Dust Collection Systems For Sale

BELFAB - LW2-5Modular Dust Collector --Self-contained patented modular designed unit for interior use. The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and inlet. -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection; rated at 2,500 CFM with 7.2" static pressure w.g. -- Equipped with: (2) High Efficiency 1/8" thick needle felt cloth bags up and (2) plastic collection bags down (includes set of 24" long extended machine legs to maximize collection capacity), 70 sq/ft total cloth filter area. -- Complete with: Direct drive centrifugal fan assembly with 5 HP TEFC motor (inlet can be mounted top, bottom, left or right to facilitate ducting), non-sparking Heavy Duty cast aluminum impeller; 7" inlet dia. and pre-wired magnetic starter.

BELFAB LW3-10 Modular Dust Collection SystemSelf-contained patented modular designed unit for interior use; Specifications: -- 10 HP, 3,600 RPM and 4,600 CFM @ 7" static pressure, standard blower. -- 12" inlet -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- 126 Sq. ft. total cloth filter area. Non-sparking Heavy-Duty cast aluminum impeller.Equipped with: -- (3) High Efficiency 1/8" thick needle felt cloth bags up and (3) plastic collection bags down (includes set of 24" long extended machine legs to maximize collection capacity). -- Includes: Wired Magnetic starter for 208/230/460/600 V.NOTE: The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and inlet.

BELFAB LW4-15 Modular Dust Collector. Self-contained patented modular designed unit for interior use with direct drive 15 HP - 3,600 RPM motor, 5,000 CFM centrifugal fan assembly @ 7" static pressure, standard blower. -- 14" Inlet -- The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower, and inlet. -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- Equipped with: (4) High Efficiency 1/8" thick needle felt cloth bags up and (4) Drum Adapter Kits for drum collection, 140 sq. ft. total cloth filter area. Non-sparking Heavy-Duty cast aluminum impeller. -- Includes: Wired Magnetic starter for 208/230/460/600 V. -- Additional options available

BELFAB LW5-20 Modular Dust Collector. Self-contained patented modular designed unit for interior use with direct drive centrifugal fan assembly @ 7" static pressure. -- The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and 16" Inlet. -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- Equipped with: (5) High Efficiency 1/8" thick needle felt cloth bags, 23.5" dia. x 64" L with 175 sq. ft. total cloth filter area and (5) Filter sleeves for 55 US-gal. drums (Not included) for collection. -- Wired Magnetic starter. -- Non-sparking Heavy-Duty cast aluminum impeller. -- 20 HP, Standard Blower with 5,000 CFM at 3,600 RPM -- Additional options and voltages available.

BELFAB NBM4-20 TILT TRUCK Modular Dust CollectorPatented Modular Technology; 6,000 CFM with a static pressure of 10"; designed for current need that can easily be upgraded, as required. -- Exterior design; each "NBM" filter module with (1) service door & (1) explosion door per NFPA 68 safety regulations, this unit has (4) filter modules.Specifications: -- Each "NBM" filter module with: (18) 7" x 60" poly twill filter tubes. -- Direct drive centrifugal fan assembly with: HUMMER 20 HP @ 1,800 RPM High Efficiency TEFC blower motor, UL & CSA approved; AMCA Class-C anti-spark blower assembly with Heavy Duty steel impeller. -- 16" In-let dia., 660 sq. ft. filter surface area. Control Panel & Shaker mechanism includes: -- (2) Interlock magnetic starters, (1) for the blower motor and (1) for the automatic shaker mechanism. -- Adjustable timer, pilot lights all pre-wired. -- Includes: (4) Heavy Duty plastic tilt trucks on rollers for disposal of waste. -- Options available, but not included are: Spark detection/fire suppression system, Fire & abort damper, 2-Way valve, Explosion vent conduit; ...please ask for quote.

BELFAB NBM5-20 TILT TRUCK Modular Dust CollectorPatented Modular Technology; 6,000 CFM with a static pressure of 10"; designed for current need that can easily be upgraded, as required. -- Exterior design; each "NBM" filter module with (1) service door & (1) explosion door per NFPA 68 safety regulations, this unit has (5) filter modules.Specifications: -- Each "NBM" filter module with: (18) 7" x 60" poly twill filter tubes. -- Direct drive centrifugal fan assembly with: HUMMER 20 HP @ 1,800 RPM High Efficiency TEFC blower motor, UL & CSA approved; AMCA Class-C anti-spark blower assembly with Heavy Duty steel impeller. -- 16" In-let dia., 660 sq. ft. filter surface area. Control Panel & Shaker mechanism includes: -- (2) Interlock magnetic starters, (1) for the blower motor and (1) for the automatic shaker mechanism. -- Adjustable timer, pilot lights all pre-wired. -- Includes: (5) Heavy Duty plastic tilt trucks on rollers for disposal of waste. -- Options available, but not included are: Spark detection/fire suppression system, Fire & abort damper, 2-Way valve, Explosion vent conduit; ...please ask for quote.CALL FOR PRICING

