Woodworking Equipment For Sale

WEEKE BHX 200 OPTIMAT CNC MACHINING CENTER (VERTICAL W/ATC). -- Specifications:Flexible "Vertical" Machining Center with "ATC" that uses less than 5 meter² of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm), "Y" axis 49.2" (1,250 mm), and max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 7.8" (200 mm), "Y" axis 2" (50 mm), min. part thickness of 0.31" (8 mm). Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 200 can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring unit:(1) 3 HP (2.3 kW), variable speed from 1,500 - 7,500 RPM motor, Split Head, (20) independent Vertical spindles, with (14) spindles in "X" axis & (6) spindles in "Y" axis.(16) Split Head, Horizontal spindles, with (6+6) in "X" axis & (2+2) in "Y" axis; Boring block has "QUICK CHANGE" spindle system, -- Operator Interface:Weeke "POWERTOUCH" + Windows + WoodWOP 6.1 + operating system; "IntelCore 2 DUO" Processor;17" TFT Monitor; international keyboard, soft-touch keypad & industrial mouse; RS-232 Serial ports, USB ports; modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:(1) NC controlled 0° - 90° "X/Y" grooving saw; 9,000 RPM, saw blade dia. 100 mm;(1) 13.4 HP (10 kW) Electro spindle router with HSK F3 adaptor, variable speed from 6,000 - 24,000 RPM.(1) 4-position ATC tool rack mounted on the side of the machine base.(1) Barcode Scanner.(1) AC unit for Electrical cabinet. -- Actual Model is WEEKE BHX 200 OPTIMAT

WEEKE BHX 050 CNC MACHINING CENTER (VERTICAL): -- Specifications: Flexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space, in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The "BHX 050" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW), Variable speed from 1,500 - 7,500 RPM motor, (6) independent spindles with: (4) spindles in "X" axis & (2) spindles in "Y" axis.Boring block has QUICK-CHANGE spindle system. -- Operator & Machine Control:WEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include: Max. workable part size for "X" axis is 120" (3,050 mm. (1) "X" Axis grooving saw; 9,000 RPM, saw blade dia. 100 mm. (1) 7 HP (5 kW) Electrospindle router with hydraulic "QUICK-CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE - BHX 050.

WEEKE - BHX 050: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 meter² of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis: 33.4" (850 mm); max. part thickness: 2.4" (60 mm). -- Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis: 2.7" (70 mm); min. part thickness of: 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 050 reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 2.4 HP (1.8 kW); Variable speed from: 1,500 - 7,500 RPM motor; (8) independent spindles with: (4) Spindles in "X" axis & (4) spindles in "Y" axis. -- (6) Horizontal spindles with: (2 + 2) In "X" axis; (1 + 1) in "Y" axis. -- Boring block has "QUICK CHANGE" Spindle System. -- Operator InterfaceWEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor. -- 17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection. -- Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include: (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. (1) 7 HP (5 kW) Electrospindle router with: Hydraulic "QUICK CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE BHX 050

Weeke Optimat BHC Venture 2.5 Point To Point CNC Router Manufacturer Specifications "X" Axis is 141.5" (3,595 mm), "Y" axis is 54.2" (1,378 mm), "Z" axis stroke is 9.8" (250 mm), max. material thickness is 3.9" (100 mm). "X" Axis 197 FPM (60 MPM), "Y" axis 164 FPM (50 MPM), "Z" axis 49 FPM (15 MPM); head travels on THK linear motion guides on all axes. (6) Tubeless K-Table support rails, (4) pneumatic panel lifters for heavy panels Pneumatic backstops, frontstops, & side stops create (2) working zones. Boring Unit, 4 HP (3.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (12) independent vertical drill spindles, (6) spindles in X-axis & (6) in Y-axis. (6) Horizontal spindles, (2 + 2) in X-axis & (1 + 1) in Y-axis; grooving saw with 100 mm dia. saw blade. (1) 10 HP (7.5 kW) Air cooled electro spindle router, HSK-F63 adaptor; powered by a frequency inverter w/programmable speed from 1,250 - 18,000 RPM, RH or LH rotation. NC Controlled C-axis for 360° horizontal processing; 8-position ride-along tool changer

