm (7.9") diameter. Shore hardness 30. 14 m/Sec (46 FPS). (2nd motor 15 KW drives 2nd & 3rd headSpecifications: --All heads equipped with 1380 x 2620 mm (54 " x 103") abrasive belts; roller & pressure shoe hold downs. -- Feed system: Vacuum conveyor system. 3 KW (4 HP) motor variable speed belt drive from 3 - 16 m/Min (11 - 52 FPM). -- Material thickness range 3 - 160 mm (0.1 - 6.3"). -- Pneumatic feed conveyor tension; constant pass-line with height adjustment (for varying material thickness) with digital read-out, driven by 0.75 HP (0.55 KW) motor for the upper section. -- Machine control system: PLC processor control with sequential motor startup and storage for multiple sanding programs.Equipped with & Features: --Panel cleaning followed by turbo-jet air jets at exit side; belt cleaning by air blasts. -- Load meters on all heads. Dust extraction for each head [email protected]" diameter and [email protected]"; disc brakes on all heads; emergency stop for belt breaks. CE Compliant.Note: Comes with 2 extra rollsActual model is VIET S2-3232620-SW53 Wide Belt Sander

VIET Planer Sander Sander model S2 321 HR/KRT ( 2018 ) !st head planer with helical insert cutter knives 30 HP 460 volts 2nd head drum contact roller 3rd head combination drum rollers with finish platen Both sanding heads run by 30 HP motor 460 volts Adjustable rubber coated pressure rollers Opening capacity range 1/8” to 6” Sanding belt size 44” x 103” Feed speed 19 to 52 FPM Electronic digital readout with auto thickness positioning Disc brakes on each machining station Front and rear emergency push buttons Electro pneumatic sanding belt tracking This machine has low hours as owner only ran half days first year and less after next years

VITAP - ALFA 27: Construction Boring Machine27-Spindle boring head on 32 mm centers; drills vertically from bottom-up and head rotates to horizontal position for edge boring; head rotation is pneumatic with switch control. -- 2-3/4" Max. drilling depth; 2-1/2 HP - 2,800 RPM motor; pneumatic drill head advance with speed control; head height adjustment with mechanical digital readout; 34" x 20" table size; max. workpiece width 31-1/2". -- Equipped with: Left & right-side fences for construction boring; (3) pneumatic holddown clamps; 118" line boring fence with: (4) Flip stops; pneumatic foot pedal control.

For pre-glued PVC, veneer, & melamine laminate coil stock; 0.4 - 1.2 mm edge thickness; up to 35 mm panel thickness cap., automatic coil feed. -- Equipped with: Electronically controlled temperature setting for hot air blower; 3,000 Watts for up to 650° F temperature; (1) Min heat up time. -- Guillotine type front & rear end trim (with fast speed, flying knife); top & bottom flush trims with single motor drive to cutterheads. -- Overhead belt type feeder; 16 FPM feed speed. -- Mounted on machine base with panel support table.

VITAP LINEA 42 Line Boring SystemSpecifications: -- (2) Drill heads of (21) spindles ea., drills from bottom up, ea. support with 2 HP motor and (21) spindle boring block w/panel support mounted on top; -- Drills panels from 100 - 3,000 mm in length, and 100 - 950 mm in width. Complete with: -- Digital readouts for boring blocks, 2,000 mm bar scale fence with (5) adjustable flip stops. -- (2) Moveable overhead pneumatic holddown cylinders, foot pedal for clamping & boring cycle.

Vitap Forma Boring Machine 21 Vertical Spindles 21 Horizontal Spindles Approx $1000 worth of carbide bits DUAL LINE machine and there are (2) vertical lines of 21 spindles each for a total of 42 ...... PLUS an additional single line of 21 horizontal spindles!

VITAP - RC 92, ...Semi-Automatic Top & Bottom Edge Trimmer: New, Never Used!Specifications -- For straight & curved edge banded panels. -- Max. edge thickness: 3 mm (0.12"). -- Panel thickness: 10 - 60 mm (0.39" - 2.36"). -- Table size: 27" x 31".Equipped with: -- (2) 0.55 kW (0.7 HP) - 12,000 RPM Spindle motors. -- Large dia. guide bearings to ensure precise trimming of edges.NOTE: Sold "As Is" without Warranty!

VITAP ALFA - 27: Construction/Line Borer27-Spindle boring head on 32 mm centers; drills vertically from bottom-up and head rotates to horizontal position for edge boring; head rotation is pneumatic with switch control. -- 2-3/4" Max. drilling depth; 2-1/2 HP - 2,800 RPM motor; pneumatic drill head advance with speed control; head height adjustment with mechanical digital readout; 34" x 20" table size; max. workpiece width 31-1/2". -- Equipped with: Left- & right-side fences for construction boring; (2) pneumatic holddown clamps; 118" line boring fence w/flip stops; pneumatic foot pedal control; magnetic starter; overload protection.

