Hogs and Wood Grinders For Sale

WEIMA - TH 614 HD : Metal Briquette Press w/WEIMA 4-Shaft Shredder & ConveyorProduces 60 mm dia. x 4" (100 mm) long compacted logs; approx. 1 cbm square vertical hopper. Specifications -- 18 HP Motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 approx. -- Includes -- Metal package for TH 614 HD ; catch pan with level switch; 1 x 45°; 1 x 90° & 1 x straight ) . Shredder 4-Shaft Shredder with electrical cabinet & controls. Specifications: -- Dual drive motors: (2) 11 kW (15 HP) Drive motors; hopper opening measures 39.4" x 55.1" (1,000 x 1,400 mm); cutting chamber opening of 18.2" x 27.6" (462 x 700 mm); rotor length of 18.2" (462 mm); rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. JORGENSEN - Transfer Conveyor18" Wide steel belt; collection hopper for under "ZMK 30" Shredder; coolant pump and float switch for fluid transfer.

WEIMA WLK-13 Shredder with Econogrind ES 560/1000 Granulator Production LineFeatures & Specs: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight-sided); -- 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length.Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full.Features: -- Heavy-duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL-approved components. -- Recommended for plastic, paper or wood applications. Econogrind ES 560/1000 Granulator. -- Includes conveyor, conveyor magnet to pull any metal out, finish grind granulator, and Mettler Toledo weigh hopper, and dust collector. -- Wash system that can be included in the sale -- Line is still hooked to power, Lots of extra parts are included.

WEIMA ZM-40 Quad Shaft 4-Shaft ShredderEquipped with: -- Dual drive motors - (2) 30 HP Drive motors. -- Hopper opening measures 51" x 55.1" (1,300 x 1,400 mm); cutting chamber opening of 30" x 27.6" (762 x 700 mm). -- Rotor length of 30" (762 mm); Rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. -- Complete with: -- Control Panel with soft start and 16' cable bundle. -- Note: "Quad Shaft" Shredders, unlike Dual Shaft Shredders, allow shredded material to be circulated through the cutting chamber until it is small enough to pass through the sizing screen. -- Machine weight: 5,500 Lbs.

WEIMA TIGER 600 Horizontal Slow Speed Grinder w/Vibratory ConveyorSpecifications: -- 6" High x 23.6" wide max. infeed opening, 50-60 HP rotor motor, 14" dia. rotor grinds at 620 RPM (fixed rotor speed depending on application). -- Equipped with: -- Patented "V-ROTOR" design utilizes a v-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Features: -- (32) Replaceable back bolt-on cutter knives (welded knife holders standard, bolt-ons per customer request), recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Infeed roller with replaceable wear strips for ease of maintenance, feed speed is controlled by monitoring the amp draw of the rotor, preventing "braking" or excessive pressure on the rotor, the vibratory infeed conveyor (12') is tied into the feed roll to eliminate binding. -- 9.85" (250 mm) Dia. dust collection outlet (3,000 CFM required). -- Includes: -- Heavy Duty low-profile frame (15-3/4" passline height); integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge); up to 16' vibratory infeed conveyor available.

WEIMA WLK 15 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 59" x 59" rear-flared hopper opening; 3 cu. yds. cap.; 368 mm (14.5") rotor dia.; 120 HP motor; hydraulic ram with 4-sided serrated ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (82) Welded knives, (4) broaching cutters & (4) counter-knives, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- Drop out discharge, hydraulically actuated lift up door for easy purge cleaning; extended screen basket; cut-out for conveyor (not included); false wall; 3/8" - 4" screen available. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

WEIMA WLK 13 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight sided), 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length; 60 HP motor and hydraulic ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Features: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

WEIMA WLK 4 Vertical Hopper-Fed, Low-Noise GrinderSpecifications: -- 31-1/2" x 39" Hopper opening at the top, 1.1 cu. yds. cap. Features: -- 30 HP rotor motor, Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. Equipped with: -- (14) Replaceable back bolt-on cutter knives, welded knife holders standard, recessed concave cutters with low clearance over the 10" dia. rotor extends cutter life, protects the bolts, and reduces machine wear. -- 6" Dia. dust collection outlet (1,200 CFM required); 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content); -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, the lateral force on the ram is minimized by a unique "U-Joint" mounting system. Includes: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for an additional charge). Options: -- Flared hopper, log Spacer, 2nd row of knives, material discharge auger; programmable logic controls;

