Knife Grinders For Sale

CM&E Chipping Heads

CAM-WOOD TG-923 1:1 Profile Knife GrinderEconomical model built for shops with 1 or 3 Moulders or a series of Spindle Shapers.Features: -- Work table and cutterhead moves front to back and left and right. -- Table travels on linear bearing with cross roller rail sets. -- Table travel is designed for extreme accuracy. -- Template holder setup is fast and simple for copy tracer. -- Grinding angle is adjusted on dovetail ways. -- Grinding center DOES NOT change with knife angle adjustments. -- Includes stainless steel water splash guard, coolant tank; with pump and filter, easy and efficient to operate. -- Heavy steel cabinet and stand. -- Cast iron Grinder body. -- Built for high precision and durability.Specifications: -- Grinding Capacity: 12” dia. x 10” long. -- Grinding Wheel Size: 7.5" dia. with 60 mm bore. -- Grinding Head Travel: 13". -- Grinding Wheel Speed: infinitely variable from 1,500 to 4,500 RPM. -- Grinding Wheel Motor: 2 HP. -- Coolant Pump Motor: 1/8 HP. -- Net Weight: 1,100 Lbs.

Can-Car Knife Sharpener Serial# 1329-23-72

CANTEK JF-330A Profile Knife Grinder Clamping length of 12" (300 mm) for both straight and profile grind; dia. of knife swing 12" (300 mm). -- Grinding Arbor: 3 HP grinding motor with VFD (LED Readout) drive from 1.500 to 4.200 RPM. Quick change removable (140 mm) wheel adapter. Machine set for axial constant grinding and template set up on right-hand side.Over the wheel precision diamond dresser assembly for dressing and dimensioning of wheel. Manual positioning: of grinding wheel to tool; positioning of back clearance angle and side clearance angle 5°/10° and 15°. Quick change stylus turret for applications; (6) included with machine. -- Carriage: SCHNEEBERGER linear bearing table movement. Table movement 12" x 6". -- Coolant system: 1/8 HP motor from coolant pump located in the tank below; (3) coolant nozzles for smooth flow of coolant to knife rest during grinding. Additional hose with nozzle for cleanup. Stainless steel splash guards throughout! -- Includes: Set up tools, coolant, HD worklight, grinding wheels and (1) arbor of choice - (1.25", 1.5", 40mm, 1-13/16", 2.125" or 50 mm).

Capital Machine Co. Knife Grinder

CM&E Knife Grinder for CM&E chipping head-rig using bent knives. Many knives are available with grinder.

DIEHL - DMG -12, ...Profile GrinderSpecifications: -- 1/2" Width cap. and 10-1/2" max. cutting circle. -- 1 HP TEFC Motor with 2,260 RPM grinding spindle. -- (2) 1-13/16" Dia.; 16" X-axis & 6" Y-axis table movement. -- 30° Clockwise & 90° counterclockwise base swivel rotation for face grinding of profile cutters or planer knives. -- +30° to -30° Vertical grinding spindle adjustment. -- 2" In & out adjustment. -- 1" X-Axis & 1-7/8" Y-axis template adjustment. -- 7" Min. & 10" max. grinding wheel dia.Equipped with & Features: --Coolant pump with 5-gallon tank.

FOLEY-UNITED 7460 910 Profile Knife GrinderSpecifications: -- Capacity: 12" Max. cutting circle x 12" W. -- Table size 7” x 12” x 34-1/2” H. -- Table travel 12". -- Side clearance 5°, 10°, & 15°. -- Back relief angle 10° - 30°. -- Wheel O.D. 7" - 10", Wheel widths: 1/16", 1/8", & 3/16", Wheel arbor dia. 1-1/4".Equipped with: -- 2 HP - 2,850 RPM TEFC Wheelhead motor.Complete with: -- 40 mm (1.57") Dia. x 9-3/4" L Tool Arbor. -- Micro Precision Wheel Dressing System (MPDS), Swing-away.Dimensions of this specific machine 55" x 41" x 54" H.NOTE: No coolant pump.

Hammer Multi Duplex 400LJ Grinder ready to load!

Hanchett Grinder

34” capacity knife grinder

Newman G 132 Knife Sharpener

NEWMAN G-200 Knife Grinder - grinds 4 chipper knives up to 20" long or 8 planer knives.   Features automatic feed and flood coolant.

Newman G-200 Tub Knife Grinder s/n 200323

Newman G-123, SN; 12528, electric drive, 32" long bed, working condition

Newman G200 Knife Grinder

Newman G200 Knife Grinder

Precision 4 Knife Grinder

Reform 60" Magnetic Bed Knife Sharpener - Model AR15/51 high precision knife grinder.   Features magnetic knife clamping; 60" bed length; flood cooling; automatic feed; replaceable wear strips; self contained controls. See all of our other items at benjones.com Call or Email for Price: (706) 324-2604 [email protected]

Reform 2100 MM (82") Capacity Magnetic Bed Knife Sharpener - Features magnetic knife clamping; 82" bed length; flood cooling; automatic feed; replaceable wear strips; self contained controls.
