Gang Saws For Sale

Brand new Double Arbor Gang Saw. In stock price will not be available after this machine sells. This one is 8". This machine is a durable heavy duty machine with 50 plus years experience behind it. MCC and operator console included. This is a limited offer as this machine comes with one complete set of saws. comes with a set of spare ware parts. Parts are stocked in the US by Kittrell Sawmill Brokers FOB Columbia, TN Will load on your truck. Call Jackie 931-698-3342. Retail price $225,000 save $26,150 Quality and performance with every cut Simple handling, operation and maintenance. Call Kittrell 931-797-6284 Try before you Buy

Unscrambler and Infeed Deck | Single Chop Saw | Feed Conveyors | Model E 2000S Pendu JR Gang Saw | 480V 3 PH

This mighty bull gang edger is ready for work. Cutting 6.25" X 27.5" cuts down to 1/2" boards. This 100 HP single arbor machine has diamond circular saws, Single saw arbor is fixed. Hydraulic feed through with hydraulic top press roll. Infeed table with hydraulic feed roller and fence for accuracy in sawing. This machine is available in a double arbor machine which will cut a little faster than the single. This saw has (2) 50 hp independent arbor motors for the double arbor machine. See it at IWF in August 2024 or order yours today. 931-698-3342

AUTO-V-GROOVE AVG-48 MFT UNIVERSAL V-GROOVER: -- Specifications:(1) Head automatic cross & linear V-Groover, 48" max. material width on cross-groove,Unlimited length for linear grooving, 1-1/4" max. material thickness. -- Features:(1) 10 HP - 3,600 RPM Motor, 30 mm dia. belt driven precision cutter arbor, 3-1/4" max. cutter width.2 HP Hydraulic feed motor for infinitely variable crosscut feed speed from 0 - 50 FPM & 0 - 60 FPM for linear feeding.Heavy-duty double belt feeder assembly for linear grooving. -- Includes: Adjustable pneumatic material hold-down bar.(1) 84" x 24" Main table, (1) 20" x 58" auxiliary table, (1) large 96" long floating table on rails. -- Complete with: Automatic tape applicator (12" max. dia. tape roll), manual quick crank tape applicator positioning system. -- Options Include: An assortment of V-Groove cutters as pictured.Actual Model is AUTO-V-GROOVE AVG-48-M/FT.

Complete Brewer Pallet Line consisting of: Brewer infeed cant deck; Brewer operators cab with controls; electric motor panel with starters; Brewer   bar-type unscrambler and infeed belt conveyor to Brewer cut-off saw with setworks; Brewer out feed belt conveyor to gang saw; Brewer 24" wide gang with motors and sizer; Cornell stacker and West Plains notcher and conveyors to connect stacker and notcher;  and waste conveyor.  Removed from service and ready to load.   Price:  $155,000.00 loaded on your truck.   NOTE: Year-end taxes or machinery investment-- Your Choice.

Brewer BR-8112 S | 460 V | 25hp Cross Cut | 100hp Bottom Arbor | 60hp Top Arbor | 30 hp Plainer Motor.

Cornell single arbor gang saw, 4" thick x 24" wide capacity, would work well for stringers, comes with extra spacers/ blades, working condition

Cornell double arbor gang saw, 6" thick x 24" wide capacity, 2- 100 hp electric motors for arbors, working condition

