Woodworking Equipment For Sale

Weinig U22N Moulder 7 head Mid 80s Freshe rebuild

1978 Weinig 7 Head Moulder S/N 2816/2248

Weinig R950 Profile Grinder

2000 Weinig Profimat 266 Moulder 460V 3ph

1st Head – Bottom– 40mm spindle – 11kw 8,000 RPM • Electronic digital display for radial adjustment Marathon Coating Table plates 2nd Head – Right – 40mm Spindle – 11kw 8,000 RPM 3rd Head – Left – Powerlock Spindle – 15kw 8,000 RPM Pressure shoe in front of left tool holder, incl. 2 lateral Pressure rollers, pneumatic. Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Left tool holder incl. electronic digital display. 4th Head – Right – Powerlock – 11kw 8000 RPM 5th Head – Top – Powerlock – 15kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Upper tool holder incl. electronic digital display Split pressure shoe in front of upper tool holder, pneumatic Oscillating axial adjustment 6th Head – Top – Powerlock – 11kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Upper tool holder incl. electronic digital display Split pressure shoe in front of upper tool holder, pneumatic Oscillating axial adjustment 7th Head – Bottom – Powerlock – 11kw 8000 RPM 8th Head – Right – Powerlock – 11kw 8000 RPM An additional pressure roller from above opposite 3rd right Tool holder, swing away for easy Tool change, pneumatic 9th Head – Left – Powerlock – 11kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after left Tool holder incl. Electronic digital display. Frequency controlled feed, 11 KW (6-36m/min 5 meter in-feed table Automatic lubrication pump Two driven rollers in the machine table, hardened Pressure rollers from above, pneumatic PowerCom Plus Software CNC controlled adjustment and positioning. Axial CNC – controlled adjustment and positioning of the Tool holders in connection with the Memory function or PowerCom. For tool holder no. • 2,3,4,5,6,7 Radial CNC – controlled adjustment and positioning of the Tool holders in conjunction with the memory function or PowerCom. For tool holder No. 3,4,5,6,7 CNC – controlled adjustment and positioning of the feed Automatic central lubrication of the oscillating Tool holders Two interior lights in the safety hood Comes with new Transformer.

WEINIG - ProfiJoint: Short Stock Finger Jointer"ProfiJoint" Flexible Finger Jointing Line: Used for processing timber packages & manufacturing horizontal, as well as vertical finger joints. Perfect for 1st-time buyers; can be modified to accommodate a Shaper combination, if need be. Easy to operate; compact design; provides same high-quality WEINIG product. Includes: High-capacity Shaper and Shaper Table (19"; wide); carries packaged timber pieces to Finger Joint either horizontally or vertically. Shaping unit with: Axial adjustment; 1/100 mm precision for the finger length horizontally or vertically. -- Optional: Scoring units for horizontal jointing and avoidance of any tear-out.Technical SpecificationsTo be confirmed: Utilizes FLANKEN-JET-Jet Glue System; only the exact amount of glue needed is automatically applied. GreCon developed FLANKEN-JET for glue spreading in Finger Jointing Plants to eliminate ridged glue rollers and perpetual glue circulation. FLANKEN-JET slotted nozzles: Target glue dosages, control glue spreading, and only take place when the workpiece has absolutely passed the System.AdvantagesOrder quantity can be adjusted and variegated in a relatively big area.Constant properties of the glue in a closed system create low adhesive wastage; PUR glue spreading can be controlled and only takes place when the workpieces have passed the system.Features Typically, a single worker operation. Infeed length: 5-7/8" - 27-1/2". Material thickness: 7/8" - 1-15/16". Material width: 1-9/16" - 5-7/8". Outfeed Press length: (min./Max.) 118"- 240" (3,000-6,000 mm). Saw motor: 22 kW (30 HP). Hogger & Scoring Motor:11.5 kW (15 HP).NOTE: Specificatins need to be confirmed

WEINIG Unimat Gold Feed-through MoulderSpecifications: --6-Head (B-R-L-T-T-B), working cap. 230 mm x 120 mm (9-1/16" x 4-3/4"). -- Head sequence: 1. Bottom 7.5 KW (10 HP), 2. right 7.5 KW (10 HP), 3. left 7.5 KW (10 HP), 4. top 11 KW (15 HP), 5. top 14.9 KW (20 HP) and 6. bottom 7.5 KW (10 HP) motor. Mechanical brakes on all motors. -- Spindles: dia. 40 mm (1-9/16") with cutterhead speed of 6,800 RPM. Mechanical digital readouts on all spindles. -- Feed system: Overhead feed wheels with pneumatic pressure. Motorized feed beam height adjustment. Inverter controlled feed speeds up to 30 m/Min (98 FPM), driven by 4 KW (5.5 HP) motor. Cardan drive, chainless, maintenance-free. (2) Powered table rollers in machine bed; (1) between top spindles & (1) at outfeed. Infeed straightening table 2,000 mm (6-1/2'), with adjustable fence. (1) side pressure roller mounted to infeed table. -- Complete with: Chromed tables. Central location of lubrication points. Manual Waxilit pump. Sound & safety enclosure. Automatic star delta starters. (2) emergency stop buttons. CE Compliance.This WEINIG Unimat Gold Moulder only has 186 Hours of use !Seller states that front bottom spindle is missing its digital readout.This machine will include Heads, Tooling, and the Dust Manifold.