Vitek Stroke sander Approx 8 foot capacity

VALPATO LBK-150-ST 1 Feed Through Profile SanderTECHNICAL FEATURES: An added small needle type drum sander can be fitted with drum sanding aggregates of 25, ­30, ­35,­40, ­45 ­50 mm diameters which can be used for tighter curves and smaller radius sanding requirements. Storage compartments (2 in total) are located on each machine extremities, these are easily accessible and can be used for sanding belts and various tooling storage. Sanding belt motor power: 3 Kw Abrasive head motor power: 1.5 Kw Oscillation motor power: 0.38 Kw Feed motor power: 0.75 Kw Motor power for electrical adjustment of sanding group: 0.19 Kw Machine voltage: 480/3/60 Full Load Amps @ 480V: 15A Compressed air: Not required Dust collection requirement one (1) only 6" (150mm) port: 950 CFM Sanding belt speed: 14 Mt/sec Variable speed of the belt: from 5 to 25 m/min Sanding belt dimensions: 150 x 2640 mm Height of working table: 930 mm Dimensions of front working table: 1980 x 250 mm Machine dimensions: 2500 x 900 x 1600 mm Net weight: 1000 KMAIN FEATURES: User friendly PLC touch screen control panel is accessible from 360° by the operator, the control panel is centrally located on the infeed end of the machine. Factory installed variable feed drive (VFD), enables machine to run from 5 M/Min to 25M/min (+/­ 80 ft/Min). The entire sanding plenum rise and fall is motorized, it can be adjusted vertically in height to utilise the full height/width of the sanding belt. An oiling unit ensure long life of sanding plenum rise and fall master cylinder.

VOORWOOD M 15A CNC Round End Tenoner & Mortiser for 45° Door --The "M15A" Miter Machine is designed to rapidly make mortise and tenon cuts at 0°, 45° Only, . Parts can be up to 1.5"; thick and up to 4"; wide, and of ANY length. --A primary application for this machine is for miter cabinet door frames. Parts can be quickly transferred from left to right. They are mortised on the left side of the machine and tenoned on the right. The machine can also mill the slots. --Specifications & Equipped with: -- The mortise station has (3) servo-controlled axes (X, Y, and Z) that are coordinated by the machine controller to achieve complex CNC motion. It is equipped with a collet-style router spindle for cutting. The tenon station uses the same X- and Y-servo-controlled axes as the mortise station and is configured for pneumatically actuated in-and-out movement along the Z-axis. The tenon station is equipped with a direct drive shaper spindle for cutting. -- -- Pneumatic clamping assemblies with non-marring urethane pads are mounted to the hold-down assembly to secure the parts during cutting and these can be adjusted to various locations over the cutting surface. -- -- M15 Miter Machine operator interface consists of a colored touch screen. For simplicity, the entire calibration, setup, and monitoring of the machine are accomplished using only four touchscreen displays. The program designs the depth and location of both the mortise and the tenon. When the design is complete, it is saved in a recipe format. Once this recipe is opened, the operation is as simple and boils down to feeding the substrate into the machine. -- -- The full-color touchscreen panel is located on the front of the machine to provide easy access for setting up or operating the machine. Clamping and shaping operations are controlled by operating lighted pushbutton switches.

VOORWOOD "A 515 GH" Arch Door Sander with Floating Head ARCH SANDER with: (4) 1.5 HP Motors for precision sanding; quality sanding using Disc sanding at continuous feed. Equipped with: -- (4) Floating Sanding Stations equipped with: 1.5 HP Precision balanced drive motors and quick change spindles. -- Infeed & outfeed (1st and last) spindles equipped with: Double collets and angular, horizontal & vertical adjustments with accurate and repeatable digital readouts. -- PLC Control with: Monitor at eye level height.Feedthrough Arch Machine capable of sanding arch profiles on cabinet door components, plus can do straight cuts.. .

7 Spindle Moulder with Manual Bed Lubrication 6000 RPM Spindle Speed 19-91 F/Min Feed Speed Will Take 7" x 5" Lumber Specs: 1ST BOTTOM--7.5 HP 1ST FENCE SIDE--7.5HP 1ST LH SIDE--10HP 2ND FENCE SIDE--7.5 HP 1ST TOP-15HP 2ND BOTTOM-10HP UNIVERSAL-7.5 HP FEED DRIVE--3 HP BEAM LIFT--.5 HP

WADKIN "GA-220" 5-Head Feed Through MoulderSpecifications: -- 5-Head, with 8-5/8" x 4-5/8" cutting capacity (220 mm x 120 mm) -- 40 mm Spindle diameter with cutterhead speed of 6,000 RPM. -- Head sequence: Bottom 10 HP, Right 7-1/2 HP, Left 7-1/2 HP, Top 15 HP, Bottom 10 HP motor. -- 2 HP variable feed speed 19 to 72 FPM, chain drive. -- Currently wired for 460 Volt, 3-Phase power.

WADKIN GD 220 6-Head Feed Through MoulderSpecifications: -- Working capacity: 230 mm W x 130mm H (9.06" W x 5.12" H) Timber admitted, 220 mm W x 120 mm H (8.66" W x 4.72" H) Finished timber. -- Head Sequence: Bottom 7-1/2 HP, Right 7-1/2 HP, Left 7-1/2 HP, Top 15 HP, Bottom 10 HP, & Universal 7-1/2 HP. -- Spindle dia. 40 mm (1.57"), Spindle speed 6,000 RPM. -- Variable feed speeds 6 - 22 MPM (20 - 72 FPM).Equipped with: -- Right, Left & Top heads with Mechanical digital readouts. -- 1/2 HP Motorized feed beam, 2.2 kW Feed motor, 3 HP Cardan drive, Reverse feed, 5-1/2" Dia. Hardened & Chromed steel feed rollers up to top head, 2" x 2" Polyurethane feed rollers after top head, All feed & pressure rollers move with rise & fall of feed beam. -- 2 M (78.74") L Infeed straightening table. -- Manual bed lubrication. -- Sound enclosure.

Wadkin GA 5363 5 Head Moulder