BELFAB BA-1800C Industrial Air Cleaner (Ceiling Configuration)The BA-1800 industrial air cleaner from BELFAB is a multi-purpose air filtration unit for ambient air filtering. The BA-1800 can be used on a wide range of industrial applications capturing fine dust released into the air therefore improving the air quality in a manufacturing environment. Whether you require a medium or high efficiency system, the BELFAB BA-1800 can be configured to your operating needs for optimal dust control. Suitable for ceiling or ground installation the BA-1800 allows you to specify the best filter arrangement for your application. Features: -- Low installation and operation costs -- Flexible design to accommodate most applications -- Low maintenance and quiet operation -- Multiple mounting options and can be a ceiling or ground configurationIncludes: -- Adjustable louver to adjust the air pattern for better air circulation and comfort. -- Dual inlet 3/4 HP Blower motor with 1,800 CFM capacity -- MERV 8 Pleated filter with MERV 13 Pocket filter -- Sound level 76 dB. -- (2) Modules for high efficiencyApplications: -- Welding and smoke fumes -- Grinding dust -- Wood dust -- Composite dust and other industrial dustAvailable Options: HEPA Filter to allow for the highest standard of air filtration -- Magnehelic guage to clearly indicate the service interval for optimal efficiency

BELFAB LW3-10 Modular Dust Collection System w/ HUMMER BlowerSelf-contained patented modular designed unit for interior use; Specifications: -- 10 HP, 1,800 RPM and 4,600 CFM, HUMMER Blower, 12" inlet -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- 126 Sq. ft. total cloth filter area. Non-sparking Heavy-Duty cast aluminum impeller.Equipped with: -- (3) High Efficiency 1/8" thick needle felt cloth bags up and (3) plastic collection bags down (includes set of 24" long extended machine legs to maximize collection capacity). -- Includes: Wired Magnetic starter 460V or 230V, 3-Phase.NOTE: The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and inlet.

BELFAB LW4-10 Modular Dust Collector. 10 HP, 3,600 RPM, 4,600 CFM centrifugal fan assembly @ 7" static pressure, standard blower. Specifications: -- Self-contained patented modular designed unit for interior use with direct drive -- The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and 12" inlet. -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- Equipped with: (4) High Efficiency 1/8" thick needle felt cloth bags up and (4) plastic collection bags down, 140 sq. ft. total cloth filter area. Non-sparking Heavy-Duty cast aluminum impeller. -- Includes: Wired Magnetic starter for 208/230/460/600 V. -- Additional options available.

BELFAB NBM3-15 HUMMER SERIES Dust Collector (Modular)Patented Modular Technology; 5,000 CFM with a static pressure of 10"; designed for current need that can easily be upgraded, as required. -- Interior and exterior design; each "NBM" filter module with (1) service door & (1) explosion door per NFPA safety regulations, this unit has (3) filter modules. -- Each "NBM" filter module with: (18) 7" x 60" poly twill filter tubes. -- Direct drive centrifugal fan assembly with: 15 HP @ 1,800 RPM High Efficiency "Hummer" TEFC motor, UL & CSA approved; AMCA Class-C anti-spark blower assembly with Heavy Duty steel impeller. -- 14" Inlet dia. and 17" outlet dia., 495 sq/ft filter surface area. -- Control Panel & Shaker mechanism includes: (2) Interlock magnetic starters, (1) for the blower motor and (1) for the automatic shaker mechanism, all pre-wired. -- Unit comes with: (3) Heavy Duty plastic tilt trucks, rollers for disposal of waste & adaptors. -- Options available, but not included are: Spark detection/fire suppression system, Fire & abort damper, 2-Way valve, Explosion vent conduit; ...please ask for quote.

BELFAB NBM7-30 TILT-TRUCK DUST COLLECTOR with Patented Modular Technology: Patented Modular Technology allows it to be purchased for current needs and easily upgraded as required; designed exterior use. Specification: -- Each "NBM" filter module is fitted with: (1) Service door & (2) explosion doors per NFPA safety regulations -- Rated Capacity: Rated @ 9,000 CFM with 9.5" static pressure -- Equipped with: Direct drive centrifugal fan assembly with 30 HP Hummer blower motor, anti-spark cast aluminum impeller, 20" inlet diameter.Unit includes: -- (1) Electrical Control Panel for (2) motors. (1) Soft Start starter for the main blower, (1) for the Auto Shaker -- (7) NBM filter modules, each with (18) 7" x 60" poly-twill cloth filter tubes, 990 sq./ft. total cloth. -- (60) Cu./ft. waste storage cap. via (7) Heavy Duty plastic Tilt-Trucks w/rollers; each with air-tight quick coupling plate.Options:Security System for Air Return (Included); -- (1) 20" Explosion Back Draft Damper, VIGIFLAP with dust sensor system integrated & control panel - ATEX CERTIFIED, -- (1) 24" Fire Damper with status signal. -- (1) 24" Derivation Tee. -- (1) 24" Diameter Abort Damper. -- (1) Single Zone Spark Detector, 38" max, (2) detectors, (1) sprinkler.