Weinig Profimat 50 6-Head Moulder Manufacturer’s Specifications (to be confirmed) Profimat 50 details Spindle arrangements U-R-L-O-O-U Feed rate 5 - 30 m/min Working width (Standard) 20 - 230 mm Working width (Option) 20 - 260 mm Working height min./max. 10-160 mm Spindle size 40 mm Spindle speed (Standard) 7.000 UpM Spindle speed (Option) 8.000 UpM Showroom Machine…less than 50 hours

WEINIG UNIMAT 23 ATS, 6 HEAD MOULDER6-Head (B-R-L-T-T-B), working capacity 9-1/16" x 6" profiling. -- Head sequence: Bottom 10 HP, right & left by 15 HP, top 20 HP, top 15 HP and bottom 15 HP motor; Spindle dia. 40 mm with cutterhead speed of 6,000 RPM. -- WEINIG ATS (Automatic Tool Setting), Storage for up to (99) profiles; automatic positioning (radially) of left and top spindles (linked). -- Mechanical digital readouts on all other spindle adjustments for both axis, radial adjustment only on 1st bottom head. -- Motorized feed beam adjustment with independent adjustment of top heads, Receding chip breakers on left and top heads. -- Feed motor 7.5 HP, variable speed 18 - 118 FPM, overhead feed wheels with pneumatic pressure, (2) powered rollers in machine table. -- Large tool cutting circles, table plates adjustable to the cutting circle on vertical spindles with axial adjustment of 3-1/8" for multiple profiles. -- Infeed straightening table 2 M (6'6") with adjustable fence & adjustable outfeed table. Side pressure roller mounted to infeed table. -- Includes: Central lubrication, full sound/safety enclosure, manual bed lubrication pump.

WEINIG - UNIMAT 10005-Head (B-R-L-T-B), 9-1/16" x 4-3/4" cap. -- Head sequence: Bottom 10 HP; right 15 HP; left 15 HP; top 25 HP; 20 HP motor. -- WEINIG "Memory Re-Dial" System with: Storage of (100) separate profiles; electronic LED readouts for all spindles. -- Spindle dia. 1-13/16" with Cutterhead speeds: Spindle #1 at 6,000 RPM; spindles #2 - #5 at 7,000 RPM with high precision bearings & mechanical spindle brakes; adjustment of vertical spindles 3-1/8" axially. -- Electronic LED readouts for: Chip breaker & pressure elements for top spindles. -- Cutting circles: 8-7/8" On spindles #2 - #5; vertical spindles with adjustable table plates to cutting circles; hardened infeed bed plates before-and-after 1st bottom head. -- Motorized feed beam adjustment; variable feed speed from: 20 - 118 FPM; 10 HP inverter controlled Cardan feed drive, overhead feed wheels with pneumatic pressure. -- (1) Powered table roller in bed at outfeed. -- Infeed straightening table 2 M (6-1/2') with adjustable fence; adjustable table at outfeed. -- Equipped with: Central location of lubrication points; side pressure roller at infeed; manual Waxilit pump; (2) lights inside sound enclosure. -- Includes Set-Up Stand.NOTE: Machine is in good running condition, but electric brakes are not functional; does not affect running or performance.

WEINIG - HYDROMAT H 1000: Moulder (Feed Through)5-Head (B-R-L-T-B); working cap.: 9-1/16" x 6-5/16" capacity. -- WEINIG - H 1000. Spindle sequence: Bottom 15 HP; right 10 HP; left 10 HP; top 20 HP; bottom 15 HP motor. -- Spindles: Dia. of 1-13/16" with cutterhead; speeds of 1st head: 6,000 RPM; 2,3,4,5, at 8,000 RPMs; mechanical digital readouts on all spindle adjustments. Pneumatic pressure elements on left & top head chip-breakers. -- Feed drive: Variable feed speed from 20 - 120 FPM; all feed wheels driven and with pneumatic pressure. -- Central lubrication: Automatic table lubrication pump; machine prepped for lateral feeder; sound enclosure; safety hood with: (1) Inside lights. -- Options Include: Nielson # 130 Tool Grinder as pictured.