WEIMA - WLB 400, ...Horizontal Low Speed Grinder Equipped with: -- 25 HP Rotor motor; rotor with (18) 4-way indexable, replaceable cutter knives. Features: -- Top infeed roller; 15-1/2" x 2-1/2" feed opening; Heavy-Duty Industrial Grade construction with stress relieved shell and frame; Heavy-Duty outboard roller bearings; separate electrical control panel. Complete with: -- 8" Dia. collection outlet; 3/4" screen.

WEIMA Horizontal Beaver 300 Slow Speed, High Torque Waste Grinder w/Vibratory Conveyor. 25 HP (18.5 kW), 10" rotor diameter, 11.8" (300 mm) rotor length, (14) 40 x 40 mm indexable, concave cutters; 11.8" x 4" infeed opening. Equipped with: -- WRRL 300 12' Vibratory Conveyor (550 Lbs). -- The "Horizontal Beaver" receives the material from a vibratory conveyor system; from the conveyor, a feed roller system pinches and feeds the material into the rotor. -- Features: Patented "V-Rotor" design utilizes a V-groove rotor closely matched to grooves in the counter-knife; the V-Rotor produces uniform discharged material that is free of splinters and dedicates more horsepower to grinding. -- Includes integrated "plug-and-play" electrical control system with UL approved components; -- Extraction requirements: 1,900 CFM (28 MPS), 8" (200 mm) diameter for dust collection. Total Approx. weight of 2,430 Lbs.

WEIMA WLK 8 Vertical Hopper-fed Low-noise GrinderSpecifications: -- 39" x 49" Hopper opening at the top, 1.75 cu. yds. cap.; (3) sides straight with curved back wall. -- 35 HP (27 kW) rotor motor, 10" dia. patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Equipped with: --39.4" Long rotor operating at 80 - 120 RPM; with (54) replaceable back bolt-on (4 x indexable) concave shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- WEIMA'S proprietary gearbox designed specifically for slow speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Options: -- Flared hopper, material discharge auger; programmable logic controls and ram comb.

WEIMA Woodchuck Low Noise Slow Speed Vertical Wood Waste Grinder:A low cost/investment solution for Woodwaste disposal - feasible for a small shop.Specifications: -- 25 HP Main Drive motor; 24" x 41" hopper opening, 0.74 cu. yds cap; 10" dia. rotor, 100 RPM. -- Equipped with: -- (28) 40 mm x 40 mm Concave, indexable cutters; 6" discharge outlet. -- Features: -- Patented V-ROTOR design utilizes tooling closely matched to grooves in the counter-knife. -- V-ROTOR Produces uniform discharged material, free of splinters and dedicates more horsepower to grinding. -- Includes: -- 5/8" or 3/4" screen (TBD); Integrated "plug-and-play" electrical control system with UL approved components; 1-Year warranty, operations and parts manuals. .

WEIMA WLK-6 Vertical Hopper-Fed Low-Noise Waste GrinderEquipped with: -- 31-1/2" x 49" hopper opening at the top, 1.2 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 30 HP rotor motor, 10" dia. Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 31-1/2" Long rotor operates at 80 - 120 RPM; equipped with (42) replaceable back bolt-on (4 x indexable) concave shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- WEIMA's proprietary gearbox designed specifically for slow speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Material output from 1,000 - 1,250 Lbs/Hr (output is an average and can be influenced by density, material size, screen size, feeding form, and other); 1" standard screen hole size. -- Includes: -- A/B Programmable Logic Controller. -- Options: -- Flared hopper, material discharge auger.

WEIMA WLK 10 Vertical Hopper-Fed Low-Noise Grinder Equipped with: -- 39.4" x 47.2" Hopper opening at the top, 1.7 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 60 HP rotor motor, 14-1/2" dia. The patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 39.4" Long rotor operates at 60 - 120 RPM; equipped with (52) replaceable back bolt-on (4 x indexable) concave-shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. Features: -- WEIMA'S proprietary gearbox is designed specifically for slow-speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL-approved components (system UL certification available upon request for an additional charge). -- Ground material output depends on screen hole size and material from 1,200-2,500 Lbs/Hr.; 3/4" holes are supplied standard screen hole size. Options: -- Flared hopper, material discharge auger; programmable logic controls, and ram comb.