Cosmec CM100 12" Dip Chain Gang Saw Parts Machine Only

LEADERMAC MODEL LMC-1600M - 63"; GANG RIPSAW Specifications: -- Width capacity: 0.6"; to 63"; -- Thickness capacity: 0.4"; to 2"; (thicker material processing is available as an option) -- Up & down motor: 1 HP -- Feed motor: 15 HP HD VFD -- Feed speed, infinitely variable: 20 - 200 FPM. -- Feed direction from Right to Left is standard -- Saw Spindle HP: 150 HP, Wye-Delta low amperage soft start (larger motors are available as an option) -- Saw Spindle diameter: 3.15"; (80 mm) double keyed -- Saw blade Diameter 12"; diameter for 2"; thick material -- Spindle RPM: Std. 4,000 RPM. 5,000 RPM optional with 10"; Blade capacity Standard Features & Equipment: -- Extra Heavy Main Frame – Stress Relieved -- Sound & Safety enclosure included – with internal strobe-free lighting -- High Precision Spindle - Double Keyed assembly with Hydro-Loc outboard bearing assembly on outboard side -- Entire Spindle assembly slides out on support for Quick, Easy and Precision Saw Setting & Changing -- Hardened & Hard Chromed Infeed Table -- (7) Sets of Top Power Driven Rolls – full width -- (5) Sets Bottom Power Driven Rolls – full width -- Infinitely Variable Pneumatic Pressure to Top Feed Rolls -- Top & Bottom Feed Rolls are all Driven by Cardan Shaft Drive with HD Gearboxes interconnected -- 1st Top & 1st Bottom Powered Roll Combination and then 2 Rows Anti Kick Back Finger Units – Full Width and then to the rest of the Powered Top & Bottom Rolls giving you the best Feeding Capability with good safety Features -- HD VFD – 15 HP Feed System – Infinitely Variable -- Main motor has Wye-Delta low amperage soft start -- Electrics are 460 volts 3/60 with all controls to CSA/UL Specifications -- Documentation: Maintenance manual, Operation manual, Electrical diagrams, Parts list & Tool Box (Electronic Version on Request) -- (8 - 4) Top & (4) Bottom 6"; Dust hoods included -- Saws, Dado Heads &/or cutter head(s) and spacers are optional at extra cost.Price Includes: -- Pedestal for all controls, on a 11 meter long cable to get around the front right (infeed side) of the ripsaw -- Moveable Main Electrical Panel with 10 ft. (3m) of main cable -- 150HP Saw Arbor Spindle motor in lieu of std. 75HP -- Pneumatic hold over on infeed table to hold wide, and allow holding over of narrow boards up to the fence -- Increased Feed Speed to 200FPM (60mpm) includes Heavier gearboxes and drive components) with 15 HP VFD -- Amp Meter for the Arbor Motor -- Faster removal speed for the arbor assembly (50% faster than standard machine) -- 1 Spare complete New Design Spindle Assembly including Drive Side Bearing Assembly with support slide and roller transfer support assembly per photo for preloaded saws Extended length per discussion.(1 only unit included in price of machine, this is for a 2nd cart and spindle assembly- total of (2) will come with the machine – additional units available, see below) -- Schneider / Telemecanique VFD drive uni

LEADERMAC MODEL LMC-1300M – 51"; GANG RIPSAW -- Specifications: -- Width capacity: 0.6"; to 51"; -- Thickness capacity: 0.4"; to 4"; -- Up & Down motor: 1 HP -- Feed motor: 7-1/2 HP with VFD -- Saw Spindle HP: 75 HP, larger motors are optional - see below -- Saw Spindle diameter: 3.15"; (80mm) double keyed -- Spindle RPM: Std. 4,000 RPM. 5,000 RPM optional with 10"; Blade capacity -- Saw blade Diameter 12"; diameter for 4"; thick material -- Feed speed, Infinitely variable: 20 To 50 FPM. 100 or 200 FPM optional -- Standard Features & Equipment: -- Extra Heavy Main Frame – Stress Relieved -- Sound & Safety enclosure included – with internal strobe-free lighting -- High Precision Spindle - Double Keyed assembly with Hydro-Loc outboard bearing assembly on outboard side -- Entire Spindle assembly slides out on support for Quick, Easy and Precision Saw Setting & Changing -- Hardened & Hard Chromed Infeed Table -- (7) Sets of Top Power Driven Rolls – full width -- (5) Sets Bottom Power Driven Rolls – full width -- Infinitely Variable Pneumatic Pressure to Top Feed Rolls -- Top & Bottom Feed Rolls are all Driven by Cardan Shaft Drive with HD Gearboxes interconnected -- 1st Top & 1st Bottom Powered Roll Combination and then 2 Rows Anti Kick Back Finger Units – Full Width and then to the rest of the Powered Top & Bottom Rolls giving you the best Feeding Capability with good safety Features -- HD VFD – 7.5 HP Feed System – Infinitely Variable -- Main motor has Wye-Delta low amperage soft start -- Electrics are 230, 450 or 575 volts 3/60 with all controls to CSA/UL Specifications -- Documentation: Maintenance manual, Operation manual, Electrical diagrams, Parts list & Tool Box (Electronic Version on Request) -- (4) Top & (4) Bottom 6"; Dust hoods included -- Saws, Dado Heads &/or cutterhead(s) and spacers optional extra -- Price Includes: -- Hanging Control Panel – in lieu of Control standard setup as shown in machine photo -- Moveable Main Electrical Panel with 10 ft. of main cable -- Amp Meter for the Arbor Motor -- 4"; thickness Capacity – using 12"; or 14"; diameter blades Available at extra cost: -- Adjustment of the Rear guide with digital readout from the front of the machine (only desirable if Side Heads are supplied) -- Additional Side Pressure Roller System on the Infeed Table of the Machine -- 100 HP saw spindle motor -- 125 HP saw spindle motor -- 150 HP saw spindle motor -- Scoring Saw Arbor ahead of main saws if desired -- Saw Spacers for Main Arbor quick Setup -- Mechanical Quick Lock Saw collars if desired for independent saw setting -- Spare Spindle Assembly, complete, including Drive Side Bearing Assembly with support slide and roller transfer support assembly per photo for preloaded saws, add $ 13,045 -- Questions? Call Jeff @ Ext 349!