WEINIG POWERMAT 1000 MOULDER WITH HOPPER FEED6-Head (B-R-L-T-T-B) working cap.: 9-1/16" x 4-3/4".Head Sequence: Bottom 25 HP (6,000 RPM); 1-13/16" spindle; 9"; helical 9"; head; Right 20 HP (8,000 RPM) - 1-13/16" spindle; 3"; straight head with: Insert knives; Left 20 HP (8,000 RPM) - 1-13/16" spindle; 3"; straight head with: Insert knives; top 50 HP (8,000 RPM) HSK 9"; helical head; 2nd Top 50 HP (8,000 RPM) - HSK 9"; head with: Insert straight blades; Bottom 30 HP (8,000 RPM) - HSK 9"; head with: Insert straight blades. All motors with: Electronic brakes.WEINIG Touch- Screen "Power Com" with PowerCom Plus+ software system features: Profile drawing storage; profile dimensions; tool changes; linear footage counter; production optimization.Electronic LED readouts for all tool holder settings including: Chip breakers & pressure elements.Motorized tool positioning; radial & axial on tool holders: #2 - #6; motorized feed beam adjustment with: Independent adjustment of 2nd top head; top heads with: independent adjustment of chipbreaker & pressure element.Variable feed speed from: 20 - 118 FPM; 7-1/2 HP inverter controlled Cardan feed drive; overhead feed wheels with: Pneumatic pressure.Vertical tools with: Adjustable table plates to cutting circles; hardened infeed bed plates before & after 1st bottom head.Chromed tables & fences; (2) powered table rollers in bed; (1) between top spindles & (1) at outfeed.Infeed straightening table: 2 M (6-1/2').Z-tech Z-Drive; 110 Hopper Feeder.Equipped with: Central location of lubrication points; electromagnetic interlocking of safety hood; automatic table lubrication pump; (2) lights inside reinforced sound enclosure; phone modem.Includes: All Heads & Tooling shown in photos; dust manifold; Parts Manuals; Setup Manuals; receipts & eMails for extra parts ordered & repairs.

WEINIG Powermat 2400 Feed Through Top/Bottom Moulder; 4-Heads, (B-T-B-T), working capacity 230 x 160 mm (9-1/16" x 6-5/16"). -- (1) Weinig lateral infeed table section with top feed rollers Head Sequence: -- 1. Bottom 15 kW (20 HP), 2. top 18.5 kW (25 HP), 3. Bottomt 15 kW (20 HP), and 4. Top 18.5 kW (25 HP) motor. -- Spindles: Dia. 1 13/16" with cutter head speed of 6,000 RPM; electronic digital readouts on spindle adjustments in combination . Counterbearings. -- Motorized feed beam adjustment with independent adjustment of top head. -- Feed System: Feed speeds infinitely variable from 6-60 m/Min (20-200 FPM). Overhead feed wheels with pneumatic pressure. (1) powered grooved roller in machine table. Cardan drive system, chainless, maintenance-free. -- Machine Tables: Made of hardened steel with MARATHON Coating.Complete with: -- Cardan feed system with bottom powered table rollers -- Electronic digital displays on both top head chip breakers -- Electronic digital displays on both top pressure shoes -- Electronic digital displays for axial adjustments -- Powered adjustment of feed beam -- Sound and safety enclosure around all of the stations -- Front lift up access hood door with inspection window and safety interlock -- Interior work lights -- Freestanding operator control station, Color touch screen display with push button master controls -- Motor ampmeters for all heads -- Includes the machine operators manualsActual model is WEINIG Powermat 2400 Feed Through Moulder; 4-HeadsNote: Machine was installed in 2019Note: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.

Unimat Gold 6-Head Moulder Manufacturer's specs to be confirmed Unimat Gold 6-Head Moulder . 4-3/4" x 9-1/16" capacity. 1-1/2" diameter spindles Spindle Configuration: 10 HP Bottom, 10 HP Right, 10 HP Left, 15 HP Top, 20 HP top, 10 HP Bottom. . 6,800 RPM on all spindles . 5.5 HP inverter controlled variable speed feed 20 to 78 FPM with LED readout. 78" in-feed straightening bed. Mechanical digital readouts on all spindles. Digiset readouts on left and top spindles. Mechanical readouts on chip-breaker and pressure element of top spindle. Pneumatically pressurized feed rollers. (2) powered table rollers in machine bed (one between top spindles and one at out-feed). Motorized up/down adjustment of feed beam Chrome table plates. Central lubrication point. All spindles are equipped with mechanical brakes. Sound and safety enclosure. Machine Weight: 6,720 lbs. Dust Requirements: (6) each (6,000 CFM)