WEIMA TIGER 400 Horizontal Slow Speed Single Shaft Wood Grinder w/Vibratory ConveyorSpecifications: -- 6" High (160 mm) x 15-11/16" (400 mm) wide max. infeed opening, 50 HP rotor motor, 14" dia. rotor grinds at 620 RPM (fixed rotor speed depending on application). -- Equipped with: -- Patented "V-ROTOR" design utilizes a v-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Features: -- (22) Replaceable back bolt-on cutter knives (welded knife holders standard, bolt-ons per customer request), recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Infeed roller with replaceable wear strips for ease of maintenance, feed speed is controlled by monitoring the amp draw of the rotor, preventing "braking" or excessive pressure on the rotor, the vibratory infeed conveyor (12'), is also tied into the feed roll to eliminate binding. -- 9.85" (250 mm) Dia. dust collection outlet (3,000 CFM required). -- Includes: -- Heavy Duty low-profile frame (15-3/4" passline height); integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge); up to 16' vibratory infeed conveyor available.

2020 Weima WLH 600 Grinder 50 HP motor Vibrating Infeed

WEIMA C 150 Briquette PressSpecifications & Features: -- Produces 2" (50 mm) dia. Briquettes; -- Hopper opening of 41" x 41" (1,040 x 1,040 mm); hopper volume 1.43 cu/yd (1.1 cbm). Equipped with: -- 9 HP Hydraulic motor; 0.75 HP auger motor; hydraulic oil volume of 26.4 gallons (100 liters). -- Vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio at 2,600 PSI; hourly output up to 80 - 120 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors").Features: -- Briquette length control, chrome plated clamp, oil level switch, control panel side-mounted to hopper, and overheating protection for hydraulic oil. Solid German engineering. - Freight, start-up, discharge pipes, etc. not included.

WEIMA TH 1500 M Briquette Press (Square Brick) -- Specifications: Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" (1,400 x 1,400 mm); hopper volume of 2.46 cu/yd (1.88 cbm). -- Equipped with: 40 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 264 gallons (1,000 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 800 - 900 Lbs. -- Features: Conical shaped agitator with curved hopper corners, "Bridge Breaker" mounted on agitator; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: Touch-Screen control panel on swivel mount; discharge ramp for briquette extraction, chrome plated clamp, and an oil level switch. -- Solid German engineering.

WEIMA TH 814 Briquetter A volume reduction of 90% is possible through the briquetting of wood, paper, aluminum and biomass or synthetics, providing significant savings in labor, disposal and storage costs.Material is hand fed or by dust system into the hopper, where an agitator pulls it into the auger and pressing chamber. Specifications: -- Produces 80 mm (approx. 3.1") dia. compacted logs; approx. 2.4 cu. yd. (55.1 x 55.1 x 37") square vertical hopper, 18 HP motor. -- Hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio; approx. hourly output between 300 - 400 Lbs/Hr.Features: -- Auto on/off integrated into feeding hopper; automatic briquette length adjustment; conical-shaped agitator; dust connection at pressing unit.Options: -- Hydraulic cooling for 24-hour operation, heating for cold weather start-ups; plastic tubing discharge into Gaylord or carousel bagging system. .

WEIMA TH 714 Briquette Press (Cylindrical). -- Produces 2-3/4" (70 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: Approx. 1.4 m³ vertical hopper, 18 HP (13.5 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 240 - 280 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: Centralized control panel for easy operation, MITSUBISHI Logic control & solid German engineering. -- Complete with: Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional:: Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA TH 514 Briquette Press (Cylindrical). Produces 2" (50 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: -- Approx. 1.4 m³ vertical hopper, 12 HP (9 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 80 - 120 Lbs/Hr. ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: -- Centralized control panel for easy operation, PLC Logic control & solid German engineering. -- Complete with: -- Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional: -- Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.