LHI 72" RFPR Wide Arbor Roll Feed Gang Panel Ripper with Custom 5' x 16' Automated Infeed -- Specifications: -- 30 HP Arbor Motor; 1/8" min. to 1-1/4" max. material thickness and 72" cutting width. -- 10" Dia. blade design cuts thru max. 2" thickness; -- 3-15/16" dia. arbor with 72" of usable width cutting capacity, min. panel length 30". -- 1-15/16" FAFNIR arbor bearings; with (8) steel feed rollers on 6" centers; fixed feed speed of 80 FPM -- 47-1/4" working height -- (1) Arbor Cart is included -- (2) 4" Dia. dust collection ports on top and (1) 8" dust collection port on bottom. Recommended 1,500 CFM Includes the Following Optional Items: -- 5-Strand powered Chain Deck; 12' long; arranged to feed 5' x 16' packages onto the Scissors Lift. Complete with controls for forward, reverse, and jog. -- 5-Sections of Gravity Rollers on Scissors Lift Deck -- 8,000 lbs. Infeed Tandem Scissors Lift with 5' x 17' Deck and 2-HP, 3-Phase Motor. Lift includes a backstop for initial alignment at the Rake Feeder -- (8) Polyurethane Rollers on 6" centers -- Variable Feed Speeds from 10 to 80 FPM. -- Rake Feeder for 16' long panels -- Auto-cycle for Rake Feeder. -- 6' Line Up Conveyor with Fence and Powered Pinch Roll Included Tooling: -- (36) Standard Saw Collars for Ripping -- (72) Standard 10" Sawblades for Ripping (Includes a spare set) -- (37) Standard Throat Plates for RippingQuick Setup Kit Included, Contains the Following -- Belt guide -- Belt Tensioner -- Hydraulic Arbor LockAdditional Arbor Setup Included. Contains the Following: -- Arbor Cart -- Cart -- Blade Box -- Arbor -- Bearings -- Sheave -- Throat Plate Rack -- (6) Throat Plates PRICE REFLECTS FACTORY'S 7% MATERIALS SURCHARGE ON $156,995, OR $10,990