--MAKE OFFER!---VERY GOOD CONDITION-- WEEKE BHP 100/VANTAGE 480 FLAT TABLE MACHINE, with ATC, Boring, Infeed Roller & Outfeed & 4,771 Hrs. (As of 10/31/23) Specifications: 4' x 8' Bridge style gantry machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. Working Area: 'X" axis 99.21" (2,520 mm), "Y" axis 49.21" (1,250 mm), Max. material thickness of 3.94" (100 mm). Travels: “X” axis 146.06” (3,710 mm), “Y” axis 81.30” (2,065 mm), “Z” axis 13.70” (348 mm) Routing, 8.46” (215 mm) Boring. Positioning Speed: "X" & "Y" axis Vector speed is 314 FPM (96 MPM), "Z" axis 65 FPM (20 MPM); The head travels via AC brushless drives & THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech "MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. (2) Fixed LH side & (2) Fixed RH side pneumatic pop-up positioning stops. Boring Unit: (1) 3 HP (2.3 kW) Motor, variable speed for 1,500 - 7,500 RPM; (21) Independent vertical spindles with (8) in "X" axis, (9) in "Y" axis (1st Row), & (4) in "Y" axis (2nd Row). Machining: (1) 12 HP (9 kW) Air Cooled High speed constant duty Router with HSK F63 adaptor, 1,250 - 24,000 RPM, constant torque achieved at 9,000 RPM, RH or LH rotation (1) 14-Position tool changer Carousel located at the back side of the spindle carriage. Machine & Operator Control: PC Front-End with WEEKE "Power Control + Windows + WoodWOP operating system. 17" TFT Color graphic monitor, Hand-held control pendant, Foot pedal control; "BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation; The controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. Complete with: 488” W x 96” L Infeed electric/hydraulic Scissor Lift platform, with 3” x 3” Support beams on 7” Centers; 4’ L Roller track intermediate table; vacuum arm with (2) 10” dia. vacuum pads; rake off-feed System; 49” W x 10’ L x 36” H Outfeed motorized belt conveyor; BUSCH "MM 1322 A VM3" 10 HP (7.6 kW) 300 mbar Vacuum Pump; 6’ H Safety fencing. Actual model is WEEKE BHP 100/VANTAGE 480 Machine Dimensions: 292” x 202” x 96” H. Machine with Scissor Lift Dimensions: 389” x 202” x 96” H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Weeke BHC 550 CNC Router S/N 0-250-13-0781 Out and ready to Load.

Weeke BHX 055 CNC Center

X-Axis Travel: 100? Y-Axis Travel: 68? Z-Axis Travel: 9? Max Workpiece Thickness: 4? Spindle Speed: 1,250 – 24,000 rpm Equipped With: Powerful HSK Router Spindle- Up to 9 kW 6 Pneumatically Fixed Work Piece Supports Safety Positioning of Work Piece Consoles and Vacuum Cups

Weeke ABD 050

WEEKE - ABD 100: CNC Bore, Glue & Dowel Inserter -- Specifications(1) Horizontal drilling aggregate with: (1) Individual spindle; (1) glue & dowel injector with glue flow control; (1) 23" dia. x 4" D vibrating hopper dowel feeder. -- Working Capacity: Material size: 20 mm - 1,250 mm (3/4" - 49") Long; 50 mm - 800 mm (1.9" - 31-1/2") wide; 10 mm - 60 mm 0.4" - 2.4") thick.Machine is set up for: 8 mm Dia. x 30 or 35 mm long dowels (additional dowel sizes are optional). -- (2) Separate working fields with: (4) 2-3/4"; LR x 3"; FB Pneumatic top clamps; can process up to (4) parts independently on the: Left-hand, right-hand, or center stops; work can be loaded in (1) field while it is being machined in the other to allow fast production of varying parts. -- Operator InterfacePC Front-End with: Windows XP + WEEKE "WoodWOP 5.0" Operating System with graphic programming & error messaging; USB front side bus; 17" TFT flatscreen monitor; CD-RW drive; modem; standard keyboard; mouse.Software allows program design with automatic mirror image by use of an active center stop located: 600 mm (23.6") From zero. -- WEEKE "ABD 100": Designed for small or large capacity horizontal drilling, gluing, and dowel insertion; built on Heavy-Duty welded steel base; main horizontal beams hold the carriage for the boring head & glue/water injector. NOTE: Monitor needs to be replaced

WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code control reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050.

