Sawmill Equipment For Sale

LIGMATECH ZHR 01 RETURN CONVEYOR for RH FEED Edgebander (i.e. Brandt, OTT) & LH RETURN to the operator.FunctionAfter panels come off a through-feed machines feed-track, they are transported via (4) powered take-up belt onto a 90° transfer section and returned back to the operator.Specifications: -- Working Length, 12" - 98" (300 - 2,500 mm) max., working width 5.9" - 40" (150 - 800 mm) max., panel thickness 0.3" - 1.6" (8 - 40 mm) max. and 100 Lbs (45 kg) max. weight. -- Variable Feed-Speed, 26 - 138 FPM (8 - 42 MPM); Approx. total length of 30'; (4) 18" pickup arms, spaced 7", 8" & 14", take product from the edgebander and transport it to cross transfer conveyor section. -- Cross Transfer Section, 43-1/2" x 83", transfers material and drops it 2-1/2" onto roller transfer section, 43-1/2" x 83", which transfers material to a powered 40" x 150" flat-belt conveyor, which transfers material to a gravity roller conveyor, 40 x 72", with 2-1/2" x 35" plastic coated rollers to be received by the operator. -- Total Length of Return Conveyor is 25'. -- Actual Model is LIGMATECH ZHR 01-R-055.NOTE: (2) Photos show (3) Rollers/Feed Belts & Pusher Arms that are missing from the machine.

Ligmatech Return Conveyor

LIGNA 8X40 Multi-Blade Edger/Gang Saw. 40" Wide by 8" high opening. Specifications: -- Bottom saw edger with (5) blades. Powered by a 125 HP TEFC motor. -- Features stacked air cylinder setworks with independent shifting on (3) blades. -- Infeed table with pop-up chains and fence, outfeed rollcase. -- Includes: Powered infeed and outfeed steel roll conveyors.

LIGNA ALT Trimmer. OPERATOR ON RIGHT. Set up for "0" saw; from 8'  to 16' on 2' increments. Has 4' and 6' saw areas. 7.5 HP motor and saw blade on ladders. 9 feed chains--hydraulically driven. PLC controlled. Includes: operators controls and hydraulic power unit; 2 air operated gates; 5 strand tipple system with dealer wheels and air operated tipple arms; 9 feed chains--hydraulically driven; 5 strand let down conveyor; 5 infeed side, even-end rolls.  Doors need work but are included.  Offered, as removed from service. $36,000.

LIGNA rosserhead debarker, model 848. Complete machine with bull wheels, 50 HP head motor, head with cutter bits, operators controls. Good condition. Offered as-is / where-is but loaded on your truck.

8" x 48" Rosserhead debarker. Used very little, LIGNA Model 848, S/N: F162085. Heavy duty. 6 sets bull wheels mounted on 3 7/16" bearings, 36" on centers - (like new, not re-poured). 50 HP head motor powering 8 section carbide tooth head. Maximum length 20'. Base frame 12" WF beam. (6) x 1 1/2" thick kicker arms., 20 HP Hydraulic system for head traverse and log rotation. Heavy duty pivot system and electric panel included. Size approximately 35' x 9' wide x 7 1/2' tall. Operators controls. Machine in great condition, but has been sitting outside . Offered as-is / where-is and loaded on your truck. Price $36,000.00.

Ligna 16' Enddogging Scragg

(6) Available New Baoli 5K Lb All Terrain Forklifts

#311 • Linde H25T Forklift - Specifications & Features -- Year: na. Make: Linde. Model: H25 T. Serial #: H2X393T01179. Engine: Linde 2.0 L. Fuel: LP. Meter Reads: 23267. Stage Mast: 2. Mast Height: 91”. ROPS: Open. Tires: Solid. Tire Size: Front: 355/50-15, Rear: 23x9x10. Side Shift: yes. Fork Positioner: no. Fork Size: 4”x48”. Reach Height: 195.5. Load Capacity: 4655. -- Seller Statement -- Propane not included, Regularly maintained, in good working condition. -- Contact -- Auction Specialist: Jonathon Miller, 574-821-7530. General Inquiries, Payment, Bidding Direction, Registration, and Loadout: Main Office, (574) 825-0704. Financing: 1 (833) 458-6210

LMC 144FTD10 Pulse Jet Dust Collector with Rotary Airlock.24,000 CFM @ 14" SPWG, 10:1 air-to-cloth ratio, contains (144), 144" long bags @ 120" long (2400) sq feet filter area) pulse jet filter. --÷ Complete with: 270 BCS-SW TWIN CITY FAN, Air Handling, Class 17 belt-driven by 60 HPTEFC motor. Volume control damper on fan discharge. NOTE: Fan is 27" and undersized for 24K CFM as was running at lower ACR. Filter to fan ducting, support legs, access ladder, explosion relief panel, -- Includes: 110 V Timer board in NEMA-4 enclosure, GOYEN diaphraghm valves, compressed air header with drain, magnehelic differential pressure gauge 0" - 10" SPWG. -- Was installed with approx. 32" trunk line. Flanged inlet, outlet, and body; perimeter railing, galvanized bag cages with Venturi's, 16 oz. singed polyester filter bags. -- Comes with: 60° Hopper, access panel into hopper, gearmotor powered LMC Rotary Air Lock, easy lift lugs. Clean air plenum with top for filter bag service, service platform. Transfer Blower is included -- 12-Ga. carbon steel construction, enclosure rated to 17" SPWG, top access cover with side door for poor weather access. --÷ Filter Dimensions: 106" x 106" x 335" high. Ready to load on a truck.

