Sawmill Equipment For Sale

Meadows #1 Automatic Circular Sawmill - Automatic Set Works - Hydraulic Log Turner - 4 Head Block Carriage - No Power - Ready to load Call 800-459-2148 for more info.

Meadows head saw with 4 head block carriage , computerized setworks, Corley cab, hydraulics and electric headsaw motor + 10 HP power pack $22,000 Delivered to your location. Call 800-459-2148 for more info.

Meadows sawmill New parts from MFG: Saw Arbor, Live belt conveyor, misc parts Computer setworks 225 HP Detroit Diesel

MEADOWS MILLS 120H Chain Log TurnerSpecifications: -- Hydraulic Cylinders: Two 2" x 12" with 1-1/2" diameter rod -- Turning Chain: #120 chain with 1" dog width and 13 bits -- Drive: H80TB13 sprocket with bushing, 80Q25 sprocket with bushing, #80 drive chain, and chain guard -- Drive Shaft: 2-3/16" diameter 1018 cold roll -- Idler Shaft: 2-3/16" diameter 1018 cold roll. Construction: -- Frame: Base constructed from 10" x 25.4 Lbs beam, feet constructed from 4" x 6" tubing, head frame: Constructed from 8" x 3" x 4" tubing -- Drive Motor: Charlyn 104-1253 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 12 GPM & 950 PSI -- Controls: not included in the base price

MEADOWS MILLS 100H CHAIN LOG TURNER -- Hydraulic Cylinders: One 2" x 12" with 1 1/2" rod -- Turning Chain: #100 chain with 3/4" dog width and 13 bits -- Drive: H60TB13 sprocket with bushing, H60SDS25 sprocket with bushing, #60 drive chain, and chain guard -- Drive Shaft: 1 11/16" diameter 1018 cold roll -- Idler Shaft: 1 11/16" diameter 1018 cold roll -- Frame: Base constructed from 3" x 4" tubing, uprights constructed from 8" channel and 4" channel, head frame constructed from 3" x 4" x 3/8" angle and various flat bar -- Drive Motor: Charlyn 103-1032 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 10 gpm & 950 psi -- Controls: not included in base price

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Hydraulic board edger, all push button functions, and variable feed speed with flow control -- Complete hydraulic power source belt driven from mandrel of edger, includes oil tank and oil cooler -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 20 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- One stationary saw collar and one shifting saw collar, each with a 16"; diameter split carbide saw -- 60 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed table and outfeed tables with dead rolls -- Laser lights aligned with each saw

6" X 54" MEADOWS "TITAN" Combination gang-edger with 100HP drive motor, 5 saws on gang side and 18" edger side movement. Door on right. Laser movement. 48" roll width infeed and push button controls. 20 HP hydraulic system. Outfeed belt, 14' long. Very good condition. Price:  $45,000.00

21' MEADOWS, green collecting chain, floored, 78 roof-top chain, 3' centers, 2 HP drive. $5,500.00

28' Sorting chain conveyor, 4'centers, 81X chain, electric drive. Price  $5,500.00

MEADOWS #1 Automatic Sawmill;Complete with the following components and features: -- 15' Long 4 HB Carriage. -- Operator’s Cab, . -- Drive & Turner. -- Computer Setworks. -- YAMANI 4" Band Headrig. -- MEADOWS Titan 4" combo Edger also new in 2001; -- 30' x 24" Live Rolls. -- Electrical Switchgear. -- 33" Dia max. log. -- Capacity: 6,000 to 8,000 BF per day.NOTES: &#9679 Can be seen in operation.

Meadows board edger, 4" thick x 66" wide capacity, infeed rollers, outfeed is a tilt table, line-shaft ready, 2 blades-1 is movable, good working condition

Meadows Circular Sawmill 1 million + board feet per year 56" blade with new bits and shanks New factory built saw arbor and bearings from Meadows New factory built live feed conveyor Computer setworks 225 hp Detroit Some hydraulic hoses and wiring could be replaced Was making crossties

Meadows Gang Edger

MEADOWS MILLS 2-STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 4 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 2 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Handset board edger, all mechanical functions, and fixed feed speed -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 14 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- Unison shifting saw collars, each with a 16"; diameter split carbide saw -- 30 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed table with dead rolls -- Tailing device up to 16' long added to outfeed -- Laser lights aligned with each saw

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Handset board edger, all mechanical functions, and fixed feed speed -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 20 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- One stationary saw collar and one shifting saw collar, each with a 16"; diameter split carbide saw -- 30 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed and outfeed tables with dead rolls -- Laser lights aligned with each saw