WEINIG Powermat 2400 Feed Through Moulder; 5-Heads, (B-R--L-B-T), working capacity 230 x 160 mm (9-1/16" x 6-5/16").Specifications: -- Max working width 230 mm (9 1/16") -- Min working width 20 mm (0.787") -- Max working thickness 160 mm (6.29") -- Min working thickness 8 mm (0.315") -- Feed speed 5 to 50 M/min.( 16' to 162'/min) -- (1) Weinig lateral conveyor table to the infeed side of the machine -- Infeed table length 2450 mm (96.4") -- Sick IVC -3D infeed material scanner system (System detects material width and thickness and automatically adjusts side heads for feeding random width material) -- Cardan feed system -- Adjustable upper pressure beam Head Sequence: -- 1st head: bottom horizontal spindle, 15 Kw,(20 HP), 6000 rpm spindle speed, 2-1/8" diameter spindle (8" wide aluminum carbide insert spiral planer head on the spindle) -- Short stock feed attachment between 1st and 2nd spindles -- 2nd head: right hand vertical spindle,7.5 Kw,(10 HP)8,000 rpm spindle speed, 1-13/16" diameter spindle, Hydrolock cutterhead on the spindle -- 3rd head: left hand vertical spindle, 11 Kw,(15 HP) , 8,000 rpm spindle speed, 1-13/16" diameter spindle -- 4th head: bottom horizontal spindle, 18.5 Kw, (25 HP, 6000 rpm spindle speed, 2-1/8" diameter spindle, Jointing attachment on 4th head(8" wide aluminum carbide insert spiral planer head on the spindle) -- 5th head: top horizontal spindle, 11 Kw, (15 HP), 6000 rpm spindle speed, Jointing attachment on 5th top head, Pneumatic top head chip breaker with electronic digital indicator, (8" wide aluminum carbide insert spiral planer head on the spindle) -- Servo spindle adjustments for spindles 2 through 5Also included: -- Electronic digital displays for axial adjustments -- Cardan feed system -- Sound and safety enclosure around all stations -- Lift up front doors with inspection windows and safety interlocks -- Freestanding operator control station -- Color touch screen display with push button master controls -- Siemens Simatic servo controls -- Includes the machine operators manuals and the tooling on the machineActual model is WEINIG Powermat 2400 Feed Through Moulder; 4-HeadsNote: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.

WEINIG PROFIMAT 23 Feed Through Moulder;(6)-Heads (B-R-L-T-T-B), working cap. 9-1/16" x 4-11/16".Specifications: -- Spindles 1-1/2" dia. with cutterhead speed of 6,000 RPM. -- Feed System & Features: variable feed speed from 20 - 78 FPM, powered by a 5.5 HP motor. -- Receding chip breaker at top spindles. Side pressure opposite right spindle; spring-loaded with (2) rollers; driven outfeed roller in bed. -- In-feed straightening table 2 M (78"), side pressure roller mounted to in-feed table. Note: Bare Machine: No dust manifold or tooling.

WEINIG PROFIMAT 22N Through Feed Moulder with (5) Heads, 8-5/8" x 4-11/16" capacity.Specifications : -- Head sequence: Bottom 10 HP, Right & Left by 10 HP, Top 15 HP, and Bottom 10 HP. -- Digital readouts on spindle adjustments. -- 1-1/2" Dia. spindles at 6,000 RPM. -- Motorized feed beam. -- Pneumatically pressurized feed rollers. -- Variable feed speed from 20 - 75 FPM. -- CARDAN (chainless) drive.Equipped with and Features: -- 6' Infeed straightening table and infeed fence with 10 mm parallel adjustment. -- Manual Waxilit pump and (1) set of cutterheads.Includes: -- Assortment of cutter heads, knives, and hold-downs (as shown in photo).

1999 Weinig Hydromat 23C 5 Head Moulder

Weinig Unimat 22E 6-Head Moulder OLDER MACHINE BUT STILL WORKING FINE WHEN REMOVED FROM SERVICE. Working dimensions: 4-3/4" x 8-5/8" Spindle configuration: B-R-L-R-T-B Motors: B-7.5 HP, R-7.5 HP, L-7.5 HP, R-7.5 (tilt), T-10 HP and B-10 HP. Amp meters on all spindle motors. Spindles: 1-1/2" dia. at 6,000 rpm. Mechanical dials for spindle positioning. Second right spindle tiltable. Feed: Cardan drive with 5.5 HP motor with feed speed; dial adjustable from 18-118 FPM. Tables: Infeed 6'0" with manual waxilit pump and siode pressure rollers Includes: Box of misc parts and cutterheads.

Weinig Unit 500 Moulder