Lobo Mdl TSP-10A 10ft Beam Panel Saw

Cut up to 36” diameter logs. Around 26’ long. Fully hydraulic. 19’1”x2 blades. Log loader, log roller. 75hp 3phase 480v Could easily made back diesel if need be. Set up stationary for best cutting results. Can easily be portable again, axles and tongue are still attached are in good condition.

Logmaster LM5 Sawmill 2" Blades 36" Max log diameter Hydraulic: Log loader, turner, log tapers 75 HP Electric Motor

LSI Right Hand 20' Drop Saw Trimmer with Even End Rollers

The LV series is specifically designed for “Low Voltage” applications that provide their own power supply. This unit features a wide spread switching power converter for applications that will accept both AC as well as DC power. As designed it has inherent reverse polarity, and surge protection, and features the industry standard M12 connector as standard. Great for control level industrial applications that require a hardwired connection. Ideal for Portable Sawmills, Bridge Saws, Industrial Automation, Control Level Power Installations, and much more! For complete specs and information, give us a call or visit our website!

The R series laser is the workhorse of our line. Low cost and well suited to many applications, the standard configuration includes a remote style AC PSU (PT#SA-115) to supply the necessary 5VDC to the unit. As always, the unit fits all of our mounting hardware and movable systems. Can also be purchased in the M12 configuration: for customers that are supplying their own 3-9VDC power. Ideal Applications: Board Edgers, Chop Saws, Part Alignment Fixtures, and Industrial Automation!

The SA-008 is a robust bracket for any mounting application that is fixed. It can be easily mounted to anything from wood beams, to steel, utilizing the mounting base that is included. The bracket is made from machined steel and aluminum here in the USA.

The SA-009 stationary bracket, also known as the “shift” bracket, is designed to clamp onto a shaft. It was designed primarily to attach to our shifting assemblies, but works very well in many other cases. Mounting Configuration: Clamping hole bored for .750? dia. shaft Can be used with our Shift Assemblies, SA-001 and SA-002

The SA-001 unison shift assembly is what is often referred to as “equidistant”. When one saw moves, the opposite saw moves with it, either apart, or together. Mounting Bolts Spacing: End plates, 2 ea 5/16? thru-bolts, 2.750? spacing End plate hole distance, same as ordered shaft length Lengths Available: 24? up to 72? Standard length 48? unless otherwise requested Lengths over 48? will incur additional per foot charges Included Installation Parts: 4 pcs Swivel block (routing) pullies 4- 5/16 x 1.5? mounting bolts with washers and nuts 2 pcs cable clamps 1/8? ac 50' ac cable You can also add an SA-009 stationary bracket to allow for a stationary saw. Unison Shift Assembly

MAC 120-MCF-572 High Capacity Baghouse Dust Collection system with Rotary Air Lock (RAL) and Medium-pressure Controlled air cleaning dust Filter (MCF). TWO systems are for sale with One common Control Panel. -- Baghouse Capacity: 50,000 CFM @ 7.2:1 Air-to-cloth ratio (ACR), approx. 6,921 sq-ft of filter area based on (572) Filter bags; 120" long x 5" dia. -- Equipped with: (1) AIR TECH size 402, BISW, Backward Inclined Air Handling Fan, Class IV, with 40" inlet, ground-mounted on unitary base, flanged inlet box & outlet. For prior application fan operating point (RPM/SP) is set up for about 41,526 CFM @ 12" WG at 1566 RPM, drawing 119 BHP. the fan is equipped with a variable volume damper on discharge. Fan range is about 40,000 - 55,000 CFM. Powered by a TOSHIBA 150 HP TEFC, 444T, 1800 RPM motor packaged with a belt drive -- Bag Cleaning: Mac "Never-Miss" Cleaning System with rotating arm, diaphragm valve for pulse cleaning Approx. 3 HP positive displacement (PD) pump for bag cleaning at only 7- 9 PSIG. 1 HP direct drive gear motor for distribution arm, integral manifold/surge tank, pneumatically controlled firing mechanism activating the diaphragm valves/nozzles. When cleaning arm & bag segments are correctly aligned air nozzles fire directly into bags without wasted cleaning air. -- Includes: MAC FS24x24 AIRLOCK Rotary Air Lock (RAL) with approx. 2 HP SYNCROGEAR MODULE gear motor; sprinkler package; 60° Cone-shaped hopper attached to MAC at bottom of cone. -- Features: (1) Floor-standing Electrical control panel (shared controls) with MOTORTRONICS Solid State AC Softstart for main 150 HP motor. -- Additional Features: Explosion vents. Summer/Winter diverter and return air ductwork. Support structure. Caged access ladder from ground Service Platform and to the top plenum. -- Baghouse constructed of 7 gauge carbon steel containment; one piece body all welded construction, 180" (15') diameter shell panelized unit, walk-in plenum for maintenance and bag replacement. -- MAC design features: MCF 4HVP Pump package. MCF Medium-pressure air requires less HP and yet offers high dust and air collecting efficiency with unmatched baghouse cleaning at lower operating cost. MCF pulses each bag the same number of times with the same amount of air. (Unlike some competitors which clean the inside rows of bags more often than necessary thus wasting energy, causes uneven pressure drop, and bag wear). -- (2) of these identical units for sale are installed per photos, Material handling fan/drive is also common for both Unts. -- Overall dimensions: 580.5" high x178.5" square frame with an estimated weight of filter unit (less structure and accessories) 31,000 Lbs. -- Professional dismantling/rigging, truck loading and transportation are available at extra cost. -- NOTE: The right-hand unit is at forefront.. The left-hand unit is not as easily accessible.