LHI MODEL RFPR AUTOMATED PANEL RIP SYSTEM --Arranged for up to 5/8"; Thick x 52"; Wide x 18’ Long Panels as follows: AUTOIMATIC INFEED SYSTEM, INCLUDES: --Rake Feeder for up to 18’ Long Sheets --Automated Feed Cycle Controls --Turnkey Controls, Plug it in and Run --1 HP, 3-Phase, 460-Volt Operation 6’ ALIGNMENT CONVEYOR, INCLUDES: --Gravity Roller Frame with 60"; Wide Rollers --Alignment Fence --Spring Loaded “Feather"; to Keep Sheets Tight to the Alignment Fence --Powered Feed Wheel to Push Sheets into the Ripsaw --2 HP, 3-Phase, 460-Volt Operation TANDEM INFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Raised and Lowered by Signals from the Sheet Feeder --2 HP, 3-Phase, 460-Volt Operation TANDEM OUTFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Long Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Lowers by Signals from Auto-Down Index Control Unit --2 HP, 3-Phase, 460-Volt Operation --OPTIONAL: 4-Sided “Accordion Skirts"; for each Tandem Lift Table, add $2.650 per lift RFPR" ROLL FEED PANEL GANG RIP SAW --50 HP Main Arbor Motor --1/8" Min. To 1-1/4" Max. Material Thickness x 72" Cutting Width --10" Dia Blade Design; 3-15/16" Dia. Arbor with 72" of Usable Width Cutting Capacity --Min. Panel Length 30". --1-15/16" FAFNIR Arbor Bearings --(8) Polyurethane Feed Rollers on 6" Centers --Variable Feed Speeds Via VFD --(1) Quick Blade Change-Out Kit --(1) Additional Arbor Cart --(2) 4" Dia. Dust Collection Ports on Top and (1) 8" Dust Collection Port on Bottom. Total Recommended 1,500 CFM. TOOLING: --(20) Saw Collars, Mount Directly to the Arbor with a Set Screw --(20) Saw Blades Configured for Clean Cuts on Your Panels

LHI RFPR-72/16 "HEAVY DUTY" MULTI-BLADE PANEL RIP SAW (W/LOADING/UNLOADING): -- Specifications (1) 30 HP Main arbor motor for 1" min. - 5" max. material thickness;16" Dia max. blade capacity with 1.25" minimum spacing between the blades;Minimum panel length 30" with 72" of usable width cutting capacity.3-15/16" Dia. arbor with 1-15/16" precision arbor bearings;Positive powered steel contact feed rollers with (8) adjustable Polyurethane drive rollers;Variable feed speed to max 80 FPM.Available Options Include:Single point height adjustment for materials from 1" to 5" thickness using customer supplied 16" dia blades(note: Ripping widths can never be less than one-half the material thickness).(1) "Quick Change" arbor cart trolley and blade box for QC set ups.(12) Saw collars to attach the customer supplied 16" dia. diamond blades to the arbors(1) In-feed Scissors Lift with auto cycle controls(1) In-feed 6' conveyor with alignment fence and powered assist feed(1) Auto sheet feeder with auto cycle controls(1) Out-feed Scissors Lift with 4 x 8 roller top.Installation technical assistance for $125/Hr plus travel time and expenses, payable upon competition of services. NOTE:Quote is valid for 30-days;Quoted price is FOB, Factory;Customer is responsible for off-rigging cost at their facility;Customer is responsible for spotting the machine to its final resting place with adequate floor foundationCustomer is responsible for adequate electric, air & dust control supply upon technician's request:Warranty: 1-yr mechanical parts (electrical controls excluded);Delivery to Customer's facility is approx 17 weeks from receipt of funds;Quote assumes customer will deliver material for testing & run-off procedures (if required);NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI RFPR 72/12 "HEAVY DUTY" MULTI-BLADE PANEL SAWSpecifications -- (1) 50 HP main arbor motor for 1/8" min. - 2" max. material thickness; 12" Dia max. blade capacity with 1.25" minimum spacing between the blades; Minimum panel length 30" & 72" of usable width cutting capacity. -- 3-15/16" Dia. arbor with 1-15/16" precision arbor bearings; positive powered steel contact feed rollers with (8) Polyurethane drive rollers; variable feed speed to max 80 FPM. -- (1) "Quick Change" arbor cart trolley and blade box for 9 1/2" cutsOn average this machine will cut a bundle (42 sheets) of 3/4" Plywood. LVL, PB, MDF or OSB into narrow strips in 4 minutes or less.Available Options: -- Blade Box Arbor Cart and Trolley $ 12,590.00 each -- Arbor Carts modifications to accept 12" dia. blades $ 700.00 each -- Single Point Height Adjustment $ 6,000.00 each -- "Quick Change" set up kit (includes belt guide, belt tensioner, and hydraulic arbor lock) $ 3,695.00 each -- Tandem 8000# capacity infeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt, 31" x 192" platform and cross bars for fork truck entry $ 14,495.00 each -- Tandem 8000# capacity outfeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt with 48" x 192" platform and beveled crossbars for fork truck entry and auto down indexing $ 16,390.00 eachTooling Cost: -- Carbide Tip Blades 12" x 40T x 4 3/16 bore with TCG and 3 pin holes $ 125.00 each -- Saw Blade Tooling Collars $ 125.00 each -- Actual Model is LAUDERDALE-HAMILTON RFPR "HEAVY DUTY" 12 Panel Rip SawNOTE: PRICING DOES NOT REFLECT FACTORY'S 7% MATERIALS SURCHARGE

