Sawmill Equipment For Sale

HMC AC40 Modular Carriage

HMC MDS50 Drop Saw Trimmer s/n 076-00

HOCKER POLYTECHNIK MULTISTAR Series Pulse Jet Baghouse. 33,000 CFM (56,000 M3/hr) based on 5.2 to 1 Air-to-cloth ratio (FPM - average air velocity thru filter media) with 6,345 square feet of filter area. -- Filtration: Filters are automatically cleaned by Pulse-Jet system based on supply of 1" dia. dried clean compressed air line from plant. Cleaning automatically controlled via timed cycles or by the Delta-P which is the differential pressure across the filter bags. -- Supplied with: (4) HOCKER DER 040/45022 radial BI fan each directly driven by 30 HP TEFC 3600 RPM high efficiency motors, mounted on the clean air side. Rated for a total of 33,000 CFM at 16" SP (4,000 Pa). Fan inlets are 18" (450 mm) dia. each. Non-return flap camper on the outlet side. -- Includes: Electrical panel with PLC controls; Explosion Relief Panels; Sprinkler heads in the clean air plenum, ATEX approved construction with 11-gauge electroplated galvanized steel shell with clean air outlet not returned to plant. -- Equipped with: (1) HP Rotary Air Lock. -- Control: SIEMENS SIMATIC TPI200 PLC controller housed in a floor-mounted central control panel with modem module for allowing HOCKER online access to assist in program changes, 12" TFT color, touch screen display. All starters and contacts for included motors. Pictorial guided navigation, and fault messages are displayed in text. Graphic images, curves, bar diagrams, parameter adjustment settings, and fault report. FI MF 22.0 kW SPS- ctrl allows start up of several fans one after the other. -- VFD drives on each motor with automatic motor tuning, automatic startup, min/max speed limits, DC brakes, operating hours meter, -- Includes: Access ladder to upper catwalk and exterior pipe. Heavy duty galvanized for outdoor operation. -- Professional dismantling and transportation available upon request.

Holmes Loader

HOLTEC Lumber  Trimmer. Manually trims bundles of lumber. Trims one end only. Manual setting of lumber bundles required. Bar & guard replaced; hydraulics tested; support frame, including steps, sand blasted and painted; electric motor drive checked; air cylinder and up-down of bar tested; manually operated saw assembly moves about 12". Offered as-is/where is. Price $14,600.00

HOLYTEK HP-11P Horizontal Resaw -- Hydraulic Feeding conveyor, hydraulic pump with 3 HP motor -- Main saw motor 20 hp. Specifications: -- Working width capacity 12“ (300 mm) -- Variable Feed Speed 0- 17 m/min (0 to 55 FPM) -- Thickness capacity 4mm to 125 mm (.11/8" to 4.92") -- Conveyor tilting 0 ° to 7° -- Electroni display of cutting height -- Blade Capacity 4270 X 25 X 0.89 mm. -- Wheels Diameter 725 mm -- Return conveyor on machine top

Holytek heavy duty band vertical resaw Model# HB-900H

Holzman 220 volt 15KW 3 Phase Gen Set

7' x 23' Honeyville Bag House Dust Collecting System with Blower & Stand 86 10' Tubes, Ready to Ship.

50' Honeyville Bucket Elevator

Honeyville 32" Blower with 12" in & 12" Out No Motor.

Honeyville bag house, includes filters, very good condition

Honeyville Metal baghouse is approx. 8' x 8', 72 - 5" x 60" bags, 11" x 13" inlet, 28" x 63" bottom outlet, includes blower and numerous pipes, good condition

Hurdle Circular Sawmill Mid 80s mill New Simmonds 54" blade 150 hp 3 phase 460 volt motor Track and carraige in good shape Includes Meadows twin blade edger Both blades moveable 30 hp 3 pahse 460 volt motor on edger Everything is in good working shape and lined up and cuts true

Hurdle 3 head-block circle mill, includes 4 blade Cedar Creek vertical edger, includes log deck, this mill is in good shape and ready for production

2017 Hurdle Automatic Sawmill on 48’ 3-beam platform, 3HB Magnum L T tong dog carriage: 40” knee openings, 29” d og openings. Variable tapering, tong dogs. Husk frame assembly w/offbearer belt. New larger sawyer’s cab w/AC. 555 Series feed. 3-strand log deck. HD chain log turner. Cant turner. Feed joystick. Nano setworks. Vertical edger w/laser lights. Top saw- includes adjustable saw guide, 36” saw blade, 30HP motor, and saw guard.

Hurdle 3 Head Block Circular Sawmill

Hurdle RH 3 Head Block Portable Mill Has Cab & Set Works & Carriage Drive, 150HP Motor, Renco 3 Saw Edger. It is Electric Over Air. Length of Track is 50' and Min Cut Length is 16' and Max Cut Length is 18'

Hurst Boiler System 1. 1- Used1995 200HP 150 PSI Hurst Hybrid Vessel 2. 1- Used 1995n refractory lined boiler furnace 3. 1- 8” underfeed stoker system 4. 1- 10” Fuel feed metering conveyor system 5. 1- Overfire air combustion fan with ductwork 6. 1- Underfire air combustion fan with ductwork 7. 1- Multi cyclone flyash collector 8. 1- Induced draft fan with exhaust stack 9. Muti cyclone and ID fan support steel with legs 10. Access platforms to boiler with ladders 11. Hurst open vented feedwater tank with 2 Grundfos feedwater pumps and control panel 12. Blowdown separator 13. Hurst Boiler control panel 14. Boiler piping parts 15. Boiler electrical parts 16.Equipment loaded onto trucks Optional: Fuel handling and storage supply system: Walking floor Vibrating Screen Screw conveyor Controls

Hurst Live Floor Feed System w/Controls, Hydraulic Pack & Auger Feed System