BELFAB NBM6-30 CHIP & DUST TRANSFER DUST COLLECTOR Patented Modular Technology and heavy-duty construction for exterior use. Heavy Duty construction designed for interior or exterior use.Specifications: -- Each "NBM" filter module is fitted with; (1) service door & (1) explosion door per NFPA safety regulations, and integrated compact hopper. -- Rated Capacity: Rated @ 9,000 CFM @ 9.5" static pressure, 7,600 CFM @ 10.4 static pressure. -- Equipped with: Direct drive centrifugal fan assembly with 30 HP "Hummer" blower motor, anti-spark cast aluminum impeller, 20" inlet diameter. Unit Includes: -- (6) "NBM" filter modules, each with (18) 7" x 60" Poly Twill cloth filter tubes; 990 sq. ft. total cloth area (165 sq. ft. per module) w/Continuous Dust Disposal Capacity. -- Pneumatic Chip / Dust Transfer System with (1) 7.5 HP and (1) 5 HP material handling blowers, continuously discharges chips and dust for re-cycling or disposal. -- (1) Electrical Control Panel w/ Shaker Mechanism to include; (4) Interlock Starters; (1) Soft start for the main blower, (2) for the Pneumatic Dust Transfer System and (1) for the shaker mechanism.Security System for Air Return: -- (1) 20" Explosion Back Draft Damper, (1) 24" Fire Damper with status signal, (1) 24" Derivation Tee, (1) 24" Abort Damper and (1) Single Zone Spark Detector. (Optional; pricing upon request)CALL FOR PRICING

BELFAB LW3-7.5 Modular Dust Collection SystemSelf-contained patented modular designed unit for interior use with 7.5 HP, 3,600 RPM and 3,500 CFM @ 7" static pressure, standard blower. -- The "LW" series can be specifically customized for current and future Dust Collection requirements as required by adding Filter Modules, a larger blower and inlet. -- Heavy Duty sheet metal constructed plenum between the top bags and bottom dust collection. -- Equipped with: (3) High Efficiency 1/8" thick needle felt cloth bags up and (3) plastic collection bags down, 126 sq. ft. total cloth filter area. Non-sparking Heavy-Duty cast aluminum impeller. -- Includes: Wired Magnetic starter for 208/230/460/600 V -- Additional options available.

CAM-WOOD DC-8075 Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 5,800 CFM.Includes: -- Heavy Duty 7.5 HP motor pre-wired at 220 V. -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 db. keeps the work area quiet. -- Optional connection for using barrels.

CAM-WOOD DC-8100X Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 7400 CFM.Includes: -- Heavy Duty 10 HP motor pre-wired at 230 V. -- 10" Inlet -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 Db keeps the work area quiet. -- Optional connection for using collection barrels.Note: 230 or 460 Volt, 60 Cy, 3-Ph please advise.

CAM-WOOD DC535 DUST COLLECTOR 2900 CFM5 HP Motor and 14" Dia. Radial-fin type steel impeller to get the best efficiency usage.Specifications: -- Two top filters and two collection bags. -- Heavy-duty motor for powerful operation. -- Larger size impeller and extra long top air exhaust bags enabling to collect sawdust and wood chips more easily. -- Standard steel spring clamps to secure the bags with the body without leaking dust. -- Low sound levels keep the working area quiet. -- Replacement bags or 5 micron bags for fine dust are available. Optional connect bags for barrels are available.

CAM-WOOD DC-07 STA Cyclone Dust Collector w/ After-filtersNew designed two-stage cyclones. As the “dirty"; air stream enters the collector, the heavy particles are separated by cyclonic action and fall to the bottom storage bag. The remaining air stream with fine dust goes through the impeller, it can increase dramatically the life of the impeller & motor preventing damage from large material.Features: -- 7.5 HP blower with 4,200 CFM. -- Inlet Diameter 12" x 4" x 5. -- Heavy sheet metal frame and base. -- Extra-large radial-fin type steel impeller for high-efficiency airflow. -- Heavy duty totally enclosed industrial motor for maximum air suction and extended service life. -- Quick-release clamps are used to tighten the bags; this helps to reduce downtime when doing maintenance. -- Low sound levels to keep the working area quiet. -- Includes: (2) Collection drums

CAM-WOOD DC-102-3 Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 460 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.

CAM-WOOD DC-10 STA Cyclone Dust Collector w/ After-filtersNew designed two-stage cyclones. As the “dirty"; air stream enters the collector, the heavy particles are separated by cyclonic action and fall to the bottom storage bag. Then the remaining air stream with fine dust goes through the impeller, it can increase dramatically the life of the impeller & motor preventing damage from large material.Features: -- 10 HP blower with 5,000 CFM. -- Inlet Diameter 13" x 4" x 5. -- Heavy sheet metal frame and base. -- Extra-large radial-fin type steel impeller for high-efficiency airflow. -- Heavy duty totally enclosed industrial motor for maximum air suction and extended service life. -- Quick-release clamps are used to tighten the bags; this helps to reduce downtime when doing maintenance. -- Low sound levels to keep the working area quiet. -- Includes: (2) Collection drums

CAM-WOOD DC-102 Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 230 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.