LHI 96" x 60" ANGULAR TYPE RIP & CROSS-CUT SYSTEM: Specifications: -- Automatic Angular Rip & Crosscut 5-Position System; max. panel size of 8' (96") long x 5' (60") wide x 1" - 4" thick; 1.25" minimum spacing between the blades; variable feed speed from 0 - 150 FPM. This system will process a unit of material in approx. (7) Min. -- Pos. # 1: LHI Automatic Staging/Infeed/Transfer & Panel Rake Feeding System: 10' (120") Long, powered 3-chain staging conveyor; (2) units can be preloaded while (1) unit is in process. Automatic up-indexing 4,500 Lbs capacity Scissors Lift with auto. rake infeed system: infeed rake system designed with a thin material device that can automatically load material as thin a 1/8". -- Pos. # 2: LHI "72": 72" Arbor length designed for panels up to max. of 5' (60") wide, min. panel length 30"; 40 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation. 2-3/4" Dia. arbor with 1-15/16" "Fafnir" arbor bearings; positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia. vertical dust outlets with an easy access strip separator box. -- Pos. # 3: LHI Cross-Transfer System: Transfer conveyor with panel hold-down & chain drive system to change direction 90° & automatically feed LHI 102". -- Pos. # 4: LHI "102": 102" Arbor length designed for panels up to max. 8' (96") long; 30 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation; 2-3/4" dia. arbor with 1-15/16" "Fafnir" arbor bearings. Positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia vertical dust outlets with an easy access strip separator box. -- Pos. # 5: LHI Stacking & Outfeed Transfer System: Auto. down-indexing 4,500 Lbs cap. Scissor Lift; (4) adjustable alignment posts & (4) bin separators to keep processed stacks square. 98' (96") Long outfeed gravity conveyor.Operating System: -- (1) LHI ALLEN-BRADLEY "Inter-Link" PLC for simple single-operator management of the entire system from (1) central control.NOTE: ...Attached description & pictures are for INFO purposes only; ...a NEW System can be modified to your exact specifications!NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI RFPR-72/10 MULTI-BLADE PANEL SAW: Specifications: -- 40 HP main arbor motor; 1/8" min. - 1-1/4" max. material thickness; 10" dia blade with 1.25" minimum spacing between the blades; -- 3-15/16" Dia. arbor with 72" of usable width cutting capacity, min. panel length 30"; -- 1-15/16" precision arbor bearings; positive powered steel contact feed rollers; -- Fixed feed speed of 80 FPM. Blades & collars: -- Thin kerf 10" dia x 40-tooth x 4.18" bore non-split blades with quick & easy setup for fast blade positioning/removal (blades not included). -- Blades & collars are sold separately & not included in the machine price; 10" dia. x 40-tooth thin kerf blades, please add ...$ 105 ea.;1.25" wide x 4.18" bore blade collars, add ...$ 145 each. Complete with: -- (2) 4" dia dust collection ports on top and (1) 8" dust collection port on bottom. Total recommended 2,200 CFM -- Actual Model is LHI RFPR-72/10 Roll Feed Panel Saw. Available Options at additional cost: -- 110 V Infeed Scissor Lift with foot pedal controls or automatic up-indexing; 110 V Outfeed Scissor Lift with automatic down-indexing;Assortment of blade thicknesses & diameters; Split blade & collar system; Additional Options Depending on application: -- Main motor power from 30 - 75 HP; 4" Max. cutting height (requires 75 HP motor); -- Variable feed speed; Non-marking Polyurethane contact feed rollers; -- Additional arbors; "QUICK CHANGE" arbor system (see video); -- "Pigtail" quick change Crosscut Saw System.Many more tooling & configuration options available upon requestThis machine will cut a bundle (42 sheets) of 3/4" Plywood. PB, MDF or OSB into narrow strips in (4) minutes or less.NOTE: PRICING DOES NOT REFLECT FACTORY'S 7% MATERIALS SURCHARGE