WEEKE VANTECH 480 (BHP - 007/410): CNC Flat Table MachineWorkpiece Capacity -- Max. panel length: 3,050 mm (120"). -- Max. panel width: 1,250 mm (49"). -- Workpiece thickness: 8 – 60 mm. -- Max. workpiece weight: 50 kG (110 Lb).Drilling Unit -- Vertical drill spindles: 9. -- Horizontal drill spindles: X Direction: 2 Y Direction: 2Spindle speed: 6,000 RPMDrill spindle power: 1.5 kWRouting / Milling -- Routing spindle power: 3.5 – 4.0 kW. -- Routing spindle speed: Up to 18,000 RPM. -- Tool holder: ISO 30. -- Tool change: Manual. -- Tool rack with: (6) Tool holders.Axes & Feed -- CNC Axes: X, Y, Z. -- Positioning Accuracy: Approx. ±0.1 mm. -- Repeatability: Approx. ±0.05 mm.Clamping & Handling -- Material positioning: Pneumatic clamps. -- Reference System: Automatic panel alignment. -- Panel Support: Phenolic / aluminum Support Rails. -- (2) Vacuum Pump: BECKER - VT 300: Vacuum Pump.Type: Dry running (oilless) Rotary Vane Vacuum Pump.Rated airflow: 300 cbm/Hr.Rated airflow: 174 SCFM.Max. vacuum: 24–25 inHg.Ultimate vacuum: −850 mbar.Motor power: 6.4 – 7.5 kW (8-1/2 – 10 HP).Motor speed: 1,720 RPM (60 Hz).Voltage: 460 V.Control -- CNC Control: HOMAG / WEEKE controller. -- Programming: WoodWOP compatible. -- Interface: Industrial control panel with display.Weight: 3,100 LbsDimensions: 80'' x 150'' x 95''.

WEEKE - BHX 055: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 33.4" (850 mm), max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 055" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety - providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Variable speed from 1,500 - 7,500 RPM motor; (15) independent vertical spindles with: (10) Spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with: (2+2) in "X" Axis & (1+1) in "Y" axis.Boring block with "Quick Change" vertical spindle system. -- Operator Interface:WEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor: International keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive: modem, Ethernet connection.Real time multitask processing: Programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include: (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. (1) 4-position ATC Changer. (1) 7 HP (5 kW) Electrospindle router with:HSK F63 Adaptor; variable speed from 6,000 - 18,000 RPM.

WEEKE VANTECH 512 / OPTIMAT BHP 008 - FLAT TABLE MACHINE (W/ATC/BORING + LOADING/UNLOADING): -- Specifications:5' x 12' Flat Table "Bridge Gantry" machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Capacity: "X" Axis 156.7" (3,980 mm), "Y" axis 61" (1,550 mm), "Z" axis stroke is 9.6" (243.8 mm); max. material thickness is 3.9" (99 mm). -- Positioning Speed:"X" & "Y" Axes 315 FPM (96 MPM); "Z" axis is 82 FPM (25 MPM).The head travels via AC brushless drives & THK linear motion guides on all axes. -- WorktableUser-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(6) Pop-up pneumatic locator/positioning on the front side & (1) on the back side in "X" axis & (2) pop-up pneumatic locator/positioning pins on RHS facing side in "Y" axis.(4) Vacuum Table work zones can be used independently or together for full table area Foot pedal vacuum zone controls. -- Boring Unit1.5 kW (2 HP) Motor, with "Quick Change" drill bit holders; programmable variable speed from 1,500 - 7,500 RPM; -- Machining(1) 12 HP (9 kW) High speed constant duty, variable speed electro-spindle router with "HSK F 63" adaptor.Router is programmable from 1,250 - 24,000 RPM, RH or LH rotation.(1) 15-Position ATC plate located at the back side of the machine. -- Operator InterfacePC Front-End with: WEEKE "PC 85T" + "Windows XP" + WoodWOP Operating System.17" TFT Color graphic monitor; keyboard for data entry; PC 85T hand control pendant; central USB hub; Ethernet interface for LAN connection to office PC; RS-232 serial interface.BECKHOFF Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the controller is contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (4) 100 m³/Hr Vacuum Pumps; safety light curtain (the machine will stop when the Operator enters the work area); safety fencing; separate control cabinet. - Manuals & Documents -- Options Include: NC Controlled Touch-Off Tool Probe, length measuring device. (1) NC controlled scissor lift/vacuum in-feed device. (1) NC controlled, powered flat belt outfeed table with Automatic Dust Control Vacuum Sweep Arm Rake system. Laser fence surround for safety -- Actual Model is: WEEKE VANTECH 512 / OPTIMAT BHP 008.

Weeke Vantech 480 CNC Router 4x8 Table

Manufacturers Specifications tool diameter: 100 - 300 mm tool width: max. approx. 230 mm motor / grinding disc drive: approx. 1,1 kW free angle, adjustable 15 - 35° drive for coolant pump: approx. 0,065 kW tank capacity: approx. 90 l

Weinig Unimat Gold - 6-Head Machine Weinig Rondamat R960 Grinder Includes: Tooling and approx (200) profiles from tool room

Weinig U22N Moulder 7 head Mid 80s Freshe rebuild

1978 Weinig 7 Head Moulder S/N 2816/2248

Weinig R950 Profile Grinder