LHI RFPR 102/10 MULTI-BLADE PANEL SAW: with 102" of usable width cutting capacity. Specifications: -- (1) 40 HP main arbor motor for 1/8" min. - 4-1/4" max. material thickness; min. panel length 30"; 102" of usable width cutting capacity. -- 12" Dia max. blade capacity; 1.25" minimum spacing between the blades; -- 3-15/16" Dia. arbor with 1-15/16" precision arbor bearings; -- Positive powered steel contact feed rollers with (8) Polyurethane drive rollers; fixed feed speed of 80 FPM. -- Includes (6) arbor collars - blades not included. -- Complete with:(2) 4" dia dust collection ports on top and (1) 8" dust collection port on bottom. Total recommended 2,200 CFM.Available Options: -- Blade Box & "Quick Change" Arbor Cart and Trolley $12,590.00 each -- Arbor Carts modifications to accept 12" dia. blades $700.00 each -- Single Point Height Adjustment $ 6,000.00 each -- "Quick Change" set up kit (includes belt guide, belt tensioner, and hydraulic arbor lock) $3,695.00 each -- Tandem 8000# capacity infeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt, 31" x 192" platform and cross bars for fork truck entry $14,495.00 each -- Tandem 8000# capacity outfeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt with 48" x 192" platform and beveled crossbars for fork truck entry and auto down indexing $16,390.00 each -- Drag Chain Feeder Conveyor - Roller conveyor transfers sheets to in-feed of saw and dog chains align and start the sheets into the saw feed rolls. Recommended with 102" wide machines, $18,800 Tooling Cost: -- Carbide Tip Blades 10" dia. x 40-tooth thin kerf blades $125.00 each -- Saw Blade Tooling Collars $125.00 eachOn average this machine will cut a bundle (42 sheets) of 3/4" Plywood. LVL, PB, MDF or OSB into narrow strips in 4 minutes or less.NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LIGNA 8X40 Multi-Blade Edger/Gang Saw. 40" Wide by 8" high opening. Specifications: -- Bottom saw edger with (5) blades. Powered by a 125 HP TEFC motor. -- Features stacked air cylinder setworks with independent shifting on (3) blades. -- Infeed table with pop-up chains and fence, outfeed rollcase. -- Includes: Powered infeed and outfeed steel roll conveyors.

MULTISCORE CD-4-30 CABINET GROOVER: -- Specifications:30" Wide x 50" long max. cap., 1" max. material thickness; 30 HP main motor; 3-15/16" dia. arbor @ 3,500 RPM; aluminum bedplate slotted at 1-1/2" spacing for about (20) tool positions; quick release tensioner on the arbor drive belts. -- Equipped with: Feed System: Reciprocating push fence with wood extension fingers to assure consistently square cuts; push fence carries the part through the entire cutting area completely past the arbor. Extension fingers are laterally adjustable for different cut widths. Pneumatic infeed plastic holdover fence laterally adj. to hold parts up against the fence. (8) Hold-down arms with lateral & vertical adjustment mount to a T-slot rack to press parts against the feed table during machining. -- Feed Drive/Speed: 2 HP - 1,750 RPM AC Inverter; variable feed motor via gear motor, with dynamic brake; 0 - 60 FPM. Features: -- Material is pushed off the exit side while machine operator can load new parts at the infeed table. Cutterhead assembly is end supported, adjustable up & down via handwheel, and jam nut tooling locking system. -- NOTE: This machine is currently setup for wainscoting and kitchen cabinet doors.
